Features
Providing Max. 16 channels of independent input.
1-16 selectable. Input signals are insulated from
the loop.
Providing two channels of independent dry contact
output.
3-18 consecutive addresses, changing with
selected channel quantity.
Power supply monitored.
Cable monitored for open circuit and short circuit.
Description
With microprocessor, DI-9309 Addressable
Multi-Channel Interface can communicate with fire
alarm control panel (FACP), monitor power supply,
judge the logic state of input signal, control output and
state indicators.
Each output channel occupies an individual address
and receives start command from FACP, energizes the
related relay, gives dry contact output and lights the
related action indicator. Each input is corresponded to
an address to receive the state signal from the
equipment and transmit it to FACP. The quantity of
channels can be set by jumpers.
Cabling
Z1, Z2: To the loop of FACP, polarity-insensitive.
D1, D2: 24VDC power, polarity-insensitive.
I(n)G: Channel n volt-free normally open input.
NC1(NC2), COM1(COM2), NO1(NO2): Dry contact
outputs of Channel I (Channel II).
Recommended Wiring
1.5mm2 or above fire cable for Z1, Z2, D1, and D2.
1.0mm2or above fire cable for others. Subject to local
codes.
Installation
Fig. 1 shows dimensions and hole distances.
XS3
1234
100mm
200mm
90mm
190mm
Fig. 1
Application
The DI-9309 interface is designed to connect with
active equipment in field such as water flow switch,
pressure switch, position switch, signal valve and
equipment able to transmit back normally open signals.
It can also connect with the equipment controlled by
FACP such as fire door, pump, smoke exhaust fan,
smoke vent, air vent, fire damper and etc.
1. Setting
DI-9309 interface can be addressed in field with power
off by using P-9910B programmer connected to Z1 and
Z2. Please refer to P-9910B Hand Held Programmer
Installation and Operation Manual for details.
Input Channel Setting: Set Channel 1-16 consecutive
(always beginning from Channel 1) input through
jumpers inserting to XS3, as shown in Table 1.
Table 1
INPUT CHANNEL SETTING
Pin
Channel QTY. 4 3 2 1
1 OFF OFF OFF OFF
2 OFF OFF OFF ON
3 OFF OFF ON OFF
4 OFF OFF ON ON
5 OFF ON OFF OFF
6 OFF ON OFF ON
7 OFF ON ON OFF
8 OFF ON ON ON
9 ON OFF OFF OFF
10 ON OFF OFF ON
11 ON OFF ON OFF
12 ON OFF ON ON
13 ON ON OFF OFF
14 ON ON OFF ON
15 ON ON ON OFF
16 ON ON ON ON
Code Range: Occupying 3-18 addresses, the output
address of Channel 1 can be set within 1～225. The
output address of Channel 2 is automatically increased
1 to Channel 1. The input address of Channel n is
automatically increased n and 1 to Channel 1. For
instance, the output address of Channel 1 is 15, and
other addresses are shown in Table 2.
Table 2
Input and Output Address
Channel 1 Output 15
Channel 2 Output 16
Channel 1 Input 17
Channel 2 Input 18
… …
Channel n Input 15+n+1
The Intelligent Solution
DI-9309
Addressable Multi-Channel Interface
HTTP://GSTRU.RUE-MAIL: [email protected]

HTTP://WWW.HOMBI.RU
30305126 Issue 1.01
2. Connection
1) Fig.2 shows the system connection with volt-free
normally open input.
470ΩVolt free
contact
I(n) G
4.7kΩ
INPUT(n)
Fig. 2
2) Fig.3 shows the system connection with dry
contact output.
GND
Controlled Equipment
COM1(2)
D1 D2
NO1(2)
DI-9309
NC1(2)
Control Input
+24V
Z1
Z2
Z2
Z1
Fig. 3
Note: This interface cannot be used to control
gas extinguishing equipment.
Specification
Operating
Voltage Loop voltage: 24V (16V~28V). Power Supply Voltage: 24VDC
(20VDC~28VDC).
Standby Current Loop ≤1.5mA Power ≤50mA
Action Current Loop ≤3mA Power ≤100mA
Output Capacity Output contact capacity: 220V/2A.
Output Type Dry contact output.
Programming
Method Electronically programming.
Code Range Occupying 3-18 addresses, the
output address of Channel 1 can
be set within 1～225. The output
address of Channel 2 is
automatically increased 1 to
Channel 1. The input address of
Channel n is automatically
increased n and 1 to Channel 1.
Action Indicators Red.
Separate polling indicator HL0.
Individual state LED(n) for each
channel input. Flashes in fault
state. Illuminates in action state.
Quiet in normal supervisory.
HL1 and HL2 for each channel
output. Illuminates when
activated.
Ambient
Temperature -10℃～+50℃
Relative
Humidity ≤95%, non condensing
Mounting Hole
Distance 190mm×90mm
Dimensions
(L×W×H) 200mm×100mm×20mm
Weight About 240g
Accessories and Tools
Model Name Remark
P-9910B Hand Held
Programmer Order separately
