Guldmann 14600 User manual

1
© Guldmann GB/US-03/2021 • # 944127_101
GB/US ........Bath chair and bath stretcher
User manual – vers. 101.00

2
© Guldmann GB/US-03/2021 • # 944127_101 © Guldmann GB/US-03/2021 • # 944127_101
Bath Chair and Bath Stretcher
Item nos.
14600 - Mobile Bath Chair, incl. oval hook
14610 - Mobile Bath Stretcher, incl. oval hook
1.00 .........Purpose and use ..............................................3
1.01 .........Manufacturer ..................................................3
1.02 .........Intended purpose...............................................3
1.03 .........Area of use ...................................................3
1.04 .........Conditions of use ...............................................3
1.05 .........Important/warnings .............................................4
2.00 .........Unpacking bath chair ..........................................5
2.01 .........Functional description of the bath chair..............................6
2.02 .........Marking for bath chair ...........................................7
3.00 .........Unpacking bath stretcher .......................................7
3.01 ........Functional description of the bath stretcher. . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3.02 .........Marking for bath stretcher ........................................9
4.00 .........Maintenance ..................................................9
4.01 ........Cleaning and maintenance .......................................9
4.02 .........Replacement of components ......................................9
4.03 .........Service life ....................................................9
4.04 .........Storage and use environment ....................................10
5.00 .........Technical specications .......................................10
6.00 .........EU declaration of conformity ...................................10
7.00 .........Environmental policy statement - V. Guldmann A/S ................10
8.00 .........Warranty and service conditions ................................11
A. ..........Warranty.....................................................11
B. ..........Service or Repair ..............................................12

3
© Guldmann GB/US-03/2021 • # 944127_101 © Guldmann GB/US-03/2021 • # 944127_101
1.00 Purpose and use
1.01 Manufacturer
V. Guldmann A/S
Graham Bells Vej 21-23A
DK-8200 Aarhus N
Tlf. + 45 8741 3100
www.guldmann.com
1.02 Intended purpose
The Bath chair and bath stretcher is intended for lifting and transferring a per-
son with disabilities in a seated or horizontal position.
1.03 Area of use
The Bath chair and Bath stretcher is suited for use in institutions, rehabilita-
tion centers and in swimming pools.
1.04 Conditions of use
The Bath chair and Bath stretcher is designed for use with ceiling hoist sys-
tems and it is ideal in connection to the bath chair and bath stretcher allows
for the lifting routines to be carried out in an ergonomically environment thus
avoiding heavy lifting.
The Guldmann bath chair and bath stretcher is suited for lifting one person
in to and out of swimming pools and similar, in a seated position (bath chair)
or in a horizontal position (bath stretcher) and to facilitate the lifting situations,
ensuring maximum safety when bathing.
The detachable and turnable armrests on the bath chair ensures a safe and
easy transfer to another seat.
The integrated oval hook on the bath chair and bath stretcher makes the lift-
ing out of and into the bath easy. Lifting only requires the snap hook of the
ceiling hoist to be connected with the oval hook.

4
© Guldmann GB/US-03/2021 • # 944127_101 © Guldmann GB/US-03/2021 • # 944127_101
1.05 Important/warnings
Always exercise caution when using the bath chair or bath stretcher. This
means that helpers should always make sure that they, the user and any
other persons are safe in order to avoid injuries or accidents.
The bath chair and bath stretcher are designed for use in bathing environ-
ments and swimming pools with the following maximum values of:
Water quality:
pH 7,6
Free chlorine, mg/l 2,0
Bound chlorine, mg/l 0,5
Air humidity:
The relative air humidity in the room should be approx. 70% at an outdoor
temperature of approx. 20°C and approx. 50% at an outdoor temperature of
approx. 0°C.
• Please read the user manual before starting the use of the bath chair or bath
stretcher.
• The bath chair and bath stretcher must only be used by trained personnel.
• The helper must pay attention to the well-being of the user when using the
bath chair or bath stretcher.
• Do not exceed the recommended safe working load of the bath chair or bath
stretcher.
• Products marked with the lowest lifting capacity determines the maximum
load of the entire system.
• If a defect appears during use of the bath chair or bath stretcher, stop using it
and contact the Guldmann Service Team for repair.
• The user on the bath stretcher may not turn or move in the lengthwise direc-
tion when lying in the lifter.
• To avoid unintentional movements of the user, the helper must position the
hoist centrally over the user before lifting is started.
• Do not modify this equipment without the authorization of the manufacturer
• Any serious incident that occurred in relation to this device should be reported
to the manufacturer and the local competent authority.
The bath chair and bath stretcher must be cleaned and maintained according
to the instructions mentioned in this manual, see section 4.01.

5
© Guldmann GB/US-03/2021 • # 944127_101 © Guldmann GB/US-03/2021 • # 944127_101
2.00 Unpacking bath chair
Visual inspection of the bath chair
If the bath chair is thought to be damaged upon receipt, it must not be used
before it is checked and approved by a qualied person or the Guldmann
Service Team.
Before use it is recommended to spray the product with a mineral oil / liquid
para󰀩n, followed up by wiping with a clean lint-free cloth.
The contents of the bath chair box
• Bath chair
• Oval hook
• User manual
Oval hook
Armrest
Footrest
Wheel brake
Safety belt

6
© Guldmann GB/US-03/2021 • # 944127_101 © Guldmann GB/US-03/2021 • # 944127_101
2.01 Functional description of the bath chair
The bath chair must be securely
attached to either snap hook (GH2) or
Oval hook (GH3), make sure that the
hook is properly closed.
Oval hook
Footrests must be adjusted to the user,
to relieve weight of users legs, and to
ensure that legs stay in place during
transfer.
Footrest
adjustment
Armrests can be turned away or com-
pletely removed to allow easy access
for user and helper during transfer
between bath chair and e.g. Wheel
chair.
Lift up to
remove Swing to
turn away
The bath chair is tted with brake
mechanism on the two back wheels,
disabling the bath chair from moving
around when transferring the user
between bath chair and e.g. Wheel
chair, when locked. Brake activation
Brake releace
User must at all time during transfer be strapped in with the safety belt.

7
© Guldmann GB/US-03/2021 • # 944127_101 © Guldmann GB/US-03/2021 • # 944127_101
2.02 Marking for bath chair
Barcode 128C / GS1-128
V. Guldmann A/S
Graham Bells Vej 21-23A
DK-8200 Aarhus N
yyyy-mm-dd
xxxxxxx
max xxx kg/xxx lbs
xxxxxx xxxxxx
3.00 Unpacking bath stretcher
Visual inspection of the bath stretcher
If the bath stretcher is thought to be damaged upon receipt, it must not
be used before it is checked and approved by a qualied person or the
Guldmann Service Team.
Before use it is recommended to spray the product with a mineral oil / liquid
para󰀩n, followed up by wiping with a clean lint-free cloth.
The contents of the bath stretcher box
• Bath Stretcher
• Oval hook
• User manual Oval hook
Safety belt
Wheel brake
Backrest
adjustment
Cloth
tension
straps
Lifting
Backrest
locking
position

8
© Guldmann GB/US-03/2021 • # 944127_101 © Guldmann GB/US-03/2021 • # 944127_101
3.01 Functional description of the bath stretcher
The bath stretcher must be securely
attached to either snap hook (GH2) or
Oval hook (GH3), make sure that the
hook is properly closed.
The bath stretcher is equipped with 5
holes to adjust center of gravity.
Oval hook
The backrest can be adjusted, raised
and locked in 4 di󰀨erent positions.
Backrest
adjustment
Backrest
locking
position
Stretcher cloth is tted with straps,
that allows the cloth tension to be
adjusted, straps is located on back-
side of cloth and can be tightened by
pulling the strap end.
Cloth
tension
straps
The bath stretcher is tted with brake mechanism on all wheels, disabling the
bath stretcher from moving around when transferring the user between bath
stretcher and e.g. Wheel chair, when locked.
User must at all time during transfer be strapped in with the safety belt.

9
© Guldmann GB/US-03/2021 • # 944127_101 © Guldmann GB/US-03/2021 • # 944127_101
3.02 Marking for bath stretcher
Barcode 128C / GS1-128
V. Guldmann A/S
Graham Bells Vej 21-23A
DK-8200 Aarhus N
yyyy-mm-dd
xxxxxxx
max xxx kg/xxx lbs
xxxxxx xxxxxx
4.00 Maintenance
4.01 Cleaning and maintenance
The bath chair and bath stretcher is made of materials with a high resistance
to salts and chlorine. However, to avoid corrosion and discoloration, cleaning
and maintenance is very important.
The below guidelines must be followed to ensure that the bath chair and the
bath stretcher are nice to look at and have a long service life.
• Daily washing with clean water, followed by wiping with a rmly wrung cloth or
wash leather.
• Washing with universal sanitary cleaning detergents once a week, followed
up by spraying the surface with a mineral oil / liquid para󰀩n at a distance of
approx 20 cm. Wipe with a clean lint-free cloth.
Particularly, during the rst month of use, daily cleaning and wiping is very
important where after the stainless steel will generate its own protecting lm.
4.02 Replacement of components
Components may be replaced only by a qualied service technician or the
Guldmann Service Team.
4.03 Service life
The bath chair and bath stretcher has an expected service life of 10 years,
when subjected to continuous maintenance and correct use. In accordance
with the international standard EN/ISO 10535 “Hoist for the transfer of disa-
bled persons – Requirements and test methods” an inspection should be per-
formed on the hoist at least once a year.
Guldmann recommends that regular safety/service inspection is performed at
least once a year with regard to the pattern of usage.
Inspection of the bath chair and bath stretcher must be performed by a quali-
ed service technician or the Guldmann Service Team.
In connection with the purchase of the bath chair and bath stretcher,
Guldmann may o󰀨er a service agreement for this inspection.

10
© Guldmann GB/US-03/2021 • # 944127_101 © Guldmann GB/US-03/2021 • # 944127_101
4.04 Storage and use environment
The bath chair and bath stretcher are designed for use in Swimming pool
areas.
Temperature +5 to 40 C°.
Keep the bath chair and bath stretcher in a dry room for long-term storage,
according to the instructions mentioned in section 1.03 “Important/warnings”.
5.00 Technical specications
Max. load ........................................255 kg. (560 lbs.)
Materials
Frame..............................................Stainless steel
Seat .............................................Molded polyester
Armrest ..........................................Molded polyester
Wheels and bearings ..................................Stainless steel
Bolts ...............................................Stainless steel
Footrest ..................................Painted, molded aluminum
Stretcher cloth ..............................................Nylon
6.00 EU declaration of conformity
The product is manufactured in compliance with regulation (EU) 2017/745
of the European parliament and of the Council of 5 April 2017, as medical
device Class I.
7.00 Environmental policy statement - V. Guldmann A/S
Guldmann is continuously working towards ensuring that the company’s
impact on the environment, locally and globally, is reduced to a minimum.
It is Guldmann’s goal to:
• Comply with the current environmental legislation (e.g. WEEE and REACH
directives)
• Ensure that we, at the widest possible range, use RoHS compliant materials
and components
• Ensure that our products do not have an unnecessary negative impact on the
environment regarding use, recirculation or disposal
• Ensure that our products contribute to a positive working environment in the
places they are utilised
Inspections are made annually by the Department for Nature and Environ-
ment from the Municipality of Aarhus using the Danish Environmental Protec-
tion Act, section 42 as a reference.

11
© Guldmann GB/US-03/2021 • # 944127_101 © Guldmann GB/US-03/2021 • # 944127_101
8.00 Warranty and service conditions
A. Warranty
Guldmann warrants its equipment is free from material defects under normal
use, and will perform substantially in accordance with the specications set
forth in documentation provided with the equipment.
This express warranty shall be in e󰀨ect for one year from the date of original
purchase and installation (the “Warranty Period”). If a valid claim is made
during the Warranty Period for malfunction or equipment defect, Guldmann will
repair or replace the equipment at no additional cost to you. Guldmann retains
sole discretion as to whether the equipment will be repaired or replaced.
The warranty does not cover any part of the equipment that has been subject
to damage or abuse by the user or others. The warranty does not cover any
part of the equipment that has been altered or changed in any way by the
user or others. Guldmann does not warrant that the lifting device functions will
meet your requirements, be uninterrupted or error free.
The warranty set forth is in lieu of all other express and implied warran-
ties, whether oral, written or implied, and the remedies set forth above are
your sole and exclusive remedies. Only an authorized o󰀩cer of Guldmann
may make modications to this warranty, or additional warranties binding on
Guldmann. Accordingly, additional statements such as advertising or presen-
tations, whether oral or written, do not constitute warranties by Guldmann.
This warranty shall be null and void if the equipment is operated and main-
tained in any manner inconsistent with its intended use or the instructions
provided with the product. Further, in order for the warranty to remain in e󰀨ect
for the full Warranty Period, all service to the equipment must be provided
by a Guldmann certied technician. Any parts or components repaired or re-
placed by a Guldmann certied technician will be guaranteed for the remain-
der of the Warranty Period.
Only for USA
This warranty shall be null and void if the equipment is operated and main-
tained in any manner inconsistent with its intended use or the instructions
provided with the product. Further, in order for the warranty to remain in e󰀨ect
for the full Warranty Period, all service to the equipment must be provided
by a Guldmann Certied Technician. A Guldmann Certied Technician is a
technician who has successfully completed Guldmann Service Training, and
who holds a valid Service Training Certicate from Guldmann, and is in pos-
session of a valid password to access Guldmann’s Service and Information
Console (SIC). A Guldmann Service Training Certicate and SIC password
are valid for three years (only USA) from the date the technician is rst certi-
ed. Thereafter, the technician must undergo re-certication training to obtain
a new valid certicate and password. Any parts or components repaired or
replaced by a Guldmann Certied Technician will be guaranteed for the re-
mainder of the Warranty Period. In the event the warranty is rendered null
and void, the purchaser shall indemnify and hold Guldmann harmless of and

12
© Guldmann GB/US-03/2021 • # 944127_101 © Guldmann GB/US-03/2021 • # 944127_101
from any and all claims or liability arising as a result of equipment malfunction
or misuse.
B. Service or Repair
Contact Guldmann Repair for an authorization to return any defective item
during the Warranty Period. You will be provided with a return authorization
number and address for returning the item for warranty service or replace-
ment. Do not return items to Guldmann under warranty without receiving a
Return Authorization Number.
If mailing the item, pack it carefully in a sturdy carton to prevent damage.
Include your Return Authorization Number, a brief description of the problem
and your return address and phone number. Guldmann does not assume the
risk of loss or damage while in transit, so it is recommended you insure the
package.

13
© Guldmann GB/US-03/2021 • # 944127_101 © Guldmann GB/US-03/2021 • # 944127_101

14
© Guldmann GB/US-03/2021 • # 944127_101 © Guldmann GB/US-03/2021 • # 944127_101

15
© Guldmann GB/US-03/2021 • # 944127_101 © Guldmann GB/US-03/2021 • # 944127_101

16
© Guldmann GB/US-03/2021 • # 944127_101
© Guldmann GB/US-03/2021 • # 944127_101
V. Guldmann A/S
Corporate O󰀩ce:
Tel. [phone]
[email protected]
www.guldmann.com
Guldmann Inc.
Tel. [phone]
Tel. [phone]
Fax [phone]
[email protected]
www.guldmann.net
