A/S MANUAL
A EN ION : Before testing, adjustment and repair

1. he Sizes and Paraneters. 3
2. he Description to models. 4
3. Adjusting the burners. 5
3.1 he burners of table. 5
3.2 Adjusting the Oven. 6
4. he Circuitry of plate 6
5. How to assembly top burners 7
6. he Possible faluts and their remoaval. 7
6.1 Do not flare up any burners. 7
6.2 Flame appers and disappears 7
7. Exploded viw 8~9
Contents.

Specification Remarks
Product 24 3/8"(W) X 21 3/4"(D) X 33 1/2"
(Height to Cooktop Maximum Width)
Oven Volume 68.5Liter 17 1/8"(W) X 17 5/8"(D) X 23 1/4"(H)
Broiler 10.5Liter 13 3/4"(W) * 14 7/8" (D) * 3 1/8" (H)
op plate Porcelain Enamel Continious Cleaning
Oven cavity Porcelain Enamel Continious Cleaning
Broiler Porcelain Enamel Continious Cleaning
Inner lining Porcelain Enamel Continious Cleaning
Glass empered Glass White Color
Inner lining Porcelain Enamel Ground coating
Panel Painted White Color
Painted White Color
Yes 25W
N/A
Electric spark Electric Continious Spark Ignition
120V 60,50Hz Variable(for Buyer standard)
Ф9.5mm
LPG
13.1kW(0.95Kg/hr)
high 3.4kW(0.25Kg/hr) Right front
Medium(2ea) 2.6kW(0.19Kg/hr) Left front.Left rear
Small 1.6kW(0.12Kg/hr) Right rear
4.0kW(0.229Kg/hr)
Phase
Dimension
Coating
Door
Oven door
Broiler door
Side panel
Oven Lamp
imer
Ignition method
Power
Hose end(input for gas)
ype of gas
Nominal
heat
capacity
otal
op burners
Oven burner
1. Sizes and parameters.
33 1/2"
24 3/8"
21 3/4"21 3/4"

*For a long ife span clean your applliance frequently.
Please set 'Back guard post' in right position and use screw to tighten
the "Back guard" to the stove
2.The Description to models
Broiler Tra
Oven Rack Oven Pan Broiler Pan
Broiler Tra
1:Backguard
2:Grate
3:Top plate
4:Lamp Switch
5:Top Burner Knob
6:Oven Knob
7:Oven Rack
8:Oven Pan
9:Oven Door
10:Broiler Tra
11:Broiler Door
12: Timer Knob

When change the used gas(LNG or LPG) exclude the following instructions.
a) Unscrew screw of fastening Fixative1 from Body burners
(for all burners)
b) Having Unscrewd with completions of pipe a nozzle,
change its on corresponding to gas.( he hread on
sition.)
Burners LPG L G
Large 0.95 1.44
Medium 0.85 1.2
Small 0.68 0.95
On upper surface of valve(4) it si inflicted diameter
calibrating sniffle(2)
After removingg the upper lid(1) change bolted in rubber
laying(3) calibrating sniffle.
Burners LPG L G
Large 0.7 0.7
Medium 0.6 0.6
Small 0.6 0.6
pipe and snot without fall to swab the special compo
3.Adjusting the burners.
3.1. Burners of table.
3.1.1 Change sniffle the burners.
3.1.1 Change calibrating sniffle valve.
Body of
burner
Body of
burner
Nozzle
Screw
N-FIX

a) Adjust the air-cushion on burner.
b) Change nozzle of burner.
able of asjusting the Oven
LPG L G
Ф1.05mm Ф1.44mm
Open
completely
Open on
66%
Ф0.52mm Ф0.75mm
Nozzle
Air-cushion
Calibrating nozzle
4.Circuitr of plate
3.1. Adjusting the Oven.
hermovalve
Calibratin
g nozzle

How to assemble Slim Burner
1. Put the cover ring on burner bod .
Make sure the locating notch on the inner side of the cover ring
is properl aligned with the corresponding bump on the burner bod .
2. Pue the burner cap ontn burner bod .
3. Put the grate onto top plate.
Note : If burner cap is not assembled properly, yellow flame or other abnormal situation may happen.
5.How to assembl top burners
Grate
Burner Cap
Cover Ring
Burner Body
How to assemble burner cap properl
Good Wrong position of burner cap Burner cap is obligue

5. Possible faults and their removal.
6.1 Do not flare up burners.
1. No fire. 1. Check connecting of electric power.
2. Check contacts and wire
3. Check Spark plug.
4. Check clearance of contacts.
5. Clean Spark Contacts.
6. Check hole of burners.
7. Check air in gas' hose
8. Check sort of gas
2. Unstabl flame 1. Check assembling of cap burners
2. Check sort of gas
3. Check bending of Gas' hose
4. Check running out of gas
5. Check wind of around burners.
6. Check clearance of contacts.
3. Bad cooking 1. Check chocking of duct.
2. Check assemble of Baffle oven.
3. Check pre heating time.
1. Check open valve of presenting 1. Open valve.
the gas. 2. Change balloon.
2. here is gas in balloon. 3. Unbend gasmain.
3. Does Not outline gasmain. 4. Install pressure of gas.
4. Check the pressure of gas. Propane gas - 280±50mm H20
Natural gas - 200±50mm H20
6.2 Flame appears and immediately go out.
1. he Flame go out after lower 1. Check the holes of leaving the gas
handles of valve. clean from water and strangers of
2. he Electromagenetic valve does subject.
not operate. 2. Check contacts and wire.
2. he Electromagenetic valve is 3. Change the electromagnetic valve.
faulty.
Faults Removal
Faults Removal
6. Possible faults and their removal.
3mm

OVE EXPLODED VIEW

o Material
number Material ame
1 5012135004 BOARD SKID
2 5012142100 BASE BO OM
3 5011014004 LEVELER
4 5011483001 RACK ASSY,BROIL.DRW(L)
5 5011483011 RACK ASSY,BROIL.DRW(R)
6 5012143004 FRAME BROILER
7 5011540041 HINGE AY OVEN DOOR - L(60)
8 5012633018 FRON ASS'Y OVEN
25 5013583021 HINGE AY OVEN DOOR - R(60)
26 5012054005 SEAL ASS'Y OVEN
27 5012159028 PANEL SIDE(60 P/WHI E)
28 5012617001 SUPPOR OP MAIN
29 5013741070 SIDE OVEN(L) - KLX
31 5013047004 RAY OVEN NEW
32 5012169001 BAFFLE OVEN FRON
33 5011029011 RACK OVEN
34 5013720011 AL WRAP
35 5015350100 OVEN LAMP MODULE
36 5011804020 OP OVEN
37 5014946380 BOX ASS'Y CON EN S OF ENVELOPE(6M07VH)
38 5014956100 BO OM OVEN ASS'Y(40KLX)
39 5012384000 BAFFLE OVEN BURNER
40 5015178100 BURNER ASS'Y OVEN(4000
41 5014157010 HERMOCOUPLE OVEN
42 5011702002 MIXER AIR BAKE
43 5011825003 CLIP BO OM OVEN
44 5011308001 CLIP OVEN CON , BULB
45 5011863002 WIRING ASS'Y OVEN LAMP
46 5013715003 HEA COVER WRAP(40)
47 5012144032 BACK OVEN - KLX
48 5012181004 COVER BACK INSULATION
49 5012149010 DUCT ASS'Y OVEN
50 5012796020 NOZZLE OVEN VALVE(Φ1.05)
51 5012612000 SUPPOR CONNEC OR NOZZLE
52 5011675002 CONNEC OR NOZZLE
53 5013740070 SIDE OVEN(R) - KLX
56 5012644001 UBE ASS'Y OVEN
57 5012156012 BACK MAIN(6M)
58 2370013000 CORD ASS'Y SE (US)
GOR-6M07
PART LIST

TOP BUR ER PART & BROILE EXPLODED VIEW

o Material
number
Material ame
9 5013651011 DRAWER-ASSY
10 5011058005 SPRING BROILER DOOR
11 5011059000 LINK BROILER SPRING
12 5011047010 HINGE-ASSY B/D(R)
13 5011046010 HINGE-ASSY B/D(L)
14 5012619012 LINING BROILER DOOR
15 5012620032 FRON BROILER DOOR - P/WHI E
16 5012621026 HANDLE DOOR - BROILER
17 5011063012 PAN BROILER
18 5011511010 INSER BROILER PAN
19 5012624041 GLASS OVEN DOOR(WH)
20 5011035002 FRAME-ASSY WINDOW
21 5011033001 GLASS DOOR INNER
22 5012632000 HEA COVER OVEN DOOR
23 5012621037 HANDLE DOOR - OVEN
24 5012613027 LINING ASS'Y OVEN DOOR
30 5012615022 FRAME OVEN DOOR(LOWER)
60 5013998000 LOGO-Haier
61 5012609020 RIM B/G END(L)-WHI E
62 5012608020 RIM B/G END(R)-WHI E
63 5012605002 COVER BACKGUARD
64 5012601032 OP MAIN
65 5051945041 RING COVER(M)
66 5050756021 CP ASS'Y-SD
67 5050755031 CP ASS'Y-MD
68 5051945041 RING COVER(M)
69 5051945011 RING,COVER(L)
70 5050754031 CP ASS'Y-LD
71 5012186012 RING COVER-(S)
73 5013850001 WIRING ASS'Y MAIN
74 5050724010 S-MIX
75 5051791000 CLIP FIXING S/P
76 2330010230 C-D4435
77 5051762003 BODY BURNER-SD
78 2330010200 C-D2406
79 5010441000 PLA E FIXING /C
80 5051761002 BODY BURNER-MD
81 5051715021 SPARK PLUG-NEW2
82 5051062001 CLIP FIXING BRACKE (0)
83 5051192005 MIXER ASS'Y-NEW(HOLE)
84 5050695002 N-FIXB
85 2330010220 C-D4406
86 5012148100
OP BURNER BOX(60
계열
)
87 5014535000 SUPPOR OP MAIN
88 5051143018 SUPPOR BURNER-SWG
89 5012659100 UBE ASS'Y R,F - LPG(0.98)
90 5012664000 UBE ASS'Y R,R(0.68)-LPG
91 5012640100 UBE ASS'Y L,R - LPG(0.85)
92 5012638100 UBE ASS'Y L,F - LPG(0.85)
93 5109300020
COCK UNI -SLIM,(AC),
동아
-0.6
95 5012686011 PIPE ASS'Y M/F
97 5109300030
COCK UNI -SLIM,(AC),
동아
-0.7
98 5013939210 HERMOVALVE OVEN(RED.0.52)
100 5014577001 BRACKE MICRO S/W MODULE
101 5012688100 BELL IMER ASS'Y
102 5011629000 BRACKE HERMOVALVE
103 5011680000 BOL HERMOVALVE
104 5012661000 WIRING ASS'Y MAIN
105 5013845001 WASHER HERMOVALVE (OVEN)
106 5055021000 OLIVE DWG(0775)
107 5011721010 NU OLIVE
108 5012630010 S/W OVEN LAMP
109 5012622080 COVER MANIFOLD-PRIN
110 5012604070 KNOB RING-COCK
111 5012607021 KNOB IMER - WHI E
112 5012625030 KNOB ASS'Y HERMOVALVE
113 5012626030 GRA E ASS'Y
113 5012618030 KNOB ASS'Y COCK
114 5012611020 KNOB RO ARY SWI CH(WHI E)
115 5012604080 KNOB RING- HERMO
GOR-6M07 PART LIST
