Gyms SilkyPure HWP-3690H User manual

20
English
Safety precautions
Do not use, keep, or leave the product in the area which
is high temperatures such as near fire, direct sunlight
or inside of a car under the blazing sun.
Doing so might cause ignition or burst.
Do not incinerate the product.
The battery may explode.
Do not put flammable liquids into the product.
Risk of explosion or fire may exist.
Do not heat the product in a microwave oven or put it in
a dishwasher or a dryer.
Otherwise, there is a risk of rupture, electric shock, or the
battery explosion.
Do not charge the product with a wet hand.
Otherwise, there is a risk of electric shock, short circuit, or fire.
Do not get the AC adapter or the USB cord wet.
Otherwise, there is a risk of electric shock, short circuit, or fire.
When generating sterilizing water (hypochlorous acid
water), strong alkaline water comes out from the bottom of
the base part. The place where clothes, leather, cloth, wood
products, etc. adhere may be discolored or deteriorated.
Please be sure to put it on the coaster attached. If it gets on
your fingers or skin, wash it immediately. Please be careful
not to get it into your eyes or mouth.
When it happens to get into your eyes or mouth, wash it
under running water and see a doctor.
<Caution regarding hypochlorous acid water>
Never mix with other acidic and alkaline products. Chlorine
gas may be generated and may be dangerous.
Before charging the product, precautions must be taken
to keep water off and dry near the power connection well.
Otherwise there is a risk of explosion, electric shock, or the
battery explosion.
Use a plug adapter when charging the product outside
the country or region where you purchased it. Use the
product by the specified power source and voltage.
If the voltage or the shape of the plug adapter does not fit in
with the product, it may break down.
Using the product by wrong power source or voltage may
cause fire, scald or electric shock.
AC100V ～240V (It fits in with the household AC outlet.)
Do not place heavy objects on the USB cord, or bundle,
bend, damage, process, pull, twist, or pinch the cord.
Otherwise, there is a risk of electric shock, short circuit, or fire.
Stop using immediately, when the AC adapter or the
USB cord is damaged or heated. In addition, do not use
the product when heat, abnormal smells, or noises are
noticed coming from the base generator.
Doing so might cause electric shock, short circuit, or fire.
Please contact your dealer or our customer support center.
Clean the AC adapter plug, the USB cord connector and
the product power connection port regularly.
Otherwise, there is a risk of electric shock, short circuit, or fire.
Remove all dust, if any, before charging.
Insert the USB cord firmly into the AC adapter or the
Silky pure body.
Otherwise, there is a risk of electric shock, short circuit, or fire.
This instruction manual contains information for the user and others to avoid personal injury or property damage.
Be sure to follow the instructions for safe and proper use.
※Refer to "Names and functions of parts" ( lpage 22) for part names.
■Classification
Ignoring the warning may result in injury, serious injury or death.
Ignoring the cautions may result in property damage or personal injury.
■Symbols
This symbol indicates that you must not do. This symbol indicates that it must not be used near
fire or placed in fire.
This symbol indicates that the product should not be
used where it gets wet.
This symbol indicates that it must not be
disassembled.
This symbol indicates that handling by a wet hand is
not allowed. This symbol indicates that you have to do.

21
English
Safety precautions
When carrying the product filled with water in, make
sure the cap and the bottle screws are tightly closed
and lock the cap.
If they are not closed tightly or the cap is not locked, water
may leak due to some reasons (such as the button on the
cap being pressed with the baggage in the bag).
When carrying the product filled with water in a bag, do
not place it sideways.
If the power is turned on with the product lying down, water
may leak from the pressure reducing valve on the cap.
Do not drop the product or subject it to strong shock.
Otherwise, it could result in deformation or damage of the product.
Do not freeze the product.
Otherwise, it may cause the product to fail or damage.
Do not charge the product with any AC adapters other
than the attached one.
Otherwise, it may cause the product to fail.
When inserting or pulling out the USB cord, be sure to
hold the connector.
Otherwise, it could result in damage or short circuit of the
USB code and a failure of the product.
Do not use the product under water or splash seawater
or hot spring water on it.
This product is water-resistant. However, do not use the
product under water. Furthermore, be careful not to spray
any water other than fresh water on the product.
Otherwise, it may cause the product to fail.
Use normal water or hot water only.
The use of liquid other than water may cause stain, coloring, smell
of the bottle and the electrode plate or failure of the product.
Place the sterilizing water on the coaster attached.
Do not generate the sterilizing water on colored cloths or
painted tables.
Otherwise, it could result in a change of color.
Be sure to clean the inside of the bottle of the product
and the ceramic particle cartridge before using for the
first time. ( lpage 23)
When the ceramic particle cartridge is replaced, clean
the new one before using. ( lpage 23)
When cleaning the inside of the bottle of the product,
remove the ceramic particle cartridge and clean it with
neutral detergent and soft sponge. ( lpage 26)
Do not use abrasives or metal brushes.
Clean the inside of the product and the ceramic particle
cartridge daily.
Do not apply hot water (above 70 °C) to the cap and the
electrode plate and sterilize them by boiling.
There is the risk of paint peeling.
Do not soak the base generator in water.
Wipe off the moisture of the base generator well.
Otherwise, it could result in failure of the product.
When using the ceramic particle cartridge,
recommended water quantity is 360cc or less.
If you put too much water, it may overflow when the cap is
closed.
However, if the amount of water is too little to reach the
ceramic particle cartridge, chlorine odor may not remove.
Do not attempt to disassemble or alter the base
generator by yourself.
Otherwise, there is a risk of electric shock, short circuit, or fire.
It is not covered by the warranty.
A person with a pacemaker or any other internal device
should not drink during the hydrogen generation.
The weak current in the water during hydrogen generation
may affect a function of the internal device.
A person whose water intake is restricted should
consult with a doctor before drinking.
It may affect your physical condition.
Drink the generated hydrogen water immediately
without keeping it.
Otherwise, there is a risk of food poisoning.
Sterilizing water is not drinkable.
Keep the product out of reach of infants.
It may cause accidental ingestion of parts or trouble.
When using hot water, wear gloves or use a dry cloth to
prevent scald.
The product may be hot and cause scald.
When using hot water, check the temperature before drinking.
It may cause scald if you drink directly.
Try to drink hot water after pouring into another vessel.
When using hot water, keep the water level below the
bottle screw. ( lpage 25)
Hot water may spout and cause scald.

22
English
Names and functions of parts
■Ceramic particle cartridge
Chlorine odor generated during electrolysis can be reduced by using the ceramic particle cartridge attached.
.● Please use the ceramic cartridge when generating hydrogen water with tap water. When using hot water, mineral water, or pure water,
remove the ceramic particle cartridge. (If purified water from a water purifier has chlorine odor, use the ceramic particle cartridge.)
The ceramic particle cartridge is consumable. Replace the ceramic particle cartridge when the generated
hydrogen water smells of chlorine.
.● The approximate time for replacement is about 2 years in case of using 2 liters a day. It is also time for replacement when the
ceramic particles turn red in the ceramic particle cartridge.
Notice
.● If the water level in the bottle is too low to reach the ceramic cartridge, chlorine odor may not remove.
■Lock function of the cap
The cap has a one-touch opening system and a locking function.
Be sure to lock the cap when carrying the product.
The cap is locked when the button is
set to the bottom position.
The cap is unlocked when the button is
set to the up position.
In the state the button unlocked, the
cap lid opens by pressing the button.
Lock button
Press to open the cap lid. (Unlocked status)
Please lock the cap button when carrying the product. ( lsee below)
Cap lid
Cap base
Ceramic particle cartridge ( lsee below)
Bottle
Base generator
Base generation button
Press the button to generate hydrogen water or sterilizing water. ( lpage 24)
Serial number
Inside of the cap
Inside the base
generator (back)
Insertion screw hole of the ceramic particle
cartridge
Base generator packing
Cap packing
LED Blue light : Hydrogen water is generating
Green light : Sterilizing water is generating
Red light : Charging
Orange light : Charging is completed
Electrode plate
Power connection port
It uses for charging. ( lpage 24)

23
English
■Removal
1 Turn the cap and the base generator
counterclockwise.
2 Turn the ceramic particle cartridge counterclockwise
while holding the cap.
■Installation
1 Turn the ceramic particle cartridge clockwise while
holding the cap.
2 Turn the cap and the base generator clockwise.
Before installation, make sure that the packing of the cap and the
base generator are installed.
After installation, make sure the cap and the base generator are
securely attached.
3 Pour water into the bottle of the product and check
the water leakage.
Close the cap lid firmly, then shake the product up and down to
check the water leakage.
Removal / Installation of parts
Loosen
Tighten
Tighten
Tighten
Loosen
Loosen
When using the product for the fi rst time
When using the product for the first time, remove the parts and wash them well.
■Cap・Bottle・Base generator
Wash them well with neutral detergent.
For details, refer to "How to care" ( lpage 26).
.● Do not use a dishwasher or a dryer.
.● When washing the base generator, close the cap of the power connection port firmly.
.● Since the product is made of plastic, please use soft sponge, etc.
.● At the beginning of use, the inside of the generator is dry.
For this reason, the hydrogen concentration of the generated hydrogen water and the sterilizing capacity of the generated
sterilizing water may not reach the specified values.
.● Generation performance may not be fully demonstrated for a while after using the product for the first time.
As a guide, the condition will continue for about one month. (When using the product three times a day.)
■Ceramic Particle cartridge
Place the ceramic particle cartridge removed in a cup or another
container and wash by shaking it for about 10 minutes in running water.
.● Use a container big enough to soak the ceramic particle cartridge in water.
(A cup is suitable.)
.● Shake the ceramic particle cartridge well in the container.
If the shaking is not enough, the ceramic particle cartridge may not be washed perfectly.
.● If you use the ceramic particle cartridge without washing or in an insufficiently washed
state, the generated hydrogen water may smell.
.● When the ceramic particle cartridge is replaced, clean the new one in the same way.
.● The ceramic particle cartridge contains calcium balls. The calcium balls will deteriorate.

24
English
Charge
The battery has not been charged sufficiently when shipped. Charge the battery before using it.
2
13
The power connection port
Groove
.● If you do not charge for a while, the battery
may discharge electricity and be unusable.
It is recommended to charge the battery
frequently.
Required charging time is about 3 hours
in case of a dead battery.
1 Open the cap of the power connection port.
2 Insert the exclusive USB cord connector
into the power connection port, so that the
grooved side is downward.
Make sure that the grooved side of the USB cord
connector faces downward and insert it into the power
connection port firmly and horizontally.
3 Insert the connector of the exclusive USB
cord into the AC adapter attached and plug
it into an outlet.
The LED lights up red, and charging starts.
When the charging is completed, the LED lights up orange.
Notice
.● It is also possible to charge by connecting the USB code to a USB
port on a computer.
.● When charging the battery using PC port, there is a case that the LED
does not light up in red, or the LED flashes. In this case, the charging
voltage is not high enough. Try changing the connection port.
.● When the remaining battery capacity is low, the LED may turn off during
generation (before the specified time). In this case, charge the battery
for 15 minutes or longer and generate the hydrogen water again.
.● Remove the AC adapter from the outlet when not in use.
.● The AC adapter attached is manufactured for use in Japan. It can
be used, however, in any other country other than Japan.
.● Because the shape of the power outlet varies depending on the
country and region, a plug adapter is required. Please purchase a
plug adapter after consulting with a travel agency or dealer.
Generate hydrogen water, sterilizing water (hypochlorous acid water) or ozone water
The amount of generation (the amount of foam) is small at the beginning of use, so pour 50 ccs of tea (green tea, black tea, etc.) into
the bottle, keep it in place for 1 hour or more and wash it before use. If you continue to use the product and the amount of bubbles
decreases again, do the same operation.
1 Open the cap, fill the bottle with water and close the cap.
.● When using hot water, mineral water, pure water, sterilizing water or ozone water, remove the ceramic particle cartridge.
.● When using hot water lpage 25
When generating hydrogen water
When the ceramic particle cartridge is installed : Water volume is 360cc or less
When the ceramic particle cartridge is not installed : Water volume is 380cc or less
When generating sterilizing water (hypochlorous acid water)
Remove the ceramic cartridge, pour water into the bottle, and add 1 gof purified salt (a spoon full of salt) to it. Never stir it. If you
stir it, the effective chlorine concentration will be 1/10 or less.
When generating ozone water
Please pour 100 cc of tap water into the bottle.
2 When generating hydrogen water
Press the generation button twice or three times continuously (within 3 seconds).
Twice continuation: 1 minute mode 3 times continuation: 3 minutes mode
.● If you do not press the number of times in succession, the power will not turn on and generation
will not start.
When generating sterilizing water (hypochlorous acid water)
Press the generation button for 3 seconds or longer.
.● When generating sterilizing water (hypochlorous acid water), water droplets may come out of the
hole on the bottom of the base generator. So please use the attached coaster.
When generating ozone water
Press the generation button for 3 seconds or longer.

25
English
Caution
.● When generating sterilizing water (hypochlorous acid water), strong alkaline water comes out from the bottom of the base part.
Please be sure to put it on the coaster attached. If it adheres, it may cause discoloration. After generationg sterilizing water,
generate hydrogen water (3 minutes) with tap water and discard. Normal hydrogen water generation will be impossible without
that operation. Please note that after sterilizing water generation, the strong alkaline water that remains in the base generator may
come out due to vibration.
Notice
.● Stir the sterilizing water (hypochlorous acid water) in the bottle and then dilute it 10 times before use.
When using it for new coronavirus, dilute it 2-3 times. It is also possible to use it without dilution.
After generation, chlorine odor will remain in the bottle.Thoroughly clean after use.
.● If the LED turns off during generation (before the specified time), the remaining battery capacity is low.
Try to generate the water again after charging for more than 15 minutes.
.● Bacteria tend to increase faster in hydrogen water than in tap water.
Do not drink the generated hydrogen water that has been left for a long time.
.● Hydrogen is easier to escape as the water temperature, air temperature or room temperature increases.
It is recommended to generate the hydrogen water left in the product again after time passed for a while to increase the hydrogen
concentration.
.● Hydrogen concentration of generated hydrogen water varies depending on the water quality.
.● Remove the ceramic particle cartridge from the cap and dry it after use. Humidity of the ceramic particle cartridge may promote the
growth of mold and the function of the ceramic particle deteriorates quickly.
.● When generating sterilizing water or after that generating hydrogen water, strong alkaline water will come out from the bottom of
the base generation. So be sure to use a coaster and wipe the bottom well with a cloth. Please note that after sterilizing water
generation, the strong alkaline water that remains in the base generator may come out due to vibration.
.● Sterilizing water is not drinkable.
.● Please use sterilizing water for sterilization and deodorization.
.● Do not generate sterilizing water repeatedly with the same water.
Do not generate sterilizing water with more than the specified amount of purified salt. Otherwise, it may cause the product to fail.
.● When cleaning the coaster and the bottom of the base, use rubber gloves to prevent the strong alkaline water from touching your
skin.
.● After using the coaster, wash with running water and dry it well. Otherwise, it will be easy for mold to grow on the coaster.
■When using hot water
Be sure to keep the water level below the bottle screw. (right illustration: below the red line)
.● Since the temperature of the bottle gets high, wear gloves or use a dry cloth to prevent scald.
.● It may cause scald if you drink directly. Try to drink hot water after pouring into another vessel and
check the temperature of water.
.● Remove the ceramic particle cartridge before use.
■When storing Silky Pure
Pour 100 cc of water into the bottle and press the generation button for 3 seconds or more to generate ozone water. After generation,
shake the bottle once or twice to disinfect the bottle. To prevent the membrane from drying, keep it with ozone water in it.
Even if you do not use it, wash it every 3 days and replace it with water to generate ozone water.
■When keeping sterilizing water
Please keep it in a cool and dark place. Please use it within one week. When diluted, please use it as soon as possible.
Depending on the container and storage method, the concentration of hypochlorous acid will be low and the effect will reduce.
3 After the LED flickers, it will light up and make a sound, and generation will
start after about 2 seconds.
Hydrogen water (1 minute mode) : Beep・Blue light flash up once ⇒Blue lights up
Hydrogen water (3 minutes mode) : Beep・Blue light flash up 2 times ⇒Blue lights up
Sterilizing water・ozone water (5 minutes) : Long beep・Green light flash up 2 times ⇒Green lights up
.● When you press the generation button 5 times continuously, the sound can be switched on and off.
On: Beep (Once) Off: Beep-beep (Twice)
.● When you want to stop generation, press the generation button once.
4 When generation is completed, beep-beep sounds and the LED turns off.
.● When the remaining battery capacity is low, the LED flashes up in red five times after generation
completed.

26
English
When you think“Is it a failure?”(Troubleshooting)
When you think“Is it a failure?”Please read the following. If you still have the problem after reading this
instruction manual, please make contact with your dealer or our customer support center.
The generation does not start when you press the generation button.
.● Press the generation button twice (or 3 times) in a row.
When generating sterilizing water, press the generation
button for 3 seconds or longer.
Water leakage.
.● Make sure that the cap is securely closed.
.● Make sure that the packings of the cap and the base
generator are installed. ( lpage 22)
.● Make sure that the cap and the base generator are screwed
firmly into the bottle. ( lpage 23)
.● When generating sterilizing water, water droplets may come
out of the hole on the bottom of the base generator. It's not a
malfunction. Please use the attached coaster.
Water overflows.
.● Is there too much water in the bottle? Please follow the
information about the amount of poured water below.
When the ceramic particle cartridge is installed: 360cc or less
When the ceramic particle cartridge is not installed: 380cc or less
When using hot water: Keep the water level below the bottle
screw. ( lpage 25)
LED turns off during generation (before the specified time).
.● The remaining battery capacity is low.
Try to generate the water again after charging for 15 minutes
or more.
Unable to charge battery.
LED does not light up in red.
LED flickers red.
.● Make sure that the exclusive USB code connector is firmly
inserted into the base generator.
The connector has a top side and bottom side. ( lpage 24)
.● Make sure that the AC adapter is firmly plugged into an outlet.
.● If the USB cord is connected to a USB plug of a computer,
make sure it is turned on.
.● Some computers have low voltage power ports. Try changing
the connection port.
How to care
Clean the inside of the product daily for hygienic use.
Remove the parts and clean them as follows. (How to remove parts lpage 23)
Notice
.● Do not use a dishwasher or a dryer.
.● Please note that if you use neutral detergent with a strong scent, it could be transferred to the product.
■Ceramic particle cartridge
Rinse the ceramic particle cartridge with water. Then wipe the ceramic
particle cartridge with a towel and dry it in a well-ventilated place.
.● Since stain on the ceramic particle cartridge may cause smell, it should be
cleaned and dried daily. Humidity of the ceramic particle cartridge may promote
the growth of mold and the function of the ceramic particle deteriorates quickly.
■Bottle
Apply mild detergent to a soft sponge, wash the
bottle with gentle stroke, and rinse it well.
.● Do not boil the bottle in hot water for cleaning.
Otherwise, the bottle may shrink.
.● Do not rub with force. Otherwise, there is a risk of scratch.
■Base generator
Apply mild detergent to a soft sponge, wash the base generator with
gentle stroke, and rinse it well.
The packing of the base generator is removable, so clean it regularly.
.● Make sure to close the cap of the power connection port firmly when
you clean the base generator.
.● If white deposits such as calcium are observed on the electrode
plate, pour about 60 °C hot water into the base generator and add
commercial pot cleaner or about 5 gof citric acid. Dissolve the citric
acid well and wash the base generator for 12 hours. When cleaning
the product in this way, remove the ceramic cartridge.
.● Apply running water to the bottom of the generator to wash away the
strong alkaline water. Wipe the bottom of the base with a cloth well.
Please note that after sterilizing water generation, the strong alkaline
water that remains in the base generator may come out due to vibration.
.● Wash the coaster with water and dry it well. Use rubber gloves when
cleaning the base generator or the coaster.
Base generator packing
■Cap
Apply mild detergent to a soft sponge, wash the
cap with gentle stroke, and rinse it well. Then wipe
the cap with a towel.
The tap packing and the cap packing are
removable, so clean them regularly.
Tap packing
Cap packing

27
English
Product Specifi cations
Dimensions φ75 mm ×220 mm
Weight 280 g(
When the ceramic particle cartridge is installed )
Capacity
When ceramic particle
cartridge is not installed
380 cc
When ceramic particle
cartridge is installed
360 cc
Power supply Battery type
Lithium-Ion Battery
Battery capacity 1400 mA/h
Charging time About 3 hours
USB input DC5 V, 1.0 A
Material Cap PCT resin
Bottle PCT resin
Base generator PCT resin
Electrode plate Titanium + platinum
plating
Packing Silicon
AC adapter
(PSE standard
product)
Power supply AC100 V - 240 V,
50 Hz/60 Hz, 0.2 A
Output DC5 V, 1.0 A
Hydrogen
concentration
(ORP)※1※2
Water
(3 minutes mode)
About 1000 ppb, About -600 mV
Water
(1 minute mode)
About 550 ppb, About -400 mV
Hot water About 600 ppb, About -550 mV
Sterilization
ability※1※2※3
pH: 2.9～3.5 (When generated)
Effective chlorine concentration 200～240ppm
(When generated)
.● Please use it after diluting 10 times.
.● When using it for new coronavirus, dilute it
2-3 times. It is also possible to use it without
dilution. ※4※5
Ozone water About 20 ppb
The practical use
number of times
※6
Hydrogen water
(3 minutes mode)
About 15 times
Sterilizing water About 15 times
※1 This is the value measured when the battery is fully charged.
※2 Values vary depending on water quality.
※3 When generating sterilizing water with tap water and 1gof purified salt.
※4 When using it for wiping, remove dirt (organic substances: hand stains,
oils, etc.) in advance.
※5 If you are sensitive to chlorine, adjust the dilution amount before use.
※6 This is the practical use number of times of the product when the battery
is fully charged. (an approximate number).
■Water-resistant
This product is water-resistant (IP55). IP55 indicates that the level
of protection against human bodies and solids is 5, and the level of
protection against water invasion is 5.
Notice
.● Specifications are subject to change without notice for improvement.
.● Specifications and design described in this document are as of
December 2019.
Please note that the warranty does not cover the following cases.
※Failure to present this warranty. (including the absence of the
date of purchase and the name of the distributor)
※When the sticker indicating the serial number is not attached to
the above of the power connection port. (when the serial number
is unknown)
※In the event of damage due to intentional or inadvertent acts or
malfunction due to disassembly or modification of the base generator.
※In case of damage due to transportation after purchase.
※
Malfunction is caused by peripheral devices other than this product.
※In the event of damage or malfunction due to natural disasters
such as fire, earthquake, wind, and flood.
※
In the event of damage or malfunction caused by wrong use
method that does not follow directions of the instruction manual.
※When consumables run out and be replaced.
.● If you have any questions about repair after warranty period please
make contact with the dealer from which the product was purchased
or our customer support center.
.● The certificate is not reissued. Keep it carefully.
.● The warranty is valid only in Japan and China.
Warranty
The warranty period is one year from the date of
purchase. (Accessories excluded）
Under warranty, repair or replacement of defective
parts shall be performed free of charge in case of
malfunction, except the cases occurs mentioned
below. When requesting free repair, please make
contact with the dealer that you purchased from or
our customer support center, with this warranty book.
製品保証書 /产品保修书 /
Product warranty
製造番号
出厂序号
Serial number
HWP-369OH
ご購入日
购入日期
Date of purchase
..年 月 日
.Year .Month .Day
お客様名
顾客姓名
Customer Name
ご住所
住所
Address
〒 －
電話番号
电话
Telephone number
（ ）
販売店名
销售店名
Dealer name

株式会社.ジームス
https://wwwgymscojp
お問い合わせ先 オンラインストア
ジームス カスタマーサポート
0800-888-3369.
（フリーダイヤル）
受付時間.10 時～ 17 時
（土・日・祝日、年末年始、夏季休業を除く）
e-mail.:[e-mail]
WeChat.ID:.江田水素Gyms
ジーム ス オンラインストア
https://www.gyms.co.jp/OS/index.html
（日本国内のみ発送）
株式会社ジームス
〒104-0041.東京都中央区新富1-6-1
200630
