Hägglunds Fusion Instruction Manual

Hägglunds Fusion
Drive system
RE 15345-WA, Version: 11.2022, Replaces: New, EN
INSTALLATION & MAINTENANCE MANUAL

The data specied only serve to describe
the product. No statements concerning
a certain condition or suitability for a
certain application can be derived from
our information. Catalog specications do
not constitute assured characteristics. The
information given does not release the user
from the obligation of own judgment and
verication. It must be remembered that our
products are subject to a natural process of
wear and aging.
© This document, as well as the data,
specications and other information set forth
in it, are the exclusive property of Bosch
Rexroth AB. It may not be reproduced or
given to third parties without its consent.
Changes in the equipment may occur. We
therefore reserve the right to introduce
amendments in the manual as we deem
necessary without notice or obligations.
This Installation and maintenance manual
is valid for drive systems manufactured
after 01.01.2022. For older drive systems
please contact your nearest Bosch Rexroth
representative.
The cover shows an example application. The
product delivered may differ from the image
on the cover.
Original instruction manual

RE 15345-WA, Version 11.2022, Bosch Rexroth AB
Contents | Hägglunds Fusion Drive system 3/72
Contents
1 This documentation ................................................................................... 5
1.1 Validity of the documentation........................................................................5
1.2 Required and additional documentations ......................................................5
1.3 Presentation of information ...........................................................................5
2 Safety instructions .................................................................................... 7
2.1 About this chapter .........................................................................................7
2.2 Intended use..................................................................................................7
2.3 Improper use .................................................................................................8
2.4 Personnel qualications ................................................................................8
2.5 General safety instructions............................................................................9
2.6 Product-specic safety instructions .............................................................10
2.7 Personal protective equipment....................................................................12
3 General notes regarding property damages and product damages........... 13
4 Scope of delivery..................................................................................... 15
5 About this product................................................................................... 15
5.1 Product description.....................................................................................15
5.2 Product identication ..................................................................................15
5.3 Main components ........................................................................................16
5.4 Hydraulic uids ...........................................................................................18
5.5 Requirements for hydraulic uid cleanliness ...............................................19
5.6 Drive system monitoring ..............................................................................20
6 Transport and storage.............................................................................. 21
6.1 Storage of the packed drive system ...........................................................21
6.2 Lifting the packed drive system ...................................................................22
7 Installation.............................................................................................. 23
7.1 Installation directives ..................................................................................23
7.2 Lifting methods ..........................................................................................23
7.3 Positioning the drive system .......................................................................25
7.4 Required tools .............................................................................................26
7.5 Drive system mounting ................................................................................27
7.6 Electric connections ....................................................................................37
8 Commissioning ........................................................................................ 40
8.1 Before commissioning .................................................................................40
8.2 Filling up the system with hydraulic uid ....................................................41
8.3 Initial start up procedure.............................................................................44
8.4 Pump settings and adjustments...................................................................46
8.5 Hägglunds BICA Brake .................................................................................50

4/72 Hägglunds Fusion Drive system | Contents
Bosch Rexroth AB, Version 11.2022, RE 15345-WA
9 Maintenance and repair ........................................................................... 50
9.1 Maintenance log ..........................................................................................50
9.2 Preventive maintenance ..............................................................................50
9.3 Filter change................................................................................................53
9.4 Inspection of hydraulic uid ........................................................................55
9.5 Air lter breather change .............................................................................56
9.6 Electric motor..............................................................................................57
9.7 Cleaning of air oil cooler .............................................................................58
9.8 Drive system out of service..........................................................................59
9.9 Repair..........................................................................................................60
9.10 Flushing after repair ....................................................................................60
9.11 Spare parts..................................................................................................62
10 Removal and replacement ....................................................................... 63
10.1 Required tools .............................................................................................63
10.2 Common......................................................................................................63
11 Disposal .................................................................................................. 65
11.1 Environmental protection ............................................................................65
12 Extension and conversion ........................................................................ 65
13 Troubleshooting ...................................................................................... 66
14 Technical data ......................................................................................... 70
14.1 Weights ......................................................................................................70

RE 15345-WA, Version 11.2022, Bosch Rexroth AB
This documentation | Drive system Hägglunds Fusion 5/72
1 This documentation
1.1 Validity of the documentation
This documentation applies to the Drive System, Hägglunds Fusion, European and
American version, and is intended for machine/system manufactures, tters and
service engineers.
Hägglunds Fusion is a exible product with a wide option range, this installation
and maintenance manual is intended to cover all these options. Some options
might not be included in the delivered drive system, see order specic
documentation for the exact content.
This documentation contains important information required to transport,
install, commission, operate, use, service and dismantle the product safely and
professionaly.
fRead this documentation completely before using the Hägglunds Fusion
1.2 Required and additional documentations
fBefore commissioning the product, make sure to have received and fully
understood the documentations identied by the book symbol and observe
the instructions included in these documentations.
Table 1: Necessary and supplementary documentation.
Title Document no Document type
Order conrmation Order specic Order conrmation
Order documentation Order specic E.g. hydraulic and electric diagrams,
bill of material, specications
Hägglunds CA* RE 15305-WA Installation & maintenance manual
Hägglunds CB* RE 15302-WA Installation & maintenance manual
Hägglunds BICA brake** EN 643 Installation & maintenance manual
Hägglunds Spider 2** RE 15330-WA User manual
HJägglunds Fusion RE 15345 Data sheet
Hägglunds Torque arms RE 15355 Data sheet
Hägglunds SPDC RE 15350 Data sheet
Hydraulic uid quick reference
Hägglunds products
RE 15414 Data sheet
Axial piston variable pump
A4VG series 32 Europe
92003-01-B Instruction manual
*Depending on the hydraulic motor type in the drive system
** Required if included in scope
1.3 Presentation of information
Consistent safety instructions, symbols, terms and abbreviations are used in the
present documentation to facilitate orientation for the reader and to ensure safe
product handling. The explanations in the following sections will provide for easy
understanding.

6/72 Hägglunds Fusion Drive system | This documentation
Bosch Rexroth AB, RE 15345-WA Version 11.2022,
1.3.1 Safety messages
This documentation includes safety messages placed before sequential operating
procedures that may involve the risk of personal or property damage. The
described precautionary measures must be observed.
Safety messages are structured as shown below:
SIGNAL WORD
Type and source of risk
Consequences if disregarded
fPrecautionary measures
f<listing>
• Warning sign: draws attention to the risk
• Signal word: identies the hazard level
• Type and source of risk: identies the type and source of the hazard
• Consequences: describes what occurs when the safety messages are of non
compliance type
• Precautions: indicates how the hazard can be avoided
Table 2: Risk categories to ANSI Z535.6-2006
Warning sign, signal word Meaning
DANGER Indicates a hazardous situation which, if not avoided, will
result in death or serious injury.
WARNING Indicates a hazardous situation which, if not avoided, could
result in death or serious injury.
CAUTION Indicates a hazardous situation which, if not avoided, could
result in minor or moderate injury.
NOTICE Indicates potential property damage: the product or the
environment may be damaged.
1.3.2 Symbols
The following symbols identify notices that are not safety-relevant, but enhance
the comprehensibility of the documentation.
Table 3: Meaning of the symbols
Symbol Meaning
When this information is not observed, optimum use or operation of the product
cannot be ensured.
fSingle, independent step
1.
2.
3.
Numbered instructions:
The number indicates that the different steps are to be performed successively.
Center of gravity
Markings on packaging to indicate where the center of gravitiy are.

RE 15345-WA, Version 11.2022, Bosch Rexroth AB
Safety instructions | Drive system Hägglunds Fusion 7/72
2 Safety instructions
2.1 About this chapter
This product has been manufactured in strict compliance with the generally
accepted rules of technology. However, this does not exclude the risk of damage
to persons or property if this chapter and the safety instructions included in the
present documentation are not observed.
fRead this documentation carefully before starting to use the product.
fKeep this documentation in a location where it is accessible to all users at any
time.
fWhen providing the product to third parties, make sure to include the
necessary documentation.
2.2 Intended use
The Hägglunds Fusion is a hydraulic drive system.
In the application the Hägglunds Fusion drive system is classied as a partly
completed machinery in the sense of the EU machine directive 2006/42/EC,
Appendix IIB. A partly completed machinery is exclusively intended to form an
incomplete or a complete machine together with other components or partly
completed machineries. The drive system may only be commissioned after it has
been installed in the machine/system for which it is intended and the safety of the
entire system has been established in accordance with the machine directive.
Intended use includes having read and understood the complete documentation,
especially the chapter 2: Safety instructions.
The product is intended for the following use:
• Closed loop hydraulic system to convert electric energy to mechanical rotation of
a shaft.
Special drive systems
Standard drive systems are not allowed to be used outside an ambient
temperature range of -20 °C to 40 °C (-4 °F to 104 °F), or in areas with potentially
explosive atmospheres.
Drive systems intended for use in ambient temperature below 0 °C (32 °F), can be
tted with special optional equipment for preheating the hydraulic system before
start.
Observe the technical data, application and operating conditions and performance
limits as specied in the product-specic documentation and in the order
conrmation.

8/72 Hägglunds Fusion Drive system | Safety instructions
Bosch Rexroth AB, RE 15345-WA Version 11.2022,
2.3 Improper use
Any use other than that described as intended use shall be considered as improper
and is therefore impermissible.
Bosch Rexroth shall accept no liability whatsoever for damage resulting from
improper use. The user shall bear all risks arising from improper use.
Similarly, the following foreseeable faulty usages are also considered to be
improper:
• Using outside the operating parameters approved in the product specic data
sheet or in the order specic documention.
• Use of uids outside of the standards as specied in RE15414 Hydraulic uid
quick reference.
• Modication of factory settings by non-authorized persons
• Use of add/on parts (e.g. mountable lter, control unit, valves) that are not
specied by Bosch Rexroth has to be approved by contact at Bosch Rexroth.
• Extension or conversion is not permissible and has to be approved by contact at
Bosch Rexroth.
• Using the drive system in explosive environments unless the component or
machine/system has been certied as compliant with the local regulations.
• Using the drive system in an aggressive atmosphere without necessary additional
measures.
2.4 Personnel qualications
The activities described in this documentation require basic mechanical, electrical
and hydraulic knowledge, as well as knowledge of the associated technical terms.
For transporting and handling the product, additional knowledge is necessary
with regard to working with a lifting device and the corresponding attachment
equipment. In order to ensure safe use, these activities may therefore only be
carried out by appropriate qualied personnel or an instructed person under the
direction and supervision of qualied personnel.
Qualied personnel are those who can recognize possible hazards and institute
the appropriate safety measures due to their professional training, knowledge, and
experience, as well as their understanding of the relevant regulations pertaining
to the work to be done. Qualied personnel must observe the rules relevant to the
subject area and have the necessary hydraulic, electric and automation knowledge.
Hydraulic knowledge means, for instance:
• Reading and fully understanding hydraulic diagram,
• Fully understanding in particular the interrelationships regarding safety devices
and having knowledge on the function and assembly of hydraulic components.
Electric knowledge means, for instance:
• Reading and fully understanding of electrical diagrams
• Certication for work with electrical equipment
Automation knowledge means, for instance:
• Reading and fully understanding of logic diagrams
• Knowledge of programmable equipment (PLC, VFD etc)
Bosch Rexroth offers training support for special elds. For more information
about training, please contact your Bosch Rexroth representative.

RE 15345-WA, Version 11.2022, Bosch Rexroth AB
Safety instructions | Drive system Hägglunds Fusion 9/72
2.5 General safety instructions
• Observe the regulations for accident prevention and environmental protection.
• Comply with the local safety provisions and regulations of the country in which
the product is used.
• Make sure to use Rexroth products in perfect working order.
• Strictly observe all instructions on the product.
• Persons, who assemble, operate, disassemble or maintain Rexroth products
must not consume any alcohol, drugs or pharmaceuticals that may affect their
ability to respond.
• Use exclusively accessories and spare parts explicitly approved by the
manufacturer to avoid accidents due to improper accessories and spare parts.
• Strictly observe the technical data and ambient conditions specied in the
product documentation.
• Inadequate products installed or used for safety-relevant applications may
produce unintended operating behavior and result in product or property
damage. For this reason, use a product in safety-relevant applications only on
condition that such use is specied and allowed in the corresponding product
documentation.
• Prior to commissioning the product, make sure that the end product (e. g. a
machine or line), into which Rexroth products are integrated, perfectly complies
with the country-specic provisions, safety regulations and standards applicable
to its use.

10/72 Hägglunds Fusion Drive system | Safety instructions
Bosch Rexroth AB, RE 15345-WA Version 11.2022,
2.6 Product-specic safety instructions
The safety instructions below apply to chapters 6: Transport and storage to 14:
Technical data
DANGER
Danger from excessively high pressure
Danger to life or risk of injury, damage to equipment.
Operating the components above the permissible maximum pressure can cause
components to burst and hydraulic uid to escape under high pressure.
fOperate the components only within permissible maximum pressure.
Danger from suspended loads
Danger to life or risk of injury, damage to equipment.
Improper transportation may cause the Hägglunds drive system to fall down lead
to injuries e.g. crushing or broken bones or damage to the product.
fMake certain that the forklift truck or lifting device has adequate lifting
capacity.
fNever stand under or put you hands under suspended loads.
fEnsure your position is stable during transportation.
fUse your personal protective equipment (e.g. protective goggles, safety gloves,
suitable working clothes, safety shoes).
fUse suitable lifting device for transport and storage, installation and for
removal and repair. Make sure the electric motor is well mounted or anchored
when the lifting device is disconnected.
fObserve the prescribed position of the lifting strap.
fObserve the national laws and regulations on work and health protection and
transportation.
Pressurized machine/system
Danger to life or risk of injury, serious injuries when working on machines/
systems not shutdown! Damage to equipment.
fAlways lockout-tagout electric motors before maintenance.
fDo not disconnect any line connections, ports and components when the
machine/system is pressurized.
fAlways ensure that no energy is accumulated before any measures.
fEnsure that no pressure will enter the hydraulic system in the drive system via
the hydraulic motor e.g. loads on the shaft or winch drum.

RE 15345-WA, Version 11.2022, Bosch Rexroth AB
Safety instructions | Drive system Hägglunds Fusion 11/72
WARNING
Escaping oil mist
Risk of explosion, re, health hazard, environmental pollution.
fDepressurize the machine/system and repair the leak.
fKeep open ames and ignition sources away from the Hägglunds drive system.
High voltage
Danger to life or personal injury hazard through electrical shock.
fPrior to accessing electrical parts with a voltage higher than 50 volts always
disconnect the device from the mains or power unit. Secure the electrical
equipment against being switched on again by accident.
fObserve the general deployment regulations, safety regulations and domestic
laws for work on heavy-current equipment.
fThe operation, maintenance and/or repair of such equipment is reserved to
skilled personnel qualied to work on or with electrical equipment.
fPrior to switching the equipment on always check the protective earth
conductor for reliable connection to all electrical equipment according to the
connection diagram.
fExclusively run the component/device - even for short-time measurements or
tests - with the protective earth conductor reliably connected to the dedicated
connection points.
Danger due to incorrect mounting and setting of electrical, hydraulic and
mechanical functions as well as controls
Risk of personal injury or property damage.
fFollow instructions for delivered equipment.
Rotating parts
Risk of injury or serious injuries.
fDo not touch rotating parts or in the zone of rotating parts.

12/72 Hägglunds Fusion Drive system | Safety instructions
Bosch Rexroth AB, RE 15345-WA Version 11.2022,
CAUTION
High noise development in operation
Danger of hearing damage, deafness.
The noise emission of Hägglunds drive system depends on speed, operating
pressure and installation conditions.
fAlways wear hearing protection when in the vicinity of the operating drive
system.
Hot surfaces on the drive system
Risk of burns.
fAllow the Hägglunds drive system to cool down sufciently before touching it.
fWear heat-resistant protective clothing, e.g. gloves.
Improper routing of cables and lines
Tripping hazard and damage to equipment.
fLay cables and lines so that they can not be damaged and nobody can trip over
them.
Contact with hydraulic uid
Hazard to health/health impairment e.g. eye injuries, skin damage, toxication
during inhalation.
fAvoid contact with hydraulic uids.
fWhen working with hydraulic uids, strictly observe the safety instructions
provided by the lubricant manufacturer.
fUse your personal protective equipment (e.g. protective goggles, safety gloves,
suitable working clothes, safety shoes).
fIf hydraulic uid should, nevertheless, come into contact with your eyes or
bloodstream or is swallowed, consult a doctor immediately.
Escaping hydraulic uid due to machine/system leakage
Risk of burns and risk of injury due to escaping oil jet.
fDepressurize the machine/system and repair the leak.
fNever attempt to block or seal the leak or oil jet with a cloth.
Operator error
Risk of personal injury or damage to the product.
fCheck both the general and the custom technical documentation to identify
the features of your unique drive system
2.7 Personal protective equipment
Use personal protective equipment like helmet, protective goggles, safety shoes
and hearing protection.
The personal protective equipment is the responsibility of the user of the
Hägglunds drive system. Observe the safety regulations and provisions of your
country.
All components of the Personal protective equipment must be in perfect condition.

RE 15345-WA, Version 11.2022, Bosch Rexroth AB
General notes regarding property damages and product damages | Drive system Hägglunds Fusion 13/72
3 General notes regarding property
damages and product damages
NOTICE
Danger from improper handling
Product can be damaged.
fDo not expose the product to an impermissible mechanical load.
fNever use the product as a handle or step.
fDo not place/lay any objects on the product.
fDo not strike the Hägglunds drive system or any part of it or its accessories.
fDo not set/place the Hägglunds motor on the drive shaft or ttings.
fDo not strike ttings (e.g. sensors or valves).
fDo not strike sealing surfaces (e.g. service line ports).
fLeave the protective covers on the Hägglunds drive system until shortly before
installation.
fMake sure that the electronics are not electro-statically charged
Damage to equipment due to improper lubrication
Product can be damaged or destroyed.
fNever operate the Hägglunds drive system with insufcient hydraulic uid.
fWhen commissioning a machine/system, make sure that the case interior and
the service lines of the hydraulic motor and pump are lled with hydraulic
uid and remain lled during operation.
Mixing of hydraulic uids
Product can be damaged.
fAny mixing of hydraulic uids of different manufacturers or different types of
the same manufacturer is not permissible in general.
Wrong voltage
Electric motor damage.
fAll electrical supply levels shall be within the limits that the equipment is
constructed for, see order specic Hägglunds Fusion documentation and
product identication.
Damage from electro-welding
Product can be damaged.
fDo not perform electro-welding on the Hägglunds drive system.
fDo not perform any electro-welding on the driven machine without
disconnecting the articulated connection from ground.
fRemove any sensitive electronic equipment before performing any
electrowelding on the machine.

14/72 Hägglunds Fusion Drive system | General notes regarding property damages and product damages
Bosch Rexroth AB, RE 15345-WA Version 11.2022,
NOTICE
Contamination of the hydraulic uid
The cleanliness of the hydraulic uid has a considerable impact on the cleanliness
and service life of the hydraulic system. Contamination of the hydraulic uid
could cause premature wear and malfunctions.
fMake sure that the working environment at the installation site is fully free of
dust and foreign substances in order to prevent contaminants, such as welding
beads or metal cuttings, from getting into the hydraulic lines and causing
product wear or malfunctions. The Hägglunds drive system must be installed
in a clean condition.
fUse only clean connections, hydraulic lines and attachments (e.g. measuring
equipment).
fKeep the connections plugged as long as possible.
fBefore commissioning, make sure that all hydraulic connections are tight and
that all of the connection seals and plugs are installed correctly to ensure that
they are leakproof and uids and contaminants are prevented from penetrating
the product.
fUse a suitable lter system to lter hydraulic uid during lling to minimize
solid impurities and water in the hydraulic system.
Improper cleaning
Product can be damaged.
fPlug all openings with the appropriate protective equipment in order to
prevent detergents from entering the hydraulic system.
fNever use solvents or aggressive detergents. Use only water and, if necessary,
a mild detergent to clean the Hägglunds drive system.
fNever use a high pressure washing system to clean inside the drive system
fFor outside washing, do not point the power washer at sensitive components,
e.g. electrical connections and components.
fUse lint-free cloths for cleaning.
Environmental pollution due to incorrect disposal
Careless disposal of the Hägglunds drive system and its ttings, the hydraulic
uid and the packaging material could lead to pollution of the environment.
fDispose of the Hägglunds drive system, hydraulic uid and packaging in
accordance with the national regulations in your country.
fDispose of the hydraulic uid in accordance with the applicable safety data
sheet for the hydraulic uid.
Escaping or spilling hydraulic uid
Environmental pollution and contamination of the ground water.
fUse an oil binding agent if hydraulic uid is spilled.
fObserve the information in the safety data sheet for the hydraulic uid and the
specications provided by the system manufacturer.
The warranty applies only to the delivered conguration.
The entitlement to warranty cover will be rendered void if the product is
incorrectly installed, commissioned or operated, or if it is used or handled
improperly.

RE 15345-WA, Version 11.2022, Bosch Rexroth AB
Scope of delivery | Drive system Hägglunds Fusion 15/72
4 Scope of delivery
Included in the delivery contents are:
• Hägglunds Fusion as per order conrmation
5 About this product
5.1 Product description
Hägglunds Fusion is a closed loop hydraulic system that converts electric energy
to mechanical rotation of a shaft. All included parts are assembled in a compact
cabinet. The drive system has one pump driven by one electric motor to provide
the hydraulic motor with the required ow of oil and pressure at the right time.
The main pump is an axial piston pump with variable displacement for closed loop
systems. The electric motor is totally enclosed (TEFC).
The standard control function is a pump control with system control interface for
controlling the pump and gather sensor signals to a common customer interface.
The drive system is a exible product with an option range. This makes it possible
to select a standard drive system to fulll the features needed in many different
applications.
This installation and maintenance manual is intended to cover all standard options.
It may not cover all details on customized drive systems that differ from the
standard Hägglunds Fusion concept.
5.2 Product identication
4
2
1
3
5
1 Type code
2 Serial number
3 Weight
4 Manufacturer
5 Max pressure
Fig. 1: Example of product identication from Fusion European version
DD00057560

16/72 Hägglunds Fusion Drive system | Scope of delivery
Bosch Rexroth AB, RE 15345-WA Version 11.2022,
Main components
Item Description See also gure
1 Hydraulic motor –
2 Electric motor –
3 Main pump –
4HDC cooler –
5Torque arm –
6Tank 3
7Oil Filter –
8Pump control and power amplier –
9 Speed sensor –
5.3 Main components
Fig. 2: Main components Hägglunds Fusion
1
2
6
4
3
5
9
8
7
Product
identication
Oil lling
point
42629
Drain tap
1˝ BSP Female
About this produkt

RE 15345-WA, Version 11.2022, Bosch Rexroth AB
Scope of delivery | Drive system Hägglunds Fusion 17/72
Item Description
1 Oil-drain valve
2 Level and temperature sensor
3Air lter breather
4Level gauge
3
Fig. 3: Detailed view, tank
1
About this produkt
2
4
42466

18/72 Hägglunds Fusion Drive system | Scope of delivery
Bosch Rexroth AB, RE 15345-WA Version 11.2022,
5.4 Hydraulic uids
The Hägglunds hydraulic system is primarily designed for operation with hydraulic
uids according to ISO 11158 HM.
Fluids by the standards given in Table 4 are suggested. Before the start of project
planning, see data sheet RE 15414, Hydraulic uid quick reference, for detailed
information on hydraulic uids and specic additional demands
Table 4: Suggested uid types
ISO 11158 ISO 15380 ISO 12922
Mineral oil based and
mineral oil related hydraulic
uids
Environmentally acceptable
hydraulic uids
Fire resistant hydraulic uids
Details regarding the selection of hydraulic uid
The hydraulic uid should be selected such that the operating viscosity in the
temperature range, as measured in the motor housing, is within optimum operation
range, see Fig. 4. General recommendation is to have a system temperature of
50°C, see dotted line in Fig. 4. A VG 68 uid will render just above 40 cSt at this
point.
• Optimum viscosity range is 40 to 150 cSt.
• Running above 150 cSt or below 40 cSt results in reduced efficiency.
• Running above 400 cSt results in substantial efficiency loss.
• For pumps, the maximum start-up viscosity is 1600 cSt.
• For motors, starting at above 10000 cSt imparts unnecessary strain on parts.
• Running below 30 cSt may impact the service life.
• Running below 20 cSt may render instant seizure.
Fig. 4: Selection diagram for viscosity ranges with straight uids, i.e. viscosity index 100
14
20
30
40
50
60
80
100
150
200
300
400
600
1000
2000
3000
5000
10000
20000
0
32
-40
-40
-30
-22
-20
-4
-10
14
0
32
10
50
20
68
30
86
40
104
50
122
60
140
70
158
80
176
90
194
100
212
110
230
Optimal operation
Continuous operation
Minimum viscosity for short-term operation
Maximum viscosity at cold start
Viscosity,
ν
ν [cSt]
Temperature, t [°C/°F]
DD00069413
About this produkt

RE 15345-WA, Version 11.2022, Bosch Rexroth AB
Scope of delivery | Drive system Hägglunds Fusion 19/72
5.5 Requirements for hydraulic uid cleanliness
The drive systems are equipped with a lter in the charge line. In order to
obtain stated service life it is important to follow recommendations concerning
cleanliness levels and maintenance.
Cleanliness level recommendations
• When lling the system with hydraulic uid it is important to ll through the
dedicated oil lling connection (see 8.2: Filling up the system with hydraulic fluid).
• For industrial applications the contamination level should not exceed ISO
4406:1999 18/16/13.
• Have a water content of <200 ppm (0,02%).
• Always use lter elements recommended and supplied by Bosch Rexroth.
• The hydraulic uid should be analysed according to the maximum intervals on
the maintenance chart (see Table 18: Maintenace chart). Be particularly careful
when removing equipment for repairs or maintenance, dirt must not be allowed
to enter the system, clean prior to opening and plug open connections.
NOTICE
Dirt in oil
Damage on equipment.
fDo not re-use hydraulic uid which has leaked out.
About this produkt

20/72 Hägglunds Fusion Drive system | Scope of delivery
Bosch Rexroth AB, RE 15345-WA Version 11.2022,
5.6 Drive system monitoring
The following function must be fullled in the system. See order specic
Hägglunds Fusion documention for the monitoring settings.
The monitoring of the drive system switches and sensors are grouped in two levels
according to Fig. 5.
The warning indication is to give an indication about a problem in the drive system
that does not need an immediate action.
The alarm indicates a need for stopping the pump. The stop sequence is to rst
stop the hydraulic motor by setting the pump swash angle to zero without ramp
to allow the hydraulic drive to stop and after a short delay switch off the electric
motor.
The low (charge) pressure indicator must be interlocked during stop and startup
of the electric motor to avoid alarm and give the pump time to build up the charge
pressure after start.
Note! For Fusion with pump control alarm and warning must be handled by
customer control system.
Fig. 5: Example of monitoring logic diagram with ISO VG 68 oil
42444
About this product
