H-Star HP-66 User manual

1
HP-66
OWNER’S MANUAL
DIGITAL PIANO

2
IMPORTANT SAFETYINSTRUCTION

3
INSTRUCTIONS PERTAININGTOARISKOFFIRE,ELECTRICSHOCK ORINJURY:
Thelightning symbolinside a triangle isintendedto alerttheuserto the presence ofuninsulatedor “danger-
ousvoltage”that couldconstitute arisk of electric shock.
Theexclamationpoint insideatrinagleisintended to alert theuserof importantoperation andmaintenance/
servicing instructions.
CAUTION: Anychangesormodificationsinconstruction of thisdevicewhicharenot expresslyapproved by
thepartyresponsibleforcompliancecouldvoid thewarrantyand theabilityto operate the equipment.
NOTE:Thisequipment hasbeen tested and found to complywith the limitsfora Class Bdigitaldevice,
pursuanttoPart15ofthe FCCRules.These limitsaredesigned to provide reasonableprotection against
harmfulinterferencein aresidentialinstallation.Thisequipment generates,uses,and canradiateradio
frequency energyand, ifnot installed and used inaccordancewith theinstructions,maycauseharmful
interference toradiocommunications.However,thereisnoguarantee that interferencewillnotoccurin a
particularinstallation. If thisequipment doescause harmfulinterferenceto radio ortelevision reception, which
canbedetermined byturning theequipment off andon,theuseris encouraged to tryto correct theinterfer-
encebyone ormoreof the following measures:
-Reorientorrelocatethereceivingantenna.
-Increasetheseparationbetweentheequipmentandreceiver.
-Connect the equipment into anoutlet on a circuit differentfrom that to whichthereceiverisconnected.
-Consultthedealeroranexperienced radio/TVtechnicianforhelp.”
GENERALPRECAUTIONS
CAUTION
RISKOFELECTRICSHOCK
DONOTOPEN
CAUTION:TOREDUCETHERISK OFELECTRIC SHOCK,
DONOTREMOVECOVER ORBACK
NOUSER-SERVICEABLEPARTSINSIDE
REFERSERVICINGTO QUALIFIEDSERVICEPERSONNEL
!
!

4
TAKE CARE OFYOUR PIANO
Thisdigitalpiano will supplyyou with years of musicalenjoyment ifyou follow thesimple ruleslisted below.
WARNING
When using electricalproducts, basicsafety
precautionsshouldalwaysbefollowed,
includingthefollowing:
SAFETY
PowerSource -Theproductshouldalwaysbe
connectedto apowersupply only of the type
describedinthe operatinginstructionsoras
markedontheproduct.
PeriodsofNonuse -The power-supplycordof
theproductshouldbeunpluggedfromthe
outletwhenleftunused fora long period of
time.
SERVICEANDMODIFICATION
Thisproduct shouldbe serviced byqualified
servicepersonnelwhen,
•thepowersupplycord orthe plughasbeen
damaged,
•liquidhasbeen spilledinto the unitorit has
beenexposedtorain,
•theinstrumentdoesnotappearto operate
normally orexhibitsa markedchange in
performance.
•theinstrumenthasbeen droppedorthe cabinet
hasbeendamaged.
•Do notattempt to open the pianoormakeany
change inthe circuitsorpartsofthe unit.
HANDLINGANDTRANSPORT
•Neverapplyexcessive force to the controls,
connectorsorotherpartsof the instrument.
•Always unplug cablesbygripping the plug
firmly, not bypulling on the cable.
•Disconnectall cablesbeforemoving the
instrument.
•Physicalshocks caused bydropping,
bumping, orplacing heavyobjectson the
instrument can resultinscratchesand/ormore
seriousdamage.
•Carefullycheckthe amplifiervolume control
before starting to play. Excessive volume can
causepermanenthearingloss.
CLEANING
•Forthehigh-polishfinishes,clean thecabinet
andpanelwithasoftnonabrasivedry cloth.
Thisclothshouldbe forHighGlossLacquer
FinishFurniture.Awaxbased polishspecifi-
cally forHighGloss LacquerFinish Furniture
maybe used on the cabinet. Do not usepaint
thinnerorpetrochemicalbasedpolishes.
LOCATION
Do not expose the instrument to the following
conditionstoavoiddeformation, discoloration, or
moreseriousdamage:
-directsunlight (nearawindow)
-high temperatures(nearaheatsource,outside,
ornearawindow)
-rainorexcessivehumidity
-excessivedust
-strongvibration
•Leave enough space around thepiano foritto
beproperlyventilated.
•Thisinstrument containsdigitalcircuitry and
maycause interferenceifplaced too closeto
radioortelevision receivers.If interference
occurs,movethe instrumentfurtherawayfrom
theaffected equipment.
•Avoidplacing vinylobjectson topof the
instrument, vinylcan stick to and discolorthe
surface.
•The instrument shall not be exposedto dripping
orsplashing andno objectsfilled with liquids,
such asvases, shall be placed on the
instrument.
POWER
•The instrument shouldbe placed whereit is
easytounplug thepowerplug
•Theinstrument is unplugged thepowerplug
duringlightningstorn,cleaning ornotunused
forlong periodsof time.
•Turnthe powerswitchoff when the instrument is
not in use.
•Toavoiddamageto the instrumentand other
devicesto whichitisconnected, turnthe power
switchesof all related devicesoff priorto
connection ordisconnection of MIDI cables.
•Turn thepoweroff ifthemain cable isdamaged
orthe instrument isspatteredwith liquid.
•Do not switch the unit on and off in quick
succession,this placesan undue load on the
electroniccomponents.
•Avoidpluggingthe ACpowercordinto the same
ACoutlet asapplianceswithhighpower
consumption, suchaselectricheatersor
refrigerators.
ForVeneerStyleWood finishastandardpolish
similarto “pledge”is acceptableoruseadry
“antu-static”cloth.
•To maintainthe lusterof the keysand buttons
wipe with a clean,slightlydampcloth, and then
polish with a soft drycloth.

5
TABLEOFCONTENTS
ASSEMBLY ................................................................................6
PANELCONTROLS.................................................................. 9
DEMO .......................................................................................18
KEYBOARDVOICES...............................................................19
Voice Selection.......................................................................19
Layer(dual).............................................................................20
Lower(split)............................................................................20
RHYTHMSECTION..................................................................22
Rhythm StyleSelect...............................................................22
AdjustingtheTempo...............................................................23
Starting andStopping the Rhythm Style..................................24
Variation..................................................................................25
Fill-In.......................................................................................25
Metronome..............................................................................25
AUTOACCOMPANIMENT (AUTOBASECHORD)................26
Single......................................................................................26
Fingered..................................................................................27
Piano......................................................................................28
Manual Bass Chord................................................................28
AutoHarmony.........................................................................28
FUNCTION ..............................................................................29
Drum Kit Selecting (KeyboardPercussion).............................30
ReverbLevel..........................................................................30
ChorusLevel..........................................................................31
TouchResponse....................................................................31
SplitPointforLowerVoice......................................................32
Split PointforAutoAccompaniment........................................32
AutoHarmony Type Selecting................................................33
MasterTune............................................................................33
Equalization............................................................................34
ReverbType...........................................................................34
Chorus Type...........................................................................35
VocalGrading.........................................................................35
Local........................................................................................35
FactorySetting.......................................................................35
RECORD ..................................................................................36
Recording...............................................................................36
Playback.................................................................................37
REGISTRATIONMEMORY......................................................39
PLAYALONG SONGS ............................................................40
MIDI...........................................................................................42
MIDI IMPLEMENTATIONCHART............................................44
VOICELIST ..............................................................................45
STYLELIST ..............................................................................48
DRUM KITLIST ........................................................................49
PEDALS....................................................................................52
SPECIFICATIONS....................................................................53

6
1. LAYING THEPEDALCABLE -Takeoff the coverof thecableslot. Insertthe
pedalcableinside,then insertthe cover.
2. CROSSBAR INSTALLATION- Attachthepedalcross bartothe legwiththe
screw(1).
ASSEMBLY
You havehardwareforinstallation inthe accessorybag listed below:
(1)ScrewM6X20 (10 pcs)(2)ScrewM6X15 (4pcs)
(3)Self-TappingScrew4X16(6pcs)(4)Self-TappingScrew4X12(2pcs)

7
ASSEMBLY
3. BACKBOARDINSTALLATION- Attache the back boardtothe legswiththe screw(3).
Headphone Holder
5. POWERSUPPLYCONNECTION- Plug the powercord
into the receptaclelocatedon the bottomofthe piano.Plug the
3-pinplugintoa groundedACwalloutlet.

8
CONNECTORPANEL
2. PHONE1 / PHONE2 -You can playin totalsilence,withoutdisturbing
othersinthe room,bypluggingasetofheadphonesinto one of the
appropriate sockets.When headphonesarepluggedintoeitherofthese
jacksthe mainspeakersystemisturnedoff.Two setsofheadphones
maybe used simultaneously.
3LINEIN -Thesestereoaudioinput jacks willamplifythesuppysignal
through the internalsounddeliverysystem.Theycanbe usedto hook
up itemssuchasahomestereo, PAsystemorotherstand alone
amplifiers.
LINEOUT -Thesestereo audiooutput jackssuppliesthepiano soutput
signalto externalamplification, such asa home stereo,PAsystemor
otherstand aloneamplifiers.
4MIDI IN /MIDIOUT -This pianocontainsMIDIin andMIDI output ports.
MIDIjacksallowcommunicationwith otherproductsequippedwithMIDI
interfaces. Please seetheMIDIsection of this manualforfurtherdetails.
5USB -The USB connectorallowsyou to connectthe piano directlyto your
computer.Thepiano canbeconnectedwithcomputerwithoutdriver
installation undertheWindowsXPenvironment.Thepiano willbe recog-
nizedasan USBAudiodevicethat receivesandtransmitsMIDI
messages.
Thisconnectorpanel, with itsvariousjacks, islocated on the bottom left ofthe piano,underthe keybed.
PHONES
AUDIO
IN OUT
IN OUT
MIDI
USB
L L
R R
MIC
23 4 5
1
1Microphone -Plugina microphone to talk/singthrough yourpiano
speakers.

9
SINGLE
FINGERED
PIANO
ACCOMPVOLUME
–TEMPO+ HARMONY LAYER LOWER
SYNCHSTART
PANELCONTROLS
The elegantcontrolpanelisdivided intoseveraldistinctsections. The following isabrief
descriptionof allthe featureslocatedonthe controlpanel.
1
2
3
4
MINMAX
MASTERVOLUME
MINMAX
1. MASTERVOLUME -Usethissliding controlbuttontoadjustthe
overall volumeofthe keyboard.
2. ACCOMPVOLUME- Slide thiscontrollertoadjustthe volumeof
theautoaccompanimentandmetronome,thekeyboardinstru-
mentvoicewillnotbeaffected.
3. TEMPO -Press oneoftheTEMPObuttons,thecurrenttempo
value will appearonthedisplay.You can usethe TEMPO +,
TEMPO –buttons,orthe +/YESand –/NObuttonstochangethe
tempovaluerangefrom40 to240 bpm(beatsperminute).
PresstheTEMPO+orTEMPO –buttonsorthe+/YESand
–/NObuttonssimultaneouslytorecallthe defaulttemposettingfor
theselectedrhythmstyle. Afterthreesecondsthedisplaywill
reverttotheselectedvoice.
Thereisafour-dotbeatindicatorabovethe tempobuttons.It
indicatesthetempoandbeatfortheaccompaniment thatis
playing.
4. HARMONY -When selected, the singlenoteplayed intheright-
hand section of thekeyboardwill sound withadditionalauto
harmonynotes.Thenoteplayedintheuppersectionof the
pianodeterminestherootkeyoftheharmony.It isrecom-
mendedthatone notebe playedatatime.If morethanonenote
isplayed onlythe highestnotewilladd harmony.
Autoharmonyisonlyavailablewhentheautoaccompani-
mentisengaged.Theharmonytypeselectionisassignedin
theFunctionmenu.Useittoselectthe typeofharmony,Duet,
CloseHarmony,OpenHarmony,orOctave.SeetheFunction
sectionformoreinformation.
START/STOP INTRO/ENDING ACCOMP FILLIN VARIATION

10
PANELCONTROLS
7
65
8
SINGLE
FINGERED
PIANO
–TEMPO+ HARMONY LAYER LOWER
MINMAX
MASTERVOLUME
MINMAX
ACCOMPVOLUME START/STOP INTRO/ENDING ACCOMP
FILLIN VARIATION
SYNCHSTART
5. LAYER -Pressing theLAYERbutton will putthe keyboardinthe
layer, ordual,mode. Layer,ordual,referstoanadditionalvoice
thatistone mixedwiththe selectedkeyboardvoice.Theassigned
layervoicewill be heardwiththeoriginalvoice. Toselect anew
layered instrument voiceusthe+Yesor-Nobuttonswithin4
secondsaftertheLayerbuttonhasbeenpressed.
6. LOWER -WiththeLOWERfeatureengagedthekeyboardoperates
insplitmode.Insplit mode the keyboardisdividedintotwo
sections. Inthe right hand sectionthe originalorlayered voicewill
sound,andinthe lefthandsectionadifferent voicecan be
assigned. Toselect anewLowerinstrumentvoiceusethe+Yes
or-Nobuttonswithin4secondsaftertheLowerbuttonhasbeen
pressed.
7. SYNCSTART -SynchronizedStart modesetsthe autoaccompani-
mentintostandbymode. When the SYNCSTARTbutton is
pressedtheindicatorlightsabovethetempowillflashtothe
Tempoofthe selected rhythmstyle.Therhythmstylewill start
assoonasyouplay intheautoaccompanimentsection of
thekeyboard. Theautoaccompanimentwill startwiththe first
recognizedchordplayedintheautoaccompaniment section ofthe
keyboard, depending onwhichfingeringmodeisselected. Press-
ing the SYNC STARTbutton againwill stop theautoaccompani-
mentandputthekeyboardbackintostandbymode.
8. START/STOP -Thisbuttonstartsorstopsthe selected rhythm
style.The autoaccompanimentwillstartwiththe firstrecognized
chordplayed intheautoaccompanimentsectionofthekeyboard,

11
PANELCONTROLS
11 1210
SINGLE
FINGERED
PIANO
–TEMPO+ HARMONY LAYER LOWER
9
START/STOP INTRO/ENDING ACCOMP
FILLIN VARIATIONSYNCHSTART
depending onthefingering mode selected.
9. INTRO/ENDING -Allof the100rhythmstylescanbestartedor
finishedwithaunique introduction orendingpattern.When
selected,an introductionof thestylewillstartfollowedbythemain
stylepattern.
Witharhythmoraccompaniment patternalreadyengagedtheac-
companimentcan beprofessionallycompleted withan ending
patternfromthenextmeasurebypressingtheINTRO/ENDING
button.Ifyoupressthefill-inbuttonduringtheendingpatternit
willreturntothemainaccompaniment pattern.
10. FILL IN -Thefill-inprovidestheaccompanimentwithashortrhythm
patternofoneortwomeasuresforeachstyle.PresstheFILLIN
buttonatanytimewhilethe accompaniment isplaying toadd afill-
in.If youholddowntheFILLINbutton,thefill-inpatternwill
repeat untilthebuttonisreleased,then the mainpatternwillplay
fromthebeginningof thenextmeasure.
11. VARIATION -Allof the100rhythmstylesincludeavariationof that
stylethatcan beplayed simplybypressing the VARIATION
button. PresstheVARIATIONbuttonagaintodisengageand
returntothe mainpattern.
12. ACCOMP -Eachrhythmstylehasafullyorchestrated autoaccom-
panimentpattern.Theseaccompanimentsarededicatedtothe
selectedrhythmstyle,andwillcreaterhythm, bassandchord
accompaniments.TheACCOMPbuttonselectstheautoaccom-
panimentmode.Withthisfunctionengaged, thekeystotheleft
sideofthesplitpoint aretheautoaccompanimentsection of the
keyboard, whilethekeystothe rightareavailablefornormal
playing.

12
PANELCONTROLS
13. A/BBUTTON -The fivequick select voiceand fivequickselect
stylebuttonsareeachassignedtoalineA and lineB.Pressthe
A/Bbutton toalternatebetween thetwoselection lines. The
indicatorlight will be lit when selection lineB isactive.Please
seethequickselectbuttonsbelowformoreinformation.
14. QUICK SELECTVOICE -Thereareten instrument voicesthatcan
be selected quicklybypressing one ofthefivevoiceselect
buttons.ThesevoicesareassignedtolineAandlineB.Eachof
theseselectionlinesconsistsof fivevoices. Thevoicenamein
theline Aisprintedabovethevoiceselectbutton and thevoice
nameonlineBisbeneaththebutton.PresstheA/Bbuttonto
selectthe voicelineof yourchoice.When the indicatorlightislit
theBlineorbottomlineisactive. Theselected voicenameand
itsnumberwillbe shownonthe display.Pleaseseethe Key-
boardVoicessectionofthismanualformoreinformation.
15. QUICK SELECTSTYLE BUTTONS -Thereareten RhythmStyles
thatcanbeselectedquicklybypressingoneofthe fiveRhythm
select buttons.TheseRhythmStylesareassigned tolineAand
line B. Eachoftheseselectionlinesconsistsoffiverhythmstyles.
TheStylenameinlineAisprintedabovetheStyleselect button
andtheRhythmstylenameonlineB isbeneaththebutton.Press
theA/BbuttontoselecttheRhythmStylelineofyourchoice.
WhentheindicatorlightislittheB line orbottomlineisactive.
Theselected rhythmnameand itsnumberwill beshownon the
display.PleaseseetheRhythmStylessectionofthismanualfor
moreinformation.
1314
15
SINGLE
FINGERED
PIANO
ACCOMP
PIANO E.PIANO ORGAN
GUITAR
USER1
STRINGS
HARPS.
TRUMPET FLUTE USER2
METRONOME
A /B
BOSSANOVA ROCK POP BALLAD USER1
LOUNGE BLUES JAZZ GOSPEL USER2

13
PANELCONTROLS
19
16
METRONOME
A /B
SONG FUNCTION USERREGPAGEPAGE
17 18
VOICE
STYLE
DEMO/SONG
16. METRONOME -Pressthe METRONOMEbuttontoengagethe
metronome.Iftheautoaccompanimentisplayingthemetronome
sound will replacethepercussiverhythmsoundimmediately.If the
autoaccompanimentisnotengaged,press theMETRONOME
buttontostartthemetronome,andagaintostopit. Timesignature
andvolumeof themetronomecanbe adjusted. Pleaseseethe
Rhythmsectionofthismanualformoreinformation.
17. INSTRUMENTVOICE -Thereare128GM(GeneralMIDI)instru-
ment voices, plusten Asian folkinstrumentvoicesavailableon this
piano.Youcaninstantlyselectan instrumentvoicebypressing one
ofthe voiceselectbuttons.OrpresstheVOICEbuttontoengagethe
voiceselection mode.Whileitsindicatorlightislit,you can usethe
numberpadtoselectall 138voiceslistedinthe backofthe
manual.Pleaseseethe Voicesection ofthismanualformore
information.
18. STYLE -PresstheSTYLE buttontoengage the styleselection
mode. Whileitsindicatorlightislit, usethe numberpadstoselect a
style.Thereisacompletelist of all100 rhythmaccompaniment
styleslistedinthebackofthe manual.Pleasesee theRhythm
sectionof thismanualformoreinformation.
19. SONG -PresstheSONGbuttontoengagetheteachingmodewitha
indicatorlighting.
The “musicteacher”featurecan beused asanaidtolearnthe50
songsbuiltintothispiano. PleaseseetheTrainingsection ofthis
manualformoreinformation.
SONG

14
parametersofanumberofsettings.Reverblevel,choruslevel,
touch,splitpoint forvoice,autoaccompanimentsplitpoint,tuning,
drumkitselection,theautoharmonytype andlocaloffareallset
fromthe functionmenu.PleaseseetheFunctionsectionofthis
manualformoreinformation.
21. PAGE -ThePAGEbuttons(upanddown)areusedtoaccessthe
differentmenusinthe Functionfeature.When theFUNCTION
buttonhasbeen pressedusethe PAGE andPAGE ttoaccess
theFunctionmenuselections.
22. USERREG -USERREG isused tostorekeyboardsettings. Press
theUSERREGbuttontoengagetheregistrationmemorymode,
theindicatorwill lightup. Press oneof thenumericbuttons1-9,
andthestored settingwillbe recalled instantly.Pleasesee the
Registration Memorysectionofthemanualformoreinformation.
23. NUMERICPAD -Usethe+/YES, –/NO orthenumericpadtoinput
numbersdirectlywhileusingthevoice,styleorfunctionsettings.
Thesebuttonsarealsousedtoaccessoraltermanyofthefunc-
tion featuresorwhereevernumericalinputisnecessary.
24. TRANSPOSE -Thetransposefeaturecan shift the pitchof the
keyboardupordowninsemitoneintervalsuptoamaximumof24
semitones. Press oneoftheTRANSPOSE buttonsandthe cur-
rent transposevaluewill appearon the display. Usethe TRANS-
POSE +orTRANSPOSE –buttonstosetthetransposevalue
rangefrom –12,oneoctavelower,to12,oneoctavehigher. Press
the+and –valuebuttonssimultaneouslytorecall thedefault
valueof0. Afterthreesecondsthedisplaywillreturntothe
PANELCONTROLS
21 22
23
VOICE
SONG FUNCTION USERREGPAGEPAGE
20
STYLE
12 3 +/YES
0
456
789–/NO
20. FUNCTION -The FUNCTIONbuttonisused toaccess the function
menu.Thefunctionmenucanbeused toadjustorchangethe

15
1
2
3
4
USERSONG ACCOMP MELODY1 MELODY2 REC PLAY/STOP USBMEMORY
–TRANSPOSE+ REVERB CHORUS LEFT RIGHT
EFFECT SONG
PANELCONTROLS
25 2624
PLAYALLLOADSAVE UTILITYPLAY/STOP 27
currentlyselectedinstrumentvoice.Transposedoesnotaffect
notesthatarecurrentlyplaying.Transposedoesnot affectthe
percussion.
25. REVERB -Thereverbeffectisengagedautomaticallywhenthe
poweristurned on. Reverbsimulatesthe effectof playingina
bigroomorhall wherethe sound reverberatesoff thewallsand
ceiling.PresstheREVERBbuttontoturnoffthereverbeffect.
Youcanswitchthereverbfeatureon andoffbypressingthe
REVERBbutton. Thereverbsettingdoesnotaffecttheauto
accompaniment. Reverbdepthcan be changedinthe function
menu “ReverbLevel”. Pleasesee the FunctionSection for
moreinformation.
26. CHORUS -The Choruseffect addsdepthand spaciousnessto
theselectedkeyboardvoice.Press theCHORUSbutton to
engagethechoruseffectand theindicatorwill lightup.Press
thebutton againtoturnoff thechoruseffect.The chorussetting
doesnotaffecttheautoaccompaniment. Chorusdepthcanbe
changed inthe functionmenu “ChorusLevel”.Pleaseseethe
FunctionSectionformoreinformation.
27. SONGLEFT ,SONG RIGHT -Thesebuttonsareusedincon-
junctionwiththeSONG button. Itallowstheplayertoplay
along withthe prerecorded traditionalsongscontainedwithin
thispiano.The LEFT button will playthe righthandofthe
selectedsong,sotheusercanpracticetheLeftHandportionof
thesong.The RIGHTbutton will playtheLeft Handof the
selectedsong,sothat the usercanpracticetheRightHand
portionofthesong.

16
1
2
3
4
USERSONG ACCOMP MELODY1 MELODY2 REC PLAY/STOP USBMEMORY
–TRANSPOSE+ REVERB CHORUS LEFT RIGHT
EFFECT SONG
PANELCONTROLS
28 29 30
Whenengaging theLEFTandRIGHTbuttonssimultaneously
onlythe accompaniment (if available)willbe heardasthe user
shouldplayboththeLeft andRightportionsoftheselectedsong.
Pleasesee the PlayAlongSongsectionofthismanualformore
information.
28. USERSONG -TheUSERSONGbutton accessesone ofthefour
availablesong settingsforrecordingorplayback. Usethe +/
YES, –/NObuttonstoselect thesongyouwish,ifthereisre-
corded informationon anyofthethree trackstheirindicatorlights
willlight up.Pleasesee the Recordsection ofthismanualfor
moreinformation.
29. ACCOMP/PLAYALL -ThisisadualfunctionbuttonforRecord
and USB FlashDrivemodes.
Inthe Recordmode,thisbutton isusedtoselectthe autoaccom-
panimenttrack ofasongforrecording orplayback.
IntheUSB FlashDrivemode,pressthisbuttontoplayallMIDI
filesstored inthe USB FlashDrive.
Pleaseseethe Recordand USB FlashDrivesectionsof this
manualformoreinformation.
30. MELODY1/LOAD,MELODY2/SAVE -Thesearedualfunction
buttonsforRecordandUSBFlashDrivemodes. InRecord
mode,therearetwotracksforrecordingmelody, whichare
assignedbytheMELODY1and MELODY 2buttons.
IntheUSBFlashDrivemode,MELODY1/LOADbuttonisused
toloadMIDIfilefromthe USB Drive;MELODY2/SAVE button is
usedtosaverecordedsongtoUSB DriveinMIDIfileformat.
Pleaseseethe Recordand USB FlashDrivesectionsof this
manualformoreinformation.
PLAYALLLOADSAVE UTILITYPLAY/STOP
DEMO

17
1
2
3
4
USERSONG ACCOMP MELODY1 MELODY2 REC PLAY/STOP USBMEMORY
–TRANSPOSE+ REVERB CHORUS LEFT RIGHT
EFFECT SONG
PANELCONTROLS
3331 32
31. REC/UTILITY -ThisisadualfunctionbuttonforRecordand USB
FlashDrivemode.
Thisunitisabletorecordfoursongs, eachwitha3-track
sequencer.It will recordallnoteeventsand theaccompaniment
patternsexactlyastheyareperformed.Thisrecordedinformation
isnonvolatileand thereforewill notbe lostwhen the poweris
turnedoff. ToRecordpressand holddowntheRECORDbutton
thenpressthe trackbutton(s)youwanttorecordon. Recording
beginsassoonasyoustart toplayonanysectionofthekeyboard.
Press the RECORD button againtostop recording.
IntheCardmode, itfunctionsasutilityaccessbuttonwhichin-
cludessolo,muteanddeleteforaselected song intheUSBFlash
Drive.
PleaseseetheRecordandUSBFlashDrivesectionsof the
manualformoreinformation.
32. PLAY/STOP -Thisisadualfunction button forRecordand USB
FlashDrivefeatures. Inthe Recordmode,press thePLAY/STOP
buttontohearselectedtracksthatyouhaverecordedon. Press
thePLAY/STOPbutton againtostop theplayback.
IntheUSB FlashDrivemode, itfunctionsasalsoplay/stopswitch
foraselected song inthe USB FlashDrive.
PleaseseetheRecordandUSB FlashDrivesectionofthis
manualformoreinformation.
33. DEMO -Thispianohastendifferent demonstrationsongs. The
demomodewill playback all tendemosongsorselectthe song
individually.
PLAYALLLOADSAVE UTILITYPLAY/STOP
Pleasesee the DEMOsectionsofthismanualformoreinformation.
DEMO

18
DEMO
1. PLAYALLDEMOSONGS -PresstheDEMO,theindicatorlights
up. Thefirstdemosong willplaybackinstantly.Thisunithasten
demosongs.All songswill playrepeatedlyuntilyou pressthe
DEMObuttonagaintostopthe demonstration.
2. PLAY ASINGLEDEMO SONG -Usethe+/YESorthe-/NObut-
tonstochange songswhilethe demoisplaying,orenterasong
numberdirectlybyusingthe numericpad.Pleasenotethattwo
digitsarerequiredforselectingasongnumber, forexample,to
selectsong No. 9enter “09”.The song will playrepeatedlyuntil
youpressthedemobuttonagaintostop.
Thereare50songsforthemusicaltrainingcoursethatcanalsobe
playedback fordemonstration. Pleasesee the Trainingsection of
thismanualformoreinformation.
PLAYINGTHEDEMOSONGS -Thispianohas10 differentdemonstrationsongsthatare
designed toshowcasethe different sampled voicesthat areavailable. The displaywillshow
thesong numberwitha “d”prefix.Whenplaying allthesongs, “ALL”will appearon the
displayinitially,and will changetothedemosongnumberasitplays. Afterexiting the dem-
onstration mode the displaywill revert toitsinitialdata.
DEMO/SONG
ALL:DemoSong
d-9:Demo Song
DEMO/SONG
1 2 3 +/YES
3456
7 8 9 –/NO
VOICE STYLE
VOICE STYLE
DEMO
DEMO

19
KEYBOARD VOICES
QUICK SELECT -Thereareten voicesthatcan be selected quicklyby
pressingoneofthe fivevoiceselectbuttons.Thesevoicesare
assignedtoInstrument LineA and InstrumentLineB.EachLine
consistsoffivevoices.The voicenameinLine A isprinted above
thevoiceselectbutton and thevoicenameinLineBisbeneath
the button.
1. PresstheA/Bbuttontoselectavoicekit.SelectionoftheInstru-
mentLineswill alternatewhenthe A/B buttonispressed
repeatedly. The indicatorwill be lit when Line B isselected .
2. Pressthevoiceselectbutton thatcorrespondstothedesiredvoice
inthe InstrumentLine youhaveselected.The voicenameandits
numberwill showon the display.
SELECTING ONE OFTHE 138VOICES
1. IftheInstrumentVoiceButtonisnot alreadylitpresstheVOICE
buttontoengage thevoiceselectionmode, theindicatorwillturn
on.
2. Usethenumericpadorthe+/YES, –/NObuttonstoselectavoice
number.
Pleasenote, whenusingthenumberpads,youmust enterthree
digitstoselectavoicenumberfrom001-138.Forexample,to
selectvoiceNo. 2youmustenter “002”. Thevoicenameandits
VOICE SELECTION -Thereare128 GMvoicesin16groupsplus10Asianethnicfolk
instrumentvoices.Thereisacompletelist ofall138voicesintheback ofthemanual.
VOICEA/B
G.PIANO
GUITAR
VOICE 001:GrandPiano
VOICE
002:BrightPiano
G.PIANO E.PIANO HARPSICHORD ORGAN USER1
GUITAR STRINGS TRUMPET FLUTE USER2 A /B
1 2 3 +/YES
3 4 5 6
7 8 9 –/NO
VOICE

20
KEYBOARD VOICES
LOWER
USER1
USER2 A /B
LAYER
numberwill showonthe display.Pleaserefertothe backofthe manual
foralistof all availablevoices.
USERDEFINEDQUICK SELECTIONBUTTON -You can assigna
favoritevoicetothevoicequickselectbutton inthe followmanner.
1. Press the voiceUSERbutton, USER1fromLine A, orUSER2from
LineBtorecallthecurrent stored voice(UserkeyLEDOn). The
defaultuservoicesareUSER1=012;Vibraphone, USER2=092;
ChoirPad.
2. If you wanttoassignyourdesiredvoicetotheUSERbutton,press
andholddownthe Userkeyfor2or3seconds,theUserkeyLED
will blinktoindicatestoremode
3. Select thedesiredvoicebyusingthenumericpadorthe+/YES,–/
NO buttons.Pleasenote:youcannotuseVoicequick select
buttons.
4. PresstheUSERbuttonagaintostorethe voice. Theindicatorstays
On.Thecurrentlyselected voicewill beassigned tothisbutton to
be availableforquick selection.
IfanothervoiceisselectedwhileUserKeyisONbuttheindicator
doesnotblinkforstoremode, thenewvoicewill becomethe active
voice.WhenUsermodeexits, theUserindicatorturnsOff.
5. UserKeyassignmentswillbe saved afterPowerOff.
LAYER(DUAL)VOICE -Layer,ordual,referstoanadditionalvoicethat
istone mixedwiththe selected keyboardvoice.The assigned
layervoicewill be heardwiththe originalvoicewhen the layer
featureisengaged.
1. Pressthe LAYERbutton,the currentlyassigned layervoicewill
showonthe display, and the indicatorwill light up.
2. Usethe+/YES, –/NObuttonsorthenumericpadtoselectthede-
sired voice.Thedisplaywill showthe layervoicenumberand
name,
3. Press the LAYERbuttonasecond timewithin3secondsand the
currentlayervolumelevelwill showonthedisplay. Usethe+/
YES, –/NObuttonstoadjustthelayervolumelevel.Otherwise, this
procedurewill be skipped.
Afterthreesecondsthedisplaywillrevert totheselectedmainvoice.
4. PresstheLAYERbuttonagaintoturnthefeatureoff.
LOWERVOICE -Inthelower,orsplit, modethekeyboardisdividedinto
twosections.Tothe rightoftheSplit Pointthecurrentlyselected
mainvoice,orthelayervoicewillsound.The keys totheleft ofthe
