H3C F5000-AI160 User manual

i
Contents
1 Preparing for installation·············································································1
Safety recommendations ···································································································································1
Safety symbols···········································································································································1
General safety recommendations··············································································································1
Electrical safety··········································································································································2
Laser safety················································································································································2
Handling safety ··········································································································································2
Examining the installation site····························································································································3
Weight support···········································································································································3
Temperature and humidity·························································································································3
Cleanliness·················································································································································3
Cooling system···········································································································································4
ESD prevention··········································································································································4
EMI·····························································································································································4
Lightning protection····································································································································5
Power supply··············································································································································5
Installation tools ·················································································································································5
Installation accessories······································································································································6
Pre-installation checklist·····································································································································6
2 Installing the firewall ···················································································8
Installation flow···················································································································································8
Mounting the firewall on a workbench················································································································8
Installing the firewall in a standard 19-inch rack ································································································9
Grounding the firewall······································································································································13
Grounding the firewall with a grounding strip···························································································13
Grounding the firewall with the grounding terminal on the rack·······························································14
Installing a fan tray···········································································································································14
Installing a power supply··································································································································15
Installing a drive···············································································································································16
Connecting Ethernet cables·····························································································································17
Connecting a fiber port·····························································································································17
Connecting power cords ··································································································································20
Connecting an AC power cord·················································································································20
Connecting a DC power cord···················································································································20
Verifying the installation···································································································································21
3 Accessing the firewall ············································································3-22
Setting up the configuration environment and configuring terminal parameters···········································3-22
Starting the firewall········································································································································3-22
Pre-start checking·································································································································3-22
Starting the firewall and observing the initial startup conditions····························································3-22
Logging in to the firewall ·······························································································································3-24
Logging in from the Web interface········································································································3-24
Logging in from the serial console port or micro USB console port······················································3-24
Logging in through Telnet ·····················································································································3-24
4 Hardware replacement···········································································4-26
Replacing a power supply·····························································································································4-26
Replacing a drive ··········································································································································4-27
Replacing a transceiver module····················································································································4-27
5 Hardware management and maintenance·············································5-29
Displaying detailed information about the firewall·························································································5-29
Displaying software and hardware version information for the firewall·························································5-29
Displaying electrical label information for the firewall ···················································································5-30
Displaying the CPU usage of the firewall······································································································5-31

ii
Displaying the memory usage of the firewall·································································································5-32
Displaying the operational status of power supplies·····················································································5-32
Displaying the operational status of fan trays ·······························································································5-33
Displaying temperature information for the firewall·······················································································5-34
Displaying the operational statistics about the firewall··················································································5-34
Displaying transceiver module information ···································································································5-35
Rebooting the firewall····································································································································5-36
6 Troubleshooting·····················································································6-37
Power supply failure······································································································································6-37
Configuration terminal display issue ·············································································································6-37
Password loss···············································································································································6-37
Cooling system failure···································································································································6-38
Software loading failure·································································································································6-38
7 Appendix A Chassis views and technical specifications························7-38
Chassis views···············································································································································7-39
Power supplies··············································································································································7-40
AC power supplies································································································································7-40
DC power supplies································································································································7-40
Fan trays·······················································································································································7-41
Dimensions and weights·······························································································································7-41
Chassis ·················································································································································7-41
Drives····················································································································································7-41
Storage media specifications························································································································7-42
Power consumption·······································································································································7-42
Chassis ·················································································································································7-42
Drives····················································································································································7-42
Power supply specifications··························································································································7-42
Fan tray specifications ··································································································································7-43
Port specifications·········································································································································7-43
Console port··········································································································································7-43
Micro USB port······································································································································7-43
GE fiber port··········································································································································7-44
10 GE fiber port·····································································································································7-45
40 GE fiber port·····································································································································7-46
100 GE fiber port···································································································································7-48
8 Appendix B LEDs··················································································8-49
9 Appendix C Cables···············································································9-51
Console cable ···············································································································································9-51
RJ-45 to DB9 console cable··················································································································9-51
Micro USB console cable······················································································································9-52
Ethernet twisted pair cable····························································································································9-52
Introduction ···········································································································································9-52
Making an Ethernet twisted pair cable··································································································9-55
Optical fiber···················································································································································9-56

1
1 Preparing for installation
This document is applicable to the F5000-AI160 and F5000-E firewalls.
Safety recommendations
To avoid any equipment damage or bodily injury, read the following safety recommendations before
installation. Note that the recommendations do not cover every possible hazardous condition.
Safety symbols
When reading this document, note the following symbols:
WARNING means an alert that calls attention to important information that if not understood or
followed can result in personal injury.
CAUTION means an alert that calls attention to important information that if not understood or
followed can result in data loss, data corruption, or damage to hardware or software.
General safety recommendations
•
Do not place the firewall on an unstable case or desk. The firewall might be severely damaged
in case of a fall.
•
Make sure the ground is dry and flat and anti-slip measures are in place.
•
Keep the chassis and installation tools away from walk areas.
•
Keep the chassis clean and dust-free.
•
Do not place the firewall near water or in a damp environment. Prevent water or moisture from
entering the firewall chassis.
•
Ensure good ventilation of the equipment room and keep the air inlet and outlet vents of the
firewall free of obstruction.
•
Make sure the operating voltage is in the required range.
•
Use a screwdriver, rather than your fingers, to fasten screws.
•
Stack devices according to the sizes of and packing symbols on the packages.
Figure1-1 Packing symbols
Symbol
Description
Stored with a maximum stack of n units.
Transported and stored with the arrows up.
Transported and stored with care.

2
Symbol
Description
Transported and stored avoiding humidity, rains and wet floor.
Electrical safety
•
Carefully examine your work area for possible hazards such as moist floors, ungrounded power
extension cables, and missing safety grounds.
•
Locate the emergency power-off switch in the room before installation. Shut the power off at
once in case accident occurs.
•
Do not work alone when the firewall has power.
•
Always verify that the power has been disconnected.
Laser safety
WARNING
!
Disconnected optical fibers or transceiver modules might emit invisible laser light. Do not stare into
beams or view directly with optical instruments when the firewall is operating.
The firewall is a Class 1 laser device.
•
Before you disconnect the fiber connector, execute the shutdown command in interface view
to disable the optical source.
•
Attach dust caps to disconnected optical fiber connectors and dust plugs to ports on
disconnected transceiver modules to avoid damage caused by built-up dust.
•
Insert a dust plug into empty fiber ports.
Handling safety
When you move the firewall, follow these guidelines:
•
Move and unpack the firewall carefully to avoid firewall damage.
•
Unpack the firewall at least half an hour and power on the firewall at least two hours after you
move it from a place below 0°C (32°F) to the equipment room. This prevents condensation and
even damage to the firewall.
•
Use a safety hand truck when you move multiple firewalls.
•
Before you move the firewall, remove all cables and mounting brackets.
•
For long-distance transportation, remove all the removable components, such as power
supplies and interface modules, and package them separately, and install the filler panels
supplied with the firewall. For short-distance transportation, make sure all the removable
components are securely seated in the slots and the screws are fastened.
•
When you move or lift the firewall chassis, support the bottom of the chassis, rather than
holding any removable component. Make sure the accessories of the firewall are not lost or
damaged during firewall moving.

3
Examining the installation site
The firewall can only be used indoors. To make sure the firewall operates correctly and to prolong its
service lifetime, the installation site must meet the following requirements.
Weight support
Make sure the floor can support the total weight of the rack, chassis, modules, and all other
components. For weights of the chassis and components, see "Appendix A Chassis views and
technical specifications."
Temperature and humidity
Maintain appropriate temperature and humidity in the equipment room.
•
Lasting high relative humidity can cause poor insulation, electricity leakage, mechanical
property change of materials, and metal corrosion.
•
Lasting low relative humidity can cause washer contraction and ESD and bring problems
including loose captive screws and circuit failure.
•
High temperature can accelerate the aging of insulation materials and significantly lower the
reliability and lifespan of the firewall.
For the temperature and humidity requirements of the firewall, see Table1-1.
Table1-1 Temperature/humidity requirements
Temperature
Relative humidity
•Operating: 0°C to 45°C (32°F to 113°F)
•Storage: –40°C to +70°C (–40°F to +158°F)
•Operating: 5% to 95%, noncondensing
•Storage: 5% to 95%, noncondensing
Cleanliness
Dust buildup on the chassis might result in electrostatic adsorption, which causes poor contact of
metal components and contact points, especially when indoor relative humidity is low. In the worst
case, electrostatic adsorption can cause communication failure.
Table1-2 Dust concentration limit in the equipment room
Substance
Concentration limit (particles/m
3
)
Dust particles ≤ 3 × 104(No visible dust on desk in three days)
NOTE:
Dust particle diameter ≥ 5 µm
The equipment room must also meet strict limits on salts, acids, and sulfides to eliminate corrosion
and premature aging of components, as shown in Table1-3.
Table1-3 Harmful gas limits in an equipment room
Gas
Max. (mg/m
3
)
SO20.2
H2S 0.006
NH30.05

4
Gas
Max. (mg/m
3
)
Cl20.01
NO20.04
Cooling system
The firewall provides front side-intake and rear side-exhaust airflow for heat dissipation. For
adequate cooling of the firewall, follow these guidelines:
•
Install the firewall at the installation site with its airflow direction meeting the ventilation
requirements.
Ensure a minimum clearance of 100 mm (3.94 in) around the air inlet and outlet vents of the
chassis.
If you install the firewall in a standard 19-inch rack, ensure a distance of 1U (44.45 mm, or
1.75 in) between the chassis and other devices.
•
Make sure the installation site has a good cooling system.
Figure1-2 Airflow through the chassis
ESD prevention
To prevent electrostatic discharge (ESD), follow these guidelines:
•
Make sure the firewall, the workbench, and the rack are reliably grounded.
•
Take dust-proof measures for the equipment room. For more information, see "Cleanliness."
•
Maintain the humidity and temperature at an acceptable level. For more information, see
"Temperature and humidity."
•
Put the removed power supplies away on an ESD workbench, with the PCB upward, or put
them in ESD bags for future use.
•
Always wear ESD clothing, ESD gloves, and an ESD wrist strap.
EMI
All electromagnetic interference (EMI) sources, from outside or inside of the firewall and application
system, adversely affect the firewall in the following ways:
•
A conduction pattern of capacitance coupling.
•
Inductance coupling.
•
Electromagnetic wave radiation.
•
Common impedance (including the grounding system) coupling.
To prevent EMI, use the following guidelines:

5
•
If AC power is used, use a single-phase three-wire power receptacle with protection earth (PE)
to filter interference from the power grid.
•
Keep the firewall far away from radio transmitting stations, radar stations, and high-frequency
devices.
•
Use electromagnetic shielding, for example, shielded interface cables, when necessary.
•
To prevent signal ports from getting damaged by overvoltage or overcurrent caused by lightning
strikes, route interface cables only indoors. If part of the network cable of an Ethernet port must
be routed outdoors, connect a lightning arrester to the cable before you plug the cable into the
port.
Lightning protection
To protect the firewall from lightning better, follow these guidelines:
•
Make sure the grounding cable of the chassis is reliably grounded.
•
Make sure the grounding terminal of the AC power receptacle is reliably grounded.
•
Install a lightning arrester at the input end of the power supply to enhance the lightning
protection capability of the power supply.
IMPORTANT:
No
network port lightning arrester or AC power lightning arrester is provided with the firewall.
Prepare them as required. For
the technical specifications and installation instructions for the
lightning protectors, see the documents shipped with them.
Power supply
Verify that the power system at the installation site meets the requirements of the power supplies,
including the input method and rated input voltage. For more information, see "Appendix A Chassis
views and technical specifications."
Installation tools
All installation tools are user supplied.
Table1-4 Installation tools
Flat-head screwdriver Phillips screwdriver Needle-nose pliers Marker
Diagonal pliers ESD wrist strap

6
Installation accessories
Table1-5 Installation accessories
M6 screw Cage nut Front mounting bracket
and M4 mounting screw Rear mounting bracket and M4 shoulder screw
Rubber feet Console cable Grounding cable
Pre-installation checklist
Table1-6 Checklist before installation
Item
Requirements
Result
Installation
site
Ventilation
•Ensure a minimum clearance of 100 mm (3.94 in)
around the air inlet and outlet vents of the chassis.
•If you install the firewall in a standard 19-inch rack,
ensure a distance of 1U (44.45 mm, or 1.75 in)
between the chassis and other devices.
•A good ventilation system is available at the
installation site.
Temperature •Operating: 0°C to 45°C (32°F to 113°F)
•Storage: –40°C to +70°C (–40°F to +158°F)
Relative humidity •Operating: 5% RH to 95% RH, noncondensing
•Storage: 5% RH to 95% RH, noncondensing
Cleanness •Dust concentration ≤ 3 × 104particles/m3
•No dust on desk within three days
ESD prevention
•The equipment, workbench, and rack are reliably
grounded.
•The equipment room is dust-proof.
•The humidity and temperature are at an acceptable
level.
•Wear an ESD wrist strap and make sure it makes
good skin contact and is reliably grounded when
installing removable components.
•Put the removed interface modules away on an ESD
workbench, with the PCB upward, or put them in ESD
bags for future use.
•Touch only the edges, instead of electronic
components when observing or moving a removed
interface module.
EMI prevention •
Take effective measures to protect the power system
from the power grid system.

7
Item
Requirements
Result
•Separate the protection ground of the firewall from
the grounding device or lightning protection
grounding device as far as possible.
•Keep the firewall far away from radio stations, radar
and high-frequency devices working in high current.
•Use electromagnetic shielding when necessary.
Lightning
protection
•The grounding cable of the chassis is reliably
grounded.
•The grounding terminal of theAC power receptacle is
reliably grounded.
•(Optional.) A power lightning arrester is installed.
Electricity safety
•Equip a UPS.
•Locate the power switch in the equipment room. In
case of emergency during operation, switch off the
power switch.
Rack-mounting
requirements
•Make sure the rack is equipped with a good
ventilation system.
•The rack is sturdy enough to support the weight of the
firewall and installation accessories.
•The size of the rack is appropriate for the firewall.
•The front and rearof the rack are a minimum of 0.8 m
(31.50 in) away from walls or other devices.
Safety
precautions
•The firewall is far away from any moist area and heat source.
•The emergency power switch in the equipment room is located.
Tools and
accessories
•Installation accessories supplied with the firewall
•User-supplied tools
Reference •Documents shipped with the firewall
•Online documents

8
2 Installing the firewall
WARNING!
Keep the tamper
-
proof seal on a mounting screw on the chassis cover intact, and if you want to open
the chassis, contact H3C for permission. Otherwise, H3C shall not be liable for any consequence.
The installation procedure is the same for the F5000-AI160 and F5000-E firewalls. This document
installs an F5000-AI160 firewall.
Installation flow
Table2-1 Installation flow for the F5000-AI160/F5000-E firewall
Step
Description
1. Start Before installation, make sure all requirements on the checklist
are met and the firewall is powered off.
2. Mounting the firewall on a
workbench Verify that the workbench is sturdy and reliably grounded.
Ensure a minimum clearance of100 mm (3.94 in) around the air
inlet and outlet vents of the chassis.
3. Installing the firewall in a standard
19-inch rack The firewall is heavy. Both mounting brackets and slide rails are
required to support the weight of the chassis.
4. Grounding the firewall Before installation, make sure the firewall and rack are
grounded correctly and you wear an ESD wrist strap.
5. Installing a fan tray Install compatible fan trays on the firewall.
6. Installing a power supply Before you install a power supply, make sure the power supply
is not connected to any power source and the grounding cable
of the firewall is connected reliably.
7. Installing a drive Install compatible drives on the firewall.
8. Connecting Ethernet cables The firewall provides various ports. Choose compatible
transceiver modules and cables as required. To avoid bodily
injury or device damage, read the restrictions and guidelines
carefully before connection.
9. Connecting power cords Connect compatible power cords to the power supplies.
10. Verifying the installation Verify that the firewall is installed securely and reliably
grounded, and that the power supplies are as required.
Mounting the firewall on a workbench
IMPORTANT:
Avoid placing heavy objects on the firewall.
If a standard 19-inch rack is not available, you can place the firewall on a workbench.
To mount the firewall on a workbench:
1. Verify that the workbench is sturdy and reliably grounded.

9
2. Place the firewall upside down on the workbench and clean the four round holes in the chassis
bottom with a dry cloth.
3. Attach the four rubber feet to the round holes in the chassis bottom.
4. Place the firewall with upside up on the workbench.
Figure2-1 Mounting the firewall on a workbench
Installing the firewall in a standard 19-inch rack
WARNING
!
To avoid bodily injury and device damage, use a minimum of two persons to rack-mount the firewall.
CAUTION:
As a best practice, use
slide rails together with the mounting brackets to support the weight of the
chassis.
To install the firewall in a standard 19-inch rack:
1. Unpack the firewall and accessories.
2. Mark the cage nut installation positions on the rack posts by using the mounting brackets.
Use a front mounting bracket to mark the installation positions on the front rack posts and use a
rear mounting bracket to mark the installation positions on the rear rack posts. Install cage nuts.
Figure2-2 Installing cage nuts

10
3. Attach the front mounting brackets and shoulder screws to both sides of the firewall with M4
screws provided with the firewall.
Figure2-3 Attaching mounting brackets and shoulder screws to the firewall
4. Attach the rear mounting brackets to the rear rack posts. The rear mounting brackets can be
attached to the rear rack posts with the wide flange inside or outside the rack.
Table2-2 Installation methods of rear mounting brackets
Distance between the front and rear rack
posts
Rear mounting bracket installation
method
421 to 556 mm (16.57 to 21.89 in) With the wide flange inside the rack.
264 to 399 mm (10.39 to 15.71 in)
With the wide flange outside the rack.
Caution:
To prevent the rear mounting brackets from
obstructing the closing of the rack door, ensure a
distance greater than 153 mm (6.02 in) between
the rear rack posts and the interior side of the rack
door.

11
Figure2-4 Attaching the rear mounting brackets to the rear rack posts (with the wide
flange inside the rack)
Figure2-5 Attaching the rear mounting brackets to the rear rack posts (with the wide
flange outside the rack)

12
5. Mount the firewall in the rack. Use M6 screws to secure the mounting brackets to the front rack
posts and make sure the shoulder screws rest firmly on the upper edge of the rear mounting
brackets.
Figure2-6 Mounting the firewall in the rack (with the wide flange of the rear mounting
brackets inside the rack)

13
Figure2-7 Mounting the firewall in the rack (with the wide flange of the rear mounting
brackets outside the rack)
Grounding the firewall
WARNING
!
•
Correctly connecting the firewall grounding cable is crucial to lightning protection and EMI
protection.
•
Do not connect the firewall grounding cable to a fire main or lightning rod.
•
The firewall has three grounding points. Use the grounding point at the power supply side to
ground the firewall. The other two grounding points at the side panels are reserved.
You can ground the firewall in one of the following ways, depending on the grounding conditions
available at the installation site.
Grounding the firewall with a grounding strip
If a grounding strip is available at the installation site, connect the grounding cable through the
grounding strip.
To connect the grounding cable:
1. Remove the grounding screw from the firewall chassis.
2. Attach the grounding screw to the ring terminal of the grounding cable.
3. Use a screwdriver to fasten the grounding screw into the grounding hole on the firewall.
4. Remove the hex nut from the grounding strip.
5. Use a pair of needle-nose pliers to bend a hook at the other end of the grounding cable. Attach
the hook to the grounding point, and secure the hook with a screw.

14
Figure2-8 Grounding the firewall with a grounding strip
Grounding the firewall with the grounding terminal on the rack
1. Remove the grounding screw from the firewall chassis.
2. Attach the grounding screw to the ring terminal of the grounding cable.
3. Use a screwdriver to fasten the grounding screw into the grounding hole on the firewall.
4. Remove the grounding screw from the grounding point on the rack.
5. Attach the ring terminal at the other end of the grounding cable to the grounding point on the
rack.
Figure2-9 Grounding the firewall with the grounding terminal on the rack
Installing a fan tray
CAUTION:
•
The firewall comes with the six fan tray slots empty. To ensure good ventilation, make sure the
firewall is fully configured with fan trays.
•
If a fan tray fails during operation, replace the fan tray as soon as possible and keep
the failed fan
tray in place before you replace it. Do not remove multiple failed fan trays at the same time.
Replace the fan trays one after another.
•
Before installation, make sure the fan tray airflow direction
meets the requirements for installation
ventilation.
•Before installation, orient the fan tray with the "TOP" mark on the top.

15
No fan trays are provided with the firewall. Purchase them as needed.
To install a fan tray:
1. Face the rear panel of the firewall.
2. Orient the fan tray with the "TOP" mark on the top. Grasp the handle of the fan tray with one
hand and support the fan tray bottom with the other. Slide the fan tray along the guide rails into
the slot until the fan tray is fully seated in the slot.
Figure2-10 Installing a fan tray
Installing a power supply
CAUTION:
•
Do not install AC and DC power supplies on the same firewall.
•
Before installing a power supply, make sure the power supply is powered off and the grounding
cable is correctly connected.
No power supplies are provided with the firewall. Purchase them as needed. The installation
procedure is similar for power supplies of different models.
To install a power supply:
1. Remove the filler panel from the target slot.
Figure2-11 Removing the filler panel from a firewall
2. Orient the power supply with its power receptacle to the right of the handle. Holding the handle
of the module with one hand and supporting the module bottom with the other, slide the power
supply slowly into the slot along the guide rails.

16
Figure2-12 Installing an AC power supply
Figure2-13 Installing a DC power supply
Installing a drive
CAUTION:
•
To avoid damage to drives, always hold a drive by its sides. Do not touch anycomponents
and do
not squeeze, vibrate, or strike a drive.
•
Drives are hot swappable.
•Install a filler panel in empty drive slots to prevent dust and ESD damage.
IMPORTANT:
•
The firewall does not come with any drives and cannot recognize drives from other vendors.
Purchase drives from H3C as needed.
•
Before using the drive, execute the fdisk and format commands from the CLI to partit
ion and
format the drive.
To install a drive, push the drive into the slot slowly along the guide rails until the drive seats in the
slot.

17
Figure2-14 Installing a drive
Connecting Ethernet cables
Connecting a fiber port
WARNING!
Disconnected optical fibers or transceiver modules might emit invisible laser light. Do not stare into
beams or view directly with optical instruments when the firewall is operating.
CAUTION:
•
Never bend or curve a fiber excessively. The bend radius of a fiber must be not less than 100 m
m
(3.94 in).
•
Keep the fiber end clean.
•
Make sure the fiber connector matches the transceiver module.
•
Before connecting a fiber, make sure the optical power at the receiving end does not exceed the
transceiver module's upper threshold of the optical receive power. If the optical power at the
receiving end exceeds the threshold, the transceiver module might be damaged.
The firewall supports the following transceiver modules:
•
GE SFP copper transceiver modules.
•
GE SFP transceiver modules.
•
10GE SFP+ transceiver modules.
•
40G QSFP+ transceiver modules.
•
100G QSFP+ transceiver modules.
For the transceiver module specifications, see port specifications in "Appendix A Chassis views and
technical specifications."
No transceiver module is provided with the firewall. As a best practice, use H3C transceiver
modules.
1

18
Figure2-15 GE SFP copper transceiver module
Figure2-16 GE SFP transceiver module
Figure2-17 10GE SFP+ transceiver module
Figure2-18 QSFP+ transceiver module with an MPO port
Figure2-19 QSFP+ transceiver module with an LC port
To connect the firewall to the network through an optical fiber:
1. Remove the dust plug from the fiber port.
2. Pull the bail latch on the transceiver module upwards. Skip this step if the bail latch is plastic.
Then correctly orient the transceiver module.
3. Taking the transceiver module by its two sides, push the transceiver module gently into the port
until you feel it snap into place.
