LCD TELEVISION SETS VISION 9 VISION 7 VISION 9 VISION 7 VISION 6 VISION 6
47-9870 T 47-7851 T 42-9870 T 42-7851 T 42-6840 T 42-6831 T
Display Active Matrix TFT-LC-Display Active Matrix TFT-LC-Display Active Matrix TFT-LC-Display Active Matrix TFT-LC-Display Active Matrix TFT-LC-Display Active Matrix TFT-LC-Display
Screen diagonal inches 47 47 42 42 42 42
16:9 wide-screen format • • • • • •
Response time approx. ms 5 5 5 5 8 8
Brightness approx. cd/m2500 500 500 500 500 500
Contrast ratio approx. 40000 : 1 (Dynamic Contrast Plus) 20000 : 1 (Dynamic Contrast Plus) 40000 : 1 (Dynamic Contrast Plus) 15000 : 1 (Dynamic Contrast Plus) 12000 : 1 (Dynamic Contrast Plus) 12000 : 1 (Dynamic Contrast Plus)
Viewing angle approx. Super Wide Super Wide Super Wide Super Wide Super Wide Super Wide
Resolution RGB pixel WUXGA 1920 x 1080 (Full HD) WUXGA 1920 x 1080 (Full HD) WUXGA 1920 x 1080 (Full HD) WUXGA 1920 x 1080 (Full HD) WXGA 1366 x 768 WXGA 1366 x 768
HD ready • • • • • •
100 Hz technology • – • – – –
Motion Picture Improvement • – • – – –
Perfect Picture Plus technology • • • • • •
Digital combfilter (3-D) • • • • • •
Digital Colour Transition Improvement (DCTI) • • • • • •
Digital Luminance Transition Improvement (DLTI) • • • • • •
Digital Noise Reduction (DNR) • • • • • •
INTEGRATED DVB-T RECEPTION
Digital TV reception via antenna (DVB-T) • • • • • MPEG 4 •
Digital TV reception via satellite (DVB-S) to retrofit by a Grundig micro receiver to retrofit by a Grundig micro receiver to retrofit by a Grundig micro receiver to retrofit by a Grundig micro receiver to retrofit by a Grundig micro receiver to retrofit by a Grundig micro receiver
Digital TV reception via cable (DVB-C) to retrofit by a Grundig micro receiver to retrofit by a Grundig micro receiver to retrofit by a Grundig micro receiver to retrofit by a Grundig micro receiver to retrofit by a Grundig micro receiver to retrofit by a Grundig micro receiver
ELECTRONICS
Picture-in-picture 1-tuner-AV-PIP 1-tuner AV-PIP 1-tuner-AV-PIP 1-tuner AV-PIP – –
PAP – splitted screen (picture / picture) • (via AV) • (via AV) • (via AV) • (via AV) – –
PAT – splitted screen (picture / text) • • • • – –
Programme memory TV / AV 100 (1000 DVB-T) / 11 100 (1000 DVB-T) / 9 100 (1000 DVB-T) / 9 100 (899 DVB-T) / 9 99 (400 DVB-T) / 8 99 (400 DVB-T) / 9
Videotext / memory • / 1000 • / 1000 • / 1000 • / 250 • / 1000 • / 1000
TV standards BG, I, DK/K’, L/L’. PAL, SECAM BG, I, DK/K’, L/L’. PAL, SECAM BG, I, DK/K’, L/L’. PAL, SECAM BG, I, DK/K’, L/L’. PAL, SECAM BG, I, DK/K’, L/L’. PAL, SECAM BG, I, DK/K’, L/L’. PAL, SECAM
via AV: NTSC 4.43 + 3.58 MHz. via AV: NTSC 4.43 + 3.58 MHz. via AV: NTSC 4.43 + 3.58 MHz. via AV: NTSC 4.43 + 3.58 MHz. via AV: NTSC 4.43 + 3.58 MHz. via AV: NTSC 4.43 + 3.58 MHz.
A2 for B/G/D/K/I, Nicam 5.85 MHz A2 for B/G/D/K/I, Nicam 5.85 MHz A2 for B/G/D/K/I, Nicam 5.85 MHz A2 for B/G/D/K/I, Nicam 5.85 MHz A2 for B/G/D/K/I, Nicam 5.85 MHz A2 for B/G/D/K/I, Nicam 5.85 MHz
(BG, L) + 6.52 MHz (I) (BG, L) + 6.52 MHz (I) (BG, L) + 6.52 MHz (I) (BG, L) + 6.52 MHz (I) (BG, L) + 6.52 MHz (I) (BG, L) + 6.52 MHz (I)
Control keys on set • • • • • •
Infrared remote control TP 1 TP 2 TP 1 TP 2 TP 2 TP 2
SOUND
Music / nominal output approx. W 210 music output overall 2-channel 20 / 10 210 music output overall 2-channel 20 / 10 2-channel 20 / 10 2-channel 20 / 10
Sound projector / SRS TruSurround •/– –/• •/– –/• –/• –/•
Virtual Dolby Surround • – • – – –
Loudspeakers 8 wide band + 8 tweeter, front 2 wide band + 2 tweeter, front 8 wide band + 8 tweeter, front 2 wide band + 2 tweeter, front 2 wide band + 2 tweeter, front 2 wide band + 2 tweeter, front
+ 2 woofer, rear (subwoofer) + 2 woofer, rear (subwoofer)
CONNECTIONS / SOCKETS
HDMI 3x rear; 1x front 3x 3x rear; 1x front 2x (3x from 11/08) 3x 3x
HDCP • (via HDMI) • (via HDMI) • (via HDMI) • (via HDMI) • (via HDMI) • (via HDMI)
USB 2.0 • (frontal) – • (frontal) – • •
Euro-AV socket / RGB and S-video suitable 2x / 1x RGB, 1x S-video 2x / 1x RGB, 1x S-video 2x / 1x RGB, 1x S-video 2x / 1x RGB, 1x S-video 1x / RGB, S-video 1x / RGB, S-video
YUV sockets • (3x Cinch video, 2x Cinch audio) • (3x Cinch video, 2x Cinch audio) • (3x Cinch video, 2x Cinch audio) • (3x Cinch video, 2x Cinch audio) • (3x Cinch video, 2x Cinch audio) • (3x Cinch video, 2x Cinch audio)
S-video input (hosiden) / Cinch-AV sockets • (lateral) / • (lateral) • (lateral) / • (lateral) • (lateral) / • (lateral) •/• •/• •/•
VGA interface for PC • (Multisync WXGA) • (Multisync WXGA) • (Multisync WXGA) • (Multisync WXGA) • (Multisync WXGA) • (Multisync WXGA)
SPDIF out • (coaxial) • (coaxial) • (coaxial) • (coaxial) • (coaxial) • (coaxial)
Subwoofer out • • • – – –
Headphones socket (Ø 3.5 mm) • (lateral) • (lateral) • (lateral) • • •
Common interface (CA modules) • • • • • •
12 V DC connector – – – – – –
MAINS UNIT
Voltage (regulated), frequency 50/60 Hz V~ 230 230 230 230 230 230
Integrated supply • • • • • •
Power consumption max. / stand-by approx. W 370 / < 1 310 / < 1 310 / < 1 210 / < 2.5 210 / < 2.5 210 / < 2.5
Weight approx. kg 34.5 32.5 26.8 23.2 23.2 23.2
Dimensions (W x H x D) approx. cm 114 x 80 x 11.5 (38.4 with pedestal) 113 x 79 x 11.5 (33 with pedestal) 101.8 x 73.7 x 11.5 (34.5 with pedestal) 104.2 x 73.5 x 11 (31.7 with pedestal) 104.2 x 73.5 x 11 (31.7 with pedestal) 104.2 x 73.5 x 11 (31.7 with pedestal)
Prepared for VESA standard wall mounting mm 200 x 200 200 x 200 200 x 200 200 x 200 200 x 200 200 x 200
Technical data supplied without liability.

LCD TELEVISION SETS VISION 4 VISION 9 VISION 7 VISION 6 VISION 6 VISION 4
42-4831 T 37-9870 T 37-7851 T 37-6840 T 37-6831 T 37-4831 T
Display Active Matrix TFT-LC-Display Active Matrix TFT-LC-Display Active Matrix TFT-LC-Display Active Matrix TFT-LC-Display Active Matrix TFT-LC-Display Active Matrix TFT-LC-Display
Screen diagonal inches 42 37 37 37 37 37
16:9 wide-screen format • • • • • •
Response time approx. ms 8 8 8 8 8 8
Brightness approx. cd/m2500 500 500 500 500 500
Contrast ratio approx. 8000 : 1 (Dynamic Contrast Plus) 40000 : 1 (Dynamic Contrast Plus) 12000 : 1 (Dynamic Contrast Plus) 10000 : 1 (Dynamic Contrast Plus) 10000 : 1 (Dynamic Contrast Plus) 8000 : 1 (Dynamic Contrast Plus)
Viewing angle approx. Super Wide Super Wide Super Wide Super Wide Super Wide Super Wide
Resolution RGB pixel WXGA 1366 x 768 WUXGA 1920 x 1080 (Full HD) WUXGA 1920 x 1080 (Full HD) WXGA 1366 x 768 WXGA 1366 x 768 WXGA 1366 x 768
HD ready • • • • • •
100 Hz technology – • – – – –
Motion Picture Improvement – • – – – –
Perfect Picture Plus technology • • • • • •
Digital combfilter (3-D) • • • • • •
Digital Colour Transition Improvement (DCTI) • • • • • •
Digital Luminance Transition Improvement (DLTI) • • • • • •
Digital Noise Reduction (DNR) • • • • • •
INTEGRATED DVB-T RECEPTION
Digital TV reception via antenna (DVB-T) • • • • MPEG 4 • •
Digital TV reception via satellite (DVB-S) to retrofit by a Grundig micro receiver to retrofit by a Grundig micro receiver to retrofit by a Grundig micro receiver to retrofit by a Grundig micro receiver to retrofit by a Grundig micro receiver to retrofit by a Grundig micro receiver
Digital TV reception via cable (DVB-C) to retrofit by a Grundig micro receiver to retrofit by a Grundig micro receiver to retrofit by a Grundig micro receiver to retrofit by a Grundig micro receiver to retrofit by a Grundig micro receiver to retrofit by a Grundig micro receiver
ELECTRONICS
Picture-in-picture – 1-tuner-AV-PIP 1-tuner-AV-PIP – – –
PAP – splitted screen (picture / picture) – • (via AV) • (via AV) – – –
PAT – splitted screen (picture / text) – • • – – –
Programme memory TV / AV 99 (400 DVB-T) / 9 100 (1000 DVB-T) / 9 100 (899 DVB-T) / 9 99 (400 DVB-T) / 8 99 (400 DVB-T) / 9 99 (400 DVB-T) / 8
Videotext / memory • / 250 • / 1000 • / 250 • / 1000 • / 1000 • / 250
TV standards BG, I, DK/K’, L/L’. PAL, SECAM BG, I, DK/K’, L/L’. PAL, SECAM BG, I, DK/K’, L/L’. PAL, SECAM BG, I, DK/K’, L/L’. PAL, SECAM BG, I, DK/K’, L/L’. PAL, SECAM BG, I, DK/K’, L/L’. PAL, SECAM
via AV: NTSC 4.43 + 3.58 MHz. via AV: NTSC 4.43 + 3.58 MHz. via AV: NTSC 4.43 + 3.58 MHz. via AV: NTSC 4.43 + 3.58 MHz. via AV: NTSC 4.43 + 3.58 MHz. via AV: NTSC 4.43 + 3.58 MHz.
A2 for B/G/D/K/I, Nicam 5.85 MHz A2 for B/G/D/K/I, Nicam 5.85 MHz A2 for B/G/D/K/I, Nicam 5.85 MHz A2 for B/G/D/K/I, Nicam 5.85 MHz A2 for B/G/D/K/I, Nicam 5.85 MHz A2 for B/G/D/K/I, Nicam 5.85 MHz
(BG, L) + 6.52 MHz (I) (BG, L) + 6.52 MHz (I) (BG, L) + 6.52 MHz (I) (BG, L) + 6.52 MHz (I) (BG, L) + 6.52 MHz (I) (BG, L) + 6.52 MHz (I)
Control keys on set • • • • • •
Infrared remote control TP 2 TP 1 TP 2 TP 2 TP 2 TP 2
SOUND
Music / nominal output approx. W 2-channel 20 / 10 210 music output overall 2-channel 20 / 10 2-channel 20 / 10 2-channel 20 / 10 2-channel 20 / 10
Sound projector / SRS TruSurround –/• •/– –/• –/• –/• –/•
Virtual Dolby Surround – • – – – –
Loudspeakers 2 wide band, front 8 wide band + 8 tweeter, front 2 wide band + 2 tweeter, front 2 wide band + 2 tweeter, front 2 wide band + 2 tweeter, front 2 wide band, front
+ 2 woofer, rear (subwoofer)
CONNECTIONS / SOCKETS
HDMI 2x 3x rear; 1x front 2x (3x from 11/08) 3x 3x 2x
HDCP • (via HDMI) • (via HDMI) • (via HDMI) • (via HDMI) • (via HDMI) • (via HDMI)
USB 2.0 • • (frontal) – • • –
Euro-AV socket / RGB and S-video suitable 1x / RGB, S-video 2x / 1x RGB, 1x S-video 2x / 1x RGB, 1x S-video 1x / RGB, S-video 1x / RGB, S-video 1x / RGB, S-video
YUV sockets • (3x Cinch video, 2x Cinch audio) • (3x Cinch video, 2x Cinch audio) • (3x Cinch video, 2x Cinch audio) • (3x Cinch video, 2x Cinch audio) • (3x Cinch video, 2x Cinch audio) • (3x Cinch video, 2x Cinch audio)
S-video input (hosiden) / Cinch-AV sockets •/• • (lateral) / • (lateral) •/• •/• •/• •/•
VGA interface for PC • (Multisync WXGA) • (Multisync WXGA) • (Multisync WXGA) • (Multisync WXGA) • (Multisync WXGA) • (Multisync WXGA)
SPDIF out • (coaxial) • (coaxial) • (coaxial) • (coaxial) • (coaxial) • (coaxial)
Subwoofer out – • – – – –
Headphones socket (Ø 3.5 mm) • • (lateral) • • • •
Common interface (CA modules) • • • • • •
12 V DC connector – – – – – –
MAINS UNIT
Voltage (regulated), frequency 50/60 Hz V~ 230 230 230 230 230 230
Integrated supply • • • • • •
Power consumption max. / stand-by approx. W 210 / < 2.5 280 / < 1 180 / < 1 180 / < 1 180 / < 1 180 / < 1
Weight approx. kg 23.2 23 18.5 18.5 18.5 18.5
Dimensions (W x H x D) approx. cm 104.3 x 73.7 x 11.5 (31.5 with pedestal) 91.2 x 67.7 x 11.5 (32.8 with pedestal) 93 x 67.1 x 11.2 (25.2 with pedestal) 93 x 67.1 x 11.2 (25.2 with pedestal) 93 x 67.1 x 11.2 (25.2 with pedestal) 93 x 67.1 x 11.2 (25.2 with pedestal)
Prepared for VESA standard wall mounting mm 200 x 200 200 x 200 200 x 200 200 x 200 200 x 200 200 x 200
Technical data supplied without liability.

LCD TELEVISION SETS VISION 7 VISION 6 VISION 6 VISION 6 VISION 4 VISION 6
32-7851 T 32-6840 T 32-6832 T ECO 32-6831 T 32-4831 T 26-6832 T ECO
Display Active Matrix TFT-LC-Display Active Matrix TFT-LC-Display Active Matrix TFT-LC-Display Active Matrix TFT-LC-Display Active Matrix TFT-LC-Display Active Matrix TFT-LC-Display
Screen diagonal inches 32 32 32 32 32 26
16:9 wide-screen format • • • • • •
Response time approx. ms 6 6 6 6 6 6
Brightness approx. cd/m2500 500 500 500 500 500
Contrast ratio approx. 12000 : 1 (Dynamic Contrast Plus) 10000 : 1 (Dynamic Contrast Plus) 10000 : 1 (Dynamic Contrast Plus) 10000 : 1 (Dynamic Contrast Plus) 8000 : 1 (Dynamic Contrast Plus) 10000 : 1 (Dynamic Contrast Plus)
Viewing angle approx. Super Wide Super Wide Super Wide Super Wide Super Wide Super Wide
Resolution RGB pixel WUXGA 1920 x 1080 (Full HD) WXGA 1366 x 768 WXGA 1366 x 768 WXGA 1366 x 768 WXGA 1366 x 768 WXGA 1366 x 768
HD ready • • • • • •
100 Hz technology – – – – – –
Motion Picture Improvement – – – – – –
Perfect Picture Plus technology • • • • • •
Digital combfilter (3-D) • • • • • •
Digital Colour Transition Improvement (DCTI) • • • • • •
Digital Luminance Transition Improvement (DLTI) • • • • • •
Digital Noise Reduction (DNR) • • • • • •
INTEGRATED DVB-T RECEPTION
Digital TV reception via antenna (DVB-T) • • MPEG 4 • • • •
Digital TV reception via satellite (DVB-S) to retrofit by a Grundig micro receiver to retrofit by a Grundig micro receiver to retrofit by a Grundig micro receiver to retrofit by a Grundig micro receiver to retrofit by a Grundig micro receiver to retrofit by a Grundig micro receiver
Digital TV reception via cable (DVB-C) to retrofit by a Grundig micro receiver to retrofit by a Grundig micro receiver to retrofit by a Grundig micro receiver to retrofit by a Grundig micro receiver to retrofit by a Grundig micro receiver to retrofit by a Grundig micro receiver
ELECTRONICS
Picture-in-picture 1-tuner-AV-PIP – – – – –
PAP – splitted screen (picture / picture) • (via AV) – – – – –
PAT – splitted screen (picture / text) • – – – – –
Programme memory TV / AV 100 (899 DVB-T) / 9 99 (400 DVB-T) / 8 99 (400 DVB-T) / 9 99 (400 DVB-T) / 9 99 (400 DVB-T) / 8 99 (400 DVB-T) / 9
Videotext / memory • / 250 • / 1.000 • / 1.000 • / 1.000 • / 250 • / 1.000
TV standards BG, I, DK/K’, L/L’. PAL, SECAM BG, I, DK/K’, L/L’. PAL, SECAM BG, I, DK/K’, L/L’. PAL, SECAM BG, I, DK/K’, L/L’. PAL, SECAM BG, I, DK/K’, L/L’. PAL, SECAM BG, I, DK/K’, L/L’. PAL, SECAM
via AV: NTSC 4.43 + 3.58 MHz. via AV: NTSC 4.43 + 3.58 MHz. via AV: NTSC 4.43 + 3.58 MHz. via AV: NTSC 4.43 + 3.58 MHz. via AV: NTSC 4.43 + 3.58 MHz. via AV: NTSC 4.43 + 3.58 MHz.
A2 for B/G/D/K/I, Nicam 5.85 MHz A2 for B/G/D/K/I, Nicam 5.85 MHz A2 for B/G/D/K/I, Nicam 5.85 MHz A2 for B/G/D/K/I, Nicam 5.85 MHz A2 für B/G/D/K/I, Nicam 5.85 MHz A2 for B/G/D/K/I, Nicam 5.85 MHz
(BG, L) + 6.52 MHz (I) (BG, L) + 6.52 MHz (I) (BG, L) + 6.52 MHz (I) (BG, L) + 6.52 MHz (I) (BG, L) + 6.52 MHz (I) (BG, L) + 6.52 MHz (I)
Control keys on set • • • • • •
Infrared remote control TP 2 TP 2 TP 2 TP 3 TP 2 TP 2
SOUND
Music / nominal output approx. W 2-channel 20 / 10 2-channel 20 / 10 2-channel 20 / 10 2-channel 20 / 10 2-channel 20 / 10 2-channel 20 / 10
Sound projector / SRS TruSurround –/• –/• –/• –/• –/• –/•
Virtual Dolby Surround – – – – – –
Loudspeakers 2 wide band, front 2 wide band, front 2 wide band, front 2 wide band, front 2 wide band, front 2 wide band, front
CONNECTIONS / SOCKETS
HDMI 2x (3x from 11/08) 3x 3x 3x 3x 3x
HDCP • (via HDMI) • (via HDMI) • (via HDMI) • (via HDMI) • (via HDMI) • (via HDMI)
USB 2.0 – • – • – –
Euro-AV socket / RGB and S-video suitable 2x / 1x RGB, 1x S-video 1x / RGB, S-video 1x / RGB, S-video 1x / RGB, S-video 1x / RGB, S-video 1x / RGB, S-video
YUV sockets • (3x Cinch video, 2x Cinch audio) • (3x Cinch video, 2x Cinch audio) • (3x Cinch video, 2x Cinch audio) • (3x Cinch video, 2x Cinch audio) • (3x Cinch video, 2x Cinch audio) • (3x Cinch video, 2x Cinch audio)
S-video input (hosiden) / Cinch-AV sockets •/• •/• •/• •/• •/• •/•
VGA interface for PC • (Multisync WXGA) • (Multisync WXGA) • (Multisync WXGA) • (Multisync WXGA) • (Multisync WXGA) • (Multisync WXGA)
SPDIF out • (coaxial) • (coaxial) • (coaxial) • (coaxial) • (coaxial) • (coaxial)
Subwoofer out – – – – – –
Headphones socket (Ø 3.5 mm) • • • • • •
Common interface (CA modules) • • • • • •
12 V DC connector – – – – – –
MAINS UNIT
Voltage (regulated), frequency 50/60 Hz V~ 230 230 230 230 230 230
Integrated supply • • • • • •
Power consumption max. / stand-by approx. W 140 / < 1 140 / < 1 76 / < 0.09 (zero stand-by) 140 / < 1 140 / < 1 57 / < 0.09 (zero stand-by)
Weight approx. kg 11.8 11.8 11.8 11.8 11.4 8.8
Dimensions (W x H x D) approx. cm 80 x 59.2 x 10.8 (20 with pedestal) 80 x 59.2 x 10.8 (20 with pedestal) 80 x 59.2 x 10.8 (20 with pedestal) 80 x 59.2 x 10.8 (20 with pedestal) 80 x 59.4 x 11 (20 with pedestal) 66.5 x 49 x 10 (17.8 with pedestal)
Prepared for VESA standard wall mounting mm 200 x 200 200 x 100 200 x 100 200 x 100 200 x 100 200 x 100
Technical data supplied without liability.

LCD TELEVISION SETS VISION 6 VISION 6 VISION 2 VISION 2 VISION 2 DAVIO 7
26-6831 T 22-6831 T 22-2830 T 19-2830 T 16-2830 T LW 18-5701 IDTV
Display Active Matrix TFT-LC-Display Active Matrix TFT-LC-Display Active Matrix TFT-LC-Display Active Matrix TFT-LC-Display Active Matrix TFT-LC-Display Active Matrix TFT-LC-Display
Screen diagonal inches 26 22 22 19 16 7
16:9 wide-screen format • • • • • •
Response time approx. ms 6 3 3 5 8 18
Brightness approx. cd/m2500 300 300 300 250 500
Contrast ratio approx. 10000 : 1 (Dynamic Contrast Plus) 3000 : 1 (Dynamic Contrast Plus) 1000 : 1 700 : 1 400 : 1 300 : 1
Viewing angle approx. Super Wide 170° vertical, 170° horizontal 170° vertical, 170° horizontal 160° vertical, 160° horizontal 65° vertical, 90° horizontal 130° vertical, 130° horizontal
Resolution RGB pixel WXGA 1366 x 768 WSXGA 1680 x 1050 WSXGA 1680 x 1050 WXGA 1440 x 900 WXGA 1366 x 768 WVGA 480 x 234
HD ready • • • • • –
100 Hz technology – – – – – –
Motion Picture Improvement – – – – – –
Perfect Picture Plus technology • • – – – –
Digital combfilter (3-D) • • • (2-D) • (2-D) • (2-D) –
Digital Colour Transition Improvement (DCTI) • • • • • –
Digital Luminance Transition Improvement (DLTI) • • • • • –
Digital Noise Reduction (DNR) • • • • • –
INTEGRATED DVB-T RECEPTION
Digital TV reception via antenna (DVB-T) • • • • • •
Digital TV reception via satellite (DVB-S) to retrofit by a Grundig micro receiver to retrofit by a Grundig micro receiver to retrofit by a Grundig micro receiver to retrofit by a Grundig micro receiver to retrofit by a Grundig micro receiver –
Digital TV reception via cable (DVB-C) to retrofit by a Grundig micro receiver to retrofit by a Grundig micro receiver to retrofit by a Grundig micro receiver to retrofit by a Grundig micro receiver to retrofit by a Grundig micro receiver –
ELECTRONICS
Picture-in-picture – – – – – –
PAP – splitted screen (picture / picture) – – – – – –
PAT – splitted screen (picture / text) – – – – – –
Programme memory TV / AV 99 (400 DVB-T) / 9 9 (400 DVB-T) / 7 100 (899 DVB-T) / 3 100 (899 DVB-T) / 3 100 (899 DVB-T) / 3 256 (999 DVB-T) / 1
Videotext / memory • / 1000 • / 1000 • / 10 • / 10 • / 10 • (via DVB-T) / –
TV standards BG, I, DK/K’, L/L’. PAL, SECAM BG, I, DK/K’, L/L’. PAL, SECAM BG, I, DK/K’, L/L’. PAL, SECAM BG, I, DK/K’, L/L’. PAL, SECAM BG, I, DK/K’, L/L’. PAL, SECAM BG, I, DK, PAL, M
via AV: NTSC 4.43 + 3.58 MHz. via AV: NTSC 4.43 + 3.58 MHz. via AV: NTSC 4.43 + 3.58 MHz. via AV: NTSC 4.43 + 3.58 MHz. via AV: NTSC 4.43 + 3.58 MHz.
A2 for B/G/D/K/I, Nicam 5.85 MHz A2 for B/G/D/K/I, Nicam 5.85 MHz A2 for B/G/D/K/I, Nicam 5.85 MHz A2 for B/G/D/K/I, Nicam 5.85 MHz A2 for B/G/D/K/I, Nicam 5.85 MHz
(BG, L) + 6.52 MHz (I) (BG, L) + 6.52 MHz (I) (BG, L) + 6.52 MHz (I) (BG, L) + 6.52 MHz (I) (BG, L) + 6.52 MHz (I)
Control keys on set • • • • • •
Infrared remote control TP 2 TP 2 RC 20 RC 20 RC 20 RC Davio 7
SOUND
Music / nominal output approx. W 2-channel 20 / 10 2-channel 12 / 6 2-channel 12 / 6 2-channel 10 / 5 2-channel 8 / 4 2-channel 6 / 3
Sound projector / SRS TruSurround –/• –/• –/– –/– –/– –/–
Virtual Dolby Surround – – – – – –
Loudspeakers 2 wide band, front 2 wide band, front 2 wide band, front 2 wide band, front 2 wide band, front 2 wide band, front
CONNECTIONS / SOCKETS
HDMI 3x • • • • –
HDCP • (via HDMI) • (via HDMI) • (via HDMI) • (via HDMI) • (via HDMI) –
USB 2.0 • • – – – –
Euro-AV socket / RGB and S-video suitable 1x / RGB, S-video 1x / RGB, S-video 1x / RGB, S-video 1x / RGB, S-Video 1x / RGB, S-Video (via 3.5 mm jack)
YUV sockets • (3x Cinch video, 2x Cinch audio) • (via VGA) • (via VGA) • (via VGA) • (via VGA) –
S-video input (hosiden) / Cinch-AV sockets •/• •/• –/• –/• –/• – / (via 3.5 mm jack)
VGA interface for PC • (Multisync WXGA) • (Multisync WXGA) • (Multisync WXGA) • (Multisync WXGA) • (Multisync WXGA) –
SPDIF out • (coaxial) • (coaxial) – – – –
Subwoofer out – – – – – –
Headphones socket (Ø 3.5 mm) • • – – – • (lateral)
Common interface (CA modules) • • • • • –
12 V DC connector – – – • • •
MAINS UNIT
Voltage (regulated), frequency 50/60 Hz V~ 230 230 230 230 230 100 – 240
Integrated supply • • • • • – (AC/DC adaptor 7 –12 V= / 2 A)
Power consumption max. / stand-by approx. W 110 / < 1 51 / < 1 51 / < 1 45 / < 1 25 / < 1 15
Weight approx. kg 8.8 4.7 4.7 4.1 2.8 0.6
Dimensions (W x H x D) approx. cm 66.5 x 49 x 10 (17.8 with pedestal) 51.8 x 42 x 6.7 (16 with pedestal) 51.8 x 42 x 6.7 (16 with pedestal) 46.5 x 39 x 7.2 (17.8 with pedestal) 38.7 x 31 x 6.5 (13.5 with pedestal) 22.5 x 12.6 x 2.8
Prepared for VESA standard wall mounting mm 200 x 100 75 x 75 75 x 75 75 x 75 75 x 75 –
Technical data supplied without liability.
