Grundig ILLION 1 User manual

DECT
TELEPHONE
ILLION A1
ILLION 1
en

ENGLISH
2
TABLE OF CONTENTS
4 INFORMATION
4Preface
4 Application information
4 Safety information
5Environment
6 Setting up/range
7SET-UP
7 Illion box contents
7 Presenting the base unit
8 Presenting the handset
9 The Navigator
9 Base unit connection
10 Inserting batteries in the handset
11 Charging status of the battery
11 Switching the handset on and off
11 Selecting the country
11 Out of range
11 Navigating through the menus
13 BLOCK DIAGRAM
15 MAKING TELEPHONE CALLS
15 Making an external call
15 Answering a call
15 Making an internal call
15 Using the call log
16 CLI (Caller Line ID) function
16 Managing calls whilst communication is underway
17 Locking the handset keypad
17 Using in hands-free mode
17 Setting the volume
18 Secret mode
18 Calling back if busy
18 Activating the redial
19 SMS SERVICES
19 Sending a message
20 Receiving messages
20 To view a stored message (Draft)
21 To view a sent message
21 To change the SMS centre number

3
TABLE OF CONTENTS
22 PHONEBOOK
22 Adding a phonebook entry
23 Viewing a phonebook entry
23 Editing a phonebook entry
23 Deleting a phonebook entry
24 Deleting the entire phonebook
24 Transferring a phonebook entry
24 Quick call
25 DISPLAY
25 Setting the display wallpaper
25 Setting the contrast
26 ALARM
26 Set the time and date
26 Setting the alarm
27 SOUND SETTINGS
27 Setting the handset volume
27 Setting the melody and handset volume for an external call
27 Setting the melody and handset volume for an internal call
28 Warning tones
29 SETTINGS
29 Handset settings
32 Base unit settings
35 CALL LOG
35 To display the list of calls made
35 Removing numbers from the list of calls
35 Storing a caller's details in the phonebook
36 ANSWERING MACHINE (Illion A1 only)
36 Playing a message
36 TAM Settings
38 Recording a memo
39 Setting the outgoing message
40 Activating/deactivating the answering machine
40 Remote control
44 Condition on delivery
45 Features
46 WARRANTY

ENGLISH
4
INFORMATION
Preface
Dear customer, congratulations on buying your Grundig DECT
telephone and thank you for placing your confidence in us. This
device has been manufactured with the utmost care. If you
should have difficulties in operating it, we recommend that you
consult this user manual.
To operate the device safely and easily, please read the following
sections carefully:
Application information
This telephone is to be used for transmitting voice messages via
telephone networks. Any other use is not permitted and is
considered unfit for the intended use.
Safety information
- Do not install your DECT telephone in a damp environment,
such as a bathroom, washroom, kitchen etc, and not within
1.50 metres of a source of water or outside. This device is
designed for use in temperatures of between 5 °C and 45 °C.
- Only use the power unit supplied and connect it to the electricity
mains in accordance with the installation instructions in this user
manual and the details on the sticker regarding voltage,
electrical current and frequency. As a precaution if there is a
risk of danger, the power plug can be pulled out to disconnect
the 230 volt power supply. Therefore the sockets should be
near the device and easily accessible.
- This device is designed to be used for connecting to the public
telephone network. If problems should arise, contact your
nearest specialist dealer. Only use the telephone cable supplied.
- For safety reasons, never put the handset in the base station
without the battery inserted or without the lid on the battery
compartment as this could cause an electric shock.
- To avoid damaging the handset, only use the rechargeable
battery supplied. The used battery must be disposed of in line
with the recycling regulations in this user manual.
- Your DECT telephone has a range of approx. 50 metres
indoors and up to 300 metres outdoors. The range can be
affected by the proximity of metal objects, such as a television
and electrical devices.
- Certain medical equipment and highly-sensitive machines or
security systems may be affected by the transmission power of
the telephone. In these cases we recommend adhering to the
safety information.
- In regions greatly affected by electrical storms we recommend
that you protect your telephone circuit with a special fixture for
excess voltage.
INFORMATION

5
INFORMATION
- You cannot make calls with the device if there is a power cut.
Therefore keep another telephone at the ready in the event of
an emergency.
- The CE label confirms that the product complies with the 1999/
5/EC regulations of the European Union Parliament regarding
wireless systems and telecommunications for user protection
and for preventing electromagnetic interference. This ensures
the allocated communication network is used properly and
radio interference is avoided. The declaration of compliance
may be looked up on the www.grundig-dect.com website,
section “support” or can be obtained from the following
address:
Sagem Communication - Customer relations department
4, rue du Petit Albi - 95800 Cergy Saint-Christophe - France
Environment
Environmental protection and sustainable development is an
important priority for Sagem Communication. Sagem
Communication has a policy of using environmentally- friendly
systems and makes environmental protection an essential part of
the life-cycle of its products – from the manufacturing, to the
installation, operation and disposal.
Packaging
The logo (green point) on the packaging means that a fee is paid
to an authorised national organisation to improve packaging
recycling and the recycling infrastructure. Follow the local sorting
regulations for this type of waste product in order to improve
recycling.
Batteries
If your product contains batteries, they must be disposed of at the
designated collection points.
The product
The crossed out dustbin displayed on the product signifies that it
belongs to the electrical and electronic equipment group. The
European regulations request you to carry out your own selective
recycling collection at:
• the sales outlet when you buy a similar new device.
• the collection points available in your area (recycling centres,
sorting points, etc).
This means you participate in the recycling and valorisation of
used electric and electronic goods which would otherwise have
a negative impact on the environment and health.

ENGLISH
6
INFORMATION
Setting up/range
Place the base station somewhere central and easily accessible
where you want to use it.
Depending on the ambient conditions, the range can be up to
approx. 300 metres outdoors. It has a range of up to 50 metres
indoors depending on the space and structure of the building.
The structure of the building can cause signal shadows to occur.
This can lead to short interruptions when speaking due to the
weak signal.
The connection breaks up temporarily when there is insufficient
field strength.
Place an anti-slip mat under the base station. The feet on the
device do not usually leave any undesirable marks behind. Due
to the variety of varnish and polish used on furniture, we cannot
completely rule out the possibility that marks from the feet of the
device are left on any surfaces.
Grundig does not accept any liability for this type of damage.
Operating the base station or charger outside or in areas
exposed to frost is not permitted.
The recommended ambient temperature for operating the base
station is +5 °C – +45 °C, the recommended relative air
humidity is 20 % to 75 %.
The installation location must have a mains socket for 230 volts
for the base station or the charger.

7
SET-UP
Illion box contents
Place the box in front of you, open it and make sure it contains
the following items:
• one base,
• one handset,
• one battery compartment cover,
• one equipped power adapter,
• two rechargeable batteries,
• power supply unit,
• one telephone line cord,
• this user guide.
In the case of purchasing a pack duo or trio, you will find in
addition for each additional handset:
• a handset charger,
• an additional battery flap,
• three additional rechargeable batteries.
Presenting the base unit
Your base is designed to fit into your family environment.
Base unit chargin
g
contacts
Base unit button
Short press:
- searches for
handsets
(paging).
Long press:
- matching of
handsets.
Indicator light (underside
of the base unit):
One flash: power on/off.
Constantly lit: handset on line.
Flashing: missed call(s),
new SMS message(s)
SET-UP

ENGLISH
8
SET-UP
Presenting the handset
You will appreciate the design and quality of the handset during
conversations with your callers.
1. Earphone
2. Display
3. Access list of calls made / Navigate to menus above
4. Return key / Secret mode key during communication
(Secret)
5. Speaker key / Answering machine rapid access key
6. Phone pick-up
7. Alphanumeric keypad
8. Star key / Lock keypad
9. Handset charging contacts
10. OK / Menu key
11. R key / Navigate to menus to the right
12. Hang up / Handset on/off
13. Phonebook access / Navigate to menus below
14. # key / Intercommunication (between handsets)
15. Microphone
1
2
3
4
5
6
7
9
10
11
12
13
15
14
8

9
SET-UP
The Navigator
This is the quick menu selection device
Base unit connection
Before making connections read the safety instructions located at
the start of this booklet.
Insert the telephone point into its housing at the rear face of the
base unit and connect the other end of the lead to the telephone
wall point.
Connect the end of the mains power unit lead to the rear of the
base unit and the mains power unit to a mains power supply. The
base will emit an audible tone.
Pass the wires through the cable guide and place the base in its
desired location.
Quick phoneboo
k
access / Navigate t
o
menus below
Quic
k
access to
l
ist o
f
ca
ll
s
made / Navigate to menus
above
Speaker key /
Answering machine
rapid access key
R key / Navigate to
menus to the right
Mains point Telephone point

ENGLISH
10
SET-UP
Inserting batteries in the handset
Open the battery compartment cover.
Place the new batteries in the compartment.
Make sure that the polarity is correct!
Close the compartment.
Remove the protective film from the display, place the handset in
the base unit in order to fully charge the batteries.
The charging icon is activated on the display and shows you the
charging status. When the icon is full your batteries are fully
charged.
Worn out batteries must be disposed of in accordance with the
recycling instructions given in paragraph Environment of this
booklet.
Use only approved rechargeable AAA format NiMH type 1.2 V
650 mAh batteries. In order to ensure optimum charging, when
first used leave the handset on the base unit for at least 12 hours.
During charging batteries may become warm. This is quite
normal and is not dangerous.
Operating time of the batteries
The operating time of the batteries in standby is up to five days
or up to ten hours for longer calls.
Service life of the batteries
To increase the service life of the batteries, note the following:
- Do not short-circuit the plug.
- Use your handset as a mobile phone and do not replace it in
the base station or charger (accessories) to be charged after
every phone call.
+
+
Direction of insertion
Direction of opening

11
SET-UP
Charging status of the battery
The charging status of the batteries appears in the display.
The number of bars show the charging status of the battery
(" " flat, " " charged). When the batteries are almost flat,the
display back lighting is deactivated and a warning tone is
emitted. This also happens if the batteries which are charging are
removed briefly and then replaced. As a rule new batteries only
attain their full capacity after several charge/discharge cycles.
Although the battery display shows that the batteries in a handset
are charged, you should take into account that the length of
normal calls and availability time is limited at the beginning.
Switching the handset on and off
To switch on your handset press the » « key.
To switch off the handset hold down the » « key for a period.
Your handset is then switched off.
Selecting the country
After inserting the batteries or after you have fully reset the
handset and the base, a menu appears in the display for
selecting the country. This is required if a country group consists
of two or more countries. You must also select the network
operator for the United Kingdom and Ireland.
1. Select the country with » ()« or » ()« and
confirm with the »OK« function button on the right.
Out of range
When the distance between the handset and the base is too
great, the "Antenna" signal flashes.
Move back towards the base unit
When the "Antenna" symbol stops flashing the link with the
base has been re-established.
Navigating through the menus
A single press of the »Menu« key gives you an overall view of the
various functions.
SMS
Phonebook
Display
Alarm/Clock
Country
OKEsc
England
Phonebook
Esc OK

ENGLISH
12
SET-UP
Remark: The »TAM« menu is only available on the Illion A1
model.
Operation using the menus and keys
Press the »Menu« key to access to the menus.
The various menus are seen on the display
Select the menu of your choice by pressing the keys of the
navigator » ()«, » ()«, » ()« or » ()«.
To enter the selected menu press the »OK« key.
To return to the previous menu press the »Esc« key.
In the menu, select the functions by pressing the
navigator keys » « or » « and save the modified settings by
pressing the »OK« key.
The activated setting is shown by » «.
Once you have selected or set the function, you can return to the
previous menu level (»Esc« key) or leave the menu (press » «).
Example: to change the handset melody for external calls:
1. Press the »Menu« key.
2. Select »Sound Setting«, press the »OK« key.
3. Select »HS Ring« using the » « or » « keys, press the
»OK« key.
4. Select »Melody« using the » « or » « keys, press the
»OK« key.
5. Select the handset melody using the » « or » « keys,
press the »OK« key.
6. Press on the » « key to exit the menu.
Sound Setting
Settings
Call log
TAM

13
BLOCK DIAGRAM
SMS - Write
- Inbox
-Draft
- Outbox
- Service Center
Phonebook - Option - New Entry
-ViewEntry
- Edit Entry
- Delete Entry
- Delete all
-PBtransfer
-QuickDial
Display - Wallpaper
- Contrast
Alarm/Clock - Clock Setting
- Alarm Setting
Sound Setting - Handset
Volume
- Earpiece
- Speaker
- HS Ring - Melody
-Volume
- Internal Ring - Melody
-Volume
- BS Ring - Melody
-Volume
-Tone -KeyTone
- Charge tone
-Batterylow
-OutofRange
- List end tone
BLOCK DIAGRAM

ENGLISH
14
BLOCK DIAGRAM
Settings - Handset Set. - Auto answer
-RegisterHS
- Economy mode
- Handset Name
- Language
-DefaultHS
- Baby Call
- Base Set - Change PIN
- Remove HS
-DefaultBS
-FlashTime
-PauseTime
- Call log
-Auto-Delete
Call log - Option - Save toP. Book
-Delete
- Delete all

15
MAKING TELEPHONE CALLS
Making an external call
External calls are calls made to the public network.
Enter the number of the person you are calling using the keypad
and press the » « key. In the event of an error being made in
entering a number, press the » « key to delete the incorrect
number.
If the person you are calling is recorded in the phonebook
contact list, press the » « key, select the name of the person
you are calling then press the » « key.
Answering a call
when a call is received, every handset registered on the base unit
will ring.
Press the » « key on one of the handsets to answer the call.
At the end of the conversation press the » « to hang up.
Making an internal call
Internal calls are calls between two handsets registered on the
same base unit. Internal calls are not charged for by your
operator.
Press the »INT« key, the numbers of handsets registered on the
base unit will appear on the display. Enter the number
corresponding to the handset that you wish to call.
At the end of the conversation press the » « key.
Using the call log
You can set the call log so that all the calls or missed calls are
displayed.
1. Open the menu by pressing the »Menu« function button on
the right.
2. Select »Settings« with »« ( ), »« ( ), » « or »R«
activate with the »OK« function button on the right.
3. Select »Base Set« with »« or »« and press the »OK«
function button on the right to activate.
Handset Set.
Base Set
Settings
MAKING TELEPHONE CALLS

ENGLISH
16
MAKING TELEPHONE CALLS
4. Select »Call log« with »« or »« and press the »OK«
function button on the right to activate.
5. Select »All Call« or »Missed Call« with »« or »« and
press the »OK« function button on the right to activate.
– The calls are displayed.
6. Press » « to end the setting.
CLI (Caller Line ID) function
Before using the phone number transfer (CLI), please contact
your provider to subscribe to Caller Line Identification. This will
enable you to receive calls displaying the callers number.
There might be a special rate or a fee required for this function
to be enabled.
If the caller’s phone number is in the phone book, the name of
the caller is displayed as well as the number.
If the caller has suppressed or not activated the CLI function,
»Unknown« appears.
Managing calls whilst communication is
underway
This function is available if your installation is made up of at least
two handsets registered on the same base unit.
Transfering a call to another handset
This function allows you to transfer the call that is in progress to
another handset registered on the same base unit.
Keep the »INT« pressed, the external call is put on hold, select the
handset to which you want to transfer the call.
When the handset being called is picked up, press the »Option«,
key, select »Call Transfer«.
Remark: if the handset called does not answer, you can
recover the call, Keep pressing the »INT« key.
Switching between an external and internal call
Keep the INT« key pressed, the external call is put on hold, select
the handset to which you want to transfer the call.
When the handset being called is picked up, press the »Option«,
key, select »Switch Calls«.
Base Settings
Change PIN
Remove HS
Default BS
Flash Time
Pause Time
Call Log

17
MAKING TELEPHONE CALLS
Setting up a three party conference call
Keep the INT« pressed, the external call is put on hold, select the
handset to which you want to transfer the call.
When the handset being called is picked up, press the »Option«,
key, select »Conference«.
You can revert to a communication between two parties for both
internal and external calls. During a conference press the
»Option« key.
Select »Switch to Ext« to talk to the external caller.
Select »Switch to Int« to talk to the internal caller.
Locking the handset keypad
Keep the »*« key pressed until the » « icon is shown on the
display.
To unlock the keypad keep the »*« key pressed until the » «
icon disappears from the display.
Using in hands-free mode
Hands-free mode allows you to hold a dialogue with your caller
without holding the handset. It also allows other persons present
in the room to hear the conversation.
Press the » « key, the » « icon appears on the display. Dial
the number of the person you are calling.
When a call is received, press the » « key. Hands-free mode is
then activated.
Setting the volume
this function allows you to set the listening volume during a
conversation.
Press the » « or » « keys to increase or reduce the listening
volume. You can set the volume to a level from 1 to 5.
The volume level selected is shown on the display.
Remark: this function is also available in hands-free mode.

ENGLISH
18
MAKING TELEPHONE CALLS
Secret mode
This function enables you to activate or deactivate the handset
microphone during a call. You can therefore allow your caller to
hear or prevent your caller from hearing what you are saying.
Press the » « key, the person on the line cannot then hear what
you are saying.
To deactivate secret mode press the » «, key. The person on
the line can now hear what you are saying.
Calling back if busy
If the number of the caller is busy, you can activate the redial.
When the line is free, your handset gives a ring tone.
1. Remove the handset from the base station.
– When the setting is activated, the call is taken
automatically,
or
press » « if the handset is not in the base station.
Activating the redial
When you hear the busy tone ...
1. Press the »Option«, function button on the left, select the
»Rich. se occup.« and activate by pressing the »OK«
function button on the right.
2. After confirmation from the telephone network,
press » «.
Note: The function remains active for approx.
45 minutes. Calling back is only possible during
this time.

19
SMS SERVICES
You telephone allows you to send, receive and monitor SMS
messages (known as mini-messages) which are sent to another
telephone equipped with an SMS function.
The SMS send and receive functions available in your telephone
will only operate if you have taken out an appropriate
subscription with your operator.
Sending a message
this function allows you to draft a message and send it to the
person you are calling.
Go to »Menu« / »SMS« / »Write«.
Enter the message text by pressing the appropriate keys in order:
Remark: In the event of an error during entry, the last letter
can be deleted by pressing the » « key.
Briefly touching the »#« key allows you to select
capital or small characters.
When you have finished an entry, press the »OK« key.
Enter the number of the person to receive the message or select
the number from the phonebook, then press the »OK« key.
Select »Send SMS« to send the SMS or »Save SMS« to store it in
the Draft box.
Write
Inbox
Draft
Service Center
Outbox
SMS
OKEsc Key 1
Key 2
Key 3
Key 4
Key 5
Key 6
Key 7
Key 8
Key 9
Key *
Key 0
Key # inversion UPDATE/min
Number:
_
Write
PBOOKEsc
SMS SERVICES

ENGLISH
20
SMS SERVICES
Receiving messages
This function allows you to read messages received, to reply to
messages, to transfer messages, to store a sender's telephone
number and to delete messages.
Go to »Menu« / »SMS« / »Inbox«.
Select the message that you wish to view by using the » «
or » « keys.
Press the »Read« key. The text of the message will appear on the
display.
To access the various options press the »Option« keys.
To view a stored message (Draft)
This function allows you to store entered messages, to edit them
and send them later or delete them.
Go to »Menu« / »SMS« / »Draft«.
Select the message that you wish to view using the » «
or » « keys.
Press the »Read« key. The text of the message will appear on the
display.
To access the various options press the »Option« keys.
Mr. Sample
01237856
text
Inbox
ReadEsc
Forward
Reply
Use Text
Inbox
OKEsc
Save to P.Book
Call
Delete
Edit SMS
Draft
OKEsc
SendSMS
Delete
Delete all
