IMPORTANT SAFETY INSTRUCTIONS
Warning – To reduce the risk of fire, electric shock, or injury
to persons when using your appliance, follow basic
precautions, including the following:
1. Read all instructions before using the appliance.
2. Do not dry articles that have been previously cleaned in, washed in,
soaked in, or spotted with gasoline, dry-cleaning solvents, or other
flammable or explosive substances, as they give off vapors that
could ignite or explode.
3. Do not allow children to play on or in the appliance. Close supervision
of children is necessary when the appliance is used near children.
4. Before the appliance is removed from service or discarded, remove the
door to the drying compartment.
5. Do not reach into the appliance if the drum is moving.
6. Do not install or store this appliance where it will be exposed to water
and/or to the weather.
7. Do not tamper with controls.
8. Do not repair or replace any part of the appliance or attempt any
servicing unless specifically recommended in the user-maintenance
instructions or in published user-repair instructions that you understand
and have skills to carry out.
9. Do not use fabric softeners or products to eliminate static unless
recommended by the manufacturer of the fabric softener or product.
10. Do not use heat to dry articles containing foam rubber or similarly
textured rubber-like materials.
11. Clean lint screen before or after each load.
12. Keep area around the exhaust opening and adjacent surrounding
areas free from the accumulation of lint, dust and dirt.
13. The interior of the appliance and the exhaust duct should be cleaned
periodically by qualified service personnel.
14. Do not place items exposed to cooking oils in your dryer. Items
contaminated with cooking oils may contribute to a chemical
reaction that could cause a load to catch fire.
15. If material has been used with any flammable liquids or solids it should
not be used in the dryer until all traces of the flammable liquids and its
fumes have been removed.
1
English

2
16. This dryer must be properly installed in accordance with the
installation instructions before it is used. See grounding instructions
in the installation section.
17. Proper grounding must be ensured to reduce the risk of electric shock
and fire. Check with a qualified electrician or service personnel if you
are in doubt as to whether the dryer is properly grounded.
18. Use the dryer only for its intended purpose, drying clothes.
19. Always disconnect dryer from electrical supply before attempting any
service. Disconnect power cord by grasping the plug, not the cord.
20. Replace worn power cords and/or loose plugs.
21. To reduce the risk of electric shock or fire, do not use extension cords or
adapters to connect dryer to electrical power source.
SAVE THESE INSTRUCTIONS
For Future Use
English

3
English
As dry cleaning solvents, gasoline, vegetable and cooking oils are highly
hazardous materials, items soaked in or spotted with such should not be used in
the dryer. Items may still contain a substantial amount of the hazardous material
after being washed. When such items are exposed to heat they could ignite. As
clothes are stacked and piled up in the dryer the heat cannot escape. Due to this,
items become hot enough to possibly ignite. Washing in hot water with extra
detergent would reduce but not eliminate the risk of fire.
WARNING
Thank you for using our Haier
product. This easy-to-use manual will
guide you in getting the best use of
your dryer.
Remember to record the model and
serial number. They are on a label in
back of the dryer.
Model number
Serial number
Date of purchase
Staple your receipt to your manual. You will need it to obtain
warranty service.
DANGER
Risk of child entrapment. Before you throw away your old
dryer, take off the door so that children may
not easily get trapped inside.

Table Of Contents
PAGE
Safety Instructions............................................................................1
OPERATING INSTRUCTIONS............................................................5
Features ................................................................................................5
Other Features ......................................................................................7
Operations ............................................................................................8
Normal Operating Sounds ......................................................................9
Tips ......................................................................................................9
Care and Cleaning Guide ............................................................10
Troubleshooting..............................................................................11
INSTALLATION INSTRUCTIONS ....................................................12
Tools and Materials Required ................................................................12
Electrical Requirements ........................................................................12
Unpacking Your Dryer ..........................................................................12
Exhaust System Connections ......................................................13
Requirements and Instructions ..............................................................13
Materials ............................................................................................14
Location of Your Dryer..........................................................................16
Installation in Mobile Home ..................................................................17
Electrical Connections ....................................................................18
Requirements and Instructions ..............................................................18
3-Wire Cord Connections ....................................................................19
4-Wire Cord Connections ....................................................................20
Warranty ........................................................................................22
4
English

5
English
Features
Control Knob:
1. Dry Timer: Lets you set the time to dry your clothes, depending on the
fabric type and depending on the load size. This is designed for you to
set the number of minutes needed to dry the clothes. This cycle provides
up to 100 minutes of drying time at the temperature selection of your
choice. Drying time varies depending on size and dampness of the
load, weight and fabric type. Room temperature, humidity, type of
installation and electric voltage can also affect drying time.
2. Auto Dry: Lets you set the dryer to a preset dry cycle. This is designed
for the casual cottons. E.g. Jeans, etc. This cycle is best for regular and
permanent press items that can be tumble-dried. Drying time is
determined automatically at the temperature selection of your choice.
Here the cycle works better when items of similar fabric, weight and
construction are dried together.
OPERATING INSTRUCTIONS
WARNING: To reduce the risk of of fire, electric shock or injury to persons, read
the IMPORTANT SAFETY INSTRUCTIONS before operating this dryer.

6
English
Temperature Knob:
Temperature Setting Control: To set the heat drying temperature, of the
dryer load, depending on the fabric type.
• Low Heat: for knitted and delicate clothes.
• Med. Heat: for permanent press, synthetic clothes.
• High Heat: for regular clothes.
Always follow directions on fabric care labels.To avoid fire do not use
heat to dry items containing feathers, foam rubber or similar textured
rubber-like material.
Start Knob:
Start Button / Power On: Push Start button for 2 seconds to power on the
Dryer after loading. Unit will automatically stop once the dryer door is
opened. The start button must be once again pushed to resume operation
once the door is closed.
