Programmable AC/DC Power Source
ASR-2000 Series
QuickStart Guide

2
SAFETY INSTRUCTIONS
This section contains the basic safety symbols that may appear on the
accompanying User Manual CD or on the instrument. For detailed safety
instructions and precautions, please see the Safety Instructions chapter in
the user manual CD.
Safety Symbols
These safety symbols may appear in the user manual or on the instrument.
Warning
Warning: Identifies conditions or practices that could result
in injury or loss of life.
Caution
Caution: Identifies conditions or practices that could result
in damage to the instrument or to other properties.
DANGER High Voltage
Attention Refer to the Manual
Do not dispose electronic equipment as unsorted municipal
waste. Please use a separate collection facility or contact
the supplier from which this instrument was purchased.

3
Power Cord for the United Kingdom
When using the instrument in the United Kingdom, make sure the power
cord meets the following safety instructions.
NOTE: This lead/appliance must only be wired by competent persons.
WARNING: THIS APPLIANCE MUST BE EARTHED IMPORTANT:
The wires in this lead are coloured in accordance with the following code:
Green/ Yellow:
Earth
Blue:
Neutral
Brown:
Live (Phase)
As the colours of the wires in main leads may not correspond with the coloured marking
identified in your plug/appliance, proceed as follows:
The wire which is coloured Green & Yellow must be connected to the Earth terminal
marked with either the letter E, the earth symbol or coloured Green/Green &
Yellow.
The wire which is coloured Blue must be connected to the terminal which is marked
with the letter N or coloured Blue or Black.
The wire which is coloured Brown must be connected to the terminal marked with the
letter L or P or coloured Brown or Red.
If in doubt, consult the instructions provided with the equipment or contact the supplier.
This cable/appliance should be protected by a suitably rated and approved HBC mains
fuse: refer to the rating information on the equipment and/or user instructions for details.
As a guide, a cable of 0.75mm2should be protected by a 3A or 5A fuse. Larger
conductors would normally require 13A types, depending on the connection method
used.
Any exposed wiring from a cable, plug or connection that is engaged in a live socket is
extremely hazardous. If a cable or plug is deemed hazardous, turn off the mains power
and remove the cable, any fuses and fuse assemblies. All hazardous wiring must be
immediately destroyed and replaced in accordance to the above standard.

4
Main Features
Performance
•Maximum AC output voltage is 350 Vrms
•Maximum DC output voltage is 500 Vdc
•Maximum output frequency is 999.9 Hz in AC mode
•Supported AC+DC waveform application
•DC full capacity output ability
•Output voltage total harmonic distortion is less than 0.5% at
all frequency.
•Crest factor reached 4 times high
Features
•Include sine, square, triangle, arbitrary and DC output
waveforms
•Variable voltage, frequency and current limiter
•Harmonic voltage and current analysis ability
•Excellent and feature-rich measurement capacity
•Sequence and simulate function
•External input amplification
•AC line synchronized output
•Preset memory function
•USB memory support
•Remote sense
•OCP, OPP and OTP protection function

5
Interface
•Built-in LAN, USB host and USB device interface
•External control I/O
•External signal input
•Factory option RS232 and GPIB interface

6
Appearance
Front Panel Overview
1
10
9
8
7
6
5432 11
12
13
14
1521 20 19 18 17 16
22
Description
1. Power switch button
2. Lock/Unlock button
3. Hardcopy key
4. USB interface connector (A Type)
5. Menu key/On phase key
6. Preset key/Local mode key
7. Shift key
8. Cancel key/ALM CLR key
9. Test key/Output waveform key
10. Output key
11. Enter key
12. Arrow keys
13. Scroll wheel
14. Function keys (blue zone)
15. Display mode select key
16. Range key/Output mode key
17. Irms/IPK-Limit button
18. F/F-Limit button
19. V/V-Limit button
20. LCD screen
21. Air inlet
22. Output socket

7
Rear Panel Overview
187
2345
6
Description
1. Line input
2. Remote sensing input terminal
3. Exhaust fan
4. External I/O connector
5. USB interface connector (B Type)
6. Ethernet (LAN) connector
7. External signal input/ External
synchronized signal input
8. Output terminal

Power up
1. Connect the power cord to the socket on the rear panel.
2. Turn on the power switch on the front panel.
Note
The power supply takes around 15 seconds to fully turn on
and shutdown.
Do not turn the power on and off quickly.
How to Use the Instrument
Background
The ASR-2000 AC power supplies generally use the
scroll wheel, Arrow keys and Enter keys to edit numerical
values or to select menu options.
Menu navigation is performed using the menu keys and
function keys on the front panel.
Selecting Menu
Items
1. Turn the scroll wheel to select parameters in
menus and lists. The selected parameter will
be highlighted in orange. The scroll wheel is
also used to increment/decrement setting
values.
2. Press the Enter key to edit the parameter or
to enter the selected menu.
3.
Example
The following is an example of the menu list that appears
when the Menu key is pressed.

9
Selected parameter
Using the Arrow
Keys and Scroll
Wheel
Use the Arrow keys to select a digit power and then use
the scroll wheel to edit the value by that power.
1. Use the Arrow keys to move the cursor to
the digit of the desired value.
2. Turn the scroll wheel to edit the value by the
resolution of the selected digit.
Cursor
3. Press the Enter key to edit the parameter or to enter the
selected menu. Repeat the steps above for all the
relevant digits.
4. Press the Enter key to confirm the edit.
5.
Note
By default the cursor starts at the lowest digit of value.

10
SPECIFICATIONS
The specifications apply when the ASR-2000 series is powered on for more
than 30 minutes.
Electrical specifications
Model
ASR-2050
ASR-2050R
ASR-2100
ASR-2100R
Input ratings (AC rms)
Nominal input voltage
100 Vac to 240 Vac
Input voltage range
90 Vac to 264 Vac
Phase
Single phase, Two-wire
Nominal input Frequency
50 Hz to 60 Hz
Input frequency range
47 Hz to 63 Hz
Max. power consumption
800 VA or less
1500 VA or less
Power factor*1
100Vac
0.95 (typ.)
200Vac
0.90 (typ.)
Max. input current
100Vac
8 A
15 A
200Vac
4 A
7.5 A
*1
For an output voltage of 100 V/200 V (100V / 200V range), maximum
current, and a load power factor of 1.
Model
ASR-2050
ASR-2050R
ASR-2100
ASR-2100R
AC mode output ratings (AC rms)
Voltage
Setting Range*1
0.0 V to 175.0 V / 0.0 V to 350.0 V
Setting
Resolution
0.1 V

11
Accuracy*2
±(0.5 % of set + 0.6 V / 1.2 V)
Output phase
Single phase, Two-wire
Maximum
current*3
100 V
5 A
10 A
200 V
2.5 A
5 A
Maximum
peak current*4
100 V
20 A
40 A
200 V
10 A
20 A
Load power factor
0 to 1 (leading phase or lagging phase)
Power capacity
500 VA
1000 VA
Frequency
Setting range
AC Mode: 40.00 Hz to 999.9 Hz, AC+DC
Mode: 1.00 Hz to 999.9 Hz
Setting
resolution
0.01 Hz (1.00 to 99.99 Hz), 0.1 Hz (100.0
to 999.9 Hz)
Accuracy
For 45 Hz to 65 Hz: 0.01% of set
For 1 Hz to 999.9 Hz: 0.02% of set
Stability*5
± 0.005%
Output on/off phase
0.0°to 359.9°variable (setting resolution
0.1°)
DC offset*6
Within ± 20 mV (TYP)
*1
100 V / 200 V range
*2
For an output voltage of 17.5 V to 175 V / 35 V to 350 V, sine wave, an
output frequency of 45 Hz to 65 Hz, no load, DC voltage setting 0V
(AC+DC mode) and 23°C ± 5°C
*3
For an output voltage of 1 V to 100 V / 2 V to 200 V. Limited by the
power capacity when the output voltage is 100 V to 175 V / 200 V to 350
V. If there is the DC superimposition, the current ofAC+DC mode
satisfies the maximum current. In the case of lower than 40 Hz, and the
ambient temperature is 40°C or higher, the maximum current will be
decrease.

12
*4
With respect to the capacitor-input rectifying load. Limited by the
maximum current.
*5
For 45 Hz to 65 Hz, the rated output voltage, no load and the resistance
load for the maximum current, and the operating temperature.
*6
In the case of the AC mode and output voltage setting to 0 V.
Model
ASR-2050
ASR-2050R
ASR-2100
ASR-2100R
Output rating for DC mode
Voltage
Setting Range*1
-250.0 V to +250.0 V / -500.0 V to
+500.0 V
Setting Resolution
0.1 V
Accuracy*2
±(|0.5 % of set| + 0.6 V / 1.2 V)
Maximum
current*3
100 V
5 A
10 A
200 V
2.5 A
5 A
Maximum peak
current*4
100 V
20 A
40 A
200 V
10 A
20 A
Power capacity
500 W
1000 W
*1
100 V / 200 V range
*2
For an output voltage of -250 V to -25 V, +25 V to +250 V / -500 V to -50
V, +50 V to +500 V, no load, AC voltage setting 0V (AC+DC mode) and
23°C ± 5°C
*3
For an output voltage of 1.4 V to 100 V / 2.8 V to 200 V. Limited by the
power capacity when the output voltage is 100 V to 250 V / 200 V to 500
V.
*4
Within 5 ms, Limited by the maximum current.
Model
ASR-2050
ASR-2050R
ASR-2100
ASR-2100R
Output voltage stability
Line regulation*1
±0.2% or less

13
Load regulation*2
±0.15% @45 - 65Hz
±0.5% @DC, all other frequencies
(0 to 100%, via output terminal)
Ripple noise*3
0.7 Vrms / 1.4 Vrms (TYP)
*1
Power source input voltage is 100 V, 120 V, or 230 V, no load, rated
output.
*2
For an output voltage of 75 V to 175 V / 150 V to 350 V, a load power
factor of 1, stepwise change from an output current of 0A to maximum
current (or its reverse), using the output terminal on the rear panel.
*3
For 5 Hz to 1 MHz components in DC mode using the output terminal on
the rear panel.
Model
ASR-2050
ASR-2050R
ASR-2100
ASR-2100R
Output voltage waveform distortion ratio, Output voltage response time,
Efficiency
Total harmonic distortion (THD)*1
<0.2 % @50/60 Hz
<0.3 % @<500 Hz
<0.5 % @500.1 Hz to 999.9 Hz
Output voltage response time*2
100 s (TYP)
Efficiency*3
70 % or more
*1
At an output voltage of 50 V to 175 V / 100 V to 350 V, a load power
factor of 1, and in AC and AC+DC mode.
*2
For an output voltage of 100 V / 200 V, a load power factor of 1, with
respect to stepwise change from an output current of 0 A to the
maximum current (or its reverse). 10% ~ 90% of output voltage
*3
For AC mode, at an output voltage of 100 V / 200 V, maximum current,
and load power factor of 1 and sine wave only.
μ

14
Model
ASR-2050
ASR-2050R
ASR-2100
ASR-2100R
Measured value display
Note:
All accuracy of the measurement function is indicated for 23 °C±5
°C.
Voltage
RMS, AVG
value*1
Resolution
0.1 V
Accuracy*2
For 45 Hz to 65 Hz and DC: ±(0.5 % of
reading + 0.3 V / 0.6 V)
For 40 Hz to 999.9 Hz: ±(0.7 % of
reading + 0.9 V / 1.8 V)
PEAK value
Resolution
0.1 V
Accuracy
For 45 Hz to 65 Hz and DC: ±(|2 % of
reading| + 1 V / 2 V)
Current
RMS, AVG
value
Resolution
0.01 A
Accuracy*3
For 45 Hz to 65 Hz
and DC:
±(0.5 % of reading
+ 0.02 A / 0.02 A)
For 40 Hz to 999.9
Hz:
±(0.7 % of reading
+ 0.04 A / 0.04 A)
For 45 Hz to 65 Hz
and DC:
±(0.5 % of reading
+ 0.04 A / 0.02 A)
For 40 Hz to 999.9
Hz:
±(0.7 % of reading
+ 0.08 A / 0.04 A)
PEAK value
Resolution
0.01 A
Accuracy*4
For 45 Hz to 65 Hz
and DC:
±(|2 % of reading|
+ 0.2 A / 0.1 A)
For 45 Hz to 65 Hz
and DC:
±(|2 % of reading|
+ 0.2 A / 0.1 A)
Power
Active (W)
Resolution
0.1 / 1 W
Accuracy*5
±(2 % of reading +
0.5 W)
±(2 % of reading +
1 W)

15
Apparent
(VA)
Resolution
0.1 / 1 VA
Accuracy*5*6
±(2 % of reading +
0.5 VA)
±(2 % of reading +
1 VA)
Reactive
(VAR)
Resolution
0.1 / 1 VAR
Accuracy*5*7
±(2 % of reading +
0.5 VAR)
±(2 % of reading +
1 VAR)
Load power factor
Range
0.000 to 1.000
Resolution
0.001
Load crest factor
Range
0.00 to 50.00
Resolution
0.01
Harmonic voltage
Effective value (rms)
Percent (%)
(AC-INT and 50/60 Hz
only)
Range
Up to 100th order of the fundamental
wave
Full Scale
175 V / 350 V, 100%
Resolution
0.1 V, 0.1%
Accuracy*8
Up to 20th ±(0.2 % of reading + 0.5 V /
1 V)
20th to 100th ±
(0.3 % of reading + 0.5 V / 1 V)
Harmonic current
Effective value (rms)
Percent (%)
(AC-INT and 50/60 Hz
only)
Range
Up to 100th order of the fundamental
wave
Full Scale
5 A / 2.5A, 100%
10 A / 5 A, 100%
Resolution
0.01 A, 0.1%
Accuracy*3
Up to 20th
±(1 % of reading +
0.1 A / 0.05 A)
20th to 100th
±(1.5 % of reading
+ 0.1 A / 0.05 A)
Up to 20th
±(1 % of reading +
0.2 A / 0.1 A)
20th to 100th
±(1.5 % of reading
+ 0.2 A / 0.1 A)

16
*1
The voltage display is set to RMS inAC/AC+DC mode andAVG in DC
mode.
*2
AC mode: For an output voltage of 17.5 V to 175 V / 35 V to 350 V and
23 °C ± 5 °C. DC mode: For an output voltage of 25 V to 250 V / 50 V to
500 V and 23 °C ± 5.
*3
An output current in the range of 5 % to 100 % of the maximum current,
and 23 °C ± 5 °C.
*4
An output current in the range of 5 % to 100 % of the maximum peak
current inAC mode, an output current in the range of 5 % to 100 % of
the maximum instantaneous current in DC mode, and 23 °C ± 5 °C. The
accuracy of the peak value is for a waveform of DC or sine wave
*5
For an output voltage of 50 V or greater, an output current in the range
of 10 % to 100 % of the maximum current, DC or an output frequency of
45 Hz to 65 Hz, and 23 °C ± 5 °C.
*6
The apparent and reactive powers are not displayed in the DC mode.
*7
The reactive power is for the load with the power factor 0.5 or lower.
*8
An output voltage in the range of 17.5 V to 175 V / 35 V to 350 V and 23
°C ± 5 °C.
Note
Product specifications are subject to change without
notice.
The spec aforementioned applies to when slew rate
mode is the Time mode.
General Specifications
Interface
Standard
USB
LAN
MACAddress, DNS IPAddress, User
Password, Gateway IP Address,
Instrument IPAddress, Subnet Mask
EXT
Control
External Signal Input
External Control I/O
Type A: Host, Type B: Device,
Speed: 1.1/2.0, USB-CDC

17
Optional 1
GPIB
SCPI-1993, IEEE 488.2 compliant
interface
RS-232C
Complies with the EIA-RS-232
specifications
Insulation
resistance
Between input and
chassis, output and
chassis, input and
output
500 Vdc, 30 MΩor more
Withstand
voltage
Between input and
chassis, output and
chassis, input and
output
1500 Vac, 1 minute
EMC
EN 61326-1 (Class A)
EN 61326-2-1/-2-2 (Class A)
EN 61000-3-2 (Class A, Group 1)
EN 61000-3-3 (Class A, Group 1)
EN 61000-4-2/ -4-3/ -4-4/ -4-5/ -4-6/
-4-8/-4-11 (Class A, Group 1)
EN 55011 (Class A, Group1)
Safety
EN 61010-1
Environment
Operating
environment
Indoor use, Overvoltage Category II
Operating
temperature
range
0 °C to 40 °C
Storage
temperature
range
-10 °C to 70 °C
Operating
humidity range
20 % RH to 80 % RH (no condensation)

18
Storage humidity
range
90 % RH or less (no condensation)
Altitude
Up to 2000 m
Dimensions (mm)
ASR-2000
ASR-2000R
285(W)×124(H)×480(
D) (not including
protrusions)
213(W)×124(H)×4
80(D) (not
including
protrusions)
Weight
ASR-2000
ASR-2000R
Approx. 11.5 kg
Approx. 10.5 kg
Others
Protections
OCP, OTP, OPP, FAN Fail
Display
TFT-LCD, 4.3 inch
Memory Function
Store and recall settings, Basic settings: 10
Arbitrary Wave
16 (nonvolatile)
4096 words
A value with the accuracy is the guaranteed value of the specification.
However, an accuracy noted as reference value shows the supplemental
data for reference when the product is used, and is not under the
guarantee. A value without the accuracy is the nominal value or
representative value (shown as type).
External Signal Input (AC+DC-EXT, AC-EXT Mode)
Specification
Factory Default
Gain setting range
100 V range: 0.0 to 250.0 times
100
200 V range: 0.0 to 500.0 times
200
Input terminal
BNC connector
Input impedance
1 MΩ
Input voltage range
±2.5 V (A/D resolution 12 bit)

19
Nondestructive
maximum input voltage
±10 V
Gain resolution
0.1 times
Accuracy
±5 % (DC, or 45Hz ~ 65 Hz, gain is at initial value,
with rate voltage output, no load)
EXT: Output voltage (V) = External signal input (V) x Gain (V/V)
Voltage Setting Signal Input (AC-VCA Mode)
Specification
Factory Default
Gain setting range
100 V range: 0.0 to 250.0 times
100
200 V range: 0.0 to 500.0 times
200
Input terminal
BNC connector
Input impedance
1 MΩ
Input voltage range
DC 0 ~ 2.5 V
Nondestructive
maximum input voltage
±10 V
Accuracy
±5 %
External Signal Input (AC+DC-ADD, AC-ADD Mode)
Specification
Factory Default
Gain setting range
100 V range: 0.0 to 250.0 times
100
200 V range: 0.0 to 500.0 times
200
Input terminal
BNC connector
Input impedance
1 MΩ
Input voltage range
±2.5 V (A/D resolution 12 bit)
Nondestructive
maximum input voltage
±10 V
Input frequency range
DC to 999.9 Hz (sine wave)
DC to 100 Hz (other than sine wave)

20
Gain resolution
0.1 times
Accuracy
±5 % (DC, or 45Hz ~ 65 Hz, gain is at initial value,
with rate voltage output, no load)
ADD: Output voltage (V) = External signal input (V) x Gain (V/V) + Internal
signal source setting (V)
External Synchronous Signal or Line (AC+DC-SYNC, AC-SYNC)
Specification
Factory Default
Synchronization signal
source
External synchronization signal
(EXT) or Power input (LINE)
LINE
Synchronization
frequency range
40.00 Hz to 999.9 Hz
Input terminal
BNC connector
Input impedance
1 MΩ
Threshold of input
voltage
TTL level
Minimum pulse width
500 us
Nondestructive
maximum input voltage
±10 V
Resolution
0.01 / 0.1 Hz
Accuracy
±0.2 Hz
