Guangzhou Yinhe Stage Lighting Equipment SL-810 User manual

LED 4 EYES BEAM LIGHT
Model：SL-810
User Manual
Guangzhou Yinhe Stage Lighting Equipment Factory

LED USER MANUAL
Model：SL-810
Please read this manual carefully before operating the LED light.
●Notes
1. This is a LED Product.
2. Do not disassemble or repair the system by yourself unless you are qualified in the
relevant field of electronics. When there is a problem, please enquire or contact a
qualified electrician, or your local dealer.
3. Installation should be done by professional technician.
4. Do not exposure the system to wet and dust-laden environment.
5. Do not touch the system by wet hand and pull the power cable forcefully.
6. Do not turn on or off the system frequently, avoid turning on it for long time.
7. Prevent strong vibration or G-shock to the system.
8. Prevent other harmful objects entering the system.
9. Keep at least 1 meter between the system and the objects in the lighting.
10.Connect the power cable only when the system has been installed.
11. Before connecting or disconnecting the power, adjust the luminance of the light
diode as dim as possible to avoid any damage to it.
12. Before powering on the system, be sure the power cable is connected into the
power socket well.
13. Turn off the system for 10 minutes after running constantly for four hours; ensure
that the system is able to cool down in a suitable environment.
14. When to be transported, use the original package to avoid damage.
15. This symbol indicate separate collection for electrical and electronic
equipment.
SKILL SPECIFICA TIONS
Voltage:
AC110V-240V 50/60Hz
Electric current：
5A
Power:
130W
Lamp:
Super bright ,4 PCS*25W LED white lamp
Working life:
50000H
IP:
IP23
Beam angle:
5°-40°
Strobe:
1-25hz ,2 kind of strobe effects
Dimmer:
0 ~ 100% smooth dimming
Color wheel:
A plate of red,green,blue,brigh colors,flowing water effect.
Pan:
540°
Tilt:
250°
Control mode:
DMX512/Auto run/sound control/master-slave
DMX channels:
11/17

DMX Channel Control
11 CH
17 CH
Channel
DMX
address
Description
1
1
Pan
0-255
0-270°
2
Pan fine
0-255
2
3
Tilt
0-255
0-450°
4
Tilt fine
0-255
3
5
Pan/tilt speed
0-255
fast - slow
4
6
Color wheel
0-9
white
10-19
red
20-29
green
30-39
blue
40-127
color wheel Position linear positioning
128-190
Color wheel motor（from fast to slow）
190-255
Color wheel motor（flow slow to fast）
5
7
Lens wheel
0-127
Lens wheel positioning
128-190
Lens wheel（turn right from slow to
fast）
191-255
Lens wheel(turn left from slow to fast）
6
8
Lens shake
0-10
None
11-255
When 5/7CH, value is less than 128,the
speed of lens shake from slow to fast.
7
9
Dimming
0-255
Dimming，Linear dimming from dark to
bright
8
10
strobe
0-255
Strobe （from slow to fast）
11
LED1
Dimming
0-255
Linear dimming from dark to bright
12
LED2
Dimming
0-255
Linear dimming from dark to bright
13
LED3
Dimming
0-255
Linear dimming from dark to bright
Function:
Effect of strong light beam , beam angle can be adjusted ,bean
macro effect show ,lights single control ,and their effect ,the
wind intelligent control ,automatic temperature detection of
lamps and lanterns.

14
LED4
Dimming
0-255
Linear dimming from dark to bright
9
15
function
0-45
None
46-75
Running effect 2（motor is controlled by
DMX）
76-105
Running effect 2（motor is controlled by
DMX）
106-135
Sound control（motor is controlled by
DMX））
136-165
Running effect 1（Built in program）
166-195
Running effect 2（Built in program）
196-225
Running effect 3（Built in program）
226-255
Sound control（Built in program）
10
16
Function
speed
0-255
From fast to slow
11
17
Rest
0-249
None
250-255
Rest in 9 seconds
Note: master-slave mode, need to disconnect the control signal, otherwise can not
properly receive the host signal.
 The display function:
The main menu:
Press the button to enter the settings by pressing the "confirm" button.
Sub menu:
Menu with address setting, channel setting, automatic operation, system testing, advanced
settings, system version and other modules
Main menu
Sub menu
Sub menu
Sub menu
Address
Set up
DMX-17 / DMX-11
D:001
DMX512 address
Aisle
Set up
DMX512
Ch17 / Ch11
DMX512channel
Function
Mood
Function
D:001
Auto run 1
Function
D:002
Auto run2

Function
D:003
Sound control
Light
Test
X Test
Test
X Test
D:000
Test X motor
Y Test
Test
Y Test
D:000
Test Y motor
F Test
Test
F Test
D:000
Test rotary electric
machine
C Test
Test
C Test
D:000
Test color motor
W Test
Test
W Test
D:000
Test lamp
Advanced
Set up
X Phase
Set up
X Phase
Positive/Anti
X motor inverting
Y Phase
Set up
Y Phase
Positive/Anti
Y motor inverting
Counting
Set up
Counting
Open/Turn off
Counter disk
X Tune
Set up
X Tune
D:128
X motor calibration
Y Tune
Set up
Y Tune
D:128
Y motor calibration
F Tune
Set up
F Tune
D:128
Rotary motor
calibration
C Tune
Set up
C Tune
D:128
Color motor
calibration
Current
Set up
Current
D:235
Lamp current
Light
Reset
Reset
Yes?
We are
Reset...
Motor reset
Recovery
Restore
Restore
Yes?
We are
Restore.
Factory Reset
Light
Release
Release
XF--10.0
Edition
