GVS K-BUS BBPS-02/640.1 User manual

KNX Power Supply, 640mA_V1.2
BBPS-02/640.1
KNX/EIB Home and Building Control System
User Manual

Attentions
1. Please keep devices away from strong magnetic field, high
temperature, wet environment;
2. Do not fall the device to the ground or make them get hard impact;
3. Do not use wet cloth or volatile reagent to wipe the device;
4. Do not disassemble the devices.

Contents
Chapter 1 Introduction -------------------------------------------------------------------------------------------------1
Chapter 2 Technical Parameter ---------------------------------------------------------------------------------------2
Chapter 3 Dimension and Connection Diagram ---------------------------------------------------------------------4
3.1. Dimension drawing ------------------------------------------------------------------------------------------- 4
3.2. Connection Diagram ------------------------------------------------------------------------------------------5
Chapter 4 Normal Working Test -------------------------------------------------------------------------------------- 6

Important safeguards
1) Before use, please read this instruction carefully and use the power supply strictly according to
the instruction.
2) This power supply is for indoor use only and shall be installed in distribution box which can
provide the protection mechanism for avoid electric shock.
3) Please keep this equipment from humidity.
4) Before use, the input and output voltage must be checked to secure correct use.
5) The cover may under no circumstances be opened. If the cover is damaged, then the adaptor
may no longer be used.
6) The power supply shall be installed and used according to national wiring rules.
7) For indoor use only.
8) The product is not a toy, keep it where the children can not reach it.
9) The power supply are only supply for KNX system equipment with bus line connection terminal.
10) Correct Disposal of this product:
This marking indicates that this product should not be disposed with other household wastes
throughout the EU. To prevent possible harm to the environment or human health from uncontrolled
waste disposal, recycle it responsibly to promote the sustainable reuse of material resources. To return
your used device, please use the return and collection systems or contact the retailer where the product
was purchased. They can take this product for environmental safe recycling.

KNX/EIB KNX Power Supply, 640mAPower Supply
1
Chapter 1 Introduction
KNX power supply produces and monitors KNX system voltage. There are two connection
terminal of the output, one for KNX bus supply and signal transmission, one for auxiliary power
supply, can provide 30V DC voltage with terminal device.The bus connection terminal has
integrated the reactor inside the power supply; if the auxiliary power supply terminal is connected
with an external reactor, it can also be used as the bus power supply terminal, and also with the
function of signal transmission.
The KNX power supply is an analog-to-digital installation equipment. In order to facilitate the
installation in the distribution box, according to the design of EN 60 715, it can be installed on a
35mm DIN rail. The device is connected with the screw post for electrical connection. The bus
connection is directly connected through the KNX connection terminal (red/ black). The auxiliary
power supply is also connected directly through the KNX connection terminal (yellow/ white), and
the input end is connected to the power supply voltage of 230V AC.
A reset of the power supply is triggered by pressing the reset button last for 22 seconds (it
does not include the time for button action).When bus supply terminal is disconnected from the
power supply,other devices on the bus will return to their initial state. If bus disconnect for a longer
period, the bus supply terminal must be removed from power supply.

KNX/EIB KNX Power Supply, 640mAPower Supply
2
Chapter 2 Technical Parameter
Power supply
Input voltage
100-240V AC, 50-60Hz
Efficiency
≥80%
Output
KNX output
1 fold with integrated choke
KNX nominal voltage
30+1V/-2V DC, SELV
Auxiliary voltage output
1 fold without integrated choke
Auxiliary voltage
30±1V DC, SELV
KNX nominal current
(Total of KNX and auxiliary voltage output)
640 mA, short-circuit-proof
Sustained short-circuit current
<1.5A
Mains failure buffer time
>200ms
Operation/ Display
Reset push button
22s delay reset function (Press the button >0.5s,
to reset the KNX bus voltage)
Red LED1
Reset the KNX Bus
Green LED2
Normal operation
Red LED3
Overload/short circuit(I>Imax)
Yellow LED4
Current level2 0≤ I <160(±20)mA
Yellow LED5
Current level3 160≤ I <320(±20)mA
Yellow LED6
Current level4 320≤ I <640(±20)mA
Yellow LED7
Current level2 640≤ I <Imax
Connection
Power supply
3-srew terminals
Cable cross-section
Single-core 0.5—2.5mm2
Multi-core 0.5—1.5mm2
KNX output
Bus connection terminal (Red/Black)
Auxiliary voltage output
Connection terminal (Yellow/White)

KNX/EIB KNX Power Supply, 640mAPower Supply
3
Temperature
Operation
-5 °C ... + 45 °C
Storage
-25 °C ... + 55 °C
Transport
-25 °C ... + 70 °C
Environment
Humidity
<93%, except dewing
Mounting
On 35mm mounting rail
Dimension
90×72×64mm
Weight
0.3kg
Housing, Color
Plastic, Beige

KNX/EIB KNX Power Supply, 640mAPower Supply
4
Chapter 3 Dimension and Connection Diagram
3.1.Dimension drawing

KNX/EIB KNX Power Supply, 640mAPower Supply
5
3.2.Connection Diagram
①Reset push button
②Reset indicator LED
③KNX Bus connection terminal
④Auxiliary voltage connection terminal
⑤Main supply
⑥Current level indicator
⑦Output voltage normally indicator
⑧Overload/short circuit indicator
Switch mode power supply unit
Non-inherently short-ciruit-proof-safety isolating
transformer

KNX/EIB KNX Power Supply, 640mAPower Supply
6
Chapter 4 Normal Working Test
When power supply has been correctly installed, switch on the main power supply for the bus
power, and the green LED “ON”, the circuit level indicator LEDs up according to the range of loads,
and the other LEDs are switched off, that is, the device function correctly.
