Grundig BP101U User manual

INSTRUCTIONMANUAL
BEDIENUNGSANLEITUNG
MANUELD'UTILISATION
GEBRUIKSAANWIJZING

UK: Digital Blood pressure monitor
DE: Digitales Blutdruckmessgerät
FR: Tensiomètre numérique
NL: Digitale bloeddrukmeter
Fully Automatic Upper Arm Style
Digital Blood Pressure Monitor
Model No.: BP101U
Item number: 871125208143
© copyright Edco Deutschland GmbH
Siemensstr. 81 47588 Kleve
Deutschland.
Item number: 871125208143
©copyright Edco Deutschland GmbH
Siemensstr. 31 47533 Kleve
Deutschland.
871125208143.indd 1 14-03-18 14:53

UK: Digital Blood pressure monitor
• Thanks for choosing the Digital Blood Pressure Monitor.
• Please read this instruction manual before using your unit.
• Please keep this instruction manual safe for future use.
Introduction
• Thank you for purchasing Fully Automatic Upper Arm Style Digital Blood Pressure Monitor.
• The unit uses the oscillometric method of blood pressure measurement. It means the unit detects
the movement of your blood through your brachial artery, and converts your blood pressure into a
digital reading. The unit is simple to use because a stethoscope is not needed while using an
oscillometric monitor.
• The unit stores automatically 2X90 sets of measurement values.
• You can read the stored data conveniently by pressing the memory button.
• The unit comes with the following components:
- Main Unit
- Arm Cuff
- Instruction Manual printed in English
Symbols Used
SYMBOLS USED IN THIS INSTRUCTION MANUAL
Warning
Indicates a potentially hazardous situation which,
if not avoided, could result in death or serious
injury.
Caution
Indicates a potentially hazardous situation which,
if not avoided, may result in minor or moderate
injury to the user or patient or damage to the
equipment or other property.
AUTHORISED REPRESENTATIVE IN THE
EUROPEAN COMMUNITY
Transport Package shall be kept away from rain.
Refer to instruction manual/booklet
MANUFACTURER
SERIAL NUMBER
The marking of electrical and electronics devices
according to Directive 2002/96/EC.
The device, accessories and the packaging have
to be disposed of waste correctly at the end of
the usage. Please follow Local Ordinances or
Regulations for disposal.
Warning and Safety Notices
To assure the correct use of the product basic safety measures should always be followed
including the precautions listed below:
• Read all information in the instruction manual and any other literature included in the box before
using the unit.
• Contact your physician for specific information about your blood pressure. Self-diagnosis and
treatment using measured results may be dangerous. Follow the instructions of your healthcare
provider.
• Operate the unit only as intended. Don't use for any other purpose.
• The unit is intended to use in measuring blood pressure and pulse rate for adult only, not
recommended for neonatal baby at home or medical center.
• Do not use a cellular phone near the unit. It may result in operational failure.
• Please avoid using in high radiant area in order to make your measuring data correctly.
• Do not disassemble or attempt to repair the unit or components.
• Do not use the equipment where flammable gas (such as anesthetic gas, oxygen or hydrogen) or
flammable liquid (such as alcohol) are present.
• Do not use a mobile phone or other devices that emit electromagnetic fields, near the unit. This
may result in incorrect operation of the unit.
• Indicating that too frequent measurements can cause injury to the PATIENT due to blood flow
interference;
871125208143.indd 2 14-03-18 14:53

• Remove the batteries if the unit will not be used for Three months or More.
• Regarding the application of the CUFF over a wound, as this can cause further injury;
• Regarding the effect of blood flow interference and resulting harmful injury to the PATIENT
caused by continuous CUFF pressure due to connection tubing kinking;
• Regarding the application of the CUFF and its pressurization on any limb where intravascular
access or therapy, or an arteriovenous (A-V) shunt, is present because of temporary interference
to blood flow and could result in injury to the PATIENT;
• Regarding the application of the CUFF and its pressurization on the arm on the side of a
mastectomy;
• Regarding the information that pressurization of the CUFF can temporarily cause loss of function
of simultaneously used monitoring
• ME EQUIPMENT on the same limb;
• Regarding the need to check (for example, by observation of the limb concerned) that operation
of the AUTOMATED SPHYGMOMANOMETER does not result in prolonged impairment of the
circulation of the blood of the PATIENT.
• When the arm is oppressed by air pressure, please loosen CUFF or remove batteries.
• Not touch the patient and battery output simultaneously when measurement.
• Warning: not allow to use the luer connectors. If Luer lock connectors are used in the construction
of tubing, there is a possibility that they might be inadvertently connected to intravascular fluid
systems, allowing air to be pumped into a blood vessel.
Know Your Unit
Body
Display
Display
Memory Button
Setting Button
START/ STOP Button
Air Socket
Battery Compartment
Systolic Blood Pressure
Diastolic Blood Pressure
Average Value Symbol
Unit Indicator
Pulse
Heartbeat Symbol
Battery Indicator
Inflation/ Deflation Symbol
or WHO Indicator
User Symbol
Memory & Times
Date/ Time
Irregular Heartbeat Symbol
871125208143.indd 3 14-03-18 14:53

Arm Cuff
• Fit for 22cm~36cm range of upper arm perimeter.
If your arm cuff is broken or not functional. Please use a new cuff.
A new arm cuff does not include an air plug. Please continue to use the old air plug on the new
arm cuff.
Power
• 3 x AA Alkaline Batteries
Instruction Manual
• Please keep the instruction manual well after using.
Warning: Do not use rechargable batteries.
Quick Refrence Guide
1. Please take off thick clothing and keep yourself quiet for 5~10 minutes before taking a
measurement.
2. Remove all clothes from your upper arm allowing the cuff to fit directly on the skin.
Proper posture
Keep your body straight and relaxing.
Proper height
At the same level as your heart
Proper wrapping
Wrap the cuff tightly on the skin
Air Plug
(Insert to Air Socket)
Hose
Metal
871125208143.indd 4 14-03-18 14:53

3. Wrap your upper arm with the cuff. The hose runs down the inside of your arm. The bottom
of the cuff should be approximately 1~2cm above your elbow.
4. Wrap the cuff tightly around your upper arm by using the Velcro strip. Do not leave any spacing
between the arm and the cuff.
5. Press the START/ STOP button. All symbols appear, then the cuff starts to inflate automatically.
6. The blood pressure and pulse rate are displayed when the measurement is completed, and the
arm cuff deflates completely.
871125208143.indd 5 14-03-18 14:53

Battery Installation/ Replacement
1. Remove the battery cover from the battery compartment.
2. Install 3 “AA” size batteries so the + (positive) and - (negative) polarities match the polarities of the
battery compartment as indicated.
3. Replace the battery cover.
The battery cover will be closed tight when you hear a clicking sound.
• Do not use rechargeable batteries.
• Use three identical 1.5V alkaline batteries type AA/LR06.
• Replace both of the batteries if the symbol of low battery appears on the
display.
• Never leave any low battery in the battery compartment since they may leak
and cause damage to the unit.
• Disposal of used batteries should be carried out in accordance with the
national regulations for the disposal of batteries.
Adjusting Settings
1. To Set Year
1.1 All information will appear when the batteries are installed at the first time. After
2 seconds the year flashes. Finally, press the “SET” button and continue with step 2.
871125208143.indd 6 14-03-18 14:53

1.2 The mark of year appears and flashes after press the “SET” Setting button for 3~4 seconds,
while the unit is off. Finally, press the “SET” button again and continue with step 2.
Press the “MEM” button to increase one year. Long press the button and the value quickly
changes
Year Setting
The year can be set between 2015 and 2050, and it will return to 2015 when the display of year
up to 2050.
2. To Set Date & Time
Press the “MEM” button to change the month and press the “SET” button and continue with next
step. Then set the day, the hour and the minute by using the same way. Continue with step 3.
Month Setting
Day Setting
Hour Setting
Minute Setting
871125208143.indd 7 14-03-18 14:53

3. To Set the 12 Hour or the 24 Hour
• Then press the “MEM” button again to change the current the 12 hour or the 24 hour.
• Press the “SET” button again and Continue with step 4.
The 12 hour or the 24 hour Setting
4. To Set Unit
• Then press the “MEM” button again to change the current unit.
• Press the “START/ STOP” button to save the current setting and turn off.
Unit Setting kPa & mmHg
You can stop setting anytime when you press the “START/ STOP” button to save the current
setting and turn off.
5. To Set User
The mark of a user will appear when pressing the “SET” button, then press the “SET” button again
to change the current user. Finally, press the “START/ STOP” button to confirm user and turn off.
12 hour format
24 hour format
“mmHg” display
“kPa” display
871125208143.indd 8 14-03-18 14:53

Before Taking a Measurement
1. Avoid eating, drinking alcohol, smoking, exercising and bathing for 30 minutes before taking a
measurement and 5 minutes should elapse before the first reading is taken.
2. Stress raises blood pressure. Avoid taking measurements during stressful times. Relax as much
as possible and no talking during the measurement procedure.
3. The cuff can be applied to your left or right Arm. Always measure your blood pressure on the
same Arm.
4. Measurements should be taken in a quiet place.
5. Position the unit at heart level throughout the measurement.
6. Keep a record of your blood pressure and pulse readings for your physician. A single
measurement does not provide an accurate indication of your true blood pressure. You need to
take and record several readings over a period of time. Try to measure your blood pressure at the
same time each day for consistency.
7. Wait 30~60 seconds between measurements. The wait time allows the arteries to return to the
condition prior to taking the blood pressure measurement. You may need to increase the wait
time depending on your individual physiological characteristics.
Proper Use of the Arm Cuff
How to Use the Arm Cuff
1. Make sure the air plug is inserted properly in the main unit.
2. Remove all clothes from your upper arm allowing the cuff to fit directly on the skin.
3. Sit in a chair with your feet flat on the floor. Place your arm on a table so as to level the cuff to
your heart.
4. Pass the end of the cuff through the metal, and keep the hose outward.
871125208143.indd 9 14-03-18 14:53

5. Put your arm through the loop, then pull it up to the position of your upper arm.
6. The hose runs down the inside of your arm. The bottom of the cuff should be approximately
1~2cm above your elbow.
7. Wrap the cuff properly around your upper arm. Not more than 2-finger-room allowed between the
cuff and your arm.
8. Have your upper arm relax, keep your palm upwarp and your fingers curving naturally, then turn
on the unit and start to measure.
871125208143.indd 10 14-03-18 14:53

Take a Measurement
How to Take a Measurement
1. Press the START/ STOP button.
All display symbols appear on the screen, the cuff starts to inflate automatically.
2. Inflation stop automatically and the measurement is started.
The heartbeat symbol flashes once a pulse is detected.
3. The blood pressure and pulse rate are displayed when the measurement completed.
The cuff is deflated automatically, and the measurement results are stored in the memory with date
and time. The IHB symbol will be displayed if irregular heartbeat is detected.
4. Press the “START/ STOP” button to turn off the unit.
The unit will automatically turn off after 2 minutes if you have forgotten to turn off it.
To stop the inflation or measurement, press the “START/ STOP” button in anytime, the unit will stop
inflating and then release and turn off.
All Symbols Display
Deflating Automatically
Start to Inflate
Start to Inflate
Inflating
Maximum Inflation
“kPa” Display
“mmHg” Display
“IHB” Display
871125208143.indd 11 14-03-18 14:53

Use the Memory Function
• The unit stores the blood pressure and pulse rate in the memory after completing a measurement
every time. It can automatically store 90 sets of measurement values. The oldest record is deleted
to save the latest measurement value when more than 90 sets.
• The unit also calculates an average reading based on the values of the latest 3 times
measurement taken.
• To Read the Average Value
§ Press the “MEM” Memory button, the average value will display.
• To Display the Measurement Values
§ Press the “MEM” Memory button to view the latest measurement value with the measuring
date and time.
§ Press the “SET” Setting button to view the oldest recorded value with the measuring date and
time.
§ Long press the button and the value quickly changes.
Unit Setting (kPa or mmHg)
Long press the memory button for 3~4 seconds until the units displayed when the unit powered off.
To Delete the Memory Value
In the memory reading mode, press the “SET” Memory button for 4-6 seconds the unit will display “
”
Press the “SET” Memory button again and LCD will display “ ”
If you are sure all the data of corresponding user can be deleted, press the “START/STOP” button, all
the corresponding user’s data will be deleted and the unit will turn off.
Note” If you have set “ ”, but do not press a button for 2 minutes, the product will shut off
automatically, but the corresponding user’s blood pressure data will not be deleted. The delete
operation must be confirmed by user.
Turn to Next
The average value of the latest
3 times measurement taken
Forward
Backward
Alternating Display
The 1
st
Latest
Measurement Value
The 2
nd
Latest
Measurement Value
The 90
th
Latest
Measurement Value
Alternative
871125208143.indd 12 14-03-18 14:53

About Blood Pressure
Irregular Heartbeat Symbol (IHB)
When the unit detects an irregular rhythm two or more times during the measurement, the Irregular
Heartbeat Symbol will appear on the display with the measurement values.
An irregular heartbeat rhythm is defined as a rhythm that is more than 25% slower or 25% faster from
the average rhythm detected while the monitor is measuring the systolic blood pressure and the
diastolic blood pressure.
If the Irregular Heartbeat Symbol (IHB) displays with your measurement results, we recommend you
consult your physician.
Follow the directions of your doctor
About Blood Pressure
Blood Circulation
The blood circulation is responsible for supplying the body with oxygen. Blood pressure is the
pressure exerted on the arteries.
The systolic blood pressure value (higher pressure or top value) represents the blood pressure
produced by contraction of the heart muscle.
The diastolic blood pressure value (lower pressure or lower value) represents the blood pressure
produced by relaxation of the heart muscle.
Health and Blood Pressure
The incidence of hypertension increases with age. In addition, a lack of exercise, excess body fat and
high levels of cholesterol (LDL), which sticks to the inside in blood vessels, reduces elasticity of these
vessels. Hypertension accelerates arterial sclerosis which can lead to very serious conditions such as
stroke and myocardial infarction. For these reasons it is very important to know whether the blood
pressure is within a healthy range. Blood pressure fluctuates from minute to minute, throughout the
day. Therefore, it is essential to take regular measurements to help you identify an average blood
pressure.
Normal Heartbeat
Irregular Heartbeat
Pulse
Blood Pressure
Pulse
Blood Pressure
Short
Long
Systolic Blood Pressure
Diastolic Blood
Pressure
Contraction of the heart muscle
Extrude Blood
Pressure Increased
to the blood vessel
High Pressure
Relaxation of the heart muscle
Blood return heart
Pressure decreased to the blood
vessel
Lower Pressure
871125208143.indd 13 14-03-18 14:53

Classification of Blood Pressure
After each measurement is completed, the LCD display will show your position automatically on the
six segments of the bar indicator which corresponds to World Health Organization (WHO) Blood
Pressure Indicator.
Reference Material: Journal of Hypertension 1999, Vol 17 No.2
*NOTE! When a person’s systolic and diastolic pressures fall into different categories,
the higher category should apply.
Classification of Blood Pressure
Symptoms of High Blood Pressure
High blood pressure can go unnoticed for a long time, since it doesn’t cause noticeable symptoms.
The following are all possible causes of abnormally high blood pressure:
• Overweight;
• High cholesterol value;
• Smoking;
• Excessive alcohol consumption;
• Stress and emotional upset;
• Excessive consumption of salt;
• Lack of physical exercise;
• Genetic/ hereditary predisposition;
• Underlying illnesses, such as kidney disorders or endocrine disturbance.
Upper Curve: Systolic Blood Pressure
Lower Curve: Diastolic Blood Pressure
Time of the Day
Diastolic
Blood
Pressure
(mmHg)
Severe hypertension
Moderate hypertension
Mild hypertension
Normal systolic value
Normal blood pressure
Optimal blood
pressure (target
value)
Systolic Blood
Pressure (mmHg)
871125208143.indd 14 14-03-18 14:53

Treatment of High Blood Pressure
If your blood pressure reaches upper values of 140~160 mmHg and lower values of 90~95 mmHg in
repeated measurements over several days, you should consult your doctor for detailed medical
examination. You can assist the treatment prescribed by your doctor in the following ways:
• Lose weight and lower your cholesterol level;
• Reduce the consumption of alcohol;
• Reduce the intake of salt;
• Stop smoking;
• Take regular exercise;
• Monitor your blood pressure.
Troubleshooting & Maintenance
Error Indicators
• The following symbol will appear on the display when measuring abnormal.
Eliminate Fault
Problem
Causes and Solutions
No power.
Replace all the worn batteries with 3 new ones.
No display appears on the display
screen.
Check the battery installation for proper placement
of the batteries polarities.
Measurement values appear too high or
too low.
Blood pressure varies constantly. Many factors
including stress, time of day, how you wrap the cuff,
may affect your blood pressure. Review the sections
"Proper Use of the Arm Cuff" and "Take a
Measurement".
Troubleshooting and Maintenance
To protect your unit from damage, please observe the following:
• Do not disassemble the unit.
• Do not fold the cuff or tubing tightly.
• Do not wash the cuff or immerse it in water.
• Do not use volatile liquids to clean the main unit.
• Do not use petrol, thinners or similar solvents to clean the cuff.
• Do not subject the unit to strong shocks or vibrations (for example, dropping the unit on the floor).
• Do not subject the main unit and the cuff to extreme temperatures, humidity, moisture or direct
sunlight
• Do not carry out repairs of any kind yourself, if a defect occurs.
• Please contact the local distributor.
If needed, please use ultraviolet radiation for disinfection.
Symbol
Cause
Correction
The course of inflating appears
error.
Wrap the cuff correctly and tightly.
Ensure the connection is close
between the air plug and the unit.
Inflate over again after ensuring.
When measurement fails.
Do not move your arm and body, and
keep quiet.
Measure over again according to correct
way.
When the batteries power is too
low.
Replace all of the worn batteries with
new ones.
871125208143.indd 15 14-03-18 14:53

• The unit should be cleaned with a soft, dry cloth.
• Use a soft, moistened cloth and soap to clean the arm cuff.
• Substitution of a cuff different from that supplied might result in measurement error.
• We will provide circuit diagrams, component part lists, descriptions, calibration instructions, or
other information to assist service personnel to repair parts.
• The service personnel need to be the personnel who is trained by the manufacture and has got
the relevant qualification certificate.
• The accuracy of this blood pressure monitor has been carefully tested and is designed for a long
service life. We recommend that the performance be checked every 2 years and after
maintenance and repair, by utilizing the manometer mode and verifying the accuracy of the
manometer at least at 50 mmHg (6,7kPa) and 200 mmHg(26,7kPa). Please contact the local
distributor for details.
Specifications
Statement
• The unit is intended to be used to measure blood pressure (systolic and diastolic) and heart rate
from the upper arm by using the oscillometric method.
• The unit is intended for using in only adult population, not applied to the other populations such as
neonatal baby.
• It can’t be used while the wrist (arm) has bleeding or wound to avoid the blood flowing from the
wound in pressurizing.
• The device, part and batteries have to be disposed of waste correctly at the end of the usage.
• Please follow Local Ordinances or Regulations for disposal.
• Applied part: CUFF.
• Protection Class: Internally powered equipment.
• Applied Part Type: Type BF.
• Moisture Protection: IPX0, continue operation.
altitude<2000m;
Model No.
BP101U
Display
LCD Digital Display
Measuring Principle
Oscillometric Method
Measurement Localization
Upper Arm
Measurement
Pressure
0 ~ 299 mmHg (0~39.9 kPa)
Range
Pulse
40 ~180 Pulses/min
Accuracy
Pressure
+3 mmHg (0.4kPa)
Pulse
+5% of reading
LCD Indication
Pressure
3 Digits Display of mmHg or kPa
Pulse
3 Digits Display
Symbol
Memory/Heartbeat/Low Battery/IHB, etc.
Inflation
Automatic by Internal Pump
Deflation Automatic by Air Valve
Rapid Air Release
Automatic by Air Valve
Memory Function 2 x 90 Sets of Measurement Values
Power Source
3 AA Alkaline Batteries; D.C.6V
Automatic Power-Off In 2 Minutes
Main Unit Weight
Approx. 290g (Batteries not included)
Cuff
Soft Arm Cuff
Device Life
2 Years
Accessorial Components
Cuff, Instruction Manual
Main Unit Weight
Approx 105 g (Batteries not included)
Operating Environment
Temperature
10~40°C (50 ~ 104 °F)
Humidity 15 ~ 90% RH(Noncondensing)
Barometric Pressure
80~105 kPa
Transport Storage Environment Temperature -20~60 °C (-4 ~ 140 °F)
Humidity
10 ~ 95% RH (Noncondensing)
Note: Subject to technical modification without prior notice.
871125208143.indd 16 14-03-18 14:53

overvoltage: Il;
pollution degree:2
• The risk of patient and user can be lowered to acceptable level.
• The unit might not meet its performance specification if stored or
• Used outside the following specified temperature, humidity and Altitude ranges.
• The unit satisfies the requirements of IEC60601-1 Medical electrical equipment,
IEC 60601-1-2: Electromagnetic compatibility –Requirements and tests
IEC 80601-2-30: Non-invasive sphygmomanometers - Part 1: Requirements and test methods for
non-automated measurement
Type EN 1060-3: Non-invasive sphygmomanometers - Part 3: Supplementary requirements for
electro-mechanical blood pressure measuring systems
EMC Table
• Guidance and manufacture’s declaration
GUIDANCE AND MANUFACTURE’S DECLARATION – ELECTROMAGNETIC EMISSION
The Digital Blood Pressure Monitor is intended for use in the electromagnetic environment specified below. The
customer of the user of the Digital Blood Pressure Monitor should assure that it is used in such an
environment.
Emission test
Compliance
Electromagnetic environment – guidance
RF emissions CISPR 11 Group 1
The Digital Blood Pressure Monitor use RF energy
only for its internal function. Therefore, its RF
emissions are very low and are not likely to cause
any interference in nearby electronic equipment.
RF emission CISPR 11
Class B
The Digital Blood Pressure Monitor is suitable for
use in all establishments other than domestic and
those directly connected to the public low-voltage
power supply network that supplies buildings used
for domestic purposes.
Harmonic Emissions IEC 61000-3-2
Not
applicable
Voltage fluctuations/ flicker emissions
IEC 61000-3-3
Not
applicable
GUIDANCE AND MANUFACTURE’S DECLARATION – ELECTROMAGNETIC IMMUNITY
The Digital Blood Pressure Monitor is intended for use in the electromagnetic environment specified below. The
customer or the user of Digital Blood Pressure Monitor should assure that it is used in such an environment.
Immunity test
IEC 60601 test
level
Compliance
level
Electromagnetic environment - guidance
Electrostatic
discharge (ESD)
IEC 61000-4-2
±6 kV contact
±8 kV air
±6 kV contact
±8 kV air
Floors should be wood, concrete or ceramic tile. If floor
is covered with synthetic material, the relative humidity
should be at least 30%.
Power frequency
(50Hz/60Hz)
magnetic field IEC
61000-4-8
3A/m 3A/m
Power frequency magnetic fields should be at levels
characteristic of a typical location in a typical
commercial or hospital environment.
Note: UT is the a.c. mains voltage prior to application of the test level
871125208143.indd 17 14-03-18 14:53

GUIDANCE AND MANUFACTURE’S DECLARATION – ELECTROMAGNETIC IMMUNITY
The Digital Blood Pressure Monitor is intended for use in the electromagnetic environment specified below. The
customer or the user of Digital Blood Pressure Monitor should assure that it is used in such an environment.
Immunity test
IEC 60601 test
level
Compliance
level
Electromagnetic environment - guidance
Radiated RF
IEC 61000-4-3
3A/m
80 MHz to 2.5
GHz
3A/m
Portable and mobile RF communications equipment
should be used no closer to any part of the Digital
Blood Pressure Monitor, including cables, than the
recommended separation distance calculated from the
equation applicable to the frequency of the transmitter.
Recommended separation distance
d=1.167  80 MHz to 800 MHz
d=2.333  800 MHz to 2.5 GHz
Where P is the maximum output power rating of the
transmitter in watts (W) according to the transmitter
manufacturer and d is the recommended separation
distance in meters (m).
Field strengths from fixed RF transmitters,
as determined by an electromagnetic site
survey, a should be less than the compliance level
in each frequency range. b Interference may occur
in the vicinity of equipment marked with the
following symbol:
NOTE 1: At 80 MHz and 800 MHz, the higher frequency range applies.
NOTE 2: These guidelines may not apply in all situations. Electromagnetic propagation is affected by
absorption and reflection from structures, objects and people.
aField strengths from fixed transmitters, such as base stations for radio (cellular/cordless)
telephones and land mobile radios, amateur radio, AM and FM radio broadcast and TV
broadcast cannot be predicted theoretically with accuracy. To assess the electromagnetic
environment due to fixed RF transmitters, an electromagnetic site survey should be
considered. If the measured field strength in the location in which the Digital Blood Pressure
Monitor is used exceeds the applicable RF compliance level above, the Digital Blood
Pressure Monitor should be observed to verify normal operation. If abnormal performance is
observed, additional measures may be necessary, such as reorienting or relocating the
Digital Blood Pressure Monitor.
b
Over the frequency range 150 KHz to 80 MHz, field strengths should be less than 3V/m.
RECOMMENDED SEPARATION DISTANCES BETWEEN
PORTABLE AND MOBILE RF COMMUNICATIONS EQUIPMENT AND THE DIGITAL BLOOD PRESSURE
MONITOR.
Pressure Monitor is intended for use in an electromagnetic environment in which radiated RF disturbances are
controlled. The customer or the user of the Digital Blood Pressure Monitor can help prevent electromagnetic
interference by maintaining a minimum distance between portable and mobile RF communications equipment
(transmitters) and the Digital Blood Pressure Monitor as recommended below, according to the maximum
output power of the communications equipment.
Output power of transmitter
Separation distance according to frequency of transmitter(m)
80 MHz to 800 MHz
d=1.167 
800 MHz to 2.5 MHz
d=2.333 
0.01
0.117
0.233
0.1
0.369
0.738
1
1.167
2.333
10
3.689
7.379
100
11.667
23.333
For transmitters rated at a maximum output power not listed above, the recommended separation distance d in
meters (m) can be estimated using the equation applicable to the frequency of the transmitter, where P is the
maximum output power rating of the transmitter in watts (W) according to the transmitter manufacturer.
NOTE l: At 80 MHz and 800 MHz the separation distance for the higher frequency range applies.
NOTE 2: These guidelines may not apply in all situations. Electromagnetic propagation is affected by
absorption and reflection from structures, objects and people.
871125208143.indd 18 14-03-18 14:53

Warranty Information:
• The unit, excluding the unit cuff, is guaranteed to be free of defects in workmanship and materials
for a period of two years from the date listed on the purchase record, when used in accordance
with the instructions provided with the unit. The unit cuff is warranted to be free from defects in
materials and
• workmanship appearing within one year from the date listed on the purchase record when the unit
is used in accordance with the instructions provided with the unit.
• This guarantee does not cover damage incurred by use of the unit not in accordance with the
instructions, accidental damage, or being tampered with or serviced by unauthorized service
agents.
• For repair under this warranty. Our authorized service agent must be advised of the fault within
the period of the warranty. This warranty covers parts and labor only under normal operations. A
transportation fee or freight fee that may be incurred will be the owner’s responsibility. Any defect
resulting from natural causes, e.g., flood, hurricane etc., is not within this guarantee.
• Unit subjected to misuse, abuse, and neglect of these manual contents, non-instructional
purposes; unauthorized repair or modifications will be excluded from this warranty. This
guarantee specifically excludes expendables and consumables, for example batteries. All
warranty claims must be directed to the distributor responsible for the sale of the device. The
content of this warranty is subject to change without further notice.
• WARNING: No modification of this equipment is allowed.
871125208143.indd 19 14-03-18 14:53
