Haier LC-162G2 User manual

Haier
Drink Cabinet
Operation
Manual
Model：LC-162G2

Content
Before Usage
Features………………………………………………………………………..1
Part Name……………………………………………………………………..2
Security Notice……………………………………………………….……….3
Outside Environment…………………………………………………………4
Begin to use
Preparations before Usage ………………………………………………..5
Adjust and control for operation….……………………………………….6-7
Food storage directions……………………………………………………….8
Maintenance
Clean·stop operation………………………………………………………...9
Question……………………………………………………………………….10
Technical data-circuit diagram……..………………………………………..11
●Please read this manual carefully before usage
●Pay attention to hold this manual.
● The product is commercial-used drink cabinet which should not be used
for the storage of living article, medicine, vaccine, chemical reagent,
blood products or biological products.

Features
●LC-162G2drink cabinet possess a fashion and elegant
appearance. Various kinds of drinks can be put into the cabinet
with a good display.
●computer temperature control, accurate temperature control,
inner blower fan design makes inner temperature evenly.
●inner temperature ranges from 0℃to 10℃, which ensures best
taste of the stored drink.
●adopt design of interpenetrate type and big handle which
produce a gracious appearance.
●inner gentle light is convenient for putting into or taking out the
drink at night.

Part Name
1. strong cold
2. weak cold
3. temperature adjustment
4. temperature display window
5. light switch
6. glass door
7. open/close
8. adjustable foot
9. drink basket
10.drink bracket
11.inner blower fan
12.cooling blower fan

Security Notice
1. The product uses single phase AC 220V/60Hz power. Providing the
power doesn’t meet the requirement of AC 220V/60Hz (187V-242V),
automatic voltage regulator of more than 1000W can be added for
auxiliary usage.
2. Separate and specific sockets should be used to provide reliable earthing.
The power cable of this product is equipped with three-line (earthing)
socket meeting the standards. The third pin of the power(earthing)
should not be removed in any case. And after the completion of the
product installation, the plug should be able to be touched.
3. Dangerous articles like inflammable or explosive articles and acid or
alkali of strong corrosiveness are forbidden to be put into the product.
3. Inflammable spraying agent should not be used in the close range to
avoid fire accident.
4. When inflammable gas like coal gas is leaking:
● Close the leaking valve,
● Open the door and window,
● Should not pull out or insert in the power plug.
5. Once the product is switch off, it should be switch on after waiting for 5
minutes to avoid compressor or system damage. When the product is in
maintenance, power plug should be pulled out.
6. Providing the power cable need to be lengthened, the cross sectional area
of the lengthen cable should not be less than 1.0 mm2 .The power cable
should not be pressed on by the cabinet body or be damaged by
man-made treading.
7. Drink cabinet should not be disassembled or reconstructed without
permission.

Outside Environment
1. The product should be placed in a stable manner, and the packing
seat should be removed to lessen shock or noise. When being moved,
the tilt angle should be no more than 45°.
2. Some room should be kept around the product for draft and heat
elimination.
3. This product should not be under direct sunlight or close to heat
source.
4. This product should not be placed in the position where there is
heavy moisture or where water is easily to be splashed.
5. This product should not be placed in the position whose
environment is too cold where freezing is possible, and should not
be placed under the rain.

Preparation before Usage
1.Remove all packing material, including foam base, all tapes used
to fasten the annex.
2.Check annex and data: check the articles in the box according to
the “packing list”.
3.Before usage, clean the product, for detail refers to “clean” part.
4.Foot adjustment：Adjust the foot according to the ground
situation to make the product stable so as to lessen shock and
noise.
5.Stewing：After being moved, the product should be stewing for
more than 30 minutes, and then the power can be connected.
6.Connect to power：Make a trial operation after connecting to
power, if obvious cooling down can be felt after one hour, it means
the cabinet is in normal operation.
7. Thru-hole pin：There is a thru-hole pin in the data-bag. When
being used for the first time, it should be placed in the water outlet.
In the using process, the water outlet should be straightway to
allow the frost melting water flow into the water box inside the
engine chamber through the water outlet. When being blocked,
the thru-hole pin inside the water outlet should be taken out,
being cleaned and then put into original place.
Attention：Thru-hole pin should not be used as a too to clean
the water outlet, and can only be placed inside the water outlet
to avoid the block of the water outlet.

Food Storage Direction
1. Before stored into this product, the food should be cleaned and
the water bubble should be mopped off.
2. The articles of live articles, medicine and flowers are forbidden
to be stored into this product.
3. Before being placed inside this product, the food should be
airproof to avoid moisture missing and odor mixture.
4. When storing food, the storing time should be in strict
accordance with the storage life marked by the manufacturer.
5. The food should be classified before storing, and the food for
one time should be too much.

Maintenance and Questions
Clean·stop operation
1. For safety, please pull out the power plug before cleaning.
2. Please use soft cloth or sponge to clean this product, dipping water or
soapy water(non-corrosive neutral cleaning agent) , using dry cloth to
clean product after washing to avoid rusting.
3. In cleaning, should not use water to flush the product, and should not
use scrub brush or steel brush for cleaning.
4. Please don’t use materials including organic solvent, boiled water,
washing powder or acid for the cleaning.
5. Providing this product will not be put into operation for a long time, the
power should be switch off. And clean the product according to the
above method, and open the door for air drying , and then keep in
custody after sealing.
Questions:
1. The product doesn’t work
● Check the condition of fuse is good or not？
● Check the condition of plug and socket to see if the contact is good or
not？
● Is there any mal-function of input circuit or control circuit？
● Is the power voltage too low？
● Is the outside temperature lower than inner preset temperature？
2. Compressor operation time is long or inner temperature is not low
enough.

● If the food placed in the cabinet is too many or there is hot food, the
compressor need a long time for operation.
● When being used for the first time, the compressor need a long time for
operation.
● The weather is hot, and the door is opened frequently or hasn’t been
closed tight.
● Whether the position of the cabinet is directly under the sunlight or too
close to the heat source like oven or heating.
3. The light is off.
● Is the cabinet connected with power?
● Is the bulb damaged？
● Is the lamp wire connection not good?
4. Too much noise
● Is the ground smooth? Is the feet adjusted to be stable?
● Does some part of the product contact the outside article or wall？
● Does inner pipelines of the product engine chamber collide with each
other？
● Are all packing material needed to be removed？
5.there is cool dew on the door
● Is the door opened too frequently or being opened for a long time？
●Is the operation temperature set to be very low?

Technical DATA
Model Climate
Type
Power
flexible
wire
Connection
way
Actual
volume
（l）
Rated
voltage
（V）
Rated
frequency
（Hz）
Rated
Current
( A )
Refrigeran
t
R134a
（g）
Power
consumptio
n
（kW·h/2
4h）
Weight
（kg）
Dimensions
LC-162G2 T Y 162 220 60 1.0 110 1.50 56 620 ×506
×1280
packing list
Name
Number
Model
Operation
Manual
Plastic
Bag
Drink
bracket
Basket Thru-hole pin
LC-162G2 1 1 9 1 1
Circuit diagram
Power plug
Display board
Power panel
Inner blower fan
Cooling blower fan
Compressor
Light
Overheat and overload protector
Strong cold
Weak cold
Sensor
Light switch
Gating switch
If there is any alteration on the product, the technical data
and circuit diagram should refer to the plate and circuit
diagram of the product.
