WALL MOUNTED TYPE INDOOR UNITS
R410A MULTI SPLIT SERIES ROOM AIR CONDITIONER
OPERATION & INSTALLATION MANUAL
Please read this manual carefully before using this air conditioner.
Please keep this manual safely for future use.
AS072XVERA
AS092XVERA
AS122XVERA
AS182XVERA
No.0010576789 B

Contents
Cautions .............................................................................................
Safety precautions...............................................................................
Parts and Functions ...........................................................................
Operation.........................................................................................
Notes for safety ...................................................................................
Operation and Maintenance .................................................................
Trouble shooting .............................................................................
Customer Need-to-know .....................................................................
Instructions to installation...............................................................
When trouble happens..........................................................................
Failure code .........................................................................................
1-2
3-5
6-7
8-18
19
20
21-22
23
24-29
30
31

Cautions
1
Disposal of the old air conditioner
Before disposing an old air conditioner
that goes out of use, please make sure it's
inoperative and safe. Unplug the air
conditioner in order to avoid the risk of
child entrapment.
It must be noticed that air conditioner
system contains refrigerants, which require
specialized waste disposal. The valuable
materials contained in a air conditioner can
be recycled. Contact your local waste
disposal center for proper disposal of an
old air conditioner and contact your local
authority or your dealer if you have any
question. Please ensure that the pipework
of your air conditioner does not get
damaged prior to being picked up by the
relevant waste disposal center, and
contribute to environmental awareness by
insisting on an appropriate, anti-pollution
method of disposal.
Disposal of the packaging of your new
air conditioner
All the packaging materials employed in
the package of your new air conditioner
may be disposed without any danger to the
environment.
The cardboard box may be broken or cut
into smaller pieces and given to a waste
paper disposal service. The wrapping bag
made of polyethylene and the polyethylene
foam pads contain no fluorochloric
hydrocarbon.
Consult your local authorities for the name and
address of the waste materials collecting
centers and waste paper disposal services
nearest to your house.
Safety Instructions and Warnings
Before starting the air conditioner, read the
information given in the User's Guide
carefully. The User's Guide contains very
important observations relating to the
assembly, operation and maintenance of the
air conditioner.
The manufacturer does not accept
responsibility for any damage that may arise
due to non-observation of the following
instructions.
Damaged air conditioners are not to be
put into operation. In case of doubt, consult
your supplier.
Use of the air conditioner is to be carried
out in strict compliance with the relative
instructions set forth in the User's Guide.
Installation shall be done by professional
people, and don't install the unit by yourself.
All these valuable materials may be taken to a
waste collecting center and used again after
adequate recycling.
For the purpose of safety, the air
conditioner must be properly grounded in
accordance with specifications.
Always remember not to operate the air
conditioner before opening its inlet grill.

4. The wiring method should be in line with
the local wiring standard.
5. The power cable and connecting cable are
self-provided.The requirement of the
connecting cable:
All the cables shall have got the local
authentication certificate.
6. The breaker of the air conditioner should
be all-pole switch; and the distance between
its two contacts should be no less than 3mm.
Such means for disconnection must be
incorporation in the fixed wiring.
7. The waste battery shall be disposed
properly.
8. The indoor unit installation height is at
least 2m.
9. The appliance is not intended for ase
young children or infirm persons without
super vision.
10. Young children should be supervised to
ensure that they do not play with the
applience.
2
All electrical repairs must be carried out
by qualified electricians. Inadequate repairs
may result in a major source of danger for
the user of the air conditioner.
Do not damage any parts of the air
conditioner that carry refrigerant by
piercing or perforating the air conditioner's
tubes with sharp or pointed items, crushing
or twisting any tubes, or scraping the
coatings off the surfaces. If the refrigerant
spurts out and gets into eyes, it may result
in serious eye injuries.
Do not obstruct or cover the ventilation
grille of the air conditioner. Do not put
fingers or any other things into the
inlet/outlet and swing louver.
Do not allow children to play with the air
conditioner. In no case should children be
allowed to sit on the outdoor unit.
Specifications
The refrigerating circuit is leak-proof.
1. Applicable ambient temperature range:
The machine is adaptive in following
situation
2. If the supply cord is damaged, it must be
replaced by the manufacturer or its service
agent or a similar qualified person.
3. If the fuse on PC board is broken, please
change it with the type of T 3.15A /250VAC
Cooling
Heating
Indoor
outdoor
Rated Maximum Minimum
27 32 18
19 23 14
35 43 10
24 26 6
20 27 15
14.5 -- --
7 24 -7
6 18 --
DB C
WB C
DB C
WB C
Indoor
outdoor DB C
WB C
DB C
WB C
Cautions
Model
AS072XVERA
AS092XVERA
AS122XVERA
AS182XVERA
Connecting cable
H05RN-F 3G 2.5mm2(For power)
H05RN-F 2X1.5mm2(For signal,
must use sheilded wires)

3
WARNING!
Carefully read the following information in order to operate the air conditioner correctly.
Below are listed three kinds of Safety Cautions and Suggestions.
INSTRUCTIONS: These information can ensure the correct operation of the machine.
Be sure to conform with the following important Safety Cautions.
The Safety Cautions should be at hand so that they can be checked at any time when needed.
If the conditioner is transferred to the new user, this manual should be as well transferred to the new user.
Safety precautions
Otherwise the one will feel unpleasant
or harm ones' health.
If any abnormal phenomena is found (e. g.
smell of firing), please cut off the power
supply immediately, and contact the dealer
to find out the handling method.
In such case, to continue
using the conditioner will
damage the conditioner,
and may cause electrical
shock or fire hazard.
When need maintenance and repairment,
call dealer to handle it.
Incorrect mainten-
ance and repairment
may cause water
leak, electrical shock
and fire hazard.
switch
off
Please let the dealer be responsible for installing
the conditioner.
Incorrect installation may cause water leak, elec-
trical shock and fire hazard.
Don't put fingers or any other things into the
inlet/outlet and swing louver while the condi-
tioner is in operation.
Because the highspeed fan is very dangerous
and may cause injuries.
Call the dealer to take measures to prevent the
refrigerant from leaking.
If conditioner is installed in a small room, be sure
to take every measure in order to prevent suffoca-
tion accident even in case of refrigerant leakage.
When conditioner is deinstalled or reinstalled
dealer should be responsible for them.
Incorrect installation may cause water leaking,
electrical shock and fire hazard.
Don't blow the human body with the cooling
air too long, and don't let the room tempera-
ture decrease too low either.
WARNING! Incorrect operations may result in severe consequences of death or serious injuries.
CAUTION! Incorrect operations may result in injuries or machine damages; in some cases may
cause serious consequences.

4
CAUTIONS!
Conditioner should not be used for any other
purpose other than airconditioning.
Don't use air-conditioner for any other special
purposes, e.g. the preservation and protection
of food, animals, plants, pecision apparatus as
well as work of art, otherwise the qualities
of these stuffs may be damaged.
Don't dismantle the outlet of the outdoor unit.
The exposure of fan is
very dangerous which
may harm human be-
ings.
When air-conditioner is co-used with other
heat-radiator the frequent replacement of
room atmosphere should be required.
Inefficient venti-
lation may cause
suffocation.
After a long time use of air-conditioner the
base should be checked for any damages.
If the damaged base is
not repaired, the unit
may fall down and
cause accidents.
No goods or nobody is permitted to placed on
or stand on outdoor unit.
The falling of goods and
people may cause acci-
dents.
Pets and plants should not be blowed directly
in the air flow.
Otherwise will suffer damage.
Don't operate the air-conditioner with damp
hands.
Otherwise will be shocked.
Only use correctly-typed fuse.
May not use wire or any other materials
replacing fuse, otherwise may cause faults or
fire accidents.
Don't place any burning unit in the air flow of
air-conditioner, which may cause incomplete
combustion.
No inflammable spray fluid should be
permitted to be placed or used near to
airconditioner other wise may cause fire
accidents.
Air-conditioner should be cleaned only after
power supply is cut off to keep from shock or
hurt.
Don't clean air-conditioner with water.
Otherwise may cause shock.
Otherwise the poisonous chemicals may settle
in air-conditioner which harm the health of
chemical-allergic people.
When use the fumigating insecticide don't
open air-conditioner.
Safety precautions

5
CAUTION !
Please ask the dealer or specialist to install, never try by the users themselves. After the installation please
be sure of the following conditions.
Safety precautions
Incorrect installation may cause water leaking, shock and fire hazard.
Please call dealer to install the air-conditioner.
CAUTIONS ON INSTALLATION
Air-conditioner can't be installed in the envi-
ronment with inflammable gases because the
inflammable gases near to air-conditioner may
cause fire hazard.
Installed electrical-leaking circuit breaker.
Connect earthing wire.
Use discharge pipe correctly to ensure efficient
discharge.
It easily cause electrical shock without circuit
breaker.
Earthing wire should not be con-
nected to the gas pipe, water pipe,
lightning rod or phone line, in-
correct earthing may cause shock.
Incorrect pipe use may cause water leaking.
Earthing
[Location]
[Wiring]
[Operating noise]
Air-conditioner should be located in well-vented
and easily-accessible place.
Air-conditioner should not be located in the
following places:
(a) Places with machine oils or other oil vapours.
(b) Seaside with high salt content in the air.
(c) Near to hot spring with high content of sulfide
gases.
(d) Area with frequent fluctuation of voltage e.g.
factory, etc.
(e) In vehicles or ships.
(f) Kitchen with heavy oil vapour or humidity.
(g) Near to the machine emitting electric-magnetic
waves.
(h) Places with acid, alkali vapuor.
TV, radio, acoustic appliances etc are at least 1 m
far away to the indoor unit, outdoor unit, power
supply wire, connecting wire, pipes, otherwise
images may be disturbed or noises be created.
As required, take measures against heavy snow.
Air-conditioner should be equipped with special
power supply wire.
Chose the following locations:
(a) Capable of supporting air-conditioner weight,
don't increase operating noise and vibration.
(b) Hot vapour from outdoor unit outlet and ope-
rating noise don't disturb neighbour.
No obstacles around the outdoor unit outlet.

Parts and Functions
6
Front panel
Air inlet grille
Louver
Display board
INDOOR UNIT FRONT VIEW
INDOOR UNIT BACK VIEW
Signal receiver
Mounting plate
Heat preservation pipe
Connecting pipes
Drainage pipes

7
Parts and Functions
REMOTE CONTROLLER YR-H65
MODE
CLOCK
Used to set correct time.
TIMER
LIGHT
Used to set temp.,temp.
range:16 C~30 C
SLEEP
Used to select sleep
mode
HOUR
Used to set clock and
timer setting.
RESET
Used to reset the
controller back to
normal condition.
LOCK
Used to select
TIMER ON, TIMER
OFF, TIMER
ON/OFF.
Used to lock buttons
and LCD display.
ON
OFF
TEMP
HEALTH FAN
MODE
SLEEP SWING
CLOCK
TIMER
SET
LOCK
LIGHT
RESET
Power ON/OFF
Used for unit start and stop.
Used to selectAUTO run,
COOL, DRY, HEAT and
FAN operation.
2
SET
Used to confirm
Timer and Clock
setting.
TEMP
HEALTH
Control the light up and go out
of the control panel's
background light source and
control the switch of the buzzer.
Used to set Health operation
function
FAN
Used to select fan speed: AUTO,
LOW FAN, MED FAN, HIGH
FAN.
Used to set UP/DOWN air
sending and RIGHT/LEFT air
sending direction.
Health display
Display when set Health
operation function.
Battery Capacity display
Display when the electric power
of the battery is insufficient.
Timer ON/OFF display
Fan speed and air sending
direction display
Swing direction display
Room temperature display
Sterilize display
(This function is optional)
Humidifying display
Clock display
Temperature display
Used to display the set
temperature
Lock state display
Sleep state display
Electric Heating display
2
SWING
29
STERILIZE
Fresh Air state display
(This function is optional)
HEALTH AIRFLOW
FRESH
STERILIZE
CODE
LOW MID HIGH AUTO
1
1
3
3
4
4
5
5
6
6
7
7
8
8
9
9
10
10
11
11
12
12
13
13
14
14
15
15
16
16 17
17
18
18
20
19
21
22
21
23
24
25
26
23
24
27
25
26
29
28
20
BA
28
27
22
19
Note: This model does not have the following related display and function
18 21
30
HEALTH AIRFLOW
Used to set health airflow
30
CODE A/B selection
31
For this unit, please set to code A
31
23 27
o2
press LIGHT button 1 times
press LIGHT button 2 times
press LIGHT button 3 times
press LIGHT button 4 times
the control panel`s backgroud light source the buzzer
normal
null
on(constantly)
on(about 5 seconds)
off normal
on(about 5 seconds) normal
power on the unit on(about 5 seconds) normal
1
2
3
4
5
4
5
123
The LIGHT function

8
MODE
SLEEP SWING
CLOCK
TIMER
SET
LOCK
LIGHT
RESET
STERILIZE
123
HEALTH AIRFLOW
FRESH
CODE
Operation
Clock set
When unit is started for the first time
and after replacing batteries in remote
controller, clock should be adjusted as follows:
Press CLOCK button, "AM"or "PM" flashes.
Press or to set correct time. Each press will increase
or decrease 1 min . If the button is kept pressed, time will
change quickly.
After time setting is confirmed, press SET, "AM" and "PM"
stop flashing, while clock starts working.
Remote controller's operation
When in use, put the signal transmission
head directly to the receiver hole on the
indoor unit
The distance between the signal transmission
head and the receiver hole should be within
7m without any obsacles as well.
Don't throw the controller, prevent it from
being damaged.
When electronic-started type fluorescent
lamp or change-over type fluorescent lamp
or wireless telephone is installed in the room,
the receiver is apt to be disturbed in receiving
the signal so the distance to the indoor unit
should be shorter.
2R-03 dry batteries
MINUTES
Confirmation indicator:
In disorderation, reload the batteries or load the new batteries
after 5 mins.
Note:The waster batteries should be disposed properly,use two
new same-type batteries when loading.
If the remote controller canít function normally or doesnít work at
all,use a sharp-pointed item to press the reset key.
Hint:Remove the batteries in case unit wonít be in usage for a long period.
If there are any displays after taking-out just need to press reset key.
When throw away the waste batteries, please perform in accordance with the local regulation.
Loading of the battery
Slightly press " " and push down the cover.
Load the batteries as illustrated.
2 R-03 dry batteries, (cylinder)
Be sure that the loading is in line with the "+"/"-" pole
request as illustrated.
Put on the cover again.

Operation Auto
2
1Press ON/OFF button
Unit starts running.
The previous status appears on the display
(except. TIMER, SLEEP mode)
Press MODE button. For each press,
operation mode changes as follows:
4
Remote
controller
Press ON/OFF button
Unit stops running.
Press FAN,For each press, operation mode
changes as follows:
Remote
controller
ON
OFF
TEMP
HEALTH FAN
MODE
SLEEP SWING
CLOCK
TIMER
SET
LOCK
LIGHT
RESET
Unit runs at the speed displayed on LCD.
When fan speed is AUTO,it is changed automatically
according to the indoor temperature.
Note:
During Auto run operation, temp. setting will be shown in LCD display, unit will select heating,
cooling or fan operation according to the room temp.
STERILIZE
HEALTH AIRFLOW
FRESH
CODE
AUTO COOL DRY FAN HEAT
Select Auto run,
" " appears and auto run starts.
LOW MID HIGH AUTO
2
5
5
1
3
Select temp. button
Press TEMP button
Every time the button is pressed, temp.
setting increases 1 C
Every time the button is pressed, temp.
setting decreases 1 C
If the button is kept pressed, setting will
increase or decrease quickly.
3
9
4
A

10
A
Operation Cooling
Press ON/OFF button
Unit starts running.
The previous status appears on the display
(except. TIMER, SLEEP mode)
Press MODE button. For each press,
operation mode changes as follows:
Select temp. button
Press TEMP button
Every time the button is pressed, temp.
setting increases 1 C
Every time the button is pressed, temp.
setting decreases 1 C
If the button is kept pressed, setting will
increase or decrease quickly.
Press ON/OFF button
Unit stops running,and when entry this mode for the
next time,it will show the previous setting.
Unit runs at the speed displayed on LCD.
When fan speed is AUTO,it is changed automatically
according to the indoor temperature.
5
3
2
1
Select cooling operation, Shows" "
Cooling operation starts.
Press FAN button. For each press, fan speed
changes as follows:
4
Remote
controller
Remote
controller AUTO COOL DRY FAN HEAT
LOW MID HIGH AUTO
ON
OFF
TEMP
HEALTH FAN
MODE
SLEEP SWING
CLOCK
TIMER
SET
LOCK
LIGHT
RESET
1
2
3
STERILIZE
HEALTH AIRFLOW
FRESH
CODE
5
3
4

11
A
Operation Dry
Press ON/OFF button
Unit starts running.
The previous status appears on the display
(except. TIMER, SLEEP mode)
Press MODE button. For each press, operation mode changes
as follows:
Select Drying operation shows" "
Dry operation starts
Select temp. button
Press TEMP button
Every time the button is pressed, temp. setting increases 1 C
Every time the button is pressed, temp. setting decreases 1 C
If the button is kept pressed, setting will increase or decrease
quickly.
Press FAN button. For each press, fan speed changes as
follows:
Press ON/OFF button
Unit stops running, and when
entering this mode for the next
time, it will show the previous setting
Unit runs at the speed displayed on LCD.
In DRY mode, when room temp.becomes 2 C lower than temp.
setting,unit will run intermittently at LOW speed regardless of FAN
setting.
3
2
1
4
5Ultra-low air flow
Temp.setting+2 C
Temp.setting
On reaching 2 C lower than temp.
setting,unitwill run in mild DRY mode.
COOL operation starts when room
temp. is higher than temp. setting.
ON
OFF
TEMP
HEALTH FAN
MODE
SLEEP SWING
CLOCK
TIMER
SET
LOCK
LIGHT
RESET
1
2
3
Remote
controller AUTO COOL DRY FAN HEAT
Remote
controller LOW MID HIGH AUTO
STERILIZE
HEALTH AIRFLOW
FRESH
CODE
5
3
4

12
A
Operation Fan
Press ON/OFF button
Unit starts running.
The previous status appears on the display
(except. TIMER, SLEEP mode)
Press MODE button. For each press,operation mode
changes as follows:
Select Fan operation shows " ", Fan operation starts.
Press ON/OFF button
Unit stops running, and when entering this mode for the
next time, it will show the previous setting.
4
1
2
3Press FAN button. For each press, fan speed changes as
follows:
Note:
In this mode, temp. can't be selected, temp.setting will not be
shown in LCD display.In Fan operation mode, "AUTO" fan
speed is not available. Operation cycles are as follows:
LOW MID HIGH
Unit runs at the speed displayed on LCD.
LOW MID HIGH
ON
OFF
TEMP
HEALTH FAN
MODE
SLEEP SWING
CLOCK
TIMER
SET
LOCK
LIGHT
RESET
1
2
STERILIZE
HEALTH AIRFLOW
FRESH
CODE
3
4
Remote
controller AUTO COOL DRY FAN HEAT

13
A
Operation Heating
Press ON/OFF button
Unit starts running.
The previous status appears on the display
(except. TIMER, SLEEP mode)
Press MODE button. For each press,operation mode
changes as follows:
Select Heating operation " " appears and Heating
operation starts.
Press FAN button. For each press, fan speed changes as
follows:
4
1
2
3Select temp. button
Press TEMP button
Note: For cooling only type, this function is invalid.
Every time the button is pressed, temp. setting increases 1 C
Every time the button is pressed, temp. setting decreases 1 C
If the button is kept pressed, setting will increase or
decrease quickly.
Press ON/OFF button
5Unit stops running, and when entering this mode for the next
time, it will show the previous setting.
In heat mode,warm air will blow out after a short period of
time due to cold-draft prevention function.
ON
OFF
TEMP
HEALTH FAN
MODE
SLEEP SWING
CLOCK
TIMER
SET
LOCK
LIGHT
RESET
1
2
3
LOW MID HIGH AUTO
STERILIZE
HEALTH AIRFLOW
FRESH
CODE
4
5
3
AUTO COOL DRY FAN HEAT

14
A
Operation Air flow adjustment
Swing louvers
(Vertical louvers)
Up and down
Put louvers at up position in cooling and down position in heating mode.
This will be helpful to keep an even room temp.
Note:
In cooling or dry operation, don't put horizontal louvers at downward
position for a long time, or outlet grill might get frosted. Don't expose
your skin to cool or warm air for a long time.
Notice:
Side from side
ON
OFF
TEMP
HEALTH FAN
MODE
SLEEP SWING
CLOCK
TIMER
SET
LOCK
LIGHT
RESET
(Horizontal louvers)
Side from side
Fixed position
Press the SWING again to fix the
horizontal louvers at your desired position.
Swing
Press SWING the horizontal
louvers move from up to down.
Fixed position
Press the SWING again to fix the
vertical louvers at your desired position.
Swing
Press SWING the vertical
louvers move from side to side.
2
STERILIZE
HEALTH AIRFLOW
FRESH
CODE
1
Position 1
Position 2
Position 3
Position 4
Position 5
Position 6
Position 7
Position 8
[COOL/DRY/FA
N/AUTO(COOL)
HAVE NOT]
(AUTO SWING)
Position 1
Position 2
Position 3
Position 4
Position 5
Position 6

15
A
Operation Sleep
Remote control unit
Usage of the Sleep function
After starting, set the Run mode and press the Sleep
button.
Run mode
1. In cooling and dry
After starting of the Sleep operation, the temperature will
be raised for 1 C higher than the set temperature 1 hour
later,and be raised for 1 C after another hour. It continues
under that condition for 6 hours, then the machine will be
switched off. The temperature is higher than the set
temperature so as to avoid catching cold in sleeping.
2. In heating ( the single-cooling conditioners do not have the
function)
After the Sleep running starts, the temperature will drop for 2 C after
one hour.The temperature will drop for 2 C after another one hour.
The temperature will raise for 1 C after 3 hours running under the
above temperature, and the conditioner will be closed down after
running for 3 hours. The temperature is lower than the set
temperature so as to avoid uneasiness in sleeping.
3. In automatic running
The conditioner will run under automatically selected working
mode of sleeping.
4. In Fan running
The Sleep function is invalid.
About 6 hours
The Sleep running starts The Sleep running stops
Set the
temperature
Close down
the machine
In cooling and dry
Raise 1 C
Drop for 2 C
Drop for 2 C
About 3 hours
The Sleep running starts The Sleep running stops
Set the
temperature Close down
the machine
In heating
1 hour Raise 1 C
1 hour Raise 1 C
1 hour
1 hour
3 hours
ON
OFF
TEMP
HEALTH FAN
MODE
SLEEP SWING
CLOCK
TIMER
SET
LOCK
LIGHT
RESET
STERILIZE
HEALTH AIRFLOW
FRESH
CODE
Before go to bed, you can press the Sleep button,
the air conditioner will operate in comfortable
sleep mode to make your sleep more comfortable.

16
A
Operation Timer on/off operation
Remote control unit
TIMER operation
Set Clock correctly before starting Timer operation (refer to page 2)
You can let unit start or stop automatically at following times: Before you wake up in the morning, or get
back from outside or after you fall asleep at night.
TIMER ON/OFF
(1) After unit start, select your desired operation mode.
Operation mode will be displayed on LCD.
(2) TIMER mode selection
Press TIMER button to change TIMER mode.
Every time the button is pressed, display changes as follows:
Remote
controller
Select your desired TIMER mide (TIMER ON or TIMEROFF) ON or OFF
will flash.
(3) Timer setting
Press HOUR / button.
Every time the button is pressed, time increases 10 min, If button is kept
pressed, time will change quickly.
Every time the button is pressed, time decreases 10 min, If button is
kept pressed, time will change quickly. Time will be shown on LCD. It can
be adjusted within 24 hours.
(4) Confirming your setting
After setting correct time, press SET button to confirm, " "
or " " stops flashing.
Time displayed: Unit starts or stops at x hour x min (TIMER
ON or TIMER OFF)
Timer mode indicator on indoor unit lights up.
To cancel TIMER mode
Just press TIMER button several times until TIMER mode disappears.
Hints
After replacing batteries or a power failure happens, Time setting should be reset.
Remote controller possesses memory function when use TIMER mode next time, just Press SET button
after mode selecting if timer setting is the same as previous one.
ON ONOFF OFF
TIMER ON TIMER OFF TIMER ON-OFF
AM 12:00 PM 12:00 PM 12:00 AM 12:00 BLANK
ON
OFF
ON
OFF
TEMP
HEALTH FAN
MODE
SLEEP SWING
CLOCK
TIMER
SET
LOCK
LIGHT
RESET
STERILIZE
HEALTH AIRFLOW
FRESH
CODE

17
A
Operation Timer on-off function
Remote controller operation TIMER ON-OFF
(1) After unit start, select your desired operation mode.
Operation mode will be displayed on LCD.
(2) TIMER mode selection
Press TIMER button to change TIMER mode.
Every time the button is pressed, display changes as follows:
(3) Timer setting for TIMER ON
Press HOUR button.
Every time the button is pressed, time increases 10 min. If button is
kept pressed, time will change quickly.
Every time the button is pressed, time decreases 10 min. If button
is kept pressed, time will change quickly.
Time will be shown on LCD.
It can be adjusted within 24 hours.
AM refers to morning and PM to afternoon.
(4) Time confirming for TIMER ON
After time setting, press TIMER button to confirm," " stops blinking,
while " " starts blinking.
To cancel TIMER mode
Just press TIMER button several times until TIMER mode disappears.
ON
Remote
controller
ON ONOFF OFF
TIMER ON TIMER OFF TIMER ON-OFF
AM 12:00 PM 12:00 PM 12:00 AM 12:00 BLANK
OFF
(5) Time setting for TIMER OFF
Follow the same procedure in "Time setting for TIMER ON".
(6) Time confirming for TIMER OFF
After time setting, press SET button to confirm, " " stops flashing.
Time displayed: Unit start or stop at x hour x min
OFF
According to the Time setting sequence of TIMER ON or TIMER OFF,either ON-OFF or OFF-
ON can be achieved.
Select your desired TIMER mide (TIMER ON or TIMEROFF) ON or OFF
will flash.
2
3
STERILIZE
HEALTH AIRFLOW
FRESH
CODE
4
5
6
ON
OFF
TEMP
HEALTH FAN
MODE
SLEEP SWING
CLOCK
TIMER
SET
LOCK
LIGHT
RESET
1

18
A
Operation
After turning on the unit and set the desired working mode. Press
the Health button, the LCD will display " ", the unit begins
health operation (start the negative ion generation device). Press the
Health button again, the " " displayed on the LCD disappears,
health operation is cancelled (turn off the negative ion generation
device).
Note: When indoor fan motor does not work, the unit will
automatically turn off negative ion generation device.
Health operation
After the start of Health operation, the negative ion generator will
generate large amount of negative ion, which can effectively
balance the amount of positive & negative ion in the air and has the
bacteria-killing and accelerating the dust deposition of the room to
make the room air fresh and healthy.
About Health operation
1
Health & Fresh Air operation
TEMP
FAN
ON
OFF
HEALTH
MODE
SLEEP SWING
CLOCK SET
TIMER
RESET LIGHT LOCK
STERILIZE
HEALTH AIRFLOW
FRESH
CODE
