CUC 2030 N/2031
2031 N/2040 N
Melbourne SE 7210 TOP
Melbourne SE 7210 NIC/TOP
ST 63-700 NIC/FT
ST 63-700 DPL/NIC/FT
ST 63-710 NIC/text
ST 70-700 NIC/FT
ST 70-700 DPL/NIC/FT
ST 70-710 NIC/text
ST 72-865 NIC/TOP
Service Manual TV
Zusätzlich erforderliche
Unterlagen für den Komplettservice
Additionally required
Service Manuals for the Complete Service Btx * 32700 #
Sachnummer
Part Number 72010-020.71
Änderungen vorbehalten
Subject to alteration
Printed in Germany
VK222 0997
Ergänzung
Supplement
1
Sach-Nr./Part No.
72010-020.71
GrundigService
Hotline Deutschland...
TV/SAT
VCR/LiveCam
HiFi/Audio
Car Audio
Telekommunikation
Fax:
0180/52318-41
0180/52318-42
0180/52318-43
0180/52318-44
0180/52318-45
0180/52318-51
...Mo.-Fr. 8.00-16.30 Uhr
Ersatzteil-Bestellannahme:
0180/52318-40
0180/52318-50
Telefon:
Fax:
Technik:
Service
Manual
CUC 2030/N
CUC 2031/N
Sach-Nr./Part No.
72010-020.70
Service
Manual
Sicherheit
Safety
Sach-Nr./Part No.
72010-800.00
Service
Manual
CUC 2000
Sach-Nr./Part No.
72010-350.35

Allgemeiner Teil / General Section CUC 2030 N / 2031 / 2031 N / 2040 N
2GRUNDIG Service
Es gelten die Vorschriften und Sicherheitshin-
weise gemäß dem Service Manual "Sicherheit",
Sach-Nummer 72010-800.00, sowie zusätzlich
dieeventuellabweichenden,landesspezifischen
Vorschriften!
The regulations and safety instructions shall be
validasprovidedbythe"Safety"ServiceManual,
part number 72010-800.00, as well as the
respective national deviations.
Table of Contents
Page
Technical Data ................................................................................ 3
Module List...................................................................................... 5
Chassis Board PCBs ...................................................................... 6
Dolby Surround Board 29504-104.75 ........................................... 13
Signal Chassis A ........................................................................... 15
Signal Chassis B ........................................................................... 19
Control Unit 29501-082.62............................................................ 22
Control Unit 29501-082.66............................................................ 24
Socket Board 29305-160.53 ......................................................... 26
Socket Board 29305-008.39 ......................................................... 27
Spare Parts List ............................................................................ 28
General Part
Test Equipment / Aids
Variable isolating transformer Test/Sweep Generator
Colour Generator Oscilloscope
DC Voltmeter AF Voltmeter
AF Generator Frequency counter
Please note the Grundig Catalog "Test and Measuring Equipment"
obtainable from:
Grundig Instruments
Test- und Meßsysteme GmbH
Würzburger Str. 150, D-90766 Fürth/Bay.
Tel.[phone], Telefax 0911/703-4130
Inhaltsverzeichnis
Seite
Technische Daten ........................................................................... 3
Modulübersicht................................................................................ 5
Chassisplatte PCBs ........................................................................ 6
Dolby-Surround-Platte 29504-104.75 ........................................... 13
Signal-Chassis A........................................................................... 15
Signal-Chassis B........................................................................... 19
Bedieneinheit 29501-082.62 ......................................................... 22
Bedieneinheit 29501-082.66 ......................................................... 24
Buchsenplatte 29305-160.53 ........................................................ 26
Buchsenplatte 29305-008.39 ........................................................ 27
Ersatzteilliste................................................................................. 28
Allgemeiner Teil
Meßgeräte / Meßmittel
Regeltrenntrafo Meß-/Wobbelsender
Farbgenerator Oszilloskop
DC-Voltmeter NF-Voltmeter
NF-Generator Frequenzzähler
BeachtenSiebittedasGrundigMeßtechnik-Programm,dasSieunter
folgender Adresse erhalten:
Grundig Instruments
Test- und Meßsysteme GmbH
Würzburger Str. 150, D-90766 Fürth/Bay.
Tel.[phone], Telefax 0911/703-4130
GB
D
For these TV sets the Service Manual CUC 2030 / CUC 2031 N is
applicable.
This Manual describes the differences and the additionally fitted
modules of the TV receivers.
The Module List and the relevant part numbers are listed in the table
on page 5.
Basic instructions for servicing are given in the:
– Safety Instructions (Part No. 72010-800.00)
–Service Manual CUC 2030 / CUC 2031 N (Part No. 72010-020.70)
–1st Suppl. CUC 2030 N / CUC 2040 N (Part No.72010-020.71)
Für diese Geräte gilt das Service Manual CUC 2030 / CUC 2031 N.
Diese Ergänzung dokumentiert die Unterschiede bzw. zusätzlichen
Bestückungen der Geräte.
Die Modulübersicht und die Sachnummern der einzelnen Bausteine
entnehmen Sie bitte der Tabelle auf Seite 5.
Grundlage für den Service sind:
–Sicherheitsvorschriften (Sach-Nr. 72010-800.00)
–ServiceManual CUC 2030/ CUC 2031N (Sach-Nr. 72010-020.70)
–1.Ergänzung CUC 2030 N / CUC 2040 N (Sach-Nr. 72010-020.71)

CUC 2030 N / 2031 / 2031 N / 2040 N Allgemeiner Teil / General Section
GRUNDIG Service 3
ST 70-700 NIC/FT
(CUC 2030N ) ST 63-700 NIC/FT (CUC 2030N) ST 70-700 DPL/NIC/FT (CUC 2040N) ST 63-700 DPL/NIC/FT (CUC 2040N) ST 70-710 NIC/text (CUC 2030N )
Bildröhre / Picture Tube
Sichtbares Bild
Visible picture 66cm 59cm 66cm 59cm 66cm
Bildschirmdiagonale
Screen diagonale 70cm (28") FST Black Line D, Philips 63cm (25") FST Black Line D, Tesla 70cm (28") FST Black Line D, Philips 63cm (25") FST Black Line D, Tesla 70cm (28") FST Black Line D, Philips
Ablenkwinkel
Deflection angle 110°110°110°110°110°
Bildwechselfrequenz
Vertical frequency
50Hz 50Hz 50Hz 50Hz 50Hz
Elektronik / Electronic
Programmspeicherplätze
Programme positions
79 TV + 3 AV 79 TV + 3 AV 79 TV + 3 AV 79 TV + 3 AV 79 TV + 3 AV
AV-Auswertung
AV evaluation auf jeden Programmplatz programmierbar / programmable for every programme position
Tuner
VST-Spannungs synthesizer
tuning UHF/VHF, glob. pinning
VST voltage synthesizer tuning
UHF/VHF, glob. pinning
VST-Spannungs synthesizer
tuning UHF/VHF, glob. pinning
VST voltage synthesizer tuning
UHF/VHF, glob. pinning
PLL-Frequenz synthesizer
tuning UHF/VHF, glob. pinning
PLL frequency synthesizer
tuning UHF/VHF, glob. pinning
PLL-Frequenz synthesizer
tuning UHF/VHF, glob. pinning
PLL frequency synthesizer
tuning UHF/VHF, glob. pinning
VST-Spannungs synthesizer
tuning UHF/VHF, glob. pinning
VST voltage synthesizer tuning
UHF/VHF, glob. pinning
TV-Normen
TV-Standard
PAL, NTSC 4.43 MHz,
BG, I, DK, K'/D (Pal only) PAL, NTSC 4.43 MHz, BG, I, DK, K'/D (Pal only) PAL, NTSC 4.43 MHz, BG, I, DK, K'/D (Pal only) PAL, NTSC 4.43 MHz, BG, I, DK, K'/D (Pal only)
PAL, SECAM,
BG, I, DK, K'/D (Pal only)
via AV: NTSC 4.43 MHz +
3.58MHz
Stereo Systeme
Stereo systems
Deutsch A2 für BG+DK
German A2 for BG+DK
Nicam 5,85+6,52
Deutsch A2 für BG+DK
German A2 for BG+DK
Nicam 5,85+6,52
Deutsch A2 für B/G/D/K
German A2 for B/G/D/K
Nicam 5,85+6,52
Deutsch A2 für B/G/D/K
German A2 for B/G/D/K
Nicam 5,85+6,52
Deutsch A2 für BG+DK
German A2 for BG+DK
Nicam 5,85+6,52
Videotext
Teletext
8 Seiten TOP/FLOF-text, VPS,
O/W Europa, Türkei
8 pages TOP/FLOF-text, VPS,
E/W Europe, Turkey
8 Seiten TOP/FLOF-text, VPS,
O/W Europa, Türkei
8 pages TOP/FLOF-text, VPS,
E/W Europe, Turkey
8 Seiten TOP/FLOF-text, VPS,
O/W Europa, Türkei
8 pages TOP/FLOF-text, VPS,
E/W Europe, Turkey
8 Seiten TOP/FLOF-text, VPS,
O/W Europa, Türkei
8 pages TOP/FLOF-text, VPS,
E/W Europe, Turkey
1 Seiten Text, Ost u. West
Europa, Türkei
1 pages text, East and Western
Europe, Turkey
Musikleistung
Music power Stereo 2 X 8W Stereo 2 X 8W Stereo 2 X 18W,
with DPL 60W Stereo 2 X 18W, with DPL 60W Stereo 2 X 8W
Anschlüsse Front / Connections Front
Kopfhörer
Headphones Stereo 3,5mm Klinkenbuchse, Lautstärke einstellbar / 3.5mm jacksocket, volume controllable
Video IN 1 x Cinch 1 x Cinch 1 x Cinch 1 x Cinch 1 x Cinch
Audio IN 2 x Cinch 2 x Cinch 2 x Cinch 2 x Cinch 2 x Cinch
Anschlüsse Rückwand / Connections Rear Panel
Euro AV 1 (schwarz/black)
FBAS in-/output, RGB input,
SBAS input FBAS in-/output, RGB input, SBAS input FBAS in-/output, RGB input, SBAS input FBAS in-/output, RGB input, SBAS input FBAS in-/output, RGB input, SBAS input
Euro AV 2 (schwarz/black)
FBAS in-/output, RGB input,
SBAS input FBAS in-/output, RGB input, SBAS input FBAS in-/output, RGB input, SBAS input FBAS in-/output, RGB input, SBAS input FBAS in-/output, RGB input, SBAS input
Netzteil / Mains Stage
Netzspannung (Regelber.)
Mains voltage (variable)
165…265V 165…265V 165…265V 165…265V 165…265V
Netzfrequenz
Mains frequency 50 / 60Hz 50 / 60Hz 50 / 60Hz 50 / 60Hz 50 / 60Hz
Leistungsaufnahme
Power consumption
ca. 75W ca. 70W ca. 80W ca. 80W ca. 75W
Standby 5W 5W 5W 5W 5W
Technische Daten / Technical Data

Allgemeiner Teil / General Section CUC 2030 N / 2031 / 2031 N / 2040 N
4GRUNDIG Service
ST 63-710 NIC/text
(CUC 2030N) ST 72-865 NIC/TOP (CUC 2031N) Melbourne SE 7210 TOP (CUC 2031) Melbourne SE 7210 NIC/TOP (CUC 2031N)
Bildröhre / Picture Tube
Sichtbares Bild
Visible picture 59cm 68cm 68cm 68cm
Bildschirmdiagonale
Screen diagonale 63cm (25") FST, Black Line D, Tesla 72cm (29") Megatron, Invar,
Super Flat,
CCS, Black Line S, Philips
72cm (29") Megatron, Invar,
Super Flat,
CCS, Black Line S, Philips
72cm (29") Megatron, Invar,
Super Flat,
CCS, Black Line S, Philips
Ablenkwinkel
Deflection angle 110°110°110°110°
Bildwechselfrequenz
Vertical frequency 50Hz 50Hz 50Hz 50Hz
Elektronik / Electronic
Programmspeicherplätze
Programme positions 79 TV + 3 AV 79 TV + 2 AV 79 TV + 2 AV 79 TV + 2 AV
AV-Auswertung
AV evaluation auf jeden Programmplatz programmierbar / programmable for every programme position
Tuner VST-Spannungs synthesizer
tuning UHF/VHF, glob. pinning
VST voltage synthesizer tuning
UHF/VHF, glob. pinning
PLL-Frequenz synthesizer
tuning UHF/VHF, glob. pinning
PLL frequency synthesizer
tuning UHF/VHF, glob. pinning
PLL-Frequenz synthesizer
tuning UHF/VHF, glob. pinning
PLL frequency synthesizer
tuning UHF/VHF, glob. pinning
PLL-Frequenz synthesizer
tuning UHF/VHF, glob. pinning
PLL frequency synthesizer
tuning UHF/VHF, glob. pinning
TV-Normen
TV-Standard
PAL, SECAM,
BG, I, DK, K'/D (Pal only)
via AV: NTSC 4.43 MHz +
3.58MHz
PAL, NTSC 4.43 MHz,
BG, I, DK,K'/D (Pal only) PAL, NTSC 4.43 MHz, BG PAL, NTSC 4.43 MHz, BG, I, DK,K'/D (Pal only)
Stereo Systeme
Stereo systems Deutsch A2 für BG+DK, K´
German A2 for BG+DK, K´
Nicam 5,85+6,52
Deutsch A2 für B/G/D/K
German A2 for B/G/D/K
Nicam 5,85+6,52 Deutsch A2
German A2 Deutsch A2 für B/G/D/K
German A2 for B/G/D/K
Nicam 5,85+6,52
Videotext
Teletext
1 Seiten Text, Ost u. West
Europa, Türkei
1 pages text, East and Western
Europe, Turkey
8 Seiten TOP/FLOF-text, VPS,
O/W Europa, Türkei
8 pages TOP/FLOF-text, VPS,
E/W Europe, Turkey
8 Seiten TOP/FLOF-text, VPS,
O/W Europa, Türkei
8 pages TOP/FLOF-text, VPS,
E/W Europe, Turkey
8 Seiten TOP/FLOF-text, VPS,
O/W Europa, Türkei
8 pages TOP/FLOF-text, VPS,
E/W Europe, Turkey
Musikleistung
Music power Stereo 2 X 8W Stereo 2 X 8W Stereo 2 X 20W Stereo 2 X 20W
Anschlüsse Front / Connections Front
Kopfhörer
Headphones Stereo 3,5mm Klinkenbuchse, Lautstärke einstellbar / 3.5mm jacksocket, volume controllable
Video IN 1 x Cinch 1 x Cinch 1 x Cinch 1 x Cinch
Audio IN 2 x Cinch 2 x Cinch 2 x Cinch 2 x Cinch
Anschlüsse Rückwand / Connections Rear Panel
Euro AV 1(schwarz/black) FBAS in-/output, RGB input,
SBAS input FBAS in-/output, RGB input, SBAS input FBAS in-/output, RGB input, SBAS input FBAS in-/output, RGB input, SBAS input
Euro AV 2(schwarz/black) FBAS in-/output, RGB input,
SBAS input FBAS in-/output, RGB input, SBAS input FBAS in-/output, RGB input, SBAS input FBAS in-/output, RGB input, SBAS input
Netzteil / Mains Stage
Netzspannung (Regelber.)
Mains voltage (variable) 165…265V 165…265V 165…265V 165…265V
Netzfrequenz
Mains frequency 50 / 60Hz 50 / 60Hz 50 / 60Hz 50 / 60Hz
Leistungsaufnahme
Power consumption ca. 70W ca. 90W ca. 90W ca. 90W
Standby 5W 5W 5W 5W
Technische Daten / Technical Data

CUC 2030 N / 2031 / 2031 N / 2040 N Allgemeiner Teil / General Section GRUNDIG Service 5
Modulübersicht / Module List
Sachnummer
Part Number
ST 70-700
NIC/FT
CUC 2030N
ST 63-700
NIC/FT
CUC 2030N
ST 70-700
DPL/NIC/FT
CUC 2040N
ST 63-700
DPL/NIC/FT
CUC 2040N
ST 70-710
NIC/text
CUC 2030N
ST 63-710
NIC/text
CUC 2030N
ST 72-865
NIC/TOP
CUC 2031N
Melbourne SE7210
TOP
CUC 2031
Melbourne SE7210
NIC/TOP
CUC 2031N
Tuner PLL 8140-601-612
––
••
––
•••
Tuner VST 8140-601-610
••
––
••
–– –
Bedieneinheit
Control Unit 29501-082.59
••••
––– – –
29501-082.62
––––
••
–– –
29501-082.66
––––––
•
––
Keyboard 29501-083.25
––––––– – –
29501-083.44
–––––––
••
Buchsenplatte
Socket Board
29305-008.38
–––––––
••
29305-008.39
––––––
•
––
29305-160.53
–
•
––––– – –
Cinch-Buchsenplatte
Phone Socket Board
29305-008.37
––––––– – –
Bildrohrplatte
CRT Panel 29305-122.18
––––––
•••
29305-122.16
••••••
–– –
Netzschalterplatte
Main Switch Panel
29305-165.71
––––––– – –
29305-165.73
–––––––
••
TP 900 29642-061.11
–––––––
••
TP 800 29642-061.01
––––––
•
––
TP 715 29642-062.11
•
–
•
–
••
–– –
TP 713 29642-063.04
–
•
–
•
––– – –
NF-Verstärker
AF Amplifier 29524-104.75
––
••
––– – –
BSO-Platte
BSO Board 29305-119.44
––––––
•
––
Panorama View 29305-119.43
––––––
•
––

Platinenabbildungen und Schaltpläne / Layout of the PCBs and Circuit Diagrams CUC 2030 N / 2031 / 2031 N / 2040 N
6 GRUNDIG Service
Pos.-Nr./ Koordinaten/
Pos. No. Coordinates
XY
Pos.-Nr./ Koordinaten/
Pos. No. Coordinates
XY
Pos.-Nr./ Koordinaten/
Pos. No. Coordinates
XY
Pos.-Nr./ Koordinaten/
Pos. No. Coordinates
XY
Pos.-Nr./ Koordinaten/
Pos. No. Coordinates
XY
AN10 191 114
AN11 358 5
AN13 358 256
AN14 191 114
AN15 5 256
AN16 5 114
AN17 5 5
AN30 344 251
AN31 10 251
ASIS01 135 21
ASIS02 135 31
ASIS03 101 26
ASIS04 131 43
ASIS05 131 46
ASIS06 74 67
ASIS07 147 86
ASIS08 144 83
ASIS09 94 111
ASIS10 104 110
ASIS11 109 110
ASIS12 159 151
ASIS13 79 115
ASIS14 147 91
ASIS15 175 46
ASIS16 108 71
BR100 94 194
BR101 20 216
BR102 170 178
BR104 114 14
BR105 63 127
BR106 154 108
BR107 123 14
BR108 117 14
BR109 120 14
BR110 347 236
BR111 288 148
BR112 185 167
BR113 148 74
BR114 148 71
BR115 68 224
BR116 165 245
BR117 96 144
BR118 94 144
BR119 24 74
BR120 96 189
BR123 278 11
BR124 161 25
BR125 161 21
BR126 131 121
BR127 199 167
BR128 203 155
BR129 186 184
BR130 208 165
BR131 191 160
BR132 121 214
BR133 168 137
BR135 69 145
BR136 233 85
BR137 95 175
BR138 63 154
BR139 80 92
BR140 60 89
BR141 63 77
BR142 104 46
BR143 63 74
BR144 63 81
BR146 286 65
BR147 211 133
BR148 180 196
BR149 177 199
BR150 194 166
BR151 185 138
BR152 56 125
BR155 27 149
BR156 177 102
BR157 175 100
BR158 22 149
BR159 25 149
BR160 62 86
BR161 79 125
BR162 162 165
BR163 68 38
BR164 71 35
BR165 159 59
BR166 269 220
BR167 217 176
BR169 289 175
BR170 164 94
BR171 161 54
BR172 189 235
BR173 200 133
BR174 186 233
BR175 35 149
BR177 116 144
BR178 123 144
BR179 18 194
BR180 72 189
BR181 63 222
BR182 61 222
BR183 110 199
BR184 168 28
BR185 88 89
BR186 59 117
BR187 138 26
BR188 134 68
BR189 141 26
BR190 135 26
BR192 264 246
BR193 46 156
BR194 190 11
BR195 275 16
BR196 199 211
BR197 209 246
BR198 192 144
BR199 160 90
BR201 58 191
BR202 9 91
BR203 81 171
BR204 74 48
BR205 142 247
BR206 93 105
BR207 142 250
BR208 41 9
BR209 195 226
BR210 164 45
BR212 127 183
BR213 101 108
BR214 94 24
BR215 156 214
BR216 176 126
BR217 121 117
BR218 49 230
BR219 185 94
BR220 108 230
BR221 49 144
BR222 49 147
BR223 127 144
BR224 23 115
BR225 70 44
BR226 260 141
BR227 19 153
BR228 71 33
BR229 239 150
BR230 161 30
BR231 46 72
BR232 152 67
BR233 108 77
BR234 240 106
BR235 15 44
BR236 29 55
BR237 155 111
BR238 80 84
BR32339 95 180
BR32340 95 183
BR32451 72 168
BR34073 80 117
BR40042 57 69
BR43005 35 198
BR43009 49 193
BR43098 162 234
BR43245 108 211
BR43255 106 211
BR43281 110 195
BR46022 125 109
BR52001 201 222
BR52002 210 226
BR52006 215 241
BR53001 270 239
BR53012 239 152
BR53072 235 221
BR53074 285 181
BR53076 289 178
BR53077 287 178
BR53078 296 187
BR54002 269 190
BR55001 184 188
BR55002 196 190
BR60012 294 84
BR60018 338 85
BR60019 233 102
BR60021 233 99
BR61040 281 131
BR61301 303 11
BR61307 328 21
BR61308 327 6
BR62501 264 76
BR62502 241 45
BR62503 239 25
BR81041 69 33
BR81042 66 38
BR81043 68 35
BR81061 161 50
C31041 149 229
C31042 157 225
C31044 156 203
C31046 159 193
C32021 120 175
C32023 61 111
C32024 60 96
C32108 135 98
C32327 46 207
C32332 54 206
C32334 57 121
C32343 24 210
C32346 31 210
C32360 37 208
C32364 60 210
C32423 112 175
C32438 151 189
C32454 48 173
C33019 156 161
C34021 127 128
C34041 116 160
C34063 156 155
C34071 155 136
C40011 22 61
C40012 28 36
C40014 18 81
C40061 19 74
C40062 29 49
C40063 42 78
C41011 31 20
C41022 13 36
C41032 15 29
C43002 29 222
C43007 35 222
C43012 10 230
C43017 21 222
C43022 42 222
C43027 48 222
C43032 73 226
C43037 55 222
C43079 118 228
C43098 124 228
C43249 69 239
C43266 95 225
C43282 112 223
C43284 80 181
C46001 74 61
C50013 195 149
C50016 202 191
C50026 213 191
C50027 210 213
C52001 204 234
C52002 193 236
C52003 200 234
C52004 226 221
C52006 213 234
C52247 125 169
C52254 156 169
C53001 290 221
C53002 253 228
C53006 281 221
C53007 264 221
C53009 234 244
C53011 304 246
C53013 235 236
C53016 353 220
C53017 353 200
C53031 292 188
C53032 288 188
C53072 235 221
C53073 222 195
C54001 289 164
C54002 274 161
C54004 214 151
C54011 251 158
C54012 228 143
C55003 192 188
C55004 205 182
C57016 169 82
C60001 288 105
C60002 335 43
C60007 281 99
C60009 334 89
C60011 314 49
C60013 335 56
C60014 325 44
C60016 325 35
C60018 310 88
C60019 263 89
C60021 263 99
C60022 213 98
C60023 238 73
C60024 196 81
C60026 228 65
C60027 215 65
C60028 233 80
C60036 346 34
C60037 317 57
C60038 329 68
C61016 345 154
C61017 346 179
C61036 295 141
C61037 315 154
Pos.-Nr./ Koordinaten/
Pos. No. Coordinates
XY
C61042 192 136
C61052 192 123
C61056 290 127
C61057 272 128
C61063 175 52
C61301 320 13
C61311 338 15
C62021 195 25
C62022 195 19
C62048 301 111
C62501 249 68
C62502 213 31
C62505 201 38
C81061 148 52
C81072 148 235
C81073 78 25
D31001 68 142
D31007 74 14
D32128 82 95
D40064 10 77
D43284 74 174
D43292 53 140
D50011 189 184
D50013 189 164
D50014 190 219
D50016 199 194
D52001 200 241
D53003 293 205
D53071 242 220
D53072 222 215
D54001 319 169
D54002 273 156
D54011 251 152
D55004 206 190
D57011 166 106
D57012 171 117
D57013 168 106
D57023 162 80
D57101 172 169
D57122 177 233
D60005 316 78
D60006 321 82
D60007 306 81
D60012 300 93
D60013 321 49
D60019 267 96
D60021 256 106
D60023 213 73
D60037 315 66
D61016 353 160
D61036 295 138
D61056 290 123
D81012 81 77
D81020 110 65
D81501 269 20
EU-AV01 39 244
EU-AV02 99 244
F32020 139 180
Bestückungskoordinaten der Bauteile auf dem
Chassis
-DieKoordinatenXundYsindsowohlalsmetrischeKoordina-
ten für die Originalplatine in Millimeter, als auch als absolute
Koordinaten für die vergrößerten Abbildungen der Platinen
verwendbar.
C --> Kondensator CC --> Chip-Kondensator
D --> Diode CD --> Chip-Diode
IC --> Integrierter Schaltkreis CIC--> Chip-IC
L --> Spule CL --> Chip-Spule
R --> Widerstand CR --> Chip-Widerstand
T --> Transistor CT --> Chip-Transistor
Assembly Coordinates of the Components at
the Chassis
-The X and Y coordinates can be used as both metric coordi-
nates in mm for the original circuit board and absolute
coordinates for the enlarged diagrams of the circuit boards.
C --> Capacitor CC --> Chip Capacitor
D --> Diode CD --> Chip Diode
IC --> Integrated Circuit CIC--> Chip IC
L --> Coil CL --> Chip Coil
R --> Resistor CR --> Chip Resistor
T --> Transistor CT --> Chip Transistor
Chassis Board
Coordinates of the Components on the Components Side (Top Side)
Chassisplatte
Koordinaten für die Bauteile der Bestückungsseite (Oberseite)

CUC 2030 N / 2031 / 2031 N / 2040 N Platinenabbildungen und Schaltpläne / Layout of the PCBs and Circuit Diagrams
GRUNDIG Service 7
Coordinates of the Components on the Components Side
(Top Side)
Koordinaten für die Bauteile der Bestückungsseite
(Oberseite)
Pos.-Nr./ Koordinaten/
Pos. No. Coordinates
XY
Pos.-Nr./ Koordinaten/
Pos. No. Coordinates
XY
Pos.-Nr./ Koordinaten/
Pos. No. Coordinates
XY
Pos.-Nr./ Koordinaten/
Pos. No. Coordinates
XY
Pos.-Nr./ Koordinaten/
Pos. No. Coordinates
XY
Pos.-Nr./ Koordinaten/
Pos. No. Coordinates
XY
F32101 127 93
F32109 127 102
F32121 99 89
F32152 145 115
F32153 145 119
F32410 148 198
F32412 139 168
F33025 145 125
IC32000 45 190
IC32420 116 185
IC34015 124 144
IC40000 33 74
IC43280 107 211
IC50020 187 205
IC60010 328 54
IC61040 184 155
IC61050 184 105
IC61060 184 55
IC61310 328 13
IC80000 106 25
IC81050 105 46
IC82000 138 50
IC82005 138 39
L31041 125 213
L31043 125 201
L32023 67 111
L32026 58 102
L32109 131 109
L32342 53 164
L32451 63 166
L43098 162 234
L46021 104 61
L46022 125 110
L53001 270 239
L53002 244 236
L53003 266 234
L53011 294 239
L53012 249 141
L53021 246 191
L53074 247 171
L54002 272 186
L55006 217 167
L60006 340 83
L60012 309 99
L60028 247 95
L61016 350 148
L61036 333 149
L61056 320 144
L62501 238 33
L81061 161 50
NETZ01 283 53
NETZ02 275 53
NETZSCH.287 35
OK60031 316 24
Q32305 66 208
Q34043 115 167
Q34044 102 167
Q80001 106 34
R21117 305 174
R32023 79 102
R32359 11 213
R34031 88 86
R34056 114 125
R34057 110 125
R34058 106 125
R34059 103 125
R34062 80 121
R34063 85 112
R34066 85 109
R40011 49 36
R40012 49 46
R40014 44 36
R40066 16 49
R41011 41 21
R41022 30 149
R41030 33 149
R43098 130 247
R43099 127 239
R43248 83 249
R43291 51 133
R43292 51 131
R50001 169 217
R50003 169 220
R50011 203 152
R50021 196 210
R50022 201 210
R50023 205 210
R50024 204 203
R50026 208 199
R52001 210 226
R52002 290 245
R52004 214 221
R52006 215 241
R53001 281 236
R53002 290 208
R53011 290 234
R53016 272 172
R53021 263 196
R53074 260 174
R54001 329 171
R54002 269 190
R54003 280 191
R54012 266 150
R55003 196 175
R55006 204 171
R57007 164 173
R57017 163 136
R57118 177 246
R60001 340 63
R60002 345 45
R60003 345 63
R60004 349 43
R60005 319 66
R60006 322 66
R60007 340 45
R60008 279 85
R60009 274 100
R60012 294 84
R60013 331 64
R60014 329 40
R60016 295 96
R60018 306 39
R60021 236 61
R60029 296 78
R60031 335 33
R60032 316 31
R60033 315 35
R60036 345 30
R60037 314 38
R61018 338 156
R61019 215 139
R61043 177 153
R61053 170 65
R61301 303 11
R61302 310 16
R61303 310 7
R61304 278 14
R61305 316 10
R61306 280 9
R61307 328 21
R61308 327 6
R61311 334 14
R61312 341 15
R61313 347 16
R61314 354 126
R62049 294 111
R62505 203 58
R81020 114 65
R81051 118 65
R81052 121 65
R81053 123 65
R81054 126 63
R81504 159 33
SI40012 46 54
SI40070 41 15
SI52001 201 221
SI60001 241 114
SI61036 301 152
SI61056 304 125
SI62501 269 76
ST-BR 205 138
ST-CI01 61 15
ST-E 220 57
ST-H 19 19
ST-JOCH 231 174
ST-KA 97 125
ST-KB\IR 144 15
ST-LSL 15 59
ST-LSR 22 90
ST-MASSE 353 250
ST-MP 102 15
ST-NET01 272 60
ST-NF01 10 135
ST-NF02 10 193
ST-PIP01 146 215
ST-PIP02 146 91
ST-PIP03 101 160
ST-RGB 107 114
ST-SB01 80 200
Coordinates of the Components on the Solder Side
(Bottom Side)
Koordinaten für die Bauteile der Lötseite
(Unterseite)
Pos.-Nr./ Koordinaten/
Pos. No. Coordinates
XY
Pos.-Nr./ Koordinaten/
Pos. No. Coordinates
XY
Pos.-Nr./ Koordinaten/
Pos. No. Coordinates
XY
Pos.-Nr./ Koordinaten/
Pos. No. Coordinates
XY
Pos.-Nr./ Koordinaten/
Pos. No. Coordinates
XY
Pos.-Nr./ Koordinaten/
Pos. No. Coordinates
XY
CBR100 110 43
CBR101 130 54
CBR102 168 211
CBR103 116 49
CBR104 139 39
CBR105 99 49
CBR107 137 91
CBR109 165 233
CBR110 151 117
CBR111 145 27
CBR112 131 49
CBR113 81 217
CBR114 73 192
CBR115 18 113
CBR116 109 251
CBR118 81 253
CBR119 38 194
CBR120 41 194
CBR121 73 188
CBR122 18 190
CBR123 73 186
CBR124 131 209
CBR125 73 190
CBR126 150 232
CBR127 102 227
CBR128 111 197
CBR129 84 215
CBR130 136 103
CBR131 149 164
CBR133 106 141
CBR134 58 174
CBR136 94 143
CBR137 44 66
CBR138 81 77
CBR139 82 59
CBR140 95 21
CBR141 117 109
CBR142 129 77
CBR143 161 233
CBR145 144 46
CBR146 176 164
CBR147 157 41
CBR148 156 148
CBR149 162 229
CBR150 154 114
CBR151 112 108
CBR152 151 105
CBR153 64 121
CBR154 91 10
CBR155 83 12
CBR156 175 115
CBR157 87 148
CBR158 142 156
CBR160 116 63
CBR161 21 210
CBR162 44 215
CBR163 164 52
CBR164 28 26
CBR165 154 57
CBR166 84 218
CBR167 180 228
CBR168 167 105
CBR169 16 109
CC31019 139 228
CC31051 140 224
CC31052 140 222
CC32026 53 99
CC32109 135 98
CC32110 127 99
CC32111 115 82
CC32118 124 97
CC32121 105 89
CC32122 105 86
CC32123 105 84
CC32124 105 81
CC32152 136 128
CC32154 142 109
CC32301 61 194
CC32302 61 202
CC32303 66 194
CC32304 73 195
CC32306 69 194
CC32307 40 173
CC32308 40 169
CC32309 32 187
CC32310 29 187
CC32311 35 173
CC32312 35 169
CC32313 30 173
CC32314 27 187
CC32315 24 187
CC32316 30 169
CC32317 25 173
CC32318 25 169
CC32319 21 187
CC32321 20 173
CC32322 20 169
CC32328 41 202
CC32333 57 205
CC32336 60 25
CC32337 60 28
CC32341 40 179
CC32345 35 187
CC32347 34 194
CC32348 62 211
CC32350 41 187
CC32365 57 211
CC32401 119 87
CC32411 134 156
CC32412 155 194
CC32422 119 186
CC32451 66 171
CC32452 63 166
CC33014 139 128
CC33016 145 133
CC33017 137 133
CC33018 145 156
CC33020 133 167
CC33025 145 130
CC34022 130 127
CC34027 113 148
CC34032 75 89
CC34037 119 156
CC34039 121 130
CC34041 110 148
CC34042 105 146
CC34043 115 165
CC34044 101 164
CC34061 112 140
CC34064 130 132
CC34067 133 132
CC34069 150 132
CC34072 148 156
CC40022 42 66
CC40026 38 64
CC40028 27 59
CC40032 11 69
CC40036 24 73
CC40038 39 61
CC40042 38 86
CC40046 39 76
CC40048 16 88
CC40049 30 86
CC40052 16 96
CC40056 16 91
CC40059 24 101
CC43001 49 194
CC43003 29 230
CC43006 52 194
CC43008 23 230
CC43011 28 194
CC43013 25 244
CC43016 31 194
CC43018 18 230
CC43021 43 194
CC43023 89 230
CC43026 46 194
CC43028 86 230
CC43031 23 194
CC43033 83 244
CC43036 26 194
CC43038 79 231
CC43046 100 246
CC43047 86 253
CC43055 149 247
CC43057 39 246
CC43058 33 246
CC43061 47 246
CC43073 108 230
CC43074 148 242
CC43099 122 242
CC43248 72 247
CC43258 121 204
CC43259 121 201
CC43261 95 228
CC43281 99 197
CC43283 115 224
CC43286 140 26
CC43289 150 43
CC46004 138 61
CC46016 82 49
CC46017 102 49
CC46021 104 49
CC46022 107 49
CC46023 82 34
CC46024 77 59
CC46026 80 42
CC46027 79 34
CC50003 192 226
CC50004 198 221
CC50011 179 200
CC50012 173 203
CC50014 182 201
CC50017 176 202
CC50018 173 190
ST-SB02 80 147
ST-SHIFT 274 221
T52001 208 234
T53001 278 244
T55002 198 246
T60006 316 69
T61301 310 12
T81501 174 34
TR52001 222 231
TR53010 322 213
TR53011 321 210
TR61000 329 118
TR61001 333 121
TUNER 136 222

Platinenabbildungen und Schaltpläne / Layout of the PCBs and Circuit Diagrams CUC 2030 N / 2031 / 2031 N / 2040 N
8 GRUNDIG Service
Coordinates of the Components on the Solder Side
(Bottom Side)
Koordinaten für die Bauteile der Lötseite
(Unterseite)
Pos.-Nr./ Koordinaten/
Pos. No. Coordinates
XY
Pos.-Nr./ Koordinaten/
Pos. No. Coordinates
XY
Pos.-Nr./ Koordinaten/
Pos. No. Coordinates
XY
Pos.-Nr./ Koordinaten/
Pos. No. Coordinates
XY
Pos.-Nr./ Koordinaten/
Pos. No. Coordinates
XY
Pos.-Nr./ Koordinaten/
Pos. No. Coordinates
XY
CC52216 132 156
CC52217 133 147
CC52246 128 162
CC52248 124 156
CC52266 138 67
CC55001 161 158
CC57003 138 156
CC57004 162 120
CC57007 157 158
CC57016 175 118
CC57021 101 133
CC61038 183 146
CC61039 180 146
CC61041 181 153
CC61051 174 100
CC61058 180 100
CC61059 160 71
CC61060 177 100
CC61061 181 58
CC61062 181 52
CC61064 178 58
CC80001 105 30
CC80002 108 30
CC80007 100 30
CC81003 97 29
CC81007 97 59
CC81008 145 35
CC81012 96 67
CC81013 84 69
CC81016 119 49
CC81020 120 77
CC81021 82 30
CC81023 108 22
CC81026 116 29
CC81028 119 29
CC81032 122 29
CC81033 89 49
CC81034 92 49
CC81036 94 49
CC81038 98 43
CC81041 93 30
CC81042 90 30
CC81043 87 30
CC81046 122 25
CC81048 127 29
CC81050 108 76
CC81055 102 76
CC81057 124 29
CC81059 95 80
CC81062 113 43
CC81063 148 51
CC81082 87 21
CC81508 174 17
CC82001 141 50
CC82004 134 39
CD32152 138 113
CD32153 138 118
CD32411 144 185
CD32421 141 185
CIC32410 128 84
CIC43050 157 245
CR31003 75 204
CR31006 73 204
CR31008 69 24
CR31009 78 10
CR31011 67 48
CR31013 64 63
CR31018 63 43
CR31019 130 219
CR31021 140 230
CR31022 132 215
CR31028 60 61
CR31029 89 215
CR31038 63 52
CR31039 91 215
CR31041 124 213
CR31042 129 215
CR31043 131 211
CR31044 131 204
CR31045 125 201
CR31046 141 236
CR31047 131 234
CR31051 89 219
CR31052 91 219
CR32021 135 185
CR32026 53 96
CR32101 124 100
CR32102 114 107
CR32103 132 120
CR32104 118 106
CR32105 127 92
CR32106 120 106
CR32107 120 101
CR32108 125 117
CR32109 130 99
CR32110 133 103
CR32111 114 97
CR32112 114 89
CR32113 108 98
CR32114 110 98
CR32119 119 92
CR32124 101 82
CR32128 90 99
CR32129 94 98
CR32131 88 115
CR32132 119 90
CR32133 109 82
CR32141 105 97
CR32142 105 99
CR32143 105 94
CR32144 105 92
CR32150 114 86
CR32151 133 109
CR32152 137 124
CR32153 138 107
CR32156 138 109
CR32157 138 116
CR32158 139 103
CR32302 54 194
CR32303 37 187
CR32307 42 173
CR32309 33 178
CR32310 30 178
CR32311 37 173
CR32313 32 173
CR32314 27 178
CR32315 25 178
CR32317 27 173
CR32318 22 178
CR32319 22 173
CR32326 109 185
CR32327 111 185
CR32334 73 183
CR32335 55 186
CR32339 58 20
CR32340 61 20
CR32360 35 204
CR32364 62 187
CR32401 127 77
CR32402 125 77
CR32403 119 82
CR32404 130 71
CR32406 119 84
CR32407 119 80
CR32408 122 77
CR32411 151 173
CR32412 155 197
CR32416 144 164
CR32417 132 77
CR32418 134 77
CR32420 138 185
CR32421 136 77
CR32422 138 77
CR32426 114 185
CR32431 148 174
CR32432 148 184
CR32433 155 173
CR32436 155 192
CR32437 157 176
CR32438 153 178
CR32439 157 179
CR32441 133 185
CR32451 59 169
CR32452 56 157
CR32453 56 159
CR32454 57 169
CR33014 141 132
CR33018 160 177
CR33019 102 173
CR33025 145 125
CR34032 75 86
CR34032 80 105
CR34033 74 92
CR34038 95 140
CR34039 101 157
CR34040 103 155
CR34041 121 156
CR34042 108 148
CR34058 153 101
CR34059 150 101
CR34064 125 125
CR34067 118 125
CR34071 162 136
CR34072 130 66
CR34076 102 141
CR40021 28 113
CR40026 38 67
CR40028 27 62
CR40031 20 113
CR40036 15 69
CR40038 35 61
CR40041 25 113
CR40042 30 113
CR40046 37 81
CR40048 16 84
CR40049 30 89
CR40051 23 113
CR40056 16 94
CR40058 16 107
CR40059 27 104
CR40060 21 101
CR40061 15 74
CR40062 38 69
CR40063 39 81
CR40064 15 72
CR41011 41 18
CR41022 19 33
CR41023 23 33
CR41032 28 28
CR41033 31 27
CR43001 48 202
CR43003 32 230
CR43004 26 230
CR43006 51 202
CR43008 20 230
CR43011 29 203
CR43013 20 244
CR43014 22 244
CR43016 32 203
CR43018 15 230
CR43021 44 202
CR43023 91 230
CR43026 46 202
CR43028 83 230
CR43031 21 203
CR43033 80 244
CR43036 23 203
CR43038 76 231
CR43041 89 244
CR43042 86 244
CR43043 30 244
CR43044 27 244
CR43046 98 243
CR43047 93 243
CR43048 155 238
CR43051 161 252
CR43052 111 243
CR43053 109 247
CR43054 36 247
CR43056 159 252
CR43057 161 236
CR43058 168 246
CR43061 151 252
CR43062 46 243
CR43063 51 243
CR43066 38 243
CR43067 33 243
CR43072 106 243
CR43073 108 226
CR43074 107 247
CR43076 169 253
CR43077 166 246
CR43078 121 230
CR43079 118 219
CR43095 118 243
CR43096 115 244
CR43181 157 252
CR43182 157 238
CR43183 153 252
CR43184 161 238
CR43241 57 244
CR43242 60 244
CR43243 62 244
CR43246 62 249
CR43247 55 244
CR43249 114 202
CR43250 103 203
CR43254 111 203
CR43255 107 202
CR43258 117 203
CR43259 121 199
CR43261 103 221
CR43262 111 223
CR43263 105 221
CR43265 66 175
CR43266 100 221
CR43267 58 230
CR43271 94 219
CR43274 85 189
CR43276 115 219
CR43277 105 226
CR43281 99 200
CR43282 108 221
CR43283 96 219
CR43284 84 221
CR43285 64 175
CR43286 99 202
CR43287 99 204
CR43288 152 43
CR43289 156 28
CR43290 136 26
CR46001 87 49
CR46003 143 67
CR46004 134 60
CR46007 138 63
CR46008 142 62
CR46009 145 67
CR46016 84 49
CR46022 84 34
CR46024 80 59
CR46026 83 43
CR50002 180 196
CR50004 189 232
CR50012 177 194
CR52216 160 215
CR52217 156 150
CR52247 125 161
CR52250 159 165
CR52251 131 139
CR52252 140 156
CR52253 170 226
CR52254 166 226
CR52256 120 149
CR52263 178 225
CR52266 140 67
CR55001 180 180
CR55002 176 186
CR57001 171 117
CR57002 169 160
CR57003 166 126
CR57004 161 117
CR57006 171 126
CR57008 165 115
CR57011 168 115
CR57012 161 114
CR57016 167 107
CR57021 167 71
CR57022 165 71
CR57101 181 170
CR57113 169 238
CR57116 175 253
CR57117 177 247
CR57121 172 253
CR57124 178 232
CR61041 181 158
CR61044 174 133
CR61046 154 80
CR61051 180 104
CR61054 161 67
CR61056 163 71
CR80001 106 34
CR80007 103 30
CR81001 145 22
CR81003 100 43
CR81004 144 9
CR81006 145 32
CR81007 97 49
CR81008 122 49
CR81009 100 34
CR81010 86 43
CR81011 80 66
CR81012 87 73
CR81013 84 73
CR81014 104 64
CR81016 114 49
CR81017 87 69
CR81021 95 34
CR81022 96 43
CR81023 114 33
CR81024 115 43
CR81026 117 33
CR81027 117 43
CR81028 120 33
CR81029 119 43
CR81032 123 33
CR81033 84 59
CR81034 92 59
CR81036 94 59
CR81037 98 34
CR81040 89 43
CR81041 93 34
CR81042 90 34
CR81043 87 34
CR81044 91 43
CR81045 93 43
CR81046 131 33
CR81047 122 43
CR81048 128 33
CR81049 130 29
CR81050 84 100
CR81055 101 105
CR81056 124 43
CR81057 125 33
CR81058 126 72
CR81059 97 104
CR81061 105 76
CR81062 101 108
CR81063 96 83
CR81072 130 222
CR81073 82 23
CR81074 82 21
CR81076 82 26
CR81077 83 16
CR81081 87 26
CR81082 87 24
CR81083 103 43
CR81084 108 43
CR81086 112 49
CR81087 109 49
CR81091 106 43
CR81500 177 38
CR81501 172 38
CR81502 149 24
CR81503 175 40
CR81505 145 24
CR81507 173 11
CR81508 174 15
CR81509 161 56
CR81511 160 58
CR82001 136 52
CR82003 128 43
CR82004 126 43
CT31005 78 16
CT31010 63 48
CT31020 60 65
CT31030 63 57
CT32105 131 117
CT32111 114 102
CT32119 119 96
CT32122 109 86
CT32123 109 93
CT32124 100 97
CT32128 94 95
CT32132 114 93
CT32308 41 165
CT32310 36 165
CT32312 31 165
CT32315 26 165
CT32318 21 165
CT32415 138 169
CT32430 142 169
CT32431 148 169
CT32435 158 183
CT32440 153 183
CT32453 58 164
CT32454 53 164
CT34031 101 146
CT34075 91 129
CT40059 16 101
CT41022 21 37
CT41030 23 30
CT43095 119 247
CT43244 58 249
CT43246 67 247
CT43255 120 195
CT43289 153 37
CT43290 59 135
CT46009 146 63
CT52253 173 226
CT57005 167 120
CT57020 166 76
CT57021 167 97
CT57103 176 173
CT57112 173 238
CT57113 173 245
CT57124 173 232
CT61043 174 138
CT61053 166 65
CT81010 80 70
CT81015 99 67
CT81058 112 77
CT81080 86 16
CT81091 130 21
CT81502 168 38
CT81508 174 22
CT81511 158 80
OM01 338 9
OM02 28 253
OM30 345 242
OM31 20 251
OM32 300 4
OM40 88 57

GRUNDIG Service
CUC 2030 N / 2031 / 2031 N / 2040 N Platinenabbildungen und Schaltpläne / Layout of the PCBs and Circuit Diagrams
GRUNDIG Service
CUC 2030 N / 2031 / 2031 N / 2040 N Platinenabbildungen und Schaltpläne / Layout of the PCBs and Circuit Diagrams
29304-764.22 2L(03)
7
1
C31046
C60037
C55004
C52002
C40062
C40063
C32108
C52247
C33019
C34063
C32021
C31044
C32364
C32332
C43249
C57016
C32327
C32346
C32343
C43002
C43007
C43022
C43027
_C32438
C43098
_C32454
_BR61301
BR46022
_BR52001
BR61307
BR61308
BR52002
BR52006
C34021
C34041
C81061
C50013
C41011
C41022
C41032
_C34071
C31041
C32423
C31042
C43282
C32360
C43012
C43017
C43032
C43037
C40061
BR118
BR133
BR132
BR131
BR130
BR129
BR128 BR127
BR125
BR124
BR123
BR120
BR117
BR221
BR222
BR164
BR237
C61052
ST-PIP3
BR171
BR224
SI62501
SI60001
D50013
R55006
GS
T55002
R55003
R53021
R54001
R53011
R52006
R52004
113
IC50020
C54002
C52006
BE
T81501
C61037
C60011
C54001
C53031
C50016
C60016
C50027
C50026
C60036
C55003
C53032
C60009
C60007
C61016
C53009
_C60018
C53073
C62502
C62501
C53002
EC
T61301
R53016
C61301
C61311
C60014
C52003
C52001
_C60019 _C60021
BR62501
_BR53072
BR81043
L60012
L53002
L61036
L61056
L61016
L53003
L53001
_L81061
L60006
R60009
R60008
R60016
R60029
R21117
_R53074
C60001
C60026
C60027
C60024
C60023
C61056
C54011
C61036
G
D
S
T60006
TR52001
R61043
R61053
_R61308
R61303
R61302
R61311
_R61305
_R61307
R61301
R52002
D81020
D60012
L55006
1
NETZ1
1
NETZ2
1
ASIS13
1
ASIS16
1
ASIS14
1
ASIS12
1
ASIS11
1
ASIS9
1
ASIS10
1
ASIS8
1
ASIS7
1
ASIS4
1
ASIS6
1
ASIS5
1
ASIS3
1
ASIS15
1
ASIS1
1
ASIS2
C53011
C53013
1 3
46
OK60031
D61036
C62022
C62021
C62048
R62505
-+
-+
D60023
BR53077
BR81041
C62505
17
102
TR61001
NETZSCHALTER
L62501
D53003
13
ST-E
1 5 7
11
2 4 6 8
10 12
TR61000
14
58
IC61310
BE
T53001
C53072
C53006
C53017
C53016
C53007
C53001
13
46
_L60028
C43266
D53072
BR235
BR220
BR218
BR183
R50024
R54012
R62049
R61018
R61313
R60037
C61017
C54012
R60021
1
10
TR53011
D61056
_D60021
_D60019
D61016
L53074
L53011
L54002
L53021
BR217
BR126
L53012
BR81061
BR53076
_BR32340
BR55001
BR234
BR215
BR214
BR213
BR216
C40012
BR219
SI52001
SI61056
SI61036
SI40070
SI40012
R60001R60007
R60002 R60003
115
IC40000
C60022
D40064
D57023
D52001
D50014
D60037
D60005
D81501
D60013
D57101
D57013
D81012
D57011
D57122
D50016
D43284
_BR53074
BR53078
_BR53001
_BR53012
BR43255
BR43245
BR60012
14
58
IC60010
14
58
IC82005
14
58
IC82000
31
IC80000
12
1
TR53010
D55004
D50011
D31001
D31007
1
56 29
28
IC34015
F32410
F32121
F33025
F32101
BR210
BR199
BR198
BR197
BR196
BR195
BR194
BR192
BR189
BR188
BR187
BR186
BR185
BR184
BR182
BR181
BR225
BR228
BR147
BR180
R50026
BE
T52001
R60018
R61314
R60014
R54002
BR223
BR178
BR177
_F32153
_F32152
F32109
R60012
1 26
2752
IC81050
1 26
2752
IC32000
1 10
11
20
IC43280
17
L32023
L32026
111
TUNER
17
814
IC32420
_C60028
R34062
13
IC61040
13
IC61050
13
IC61060
F32020
F32412
BR43281
BR55002
BR62503
BR62502
_BR61040
BR54002
_BR32451
BR190
121
220
EURO-AV2
121
220
EURO-AV1
BR175
BR174
BR173
BR172
BR170
BR169
BR229
BR166
BR165
BR162
BR161
BR160
BR159
_BR158
BR157
BR156
BR155
BR230
BR238
_BR231
_BR60019
BR226
BR209
BR208
BR207
BR206
BR205
BR204
BR203
BR202
BR201
BR232
BR236
_BR152
BR151
BR150
BR149
BR148
BR146
R61019
BR144
BR143
BR142
BR141
BR140 BR139
BR138
BR137
R40012
L32109
L46022
L46021
_L31041
L31043
_L32451
Q80001
Q34044
Q34043
Q32305
_BR34073
_BR32339
R81504
BR135
R40011
BR193
BR119
BR115
BR114
BR113
BR112
BR111
BR110
BR106
BR105
BR102
BR101
BR100
_BR227
D43292
D32128
C60002
C46001
C32024
C32023
C60013
C60038
C43284
C43079
C32334
C81073
C40014
C81072
C40011
C52254
_R41011
R54003
R32359
R50021
R52001
R50011
R50022
R50023
_R40014
R53002
R53001
C54004
BR116
_BR43005
C61057
L43098
17
ST-RGB
17
ST-PIP2
17
ST-SB1
19
ST-KB\IR
19
ST-SB2
19
ST-NF2
19
ST-NF1
13
ST-LSL
13
ST-H
13
ST-LSR
13
_ST-KA
15
ST-BR
15
ST-CI1
15
_ST-MP
15
ST-PIP1
L32342
BR163
BR212
BR43098
R40066
R50001
R50003
R81020
R81053 R81052 R81051
R57007
R61312
R34031
R60004
R60032
R60013
R60031
R60006 R60005
R81054
R34056
R34063
R34057
R34059
R43291
R34066
R57118
R43099
R34058
R43292
R60036
R32023
R61304
R43248
R61306
R41030 R41022
R57017
D53071
D54011 D54002
D60007
D54001
D60006
BR60021
BR81042
_BR60018
BR107 BR109 BR108 BR104
BR136
BR167
BR233
1 7
ST-JOCH
BR179
C52004
R60033
D57012
12
ST-SHIFT
_BR43009
C61063
R43098
_BR40042
NETZ2 NETZ1
29304-764.22 4B(03)
BSO-PL.
GRUNDIG
1011
875
4
2
1
39
6
12
(CUC2031 T4A)
ROT
T1,6A
(CUC2040 T1,6A)
T1,25A
T2,5A
+M
(CUC2040 T5A)
T2,5A
DYN-FOK. / PANORAMA VIEW / UG 2
T315mA
T1,6A
LOETRICHTUNG
T2,5A
0
0 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170 180 190 200 210 220 230 240 250 260 270 280 290 300 310 320 330 340 350 360
10
20
30
40
50
60
70
80
90
100
110
120
130
140
150
160
170
180
190
200
210
220
230
240
250
260
Y
X
39 3235 34 38 40 37303345 36 46 46A
18
4
5
A
B
C
DHI
K
L
M
EG
F
19 1516 16A50A47A 201314 1755 7 12212242 43415154525347 49 50 8 44 23 9 10 11
2
3
1
Chassisplatte / Chassis Board
910
Bestückungsseite, Ansicht von oben
Component side, top view

GRUNDIG Service
Platinenabbildungen und Schaltpläne / Layout of the PCBs and Circuit Diagrams CUC 2030 N / 2031 / 2031 N / 2040 N
GRUNDIG Service
Platinenabbildungen und Schaltpläne / Layout of the PCBs and Circuit Diagrams CUC 2030 N / 2031 / 2031 N / 2040 N
29304-764.22 2L(03)
7
1
CR43286
CR43287
_CR32326 CR81087
CR81086
CR81057
CR81049
CR81082
CR81048
CR80001
CR81046
CR81023
CR81016
CR81081
CR81026 CR81028
CR81007
CR81073
CR81076
CR81074
CR81032
CR31029
CR43259
CR43249
CR43281
CR43263
CR43262
CR43282
CR43277
CR43271
CR32302
_CR32156
_CR32153
_CR32152
CR43073
CR31039
CR34042
CR33014
CR32402
CR32401
CR31051 CR31052
CR32403
CR32418
CR32406
CR32408
CR32407
CR32417
_CR32421
_CR32422
_CR32426 _CR32327
CR52256
CC34037
CC46027 CC46023
CC81082
CC81057
CC81046
_CC81003
CC81048 CC81032
CC80007
CC81033
CC81062
CC80001
CC81026 CC81028
CC81021
CC46021 CC46022
CC80002
CC81038
CC81036 CC81034 CC81016
CC81043
CC81042 CC81041
CC81020
CC46017
CC43258
CC34067
CC34064
CC43281
CC34027 CC34061
CC32345 CC32315 CC32310
CC32301
CC32314
CC32304
CC32311
CC32347
CC32303
CC32317
CC43001 CC43006
CC43011 CC43016
CC43021 CC43026
CC43031 CC43036
CC32313
CC32309
CC32307
CC32306
_CC32154
_CC32152
_CC34072
CC52216
CC33025
CC52248
CC33018
CC34042
CC34041
CC33014
CC34022
CC33016
_CC32411
CC32401
CC43259
_CC32321
_CC32319
_CC57003
_CR32437
CD32421 CD32411
_CD32152
CIC43050
CIC32410
_CC50018
CR34032
CR32026
_CR32451
CR52263
_CR32453
CR52250
CR40064
CR81091
CR46007
CR40060
_CR32319
_CR32318
CR32334
CR43283
CR43284
CR31042
CR31041
CR31043
CR41023
CR31021
CR31022
CR81509
CR40058 CR40059
CR32109
CR31019
CR34039
CR32021
CR52247
CR34058
CR61046
CR43254
CR55001
CR50012
CR55002
CR52251
CR57121 CR43076 CR57113
CR57124
CR81001
CR81503
CR81505
CR81500
CR57011
CR61056
CR43289
CR57022
CR43250
CR32364
CR43078
CR32431
CR81045
CR46016
_CR81003
CR81083
CR82004 CR81056
CR81021
CR81012
CR81029
CR81043
CR32404
CR81041
CR81022
CR81042
CR81037
CR46024
CR81034
CR81024
CR81027
CR82003
CR81013
_CR81009
CR81036
CR52266
CR46022
CR81044
CR81040
CR81010
CR32144
CR81047
CR32102
CR34040
CR43242 CR43243
CR43006
CR31011
CR32107
CR34059
CR81507
CR43255
CR43258
CR43241
CR43013
CR43261
CR81502
CR43285CR43246
CR57021
CR61041
CR57012
CR57001
CR57008
CR57016
CR32339
CR43274
CR32310
CR32314 CR32315
CR43036
CR32313 CR32311
CR32307
_CR43004
_CR43014 CR43008
CR43011
CR43042
CR43021 CR43026
CR43016
CR43031
CR32309
CR33025
CR32103
_CR32438
CR81063
CR32411
CR32113
CR43044
_CR31018
_CR31038
CR57117
CR43072
CR43056
CR43074
CR43047
CR43053
CR43062 CR43067 CR43063
CR43096
CR43079
CR43181
CR43058
CR43184
CR43077
CR43046 CR43095 CR43276
CR43041 CR43043
CR43183
CR43182 CR43048
CR43061
_CR32439
_CR32433
_CR34071
CR32112
CR34064
CR32141
CR32150
CR32143
CR32124
CR32132
CR32114
CR31044
CR31045
_CR32436
CR32420
CR31046
CR81072
CR31006
CR46026
CR32432
CR40031
CR32340
CR41022
_CR40036
_CR40049
_CR40028
CR40041
_CR40038
CR40051
CR40026
CR40063
CR34038
CR40021
CR50002
CR52217
CR81508
CR61051
CR80007
CR81017
CR81014
CR81033
CR57004
CR43023
CR43290
CR43266
CR43001
CR32360
CR32317
CR43267
CR43003
CR43028
CR43033
CR43038
CR31008
CR43051
CR43052 CR43066
CR43247
CR40061
_CR40048
CR40046
_CR40056
CR40062
CR41011
CR33019
CR34041
CR34067
_CR32157
CR32101
CR32110
CR52252
CR32104
CR32412
CR57002
CR31009
CR46001
CR81004
CR43265
CR34076
CR32416
CR52216
CR57116
CR31047
CR31003
CR82001
CR81006
CR81008
CR81084
CR43057
CR50004
CR81501
CR61044
CR61054
CR81011
CR81077
CR32142
CR57003
CR41032
CR32108
CR32105
CR32128
CR32119
CR32133
CR43288
_CR31028 _CR31013
_CR32452
CR43018
CR41033
CR81511
CR32129
CR32335
CR32131
CR57006
_CR32106
CR46008
CR46009
CR46004
CR46003
CR81059
_CR34032
_CT32454
_CR32454
CR52254
CR52253
CR34033
CR57101
_CR40042
CR81055
CR81050
CC81055
CC34032
CC50012 CC50017
_CC81063
_CC32111
_CC32322
_CC43289
CC50003
CC61038
CC61041 CC61062
CC32302
CC46024
CC81008
CC81013
CC81023
CC81007
CC46016
CC46026
CC57016
CC43073
CC43283
CC52266
CC34039
CC32336
CC32350
CC43023
CC43038
CC43018
CC32328
CC43003
CC32121
CC32412
_CC34069
CC43074
CC43046
CC43061
CC43013
CC43099
CC52246
CC32118
CC32110
CC31019
CC33020
CC57004
_CC40028
_CC40049
_CC40052
CC40042
_CC40032
CC34043
CC50004
CC50011 CC61039
CC61061 CC61064
CC61051 CC61060
CC43286
CC32124
CC32341
CC32333
CC32312CC32316
CC32348 CC32365
CC43008
CC43028
CC32337
CC32318
CC43033
CC43055
CC43261
CC43058
CC40022
_CC40036
CC40046
_CC40038
_CC40048
CC34044
CC32123
CC32122
CC33017
CC31052
CC40026
CC31051
CC43057
CC61058
CC32026
CC82001
CC32422
_CC40056
CC43047
CC32109 CC82004
CC81508
CC81012
CC57021
CC61059
CC32308
CC43248
_CC40059
CC46004
_CC32452
_CC32451
CC50014
CC55001
CC52217
CC57007
CC81050
CC81059
CT40059
CT81508
CT57005
CT61043
CT81015
CT43255
CT43246
CT32132 CT32123
CT32111
CT32105
CT34075
CT81502
CT61053
CT43290
CT32119
_CT32435
CT81010
CT32431
CT43095
CT32415 CT32430
CT57124
CT32128
CT81080
CT81058
CT46009
_CT32453
CT57103
CT57021
CT52253
_CT32318
CT41022
CT81511
CT41030
CT31030
CT31020
CT31010
CT32124
CT31005
CT57020
CT32122
CT32308
CT43289
CT34031
CT43244
_CT32440
CT57113 CT57112
CT32310 CT32312 CT32315
CT81091
CBR166
CBR152
CBR150
CBR142
CBR127
CBR125
CBR123
CBR122
CBR121
CBR119
CBR114
CBR110
CBR103
CBR169
CBR154
CBR160
CBR161
CBR162
CBR124
CBR163
CBR164
CBR158
CBR157
CBR136
CBR146
CBR107
CBR101
CBR100
CBR111
CBR137
CBR141
CBR129
CBR148
_CD32153
CBR149
CBR130
CBR104
CBR115
CBR145
CBR112
CBR140
CBR105
CBR147
CBR118
CBR134
CBR128
CBR156
CBR109
CBR153
CBR126
CBR151
CBR113
CBR143
CBR138
CBR116
CBR131
CBR133
CBR165
CBR155
CBR102
CBR167
CBR168
CR81062
CR33018
CR81061
CBR120
CR32303
0
0102030405060708090100110120130140150160170180190200210220230240250260270280290300
310320330340350360
10
20
30
40
50
60
70
80
90
100
110
120
130
140
150
160
170
180
190
200
210
220
230
240
250
260
Y
X
3932 3435384037 30 33 45364646A
18
4
5
A
B
C
D
H
I
K
L
M
E
GF
1915 1616A 50A 47A20 13 1417 55712 21 22 4243 41 51 54 52 53 4749508442391011
2
3
1
Chassisplatte / Chassis Board
11 12
Lötseite, Ansicht von unten
Solder side, bottom view

GRUNDIG Service
CUC 2030 N / 2031 / 2031 N / 2040 N Platinenabbildungen und Schaltpläne / Layout of the PCBs and Circuit Diagrams
GRUNDIG Service
CUC 2030 N / 2031 / 2031 N / 2040 N Platinenabbildungen und Schaltpläne / Layout of the PCBs and Circuit Diagrams
Dolby-Surround-Platte / Dolby Surround Board 29524-104.75
13 14
10
29304-352.70/2L(03)
0123456789
BR020
C40058
C40056
BR009
BR008
BR102
BR103
BR012
BR021
BR100
BR010
BR007
BR006
BR005
BR004
BR003
BR011
BR101
BR002
BR001
Q40012
115
IC40050
19
ST-NF1
19
ST-NF2
C40001
C40018
C40006
C40008
C40007
C40053
C40052
C40067
C40064
C40062
C40069
C40037
L40002
R40057
R40037
D40056 C40051
17
ST-LS
1 32
3364
IC40010
29304-352.70/4B(02)
10
29304-352.70/2L(03)
0123456789
CC40047
CC40031
CC40041
CC40016
CC40023
CC40017 CC40033
CC40009
CC40013
CC40014
CC40019
CC40011
CC40004 CC40036 CC40028
CC40027
CC40001
CC40021
CC40022
CC40012
CC40018
CC40042
CC40044
CC40063 CC40061 CC40068 CC40066
CC40048
CC40049
CC40043
CC40046
CC40057
CC40059
CBR004
CBR002 CBR003
CBR001
CT40015 CT40020
CT40030
CT40025
CR40054
CR40043
CR40048
CR40032 CR40024
CR40012
CR40011
CR40006
CR40036
CR40026
CR40001
CR40028
CR40034
CR40013
CR40016
CR40014
CR40021
CR40018
CR40017
CR40063 CR40068 CR40066 CR40061
CR40051
CR40046
CR40053
CR40041
CR40057
CR40056
CR40058
CR40055
CC40054
CT40058
CT40054
Lötseite, Ansicht von unten / Solder Side, Bottom View
Bestückungsseite, Ansicht von oben / Component Side, Top View
0,1u
CC40041
3,3n
CC40047
0,1u
CC40046
1k
CR40048
+
100u/25V
C40051
+
1000u/16V
C40062
A
1k
CR40043
M
0,1u
CC40043
A
A
F
0,1u
C40057
3,3n
CC40049
1k
CR40041
10k
CR40053
0,1u
CC40048
1k
CR40046
+M
M
10k
CR40051
M
M
+
1000u/16V
C40069
+
1000u/16V
C40064
22n
CC40066
4,7
CR40061
4,7
CR40066
M
22n
CC40068
4,7
CR40068
22n
CC40061
M
4,7
CR40063
22n
CC40063
M
A
Vref
MUTE
STANDBY
-
-
-
-
+
+
+
+
1
2
3
4
5
6
7
89
10
11
12
13
14
15
TDA7372B
IC40050
A
+
47u/16V
C40052
A
+
1u/100V
C40053
+
1000u/16V
C40067
A
A
3,3n
CC40044
+
1000u/25V
C40056
0,1u
CC40042
A
3,3n
CC40018
A
3,3n
CC40012
A
3,3k
CR40017
BC858B
CT40020
3,3k
CR40018
2,2k
CR40021
560p
CC40022
10n
CC40021
A
10
R40037
100
CR40056
10k
CR40057
3,3k
CR40014
U
WISCH
U
STAND
BY
BC858B
CT40015
A
2,2k
CR40016
0,1u
CC40001
3,3n
CC40023
58
59
60
6162 63 64
57
56 41 42
43444546 47
48
49 50
51
52
53
54
55 16 17 18
19
20 21 22 23 24
25 26 27 28 2930 31 32
33
34
35
36
37
38 3940
45
67
8 9 10 11 12 13 14 15
23
1
DPL3519A
IC40010
SCL
A A
A
10u
L40001
RESET
MSP
SDA
A
10n
CC40027
3,3k
CR40013
A
560p
CC40028
3,3k
CR40034 2,2k
CR40028
560p
CC40036
A
A
A
0,1u
CC40004
A
AA
A
A
0,1u
CC40011
0,1u
CC40019
1,5p
CC40014
1,5p
CC40013
0,1u
CC40009
+
10u/50V
C40007
+
10u/50V
C40008
+
10u/50V
C40006
+
4,7u/63V
C40018
A
0
CR40001
18,432MHz
Q40012
n.V.
3,3k
CR40026
2,2k
CR40036
10n
CC40033
BC858B
CT40025
10u
L40002
10k
CR40006
270
CR40011
270
CR40012
M
A
+
220u/10V
C40001
3,3n
CC40031
A
560p
CC40017
10n
CC40016
3,3k
CR40024
M
A
BC858B
CT40030
3,3k
CR40032
A
M
M
I2S
WS
I2S
CL
I2S
TER
I2S
D_IN
A
7
1
2
3
4
5
6
ST-LS2
7
8
9
1
2
3
4
5
6
ST-NF1
+
1000u/25V
C40058
M
7
8
9
1
2
3
4
5
6
ST-NF2
2,7/6,5W
R40057
1N4148 D40056
+
1000u/16V
C40037
A
0,1u
CC40059
M
BC817/25
CT40058
1k
CR40055
BC848C
CT40054
22k
CR40058
220k
CR40054
A
A
n.V.
+E
+E
+E
+E/2
+E/2+E/2+E/2+E/2
+F
+F
+M
+M/1
+M/1
300797
DOLBY-SURROUND-PL. 29504-104.75
PLACA DOLBY SURROUND
PIASTRA DOLBY SURROUND
C. I. DOLBY SURROUND
DOLBY SURROUND BOARD
AL TELAIO
AL CHASIS
VERS CHASSIS
TO CHASSIS
ZUM CHASSIS
DRUCK: 29304-352.70
RESERV. EL DEREC. DE MODIFIC.
CON RISERVA DI MODIFICA
SOURS RESERVE DE MODIFIC
SUBJECT TO ALTERNATE
AENDERUNGEN VORBEHALTEN
A LA PLACA DE TOMAS
Seite/Page 26
Seite/Page 18
VERS C.I.PRISES
ALLA PIASTRA PRESE
TO SOCKET BOARD
ZUR BUCHSENPLATTE

GRUNDIG Service
Platinenabbildungen und Schaltpläne / Layout of the PCBs and Circuit Diagrams CUC 2030 N / 2031 / 2031 N / 2040 N
GRUNDIG Service
Platinenabbildungen und Schaltpläne / Layout of the PCBs and Circuit Diagrams CUC 2030 N / 2031 / 2031 N / 2040 N
Signal-Chassis A / Signal Chassis A
15 16
_+F
+33V
_+33V
M
M
M
M
M
M
M
MM
M
M
M
MM
M
M
MM
M
M
M
M
M
M
M
M
M
M
MM
MM
M
M
MMM
M
M
M
MM
M
M
M
M
M
M
M
M
M
M
M
M
M
M
M
M
M
M
M
M
A
A
A
A
A
AA
AA
AA A
RESET
MSP
M
M
M
M
M
M M
A
M
M
M
M
M
M
M
M
M
M
A
M
M
M
M
M
M
A
M
0
CR81010
22k
_CR32439
10k
CR81087
10k
CR81086
100
CR81057
560k
CR46001
10k
CR81084
4,7k
_CR81003
4,7k
CR82003
4,7k
CR82001
4,7k
CR82004
100k
CR81049
18k
CR81082
10k
CR81041
**
CR46024
4,7k
CR81011
100
CR81048
4,7k
CR81024
4,7k
CR81047
**
CR46022
BC848B
_CT32454
10k
CR81042
220
CR81017
5,6k
CR81083
4,7k
CR81006
**
CR80001
47k
CR81013
CR41032
10k
CR81043
100
CR81021
10k
CR81033
10k
CR81034
**
CR46016
820
CR81004
0
CR46003
BR81043
10k
CR81036
4,7k
CR81027
4,7k
CR81029
100
CR81023
330
CR81008
22k
CR81016
27k
CR81012
1k
CR81037
100k
CR81014
6,8k
CR81081
4,7k
CR81022
0
CR32404
100
CR81026
100
CR81028
1k
CR81007
22k
CR81072
1k
CR46004
22k
CR81073
150k
CR81076
22k
CR81074
330
CR81077
CR41022
0
CR31043
**
CR46026
100
CR31039
A
0
CR31011
xx
_CR31013
1
ASIS2
XX
_CR31028
0
_CR32326
0
CR31041
47k
CR32411
6,8k
CR32417
22k
_CR32436
1k
_CR32433
47k
CR32416
10k
_CR32437
1,2k
_CR32438
56k
CR32407
56k
CR31046
10k
CR32408
47k
CR31047
56k
CR32406
2,2k
CR32432
0
CR32412
4,7k
CR32418
56k
CR32403
100
CR31052
2,2k
CR32021
100
CR31051
10k
CR32401
10k
CR32402
0
CR31044
470
CR32302
100
CR31006 100
CR31003
3,3k
CR32307
3,3k
CR32311
3,3k
CR32310
3,3k
CR32309
470
CR32339
470
CR32340
0
CR32420
330
CR31009
22k
CR31008
+E
+
4,7u/100V
_C32454
10k
_CR32454
0
CR31042
680
CR81001
100
CR31029
10k
CR81032
22k
CR81045
22k
CR81044
22k
CR81040
100
_CR81009
470
_CR32453
BC848B
_CT32453
3,3n
_CC32452
4,7m
_L32451
0
_CR32327
0
_CR32426
xx
_CR32421
xx
_CR32422
47k
CR32431
100
CR31019
4,7k
CR81056
0
CR31045
MEGA
LOGIC
G
OSD
R
OSD
B
OSD
RESET
MSP
H
SYNC
V
SYNC
KH
AUDI-L
KH
AUDI-R
+M
AUDIO
1
AUDIO
EURO-AV
FBAS
CINCH
CINCH
AUDIO-L
CINCH
AUDIO-R
KH
AUDIO-R
RESET
MSP
FBAS TEXT
FBAS
CINCH-
FBAS
CINCH-
M
FR
PLL
3,3n
_CC32451
n.v.
SAT
PLL
+45V
U
WISCH
U
LED
F
33n
C81073
F
33n
C81072
10k
CR46009
+
470u/10V
C81061
+
10u/50V
C31044
+
10u/50V
C32021
+
10u/50V _C32438
+
220u/10V
C31042
+
22u/50V
C32423
+
220u/10V
C31041
BR190
+
47u/25V
C31046
U
DATA
OSD
U
EURO-
AV1
U
EURO-
AV2
U
STAND
BY
2,2n
CC81082
100p
CC81057
10n
CC81046
100p
CC82004
100p
_CC81003
100p
CC81048
10n
CC82001
**
CC46024 10n
CC81032
**
CC46023
**
CC46026
0,1u
CC80007
10n
CC81033
270p
CC81013
0,1u
CC81062
**
CC80001
220p
CC81012
0,1u
CC46016
100p
CC81026
100p
CC81028
10n
CC81021
**
CC46021
**
CC46022
**
CC80002
1n
CC81007
100p
CC81038
BC808-40
CT41030
10n
CC81036
100p
CC81023
10n
CC81034
100p
CC81016
10n
CC81043
10n
CC81042
10n
CC81041
100p
CC81020
1n
CC81008
BC808-40
CT41022
100k
_CR32451
1,5p
CC32306
100p
CC31019
0,1u
CC32412
0,1u
CC32422
0,1u
CC32401
100p
CC31051
3,3p
_CC32411
100p
CC31052
10n
CC32307
3,3n
CC32309
470
p
CC32
3
10n
CC32302
1,5p
CC32303
560p
CC32312
10n
CC32311
560p
CC32308
1n
CC32304
1n
CC32301
3,3n
CC32310
**
CC46027
0,1u
CC46017
BA582
CD32411
BA582
CD32421
+H/1
+F
+F
+M +H/1
+H/1 +H/1
+H/1
+H/1
+H/1
+F
+H/1
+H
+F
+H/1 +F
+H/1
+H/1
+F
+F
+33V
+H/1
+H/1
+E
/
+E
/
+F +E
+E/3 +E/3
A
+F
+E/3
+E
+E/3
+F
+H/1
+F
+E
+E/3
CR41023
1
ASIS1
_BR32339
_BR32340
BC858B
_CT32440
BC858B
CT31020
BC858
CT3231
BC858B
CT31030
BC858B
CT32308
BC858B
CT31005
BC858B
CT31010
390k
_CR32452
n.v.
n.V.
M
BC848B
CT32415
BC848B
CT81010
BC848B
CT81015
BC846B
CT81080
BC848B
CT32430
BC848B
_CT32435
CR41033
BC848B
CT32431
U
POWER
OFF
U
IDEN1
U
PV
U
TER
U
B1
U
IDENT
U
B3
U
UHF
U
UHF
U
TER
U
NORM2
U
NORM1
U
B3
U
B1
U
IDEN1
U
NORM3
n.V.
+F
SDA
SCL
SDA
CLK
DATA
IR
ENA1
SCL SDA
KB
+H
ENA2
VDR
SCL SDA ZF. ZF_
ENA2 FBAS ENA1
SDA SCL
A-ZF1 A-ZF2
A-AM A-AM
A-ZF1
+F
SDA1 SCL1
ENA2
SDA1 SCL1
SCL
0,1u
_CC81063
+H/1
6 5 4 3 2 1 7
ST-SB1
VCC
SDA
SCL
A0 A1 A2 VSS
TEST
8
7
6
5
4321
ST24W02C
IC82005
VCC SDA
SCL
A0A1A2VSS
TEST
8
76
5
4321
X24C08
IC82000
U
AFC
U
TUN
U
AFC
U
TUN
U
TUN
**
Q80001
18,432MHz
Q32305
**
L46021
8,2uH
L31043
xx
_L31041
12
3
8305-210-065
MC33164
IC80000
PERLE
_L81061
10
8
5
4
3
2
1
OFWK6260
F32412
3
L9460
F32020
MC14094
STROBE
DATA
CLOCK
1615
14
13
12
11
1098
7
6
5
4
3
2
1
CIC32410
LOGICAGC
2
1
14
1312 11
10
9
8
7
6
5
4
3
STV8225
IC32420
MONO
A
n.V.
F
C32334
0,1u
A
MONO
M
A
SIG.-B
INL
22k
CR81058
ZF
ZF
M12 M13 M14 M15
B1 B3
UHF
AGC
12
34567
8
9
10
11
12 13 14 15
TUNERTUNER
GB
FR
2,2k
CR81059
FR
ZTK33D
D31001
U
1N4148
D81012
1N4148 D81020
BC848B
CT81058
VST
SAT
5
4
3
2
1
_ST-MP
5
4
3
2
1
ST-CI1
6 5 4 3 2 1 9 8 7
ST-SB2
SIG.-B
3
1
78
4
6
2
8140-107-600
F32410
P3.2 P3.3 P3.4 P2.2 P0.6 CVBS
HS/SC
VS/P4.7
R G B
BLAN
XTAL2 XTAL1 FIL1SCL FIL2SCL FIL3SCL LCOUT LCIN RST
P3.7 P3.6 P4.0 P3.0 P3.1 IREF VDDA VDD VDD CUR
VSSA
VSS
VSS
P2.0 P3.5 P1.4 P0.1 P0.2 P0.0 P2.1 P2.3 P1.2 P1.3 P1.1 P0.4 P0.5
P1.7 P0.7 P1.0
P0.3
P1.6
P1.5
12
3456789
10
111213 1415 1617
1819 20 21 22
23
24
2526 27 2829
303132 3334
35
36
373839 40 41
42 4344 45 46 47 48 49 50
5152
**
IC81050
BC858B
CT81091
SAT
VST
INL.
16:9
VST
n.V.
BR81061
DACA_R
ANA_IN1+
ANA_IN2+
ANA_IN-
DACA_L XTAL_IN XTAL_OUT VREF2 DVSS NC
I2S_DA_IN2
ADR_CL ADR_WS
MONO_IN
47
48
49
51 52
44 14 15
17
18 19
21 22 2
MSP3410
2-SCART
16:9
R81052
3,3k
R41030
100
R81051
3,3k
+H/1
R81053
3,3k
SIG.-B
SIG.-B
MP20
MP21
MP22
MP23
MP24
MP60
MP62
MP61
MP77 MP78 MP79 MP81
MP106
MP93
MP94
MP97
MP98
MP99
MP102
MP103
10k
CR81091
ZPD4,7V
D31007
NIC
NIC
FR
MONO
FR
M
MP95
MP92
XX
_CR31038
MP118
MP125
MP115
6
5
4
3
2
1
9
8
7
ST-KB\IR
56k
CR31021
56k
CR31022
M
+F/1
R81020
100
33
CR31049
0
_CR32441
CUC2040
0
CR32303
I2S
D_IN
MMM
1k
CR81063
BR225
BR228 BR163 BR164
+E/3
FR
n.v.
U
WISCH
1
U
POWER
OFF2
SAT
U
WISCH
1
PLL
PLL
PLL
U
POWER
OFF2
VST
10k
CR80007
1k
CR81062
1k
CR81061
+H/1
1k
CR46008
5,6k
CR46007
10n
CC46004
M
BC848B
CT46009
FR
2-SCART
PLL
PLL
R81054
470
VST
VST
_BR32451
BR81042
BR81041
M
100
CR81046
XX
_CR31018
1
ASIS3
1
ASIS5
1
ASIS6
1
ASIS4
1
ASIS7
1
ASIS8
1
ASIS10
1
ASIS9
1
ASIS11
1
ASIS14
1
ASIS15
1
ASIS16
2,2k
CR81050
39p
CC81055
2,2k
CR81055
39p
CC81050
+H
MP117
M
FBAS
TEXT
V
SYNC
H
SYNC
B
OSD
R
OSD
G
OSD
U
DATA
OSD
FR
F
0,33u
C46001
39p
CC81059
M
+33V
M
M
M
M
+E +F
+F/1
+F/1
ZD33B (PLL-TUNER)
560 bei 29704-003.13/14/15
22u/50V
533-607
**
IC81050
120p/5%
56k
82k
CR46016
33p/2%
CC46021CC46022
6,8u/2%
L46021
0,1u
CC46027
100p
0,1u
CC46023
100k
8,2k
CR46022CR46024
6,8k33n
CC46024
33n
CC46026
6,8k
CR46026
56p
33p
15p
CC80002
33p
CC80001
6MHz
18MHz
Q80001
0
33
CR80001
SDA 5257-2
SDA 5256C
30
7
ST24C04
X24C08, ST24W02C
HIGH
ST24C04
BASIS
MEMORY
RESET
38
39
40
2133 34 35
36 37
32
55
SIGNAL-CHASSIS A
ST-PIP1
MOD. SEGNALE
PLACA LED
CHASIS SENAL A
CHASSIS SEGNALE A
CHASSIS SIGNAL A
(ADR)
29504-162.52
470
1k
VST: UV 1315 // UV 1343 UHF only
PLL: UV 1316 w.w. TEC 2949 w.w. TEMIC 5002
TEC 2949
UV 1316
TEMIC 5002
BR81041BR81042BR81043PLL-TUNER
10k
3,3k
OFWK3452(OIRT)
MOD. SENAL
SIGNAL-BAUSTEIN
Prozessorplatte 29305-119.37/39/40
w.w.
100p
CC81081
2,2k
(SCL) (SDA)
0
(CR81025)
(0)
SIGNAL-BAUSTEIN
MOD. SENAL
MOD. SIGNALE
ENTFAELLT BEI
NO EXISTE EN
MANCA NELLA VERS.
N’EXISTE PAS POUR
NOT FITTED ON
(VST-TUNER)
OFWK3451(FR)
0,22u
NUR BEI MEGALOGIC
OFWG1984(INL)
PIASTRA LED C.I. LED LED-BOARD
LED-PLATTE
MODULE SIGNAL
MODULE SIGNAL
SIGNAL MODULE
SIGNAL MODULE
1
25
4
Seite/Page 27
Seite/Page 24
ZUR BEDIENEINHEIT
A LA UNIDAD DE MANDO ALLA UNITA DI COMANDO VERS UNITE DE COMANDE TO CONTROL UNIT
ZUR BUCHSENPLATTE
A LA PLACA DE TOMAS VERS C.I.PRISES ALLA PIASTRA PRESE TO SOCKET BOARD

GRUNDIG Service
CUC 2030 N / 2031 / 2031 N / 2040 N Platinenabbildungen und Schaltpläne / Layout of the PCBs and Circuit Diagrams
GRUNDIG Service
CUC 2030 N / 2031 / 2031 N / 2040 N Platinenabbildungen und Schaltpläne / Layout of the PCBs and Circuit Diagrams
+E
+E/1
+M
+E/2
+E2
+F
+H
+45V +M1
A
A
A
A
A
A
+
100u/25V
C40061
A
A
A
A
A
A
A
+F
A
A
A
A
M
A
A
A
A
A
A
AA
A AA A
A
A
A
A
AA
A
A
A
AA
A A
A
M
M
M
M
M
A
M
M
M
M M
M
M
M
M
M
M
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
AA
M
M
MM
M
22n
_CC40048
A
A
A
M
M
M
1k
CR40046
10k
CR40062
1k
_CR40036
2,2k
CR40041
1k
CR40026
2,2k
CR40021
2,2k
CR40031
10k
CR40063
1k
_CR40056
4,7
_CR40038
1N4148
D40064
4,7
_CR40049
10k
CR40061
4,7
_CR40028
100
CR41032
100
CR41022
0
CR43183
0
CR43182
0
CR43184
0
CR43246
0
CR43181
10k
CR43044
10k
CR43042
47
CR43079
75
CR43096
1k
CR43095
6,8k
CR43041
47
CR43058
47
CR43057
47
CR43061
47
CR43056
47
CR43073
75
CR43078
75
CR43072
6,8k
CR43043
75
CR43067
75
CR43066
75
CR43062
75
CR43063
75
CR43047 75
CR43052
75
CR43046
47
CR43053
47
CR43051
47
CR43048
47
CR43074
47k
CR43077
18k
CR43076
A
220
_CR43014
470
_CR43004
220
CR43036
220
CR43031
470
CR43026
470
CR43021
470
CR43006
470
CR43008
220
CR43038
220
CR43033
470
CR43028
470
CR43023
220
CR43016
220
CR43018
220
CR43013
220
CR43011
470
CR43003
3,3k 3,3k
CR32313
3,3k
CR32317
0
CR32360
3,3k
CR32314
3,3k 3,3k
CR32315
1,8
CR32364
7
0
2
340
1k
CR43243
75
CR43267
75
CR43247
2,2k
CR40051
470
CR43001 0
CR43242
1k
CR43241
4,7
CR41011
AUDIO-L AUDIO-R
KH
AUDI-R
KH
AUDI-L
WISCH
1
H
SYNC
V
SYNC
KH
L
KH
R
AUDI-L
MEGA
LOGIC
KH
AUDIO-L
CHROMA
AV_1
FBAS
IN_2
FBAS
OUT_2
CHROMA
AV_2
FBAS
OUT_1
FBAS
IN_1
I2S TER I2S
WS
I2S
CL
I2S
D_IN
I2S TER I2S
WS
I2S
CL
RESET
MSP
+E/1
U
WISCH
U
WISCH
U
WISCH
F
0,1u
C40011
F
0,1u
C40014
F
0,22u
C43079
+
1u/100V
C40062
+
1000u/16V
C40012
+
100u/25V
C41032
+
100u/25V
C41022
+
100u/25V
C41011
+
100u/10V
C43098
+
22u/50V
C43037
+
22u/50V
C43032
+
4,7u/100V
C43027
+
4,7u/100V
C43022
+
22u/50V
C43017
+
22u/50V
C43012
+
4,7u/100V
C43007
+
4,7u/100V
C43002
+
10u/50V
C32343
+
10u/50V
C32346
+
4,7u/63V
C32327
+
220u/10V
C32360
_BR43005
AUDIO
SUB
+
100u/10v
C43249
100
CR40064
+
1u/100V
C40063
+
10u/50V
C32332
+
100u/10V
C32364
U
STAND
BY
U
STAND
BY
U
EURO-
AV2
U
EURO-
AV1
U
STAND
BY-
0,1u
CC40022
0,1u
_CC40052
3,3n
CC40026
0,1u
_CC40032
0,1u
CC40042
22n
_CC40038
0,1u
_CC40056
22n
_CC40049
R40066
10k
22n
_CC40028
3,3n
_CC40036
BC808-40
CT41030
BC808-40
CT41022
3,3n
CC40046
0,1u
CC43061
0,1u
CC43057
0,1u
CC43058
10n
CC43099
0,1u
CC43073
0,1u
CC43074
0,1u
CC43046
0,1u
CC43047
10n
CC43055
AUDIO
SUB
A
470p
CC32337
560p
CC32316
10n
CC32313
470p
CC32336
1n
CC43038
1n
CC43036
1n
CC43033
1n
CC43031
470p
CC43028
470p
CC43026
470p
CC43023
470p
CC43021
1n
CC43018
1n
CC43016
1n
CC43013
1n
CC43011
470p
CC43008
470p
CC43006
470p
CC43003
470p
CC43001
0,1u
CC32365
0,1u
CC32341
560p
CC32318
0,1u
CC32328
10n
CC32317
0,1u
CC32347
560p
10n
CC32311
3,3n
CC32314
1n
CC32350
3,3n
CC32315
47n
CC32345
0,1u
CC32333
10n
CC43248
1n
CC32348
+M
+E
+E/2
+E/2
A
+E/3
A
+E/3
+E
+E/3
+G +F+E
R41022
100
2,2k
CR40060
100
CR41023
T1,25A
SI40012
T1,6A
SI40070
2,7/6,5W
R40012
A
_BR43009
BC858B
CT43244
BC858B
CT32315
BC858B
CT32312
BC858B
CT32310
6
5
4
3
2
1
9
8
7
ST-NF1
BC848B
CT43095
BC848B
CT43246
100
CR41033
U
POWER
OFF
U
PV
U
RGB
U
RGB
U
DATA
U
KLEMM
AUDIO-R AUDIO-L
SCL SDA
R G B
SCL SDA
3,3n
_CC32319
BC858B
_CT32318
+E
A
6 5 4 3 2 1 9 8 7
ST-NF2
8,2
_R40014
6,8
R43098
3,3k
_CR32319
82
R32359
3
2
1
ST-H
MC14551
1
16
15 14
13
12
11
10
9
8
7
65
4
3
2
MC14551
CIC43050
MONO
n.V.
3,3k
_CR32318
560p
_CC32322
10n
_CC32321
10u
L32342
+
+
+
+
-
-
-
-
STANDBY
MUTE
Vref
1
2
3
4
5
6
7
89
10
11
12
13
14
15
TDA7297
IC40000
n.V.
4,7
_R41011
A
XX
_CC40059
1-SCART
SC2_OUT_L
SC2_OUT_R
SC2_IN_R
SC2_IN_L
SC1_OUT_L
SC1_OUT_R
SC1_IN_R SC1_IN_L
DACM_SUB
(V.B3)
DACA_L VREF2 DVSS DACM_R AVSS DACM_L VREF1 AHVSS AGNDC TESTEN NC VREFTOP D_CTR_OUT0 D_CTR_OUT1 AUD_CL_OUT ADR_DA I2S_DA_IN1 I2S_DA_OUT I2S_WS I2S_CL I2C_DA I2C_CL
AVSUP
AHVSUP CAPL_M CAPL_A
ADR_SEL
DVSUP
STANDBYQ
SC_3_IN_R SC_3_IN_L
RESETQ
NC
I2S_DA_IN2
ADR_CL
50
46
27
28
29
30
31
32 3334
35 36
37 38
39
40
41 42
4345
56
7 8 910111213
15 16
17
18 19 20
22 23 24 25 26 3412
IC32000
MSP3410
2-SCART
10k
CR40058
PERIDEC1
6
2
1
3
8
20
16
15
11
7
19
21
18
17
14
13
9
5
4
10 12
DEC
EURO-AV1
PERIDEC1
6
2
1
3
8
20
16
15
11
7
19
21
18
17
14
13
9
5
4
10 12
VCR EURO-AV2
R43099
2,2
R43248
2,2
MP12
220
CR32335
220
CR32334
MP29
MP30
MP31
MP37
MP38
MP39
MP40
MP41
MP42
MP43
MP44
MP45
MP46
MP47MP48
MP49
DOLBY
1k
CR40059
BC848B
CT40059
+E
+E/1
n.V.
CUC2040
n.V.
n.V.
n.V.
n.V.
n.V.
FR NIC
2-SCART
3
2
1
ST-LSR
3
2
1
ST-LSL
2,7/4W
R40011
2,2k
CR32304
1-SCART
MONO
BR43098
AUDIO-L
MONO
_BR40042
+E/3
1-SCART
1-SCART
+E
22u
L43098
0
CR43054
1-SCART
CUC2050
n.V.
4,7
_CR40048
CUC2040
0
_CR40042
MONO
A
MONO
U
STAND
BY-
MONO
5,6k
+M
T1,6A
CHASSIS DI RETE
AL CHASSIS SENAL B AL CHASSIS SEGNALE B
Seite/Page 19
VERS CHASSIS SIGNAL B TO SIGNAL CHASSIS B ZUM SIGNAL-CHASSIS B
DOLBY-SURROUND-PL.29504-104.75
PLACA DOLBY SURROUND
Seite/Page 13
PIASTRA DOLBY SURROUND
C. I. DOLBY SURROUND
DOLBY SURROUND BOARD
CHASIS RED
CHASSIS SECTEUR
MAINS CHASSIS
NETZ-CHASSIS
ST-H
2x4/8W
2x4/8W
2x9/18W
2200u/25V
MSP3401
MSP3400C
1k
680
ZUR KH-BUCHSE
A LA TOMA DE AURICUL.
Seite/Page 27
ALLA PRESA CUFFIA
VERS PRISE CASQUE
TO HEADPHONE SOCKET
2 12 1
18
PIN V
1 0
2 2,2
3 0
4 0
5 0
6 5,0
7 5,0
8 4,8
9 2,5
10 2,5
11 2,5
12 1,5
13 1,1
14 1,1
15 1,1
16 5,0
17 0
18 1,5
19 0
20 5,0
21 1,5
22 1,5
23 0
24 0
25 0
26 0
PIN V
27 3,6
28 3,6
29 0
30 3,6
31 3,6
32 5,4
33 7,0
34 6,0
35 0
36 3,6
37 3,6
38 3,6
39 3,6
40 3,6
41 3,6
42 3,6
43 2,5
44 3,6
45 0
46 4,9
47 1,4
48 1,4
49 1,8
50 0
51 2,3
52 2,0
IC32000
PIN V
1 7,3
2 7,3
314,6
4 1,5
5 0
6 5,0
7 5,5
8 0
PIN V
9 0
10 0
11 0
12 1,5
13 14,6
14 7,3
15 7,3
IC40000
17

GRUNDIG Service
Platinenabbildungen und Schaltpläne / Layout of the PCBs and Circuit Diagrams CUC 2030 N / 2031 / 2031 N / 2040 N
GRUNDIG Service
Platinenabbildungen und Schaltpläne / Layout of the PCBs and Circuit Diagrams CUC 2030 N / 2031 / 2031 N / 2040 N
+E
+H
+F
M
M
M
M
M
MM
M
M
M
M
M
M
M
M M
M
M
M
M
M
M
M
M
M
M
M
M
M
M
M
M
MMM
M
M
M
M
M
M
M
M
MM M
M
A
M
M
M
M
M
M
M
M
M
M
M
M
M
MM
M
M
M
M
M
M
M
M
M
M
M
56k
_CR34071
3,9k
R43291
*
CR34064
470
CR32103
0
CR32111
15k
CR52266
4,7k
CR32119
820
CR32107
C
560
CR32112
470
CR32113
47
CR32110
220
CR32108
2,7k
CR32104
22
CR32109
560
CR32101
680
CR57021
39k
CR52252
3,9K
CR57011
3,9K
CR57012
150k
CR57008
1M
CR57004
390
CR33014
39k
CR57003
100k
CR57002
1k
CR57022
8,2k
CR52251
82k
CR34042
18k
CR52247
0
CR33018
8,2k
CR33025
1M
CR43265
470k
CR43289
47
CR43271
220
CR43284
220
CR43283
100k
CR43277
100k
CR43276
0
CR43282
47
CR43266
100k
CR43262
100k
CR43263
47
CR43261
100k
CR43281
2,2k
CR43254
2,2k
CR43255
2,2k
CR43250
2,2k
CR43249
1k
CR43259
470
CR32114
100
CR52216
22k
CR57016
100k
CR43285
100
CR52217
1M
CR57001
*
CR34067
M
2,2k
_CR32152
2,2k
_CR32151
2,2k
_CR32156
2,2k
_CR32157
0
_CR32153
270
CR32102
330
CR34076
100
CR34058
100
CR34059
0
CR34040
0
CR34039
0
CR34038 100k
CR43288
22k
CR33019
0
CR43258
0
CR43287
0
CR43286
FR
0
CR43274
0
CR34041
0
CR32105
AUDIO-L SSC
SSC
R
G
B
SDA
SCL
ZF.
ZF_
A-ZF2
FBAS
SCL3
SDA3
SDA2
SCL2
AUDIO
EURO-AV
AUDIO
1
FBAS
CINCH-
CHROMA
AV_2
FBAS
IN_1
FBAS
IN_2
FBAS
OUT_1
R
OSD
G
OSD
B
OSD
FBAS
OUT_2
CHROMA
AV_1
H
SYNC
CHROMA
AV_2
CHROMA
AV_1
FBAS
OUT_2
FBAS
CINCH-
FBAS IN_2
AUDIO
1
AUDIO
EURO-AV
AUDIO
ZF-MONO
FBAS IN_1
R
OSD
G
OSD
B
OSD
FBAS
CINCH
FBAS
CINCH
FBAS
TEXT
H
SYNC
V
SYNC
FBAS
PIP
V
SYNC
FBAS
PIP
H
SYNC
AUDIO
ZF-MONO
FBAS
OUT_1
FBAS
CINCH
FBAS
OUT_2
FBAS TEXT
INL
+F
+E
+E
F
0,1u/5%
C52254
F
0,22u
C43284
F
1,5n/2,5%
C32023
F
0,22u
C43266
F
2,2n/2,5%
C32024
+
100u/10V
C32108
+
470u/10V
C34021
+
47u/16V
C34063
+
4,7u/100V
C33019
+
1u/100V
C52247
+
10u/50V
C57016
+
220u/10V
C43282
+
22u/50V _C34071
+
220u/10V
C34041
U
DATA
OSD
U
SCHUTZ
VG
U
DATA
OSD
M
1n
_CC34069
1n
_CC57003
33p
CC52266
33p
CC32118
10n
CC32109
22p
CC32110
10p
CC33016
10n
CC34022
0,1u
CC33017
0,1u
CC33014
3,3n
CC34041
0,1u
CC34042
18p
CC34043
1n
CC33018
**
CC34039
1n
CC52246
10n
CC52248
0,1u
CC34061
18p/2%
CC34044
10n
CC34027
**
CC33025
1n
CC52216
47p
CC32026
47n
CC43283
0,1u
CC43286
0,1u
CC43261
10n
CC43281
0,1u
CC43259
2,7n
_CC34072
*
CC34064
*
CC34067
47p
_CC32152
10n
_CC32154
47n
CC57016
0,1u
CC43258
10n
CC33020
1n
CC57021
100p
_CC43289
33n
CC57004
**
CC34037
BA582
_CD32153
BA582
_CD32152
+E/3
+E
+E
+E
+E
+E
+E
+E
+E
+E
+45V +E/3
+E
+E/3
+E/3
+E
_+F
_+33V
+E
+E
+E/3
+E
+F
BR43255
BR43281
_BR34073
BR43245
BR46022
BC858B
CT43289
BC858B
CT57020
BC858B
CT34031
1N4148
D57012
BC848B
CT32119
B
C
C
T
BC848B
CT57005
BC848B
CT43255
BC848B
CT34075
BC817-25
CT32105
U
SCUTZ
U
NORM1
U
DATA
U
TER
U
NORM2
U
IDENT
U
KLEMM
U
RGB
U
NORM1
U
RGB
U
NORM3
UDATA
U
SCUTZ
U
SCUTZ
U
KLEMM
U
IDENT
U
NORM3
U
IDEN1
VIDEO
FBAS
HDR
VB
VA
OWA
BB
A-ZF2
FBAS
SDA
SB
BB
ZF_ ZF.
CHROMA
VIDEO
SCL
G B R
R
G
B
SW
SSC
CHROMA
SDA1 SCL1
FBAS
SDA SCL
MP199
U
AFC
4,43MHz
Q34043
3,58MHz
Q34044
6 5 4 3 2 1 7
ST-PIP2
5 4 3 2 1
ST-PIP1
n.V.
MONO
MONO
NIC
NIC
U
U
M
M
M
M
1N4148 D57011
1N4148
D43292
+F
1N4148 D57013
1N4148 D43284
1N4148
D57023
2,7u
L46022
10u
L32109
10u
L32026
1u
L32023
TPS6,0MB
F32109
5,5MHz
_F32152
6,0MHzFR
6,5MHzOIRT
_F32153
2
6
71
34
8
8141-112-405
F32101
MULTI
SIG.-B
SIG.-B
INL
VIDEO
OSC.ZF
AGC
AFC
RGB
FBAS Y/C AUDIO RGB-MATRIX
DELAY
PEAKING BLACK STRE.
I C
2
V-DRIVE
PAL/NTSC-DECODER MATRIX H-DRIVE
3
3
876
5
43 215655
54
53
52
51
50
49
48
47
46
45
4443 42 41
40
39 38
37
36 35 3433 32 31302928
27
26
25
24
23
22
21
20
19
18
17
16
15
14
1312 11 10
9
**
IC34015
6
5
4
3
2
1
7
ST-PIP3
2
36 17
4
8
8140-535-391
F33025
XX
_CR32106
M
100n
_CC32111
470k
CR57006
n.v.
R34059
1,5k
1-SCART
20 19
18
14
13
12
119
7421
56
10
8
31516
17
TEA6415
IC43280
R34056
470
BC848B
CT43290
R34057
1,5k
R32023
220
47
R34062
R34063
*
R34058
1,5k
R57017
10k
1-SCART
1u
CC33021
MP158 MP159 MP160 MP161 MP162 MP163
MP164
MP170
MP174
MP171
MP179
MP177
MP178
MP180
MP181
MP183
MP184
MP190
MP189
MP191
MP192
MP193
MP195
MP196
MP197
MP203
MP204
MP205
MP207MP208 MP209
MP210
1-SCART
INL
FR
1-SCART
1-SCART
1-SCART
2-SCART
MP153
MP157
6
5
4
3
2
1
7
ST-RGB
+E
**
R34031
+M
FR
1 2
ST-ASIS13
AUDIO-L
MONO
0
_CR34072
0
_CR32158
NIC
47k
CR43290
MONO
MONO
INL
n.v.
**
CR34033
1-SCART
A
FR
R34066
*
R43292
3,9k
2-SCART
A
B
A
B
A
A
B
A
1-SCART
2-SCART
2-SCART
2-SCART
0
_CR34032
VIDEO
+E
KAMMF.
KAMMF.
3
2
1
_ST-KA
BC858B
CT57021
BC858B
CT52253
M
1k
CR52254
+E
12k
CR52253
M
330
CR52256
330
CR52263
1
ASIS12
0
CR52250
10k
CR32026
100
R57007
100p
CC57007
M
100p
CC52217
M
**
CR34032
**
CC34032
6,8M
w.w TDA8375/FR
**
IC34015
NUR BEI 29"PHSF
CC34032
** MULTI/FR/16:9
0,1u
0,22u
0
0,1u
3,9p220p
330p560
3,3k
390
2,2k
CC34039CC34037CC33025CR34033CR34032R34031
TDA 8375
TDA 8843/8844
2,7k2,7k
47A
50A
52
R34066
R34063
43
41 42
44
45
46
47
21
8
2223
50
51
5354
SIGNAL-CHASSIS B
AL CHASSIS SENAL A AL CHASSIS SEGNALE A TO SIGNAL CHASSIS A VERS CHASSIS SIGNAL A
SOLO CON
SOLO CON
SEUL.POUR
ONLY WITH
NOT FITTED ON IMAGE FEATURE MODULE
NO EXISTE EN IMAGEN FEATURE MODULO
MANCA NELLA VERS. IMMAGINE FEATURE MODULO
N’EXISTE PAS POUR IMAGE FEATURE MODULE
PLACA ALTERNATIVA
PIASTRA DI RICAMBIO
PLAQUE DE RECHANGE
ALTERNATIVE BOARD
ERSATZPL.29305-119.42/.45
ZUM SIGNAL-CHASSIS A
MOD. SEGNALE
CHASSIS DI RETE
NETZ-CHASSIS
CHASIS RED
CHASSIS SECTEUR
MAINS CHASSIS
-106.52
MODULO PIP
MODULO PIP
MODULE PIP
PIP MODULE
PIP-BAUSTEIN 29504-106.51
CHASIS SENAL B
CHASSIS SEGNALE B
CHASSIS SIGNAL B
10
15u
680
ENTF. BEI BILD-FEATURE MODUL
TEA6425
100
100
470
100
SAT
PIP
0,1u
0,1u
0,1u
0
CC3406
7
CC3406
4
*
SIGNAL-BA
U
MOD. SENAL
ENTFAELLT BEI
NO EXISTE EN
MANCA NELLA VERS.
N’EXISTE PAS POUR
NOT FITTED ON
0,1u
0
0
6,8k
820
0
TPS5,5MB
BILD_FEATURES 1
BILD_FEATURES 2
MODULE SIGNAL
SIGNAL MODULE
A LA PLACA-ZOCALO TRC ALLA PIASTRA CINESC. VERS C.I. tube cathod TO CART BASE ZUR BILDROHRPLATTE
BUS CONTROLLED VIDEO MATRIX
Seite/Page 18
Signal-Chassis B / Signal Chassis B
19 20
PIN V
1 2,8
2 4,9
3 3,2
4 4,8
5 2,8
6 3,8
7 0
8 3,8
9 7,7
10 2,8
PIN V
11 2,8
12 3,1
13 3,1
14 1,8
15 1,8
16 3,4
17 1,8
18 3,1
19 0
20 2,6
IC43200
PIN V
1 1,3
2 3,8
3 3,8
4 3,8
5 3,0
6 3,4
7 5,0
8 5,0
9 6,8
10 0
11 4,0
12 8,0
13 3,8
14 0
15 3,4
16 0
17 3,8
18 4,8
19 3,3
20 3,0
21 3,0
22 3,5
23 3,6
24 3,6
25 3,6
26 0
27 3,0
28 3,0
PIN V
29 2,4
30 2,4
31 2,4
32 2,4
33 0
34 2,5
35 2,5
36 5,0
37 8,0
38 3,2
39 5,0
40 2,0
41 0,7
42 3,2
43 4,0
44 0
45 0,5
46 2,5
47 2,5
48 4,6
49 4,6
50 2,3
51 3,8
52 3,8
53 4,0
54 4,0
55 3,0
56 3,8
IC34015

CUC 2030 N / 2031 / 2031 N / 2040 N Platinenabbildungen und Schaltpläne / Layout of the PCBs and Circuit Diagrams
GRUNDIG Service 21
M
M M
M
M
10k
CR32133
1,8k
CR32141
560
CR32112
470
CR32113
1,5k
CR32142
*
CR32128
470
CR32150
100k
CR32132
33
CR32124
1,5k
CR32143
1,8k
CR32144
+E
56p
CC32121
10
n
68p
CC32122
68p
CC32124
68p
CC32123
+E
BC858B
CT32124
BC858B
CT32122
*
CR32131
BC848B
CT32123
*
CT32128
BC848B
CT32111
BC848B
CT32132
U
NORM2
U
TER
FBAS
n.V.
A
MP145
n.
V
.
*
D32128
31
6
7
24
8
8141-111-360
F32121
M
100n
_CC32111
FR NIC
INL
*
CR32129
n.v.
B
B
170997
HIGH
BASIS
EGNALE
_R.....=
CUC 2010
TUNER TEXT SCART uP-PLATTE SIGNAL-Bst. BR
CUC 2030
CUC 2030F
CUC 2031
CUC 2031M
CUC 2040N
CUC 2060
CUC 2060M
CUC 2068
CUC 2068M
CUC 2069
CUC 2069M
CUC 2080M
VST
VST
PLL
PLL
PLL
PLL
PLL
PLL
PLL
PLL
PLL
PLL
PLL
1S
1S
1S
8S
8S
8S
8S
8S
8S
8S
8S
8S
8S
1
1
2
2
2
2
2
2
2
2
2
2
2
28"
25/28"
25/28"
29"SF
29"SF
25/28"
25/28"
25/28"
32"16:9
32"16:9
NIC/DPL
Sonst.
28"16:9
28"16:9
34"
MONO
FR
0
0
CR34064
4,7k
4,7k
1N4148
1N4148
BC848B
BC848B
4,7k
4,7k
4700,1u
0,1u
0,1u
0
MATRIX
VIDEO
CR32128D32128CT32128CR32129CR32131
CR34067
CC34067
CC34064
S
IGNAL-BAUSTEIN
0
RESERV. EL DEREC. DE MODIFIC.
CON RISERVA DI MODIFICA
SOURS RESERVE DE MODIFIC
SUBJECT TO ALTERNATE
AENDERUNGEN VORBEHALTEN
LE SIGNAL
D
ULE

Platinenabbildungen und Schaltpläne / Layout of the PCBs and Circuit Diagrams CUC 2030 N / 2031 / 2031 N / 2040 N
22 GRUNDIG Service
Bedieneinheit / Control Unit 29501-082.62
K
8,2n
C44506
+H
U
LED
FBAS
1N4148 D81501
R83001
1,2k
+M
IR
IR
+5V
12
3
TFMS5300
IC84001
U
IDEN1
1
2
3
4
5
ST-CI1
CINCH
AUDIO-L
CINCH
AUDIO-R
+
47u/10V
C84001
BU11
K
0,1u
C84002
L
R
1
2
3
BU10
KH
AUDIO-R
KH
AUDIO-L
K
470p
C44501
R41501
33
R44503
470
K
8,2n
C41502
K
5,6n
C41501
K
5,6n
C41503
K
470p
C44503
R44501
470
R41503
33
R84001
270
R
L
+
2,2u/100V
C44504
R83004
8,2k
R83003
4,7k
R83002
2,2k
R44511
47k
TLHR4601
D85001
+
2,2u/100V
C44502
-L
+L
+P
-P
KB
U
OFF
POWER
7
8
9
1
2
3
4
5
6
ST-KB\IR
1
2
3
ST-H
FBAS
CINCH
R44509
75
IR
+5V
12
3
TFMS5300
IC84002
28500-708.97
S60000
TLHR4601
D85002
n.V.
n.V.
n.V.
R84002
100
R44508
82k
1
2
3
4
F
220n
C44508
1
2
ST-NETZ1
BC558C
T44510
BC548B
T44505
n.V.
1
2
ST-NETZ2
n.V.
R44506
3,3k
R44507
1,8k
U
WISCH
A
A
A
IR
IR
IR
IR
IR
+M
+M
V
VV
V
VV
V
V
KH
KH KH
KH
+H
+H
+H
+H
+H
+H
310797
DRUCK 29306-202.21
BEDIENEINHEIT 29501-082.62
CIRCUIT NOT MAINS ISOLATED
AL TELAIO
AL TELAIO
UNIDAD DE MANDO
UNITA DI COMANDO
UNITE DE COMANDE
CONTROL UNIT
SECTOUR DE COM. NO SEP. DE LA RED
CIRCUITO NON SEPAR., DALA RETE
CIRCUIT NON ISOLE DU SECTEUR
NICHT NETZGETRENNTES SCHALTUNGSTEIL
AL CHASIS
Seite/Page 15
SM. Seite/Page 3-13
VERS CHASSIS
TO CHASSIS
ZUM CHASSIS
ZUM CHASSIS
TO CHASSIS
VERS CHASSIS
AL CHASIS

CUC 2030 N / 2031 / 2031 N / 2040 N Platinenabbildungen und Schaltpläne / Layout of the PCBs and Circuit Diagrams
GRUNDIG Service 23
2
29306-202.21/2L(00)
C44506
D81501
R83001
31
IC84001
51
ST-CI1
C84001
C84002
C44501
R41501
R44503
C41502
C41501
C41503
C44503
R44501
R41503
1
NETZ22
1
NETZ21
C44504
R83004
R83003
R83002
R44511
D85001
C44502
P-
L+L- P+
91
ST-KB\IR
31
ST-H
R44509
31
IC84002
S60000
1
NETZ11
BRU100
D85002 BU11
1
NETZ12
BRU003
R44508
C44508
CE
T44510
CE
T44505
BU10
R84001
R44507
BRU002
R84002
R44506
BRU004
NETZTRENNUNG
KEINE
29306-202.21/4B(00)
2
29306-202.21/2L(00)
C44506
D81501
R83001
31
IC84001
51
ST-CI1
C84001
C84002
C44501
R41501
R44503
C41502
C41501
C41503
C44503
R44501
R41503
1
NETZ22
1
NETZ21
C44504
R83004
R83003
R83002
R44511
D85001
C44502
P- L+ L-
P+
91
ST-KB\IR
31
ST-H
R44509
31
IC84002
S60000
1
NETZ11
BRU100
D85002
BU11
1
NETZ12
BRU003
R44508
C44508
CE
T44510
CE
T44505
BU10
R84001
R44507
BRU002
R84002
R44506
BRU004
NETZTRENNUNG
KEINE
29306-202.21/4B(00)
Bestückungsseite, Ansicht von oben
Component Side, Top View
Lötseite, Ansicht von unten
Solder Side, Bottom View

Platinenabbildungen und Schaltpläne / Layout of the PCBs and Circuit Diagrams CUC 2030 N / 2031 / 2031 N / 2040 N
24 GRUNDIG Service
Bedieneinheit / Control Unit 29501-082.66
U
IDEN1
TLHR4601
D85001
100
R84002
R83001
1,2k
R83004
8,2k
R83003
4,7k
-L
+L
+P
-P
R83002
2,2k
1
2
ST-ID
1
2
ST-NETZ2
+H
U
LED
1N4148 D81501
U
WISCH
IR
IR
+5V
12
3
TFMS5300
IC84001
270
R84001
+M
+
47u/10V
C84001
KB
1
2
ST-NETZ1
7
8
9
1
2
3
4
5
6
U
OFF
POWER
28500-708.97
S60000
+H
+H
+H
+H
+H
IR IR
IR
+M
+M
+M
030697
DRUCK 29306-202.22 ST 72-865 CUC2000
BEDIENEINHEIT 29501-082.66
UNIDAD DE MANDO
UNITA DI COMANDO
UNITE DE COMANDE
CONTROL UNIT
CIRCUIT NOT MAINS ISOLATED
AL TELAIO
AL TELAIO
AL TELAIO
SECTOUR DE COM. NO SEP. DE LA RED
CIRCUITO NON SEPAR., DALA RETE
CIRCUIT NON ISOLE DU SECTEUR
NICHT NETZGETRENNTES SCHALTUNGSTEIL
ZUM CHASSIS
ZUM CHASSIS
ZUM CHASSIS
TO CHASSIS
TO CHASSIS
TO CHASSIS
VERS CHASSIS
VERS CHASSIS
VERS CHASSIS
AL CHASIS
AL CHASIS Seite/Page 15
SM. Seite/Page3-13
AL CHASIS
ZUR CINCH-BUCHSENPLATTE LA PLACA DE TOMAS CINCH ALLA PIASTRA PRESE CINCH VERS C.I.PRISES CINCH TO PHONE SOCKET BOARD
SM. Seite/Page 3-13 Seite/Page 27

CUC 2030 N / 2031 / 2031 N / 2040 N Platinenabbildungen und Schaltpläne / Layout of the PCBs and Circuit Diagrams
GRUNDIG Service 25
Bestückungsseite, Ansicht von oben
Component Side, Top View
4
29306-202.22/2l(01)
31IC84001
R84001
C84001
D81501
+P
S60000
R83002
R83003
R83004
R83001
-L
+L
-P
1
1
1
1
91
21
R84002
29306-202.22/4B(01)
Netztrennung
keine
st-netz2
st-netz1
4
29306-202.22/2l(01)
31 IC84001
R84001
C84001
D81501
+P
S60000
R83002
R83003
R83004
R83001
-L +L -P
1
1
1
1
91 21
R84002
29306-202.22/4B(01)
Netztrennung
keine
st-netz2
st-netz1
Lötseite, Ansicht von unten
Solder Side, Bottom View

Platinenabbildungen und Schaltpläne / Layout of the PCBs and Circuit Diagrams CUC 2030 N / 2031 / 2031 N / 2040 N
26 GRUNDIG Service
Buchsenplatte / Socket Board 29305-160.53
Bestückungsseite, Ansicht von oben
Component Side, Top View
2
0123456789
29304-519.88/2L(00)
L40078
L40076
L40073
L40071
71
ST-LS
29304-519.88/4B(00)
2
0123456789
29304-519.88/2L(00)
CR40076
CC40073
CR40078
CR40077
CR40073 CR40074
CR40072
CR40071
CR40079
CC40071
CC40078
CC40076
29304-519.88/4LS(00)
Lötseite, Ansicht von unten
Solder Side, Bottom View
M1 M1
M1M1
FEDERKLEMME
4 3
2 1
FEDERKLE
FEDERKLEMME
4 3
2 1
FEDERKL
M1
M1
2,2k
CR40079
22
CR40078
09238-224.06
L40078
4,7n
CC40078
4,7n
CC40076
09238-224.06
L40076
22
CR40076
2,2k
CR40077
M1
M1
22
CR40073
2,2k
CR40074
M1 M1
2,2k
CR40072
22
CR40071
4,7n
CC40073
09238-224.06
L40073
09238-224.06
L40071
4,7n
CC40071
M1M1
M1
7
1
2
3
4
5
6
ST-LS1
040697
DRUCK: 29304-519.88
PLACA DE TOMAS
C.I.PRISES
PIASTRA PRESE
SOCKET BOARD
BUCHSENPLATTE 29305-160.53
SURR.CENTER
LS-RLS-L
EMME MME
ZUR DOLBY-SURROUNDPLATTE
A LA PLACA DOLBY SURROUND
Seite/Page 13
ALLA PIASTRA DOLBY SURROUND VERS C. I. DOLBY SURROUND TO DOLBY SURROUND BOARD
