Grundig GSN 10720 User manual

ENG DA SV
www.grundig.com
www.grundig.com
REFRIGERATOR
USER INSTRUCTIONS
NO
GSN 10720
GSN 10722
GSN 10722 X
GSN 10722 FX
GSN 10724
GSN 10724 X
GSNE 107E20F
GSNE 107E20 FX
GSN 10728 F
GSN 10728 FB
GSN 10728 FX
GSNS 107S20 F
GSNS 107S20 FX

4
Contents
1. Safety and environment
instructions 6
2. Your Refrigerator 10
3. Installation 11
3.1Appropriate installation
location .......................................11
3.2 Installing the plastic
wedges........................................12
12
12
3.3 Electrical connection ........12
3.4 Illumination lamp..............12
4 Preparation 13
4.1 Things to be done for energy
saving..........................................13
4.2 Initial use...........................13
5. Operating the product 15
5.1 Indicator panel..................15
5.2 Using interior
compartments............................17
5.3 Cooling..................................17
6. Maintenance and cleaning 19
6.1 Avoiding bad odours .............19
6.2 Protecting the plastic
surfaces .....................................20
7. Troubleshooting 21

5
A
SV
NO
FIN
NL
Please read this manual first!
Dear Customer,
We hope that your product, which has been produced in modern plants
and checked under the most meticulous quality control procedures, will
provide you an effective service
For this, we recommend you to carefully read the entire manual of your
product before using it and keep it at hand for future references.
The user manual will help you use the product in a fast and safe way.
Will help you use your appliance in a fast and safe way.
Read the manual before installing and operating your product.
Follow the instructions, especially those for safety.
Keep the manual in an easily accessible place as you may need it later.
Besides, read also the other documents provided with your product.
Please note that this manual may be valid for other models as well.
Symbols and their descriptions
This instruction manual contains the following symbols:
CImportant information
or useful usage tips.
A
Warning against
dangerous conditions
for life and property.
BWarning against
electric voltage.
Packaging materials
of the product are
manufactured from
recyclable materials
in accordance with our
National Environment
Regulations.

6
1. Safety and environment instructions
This section provides the safety
instructions necessary to prevent
the risk of injury and material
damage. Failure to observe these
instructions will invalidate all
types of product warranty.
Intended use
A
WARNING:
Keep ventilation
openings, in the
appliance enclosure or
in the built-instructure,
clear of obstruction.
A
WARNING:
Do not use mechanical
devices or other means
to accelerate the
defrosting process,
other than those
recommended by the
manufacturer.
AWARNING:
Do not damage the
refrigerant circuit.
A
WARNING:
Do not use electrical
appliances inside
the food storage
compartments of the
appliance, unless
they are of the type
recommended by the
manufacturer.
This appliance is intended to be
used in household and similar
applications such as
– staff kitchen areas in shops,
offices and other working
environments;
– farm houses and by clients
in hotels, motels and other
residential type environments;
– bed and breakfast type
environments;
– catering and similar non-retail
applications.
1.1. General safety
• This product should not
be used by persons with
physical, sensory and mental
disabilities, without sufficient
knowledge and experience
or by children. The device
can only be used by such
persons under supervision
and instruction of a person
responsible for their safety.
Children should not be
allowed to play with this
device.
• In case of malfunction,
unplug the device.
• After unplugging, wait at
least 5 minutes before
plugging in again.
• Unplug the product when not
in use.
• Do not touch the plug with
wet hands! Do not pull the
cable to plug off, always hold
the plug.
• Do not plug in the refrigerator
if the socket is loose.
• Unplug the product during
installation, maintenance,
cleaning and repair.
• If the product will not be
used for a while, unplug the
product and remove any food
inside.
• Do not use the product when
the compartment with circuit
cards located on the upper
back part of the product

7
A
SV
NO
FIN
NL
(electrical card box cover) (1)
is open.
1
1
• Do not use steam or steamed
cleaning materials for
cleaning the refrigerator and
melting the ice inside. Steam
may contact the electrified
areas and cause short circuit
or electric shock!
• Do not wash the product by
spraying or pouring water on
it! Danger of electric shock!
• In case of malfunction, do not
use the product, as it may
cause electric shock. Contact
the authorised service before
doing anything.
• Plug the product into an
earthed socket. Earthing
must be done by a qualified
electrician.
• If the product has LED
type lighting, contact the
authorised service for
replacing or in case of any
problem.
• Do not touch frozen food with
wet hands! It may adhere to
your hands!
• Do not place liquids in bottles
and cans into the freezer
compartment. They may
explode.
• Place liquids in upright
position after tightly closing
the lid.
• Do not spray flammable
substances near the product,
as it may burn or explode.
• Do not keep flammable
materials and products with
flammable gas (sprays, etc.)
in the refrigerator.
• Do not place containers
holding liquids on top of the
product. Splashing water on
an electrified part may cause
electric shock and risk of fire.
• Exposing the product to rain,
snow, sunlight and wind
will cause electrical danger.
When relocating the product,
do not pull by holding the
door handle. The handle may
come off.
• Take care to avoid trapping
any part of your hands or
body in any of the moving
parts inside the product.
• Do not step or lean on the
door, drawers and similar
parts of the refrigerator. This
will cause the product to fall
down and cause damage to
the parts.
• Take care not to trap the
power cable.

8
1.1.1 HC warning
If the product comprises a
cooling system using R600a
gas, take care to avoid
damaging the cooling system
and its pipe while using and
moving the product. This gas
is flammable. If the cooling
system is damaged, keep the
product away from sources
of fire and ventilate the room
immediately.
C
The label on the inner
left side indicates the
type of gas used in the
product.
1.1.2 For models with
water dispenser
• Pressure for cold water inlet
shall be maximum 90 psi (6.2
bar). If your water pressure
exceeds 80 psi (5.5 bar), use
a pressure limiting valve in
your mains system. If you
do not know how to check
your water pressure, ask for
the help of a professional
plumber.
• If there is risk of water
hammer effect in your
installation, always
use a water hammer
prevention equipment in
your installation. Consult
Professional plumbers if you
are not sure that there is no
water hammer effect in your
installation.
• Do not install on the hot
water inlet. Take precautions
against of the risk of
freezing of the hoses. Water
temperature operating
interval shall be 33°F (0.6°C)
minimum and 100°F (38°C)
maximum.
• Use drinking water only.
1.2. Intended use
• This product is designed for
home use. It is not intended
for commercial use.
• The product should be used
to store food and beverages
only.
• Do not keep sensitive
products requiring controlled
temperatures (vaccines,
heat sensitive medication,
medical supplies, etc.) in the
refrigerator.
• The manufacturer assumes
no responsibility for any
damage due to misuse or
mishandling.
• Original spare parts will
be provided for 10 years,
following the product
purchasing date.
1.3. Child safety
• Keep packaging materials
out of children’s reach.
• Do not allow the children to
play with the product.
• If the product’s door
comprises a lock, keep the
key out of children’s reach.

9
A
SV
NO
FIN
NL
1.4. Compliance with WEEE
Directive and Disposing of the
Waste Product
This product complies
with EU WEEE Directive
(2012/19/EU). This product
bears a classification symbol for
waste electrical and electronic
equipment (WEEE).
This product has been
manufactured with
high quality parts and
materials which can be
reused and are
suitable for recycling.
Do not dispose of the
waste product with normal
domestic and other wastes at
the end of its service life. Take it
to the collection center for the
recycling of electrical and
electronic equipment. Please
consult your local authorities to
learn about these collection
centers.
1.5. Compliance with RoHS
Directive
• This product complies with EU
WEEE Directive (2011/65/EU).
It does not contain harmful and
prohibited materials specified in
the Directive.
1.6. Package information
• Packaging materials of the
product are manufactured
from recyclable materials in
accordance with our National
Environment Regulations. Do
not dispose of the packaging
materials together with the
domestic or other wastes. Take
them to the packaging material
collection points designated by
the local authorities.

10
C
Figures in this user manual are schematic and may not
match the product exactly. If the subject parts are not
included in the product you have purchased, then those parts
are valid for other models.
2. Your Refrigerator
1. Indicator panel
2. Butter & Cheese sections
3. Adjustable door shelves
4. Bottle shelves
5. Shelter wire
6. Adjustable front feet
7. Crispers
8. Chiller
9. Chiller cover and glass
10. Movable shelves
11. Wine cellar
12. Fan
1
2
5
3
4
7
8
9
11
10
12
6

11
A
SV
NO
FIN
NL
3. Installation
Refer to the nearest Authorised
Service Agent for installation of
the product. To make the product
ready for use, make sure that
the electricity installation is
appropriate before calling the
Authorised Service Agent. If not,
call a qualified electrician to have
any necessary arrangements
carried out.
C
Preparation of the
location and electrical
installation at the place
of installation is under
customer's responsibility.
B
Product must not be
plugged in during
installation. Otherwise,
there is the risk of death
or serious injury!
B
WARNING: Installation
and electrical connections
of the product must
be carried out by the
Authorised Service Agent.
Manufacturer shall not be
held liable for damages
that may arise from
procedures carried out by
unauthorised persons.
A
WARNING: Prior to
installation, visually
check if the product has
any defects on it. If so,
do not have it installed.
Damaged products cause
risks for your safety.
C
Make sure that the power
cable is not pinched or
crushed while pushing
the product into its place
after installation or
cleaning procedures.
3.1 Appropriate
installation location
A
WARNING: If the door
of the room where the
product will be placed
is too small for the
product to pass, then the
product's doors must be
removed and the product
must be turned aside to
pass it through.
• Choose a place at where
you would use the product
comfortably.
• Install the product at least 30
cm away from heat sources
such as hobs, ovens, heater
cores and stoves and at least 5
cm away from electrical ovens.
Product must not be subjected
to direct sun light and kept in
humid places after installation.
• Appropriate air ventilation must
be provided around your product
in order to achieve an efficient
operation. If the product is to be
placed in a recess in the wall,
pay attention to leave at least 5
cm distance with the ceiling and
side walls.
• Do not place the product on
the materials such as rugs or
carpets.
• Place the product on an even
floor surface to prevent jolts.
• Your product can operate in
ambinet temperatures between
5°C to +43°C.

12
3.4 Illumination lamp
Do not attempt to repair yourself
but call the Authorised Service
Agent if the LED illumination
lamps do not go on or are out of
order.
C
If two coolers are to be
installed side by side,
there should be at least
4 cm distance between
them.
3.2 Installing the
plastic wedges
Plastic wedges are used to create
the distance for the air circulation
between the product and the rear
wall. Insert the 2 plastic wedges
onto the rear ventilation cover as
illustrated in the figure. To install
the wedges, remove the screws
on the product and use the screws
given in the same pouch with the
wedges.
3.3 Electrical connection
Connect the product to a grounded
outlet protected by a fuse
complying with the values in the
rating plate. Our company shall
not be liable for any damages that
will arise when the product is used
without grounding in accordance
with the local regulations.
• Electrical connection
must comply with national
regulations.
• Power cable plug must be within
easy reach after installation.
• The voltage and allowed fuse or
breaker protection are specified
in the Rating Plate which is
affixed to interior of the product.
If the current value of the fuse
or breaker in the house does
not comply with the value in the
rating plate, have a qualified
electrician install a suitable
fuse.
• The specified voltage must be
equal to your mains voltage.
• Do not make connections via
extension cables or multi-plugs.
B
WARNING: Damaged
power cable must
be replaced by the
Authorised Service
Agents.
B
WARNING: If the
product has a failure, it
should not be operated
unless it is repaired by
the Authorised Service
Agent! There is the risk of
electric shock!

13
A
SV
NO
FIN
NL
4 Preparation
4.1 Things to be done
for energy saving
A
Connecting the product
to electric energy saving
systems is risky as it may
cause damage on the
product.
• Do not leave the doors of your
refrigerator open for a long
time.
• Do not put hot food or drinks in
your refrigerator.
• Do not overload the refrigerator.
Cooling capacity will fall when
the air circulation inside is
hindered.
• Do not place the refrigerator in
places subject to direct sunlight.
Install the product at least 30
cm away from heat sources
such as hobs, ovens, heater
cores and stoves and at least 5
cm away from electrical ovens.
• Pay attention to store your
food in refrigerator in closed
containers.
• You can load maximum
amount of food to the freezer
compartment of the refrigerator
by removing the freezer
compartment drawers. Declared
energy consumption value of
the refrigerator was determined
with the freezer compartment
drawers removed,except if
available bottom drawer and
with maximum amount of food
loaded. There is no risk in using
a shelf or drawer suitable for
the shapes and sizes of the
foods to be frozen.
• Thawing frozen food in fridge
compartment will both provide
energy saving and preserve the
food quality.
CThe ambient temperature
of the room where you
install the refrigerator
should at least be
5°C. Operating your
refrigerator under colder
conditions than this is not
recommended.
CInside of your refrigerator
must be cleaned
thoroughly.
CIf two coolers are to be
installed side by side,
there should be at least
4 cm distance between
them.
4.2 Initial use
Before starting to use the product,
check that all preparations are
made in accordance with the
instructions in sections "Important
instructions for safety and
environment" and "Installation".
• Clean the interior of the
refrigerator as recommended in
the “Maintenance and cleaning”
section. Check that inside of it is
dry before operating it.
• Plug the refrigerator into the
grounded wall outlet. When
the door is opened the interior
illumination will turn on.
• Run the refrigerator without
putting any food for 6 hours
and do not open its door unless
certainly required.

14
CYou will hear a noise
when the compressor
starts up. The liquids and
gases sealed within the
refrigeration system may
also give rise to noise,
even if the compressor
is not running and this is
quite normal.
CFront edges of the
refrigerator may feel
warm. This is normal.
These areas are designed
to be warm to avoid
condensation.
CFor energy efficiency, it
is recommmended to
remove top shelf and
load food on the shelf
below.Net volume of your
appliance is declared
without top two flaps and
the top shelf in place.
Place two ice pack ( if
provided ) directly on the
top of frozen food to be
stored on top shelf.
1 1113
2
53 7
4
6 8109 14
12

15
A
SV
NO
FIN
NL
5. Operating the product
5.1 Indicator panel
1. On/Off Function:
This function allows you to make
the Fridge turn off when pressed
for 3 seconds.The fridge could
be turned on by pressing On/Off
button for 3 seconds again .
2. On/Off Indicator:
This icon come on when the fridge
is turned off. All the other icons
turn off.
3. Quick Fridge Function:
Quick Fridge indicator turns on
when the Quick Fridge function
is on. Press Quick Fridge button
again to cancel this function.
Quick Fridge indicator will turn
off and normal settings will be
resumed. Quick Fridge function
will be cancelled automatically 2
hours later if you do not cancel it
manually. If you want to cool plenty
amount of fresh food, press Quick
Fridge button before you place the
food into the fridge compartment.
4. Quick Fridge Indicator :
This icon comes on when the Quick
Fridge function is on.
5. Fridge Set Function:
This function allows you to
make the Fridge compartment
temperature setting. Press this
button to set the temperature
of the fridge compartment to
8,7,6,5,4,3 and 2 respectively.
6. Fridge Compartment
Temperature Setting Indicator:
Indicates the temperature set for
the Fridge Compartment.
7. Vacation Function:
When you press Vacation button,
vacation function is activated and
vacation indicator lights. You can
use this function when you will
1 1113
2
5
3 7
4
68109 14
12

16
not use your fridge for a long
time. Note that there should be no
food inside your fridge, otherwise
fridge can not preserve your food
at Vacation mode. If this function
is activated, fridge compartment
temperature is kept at 15 C° in
order to prevent bad smelling.
Press Vacation button again to
deactivate vacation function.
8. Vacation Indicator:
This icon lights up when the
Vacation Function is active.
9. High Temperature/Error
Warning Indicator:
This light comes on during high
temperature failures and error
warnings. If you see this light is on,
please check the “Recommended
Solutions for the Problems” part
from you manual.
10. Economic Usage Indicator:
This icon comes on when the
Fridge Compartment is set to 8°C
which is the most economical set
value. Economic Usage Indicator
turns off when the Quick Fridge or
Quick Freeze function is selected.
11.Energy saving Function
(Display Off):
When you press this button, Energy
saving icon will light up and Energy
Saving Function will be activated.
If energy saving function is active,
all icons on the display other than
energy saving icon will turn off.
When the Energy Saving Function
is active, if any button is pressed,
Energy Saving Function will be
exited and the icons on display will
return to normal.If you press this
buton again, Energy Saving icon
will turn off and Energy Saving
Function will not be active.
12.Energy Saving Indicator :
This icon (“-“) lights up when the
Energy Saving Function is selected.
13. Key Lock Mode:
Press Key Lock button
concurrently for 3 seconds. Key
lock icon will light up and key lock
mode will be activated. Buttons will
not function if the Key Lock mode
is active. Press Key Lock button
con-currently for 3 seconds again.
Key lock icon will turn off and the
key lock mode will be exited.
14. Key Lock Indicator:
This icon lights up when the Key
Lock mode is activated.

17
A
SV
NO
FIN
NL
5.2 Using interior
compartments
Body shelves: Distance between
the shelves can be adjusted when
necessary.
Crisper: Vegetables and fruits can
be stored in this compartment for
long periods without decaying.
Bottle shelf: Bottles, jars and tins
can be placed in these shelves.
5.3 Cooling
Food storage
The fridge compartment is for the
short-term storage of fresh food
and drinks.
Store milk products in the intended
compartment in the refrigerator.
Bottles can be stored in the bottle
holder or in the bottle shelf of the
door.
Raw meat is best kept in
a polyethylene bag in the
compartment at the very bottom of
the refrigerator.
Allow hot foods and beverages to
cool to room temperature prior to
placing them in the refrigerator.
• Attention
Store concentrated alcohol only
standing upright and tightly closed.
• Attention
Do not store explosive substances
or containers with flammable
propellant gases (canned cream,
spray cans etc.) in the device.
There is a danger of explosion.
Placing the food
Egg tray Egg
Fridge
compartment
shelves
Food in pans,
covered plates
and closed
containers
Fridge
compartment
door shelves
Small and
packaged food
or drinks (such
as milk, fruit
juice and beer)
Crisper Vegetables and
fruits
Defrosting of the appliance
The appliance defrosts automatically.

18
5.4 Humidity controlled crisper
(everfresh)
(This feature is optional)
Humidity rates of the vegetables
and fruit are kept under control
with the feature of humidity-
controlled crisper and the food is
ensured to stay fresh for longer.
We recommend you to place the
leafy vegetables such as lettuce,
spinach and the vegetables which
are sensitive to humidity loss, in
a horizontal manner as much as
possible inside the crisper, not on
their roots in a vertical position.
While the vegetables are being
placed, specific gravity of the
vegetables should be taken into
consideration. Heavy and hard
vegetables should be put at the
bottom of the crisper and the
lightweight and soft vegetables
should be placed over.
Never leave the vegetables
inside the crisper in their bags.
If the vegetables are left inside
their bags, this will cause them
to decompose in a short period
of time. In case contacting with
other vegetables is not preferred
for hygiene concerns, use a
perforated paper and other similar
packaging materials instead of a
bag.
Do not place together the pear,
apricot, peach, etc. and apple in
particular which have a high level
of generation of ethylene gas in
the same crisper with the other
vegetables and fruit. The ethylene
gas which is emitted by these fruit
may cause the other fruit to ripen
faster and decompose in a shorter
time.

19
A
SV
NO
FIN
NL
6. Maintenance and cleaning
Cleaning your fridge at regular in-
tervals will extend the service life
of the product.
BWARNING:
Unplug the product before cleaning
it.
• Never use gasoline, benzene or
similar substances for cleaning
purposes.
• Never use any sharp and
abrasive tools, soap, household
cleaners, detergent and wax
polish for cleaning.
• For non-No Frost products,
water drops and frosting up to a
fingerbreadth occur on the rear
wall of the Fridge compartment.
Do not clean it; never apply oil
or similar agents on it.
• Only use slightly damp
microfiber cloths to clean the
outer surface of the product.
Sponges and other types of
cleaning cloths may scratch the
surface
• Dissolve one teaspoon of bi-
carbonate in half litre of water.
Soak a cloth with the solution
and wrung it thoroughly. Wipe
the interior of the refrigerator
with this cloth and the dry
thoroughly.
• Make sure that no water enters
the lamp housing and other
electrical items.
• If you will not use the
refrigerator for a long period of
time, unplug it, remove all food
inside, clean it and leave the
door ajar.
• Check regularly that the door
gaskets are clean. If not, clean
them.
• To remove door and body
shelves, remove all of its
contents.
• Remove the door shelves by
pulling them up. After cleaning,
slide them from top to bottom to
install.
• Never use cleaning agents or
water that contain chlorine to
clean the outer surfaces and
chromium coated parts of
the product. Chlorine causes
corrosion on such metal
surfaces.
6.1 Avoiding bad odours
• Materials that may cause odour
are not used in the production of
our refrigerators. However, due
to inappropriate food preserving
conditions and not cleaning the
inner surface of the refrigerator
as required can bring forth the
problem of odour. Pay attention
to following to avoid this
problem:
• Keeping the refrigerator clean
is important. Food residuals,
stains, etc. can cause odour.
Therefore, clean the refrigerator
with bi-carbonate dissolved in
water every few months. Never
use detergents or soap.
• Keep the food in closed
containers. Microorganisms
spreading out from uncovered
containers can cause
unpleasant odours.

20
• Never keep the food that have
passed best before dates and
spoiled in the refrigerator.
6.2 Protecting the plas-
tic surfaces
Do not put liquid oils or oil-cooked
meals in your refrigerator in un-
sealed containers as they dama-
ge the plastic surfaces of the refri-
gerator. If oil is spilled or smeared
onto the plastic surfaces, clean and
rinse the relevant part of the surfa-
ce at once with warm water.

21
A
SV
NO
FIN
NL
7. Troubleshooting
Check this list before contacting
the service. Doing so will save you
time and money. This list includes
frequent complaints that are not
related to faulty workmanship
or materials. Certain features
mentioned herein may not apply to
your product.
The refrigerator is not working.
• The power plug is not fully
settled. >>> Plug it in to settle
completely into the socket.
• The fuse connected to the
socket powering the product
or the main fuse is blown. >>>
Check the fuses.
Condensation on the side wall of
the cooler compartment (MULTI
ZONE, COOL, CONTROL and FLEXI
ZONE).
• The door is opened too
frequently >>> Take care not
to open the product’s door too
frequently.
• The environment is too humid.
>>> Do not install the product in
humid environments.
• Foods containing liquids are
kept in unsealed holders. >>>
Keep the foods containing
liquids in sealed holders.
• The product’s door is left open.
>>> Do not keep the product’s
door open for long periods.
• The thermostat is set to too
low temperature. >>> Set the
thermostat to appropriate
temperature.
Compressor is not working.
• In case of sudden power failure
or pulling the power plug
off and putting back on, the
gas pressure in the product’s
cooling system is not balanced,
which triggers the compressor
thermic safeguard. The product
will restart after approximately 6
minutes. If the product does not
restart after this period, contact
the service.
• Defrosting is active. >>>
This is normal for a fully-
automatic defrosting product.
The defrosting is carried out
periodically.
• The product is not plugged in.
>>> Make sure the power cord is
plugged in.
• The temperature setting
is incorrect. >>> Select the
appropriate temperature
setting.
• The power is out. >>> The
product will continue to operate
normally once the power is
restored.
The refrigerator’s operating noise
is increasing while in use.
• The product’s operating
performance may vary
depending on the ambient
temperature variations. This is
normal and not a malfunction.
The refrigerator runs too often or
for too long.
• The new product may be larger
than the previous one. Larger
products will run for longer
periods.
• The room temperature may
be high. >>> The product will
normally run for long periods in
higher room temperature.
• The product may have been
recently plugged in or a new
food item is placed inside. >>>
