Assembly Instruction
Sat inputs
Terr. input
Equipotential bonding
4 x
Outputs Receiver
4 x
Outputs Receiver
Low-Band / High-Band
Example: SDSP 908
Power supplyPower LED
Sat inputs
Terr. input
Equipotential bonding
6 x
Outputs Receiver
6 x
Outputs Receiver
Low-Band /
High-Band
Example: SDSP 1312
Power supply
Power LED
SDSP 506/508/512/516/524/532
SDSP 908/912/916/924/932
SDSP 1308/1312/1316/1324/1332
SDSP 1708/1712/1716/1724/1732
- 2 - SDSP 506 … SDSP 1732
1 Important InformatIon o n the safety and assembly
• Assembly and servicing should be carried out by electricians.
• Check the system for short circuits in the coaxial cables before starting up.
• Only install the system when it is not connected to the mains supply.
• Mount the multiswitch…
- on a non-flammable background (wall),
- in a dust-free, dry environment,
-
in such a manner that it is protected from moisture, fumes, splashing water
and dampness,
- somewhere protected from direct sunlight,
- not within the immediate vicinity of heat sources,
• Make sure the input levels of the SAT stages are as equal as possible.
• Beware of short circuits!
• Earth the unit via the equipotential bonding connector (screws ).
• No liability is accepted for any damage caused by faulty connections or
inappropriate handling.
• Observe the relevant standards, regulations and guidelines on the installation and
operation of antenna systems.
• The standards IEC/EN/DIN EN 61319-1, IEC/EN/DIN EN 60065 and
IEC/EN/DIN EN 60728 must be observed.
Electronic devices should never be disposed of in the household rubbish. In accordance
with directive 2002/96/EC of the European Parliament and the European Council from
January 27, 2003 which addresses old electronic and electrical devices, such devices
must be disposed of at a designated collection facility. At the end of its service life,
please take your device to one of these public collection facilities for proper disposal.
2 technIcal descrIptIon
a p p l I c a t I o n
This multiswitch is used for distribution of 4 SAT-IF-polarisations (SDSP 5xx;
e.g. ASTRA or EUTELSAT), 2 x 4 SAT-IF-polarisations (SDSP 9xx; e.g. ASTRA
and EUTELSAT), 3 x 4 SAT-IF-polarisations (SDSP 13xx) or 4 x 4 SAT-IF-polari-
sations (SDSP 17xx) and terrestrial signals (active).
The SDSP 5xx and SDSP 9xx ranges are equipped with an internal 22 kHz
generator, in order to support QUAD LNBs. The signals of the terrestrial input
will be active routed to the outputs (low insertion loss). Dependent on the typ,
6, 8,12,16,24 or 32 subscribers/receivers can be connected.
po w e r s u p p ly
Power supply is be done via the internal power supply unit.
- 3 - SDSP 506 … SDSP 1732
3 connectIons and controls
Identification of connections:
Connecting element Symbol
SAT inputs
Horizontal High
Vertical High
Horizontal Low
Vertical Low
Terrestrial input
Equipotential bonding (min. 4 mm2)
Receiver outputs
The outputs are selected by receivers control signals 14/18 V (Vertical/Hori-
zontal) , 0/22 kHz (Low-, High-Band). Selecting the Satellite position by
SDSP 9/12/17xx is done by DiSEqC signals from the SAT-receiver.
Please check the input levels of the SAT-lines: They should be nearly equal.
Connect the PE connection terminal to a potential equalisation rail (sup-
plied by customer) using a PE wire with at least 4mm².
Not used receiver outputs
can be terminated (reduc-
es the terrestrial signal
ripple).
Example of a house in-
stallation using SDC 912
and SDSP 908:
Potential equalisation rail
Receiver
CH 999
4 specIfIcatIons
GSS Grundig Systems GmbH • Beuthener Straße 43 • D-90471 Nuremberg
Phone: +49 (0) 911 / 703 8877 • Fax: +49 (0) 911 / 703 9210
www.gss.de/en • i[email protected]
Service: Phone: +49 (0) 911/703 2221; Fax: +49 (0) 911/703 2326; [email protected]
Alterations reserved. Technical data E. & O.E. © by GSS Grundig Systems GmbH 001/2018
SDSP
506
508
512
516
524
532
908
912
916
924
932
1308
1312
1316
1324
1332
1708
1712
1716
1724
1732
Number of inputs 4 x SAT, 1 x TERR 8 x SAT, 1 x TERR 12 x SAT, 1 x TERR 16 x SAT, 1 x TERR
Receiver outputs 6 8 12 16 24 32 8 12 16 24 32 8 12 16 24 32 8 12 16 24 32
Frequency
range
SAT 950 – 2150 MHz
TERR 47 - 862 MHz
Gain (dB) SAT 0 – 8 0 – 6 0 – 5 -9 0 – 8 -3–6 -9 0 – 8 -3–6 -9
TERR 5 – 8 2 – 6 0–8 -2–6 -3–4 -5–3 -7 – 2 -3–6 0 – 8 -3–6 0 – 8
Isolation
(dB)
TERR/SAT 30
SAT/TERR 28
Cross polarization isolation
H/V (dB) 25
Isolation
(dB)
out – out TERR 22
out – out SAT 35 30
Return loss
(dB)
SAT inputs 10
SAT outputs 8
TERR input 10
TERR output 8
Output level
(dBµV)
SAT (IMD3-35
dB) 100
TER (IMD3-60 dB) 88 85 83 88 83 88 83 88 83
Impedance (Ω) 75
22 kHz Generator • —
Switching signals 13 V/18 V,
13 V-22 kHz/18 V-22 kHz 13 V/18 V, 13 V-22 kHz/18 V-22 kHz, DiSEqC 2.0
Dimensions (mm)
235x129x55
255x129x55
295x129x55
335x129x55
415x129x55
495x129x55
235x129x55
275x129x55
315x129x55
395x129x55
475x129x55
147x203x50
187x203x50
227x203x50
307x203x50
387x203x50
147x203x50
187x203x50
227x203x50
307x203x50
387x203x50
Weight (kg) 1.0 1.0 1.1 1.1 1.3 1.3 1.0 1.1 1.1 1.3 1.3 1.4 1.4 1.4 1.8 1.8 1.4 1.4 1.4 1.8 1.8
Order no. G.BB… 51-
00
52-
00
53-
00
54-
00
55-
00
56-
00
62-
00
63-
00
64-
00
65-
00
66-
00
72-
00
73-
00
74-
00
75-
00
76-
00
82-
00
83-
00
84-
00
85-
00
86-
00
