GVA Lighting PS-INF 3000 User manual

PS-INF 3000
& PDC INF
POWER SUPPLY FOR INFINITY® LIGHTING SYSTEMS INSTALLATION GUIDE
GVA Lighting, Inc. 2771 Bristol Circle, Oakville, Ontario L6H 6X5
Tel: + 1 905 569 6044 Email: [email protected] gvalighting.com
IG-PS-INF-3000, 06-06-2019 Page 1 / 13

POWER SUPPLY FOR INFINITY® LIGHTING SYSTEMS INSTALLATION GUIDE
Specifications are subject to change without notice. Every effort has been made to ensure that the information provided in this manual is accurate.
GVA Lighting Inc. is not responsible for printing or clerical errors. Refer to www.gvalighting.com for additional information.
PS-INF 3000
& PDC INF
REVISION HISTORY
REVISION NUMBER REVISION DATE DESCRIPTION
1
2
September 08, 2016
June 20, 2017
July 06, 2018
June 06, 2019
Initial Release
Aesthetic Adjustments
Corrections, addition of information
Update of information
3
4
GVA Lighting, Inc. 2771 Bristol Circle, Oakville, Ontario L6H 6X5
Tel: + 1 905 569 6044 Email: [email protected] gvalighting.com
IG-PS-INF-3000, 06-06-2019 Page 2 / 13

POWER SUPPLY FOR INFINITY® LIGHTING SYSTEMS INSTALLATION GUIDE
Specifications are subject to change without notice. Every effort has been made to ensure that the information provided in this manual is accurate.
GVA Lighting Inc. is not responsible for printing or clerical errors. Refer to www.gvalighting.com for additional information.
PS-INF 3000
& PDC INF
CONTENTS
About This Guide............................................................................................................................................................
Warnings & Cautions......................................................................................................................................................
Package Contents..........................................................................................................................................................
System Installation & Electrical Requirements...............................................................................................................
Mounting Instructions.....................................................................................................................................................
Typical System Diagram: PS-INF 3000 (for non-dimming INFINITY® lighting systems)...........................................................................
Typical System Diagram: PS-INF 3000 & PDC-INF (for dimming INFINITY® lighting systems)...........................................................
ABOUT THIS GUIDE
This Installation Guide describes how to install the following Power Supply Units (PSUs):
G20337: POWER SUPPLY, PS-INF-3000, 120VAC, 1W+N+PE, 60Hz, 16A MAX, 380VDC, 1500W, IP66, NA, REV. 1
G20338: POWER SUPPLY, PS-INF-3000, 208/240VAC, 2W+PE, 60Hz, 16A MAX, 380VDC, 3000W, IP66, NA, REV. 1
G20341: POWER SUPPLY, PS-INF-3000, 220/230/240VAC, 1W+N+PE, 50Hz, 16A MAX, 380VDC, 3000W, IP66, EU, REV.1
Before you begin:
Thank you for purchasing GVA's PS-INF 3000 power supply unit. Before installing the unit, please read this installation guide carefully, gather
necessary tools and equipment, and verify the package contents. Remove the unit from its packaging material and follow the instructions
correctly for safe operation. Save this guide for future reference. Be sure to always include this installation guide in the packaging when
transferring or transporting this product to a different location.
3
4
5
5
6
7
10
GVA Lighting, Inc. 2771 Bristol Circle, Oakville, Ontario L6H 6X5
Tel: + 1 905 569 6044 Email: [email protected] gvalighting.com
IG-PS-INF-3000, 06-06-2019 Page 3 / 13

POWER SUPPLY FOR INFINITY® LIGHTING SYSTEMS INSTALLATION GUIDE
Specifications are subject to change without notice. Every effort has been made to ensure that the information provided in this manual is accurate.
GVA Lighting Inc. is not responsible for printing or clerical errors. Refer to www.gvalighting.com for additional information.
PS-INF 3000
& PDC INF
WARNING
1. Only qualified personnel should be permitted to install, replace, or service this equipment.
2. Only use attachments and/or accessories specified by GVA Lighting.
3. Follow instructions for wall, shelf, or ceiling mounting as recommended by GVA Lighting.
4. Use properly rated and stable input voltage within the range of 100~240V. (Use of non-rated and/or unstable AC input voltage may result in
severe damage to the product.
5. Do NOT, under any circumstance, modify or disassemble this product. Doing so may result in a fire, electric shock and/or severe damage to
the product.
6. Do NOT touch power cables or power plugs in such circumstances as a lightning storm, as this may cause electric shock.
7. Any severe physical impact on the product, other than what is specified by GVA Lighting, may cause certain components to fall out of place
within and break, which may cause fire or electric shock. In such an event, do not operate the product. Contact your authorized GVA Lighting
representative for support.
8. Protect the power cord from being walked on or pinched.
9. Do NOT destroy, process, or place the product close to any heating device as this may result in damages to the product.
10. Do NOT bend or twist power cords, power plugs, cables, or wires with excessive force as this may result in damages to the product.
11. Do NOT place any heavy object on the product as this may result in damages to the product.
12. Do NOT touch power cables with wet hands and/or when the power supply is running as this may cause electric shock.
13. Do NOT use any non-rated power sockets and/or power strips with many other devices jointly plugged in. The wire of non-designated capacity
may cause fire due to build up heat emission.
14. In case of product malfunction or unusual events, such as electrical burning smell and smoke, immediately turn OFF and contact GVA
Lighting.
15. Do NOT install this product in an unstable environment, such as on moving objects, or on unstable surfaces. Improper installation may result
in dismounting of the product and may result in equipment damages, fires, personal injury, and death.
16. Do NOT install the product near a poisonous gas or chemically unstable atmosphere as it may cause fire.
17. Do NOT install the product near a strong magnetic or electric field. It may result in equipment damages, fires, electric shock, and personal
injury.
18. Do NOT move or transport this product with any power cables connected to the source devices. Damages may occur to the cables, plugs, or
jointing connectors of the cables due to forcible bending and stress. This may cause damages to the waterproof seal of the product, making
it subject to fire, electric shock, or shorted circuit.
19. When disconnecting the equipment, always hold the plugs of power cords or cables. Improper pulling of the cords or cables may cause
damages to the waterproof seal of the product. This may result in equipment damages, shorted circuits, fires, electric shock, and personal
injury.
20. Do NOT use any other power cords or connection cables than what is recommended/provided by the manufacturer directly. Use of untested,
unauthorized, or substituted power cords and/or connection cables may be a cause for malfunction, fire, electric shock, or severe damages
to the product. Also, such use of improper or undesignated power cords or connection cables will void product warranty.
21. Always leave the power OFF when connecting or disconnecting the power cords or connection cables to avoid electric shock or damages to
the product.
22. Do NOT use aggressive cleaning agents, such as paint thinner or benzene to clean the exterior of the product. It may cause scratches on
the surface, erasing proper indications, identification labels, or instructions on the exterior, which may be a cause for misuse and
improper operation of the product.
23. This equipment must be externally grounded using a customer-supplied ground wire before power is applied. Contact the local electrical
inspection authority or a licensed electrician if uncertain that suitable grounding is available.
24. Do not work on the system or connect or disconnect cables during periods of lightning activity.
25. No serviceable parts inside the product. Do not open.
GVA Lighting, Inc. 2771 Bristol Circle, Oakville, Ontario L6H 6X5
Tel: + 1 905 569 6044 Email: [email protected] gvalighting.com
IG-PS-INF-3000, 06-06-2019 Page 4 / 13

POWER SUPPLY FOR INFINITY® LIGHTING SYSTEMS INSTALLATION GUIDE
Specifications are subject to change without notice. Every effort has been made to ensure that the information provided in this manual is accurate.
GVA Lighting Inc. is not responsible for printing or clerical errors. Refer to www.gvalighting.com for additional information.
PS-INF 3000
& PDC INF
PACKAGE CONTENTS
The following items are included with each PSU. Contact your authorized GVA Lighting representative if products are damaged or missing.
1 x PS-INF 3000 Power Supply Unit with input & output cables attached
1 x Installation Guide
NOTE: PDC-INF units purchased for use with the PS-INF 3000 are shipped separately with leader cables.
SYSTEM INSTALLATION & ELECTRICAL REQUIREMENTS
ELECTRICAL CODE:
NOTE: To the power supply unit installer:
Check National and/or Local Electrical Codes for guidelines on proper grounding / bonding of electrical systems and circuits. The power cable
ground wire (green or green/yellow) must be connected to the grounding system of the facility.
For safety reasons (high leakage current / high touch current) the power cable ground wire (green or green/yellow) must be connected first
to the AC Ground (or PE - Protective Earth) terminal, prior to connecting the other AC input wires.
NOTE: Installation shall incorporate UL Listed (or applicable local safety agency listing) external surge protection rated 2500 Vpk or less, for 150
to 300 Vac mains (depending on jurisdiction), installed in accordance with Article 285 of ANSI/NFPA 70 or applicable local codes.
POWER SOURCE:
The product must be connected to the specified voltage indicated on the product label, using a junction box with a Ground or PE connection.
The branch circuit breaker is used as the disconnect device (Line-Neutral for G20337 & G20341 and Line-Line for G20338) and shall remain
readily accessible. This product operates on 100-240 Volts, 47-63 Hz, AC current. Never connect the product to anything other than the
voltage specified on the product label.
To prevent electric shock from the product, do not use with an extension cord, receptacle, or other outlets. This product has to be connected to
a separate AC line branch.
GVA Lighting, Inc. 2771 Bristol Circle, Oakville, Ontario L6H 6X5
Tel: + 1 905 569 6044 Email: [email protected] gvalighting.com
IG-PS-INF-3000, 06-06-2019 Page 5 / 13

MOUNTING SURFACE
PS-INF 3000
HARDWARE REQUIRED:
M6 or 1/4in SCREW
(by others)
COUNTER BORE
FOR MOUNTING
FASTENER
4.62"
117 mm
3.44"
mm87
.53"
13.5 mm
UP
L AMP CONT ROL GE AR P OWE R-SUP PLY
EQUIP MENT: G20220 - P OWE R SUPP LY,
PS -INF-3000, 100~240VAC, IP66
INPUT:
100-240VAC, 17A MAX, 47-63Hz
NOMINAL OUTP UT:
380VDC
MAXIMUM OUTPUT P OWE R:
1500W @ 100-200VA C INPU T
3000W @ 200-240VA C INPU T
SUITABLE F OR DRY DAMP AND WET LOCATI ONS
MAXt=50°C
a
Constructed to me et
req uire me nts o utli ned
in UL 1 012 & 87 50
IP66
380VDC
GVA Lig htin g, I nc.
gvalighting.com
M ADE I N CANADA
0 /00 0
00000
UNIT # 000 00 000
L AMP CONT ROL GE AR P OWE R-SUP PLY
EQUIP MENT: G20220 - P OWE R SUPP LY,
PS -INF-3000, 100~240VAC, IP66
INPUT:
100-240VAC, 17A MAX, 47-63Hz
NOMINAL OUTP UT:
380VDC
MAXIMUM OUTPUT P OWE R:
1500W @ 100-200VA C INPU T
3000W @ 200-240VA C INPU T
SUITABLE F OR DRY DAMP AND WET LOCATI ONS
MAXt=50°C
a
Constructed to me et
req uire me nts o utli ned
in UL 1 012 & 87 50
IP66
380VDC
GVA Lighting, Inc.
gvalighting.com
M ADE I N CANADA
0 /0 00
00000
UNIT # 000 00 000
UP
The area around the unit,
indicated with red, must be
kept clear at all times.
MIN. 300mm
12in
MIN. 150mm
5.9in
MIN. 150mm
5.9in
POWER SUPPLY FOR INFINITY® LIGHTING SYSTEMS INSTALLATION GUIDE
Specifications are subject to change without notice. Every effort has been made to ensure that the information provided in this manual is accurate.
GVA Lighting Inc. is not responsible for printing or clerical errors. Refer to www.gvalighting.com for additional information.
PS-INF 3000
& PDC INF
MOUNTING INSTRUCTIONS
WARNING
For safety reasons, only mount with a UL listed wall mount bracket (if used) that supports the weight of the enclosure (12 Kg or 26.5 lbs) and any hardware.
When mounting the enclosure outdoors or in harsh environments, only use wall mounts that are designed to resist water, rust and wind.
Install PS-INF 3000 in a well-ventilated area. Keep recommended distances from the walls / other obstacles. Do NOT block fans on top of the power supply unit.
Total weight PS-INF 3000 (including cables) = 12 Kg (26.5 Lbs)
CABLE GLAND
GVA Lighting, Inc. 2771 Bristol Circle, Oakville, Ontario L6H 6X5
Tel: + 1 905 569 6044 Email: [email protected] gvalighting.com
IG-PS-INF-3000, 06-06-2019 Page 6 / 13

MOUNTING SURFACE
380VDC FIXTURE
LEADER CABLE
(to non-dimming luminaires)
380VDC OUTPUT
(1m x 3C-14AWG (2.08 mm2)
TC-ER CABLE OD MAX. 9.15mm (0.36in)
100~264VAC INPUT
(Line-Neutral for G20337 & G20341,
Line-Line for G20338)
(1.2m x 3C-14AWG (2.08 mm2)
SOOW CABLE OD MAX. 14.2mm (0.56in)
JUNCTION BOX
(BY OTHERS)
FIG.2
FIG.3
PS-INF 3000
JUNCTION BOX
(BY OTHERS)
FIG. 1
POWER SUPPLY FOR INFINITY® LIGHTING SYSTEMS INSTALLATION GUIDE
Specifications are subject to change without notice. Every effort has been made to ensure that the information provided in this manual is accurate.
GVA Lighting Inc. is not responsible for printing or clerical errors. Refer to www.gvalighting.com for additional information.
PS-INF 3000
& PDC INF
TYPICAL SYSTEM DIAGRAM: PS-INF 3000, NON-DIMMING
For non-dimming INFINITY® lighting systems.
CAUTION When routing cables through the cable entry be sure that the cables are formed in such a way as to remove any stress on the cable glands.
Installation shall be in accordance with the applicable parts of Chapter 8 of ANSI/NFPA70 or applicable local codes.
GVA Lighting, Inc. 2771 Bristol Circle, Oakville, Ontario L6H 6X5
Tel: + 1 905 569 6044 Email: [email protected] gvalighting.com
IG-PS-INF-3000, 06-06-2019 Page 7 / 13

380V DC FIXTURE
LEADERCABLE 380VDC
“Wire colors could be different
for different countries”
TO NON-DIMMING
LUMINAIRES
FROM
PS-INF 3000
GND
DC -
DC +
GND
DC -
DATA
DC +
POWER SUPPLY FOR INFINITY® LIGHTING SYSTEMS INSTALLATION GUIDE
Specifications are subject to change without notice. Every effort has been made to ensure that the information provided in this manual is accurate.
GVA Lighting Inc. is not responsible for printing or clerical errors. Refer to www.gvalighting.com for additional information.
PS-INF 3000
& PDC INF
TYPICAL SYSTEM DIAGRAM: PS-INF 3000, NON-DIMMING
FIGURE 2: JUNCTION BOX CONNECTION (by others)
NOTE: This is a sample drawing. Actual junction boxes (supplied by others) may vary in appearance.
FIG. 2
GVA Lighting, Inc. 2771 Bristol Circle, Oakville, Ontario L6H 6X5
Tel: + 1 905 569 6044 Email: [email protected] gvalighting.com
IG-PS-INF-3000, 06-06-2019 Page 8 / 13

AC POWER SOURCE
100~264VAC
“Wire colors could be different
for different countries”
AC INPUT 100~264VAC
TO PS-INF 3000
MODEL G20337
PROTECTIVE
NEUTRAL
LINE 1
GREEN
WHITE
BLACK
FIG. 3.1
POWER SUPPLY FOR INFINITY® LIGHTING SYSTEMS INSTALLATION GUIDE
Specifications are subject to change without notice. Every effort has been made to ensure that the information provided in this manual is accurate.
GVA Lighting Inc. is not responsible for printing or clerical errors. Refer to www.gvalighting.com for additional information.
PS-INF 3000
& PDC INF
TYPICAL SYSTEM DIAGRAM: PS-INF 3000, NON-DIMMING
FIGURE 3.1. Junction Box Connection for G20337 (Line, Neutral, Protective Earth) - North America
NOTE: This is a sample drawing. Actual junction boxes (supplied by others) may vary in appearance.
FIGURE 3.2. Junction Box Connection for G20341 (Line, Neutral, Protective Earth) - Europe
NOTE: This is a sample drawing. Actual junction boxes (supplied by others) may vary in appearance.
GVA Lighting, Inc. 2771 Bristol Circle, Oakville, Ontario L6H 6X5
Tel: + 1 905 569 6044 Email: [email protected]
AC POWER SOURCE
100~264VAC
“Wire colors could be different
for different countries”
AC INPUT 100~264VAC
TO PS-INF 3000
MODEL G20341
PROTECTIVE
NEUTRAL
GREEN or
GREEN/YELLOW
BLUE
BROWN
FIG. 3.2
EARTH
EARTH
LINE 1
gvalighting.com
IG-PS-INF-3000, 06-06-2019 Page 9 / 13

“Wire colors could be different
for different countries”
AC INPUT 100~264VAC
TO PS-INF 3000
MODEL G20338
AC POWER SOURCE
100~264VAC
PROTECTIVE
EARTH GREEN
RED or BLUE
BLACK
FIG. 3.3
POWER SUPPLY FOR INFINITY® LIGHTING SYSTEMS INSTALLATION GUIDE
Specifications are subject to change without notice. Every effort has been made to ensure that the information provided in this manual is accurate.
GVA Lighting Inc. is not responsible for printing or clerical errors. Refer to www.gvalighting.com for additional information.
PS-INF 3000
& PDC INF
TYPICAL SYSTEM DIAGRAM: PS-INF 3000, NON-DIMMING
FIGURE 3.3. Junction Box Connection for G20338 (Line, Line, Protective Earth) - North America
NOTE: This is a sample drawing. Actual junction boxes (supplied by others) may vary in appearance.
GVA Lighting, Inc. 2771 Bristol Circle, Oakville, Ontario L6H 6X5
Tel: + 1 905 569 6044 Email: [email protected] gvalighting.com
IG-PS-INF-3000, 06-06-2019
Page 10 / 13
LINE 1
LINE 2

DATA INPUT
(from lighting
controls, by others)
DATA OUTPUT
(optional, cables by others)
380VDC BUS OUTPUT
(optional, cables by others)
POWER-DATA OUTPUT
“LEADER CABLE”
(to luminaires, circuit 1,
MAX 30m to first fixture)
JUNCTION BOX
(by others)
AC INPUT 100~264VAC
(Line-Neutral for G20327 &
G20341, Line-Line for G20338)
(1.2m x 3C-14AWG SOOW
cable OD MAX 14.2mm/0.56in)
PS-INF 3000
PDC-INF
FIG. 5
380VDC OUTPUT
(1m x 3C-14AWG TC-ER cable
OD MAX 9.15mm/0.36in)
MOUNTING SURFACE
TO NEXT PDB
(optional, if multiple
PDC-INF units are used)
FIG. 4
POWER SUPPLY FOR INFINITY® LIGHTING SYSTEMS INSTALLATION GUIDE
Specifications are subject to change without notice. Every effort has been made to ensure that the information provided in this manual is accurate.
GVA Lighting Inc. is not responsible for printing or clerical errors. Refer to www.gvalighting.com for additional information.
PS-INF 3000
& PDC INF
TYPICAL SYSTEM DIAGRAM: PS-INF 3000 & PDC-INF, DIMMING
For dimming INFINITY® lighting systems.
CAUTION When routing cables through the cable entry be sure that the cables are formed in such a way as to remove any stress on the cable glands.
Installation shall be in accordance with the applicable parts of Chapter 8 of ANSI/NFPA70 or applicable local codes.
GVA Lighting, Inc. 2771 Bristol Circle, Oakville, Ontario L6H 6X5
Tel: + 1 905 569 6044 Email: [email protected]
IG-PS-INF-3000, 06-
gvalighting.com
06-2019| Page 11 / 13

380V DATA
POWER SUPPLY FOR INFINITY® LIGHTING SYSTEMS INSTALLATION GUIDE
Specifications are subject to change without notice. Every effort has been made to ensure that the information provided in this manual is accurate.
GVA Lighting Inc. is not responsible for printing or clerical errors. Refer to www.gvalighting.com for additional information.
PS-INF 3000
& PDC INF
TYPICAL SYSTEM DIAGRAM: PS-INF 3000 & PDC-INF, DIMMING
FIGURE 5. PDC-INF
GVA Lighting, Inc. 2771 Bristol Circle, Oakville, Ontario L6H 6X5
Tel: + 1 905 569 6044 Email: [email protected]
IG-PS-INF-3000, 06-
gvalighting.com
06-2019| Page 12 / 13

POWER SUPPLY FOR INFINITY® LIGHTING SYSTEMS INSTALLATION GUIDE
Specifications are subject to change without notice. Every effort has been made to ensure that the information provided in this manual is accurate.
GVA Lighting Inc. is not responsible for printing or clerical errors. Refer to www.gvalighting.com for additional information.
PS-INF 3000
& PDC INF
NOTES
GVA Lighting, Inc. 2771 Bristol Circle, Oakville, Ontario L6H 6X5
Tel: + 1 905 569 6044 Email: [email protected]
IG-PS-INF-3000, 06-
gvalighting.com
06-2019| Page 13 / 13
