HAEGER Xplorer FX-30 User manual

EN User Manual
PT Manual de Utilização
ES Manual de Instrucciones
Model:
Xplorer FX-30
PMR –2 Way Rádio
Emissor / Receptor PMR

EN The features described in this manual are published
subject to modifications.
PT As características descritas neste manual são
publicadas sob reserva de modificação.
ES Las funciones descritas en este manual pueden sufrir
modificaciones.
The CE Symbol indicates that the unit complies with the
essential requirements of the R&TTE directive 1995/5/EC.
The (!) symbol next to the CE mark indicates that the PMR
standard is not allowed in all European countries.
O símbolo CE indica que esta unidade cumpre com os
requisitos essenciais da Directiva R&TTE 1995/5/CE.
O símbolo (!) junto da marca CE indica que a norma PMR não é
autorizada em todos os países europeus.
El símbolo CE indica que la unidad cumple con los requisitos
esenciales de la Directiva R&TTE.
El símbolo (!) al lado de la marca CE indica que la norma PMR
no está autorizada en todos los países europeos.
For use / Para uso em / Para su uso en:
AT, BE, CH, CY, CZ, DE, DK, EE, GR, ES, FI, FR, GB, HU, IRL, I, LT,
LU, LV, MT, NL, PL, PT, SE, SK, SI

EN - Index
1INTRODUCTION..................................................................................1
2INTENDED PURPOSES .......................................................................... 1
3SAFETY INSTRUCTIONS......................................................................... 1
3.1 General............................................................................................1
3.2 Burning Injuries...............................................................................1
3.3 Personal Safety ...............................................................................2
3.4 Poisoning Danger ............................................................................2
3.5 Legal................................................................................................2
3.6 Notes...............................................................................................2
4INCLUDED IN PACKAGE ........................................................................3
5CLEANING AND MAINTENANCE............................................................. 3
6DISPOSAL OF THE DEVICE .................................................................... 3
7GETTING STARTED..............................................................................4
7.1 Diagram and functions....................................................................4
7.2 LCD Screen .....................................................................................4
7.3 Removing Installing the Belt Clip ....................................................5
7.4 Battery Installation .........................................................................5
7.4.1 Charging the batteries .................................................................6
8OPERATION ......................................................................................7
8.1 Transmitting range..........................................................................7
8.2 Turning the Unit ON/OFF................................................................7
8.3 Adjusting the Speaker volume........................................................7
8.4 Receiving a call................................................................................8
8.5 Transmitting (sending)....................................................................8
8.6 Changing Channels..........................................................................8
8.7 Calling (paging) tone .......................................................................9
8.8 Key tone On/Off setting..................................................................9
8.9 Roger beep......................................................................................9
8.10 VOX (voice activated transmission) mode ..................................10
8.11 Monitor.......................................................................................10
8.12 Channel auto scan.......................................................................10
8.13 Key lock .......................................................................................11
9AUXILIARY FEATURES ........................................................................11
9.1 LCD Screen Back Light...................................................................11

9.2 Power saving.................................................................................11
9.3 Battery charge level/Low battery indication ................................12
10 EFFECTIVE RANGE ..........................................................................12
11 SPECIFICATIONS .............................................................................13
12 CHANNEL FREQUENCY TABLE............................................................13
13 WARRANTY ..................................................................................13
13.1 Warranty Period..........................................................................13
13.2 Warranty Handling......................................................................13
13.3 Warranty Exclusions ...................................................................14
14 CE CONFORMITY DECLARATION ........................................................14

PT - Índice
1INTRODUÇÃO ..................................................................................15
2FINALIDADE ESPECÍFICA .....................................................................15
3INSTRUÇÕES DE SEGURANÇA .............................................................. 15
3.1 Geral..............................................................................................15
3.2 Queimaduras.................................................................................15
3.3 Segurança Pessoal.........................................................................16
3.4 Perigo de Envenenamento............................................................16
3.5 Restrições legais............................................................................16
3.6 Notas:............................................................................................17
4CONTEÚDO DO PACOTE.....................................................................17
5MANUTENÇÃO E LIMPEZA.................................................................. 17
6ELIMINAÇÃO DO APARELHO ................................................................17
7PRIMEIROS PASSOS ..........................................................................18
7.1 Diagrama e funções ......................................................................18
7.2 Visor LCD ......................................................................................18
7.3 Retirar/Instalar o suporte de cinto ...............................................19
7.4 Instalação das baterias .................................................................19
7.4.1 Carregamento das baterias........................................................20
8OPERAÇÃO .....................................................................................21
8.1 Alcance de Transmissão................................................................21
8.2 Ligar e Desligar o aparelho............................................................21
8.3 Regular o volume do altifalante....................................................21
8.4 Receber uma chamada .................................................................22
8.5 Transmitir (enviar) ........................................................................22
8.6 Mudança de canais .......................................................................22
8.7 Tons de chamada (paging)............................................................23
8.8 Activar ou Desactivar o Tom de Tecla...........................................23
8.9 Definir Tom Fim de chamada (Roger Bip).....................................23
8.10 Função VOX (Voz Activada).........................................................24
8.11 Monitorização.............................................................................24
8.12 Activar a procura automática de Canal.......................................25
8.13 Bloqueio do teclado....................................................................25

9FUNÇÕES AUXILIARES........................................................................25
9.1 Iluminação do visor LCD................................................................25
9.2 Poupança de energia ....................................................................26
9.3 Nível de carregamento das baterias/pilhas..................................26
10 ALCANCE EFECTIVO ........................................................................26
11 ESPECIFICAÇÕES.............................................................................27
12 TABELA DE FREQUÊNCIAS.................................................................27
13. GARANTIA ..................................................................................27
13.1 Período de Garantia....................................................................27
13.2 Modo de Funcionamento da Garantia........................................27
13.3 Excluído da Garantia ...................................................................28
14. DECLARAÇÃO DE CONFORMIDADE.....................................................29

ES - Índice
1INTRODUCCIÓN................................................................................ 30
2FINALIDAD ESPECÍFICA ......................................................................30
3INSTRUCCIONES DE SEGURIDAD........................................................... 30
3.1 General..........................................................................................30
3.2 Quemaduras .................................................................................30
3.3 Seguridad Personal .......................................................................31
3.4 Peligro de Envenenamiento..........................................................31
3.5 Restricciones legales.....................................................................31
3.6 Notas:............................................................................................32
4CONTENIDO DEL PAQUETE..................................................................32
5MANUTENÇÃO E LIMPEZA.................................................................. 32
6ELIMINACIÓN DEL APARATO................................................................ 32
7PRIMEROS PASOS.............................................................................33
7.1 Diagrama y funciones ...................................................................33
7.2 Pantalla LCD .................................................................................33
7.3 Retirar / Instalar el soporte de cinturón .......................................34
7.4 Instalación de las baterías.............................................................34
7.4.1 Carga de las baterías..................................................................35
8OPERACIÓN ....................................................................................36
8.1 Alcance de Transmisión ................................................................36
8.2 Encender y apagar el aparato .......................................................36
8.3 Ajuste del volumen del altavoz.....................................................36
8.4 Recibir una llamada ......................................................................37
8.5 Transmitir (enviar) ........................................................................37
8.6 Cambio de canales ........................................................................37
9FUNCIONES AUXILIARES.....................................................................40
9.1 Iluminación de la pantalla LCD......................................................40
9.2 Ahorro de energía.........................................................................41
9.3 Nivel de carga de las pilas.............................................................41
10 ALCANCE EFECTIVO ........................................................................41
11 ESPECIFICAÇÕES.............................................................................42
12 TABLA DE FRECUENCIAS................................................................... 42

13. GARANTÍA ..................................................................................42
13.1 Período de Garantía....................................................................42
13.2 Modo de Funcionamiento de la Garantía...................................42
13.3 Excluido de la Garantía ...............................................................43
14. DECLARACIÓN DE CONFORMIDAD .....................................................44

English
1
1 INTRODUCTION
Thank you for purchasing the Xplorer FX-30.It’s a short range, low powered radio
communication device that has no running costs other than the minimal cost of
the batteries.
The Xplorer FX-30 operates on Private Mobile Radio frequencies and can be used
in any country where PMR446 frequencies are authorised as indicated on the
packing box and in this manual.
2 INTENDED PURPOSES
It can be used for different professional as well as for recreational purposes. For
example: to keep in contact during travelling with 2 or more cars, biking, skiing. It
can be used to keep in contact with your children when they are playing outside,
etc.
Restriction:
Check the local regulations before using it outside the country
where it was purchased. The standard may be prohibited in
this country.
3 SAFETY INSTRUCTIONS
3.1 General
Please read carefully through the following information concerning safety and
proper use. Make yourself familiar with all functions of the device. Keep this
manual on a safe place for future use.
3.2 Burning Injuries
If the cover of the antenna is damaged, do not touch because when an
antenna comes in contact with the skin, a minor burn may result when
transmitting.
Batteries can cause property damage such as burns if conductive material
such as jewellery, keys or beaded chains touches exposed terminals. The
material may complete an electrical circuit (short circuit) and become quite
hot. Exercise care in handling any charged battery, particularly when placing
it inside a pocket, purse or other container with metal objects. Do not replace
or charge batteries in a potentially explosive atmosphere. Contact sparking
may occur while installing or removing batteries and cause an explosion.

English
2
3.3 Personal Safety
Use in cars: do not place your device in the area over an air bag or in the air
bag deployment area. Air bags inflate with great force. If a communicator is
placed in the bag deployment area and the air bag inflates, the communicator
may be propelled with great force and cause serious injury to the occupants
of the vehicle.
Keep the radio at least 15 centimetres away from a pacemaker.
Turn your radio OFF as soon as interference is taking place with medical
equipment.
Do not replace batteries in a potentially explosive atmosphere. Contact
sparking may occur while installing or removing batteries and cause an
explosion.
Turn your communicator off when in any area with a potentially explosive
atmosphere. Sparks in such areas could cause an explosion or fire resulting in
bodily injury or even death.
Never throw batteries in fire as they may explode.
3.4 Poisoning Danger
Keep the batteries away from small children.
3.5 Legal
In some countries it is prohibited to use your PMR while driving a vehicle. In
this case leave the road before using the device.
Turn your unit OFF when on board an aircraft when instructed to do so. Any
use of the unit must be in accordance with airline regulations or crew
instructions.
Turn your unit OFF in any facilities where posted notices instruct you to do so.
Hospitals or health care facilities may be using equipment that is sensitive to
external RF energy.
Replacing or modifying the antenna may affect the PMR radio specifications
and violate the CE regulations. Unauthorised antennas could also damage the
radio.
3.6 Notes
Does not touch the antenna while transmitting, it could affect the range.
Remove the battery if the device is not going to be used for a long period.

English
3
4 INCLUDED IN PACKAGE
2 x PMR Xplorer FX-30
6 x rechargeable AAA size batteries
1 x Y type Power adaptor charger
2 x Belt Clips
1 x User manual
5 CLEANING AND MAINTENANCE
To clean the unit, wipe with a soft cloth dampened with water. Don’t use a
cleaner or solvents on the unit; they can damage the case and leak inside,
causing permanent damage.
Battery contacts may be wiped with a dry lint-free cloth.
If the unit gets wet, turn it off and remove the batteries immediately. Dry the
battery compartment with a soft cloth to minimize potential water damage.
Leave the cover off the battery compartment overnight or until completely
dry. Do not use the unit until completely dry.
6 DISPOSAL OF THE DEVICE
Dispose of the unit and used batteries in an environment
friendly manner.
Do not dispose of batteries in normal household garbage.

English
4
7GETTING STARTED
7.1 Diagram and functions
7.2 LCD Screen
Channel Number: Changes from 1 to 8 as selected
by the user
Displays the current battery charge level
Displays the current Speaker volume level
Displayed when the Key Lock feature is activated
Display when transmitting a signal
Display when receiving a signal
SCAN Show when the Scan feature is turned ON
VOX Show when the unit is in VOX (voice activated) mode
Charger
connector

English
5
Figure 1
Figure 2
Belt Clip latch
7.3 Removing Installing the Belt Clip
1. To remove the clip from the unit, push the belt clip
towards the antenna, while pulling the clip latch as
shown in Fig.1.
2. When re-installing the belt clip, slide the belt clip
into the slot as shown in figure 2. A click indicates
the Belt Clip is locked into position.
7.4 Battery Installation
Caution: Observe the proper battery polarity orientation when installing
batteries. Incorrect positioning can damage both the batteries and the
unit.
1. Slide down the battery compartment cover.
2. Insert 3 AAA size batteries by following the polarity marking inside the
battery compartment as shown in Figure 3.
3. Replace the battery compartment cover. See Figure 4.
Notes:
Use only same type and make of batteries on the PMR units.
The PMR units have a build Power Saver (PS) for maximum battery
life, but when not in use, turn the units OFF to conserve battery power.
Remove the batteries if the units will not be used for long period of
time.
Figure 3
Figure 4

English
6
7.4.1 Charging the batteries
1. Insert the DC JACK of the 7.5V
DC/300mA adaptor into the
charge connector on top of
the unit.
2. Plug the mains adaptor into a
230V AC, 50Hz main socket
with the switch on the socket
set to OFF. Then switch ON the
main socket.
3. Use only power supply listed
in the user Instruction.
Model No. TEE75P030
4. Use only batteries listed in the
user instruction:
Jiang Su CEL Co.,Ltd.,3X1.2V
AAA size/600mAh Ni-MH Rechargeable batteries.
The PMR must be charged using the mains adaptor provided. Using any
other adaptor will result in non-compliance with EN60950-1 and will
invalidate any approval/warranty for this product.
During charging, the battery level indicator icon will start flashing on the display in
both off mode and PMR on mode. During charging mode, the PMR transmit and
receive is disabled.
It takes about 10 hours to recharge the battery fully if they've become completely
run down. New batteries take up to 12 hours to charge fully.
Important: Read these safety warnings before you charge the batteries.
Don’t try to recharge non-rechargeable batteries.
Make sure the battery compartment cover is securely locked in place
when you are charging the batteries.
Dispose of used batteries safely and in a way that will not harm the
environment - never try to burn them or put them anywhere, they could
get burnt or punctured.
Don’t leave dead batteries in your handset. They might leak if you do
and damage the unit.

English
7
8 OPERATION
8.1 Transmitting range
The talk range depends on the environmental and terrain. It should be longest (up
to about 5 km) in wide open spaces, without obstructions such as hills or buildings.
Don’t try to use two PMR units which are less than 1.5m (5feet) apart. If you do,
you may experience interference.
Important safety warning
To reduce radio frequency exposure when you are using your PMR, hold
the unit at least 5cm (2 inches) away from your face.
Never use your PMR outdoors during a thunderstorm.
Don’t use the PMR in the rain.
If your PMR ever gets wet, turn it off and remove the battery. Dry the
battery compartment and leave the cover off for a few hours. Don’t use
the unit until it is completely dry.
Keep the PMR out of the reach of babies and young children.
8.2 Turning the Unit ON/OFF
To Turn ON
a. Press and hold the (POWER) button. A special "beep”sound
will be heard. The LCD screen will be illuminated by an orange
light for several seconds, and will display the current channel.
To switch OFF
b. Press and hold the (POWER) button. A “beep” sound will be
heard and the LCD screen will turn blank.
8.3 Adjusting the Speaker volume
There are 8 volume levels; the current speaker volume level is
displayed on the LCD screen.
To adjust the speaker volume level, press the (UP)button to
increase, or press the (DOWN) button to decrease. The LCD
screen will display the speaker volume icon bars ascending or
descending respectively.

English
8
8.4 Receiving a call
The unit is continuously in received mode when it is turned on and
not transmitting. When a signal is received on the current channel
the receive signal icon will be displayed on the LCD screen.
8.5 Transmitting (sending)
The transmission on these units is “one way-at-a-time.” While you are speaking,
you can not receive a transmission.
These PMR’s are an open-license band. Always identity yourself when are
transmitting on the same channel.
a. Press and hold the PTT (push to talk) button to transmit your
voice. The transmit signal icon will display on the LCD screen.
b. Hold the unit in a vertical position with the MIC (microphone) 5
cm away from the mouth while holding the PTT button; speak
into the MIC (microphone) in a normal tone of voice.
c. Release the PTT button when you have finished transmitting.
Important
In order for other people to receive your transmission, they must also be
on the same channel that you are currently using. Refer to the “changing
Channels”section for more information.
When the PTT and/or CALL buttons are continuously pressed, your PMR
can not receive any transmissions.
8.6 Changing Channels
The PMR has 8 available channels to communicate with other PMR users within a
range; you must all have your PMR tuned in to the same channel.
a. Press the MENU button, the current channel number and
channel icon “ch”on the LCD screen will start blinking.
b. While it is blinking, press the (UP)or (DOWN) button to
select the desired channel. The channel changes from 1 to 8 or
from 8 to 1.
c. Press the PTT button to confirm your setting and return to
standby mode.

English
9
Note: Refer to the “Channel Table” section of this Owner’s Manual for
detailed frequency listing.
8.7 Calling (paging) tone
You can use the call button to send a tone to other users on the same channel.
To activate this feature:
a. Press the MENU button two times, the “CA” icons flashes on
the display.
b. Press the (UP)button or (DOWN) to select the desired call
tone (1 to 5). Or set the Call tone “Off” if you do not want to
activate this function.
c. Press the PTT button to confirm your setting.
8.8 Key tone On/Off setting
This feature allows the handset to sound a confirmation tone whenever keys are
pressed.
To turn the key-tone On or Off:
a. Press the MENU button three times, the icons flashes on the
display.
b. Press the (UP)button to enable or (DOWN) to disable the
Key tone feature.
c. Press the PTT button to confirm your setting.
8.9 Roger beep
The Roger beep is a tone which is automatically transmitted
whenever the PTT button is released. This alerts the receiving party
that you have ended the transmission, and you are now in receive
mode.

English
10
To activate this feature:
a. Press the MENU button four times, the icons flashes on the
display.
b. Press the (UP)button to activate or (DOWN) to deactivate
the Roger tone feature.
c. Press the PTT button to confirm your setting.
8.10 VOX (voice activated transmission) mode
In VOX mode your handset will transmit whenever it detects your Voice (or other
noise) without the PTT button having to be pressed.
To turn VOX mode ON and OFF:
a. Press the MENU button five times. VOX icon is displayed and
“OF” flashes on the LCD panel.
b. Press the (UP)button to activate or (DOWN) to deactivate
the VOX feature.
c. Press the PTT button to confirm your setting. As long as the
handset is in VOX mode, VOX is shown steadily on the display.
VOX operation is not recommended if the PMR will be used in a noisy or
windy environment.
8.11 Monitor
You can use the Monitor feature to check for weak signals on the current channel.
a. To activate the monitor function, press the MENU and (UP)
button at the same time.
b. If you hear constant noise and hissing sound, press the MENU
button once to turn Off the monitor function.
8.12 Channel auto scan
Channel scan perform searches for active signals in an endless loop from channels
1 to 8. This allows you to find other radios without having to change channel. To
activate this feature:

English
11
a. Press the MENU and (DOWN) button. The channel number
on the LCD screen changes rapidly until an active signal is
detected.
b. When an active signal (on one of the 8 channels) is detected,
channel scan pauses on the active channel.
c. Press the PTT button to communicate through the active signal
channel, then the channel scan will be deactivated. Or press
the (UP)or (DOWN) button to continue the channel
scanning.
d. Press the MENU button to stop the channel scanning operation.
8.13 Key lock
The key lock feature allows the user to disable the UP or DOWN and the MENU
buttons so that the PMR settings can not be changed accidentally.
a. To activate the key lock feature, press and hold the MENU
button until the key lock icon appears on the LCD screen.
b. To deactivate the key lock feature, press and hold the MENU
button again until the key lock icon disappears on the LCD
screen. The PTT, CALL, and the POWER buttons will remain
functional even if the key lock feature is activated.
9 AUXILIARY FEATURES
9.1 LCD Screen Back Light
Every time a button is pressed (except PTT and CALL button), the LCD Screen back
light will illuminate for 4 seconds.
9.2 Power saving
Your PMR unit has special circuitry designed to extend the life of your battery.
When the unit is not used for 4 seconds, it will automatically switch into a low
power mode. The power saving feature does not affect the PMR ability to receive
transmission, when a signal is detected, It automatically returns to full power
mode.

English
12
9.3 Battery charge level/Low battery indication
The BATTERY CHARGE LEVEL is indicated by the number of rectangles present
inside the BATTERY icon on the LCD Screen.
-Battery charge capacity at full level
-Battery 2/3 charged
-Battery 1/3 charged. At this level, connect the charger and leave
the battery charging.
-Battery charge at empty level. The empty battery symbol start
flashing and the unit emits 3 "beep" tones.
-Battery totally empty level. At this level the unit will emit 3 beep
tones and flash the icon for 3 minutes and then automatically
turn OFF.
10 EFFECTIVE RANGE
The transmission range of the product is dependent on the environment terrain
where it is being used. The following diagram attempts to guide the user on the
sort of performance to expect for everyday use.
Signal Strength Optimum (open area)(1)
Medium ground based
Obstruction (2)
Heavily built up area (3)
0 Range (Km) 5 Range Slope
Range check
The transmission range will be affected as shown in the above diagram.
The transmitting range typical values for different environment conditions will be
(1) 5 km (2) 2.5 km (3) 1250m. It should be remembered that these are only guide
values as actual achieved distances will be dependent on the environment and
terrain.
