* Specifications are subject to change without notice.
Mechanical drawing
I/O Ports
UNiT : mm
GVision Incorporated TEL: +886-2-8226-5511 / FAX : +886-2-8226-5533 / www.gvision.com.twGVision Incorporated TEL: +886-2-8226-5511 / FAX : +886-2-8226-5533 / www.gvision.com.tw
Configuration
LCD Display
Pixel Pitch
Max. Resolution
Contrast Ratio
Brightness
Response Time ( Tr+ Tf )
Display Color
Effective Display Area
Viewing Angle (CR
ꇙ
10)
Backlight
Lamp Life
Stand Base
Signal Connector Analog
Digital
Scan Frequency
Audio System
USB HUB
Key Control
Operating Condition Temperature
Humidity
Altitude
Storage Condition Temperature
Humidity
Power
Power Consumption
Dimensions Landscape
Portrait
Weight (Net)
Certification
F15AX-DP
15" TFT active matrix panel
0.297(H)x0.297(V) mm
XGA 1024x768
400:1 (Typical )
250 Cd/m2(Typical )
25 ms
16M
304.1(H)x228.1(V) mm
120 (H) x 100 (V)
2 CCFLs
40,000 hrs
Tilt down:0o, Tilt up: +20o
D-sub 15 pin (VGA)
DVI-D (option)
H. scan 31~ 60KHz,
V. scan 60 ~ 75Hz
1W / per channel driver
A type x 2, B type x1
Power on/off with LED, Menu,
Select, Adjustment (+, - )
5oC-35oC (41oF-95oF)
20%-80% (no condensation)
To 10,000 feet
-20oC-60oC ( -4oF-140oF )
10%-90% ( no condensation )
Input AC 100~240V, 50~60Hz;
Output DC 12V / 4A
48 W
351(W) x 334(H) x163(D)
N/A
3.1 Kg
CE, FCC, UL,TUV, TCO
Features :
* High contrast color TFT LCD display support resolution up
to XGA 1024x768. Compatible with IBM VGA, VESA
standards.
* Independent JPEG player and Flash memory card reader
(USB interface), support CF, SD, MMC, SM.
* Various imbedded multimedia providing audio system,
earphone jack, and audio-out jack.
* Support VESA standard mounting holes for wall mount or
ARM mounting application.
* Fold down base for easy wall hanging application.
* Support a USB hub with 2 downstream ports and 1
upstream port.
* Support JPEG player and Card reader functions are
offering a user-friendly device for various applications and
environments.
* Enable remote control TV function and JPEG player with
build-in IR receiver.
* Optional TV tuner supports NTSC or PAL TV system and
Video-in function.
Optional Accessories :
* TV tuner
Please see the TV tuner specification for more
information.
Ordering Information :
* F15AX-DC VGA, JPEG, USB (TV function is not available)
* F15AX-DH VGA, DVI, JPEG, USB (TV function is not available)
* F15AX-DK VGA, JPEG
* F15AX-DP VGA, DVI, JPEG
Remark: F15AX-DK and F15AX-DP: TV function is available.
TV Tuner Audio in DVI-D VGA DC in
Audio in DVI-D VGA DC in USB HUB
TV tuner
Specification
Signal connector : TV antenna x1/S-video x 1
RCA x3 (Video, Audio L/R)
Order Information
(TV tuner module is packed separately)
IF2-U9 (NTSC)
IF2-UM(NTSC+MTS)
IF2-M9(Multi PAL)
IF2-MN(Multi PAL + NTSC)
IF2-MY(Multi PAL + NTSC + Teletext)
