Gyration Cyberview3010 User manual

User manual
Smart Battery Camera
Solar Recharging Kit
Cyberview3010

Packing list
1. Camera ×1
2. Bracket ×1
3. Mounting kit ×1
4. USB charging cable ×1
5. Operation instruction ×1
1. Solar Panel ×1
2. Mounting bracket ×1
3. Screws ×4
4. Wall Anchors ×3
Camera: Solar panel:
01

Product appearance
Human body
infrared sensor
Infrared light
Indicator light
Wi-Fi antenna
Microphone
Spotlight
Lens
Mounting bracket
Solar panel
02

Reboot button
Micro-SD card slot
Micro-USB Port
Power button
DC-5V
03

Quick start
The wireless smart battery camera supports DC power supply.
The wireless smart battery camera supports Android and iOS App.
For your best experience, please scan the QR code below with your
mobile phone, install the app, and follow the instruction to
complete the user registration.
Sign in to App，connect to Wi-Fi and add the device according to
the prompts (please bring the device close to the router when
configuring).
1. Download and install the App
2. Add the device
Scan QR code or go to the link to download and install
the App：https://www.cyberviewplus.com/download/
Android
Download
Download
App Store
04

Power on/o and
network configuration
Long press the power button for 3s to power on/o the device.
Double click the power button to enter the network configuration
mode after the prompt tone.
When connecting the camera for the first time, use the App and
follow the instruction to configure the camera network.
05

Possible problems with binding:
06
When you hear the "Wi-Fi Password Error", please check whether
the Wi-Fi password you entered in the App is correct.
When you hear the "Authentication error", please ensure that your
Wi-Fi network is not an enterprise-level network, and the device
supports only the network with the security level below WPA-2.
When you hear the "Wi-Fi not found", please check whether you
select or enter the correct Wi-Fi name, and place the device near
the Wi-Fi router and ensure that the router is powered on. Please
note that 5Ghz Wi-Fi cannot be searched by the device.
When you hear the "Retrieving IP timeout", it indicates that the
number of devices connected to the router in your home is too
many to connect more devices. Please remove some of the
connected devices that are not commonly used or restart the
router to clear the unconnected devices. You may need to contact
the router administrator.
When you hear the "Cloud service connection fail", please check
whether your router is connected properly to the external
network. When you hear this error prompt, it is common on the
condition of network disconnection or that the selected router in
your home is a local area network server. Please ensure that the
network connection is normal, and try to temporarily turn o the
firewall to connect again.

Bind the camera
1) Click the "Add Now" button in the app, press and hold the camera
switch button for 3 seconds to turn on the camera, and the app will
automatically search for devices that are on and not bound. Select
the device you want to bind in the search results for the next step.
2) Enter the name and password of the Wi-Fi network you want the
camera to connect to. To ensure longdistance connection, the
camera only supports 2.4GHz WiFi network with stronger wall
penetration capability and does not support Wi-Fi with enterprise
level authentication.
07

3) After a while, the camera will play a sound indicating that the
connection is successful. At this point, please set a name for the
camera on the app and select the location where you want to place
the camera. Click Finish to complete the pairing.
Please make sure that the Wi-Fi meets the requirements, click Next
after completion, and the app can try to connect the camera to the
Wi-Fi.
08

Install the camera
(1) Select a good spot for your camera
Select a good spot for your camera, please install the camera in a
position where its view is not blocked and ensure that it is within
the coverage of the WiFi network. The PIR infrared sensor is more
sensitive to movements across the camera's field of view than
movements toward or away from the camera.
You can place the camera on a shelf or other surfaces to use, or you
can install it on a wall to use.
About 15° downward
Recommended
height about 6 ft
09

(2) Install the bracket
1) Screw fixing
Use the drilling tool to punch holes on the wall according to the hole
distance of the base. It is recommended to mark the holes on the
wall with a pencil before drilling. Screw the expansion nut into the
holes on the wall, and then connect the bracket to the expansion
nut with screws to complete the fixing.
2) Fix the camera
Align the racket screw with the screw hole on the back or bottom of
the camera, and then rotate it to the tightened state.
10

3) Adjust the angle
Adjust the camera to an appropriate angle, the best angle is about
15 degrees downward, and then tighten the base by rotating it in
clockwise direction to fix the angle.
About 15° downward
11

Install the solar panel
When adjusting the solar panel left or right,loosen the locking screw
cap,turn the sleeve rod,and tighten the locking screw cap when the
panel is in position.
Locking screw cap
Locking screw capSleeve rod
12

How to position your solar panel
Solar panel’s angle can be adjusted up and down up to 90°.
Tip:After the installation is complete,please check that all locking
mechanisms are tightly secured.
Find the area that gets the most direct sunlight throughout the
day
Angle the solar panel upward 30°.
Point it south if in the northen hemisphere and north if in the
southern hemisphere.
°
13

Share the camera
When you need to view the camera with other family members or
friends, you can use this function. Only the administrator whose
account is bound with the camera for the first time can share and
set the device. Other members can only view the live or playbacks of
the device.
2) Click "Invite", and a QR code will be generated for sharing.
4) Scan the QR code on your mobile phone, and you will receive the
confirmation notification after success. The sharing will be completed
after you agree.
3) For the members you need to share, find "Add Friend’ s Camera"
in the "User" page to enter the scanning page.
1) Find the camera you want to share on the App homepage or
camera setting page. Find the button and enter the sharing page.
14

Charge the camera
App will remind you to charge your camera when the battery is low.
Please use the Micro USB cable to plug into the 5V/1.5A charging
adapter to charge the camera. During charging, the camera's
indicator light is solid yellow, and when the camera is fully charged,
the indicator light will turn into solid green. It will take 10 hours to
fully charge the camera.
15

16
Indicator light status
Product specification
Working mode
Sleep mode
Charging mode
Fully charged mode
Blue
O
Yellow
Green
Mode Status
Field of view
Image resolution
Video bit rate
Storage media
Battery capacity
Adapter requirement
Size
95° horizontal, 55° vertical
2304 X 1296
Adaptive
Micro SD card (Up to 128GB)
9000mAh
5V/1.5A
81.3×119.2×80.6 (mm)
Item Specification

Firmware upgrade
When you connect your camera through the App, it will prompt you
if the latest firmware is available. You can also manually check the
firmware upgrade in the settings of the App.
FCC warning
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions:
(1) this device may not cause harmful interference.
(2) this device must accept any interference received,including
interference that may cause undesired operation.Any changes or
modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the
equipment.
NOTE: This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning
the equipment o and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit dierent from
that to which the receiver is connected.
17
Please make sure that your camera is fully charged or connected
to the power adapter before upgrading the firmware, please do
not cut o the power supply duringthe upgrading

FAQ
A: Open the App and select your camera on the home page. Click the
share button on the home page or the "Share" in the camera settings
to enter the sharing page, and then click "Invite" to generate a QR
code. Your friends can now get some of the access rights by
scanning the QR code in your phone.
1. Q: Camera permission management: How to invite family
and friends to use my camera together?
A: On Apple devices with iOS 13 and above, you need to turn on the
"location permission" for the app in the system settings and change
it to "allow when using".
2. Q: Why doesn't the Wi-Fi name appear when I connect to Wi-Fi?
A: The built-in infrared lamp beads make the camera only show
some dim red lights when night vision is activated, but the image
quality is still clear under no light environment.
3. Q: Will the camera show red lights when night vision is activated?
A: Please use a 2.4GHz wireless network. The device does not
support the 5GHz wireless network. Meanwhile, please set the Wi-Fi
authentication method to WPA2-PSK or other lower level of security
method. A password is required.
4. Q: What are the requirements for Wi-Fi?
Consult the dealer or an experienced radio/TV technician for help.
To maintain compliance with FCC’ s RF Exposure guidelines, this
equipment should be installed and operated with minimum distance
between 20cm the radiator your body: Use only the supplied
antenna.
18

A: After testing, the Wi-Fi connection distance can normally reach
up to 150 meters in the open area. However, the actual situation
depends on the strength of Wi-Fi and its surrounding environment
(thick walls, electromagnetic devices, large metal objects will all
cause interference to the Wi-Fi signals). If the camera connection
signal is weak or unstable, please place the camera as close to the
router as possible.
5. Q: How far should the camera be placed from the router?
A: If you set the duration as "Auto", when someone occurs in the view
of the camera, it will start recording a video for up to 3 minutes.
6. Q: What is the maximum length of recording time?
A: Click the icon in the upper left corner of the "Library" page to
start filtering videos by category. Select the category you want to
see and then click "Save" to view the video playbacks.
7. Q: How to quickly view videos by category?
A: Long press the power button to restart it. If there is no response,
you can remove the rubber plug at the bottom of the camera. Press
the reboot hole for 3 seconds with a pointed object to restart the
camera.
8. Q: What should I do when the device is in malfunction?
19
