Guangzhou Yingfeng PY5403 User manual

Guangzhou Yingfeng Lighting Equipment Co.,Ltd www.yf-light.com
PY5403 LED PAR
User Manual

Guangzhou Yingfeng Lighting Equipment Co.,Ltd www.yf-light.com
Catalogue
1. Open-package inspection………………………………………………….........…02
2. Product introduction………………………………………………........................02
3. Product parameter……………………………………………………………........02
A. The fittings…………………………………………………………..................02
B. Product features……………………………………………………..................02
4. Channel mode……………………………………………………..............………03
5. Operation introduction……………………………………………….....................05
(1). Address setting………………………………………………..………............05
(2). KEY dimming…………………………………………………..…….........…05
(3). Running-sound control mode…………………………………………............05
(4). Invoking the built-in program …………………………………..…………....06
(5). Channel mode selecting…………………………………………....................06
(6) Id address setting………………………………………………....................…06
6. Common problems and solutions……………………………………...........….....07
7. Points for attention……………………………………...........................................08

Guangzhou Yingfeng Lighting Equipment Co.,Ltd www.yf-light.com
1. Open-package inspection
PY5403 LED par: 4 pcs/carton
User manual: 1pcs
Power transfer cable：1 pcs for each 8 LED par
Signal transfer cable：1 pcs for each 8 LED par
2. Product introduction
This LED par use 54pc*3W high power LED for the light source. Go with elegant
cast aluminum shell, excellent heat dissipation and wide voltage switching power
supply. Independent research and development driven template, made the high
efficiency and long life, low fever,energy saving and environmental protection. and
with stable performance, is welcomed by home and abroad customers
3. Product parameters
A. The fittings
LED：R12 G15 B15 W12
Voltage：AC100-240V
Frequency：50-60HZ
Rated Power：160W
Size：22×29.5×31.5cm
Net weight：3.2kg
DMX channels：5/6/8/11 channel
B. Product features
(1) The scientific combination of LED , matching the advanced optical lens make the
excellent color mixing effects
(2) AC100-240V wide input voltage range without problems due to unstable voltage.
(3) Simple and clear display interface make the use simple and practical
(4) High sensitive sound control can capture up to 10 sound signals per second
(5) 0-255 linear dimming,make the color more delicate and colorful.
(6) Automatic recognition of master-slave and DMX control.

Guangzhou Yingfeng Lighting Equipment Co.,Ltd www.yf-light.com
4. Channel modes
Aod 1 …………11channel mode
Aod 2 …………8 channel mode
Aod 3 …………6 channel mode
Aod 4 …………5 channel mode
Aod1
(11CH）
No. Function value
1 Master dimming
2 R red light 001-255 from dark to bright
3 G green light 001-255 from dark to bright
4 B blue light 001-255 from dark to bright
5 W white light 001-255 from dark to bright
6 Automatic color
7 Strobe 001-255 from slow to fast
8 Macro 001-010 invalid
011-180 color change gradient
181-195 color jump
196-225 color pulse
226-255 sound control
9 Color gradient,jump,Pulse 001-255 from slow to fast
10 Dimming delay
11 Id extract 001-009 Id01
010-019 Id02
020-029 Id03
030-039 Id04

Guangzhou Yingfeng Lighting Equipment Co.,Ltd www.yf-light.com
Aod2
(8CH)
1 Master dimming 001-255 from dark to bright
2 R red light 001-255 from dark to bright
3 G green light 001-255 from dark to bright
4 B blue light 001-255 from dark to bright
5 W white light 001-255 from dark to bright
6 Strobe 001-255 from slow to fast
7
Macro
001-010 Invalid
011-180 color change gradient
181-195 color jump
196-225 color pulse
226-255 sound control
8 Macro speed
Aod3
(6CH)
1 Master dimming 001-255 from dark to bright
2 R red light 001-255 from dark to bright
3 G green light 001-255 from dark to bright
4 B blue light 001-255 from dark to bright
5 W white light 001-255 from dark to bright
6 strobe 001-255 from slow to fast

Guangzhou Yingfeng Lighting Equipment Co.,Ltd www.yf-light.com
Aod4
(5CH)
1 R red light 001-255 from dark to bright
2 G green light 001-255 from dark to bright
3 B blue light 001-255 from dark to bright
4 W white light 001-255 from dark to bright
5 Strobe 001-255 from slow to fast
5. Operation introduction
(1) Address setting
Press “MENU” key display “A001”, press “ENTER” display “001” then press
“UP” or “DOWN” to change the value, at last press “ENTER” to confirm.
(2) Key dimming
Press the “MENU” key make the display return to A001, press “DOWN” key will
display “∩A∩”, then press “ENTER” will display “CH01”,( CH01 indicated the 01
DMX channel of this LED par light), then press “UP” or “DOWN” to select the other
channel such as CH02.
After select the channel, press “ENTER” will display “H000”(H000 indicated the
current selected channel value is 0), then press “UP” or “Down”key to change the
channel and press “ENTER”key to confirm.
The function of each channel please see the current channel mode and the channel
table
(3) Running - sound control mode
Press “MENU” key ,make the display return to A001, press “DOWN” key to find
the “SOUN”, then press “ENTER” key to confirm

Guangzhou Yingfeng Lighting Equipment Co.,Ltd www.yf-light.com
(4) Inworking the built-in program
Press “MENU” make the display return to A001; 「ES 「, then press “ENTER”
display P「01 (01 indicated the first built-in program) now the LED par light start
running the 01 built in program, can press “UP” or “DOWN” to select P
「01、
P
「02…
P「16, after selected the program you needed, press “ENTER” will display “SP01”,
can press “UP” or “DOWN” to adjust the running speed of the program, at last press
“ENTER” to confirm.
(5) Channel mode selecting
Press “MENU” make the display return to A001, press “DOWN”to find dΠP「,
then press “ENTER” display ∏od1 (∏od1 indicated the first channel mode), press
“UP” or “ DOWN” key can select the channel mode of ∏1、 2、 3、 4 and so on, at
last press “ENTER” to confirm.
(6) Id address setting
This LED par light can subdivided the same DMX address into 26 ID, so save
much channel for the console.Which means users can use a console controls 26 LED
par lights with the same DMX address, and also can control any one alone.
Press “MENU” make the display return to “A001”, press “UP” display Id, Press
“ENTER” display “Id01”, press “UP” or “DOWN” key can select Id01、Id02…Id26

Guangzhou Yingfeng Lighting Equipment Co.,Ltd www.yf-light.com
6. Common problems and solutions
Although the products made from our factory have bean rigorous tested before send
out, but because of the transport environment is not expected , the error installation
and commissioning, the passage of time, individual electronic components aging
factors,will cause some problems. If your LED par light have some problems that
affect your normal use please refer to the following solutions or contact the dealer
directly.
LED par light problem and solution table
Problems Reasons Solutions
1.The light don’t light up, no
menu display, the fan can’t
running
1. Don’t have power
2.The power input circuit didn’t
connected
Connecting the power
correctly
2.One of the LED par didn’t
controlled by the signal
1.The address is incorrect, not in
the DMX mode
2.The Id code is incorrect, the
signal connecting is incorrect
Reset the parameter and
reconnecting the signal
cable
3.One of the LED par light is
running inconsistent to the
others
1.The LED par channel mode is
not the same Readjust
4.One color of one LED par
light didn’t light up
The LED bead is virtual welding
or burned out
Well welding or replaced
the LED bead

Guangzhou Yingfeng Lighting Equipment Co.,Ltd www.yf-light.com
7. Points for attention
Please read this user manual before using the LED par light
Installation should be carried out by professionals
Don’t use the dilute solvent such as alcohol to clean the surface of the lights
The lights should not use in the ambient temperature which more than 40 degrees,
keep away from the fire and flammable things,the lights should keep dry.
Hanging installation must be equipped with hook and safety rope which can
carry the 10 times weight of the LED par light itself.
