HAI UPB™ Lumina Mode Controller

Installation and Operating Instructions

For the following Model:

38A00-3 HAI UPB™ Lumina Mode Controller

READ THESE INSTRUCTIONS BEFORE INSTALLING DEVICE

This HAI UPB™ Lumina Mode Controller is intended for installation in accordance with the National Electrical Code and local

regulations. It is recommended that a qualified electrician perform this installation. Retain these instructions for reference.

This product is for indoor use only. Connect only copper or copper clad wire to this device.

Important Notes Prior To Installation

Be sure that all power to the load has been disconnected by turning off the circuit breaker. Installing an HAI UPB™ Lumina Mode

Controller with power on may expose you to dangerous voltage and may damage the device.

HAI UPB™ Lumina Mode Controller Overview

The HAI UPB™ Lumina Mode Controller (Figure 1) is used to easily change the mode before leaving your house, going to bed,

arriving home, going on vacation, entertaining for the evening, or any other special event. It uses the UPB™ two-way powerline

communication technology to communicate with a Lumina controller to initiate programs for preset lights and temperatures.

The HAI UPB™ Lumina Mode Controller has six pushbuttons labeled AWAY, HOME, SLEEP, VAC (Vacation), SPCL (Special),

and PARTY. Each pushbutton is slightly backlit so that the buttons can be seen in a dark room. The pushbuttons of the current

Lumina Mode will be distinctly illuminated, so that you can always tell which mode you are currently in just by glancing at the

Lumina Mode Controller.

To change the current mode from a Lumina Mode Controller, simply press the desired mode button. The new mode button will

illuminate and the lighting and temperatures in your home will be changed accordingly.

AWAY

SLEEP

SPCL

HOME

PARTY

VAC

Figure 1 - HAI UPB™ Lumina Mode Controller

38I00-3, Rev B

Changing Switch Color

The color of the HAI UPB™ Lumina Mode Controller may be changed to complement

the interior décor. The HAI UPB™ Lumina Mode Controller is supplied with a white

bezel. Additional colors are available; contact your HAI distributor for more

information. When changing the bezel, make sure that the HAI UPB™ Lumina Mode

Controller is disconnected from all power, and proceed as follows:

1. The bezel attaches to the HAI UPB™ Lumina Mode Controller with two small

Philips head screws: one on the upper-right corner and one on the lower-left corner

(Figure 2).

2. Using a small-bladed Philips screwdriver, unscrew each of the two screws.

Remove the bezel from the back housing.

3. Install the new bezel by aligning the mounting holes on the bezel with the

installation pins on the back housing. Secure bezel to back housing with the two

Phillips screws that were removed in Step 1.

INSTALLATION INSTRUCTIONS

1. Be sure that all power at the wall box has been disconnected by turning off the circuit breaker.

2. If applicable, remove the faceplate from the existing device, remove the existing device from the wall box, and disconnect the

wires from the existing device. Identify the “Line” (black) and "Neutral" (white) wires.

3. Remove ¾” of insulation from each of the wires on the HAI UPB™ Lumina Mode Controller. Install the HAI UPB™ Lumina

Mode Controller by connecting wires per wiring configuration shown in Figure 3.

4. After all connections have been made, be certain that all wire connectors are firmly attached and there is no exposed copper.

5. Gently place the wires and HAI UPB™ Lumina Mode Controller into the wall box with the “AWAY” pushbutton at the top of

device. Using the supplied screws, attach the HAI UPB™ Lumina Mode Controller to the wall box.

6. Before installing the faceplate, restore power to the circuit for testing.

7. After testing the HAI UPB™ Lumina Mode Controller for proper local operation, install a Decora-style faceplate over the HAI

UPB™ Lumina Mode Controller.

BLACK WHITE

LINE

NEUTRAL

38A00-3

CIRCUIT

MAIN

PANEL

BREAKER

120VAC

60Hz

LUMINA

MODE

CONTROLLER

AWAY

SLEEP

SPCL

HOME

PARTY

VAC

Figure 3 – Wiring Diagram

Figure 2 – Changing Switch Color

HAI UPB™ LUMINA MODE CONTROLLER OPERATION

Although the HAI UPB™ Lumina Mode Controller will perform differently once it is configured by the Lumina controller, the

following describes the operation of the HAI UPB™ Lumina Mode Controller in its factory default configuration.

The HAI UPB™ Lumina Mode Controller has six pushbuttons labeled AWAY, HOME, SLEEP, VAC, SPCL, and PARTY, which

(by factory default) are used to control six lighting scenes. When the pushbutton labeled “AWAY” is pressed, the LED behind the

“AWAY” pushbutton is illuminated and any other is turned off. When the pushbutton labeled “HOME” is pressed, the LED behind

the “HOME” pushbutton is illuminated and any other is turned off. When one of the pushbuttons labeled “SLEEP”, “VAC”, “SPCL”,

or “PARTY” is pressed, the LED behind the respective pushbutton is illuminated and any other is turned off. No more than one

pushbutton is illuminated at a time.

Pushbutton Operation

In its factory default configuration, the “AWAY” pushbutton will brighten the UPB™ Wall Switch Dimmers to 100% at each switch’s

default fade rate when pressed. When the “AWAY” pushbutton is double-tapped, the UPB™ Wall Switch Dimmers will snap to

100%. When pressed or double-tapped, the “AWAY” pushbutton will illuminate and any others are turned off. The “AWAY”

pushbutton is also used to brighten the last lighting scene that was turned on. When the “AWAY” pushbutton is pressed and held

down, the UPB™ Wall Switch Dimmers will slowly brighten, and then stop brightening when the “AWAY” pushbutton is released.

In its factory default configuration, the “HOME” pushbutton will fade the UPB™ Wall Switch Dimmers to 0% (off) at each switch’s

default fade rate when pressed. When the “HOME” pushbutton is double-tapped, the UPB™ Wall Switch Dimmers will snap to 0%.

When pressed or double-tapped, the “HOME” pushbutton will illuminate and any others are turned off. The “HOME” pushbutton is

also used to dim the last lighting scene that was turned on. When the “HOME” pushbutton is pressed and held down, the UPB™ Wall

Switch Dimmers will slowly dim, and then stop dimming when the “HOME” button is released.

In its factory default configuration, the “SLEEP” pushbutton will brighten the UPB™ Wall Switch Dimmers to 80% at each switch’s

default fade rate when pressed or double-tapped. When pressed, the “SLEEP” pushbutton will illuminate and any others are turned

off.

In its factory default configuration, the “VAC” pushbutton will brighten the UPB™ Wall Switch Dimmers to 60% at each switch’s

default fade rate when pressed or double-tapped. When pressed, the “VAC” pushbutton will illuminate and any others are turned off.

In its factory default configuration, the “SPCL” pushbutton will brighten the UPB™ Wall Switch Dimmers to 40% at each switch’s

default fade rate when pressed or double-tapped. When pressed, the “SPCL” pushbutton will illuminate and any others are turned off.

In its factory default configuration, the “PARTY” pushbutton will brighten the UPB™ Wall Switch Dimmers to 20% at each switch’s

default fade rate when pressed or double-tapped. When pressed, the “PARTY” pushbutton will illuminate and any others are turned

off.

CONFIGURING THE HAI UPB™ LUMINA MODE CONTROLLER

The HAI UPB™ Lumina Mode Controller is designed to set the mode in a Lumina system, but also has several configuration options:

Option Factory Default CONFIGURED AS LUMINA MODE CONTROLLER

“AWAY” Pushbutton On Button / Link 001 Sets the Lumina mode to Away.

“HOME” Pushbutton Off Button / Link 002 Sets the Lumina mode to Home.

“SLEEP”, “VAC”, “SPCL”,

and “PARTY” Pushbutton

Scene Activator / Links 003,

004, 005, 006 – respectively

Sets the Lumina mode to Sleep, Vacation, Special, and Party,

respectively.

“AWAY”, “HOME”, “SLEEP”,

“VAC”, “SPCL”, and

“PARTY” LED Indicators

Each LED Indicator is assigned

to its pushbutton’s Link ID

Each LED Indicator is mutually

exclusive (only one LED is on

at a time).

When the Lumina mode is changed, the LED indicator behind

the respective pushbutton is illuminated and any other is turned

off.

UPB Transmission Attempts 2 No change

UPB ID NID = 255

UID = 080

The Lumina controller configures Network ID (NID), Unit ID

(UID), Network Password, Network Name, Room Name,

Device Name, etc.

LED Brightness High No change.

LED Backlighting Enabled No change.

Setup Mode

To configure the HAI UPB™ Lumina Mode Controller using a Lumina keypad, it must be put into Setup Mode as follows:

Step Operation

1 Press and hold the “AWAY” and “HOME” pushbuttons simultaneously for at least 3 seconds.

2 All of the LED indicators will blink to indicate that the HAI UPB™ Lumina Mode Controller is in Setup Mode.

Configuring the HAI UPB™ Lumina Mode Controller from a Lumina Keypad

HAI UPB™ Lumina Mode Controllers reside on the 8th unit in any Room. Configure the HAI UPB™ Lumina Mode Controller on

the 8th unit in a Room as follows:

Step Operation

1 Put the HAI UPB™ Lumina Mode Controller into Setup Mode (as described above).

2 On the Lumina keypad, from the main menu or top-level display, press 6 (STATUS), and then press 1 (CTRL).

3 Enter the Unit Number of the HAI UPB™ Lumina Mode Controller followed by the ' # ' key, and then press ' # # '.

4 The display will provide you with step-by-step configuration status. When complete, the display shows “COMPLETED”.

Reset to Factory Default Settings

To reset the HAI UPB™ Lumina Mode Controller to factory default settings:

Step Operation

1 Press and hold the “AWAY” and “HOME” pushbuttons simultaneously for at least 3 seconds.

2 All of the LED indicators will blink to indicate that the HAI UPB™ Lumina Mode Controller is in Setup Mode.

3 Press and hold the “SLEEP” and “PARTY” pushbuttons simultaneously for at least 3 seconds.

4 The LED indicators will stop blinking and the “SLEEP” and “PARTY” pushbuttons will illuminate to indicate that it has

been reset.

SPECIFICATIONS

Model Number 38A00-3

Number of Backlit Pushbuttons with LED Indicators 6

Connections 18 GA

Dimensions 4.1 x 1.7 x 1.5

Weight 0.25 lb.

Mounting Standard J Box

Input Power 120 ± 12 VAC

Input Frequency 60 ± 3 Hz

Operating Temperature -40 °F to 104 °F

Note: It is normal for this switch to make a slight buzzing sound during operation.

LIMITED WARRANTY

HAI warrants this product against defects in material and workmanship, under normal use and service, for a period of two (2) years from the date of

purchase. During the warranty period, HAI will repair or replace, at its sole option, if this product fails due to defect. This warranty does not cover the

cost of removal or reinstallation of any product. This warranty does not cover failure caused by normal wear, damage to the product while in

your possession (other than damage caused by defect or malfunction), or by its improper installation, including failure to follow the written

installation and operation instructions, alterations, misuse, or abuse. The remedies provided for in this warranty are the sole and exclusive

remedies thereof. In no event shall HAI be liable for incidental expenses or consequential loss or damages. For the complete HAI Warranty for USA

policy, see the HAI web site at www.homeauto.com.

Any implied warranties, including warranties of merchantability and fitness for particular use or purpose are limited to a period of two (2)

years from purchase date. This warranty gives you specific legal rights, and you may have other legal rights, which vary from state to state. Some

limitations may not apply to you.

For warranty and repair service within the continental United States, send defective unit carefully packaged, postage prepaid, along with description of
