Grundig Planatron DS2 User manual

TV Service Manual
Planatron
DS2
(G.AE 3952)
Btx * 32700 # • Materialnummer/Part Number 72010 024 5000
Änderungen vorbehalten/Subject to alteration • Printed in Germany
E-BS33/32 1299
http://www.grundig.com
Zusätzlich erforderliche Unterlagen für den Komplettservice
Additionally required Service Documents for the Complete Service
Service
Manual
GrundigService
Hotline Deutschland...
TV
TV
SAT
VCR/LiveCam
HiFi/Audio
Car Audio
Telekommunikation
Fax:
Planatron (8.00-22.00 Uhr)
0180/52318-41
0180/52318-49
0180/52318-48
0180/52318-42
0180/52318-43
0180/52318-44
0180/52318-45
0180/52318-51
0180/52318-99
...Mo.-Fr. 8.00-18.00 Uhr
0180/52318-40
0180/52318-50
Telefon:
Fax:
Technik:
Ersatzteil-Verkauf: ...Mo.-Fr. 8.00-19.00 Uhr
Sicherheit
Safety
Materialnr./Part No.
72010 800 0000

Allgemeiner Teil / General Section Planatron DS2
1 - 2 GRUNDIG Service
Table of Contents
Page
General Section................................................................. 1-2…1-8
Module List................................................................................... 1-2
Operating Hints ............................................................................ 1-6
Layout of the PCBs
and Circuit Diagrams ...................................................... 2-1…2-14
Connecting Board ........................................................................ 2-1
Socket Board ............................................................................... 2-1
Chassis Board.............................................................................. 2-3
Connection Board Cable............................................................ 2-11
Spare Parts Lists............................................................... 3-1…3-2
Inhaltsverzeichnis
Seite
Allgemeiner Teil ................................................................ 1-2…1-8
Modulübersicht............................................................................. 1-2
Bedienhinweise ............................................................................ 1-3
Platinenabbildungen
und Schaltpläne .............................................................. 2-1…2-14
Verbindungsplatte ........................................................................ 2-1
Buchsenplatte .............................................................................. 2-1
Chassisplatte ............................................................................... 2-3
Anschlussplatte Kabel................................................................ 2-11
Ersatzteillisten................................................................... 3-1…3-2
Es gelten die Vorschriften und Sicherheitshin-
weise gemäß dem Service Manual "Sicherheit",
Materialnummer720108000000,sowiezusätz-
lich die eventuell abweichenden, landes-
spezifischen Vorschriften!
The regulations and safety instructions shall be
validasprovidedbythe"Safety"ServiceManual,
part number 72010 800 0000, as well as the
respective national deviations.
GB
D
General Section
Test Equipment
Please note the Grundig Catalog "Test and Measuring Equipment"
obtainable from:
Allgemeiner Teil
Meßgeräte
BeachtenSiebitte das Grundig Meßtechnik-Programm,dasSieunter
folgender Adresse erhalten:
Grundig AG
Geschäftsbereich Instruments
Test- und Meßsysteme
Würzburger Str. 150
D-90766 Fürth
Tel.: 0911 / 703-4118
Fax: 0911 / 703-4130
eMail: [email protected]
Internet: http://www.grundig-instruments.de
Modulübersicht / Module List
Materialnummer
Part Number Planatron DS2
Bestell-Nr.
Order No. G.AE 3952 (VNM)
Verbindungsplatte
Connection Board 29305 312 0200
•
Buchsenplatte
Socket Board 29305 304 0200
•
Anschlussplatte Kabel
Connection Board Cable 29305 307 0200
•
Chassisplatte
Chassis Board 29305 314 0100
•

Planatron DS2 Allgemeiner Teil / General Section
GRUNDIG Service 1 - 3
Bedienhinweise Dieses Kapitel enthält Auszüge aus der Bedienungsanleitung. Weitergehende Informationen entnehmen Sie bitte der
gerätespezifischen Bedienungsanleitung, deren Materialnummer Sie in der entsprechenden Ersatzteilliste finden.

Allgemeiner Teil / General Section Planatron DS2
1 - 4 GRUNDIG Service

Planatron DS2 Allgemeiner Teil / General Section
GRUNDIG Service 1 - 5

Allgemeiner Teil / General Section Planatron DS2
1 - 6 GRUNDIG Service
Operating Hints Thischaptercontainsexcerptsfromtheoperatinginstructions.Forfurtherparticularspleaserefertotheappropriateuser
instructions the part number of which is indicated in the relevant spare parts list.

Planatron DS2 Allgemeiner Teil / General Section
GRUNDIG Service 1 - 7

Allgemeiner Teil / General Section Planatron DS2
1 - 8 GRUNDIG Service

GRUNDIG Service GRUNDIG Service
Planatron DS2 Platinenabbildungen und Schaltpläne / Layout of PCBs and Circuit Diagrams Planatron DS2 Platinenabbildungen und Schaltpläne / Layout of PCBs and Circuit Diagrams
Verbindungsplatte / Connecting Board
2 - 22 - 1
29306-207.02/2L(02)
6
12
LED1
12
LED2
D44018
17
ST-SV3 BU1
12 34
ST-SVHS1 ST-KH
13
ST-H2
1
6
3
2
548 7
051
42
3
9
MI-
29306-207.02/4B(02)
BUCHSENPLATTE
29306-207.02/2L(02)
6
CR44010
CR44011
CR44001
CR44005
CR44004
CR44016
CR44015
CR44019
CC44001
CC44005
CC44004
CC44003
CC44002
CC44015
CC44016
CC44019
29306-207.02(02)4LS
5
29306-216.02/2L(01)
10 1
VS329_51
110
5 1
FSTIFT10
5 1
FSTIFT10
10 1
VS329_51
110
5 1
FSTIFT10
5 1
FSTIFT10
10 1
VS329_51
110
5 1
FSTIFT10
5 1
FSTIFT10
10 1
VS329_51
110 10 1
VS329_51
110
5 1
FSTIFT10
5 1
FSTIFT10
5 1
FSTIFT10
5 1
FSTIFT10
n.V.
TLHR4601
D44018
100n
CC44001
7
1
2
3
4
5
6
ST-SV3
1
2
3
ST-H2
BU1
12
34
ST-SVHS1
FBAS
XX
CR44010
XX
CR44011
V
100
CR44001
5,6n
CC44005
5,6n
CC44004
8,2n
CC44003
150p
CC44002
L
R
1
2
3
ST-KH
100
CR44005
100
CR44004
470p
CC44015 470p
CC44016
BU1
470
CR44016
470
CR44015
BU1
CAV
L
CAV
R
n.V.
100
CR44019
CHROMA
150p
CC44019
1
2
LED1
1
2
LED2
KH
KH
KH
KH
A
A
A
A
A
V
V
V
VV
VV
V
V
290799
BUCHSENPLATTE 29305 304 0200
SOCKET BOARD
C.I. PRISES
PIASTRA PRESE
PLACA DE TOMAS
Lötseite, Ansicht von unten
Solder Side, Bottom View
Bestückungsseite, Ansicht von oben
Component Side, Top View
Buchsenplatte / Socket Board
Spannungstabelle
Voltage table
+1 12V
+2 5V
+3 3,3V
+4 5V
+5 5V
+H 5V
+M 20V
+K 12,5V
+F 5V
+G 16,5V
–G -16,5V
+Q 8,5V
+S 5V
+R 6,5V
+ECO 6,5V
PlatinenabbildungenundSchaltpläne/LayoutofthePCBsandCircuitDiagrams
Seite / Page 2-8
Seite / Page 2-8
zu LED2
to LED2
zu LED1
to LED1

GRUNDIG Service GRUNDIG Service
Platinenabbildungen und Schaltpläne / Layout of PCBs and Circuit Diagrams Planatron DS2 Platinenabbildungen und Schaltpläne / Layout of PCBs and Circuit Diagrams Planatron DS2
Chassisplatte / Chassis Board
2 - 3 2 - 4
29306-219.01/2L(02)
6
0 1 2 3 4 5 6 7 8 9
1 26
2752
IC41650
1 26
2752
IC41660
C41668 C41674
C41651 C41652
C41693
C41691
C41642
C41722
C41681
C41687
C41751
C41752 C41794
C41791
C41742
C41512
BR108
BR109
BR110
BR111
BR113
BR125
BR126 BR132 BR134 BR145
BR112
BR116
BR127
BR166
BR120
BU1C-VGA
DOLBY2 DOLBY1
BR143
BR153
41
58
IC41620
VGA-VIDEO
BU4
1
ST-DP2
1
ST-DP1
1
ST-DP3
1
ST-DP4
1
ST-DP5
Q41662 Q41762
BR117
BR141
BR152
BR157
BR129
L41644 L41744
C41619
119
37 20
ST
D41621
D41616
D41617
BR167
BR158
BR159
BR160
13
IC41600
13
IC41500
17
814
IC41720
17
814
IC41750
BR170
BR171
BR168
BR172
BR142
BR154
BR165
BR169
BR122
BR161
BR162
L41742
L41642
BR149
BR114
BR137 BR146
BR100
BR148
BR130
BR121
BR135
BR139
BR115
BR106
BR150
BR163
BR164
BR119
BR128
BR138
BR133
BR151
BR147
13
ST-H2
17
ST-SV3
BR118
R41602
R41601
13 46
S1
123
4
5
6
7
8
90
51
2
3
4
C41649
C41749
C41647
MI-
R41500
2
1
ST-LUEFTER
29306-219.01/4B(02)
0
10
20
30
40
50
60
70
80
90
100
110
120
130
140
150
160
170
180
190
200
210
220
230
240
250
260
Y
0102030405060708090100110120130140150160170180190200210220230240250260270280290300310320330340350360370
X
Bestückungsseite, Ansicht von oben
Component Side, Top View
Koordinaten Seite 2-7
Coordinates Page 2-7

GRUNDIG Service GRUNDIG Service
Planatron DS2 Platinenabbildungen und Schaltpläne / Layout of PCBs and Circuit Diagrams Planatron DS2 Platinenabbildungen und Schaltpläne / Layout of PCBs and Circuit Diagrams
29306-219.01/2L(02)
6
0 1 2 3 4 5 6 7 8 9
CT41665
CT41670
CT32615
CT41675
CT41785
CT41790
CT41780
CT41505
CR41746
CR41753
CR41752
CR41751
CR44645
CR44646
CR41696
CR41618
CR41621
CR41616
CR41727 CR41726 CR41724
CR41714CR41713
CR41669 CR41676
CR41717 CR41716
CR41617
CR41731
CR41733
CR41667
CR41672
CR41678
CR41684
CR41677
CR41702 CR41701
CR41671
CR41683
CR41666
CR41704
CR41686 CR41679
CR41673
CR41668
CR41707
CR41706
CR41703
CR41699
CR41698
CR41697
CR41641
CR41688
CR41682
CR41734
CR41723
CR41606
CR41806
CR41801 CR41802 CR41803 CR41804
CR41708
CR41712
CR41711
CR41745
CR41722
CR41725
CR41721
CR41607
CR41645
CR41741
CR41797
CR41729
CR41744
CR41783
CR41812
CR41811
CR41814
CR41813
CR41788
CR41635
CR41787 CR41786 CR41793 CR41792
CR41619
CR41624
CR41632
CR41791
CR41633
CR41634
CR41622
CR41623
CR41782
CR41762
CR41781
CR41609
CR41766
CR41768
CR41767
CR41764
CR41772
CR41771
CR41763
CR41761
CR41754
CR41644
CR41779
CR41710
CR41507
CR41506
CR41502
CR41501
CR41503
CR41816
CR41815
CR41675
CD41731
CD41732
CD41511 CC41508
CC41801 CC41803
CC41754 CC41755
CC41602
CC41601
CC41751
CC41753
CC41723
CC41734
CC41669
CC41726
CC41724
CC41727
CC41714
CC41713
CC41666
CC41664
CC41678
CC41679
CC41654
CC41644
CC41684
CC41694
CC41692
CC41686
CC41663 CC41662
CC41653
CC41672
CC41673
CC41667
CC41677
CC41656
CC41646
CC41671
CC41683
CC41643 CC41641
CC41706 CC41707
CC41704
CC41703
CC41731
CC41752
CC41676
CC41682
CC41732
CC41688
CC41759
CC41744
CC41742
CC41796
CC41793
CC41765
CC41762
CC41758
CC41756
CC41746
CC41789
CC41722
CC41725
CC41741
CC41743
CC41787
CC41721
CC41811
CC41813
CC41788 CC41792 CC41783
CC41763CC41767
CC41771
CC41772
CC41761
CC41501
CC41511
CC41675
CBR100
CBR106
CBR119
CBR118
CBR120
CBR115
CBR116
CBR117
CBR105
CBR104
CBR113
CBR114
CBR112
CBR109
CBR108
CBR101
CBR103
CBR121
CT41634
CT41632
CT41633
CL41796
CR41807
CC41815
CC41816
29304-219.01/4LS(02)
0
0
10
20
30
40
50
60
70
80
90
100
110
120
130
140
150
160
170
180
190
200
210
220
230
240
250
260
10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170 180 190 200 210 220 230 240 250 260 270 280 290 300 310 320 330 340 350 360 370
Y
X
Lötseite, Ansicht von unten
Solder Side, Bottom View
Chassisplatte / Chassis Board
2 - 62 - 5
Koordinaten Seite 2-7
Coordinates Page 2-7

GRUNDIG Service GRUNDIG Service
Platinenabbildungen und Schaltpläne / Layout of PCBs and Circuit Diagrams Planatron DS2 Platinenabbildungen und Schaltpläne / Layout of PCBs and Circuit Diagrams Planatron DS2
Chassisplatte / Chassis Board
BR100 282 37
BR106 226 26
BR108 294 122
BR109 286 129
BR110 291 124
BR111 296 119
BR112 292 56
BR113 289 127
BR114 278 37
BR115 288 49
BR116 294 61
BR117 316 5
BR118 87 169
BR119 246 8
BR120 33 169
BR121 111 24
BR122 112 207
BR125 286 156
BR126 294 156
BR127 294 58
BR128 248 8
BR129 36 151
BR130 274 37
BR132 289 156
BR133 342 166
BR134 296 156
BR135 91 211
BR137 264 18
BR138 103 170
BR139 120 183
BR141 300 46
BR142 170 212
BR143 13 195
BR145 291 156
BR146 229 18
BR147 188 166
BR148 343 29
BR149 36 16
BR150 13 199
BR151 289 169
BR152 36 158
BR153 13 190
BR154 353 19
BR157 36 155
BR158 126 186
BR159 149 187
BR160 130 185
BR161 31 208
BR162 144 164
BR163 137 185
BR164 96 228
BR165 11 164
BR166 93 150
BR167 200 224
BR168 200 221
BR169 171 56
BR170 182 21
BR171 203 232
BR172 288 23
BU01 136 4
Koordinaten für die Bauteile der Bestückungsseite (Oberseite)
Coordinates of the Components on the Components Side (Top Side)
Pos.-Nr./ Koordinaten/
Pos. No. Coordinates
XY
Pos.-Nr./ Koordinaten/
Pos. No. Coordinates
XY
Pos.-Nr./ Koordinaten/
Pos. No. Coordinates
XY
BU04 264 5
CVGA 166 4
C41512 71 186
C41619 212 35
C41642 170 201
C41647 172 223
C41649 115 223
C41651 124 222
C41652 130 222
C41668 88 191
C41674 82 191
C41681 21 206
C41687 19 216
C41691 137 222
C41693 146 222
C41722 129 151
C41742 93 219
C41747 74 226
C41749 36 223
C41751 45 222
C41752 51 222
C41791 58 222
C41794 67 222
D41616 215 45
D41617 212 45
D41621 209 45
DOLBY01 55 4
DOLBY02 85 4
IC41500 61 188
IC41600 97 196
IC41620 212 28
IC41650 141 208
IC41660 62 208
IC41720 142 151
IC41750 195 36
L41642 161 227
L41644 148 196
L41742 97 225
L41744 70 196
Q41662 163 221
Q41762 84 221
R41500 77 182
R41601 114 190
R41602 99 207
S01 197 11
ST 322 2
STDP01 30 173
STDP02 103 173
STDP03 182 173
STDP04 260 173
STDP05 333 173
STH02 240 228
STLUEFTER 42 184
STSV03 203 228
VGAVIDEO 229 5
Pos.-Nr./ Koordinaten/
Pos. No. Coordinates
XY
Pos.-Nr./ Koordinaten/
Pos. No. Coordinates
XY
Pos.-Nr./ Koordinaten/
Pos. No. Coordinates
XY
CBR100 337 146
CBR101 185 12
CBR103 233 5
CBR104 241 6
CBR105 229 5
CBR106 204 20
CBR108 42 137
CBR109 249 193
CBR112 260 40
CBR113 267 35
CBR114 265 37
CBR115 267 40
CBR116 228 27
CBR117 228 24
CBR118 235 6
CBR119 82 183
CBR120 84 183
CBR121 259 166
CC41501 65 184
CC41508 53 194
CC41511 69 185
CC41601 94 194
CC41602 94 199
CC41641 130 204
CC41643 157 204
CC41644 135 206
CC41646 139 204
CC41653 130 212
CC41654 152 219
CC41656 153 212
CC41662 162 212
CC41663 165 212
CC41664 123 204
CC41666 113 207
CC41667 108 201
CC41669 69 13
CC41671 119 204
CC41672 121 212
CC41673 116 212
CC41675 182 7
CC41676 84 13
CC41677 44 205
CC41678 28 202
CC41679 33 207
CC41682 39 10
CC41683 41 205
CC41684 41 212
CC41686 36 212
CC41688 54 13
CC41692 135 212
CC41694 148 212
CC41703 152 204
CC41704 149 204
CC41706 145 204
CC41707 142 204
CC41713 121 15
CC41714 134 15
CC41721 71 204
CC41722 68 204
CC41723 134 151
CC41724 148 143
CC41725 65 204
CC41726 143 143
CC41727 138 143
CC41731 142 159
CC41732 150 159
CC41734 144 168
CC41741 51 204
CC41742 78 212
CC41743 78 204
CC41744 56 206
CC41746 61 204
CC41751 295 21
CC41752 295 24
CC41753 295 18
CC41754 198 28
CC41755 203 28
CC41756 74 212
CC41758 51 212
CC41759 73 219
CC41761 203 36
CC41762 83 212
CC41763 199 43
CC41765 86 212
CC41767 194 43
CC41771 184 35
CC41772 184 39
CC41783 229 40
CC41787 237 40
CC41788 240 40
CC41789 249 40
CC41792 252 40
CC41793 56 212
CC41796 69 212
CC41801 254 169
CC41803 251 163
CC41811 313 26
CC41813 311 23
CC41815 170 168
CC41816 165 168
CD41511 48 190
CD41731 146 159
CD41732 148 164
CL41796 226 48
CR41501 56 194
CR41502 56 190
CR41503 65 189
CR41506 58 185
CR41507 48 188
CR41606 238 5
CR41607 269 6
CR41609 272 6
CR41616 216 20
CR41617 213 20
Koordinaten für die Bauteile der Lötseite (Unterseite)
Coordinates of the components on the Solder Side (Bottom Side)
Pos.-Nr./ Koordinaten/
Pos. No. Coordinates
XY
Pos.-Nr./ Koordinaten/
Pos. No. Coordinates
XY
Pos.-Nr./ Koordinaten/
Pos. No. Coordinates
XY
CR41618 210 43
CR41619 208 20
CR41621 211 20
CR41622 251 26
CR41623 243 26
CR41624 235 26
CR41632 251 22
CR41633 243 22
CR41634 235 22
CR41635 201 18
CR41641 135 203
CR41644 155 204
CR41645 161 227
CR41666 114 203
CR41667 111 203
CR41668 102 208
CR41669 74 13
CR41671 117 205
CR41672 118 212
CR41673 96 210
CR41675 182 4
CR41676 89 13
CR41677 35 203
CR41678 32 203
CR41679 23 206
CR41682 44 11
CR41683 38 205
CR41684 38 212
CR41686 22 220
CR41688 59 13
CR41696 72 13
CR41697 87 13
CR41698 42 11
CR41699 57 13
CR41701 153 196
CR41702 151 196
CR41703 149 191
CR41704 148 196
CR41706 132 191
CR41707 142 196
CR41708 51 196
CR41710 145 196
CR41711 74 194
CR41712 72 194
CR41713 153 11
CR41714 168 11
CR41716 124 15
CR41717 137 15
CR41721 69 194
CR41722 67 194
CR41723 125 158
CR41724 137 151
CR41725 64 194
CR41726 142 151
CR41727 147 151
CR41729 125 153
CR41731 138 159
CR41733 148 167
CR41734 148 169
CR41741 56 203
CR41744 75 204
CR41745 82 226
CR41746 96 228
CR41751 156 141
CR41752 152 141
CR41753 141 140
CR41754 143 191
CR41761 203 44
CR41762 200 36
CR41763 200 47
CR41764 198 47
CR41766 195 36
CR41767 195 47
CR41768 193 47
CR41771 313 5
CR41772 316 5
CR41779 132 196
CR41781 238 30
CR41782 235 40
CR41783 232 40
CR41786 247 30
CR41787 246 40
CR41788 243 40
CR41791 256 30
CR41792 257 40
CR41793 254 40
CR41797 226 42
CR41801 251 169
CR41802 254 163
CR41803 248 169
CR41804 248 163
CR41806 130 196
CR41807 181 231
CR41811 173 168
CR41812 311 19
CR41813 167 168
CR41814 309 19
CR41815 173 178
CR41816 170 178
CR44645 210 16
CR44646 210 14
CT32615 31 212
CT41505 54 185
CT41632 255 22
CT41633 247 22
CT41634 239 22
CT41665 107 205
CT41670 111 212
CT41675 28 206
CT41780 233 34
CT41785 242 34
CT41790 252 34
Pos.-Nr./ Koordinaten/
Pos. No. Coordinates
XY
Pos.-Nr./ Koordinaten/
Pos. No. Coordinates
XY
Pos.-Nr./ Koordinaten/
Pos. No. Coordinates
XY
2 - 7 2 - 8
VCC A6
Y6
A5
Y5
A4
Y4
GND
Y3
A3
Y2
A2
Y1
A1
1
2
3
4
5
6
7
8
9
10
11
12
13
14
74HCT04
IC41750
0,1u
CC41789
1
CR41761
0,1u
CC41761
1,5k
CR41763
100
CC41772
100
CC41771
47
CR41764
1,5k
CR41767
10p
CC41767
47
CR41768
10p
CC41763
1k
CR41766
0
CR41606
ST
0
CR41607
0
CR41609
1n
CC41801
1n
CC41803
100
CR41781
xx
CC41783
470
CR41803
BC858B
CT41780
7
8
9
10
1
2
3
4
5
6
ST-DP5
ST
100
CR41806
ST
ST
1k
CR41762
18,432MH
z
Q41662
47n
CC41641
1,5p
CC41662
CC41663
470
CR41804
150p
CC41675
330
CR41782
100
CR41617
CHROMA
S-VHS
V
ZPD5,1 D41617 ZPD5,1 D41616
U
VGA
VIDEO
S-VHS
OUT
L
BC817-25
CT41633
KH
GND
BC817-25
CT41632
75
CR41623
KH
R
75
CR41622
B
G
U
DATA
R
H
DISPLAY
V
DISPLAY
680
CR41634
470
CR41716
BU1
470
CR41717
680
CR41633
G
VGA-IN
R
VGA
F
0,1u
C41619
G
VGA
B
VGA
VIDEO
+R
+M
I2S
WS
I2S
CL
I2S
DATA3
7
8
9
10
1
2
3
4
5
6
ST-DP4
7
8
9
10
1
2
3
4
5
6
ST-DP3
7
8
9
10
1
2
3
4
5
6
ST-DP1
7
8
9
10
1
2
3
4
5
6
ST-DP2
KH
L
CHROMA
FBAS
TXT
100
CR41791
470p
CC41713
IN
L
IN
R
C-VGA
470
CR41713
xx
CC41792
BC858B
CT41790
470p
CC41714
470
CR41714
C-VGA
ST
ST
ST
ST
ST
ST
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
BU4
V
ST
ST
ST
ST
ST
ST
ST
680
CR41632
ST
ST
ST
ST
BC817-25
CT41634
ST
ST
ST
ST
ST
CAV
R
CAV
L
RXD
IN
TXD
OUT
n.V.
V
U
RESET
SYSTE
B
VGA-IN
SDA2
R
VGA-IN
U
WAKE
UP
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
VGA-VIDEO
SCL3
VGA
L
VGA
R
75
CR41624
100
CR41616
100
CR41621
47k
CR41618
V
100
CR41619
TEST
VSSA2A1A0
SCL
SDA VCC
1234
5
67
8
ST24LC21
IC41620
VV
ZPD5,1 D41621
470
CR41801
ST
BU1
ST
OUT
R
330
CR41792
47
CR41793
100
CR41786
xx
CC41788
BC858B
CT41785
330
CR41787
A
10k
CR41635
V
47
CR41788
+F
1
CR41797
CC41601
100
CR41675
SU358_04
S1
1k
CR41813
470
CR41802
47
CR41814
100p
CC41755
100p
CC41754
220
CR44646
220
CR44645
330
CR41807
1k
CR41811
ST
1n
CC41815
1n
CC41816 47
CR41812
470p
CC41813
ST
330p
CC41811
47
CR41783
DACA_R
ANA_IN1+
ANA_IN2+
ANA_IN-
XTAL_IN
MONO IN
47
48
49
5121
0,1u
CC41787
1k5
CR41816
6,8
R41601
1k5
CR41815
1
2
3
ST-H2
7
1
2
3
4
5
6
ST-SV3
Sa.Nr.8104/982/330
CL41796
V
VV
V
V
V V
V
V
V
V
V
V
VV
V
V
V
VV
VV
VV
V
VV
V
V
V
V
V
V
V
V
+F
+F
+F
+F
+R
M
M1
M1
M1 M1
KH
KH
+M
+M
A
AA
A
A
A
A
33
ANMERKUNG ST_1 - ST_37 SUB-D-BUCHSENLEISTE 37POLIG
1
VERS C.I. PRISES
LA PLACA DE TOMAS
ALLA PIASTRA PRESE
TO SOCKET BOARD
ZUR BUCHSENPLATTE
25
24
6
5
31
34
15
32
31
32
OUT
IN
34
27
23
22
16
35
17
36
18
37
19
13
14
15
9
28
10
29
11
30
12
4
3
Seite / Page 2-1

GRUNDIG Service GRUNDIG Service
Planatron DS2 Platinenabbildungen und Schaltpläne / Layout of PCBs and Circuit Diagrams Planatron DS2 Platinenabbildungen und Schaltpläne / Layout of PCBs and Circuit Diagrams
2- 102 - 9
Spannungstabelle
Voltage table
+1 12V
+2 5V
+3 3,3V
+4 5V
+5 5V
+H 5V
+M 20V
+K 12,5V
+F 5V
+G 16,5V
–G -16,5V
+Q 8,5V
+S 5V
+R 6,5V
+ECO 6,5V
SC2_OUT_L
SC2_OUT_R
SC2_IN_R
SC2_IN_L
SC1_OUT_L
SC1_OUT_R
SC1_IN_R SC1_IN_L
DACM_SUB DACA_R
ANA_IN1+
ANA_IN2+
ANA_IN- (V.B3)
DACA_L XTAL_IN XTAL_OUT VREF2 DVSS DACM_R AVSS DACM_L VREF1 AHVSS AGNDC TESTEN NC VREFTOP D_CTR_OUT0 D_CTR_OUT1 AUD_CL_OUT ADR_DA I2S_DA_IN1 I2S_DA_OUT I2S_WS I2S_CL I2C_DA I2C_CL
AVSUP
AHVSUP CAPL_M CAPL_A
ADR_SEL
DVSUP
STANDBYQ
SC_3_IN_R SC_3_IN_L
RESETQ
NC
I2S_DA_IN2
ADR_CL ADR_WS
MONO_IN
47
48
49
5051 52
46
27
28
29
30
31
32 3334
35 36
37 38
39
40
41 42
43
44
45
56
7 8 9 10111213
14 15 16
17
18 19 20
21 22 23 24 25 26 3412
MSP3400C
IC41660
L41742
100
CR41708
+
10u/50V
C41751
+
10u/50V
C41752
+
10u/50V
C41794
+
4,7u/63V
C41791
+
470u/16V
C41749
+
220u/10V
C41747
+
47u/10V
C41742
220
CR41712
220
CR41711
2,2
CR41745
180
CR41722
180
CR41725
220
CR41503
180
CR41721
1n
CC41759
0,1u
CC41744
10n
CC41742
0,1u
CC41796
0,1u
CC41793
1,5p
CC41765
1,5p
CC41762
0,1u
CC41758
0,1u
CC41756
1n
CC41746
n.V.
31
2
OUTIN 7808
IC41600
10
CR41771
10
CR41772
100p
CC41772
100p
CC41771
47
C
R41764
47
C
R41768
L41644
+
10u/16V
C41512
DOLBY2
n.V.
n.V.
14
12
34
56
7
89
1011
1213
IC41720
74HCU04
n.V.
0,1u
CC41511
0
CR41754
LS4148
CD41732
+F
LS4148
CD41731
3,3
CR41723
1,5k
CR41501
470p
CC41688
10n
CC41732
100k
CR41734
470
CR41682
470p
CC41682
+
22u/50V
C41687
+
22u/50V
C41681
470
CR41688
DOLBY1
L41744
+
47u/..V
C41722
470p
CC41676
XX
CR41641
47k
CR41697
BC858B
CT41675
BC858B
CT32615
BC858B
CT41670 BC858B CT41665
100p
CC41752
n.V.
n.V.
18,432MHz
Q41662
100p
CC41731
47k
CR41698
47k
CR41699
AUDIO-L
AUDIO-R
n.V.
xx
CC41703
xx
CC41704
xx
CC41707
xx
CC41706
XX
CR41644
47n
CC41643
3,3n
CC41683
3,3n
CC41671
1n
CC41646
0,1u
CC41656
3,3n
CC41677
470p
CC41667
10n
CC41673
470p
CC41672
0,1u
CC41653
1,5p
CC41662
1,5p
CC41663
10n
CC41686
0,1u
CC41692
0,1u
CC41694
470p
CC41684
0,1u
CC41644
1n
CC41654
10n
CC41679
470p
CC41678
3,3n
CC41664
10n
CC41666
I2S
DATA3
I2S
WS
I2S
DATA2
I2S
CL
AUDIO
SURROUND AUDIO
CENTER
100
CR41703
0
CR41706
180
CR41707
2,2k
CR41668
2,2k
CR41673
2,2k
CR41679
2,2k
CR41686
180
CR41704
2,2
CR41645
3,3k
CR41666
3,3k
CR41683
3,3k
CR41671
220
CR41701
220
CR41702
3,3k
CR41677
3,3k
CR41684
3,3k
CR41678
3,3k
CR41672
3,3k
CR41667
+
47u/10V
C41642
+
220u/10V
C41647
+
470u/16V
C41649
+
4,7u/63V
C41691
+
10u/50V
C41693
+
10u/50V
C41652
+
10u/50V
C41651
100
CR41733
3,3
CR41729
1k
CR41731
n.V.
+F
+
22u/50V
C41674
+
22u/50V
C41668
470
CR41676
470
CR41669
DOLBY1
DOLBY2
33p
CC41727
33p
CC41724
33p
CC41726
470p
CC41669
1k
CR41724
1k
CR41726
1k
CR41727
ST
10n
CC41734
0,1u
CC41501
0,1u
CC41723
ST
ST
ST
47k
CR41696
XX
CR41741
100p
CC41753
100p
CC41751
100n
CC41601
0.47u
CC41602
6,8
R41602
15
CR41751
15
CR41752
15
CR41753 ST
ST
ST
V
ADJUST OUTIN
1
23 LM317
IC41500
6,8
R41500
18,432MHz
Q41762
xx
CC41721
xx
CC41722
xx
CC41725
XX
CR41744
100
CR41779
47n
CC41741
47n
CC41743
L41642
SC2_OUT_L
SC2_OUT_R
SC2_IN_R
SC2_IN_L
SC1_OUT_L
SC1_OUT_R
SC1_IN_R SC1_IN_L
DACM_SUB
_
IN1+
_
IN2+
_
IN- (V.B3)
DACA_L XTAL_IN XTAL_OUT VREF2 DVSS DACM_R AVSS DACM_L VREF1 AHVSS AGNDC TESTEN NC VREFTOP D_CTR_OUT0 D_CTR_OUT1 AUD_CL_OUT ADR_DA I2S_DA_IN1 I2S_DA_OUT I2S_WS I2S_CL I2C_DA I2C_CL
AVSUP
AHVSUP CAPL_M CAPL_A
ADR_SEL
DVSUP
STANDBYQ
SC_3_IN_R SC_3_IN_L
RESETQ
NC
I2S_DA_IN2
ADR_CL ADR_WS
MONO_IN
5051 52
46
27
28
29
30
31
32 3334
35 36
37 38
39
40
41 42
43
44
45
56
7 8 9 10111213
14 15 16
17
18 19 20
22 23 24 25 26 3412
DPL3519A
IC41650
100
CR41710
470
CR41502
100k
CR41506
0,22u
CC41508
100k
CR41507
BC858B
CT41505
6,8
R41601
LS4148
CD41511
2,2
CR41746
1
2
ST-LUEFTER
+Q
+Q
+Q
+Q
V
V
+F
M1
M1
M1
M1M1
M1
M1
M1
M1
M1
M1
M1M1
M1 M1
M1 M1 M1 M1
M1
M1
M1
M1
M1
M1
M1 M1 M1
M1
M1
M1
M1
M1
M1
M1
M1
M1M1
M1
M1
M1
M1
M1
M1 M1 M1 M1 M1
M1 M1
M1
M1
M1
M1 M1 M1
M1 M1
M1
M1
M1 M1 M1 M1
M1
M1
M1
M1 M1
M1
M1
M1
M1
M1
M1
M1
M1
M1
M1
-4V
+M
+Q1
+Q1
+Q1
+Q1
060799
SDIP52 SDIP52
AUDIO-UP AUDIO-UP
26
1
2
20
21
8
7
32 32

GRUNDIG Service GRUNDIG Service
Platinenabbildungen und Schaltpläne / Layout of PCBs and Circuit Diagrams Planatron DS2 Platinenabbildungen und Schaltpläne / Layout of PCBs and Circuit Diagrams Planatron DS2
29306-210.02/2L(02)
5
BR112
BR103
17
814
IC49720
17
814 IC49750
17
814
IC49711
R49767
BR116
BR105
BR104 BR102
BR114
BR117
BR115
R49724
R49726
R49727
R49733
R49735
R49732
R49737
R49741
R49738
R49723
R49722
R49792
R49791
R49736
R49774
R49772 R49773
R49771
R49769
R49766
R49768
R49753
R49752
R49751
R49754
R49756 R49758 R49757
R49712
R49711
R49714
R49715
R49716
R49713
R49718
R49717
R49734
D49723
D49791
D49711
C49734
C49732
C49733
C49735
C49736
C49737
C49729
C49723
C49726 C49724 C49727
C49731 C49728
C49716
C49711
C49717
C49742
C49743
BR107
BR108
BR109
BR110
110
ST-DP2
110
ST-DP3
110
ST-DP4
110
ST-DP5
110
ST-DP1
BR49726 BR49727
BR49724
C49722
C49788
C49763
C49757
C49712
BR113
R49745
R49742
R49728
R49729
R49731
R49744
R49743
BR111
D49758
D49761
D49753
D49762
14
58
IC49770
L49774
L49796 L49761
C49768
C49796
C49787
C49791
C49774
C49772
C49771
C49786
C49766
C49767
C49756
C49762
C49761
C49751
R49759
R49788
R49778
R49777
R49776
R49783
R49782
R49781
123
4
5
6
7
8
90
51
2
3
4
D49793
D49792
MI-
BR101
BR106
2037
19 1
29306-210.02/4B(02)
0
10
20
30
40
50
60
70
80
90
Y
0102030405060708090100110120130140150160170180190200210220230240250260270280290300310320330340350360370380390400
X
29306-210.02/2L(02)
5
BR112
BR103
17
814
IC49720
17
814
IC49750
17
814
IC49711
R49767
BR116
BR105
BR104BR102
BR114
BR117 BR115
R49724
R49726
R49727
R49733
R49735
R49732
R49737
R49741
R49738
R49723
R49722
R49792
R49791
R49736
R49774
R49772 R49773
R49771
R49769
R49766 R49768
R49753
R49752
R49751
R49754
R49756 R49758 R49757
R49712
R49711
R49714
R49715
R49716
R49713
R49718
R49717
R49734
D49723
D49791
D49711
C49734
C49732
C49733
C49735
C49736
C49737
C49729
C49723
C49726 C49724 C49727
C49731 C49728
C49716
C49711
C49717
C49742
C49743
BR107 BR108
BR109
BR110
110
ST-DP2
110
ST-DP3
110
ST-DP4
110
ST-DP5
110
ST-DP1
BR49726 BR49727
BR49724
C49722
C49788
C49763
C49757
C49712
BR113
R49745
R49742
R49728
R49729
R49731
R49744
R49743
BR111
D49758
D49761
D49753
D49762
14
58
IC49770
L49774
L49796
L49761
C49768
C49796
C49787
C49791
C49774
C49772
C49771
C49786
C49766
C49767
C49756
C49762
C49761
C49751
R49759
R49788
R49778
R49777
R49776
R49783
R49782
R49781
1
2
3
45678
9
0
51
234
D49793
D49792
MI-
BR101
BR106
20 37
19
1
29306-210.02/4B(02)
0
10
20
30
40
50
60
70
80
90
Y
0 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170 180 190 200 210 220 230 240 250 260 270 280 290 300 310 320 330 340 350 360 370 380 390 400
X
Bestückungsseite, Ansicht von oben
Component Side, Top View
Lötseite, Ansicht von unten
Solder Side, Bottom View
Anschlußplatte Kabel / Connection Board Cable
2 - 11 2 - 12

GRUNDIG Service 2 - 13
Planatron DS2 Platinenabbildungen und Schaltpläne / Layout of PCBs and Circuit Diagrams
BR101 160 20
BR102 200 56
BR103 201 51
BR104 222 56
BR105 221 51
BR106 78 54
BR107 228 63
BR108 378 63
BR109 239 20
BR110 328 20
BR111 120 77
BR112 153 71
BR113 224 25
BR114 210 34
BR115 210 29
BR116 191 31
BR117 191 26
BR49724 121 30
BR49726 115 30
BR49727 108 30
C49711 166 69
C49712 172 75
C49716 167 49
C49717 186 52
C49722 132 41
C49723 127 41
C49724 108 20
C49726 113 20
C49727 118 20
C49728 106 68
C49729 116 68
C49731 111 68
C49732 178 46
C49733 175 46
C49734 265 73
C49735 265 78
C49736 340 65
C49737 325 73
C49742 342 73
C49743 336 73
C49751 299 28
C49756 311 49
C49757 311 54
C49761 294 60
C49762 286 39
C49763 286 44
C49766 286 30
C49767 283 30
C49768 290 30
C49771 260 43
C49772 265 29
C49774 241 35
C49786 266 53
C49787 261 33
C49788 256 33
C49791 276 50
C49796 360 73
D49711 162 74
D49723 128 54
D49753 314 29
D49758 300 64
D49761 292 51
D49762 286 55
D49791 284 53
D49792 139 74
D49793 139 68
IC49711 177 60
IC49720 113 42
IC49750 304 40
IC49770 272 41
L49761 306 60
L49774 250 40
L49796 363 68
R49711 166 65
R49712 175 36
R49713 182 46
R49714 171 46
R49715 166 59
R49716 170 59
R49717 185 62
R49718 188 62
R49722 142 53
R49723 135 49
R49724 105 30
R49726 111 30
R49727 118 30
R49728 106 55
R49729 116 55
R49731 111 55
R49732 175 75
R49733 184 75
R49734 188 40
R49735 185 40
R49736 258 75
R49737 254 76
R49738 246 71
R49741 246 76
R49742 346 73
R49743 333 73
R49744 328 73
R49745 338 61
R49751 310 28
R49752 303 28
R49753 306 28
R49754 317 33
R49756 296 53
R49757 300 53
R49758 304 53
R49759 286 64
R49766 281 20
R49767 275 27
R49768 288 23
R49769 280 39
R49771 278 29
R49772 269 29
R49773 272 29
R49774 265 44
R49776 214 45
R49777 211 41
R49778 210 37
R49781 255 17
R49782 251 19
R49783 247 21
R49788 225 31
R49791 276 54
R49792 279 60
ST 200 2
STDP01 44 89
STDP02 122 89
STDP03 200 89
STDP04 278 89
STDP05 360 88
Koordinaten für die Bauteile der Bestückungsseite
Coordinates of the Components on the Components Side
Pos.-Nr./ Koordinaten/
Pos. No. Coordinates
XY
Pos.-Nr./ Koordinaten/
Pos. No. Coordinates
XY
Pos.-Nr./ Koordinaten/
Pos. No. Coordinates
XY

2 - 14 GRUNDIG Service
Platinenabbildungen und Schaltpläne / Layout of PCBs and Circuit Diagrams Planatron DS2
M1
M1
M1 KH
A
A
V
RS
V
V
RS
VT
A
K
470p
C49737
K
470p
C49736
270
R49742
270
R49743
47
R49745
47
R49744
VT
ST
470
R49741
470
R49738
470
R49737
470
R49736
K
1n
C49734
K
1n
C49735
A
ST
ST
CL
I2S
ST
ST
ST
10
R49757
V
ST
ST
ST
+
47u/16V
C49722
K
100p
C49728
ST
ST
V
VGA1
V
H
VGA1
DATA2
I2S
47
R49729
n.V.
7
8
9
10
1
2
3
4
5
6
ST-DP5
7
8
9
10
1
2
3
4
5
6
ST-DP4
7
8
9
10
1
2
3
4
5
6
ST-DP3
VCC A6
Y6
A5
Y5
A4
Y4
GND
Y3
A3
Y2
A2
Y1
A1
74HCU04T
1
2
3
4
5
6
7
8
9
10
11
12
13
14
IC49750
BR49724
CHROMA
S-VHS
U
VGA
VIDEO
S-VHS
KH
GND
KH
R
B
G
U
DATA
R
H
DISPLAY
V
DISPLAY
G
VGA-IN
R
VGA
G
VGA
B
VGA
VIDEO
+R
+M
I2S
WS
I2S
CL
I2S
DATA2
n.V.
V
ws
I2S
RS
KH
L
CHROMA
FBAS
TXT
n.V.
K
100p
C49733
BR49727
ST
ST
ST
ST
ST
V
ST
ST
ST
ST
ST
ST
ST
K
100p
C49731
K
33p
C49727
K
33p
C49724
ST
ST
ST
ST
ST
ST
ST
ST
ST
V
CAV
R
+
100u/10V
C49757
CAV
L
TXD-T
RXD-T
V
VCC A6
Y6
A5
Y5
A4
Y4
GND
Y3
A3
Y2
A2
Y1
A1
74HCU04T
1
2
3
4
5
6
7
8
9
10
11
12
13
14
IC49720
K
100p
C49732
1k
R49733
470
R49723
1k
R49727
1k
R49726
U
RESET
SYSTE
B
VGA-IN
SDA2
R
VGA-IN
U
WAKE
UP
SCL3
VGA
L
VGA
R
ST
K
33p
C49726
BR49726
1k
R49724
1k
R49732
ST
V
ST
K
0,1u
C49723
K
100p
C49729
AA A
I2S
DATA_R
10
R49734
10
R49735
ZPD5,1V
D49723
A
47
R49728 47
R49731
7
8
9
10
1
2
3
4
5
6
ST-DP1
7
8
9
10
1
2
3
4
5
6
ST-DP2
A
10
R49758
A
10
R49756
100k
R49754
100k
R49751
2,2k
R49752
4,3k
R49753 BAT42
D49762
1N4148
D49753
F
1n/5%
C49751
F
0,33u
C49761
10u
L49761
BAT42
D49761
F
0,1u
C49762
+
470u/10V
C49763
F
0,1u
C49756
1N4148
D49758
F
0,1u
C49767
F
0,1u
C49766
-
+
LM358
IC49770
-
+
LM358
IC49770
1k
R49767
1k
R49768
470
R49766
100k
R49769
F
0,22u
C49786
82k
R49771
18k
R49773
F
1n/5%
C49771
XX
R49772
F
XX
C49772
470k
R49774
8104-982-014
L49774
1N4001
D49792
F
0,1u
C49774
7,5k
R49777
7,5k
R49776
7,5k
R49778
7,5k
R49781
7,5k
R49782
7,5k
R49783
F
0,22u
C49791
470k
R49791
330
R49792
F
0,1u
C49787
ZPD5,1 D49791 +
22u/25V
C49788
6,8
R49788
REF
V
V V
V V
V
V
6,8
R49759
n.V.
V
V
V
V V
V V
n.V.
F
0,1u
C49768
n.V.
V
0,47u
L49796
F
2,7n
C49796
VVT
470
R49722
REF
1N4001
D49793
VCC
A6
Y6
A5
Y5
A4
Y4 GND Y3
A3
Y2
A2
Y1
A1
74HCU04T
1
2
3
4
5
6
7
8
9
10
11
12
13
14
IC49711
K
2,2n
C49743
K
2,2n
C49742
K
10p
C49717
K
0,1u
C49711
1k
R49717
1,5k
R49718
+
47u/16V
C49712
V
ZPD5,1V
D49711
VVV
47
R49713
K
10p
C49716 1k
R49716
1,5k
R49715
V
47
R49714
470
R49712
470
R49711
V
V
V
ST
ST
B
B
R
R
G
G
TXT
TXT
VIDEO
VIDEO
CHROMA
CHROMA
V
+R
+R
+R
-5V
-5V
+M
+M
+M
+M
+M
260899
ANSCHLUSSPLATTE KABEL 29305 307 0200
7
6
5
3
2
1
4
8
4
8
33
6
24
5
26
CI RACCORDEMENT TELE
PLACA DE CONECCION PARA CABLE
PIASTRA DI COLLEGAMENTO PER TV CAVO
CONNECTION BOARD CABLE
21
20
2
1
34
32
25
27
23
22
16
35
17
36
18
37
19
13
31
15
9
28
10
29
11
30
12
4
3
7
14
8
Anschlußplatte Kabel / Connection Board Cable
Spannungstabelle
Voltage table
+1 12V
+2 5V
+3 3,3V
+4 5V
+5 5V
+H 5V
+M 20V
+K 12,5V
+F 5V
+G 16,5V
–G -16,5V
+Q 8,5V
+S 5V
+R 6,5V
+ECO 6,5V

GRUNDIG Service 3 - 1
Planatron DS2 Ersatzteillisten / Spare Parts Lists
Btx *32700# ÄNDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
Ersatzteilliste
Spare Parts List
DOCKING STATION DS2
TV
MATERIAL-NR. / PART NO.: 92179 701 5200
BESTELL-NR. / ORDER NO.: G.AE 39-52
ǵ
8 / 99
POS. NR. ABB. MATERIAL-NR. ANZ. BEZEICHNUNG DESCRIPTION
POS. NO. FIG. PART NUMBER QTY. d©
92179 701 5200 PLANATRON DS2 PLANATRON DS2
KEIN E-TEIL NO SPARE PART
0250.000 29633 054 0100 NETZTASTE NETZTASTE
0252.000 29303 119 1201 2 D-SUB BUCHSENLEISTE 37-POL. D-SUB SOCKET 37 P
0252.000 29303 119 1800 2 D-SUB BUCHSENLEISTE 15-POL. D-SUB SOCKET STRIP 15 P
0253.000 29303 168 0600 CINCH-BUCHSE 2-FACH GE/WS CINCH SOCKET 2 FOLD YE/WH
0253.000 29303 168 4700 3 CINCH-BUCHSE 2-FACH WS/RT CINCH SOCKET 2 FOLD WH/RD
0257.000 29501 713 0103 KLAPPE DRUCK KPL FLAP PRINT CPL
0267.000 29638 216 0101 4 FUSS FOOT
0282.000 29703 358 0400 SCHIEBESCHALTER SLIDE SWITCH
0320.000 29110 001 0101 TYPENAUFKLEBER TYPE LABEL SELF-ADH.
0350.000 29638 264 0101 LUEFTER FAN
0360.000 29501 707 0101 2 GRIFFSTUECK HANDLE PART
0400.000 29305 304 0200 BUCHSENPLATTE DOCKING STATION SOCKET BOARD DOCKING STATION
0410.000 29303 522 0600 S-VHS-BUCHSE O.SCHALTER S-VHS-SOCKET
0420.000 29303 168 0503 CINCH-BUCHSE 3-FACH GE/WS CINCH SOCKET 3 FOLD GE/WS
0430.000 29303 390 4200 KOPFHOERERBUCHSE 3,5 O.SCHALTER HEADPHONE SOCKET 3,5 W/O SWITCH
2200.000 S81320 100 6200 EINBAU-KALTGERAETESTECKER BUILT-IN APPLIANCE PLUG
21797 941 0100 BEDIENUNGSANLEITUNG OPERATING INSTRUCTIONS
72010 024 5000 SERVICE MANUAL DOCKING STATION SERVICE MANUAL DOCKING STATION
29305 364 0100 CHASSIS DOCKING STATION CHASSIS DOCKING STATION
KEIN E-TEIL NO SAPRE PART
2950.000 29305 315 0100 ADAPTERBOX ADAPTER BOX
WW. = WAHLWEISE WW. = OPTIONAL
C 41723 86682 030 2300 ABBLOCK-C 0,1 UF -GR 25V
C 41756 86682 030 2300 ABBLOCK-C 0,1 UF -GR 25V
C 41762 86682 030 2300 ABBLOCK-C 0,1 UF -GR 25V
C 41766 86682 030 2300 ABBLOCK-C 0,1 UF -GR 25V
C 41768 86682 030 2300 ABBLOCK-C 0,1 UF -GR 25V
C 41774 86682 030 2300 ABBLOCK-C 0,1 UF -GR 25V
C 41787 86682 030 2300 ABBLOCK-C 0,1 UF -GR 25V
BLOCKING CAPACITOR
CD 41511 83250 041 4800 SMD DIODE LS 4148
CL 41796 81049 823 3000 SMD DAEMPF-PERLE 0805
CT 32615 83010 038 5800 SMD TRANS BC858B
CT 41505 83010 038 5800 SMD TRANS BC858B
CT 41632 83010 058 1700 SMD-TRANS.BC 817-25
CT 41633 83010 058 1700 SMD-TRANS.BC 817-25
CT 41634 83010 058 1700 SMD-TRANS.BC 817-25
CT 41665 83010 038 5800 SMD TRANS BC858B
CT 41670 83010 038 5800 SMD TRANS BC858B
CT 41675 83010 038 5800 SMD TRANS BC858B
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION POS. NR. MATERIAL-NR. BEZEICHNUNG POS. NO. PART NUMBER DESCRIPTION
CT 41780 83010 038 5800 SMD TRANS BC858B
CT 41785 83010 038 5800 SMD TRANS BC858B
CT 41790 83010 038 5800 SMD TRANS BC858B
D 01806 83099 446 0100 LE DIODE TLHR 4601 TFK
D 41723 83097 200 5200 Z DIODE 5,1 C 0,5W
D 41753 83092 150 4500 DIODE 1N4148
D 41758 83092 150 4500 DIODE 1N4148
D 41761 83091 985 4200 DIODE BAT42/43
D 41762 83091 985 4200 DIODE BAT42/43
IC 41500 83052 043 1700 IC LM317T NSC
IC 41600 83052 028 0800 IC UA78M08UC FAI/
IC 41650 83051 474 1900 IC DPL3519A-PO-A2
IC 41660 83054 334 0800 IC MSP3400C-PO-C8
IC 41720 83051 830 0400 IC SN74HCU04N TEXAS
IC 41750 83051 830 0400 IC SN74HCU04N TEXAS
WW. 83051 820 0400 IC PC74HCT04N PHI
IC 41770 83052 935 5800 IC RC4558NB RAY
L 41642 81049 820 1400 DAEMPF-PERLE 433003038102
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
Btx *32700# ÄNDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
( ! )
!
Es gelten die Vorschriften und Sicherheitshinweise
gemäß dem Service Manual "Sicherheit", Mat.-Num-
mer 72010 800 0000, sowie zusätzlich die eventuell
abweichenden, landesspezifischen Vorschriften!
The regulations and safety instructions shall be valid
as provided by the "Safety" Service Manual, part
number 72010 800 0000, as well as the respective
national deviations.
L 41644 81049 820 1400 DAEMPF-PERLE 433003038102
L 41742 81049 820 1400 DAEMPF-PERLE 433003038102
L 41744 81049 820 1400 DAEMPF-PERLE 433003038102
DAMPING BEAD
L 41761 81405 260 3400 DR 0309 10UH 5%
L 41774 81049 820 1400 DAEMPF-PERLE 433003038102
DAMPING BEAD
L 41796 81405 260 4600 DR AX 0309-GA 0,47UH 10%
Q 41662 83824 391 8600 QUARZ #439-9 18,432MHZ
Q 41762 83824 391 8600 QUARZ #439-9 18,432MHZ
R 41601 S87004 290 2100 KSW NB 0207 6,8 OHM 5%
R 41602 S87004 290 2100 KSW NB 0207 6,8 OHM 5%
R 41753 87000 112 8800 KSW 0204 4,3 KOHM 5%
R 41759 S87011 190 2100 KSW SI B 6,8 OHM 5%
R 41776 87650 974 9400 MSW 0204 7,5 KOHM 1%
R 41777 87650 974 9400 MSW 0204 7,5 KOHM 1%
R 41778 87650 974 9400 MSW 0204 7,5 KOHM 1%
R 41781 87650 974 9400 MSW 0204 7,5 KOHM 1%
R 41782 87650 974 9400 MSW 0204 7,5 KOHM 1%
R 41783 87650 974 9400 MSW 0204 7,5 KOHM 1%
R 41788 S87011 190 2100 KSW SI B 6,8 OHM 5%

Kundendienst Europa
Kundendienst Deutschland
GRUNDIG ESPAÑA S.A.
Solsonés, 2 planta baja B3
Edificio Muntadas (Mas Blau)
E-08820 El Prat De Llobregat (Barcelona)
00 34-93-4 79 92 00
GRUNDIG BELUX N.V.
Deltapark, Weihoek 3, Unit 3G
B-1930 Zaventem
00 32-2-7 16 04 00
GRUNDIG UK LTD.
Elstree Way, Borehamwood, Herts, WD6 1RX
GB Großbritannien/Great Britain
00 44-1 81-3 24 94 00
GRUNDIG IRELAND LTD.
2 Waverley Office Park, Old Naas Road
EIR Dublin 12
0 03 53-1-4 50 97 17
GRUNDIG FRANCE S.A.
5 Boulevard Marcel Pourtout
F-92563 Rueil Malmaison Cedex
00 33-1-41 39 26 26
GRUNDIG SCHWEIZ AG
Steinacker Str. 28
CH-8302 Kloten
00 41-1-8 15 81 11
GRUNDIG PORTUGUESA
Comércio de Artigos Electrónicos, Lda.
Rua Bento de Jesus Caraça 17
P-1495 1495 Cruz Quebrada, Lisboa
0 03 51-1-4 15 67 00
GRUNDIG NEDERLAND B. V.
Gebouw Amstelveste
Joan Muyskenweg 22
NL-1096 CJ Amsterdam
00 31-20-5 68 15 68
GRUNDIG ITALIANA S.P.A.
Via G.B. Trener, 8
I-38100 Trento
00 39-04 61-89 31 11
GRUNDIG OY
Luoteisrinne 5
FIN-02271
Espoo
0 03 58-98 04 39 10
GRUNDIG AUSTRIA Ges.m.b.H.
Breitenfurter Straße 43-45
A-1120 Wien
00 43-1-81 11 76 03
GRUNDIG POLSKA SP.Z.O.O.
Ul. Czéstochowska 140
PL-62800 Kalisz
00 48-62-7 66 77 70
GRUNDIG NORGE A. S.
Glynitveien 25, Postboks 234
N-1402 Ski
00 47-64 87 82 00
GRUNDIG DANMARK A/S
Lejrvej 19
DK-3500 Værløse
00 45-44 48 68 22
GRUNDIG SVENSKA AB
Albygatan 109 d, Box 4050
S-17104 Solna
00 46-8-6 29 85 30
Technical Service
Unit 35. Woodside Park, Wood Street
Rugby, Warwickshire, CV21 2NP
Großbritannien/Great Britain
00 44-1 78-8 57 00 88
Dudenstr. 45-53
68167 Mannheim
Tel. [phone]
Fax [phone]
Kolumbusstr. 14
22113 Hamburg
Tel. [phone]
Fax [phone]
Wittestr. 30e
13509 Berlin
Tel. [phone]
Fax [phone]
Beuthener Str. 65
90471 Nürnberg
Tel. [phone]
Fax [phone]
Horbeller Str. 19
50858 Köln
Tel. [phone]
Fax [phone]
KUNDENDIENST MITTE
KUNDENDIENST WEST
KUNDENDIENST NORD
KUNDENDIENST OST
KUNDENDIENST SÜD
