Grundig VANTO+ GLED1907HDB User manual

VANTO+ HD
LED LCD TV
GLED1907HDB
GLED2207HDB
GLED2407HDB
The Gold Technical Support Line: 1902 215 259
(Charges will apply at $2.95 per minute)

- 1 -
Introduction
Thank you for buying this Grundig product, which is designed to give you
many years of trouble-free service.
You may already be familiar with using a similar unit, but please the take time
to read these instructions. They are designed to familiarise you with the unit‟s
many features and to ensure you get the very best from your purchase.
Your safety and the safety of others is important. Therefore, please ensure
you read the “Safety Instructions” before you operate this unit.
Warranty
In the unlikely event that your product fails to work normally. Please call the
below free phone numbers to discuss the problem with one of our qualified
service engineers.
Australia.
Grundig Warranty: 1800 509 394
New Zealand
Grundig Warranty: 0800 450 259

- 2 -
Contents
Introduction………………...…………………………………..….………1
Safety Instructions……………………………………………………..3-4
Unpacking………………………………………………………………...5
LED LCD TV Installation……………………………....…………………..6
Wall Mount Bracket Installation ………………………………………....7
View of LED LCD TV……………………………………………….…..8-9
Remote Control …………………..………………………….…….10-13
Installation and Connection …………………………….………….14-15
TV Basic Operation ………………….……..…….…………………15-17
TV Channel Menu …………………...………………….……….….17-39
Auto Scan………………………………………..………..…...18
Manual Scan…………………………………………………......19-20
Program Edit…………………………………………….............20-21
PVR Basic Operation………………………………………….22-39
Picture Menu………………………….…….………………….30-31
Sound Menu……………………………………………………31-32
Time Menu…………………………………………................ 32-33
Option Menu ………………………………………...................…34
Lock Menu ………………………………………....................35-37
EPG Menu……………………………………….....................37-38
Multimedia/Other Operation ….……..……………………………..38-40
Troubleshooting……………………………………………….…………41
Specifications ….………………………………………….…………42-44
Display Modes...………………………………………..……………45-46
Warranty….………………………………………….…….……………..47

- 3 -
Safety Instructions
1. Please read these operating instructions carefully before you operate this unit.
2. Do not use this television near water.
3. Clean with a dry cloth only.
4. Do not block any ventilation openings. Install in accordance with the manufacturers‟
instructions.
5. Do not install near any heat sources such as radiators, heat registers, stoves, or other
devices (including amplifiers) that produce heat.
6. Protect the power cord from being walked on or pinched particularly at the power point
and the TV power input.
7. Only use attachments/accessories specified by the manufacturer.
8. Unplug this television during lightning storms or when unused for long periods of time.
9. Refer all servicing to qualified service personnel. Servicing is required when the television
has been damaged in any way, such as the power-supply cord or plug has been damaged,
liquid has been spilled or objects have fallen into the television, the television has been
exposed to rain or moisture, does not operate normally, or has been dropped.
10. The television should not be exposed to dripping or splashing water and no objects filled
with liquids, such as vases, should be placed on the television.
11. Beware, if the television is to be built into a compartment or similar enclosed space, heat
build-up can occur and can reduce the service life of your television and can be dangerous.
Make sure you leave plenty of space around the unit.
12. If there is a sudden change in temperature or humidity, or when warm air comes into
contact with any cold parts in the unit, condensation may form. Placing the unit in a warm
room to dry out any condensation, this may take 1 to 2 hours, depending on environmental
conditions. Once condensation disappears, the unit will return to normal functions.

- 4 -
Installation Notes
This TV can be connected to AC 100-240 Volts, 50/60 Hz power source.
Never connect straight to a DC supply or any other power supply, then
specified above.
Locate the TV in the room where light does not directly strike the screen.
Total darkness or a reflection on the picture screen can cause eyestrain.
Soft and indirect lighting is recommended for comfortable viewing.
Allow enough space between the TV and the wall to permit ventilation.
Avoid excessively warm locations to prevent possible damage to the
cabinet or premature component failure.
Do not cover the ventilation openings when using the TV.
Additional Safety Notes
Never tamper with any components inside the TV, or any other
adjustment controls not mentioned in this manual.
To clean up dust, water drops or smudges from the screen or cabinet,
use a dry soft cloth. Also make sure you disconnect the TV when you are
cleaning the unit.
During thunder and lighting, unplug the power cord and antenna cord to
prevent damage to your TV.
All repairs to this TV should only be performed by a qualified technician.
Be cautious of this safe mark and beware to the below warning
WARNING:
To prevent fire or shock hazard, do not expose this unit to water or moisture.
Do not remove any parts as there are no user serviceable parts inside. Refer
all servicing to qualified service personnel.

- 5 -
Unpacking
___________________________________________
Please make sure that the following items are included with your LED LCD
TV. If any item is missing, please contact the warranty line.
LED TV
Remote Control
Operation Manual
DC Adaptor
Power Cord
RCA Cable
4 Cabinet Screws
SJ2822-87 ST4*12

- 6 -
TV Installation
1. Place the “LED LCD TV” on a solid flat surface. Use soft material to
place over the front screen to avoid any damage.
2. Use the 4 screws provided to attach the unit to the stand as per the
diagram below.

- 7 -
Wall Mount Bracket Installation
Use the 4 screws provide to fix the TV to your wall mount bracket (not
included). This TV is VESA Standard and as shown below there are 4 VESA
holes provided (100mm x 100mm).

- 8 -
View of the TV
Front View
Back View

- 9 -
LED LCD TV Key Functions
1. Power Indicator
In Power On Mode the indicator will
turn green. In Standby mode the
indicator will be red.
2. Remote Sensor
Receives the remote signals from the
remote control.
3. Power Button
Press the Power Button to turn on or
turn of the TV.
4. CH+ Button
Press the CH+ Button to scroll
upwards through the channel list.
5. CH- Button
Press the CH- Button to scroll
downward through the channel list
6. VOL+ Button
Press the VOL+ to increase the
volume level.
7. VOL- Button
Press the VOL- Button to decrease the
volume level.
8. MENU Button
Press the Menu Button to enter the
Main Menu.
9. SOURCE Button
Press the Source Button to select the
input source.
10. DC Input
The DC Input allows you to connect your
DC 12 Volt power supply.
11. USB Input
The USB Input enables you to insert your
USB stick and play/view AVI, MP4, DivX4,
DivX5, Xvid, JPEG, BMP, PNG, MP3 &
AAC files.
12. HDMI Input
The HDMI Input allows you to connect your
HDMI Cable for greater definition.
13. VGA Input
The VGA Input allows you to connect your
TV to your PC to use as a monitor or view
movies.
14. PC Audio Input
The PC Audio Input allows you to connect
your TV to your PC to use as a monitor and
enable the sound for movies etc.
15. AV 1 Input
16. Headphone Input
The Headphone Input enables you to
connect headphones for private listening.
17. Coaxial Out
The Coaxial Out allows you to connect the
TV to your surround sound system.
18. RF IN
The RF IN allows you to connect your
aerial.
19. AV 2 Input
20. YPbPr Input
