Haier HMV1472BHS User manual

Installation Instructions
Instructions d’installation
Instrucciones de instalación
HMV1472BHS
Microwave Oven
Four à micro-ondes
Horno de microondas
Part # 0570001268 REV A

TABLE OF CONTENTS
MICROWAVE SAFETY ........................................................................... 2
INSTALLATION REQUIREMENTS ............................................................. 3
Tools and Parts ............................................................................. 3
Location Requirements ................................................................... 4
Electrical Requirements .................................................................. 5
INSTALLATION INSTRUCTIONS ............................................................. 6
Step 1 - Unpack Microwave Oven ....................................................... 6
Step 2 - Locate Wall Studs ............................................................... 7
Step 3 - Align Rear Wall Template and Mark Wall ..................................... 7
Step 4 - Drill Holes for Mounting Microwave Oven .................................. 9
Step 5 - Determine Ventilation Method ............................................. 10
Step 6 - Install Microwave Oven ....................................................... 11
Step 7 - Complete Installation ........................................................ 25
1
ENGLISH

MICROWAVE SAFETY
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and
on your appliance. Always read and obey all safety messages.
DANGER
WARNING
CAUTION
This is the safety alert symbol.
This symbol alerts you to potential hazards that can
kill or hurt you and others. All safety messages will
follow the safety alert symbol and either the word
“DANGER,” “WARNING” or “CAUTION.”
These words mean:
An imminently hazardous situation. You
could be killed or seriously injured if you
don’t immediately follow instructions.
A potentially hazardous situation
which, if not avoided, could result in
death or serious bodily injury.
A potentially hazardous situation
which, if not avoided, may result in
moderate or minor injury.
All safety messages will tell you what the potential hazard is, tell you
how to reduce the chance of injury, and tell you what can happen if the
instructions are not followed.
IMPORTANT SAFETY
INSTRUCTIONS
IMPORTANT: To reduce the risk of re, electrical shock, injury to
persons, or damage when using the microwave oven, follow basic
precautions, including the following:
•Read all of the instructions before using this appliance.
•This appliance must be properly installed and located in accordance
with the installation instructions before it is used.
•The microwave oven must be properly grounded. Connect only to
properly grounded outlet. See “GROUNDING INSTRUCTIONS” found
in this installation guide.
•Consult a qualied electrician or serviceman if the grounding
instructions are not completely understood, or if doubt exists as to
whether the microwave oven is properly grounded.
•Do not remove ground prong.
•Do not use an adapter.
•Do not use an extension cord.
2
ENGLISH

IMPORTANT SAFETY
INSTRUCTIONS
•Disconnect electrical power at the fuse box or circuit breaker box
before installing.
•The mounting surface must be capable of supporting the cabinet
load, in addition to the added weight of this 63–85 pound (28.5–
38.5 kg) product, plus additional oven loads of up to 50 pounds
(22.7 kg) or a total weight of 113–135 pounds (51.3–61.2 kg).
•This product cannot be installed in cabinet arrangements such as an
island or a peninsula. It must be mounted to BOTH a top cabinet AND
a wall.
•Use two or more people to move and install microwave oven.
READ AND SAVE THESE
INSTRUCTIONS
INSTALLATION REQUIREMENTS
TOOLS AND PARTS
Gather the required tools and parts before starting installation. Read and follow the
instructions provided with any tools listed here.
TOOLS NEEDED
•Phillips Screwdriver
•Pencil
•Tape Measure or Ruler
•Carpenter's Square
•Tin Snips (for cutting damper, if
required)
•Scissors
•Cordless Electric Drill
•³⁄₁₆", ½" and ⅝" Drill Bits
•Reciprocating Saw, Hole Saw or
Keyhole Saw
•Stud Finder
•Hammer
•Carpenter's Level
•Duct Tape
•Masking Tape
•Safety Gloves and Goggles
PARTS SUPPLIED
Wood Screws (¹⁄₄" x 2") Toggle Bolts and wing
nuts (³⁄₁₆" x 3") Grease Filters (packed separately)
3
ENGLISH

TOP CABINET TEMPLATE
REAR WALL TEMPLATE
Nylon Grommet (for metal
cabinets) Top Cabinet Template Rear Wall Template
Glass Tray Turntable Ring
PARTS NEEDED
•M6-1.00 Self-aligning Machine Screw (2) - of the length needed to go through
the cabinet bottom, ller block (if needed for recessed bottom cabinets), and
into the top of the microwave.
LOCATION REQUIREMENTS
24" (61.0 cm) 30"
(76.2 cm)
min.
16½" (42 cm)
c
b
d
a
2
" (5.1 cm)
AGrounded 3 Prong Outlet
BBottom edge of cabinet
needs to be 30" (76.2 cm)
or more from the cooking
surface.
CBacksplash
D66" (167.6 cm) or more
from the oor to the top
of the microwave
•The space between the cabinets on each side of the range must be at least 24"
(61 cm) wide and free of obstructions.
•Grounded electrical outlet inside overhead cabinet. See “Electrical
Requirements” section.
•If you are going to vent the microwave oven to the outside, see “Install
Microwave Oven” for exhaust and duct preparation.
•When installing the microwave oven beneath smooth, at cabinets, follow the
instructions on the Top Cabinet template for power cord clearance.
4
ENGLISH

ELECTRICAL REQUIREMENTS
WARNING
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove the ground prong from the power cord plug.
Do not use an adapter.
Do not use an extension cord.
Failure to do so can result in death, fire or electrical shock.
Observe all governing codes and ordinances.
Product rating is 120 volts AC, 60 Hertz and 1500 watts. This product must be
connected to a supply circuit of the proper voltage and frequency.
The power supply cord and plug should be brought to a separate 15 to 20 ampere
branch circuit single grounded outlet.
The outlet box should be located in the cabinet above the microwave oven.
The outlet box and supply circuit should be installed by a qualied electrician and
conform to the National Electrical Code or the prevailing local code.
GROUNDING INSTRUCTIONS
For a grounded, cord-connected microwave:
The microwave oven must be grounded. In the event of an electrical
short circuit, grounding reduces the risk of electric shock by providing an
escape wire for the electric current. The microwave oven is equipped
with a cord having a grounding wire with a grounding plug. The plug must
be plugged into an outlet that is properly installed and grounded.
WARNING: Improper use of the grounding plug can result in a risk of
electric shock. Consult a qualied electrician or serviceman if the
grounding instructions are not completely understood, or if doubt
exists as to whether the microwave oven is properly grounded.
Do not use an extension cord. If the power supply cord is too short, have
a qualied electrician or serviceman install an outlet near the microwave
oven.
READ AND SAVE THESE
INSTRUCTIONS
5
ENGLISH

INSTALLATION INSTRUCTIONS
WARNING
Electrical Shock Hazard
Disconnect electrical power at the fuse box or circuit breaker box
before installing microwave.
Failure to do so can result in death or electrical shock.
STEP 1 - UNPACK MICROWAVE OVEN
WARNING
Excessive Weight Hazard
Use two or more people to move and install microwave oven.
Failure to do so can result in back or other injury.
1. Using two or more people move the microwave close to the installation site.
2. Open the four aps on the carton top. From the top of the microwave, remove
the foam packing that contains the turntable and turntable ring.
NOTE: Do not remove the foam packing from the front of the oven.
3. Open the top of the plastic bag. Using two people, lift the microwave out of the
carton and gently set it front down on the foam packing. Remove the grease
lters and User Manual from the carton.
a
b
AFoam Packing
BCarton
4. Locate and remove the two screws attaching the mounting plate to the back of
the oven, and then remove the mounting plate.
6
ENGLISH

NOTE: The mounting plate will be used as the wall template and to mount
the microwave oven onto the wall.
a
b
AScrews
BMounting Plate
(Wall Template)
5. Replace the two screws into the holes from which they were removed.
STEP 2 - LOCATE WALL STUDS
IMPORTANT: The microwave must be installed to at least one wall stud,
preferably two wall studs. If there is no wall stud within the cabinet opening, do
not install the microwave oven.
1. Find the studs using one of the following methods:
Stud nder – a magnetic device that locates nails.
OR
Using a hammer, tap lightly across the mounting surface while listening for a
solid sound. A solid sound indicates a stud location.
2. After locating the stud(s), nd the center by probing the wall with a small nail to
nd the edges of the stud. Then place a mark halfway between the edges. The
center of any adjacent studs should be 16" (40.6 cm) or 24" (61 cm) from this
mark.
3. Mark the center of the adjacent stud, and then draw a vertical plumb line down
the center of each stud.
STEP 3 - ALIGN REAR WALL TEMPLATE AND MARK
WALL
Overhead cabinet styles vary. Follow the instructions that apply to the cabinet style
in your home.
IMPORTANT: Disconnect power to electrical outlet.
STYLE 1 - FLAT-BOTTOM CABINET
IMPORTANT: The microwave must be level. Use a carpenter’s level to make
sure the cabinet bottom is level.
1. Draw a vertical line on the wall at the center of the 24" (61 cm) wide opening.
2. Place the Mounting Plate/Rear Wall Template onto the wall so that the
centerline of the template is aligned with the center line, and the top of the
template is touching the bottom of the cabinet. Tape the template in this
position.
7
ENGLISH

16½"
(41.9 cm)
a
ACenter
Line
STYLE 2 - FRAMED, RECESSED CABINET
IMPORTANT: The microwave must be level. Use a carpenter’s level to make
sure the cabinet bottom is level.
1. Draw a vertical line on the wall at the center of the 24" (61 cm) wide opening.
2. Place the Mounting Plate/Rear Wall Template onto the wall so that the
centerline of the template is aligned with the center line, and the top of the
template is touching the bottom of the cabinet. Tape the template in this
position.
a
3/8"TOEDGE
  

  
      
            
 





         
  

NOTE:IT IS VERY IMPORTANT TO
READAND FOLLOW THE DIRECTIONS
INTHE INSTALLATION INSTRUCTIONS
BEFOREPROCEEDING WITH THIS
REARWALL TEMPLATE.
ThisRear Wall Template serves to positionthe bottom
mountingplate and to locate thehorizontal exhaust
outlet.
1.Use a level to check that the template is positioned
accurately.
2.Locate and mark at least one stud on the leftor
right side of the centerline.
 
Itis important to use at least one wood
screwmountedfirmlyina stud to support the weight
ofthe microwave. Mark two additional, evenly spaced
locationsfor thesuppliedtoggle bolts.
3.Drillholes in themarked locations. Wherethere is
a stud, drill a 3/16" hole for wood screws. Forholes
that donot line up with astud, drill 5/8" holes for
toggle bolts.

DONOT INSTALL THE MOUNTING PLATE
ATTHIS TIME.
4.Removethe template from the rear wall.
5.Review the Installation Instruction book for your
installation situation.
Locateand mark holes toalign with holes in the
mountingplate.
IMPORTANT:
LOCATEATLEAST ONE STUD ON EITHER SIDE OF
THECENTERLINE.
MARKTHE LOCATION FOR 2 ADDITIONAL, EVENLY
SPACEDTOGGLE BOLTS IN THE MOUNTING PLATE
AREA.
Locateand mark holes to align with holes in the
mountingplate.
IMPORTANT:
LOCATEATLEAST ONE STUD ON EITHER SIDE OF
THECENTERLINE.
MARKTHE LOCATION FOR 2 ADDITIONAL, EVENLY
SPACEDTOGGLE BOLTS INTHE MOUNTING PLATE
AREA.
Trimthe rear wall template along the dotted line.
Trimtherear wall template along the dotted line.




 

    
      
12"
4"
Darlevueltaa la hoja paraconsultarla
versiónenEspañol.
b
ACenter Line
B30" (76.2 cm) to
cooktop
STYLE 3 - RECESSED CABINET WITH FRONT OVERHANG OR
DECORATIVE TRIM
IMPORTANT:
•The microwave must be level. Use a carpenter’s level to make sure the
cabinet bottom is level.
•If a decorative cabinet trim is interfering with the installation and leveling of
the microwave oven, remove the decorative trim.
•If the cabinets have a front overhang, but no back or side overhang, to keep
the microwave level, place the mounting plate so that the distance from the
top of the mounting plate to the cabinet bottom is equal to the distance
from the bottom of the front overhang to the bottom of the cabinet.
8
ENGLISH
