GVision K12TX-C User manual

Industrial A
pp
licatio
n
12.1"
C
hassis TFT L
C
D Monito
r
Where
Versatility
Meets
Flexibility
Where Versatility Meets Flexibility
Confi
g
uratio
n
LCD Displa
y
Pix
e
l Pit
ch
M
a
x. R
eso
l
u
ti
on
Contrast Ratio
Brightness
Response Time ( Tr+ Tf )
Display Color
Effective Display Area
Viewing Angle (CR ꇙ 10)
Backlight
Lamp Life
Input Signals
Signal Connector Analog
Digital
Video-in
Scan Frequency
Speakers
USB HUB
Touch panel
Key Control
Operating Condition Temperature
Humidity
Altitude
Storage Condition Temperature
Humidity
Power
Power Consumption
Power Management
Dimensions (WxHxD)
Dimensions (Carton 2 in 1)
Weight (Net)
Certification
* Specifications are subject to change without notice.
Mechanical drawing
* Ru
gg
ed metal chassis offerin
g
stron
g
protectio
n
* Hi
g
h contrast color TFT LCD open frame displa
y
support
resolution u
p
to SVGA 1024 x 768. Com
p
atible with IBM,
VGA, VESA standards.
* Flexible mechanical designs for industrial application.
* Multi-signals: VGA, DVI, Composite video, s-video
(Auto detection of input signals).
* Composite video system PAL/NTSC and SECAM
compatible.
* Support DDC1/2B for Plug & Play compatibility.
* Advanced OSD control for picture quality adjustment.
* Optional touch solutions.
* Flexible Mounting Solutions - Front mounting, Racking
mounting & VESA mounting.
* Optional Industrial Power Plug.
* Hot key for AUTO adjustment.
* Space reserved under I/O port.
* IP54 water resistant compliant (Option)
Optional Accessories :
• 3M 5 Wire resistive touch panel
• 3M Capacitive touch panel
• ELO 5 Wire resistive touch panel
• Anti-Glare tempered glass
• Customized touch solution acceptable.
• Front Mounting Frame.
• 19" Rack Mounting Frame.
• Built-in Industrial Power Plug
Ordering Information :
• K12TX-CA VGA only
• K12TX-CW VGA + Video-in
• K12TX-CB VGA + DVI
• K12TX-CE VGA + DVI + Video-in
K
1
2TX-
CA
12.1" TFT active matrix
p
ane
l
0.240
(
H
)
x 0.240
(
V
)
m
m
S
V
G
A 1
0
24 x 7
68
300:1 (typical)
150 Cd/m2(typical)
30 ms (typical)
262K
245.8 (H) x 184.3 (V)
90 (H) x 70 (V)
CCFL x 1
15,000(hr)
Analogue VGA
D-sub 15 pin (VGA)
DVI-D (Option)
RCA, S-video (Option)
H. scan 31 ~ 68 KHz,
V. scan 56 ~ 85 Hz
N/A
N/A
Resistive/Capacitive - RS232 or USB
A type (Option)
Power on/off with LED, Menu, Select,
Adjustment (+, - )
0oC-50oC (32oF-122oF)
20%-80% (no condensation)
To 10,000 feet
-20oC-60oC ( -4oF-140oF )
10%-90% ( no condensation )
Universal power adaptor
Input AC 100~240V, 50~60Hz;
Output DC 12V / 3A
25W
VESA DPMS Standard
340.5 x 270.5 x 46.5 mm
390 x 350 x 175 mm
4.2 Kg
C-UL, FCC, CE
K12TX
-
CA
K12TX CA
K12TX CA
I/O Ports
GVision Incorporated TEL: [phone] / FAX : [phone] / www.gvision.com.twGVision Incorporated TEL: [phone] / FAX : [phone] / www.gvision.com.tw
Tou c hDC inVGADVIS-VideoVideoAudio RAudio L
Front Side Back Side
UNOT : mm
