Haier DTA21F98 User manual
.
2
CONTENTS
1.Safetyprecautions……………………………………………………………..……………3
2.TVblock diagram……………………………………………………………………..…….4
3.ReplacementofmemoryIC………………………………………………………….……5
4.Service adjustment……………………………………………………………..…………...5
5.ICsfunctionaldescription…………………………………………………………………8
6.Testpointwaveform………………………………………………………………………10
7.All ICsvoltages……………………………..……………………………………………….10
8.Purity/convergence adjustment………………………………………………………11
9.DVDmaintenance…………………………………………………………………………13
10.ListofParts ………………………………………………………………………….…….14
11.Circuitdiagram………………………………………………………………………Attached
12.Explodedview…………………………………………………………………Attached
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn
.
3
1. SAFETY PRECAUTIONS
1.Thedesignofthisproductcontainsspecial hardware,many
circuitsandcomponentsespeciallyforsafetypurposes.For
continued protection,nochangesshouldbemadetothe
originaldesignunless authorizedinwritingbythe
manufacturer.Replacementpartsmustbeidenticaltothose
usedintheoriginal circuits.Serviceshouldbeperformed by
qualified personnel only.
2.Alterationsofthedesignorcircuitryoftheproductsshould
notbemade.Anydesignalterationsoradditionswill voidthe
manufacturer swarrantyandwill furtherrelievethe
manufacturerofresponsibilityforpersonal injuryorproperty
damageresultingtherefrom.
3.Manyelectrical andmechanical partsintheproductshave
special safety-related characteristics.Thesecharacteristics
areoften notevidentfromvisual inspectionnorcan the
protectionaffordedbythemnecessarilybeobtained byusing
replacementcomponentsrated forhighervoltage,wattage,
etc.Replacementpartswhichhavethesespecialsafety
characteristics areidentifiedinthepartslistofService
manual.Electrical componentshavingsuchfeaturesare
identifiedbyshadingon theschematics andby( )on
thepartslistinServicemanual.Theuseofasubstitute
replacementwhichdoesnothavethesamesafety
characteristics astherecommendedreplacementpart
showninthepartslistofServicemanual maycauseshock,
fire,orotherhazards
4. Don’tshortbetweentheLIVE sideground and
ISOLATED(NEUTRAL)sidegroundorEARTHside
groundwhenrepairing.Somemodel spowercircuitis
partlydifferentintheGND.ThedifferenceoftheGNDis
shownbytheLIVE:()sideGND,ISOLATED
(NEUTRAL): ()sideGNDandEARTH: ()sideGND.
Don tshortbetweentheLIVEsideGNDandISOLATED
(NEUTRAL)sideGND orEARTHsideGND andnever
measurewithameasuringapparatus(oscilloscopeetc.)the
LIVEsideGND andISOLATED(NEUTRAL)sideGNDor
EARTHsideGND atthesametime.If abovenotewillnotbe
kept, afuseoranypartswill bebroken.
5.Ifanyrepairhasbeenmadetothechassis,itis
recommended thattheB1settingshouldbecheckedor
adjusted (See ADJUSTMENT OFB1POWERSUPPLY).
6.The highvoltageapplied tothepicturetubemustconformto
that specifiedinServicemanual. Excessivehighvoltagecan
causean increasein X-Rayemission,arcingand possible
componentdamage,thereforeoperationunderexcessive
highvoltageconditionsshouldbekepttoaminimum,or
shouldbeprevented.Ifseverearcingoccurs,removetheAC
powerimmediatelyanddeterminethecausebyvisual
inspection (incorrectinstallation,cracked ormelted high
voltageharness,poorsoldering,etc.).Tomaintain theproper
minimumlevel ofsoftX-Rayemission,componentsin the
highvoltagecircuitryincluding thepicturetubemustbethe
exactreplacementsoralternativesapproved bythe
manufacturerofthecompleteproduct.
7.Donotcheckhighvoltagebydrawinganarc.Useahigh
voltagemeterorahighvoltageprobewithaVTVM.
Dischargethepicturetubebeforeattemptingmeter
connection,byconnectingacliplead tothegroundframe
andconnectingtheotherendofthelead through a10kΩ2W
resistortotheanodebutton.
8.Whenserviceisrequired,observetheoriginal leaddress.
Extraprecautionshould begiventoassurecorrectlead
dress in thehighvoltagecircuitarea.Whereashortcircuit
hasoccurred,thosecomponentsthatindicateevidenceof
overheatingshouldbereplaced.Alwaysusethe
manufacturer sreplacement components.
9.Isolation Check
(SafetyforElectricalShockHazard)
Afterre-assemblingtheproduct, alwaysperformanisolation
checkon theexposed metal partsofthecabinet(antenna
terminals,video/audioinputandoutputterminals,Control
knobs,metal cabinet, screwheads,earphonejack,control
shafts,etc.)tobesuretheproductissafetooperatewithout
dangerof electrical shock.
10.The surfaceoftheTVscreeniscoatedwithathinfilmwhich
can easilybedamaged. Beverycarefulwithitwhen handle
theTV. ShouldtheTVscreen becomesoiled, wipeitwitha
softdrycloth.Neverrubitforcefully.Neveruseanycleaner
ordetergenton it.
(1)DielectricStrengthTest
Theisolation between theACprimarycircuitandallmetal
partsexposed totheuser,particularlyanyexposed metal
parthavingareturnpathtothechassisshouldwithstanda
voltageof 3000VAC(r.m.s.)foraperiod of onesecond.
(…Withstandavoltageof 1100VAC(r.m.s.)toanappliance
ratedupto120V,and 3000VAC(r.m.s.)toanappliance
rated 200Vormore,foraperiodof onesecond.)
Thismethodoftestrequirestestequipmentnotgenerally
foundintheservicetrade.
(2)LeakageCurrentCheck
PlugtheAClinecorddirectlyintotheACoutlet(donotuse
lineisolation transformersduring thischeck).Using a
“LeakageCurrent Tester”,measuretheleakagecurrentfrom
eachexposedmetal partofthecabinet, particularlyany
exposedmetal parthavingareturnpathtothechassis,toa
knowngood earthground(waterpipe,etc.).Anyleakage
currentmustnotexceed0.5mAAC(r.m.s.).
However,intropical area,thismustnotexceed0.2mAAC
(r.m.s.).
●AlternateCheck Method
PlugtheAClinecorddirectlyintotheACoutlet (donotuse
alineisolationtransformerduringthischeck.).UseanAC
voltmeterhaving 1000 ohmspervoltormoresensitivityin
thefollowingmanner.Connecta1500Ω10Wresistor
paralleled bya0.15μFAC-typecapacitorbetween an
exposed metal partand aknowngoodearthground(water
pipe,etc.).MeasuretheACvoltageacross theresistorwith
theACvoltmeter.Movetheresistorconnection toeach
exposed metal part, particularlyanyexposed metal part
having areturnpathtothechassis,and measuretheAC
voltageacross theresistor.Now,reversetheplug intheAC
outletand repeateachmeasurement.Anyvoltagemeasured
mustnotexceed0.75VAC(r.m.s.).Thiscorrespondsto
0.5mAAC(r.m.s.).
However,intropical area,thismustnotexceed0.3VAC
(r.m.s.).
Thiscorrespondsto0.2mAAC(r.m.s.)
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn
5
3. REPLACEMENTOFMEMORYIC
1.MEMORYIC.
ThisTVusesmemory IC.Inthe memoryICarememorized dataforcorrectlyoperating the video and deflection
circuits.
2.PROCEDUREFORREPLACINGMEMORYIC
(1)Poweroff
Switchthe poweroff and unplug the powercordfromACoutlet.
(2)ReplaceIC
BesuretousememoryICwritten withthe initial datavalues.
(3)PowerOn
Plug thepowercordintothe ACoutlet and switchthe poweron.
(4)Check and set SYSTEM default value:
1)Press “MUTE”à“CALL”à“-\--“à“CALL”à“MUTE”buttonsinsequencetoenterintofactory
status.
2)Ifthe memoryIChaven t been written withthe initial data, press [Program+]/[Program-]toselectitem
INITand press [VOLUME+] /[VOLUME-]tostartinitializememory IC.
3)Check the setting value ofthe SYSTEMdefaultvalue ofTablebelow.Ifthe value isdifferent, select
itemsby[Program+]/ [Program-] keysand setvalue by[VOLUME+]/[VOLUME-]keys.
4)Press “EXIT”button toreturntothe normalscreen.
4. SERVICE ADJUSTMENT
Specificoperation:useremotecontroller
Press “MUTE”à“CALL”à“-\--“à“CALL”à“MUTE”buttonsinsequencetoenterintofactory mode.
Press [Program+]/[Program-]toselectitemsand press [VOLUME+]/[VOLUME-] key,tomakedataadjustment
of corresponding factory menus.
Press “EXIT”keytoexit factory mode.
Focusadjustment
1.Receiveacrosshatchsignal.
2.Whilewatching the screen,adjustthe FOCUSVRon the FBTtomakethe verticaland horizontallinesas
fine and sharpaspossible.
Geometrical adjustment
ReceivePALstandardcompletepatternsignal.
Adjustment steps：
a)Adjust VSL,tothe centrehorizontallinejust appearsfromhalf bottomshadow.
b)Adjust VAM,toget 92%ofvertical picturecontentswouldbe displayed on CRT.
c) Adjust VSH,the centrehorizontalline correspondstoCRT vertical centre.
d)Adjust SCL,tothe linearityofPcardfieldisinpropercondition.
e)Adjust HSH,togetthe picturehorizontal centrecorrespond toCRThorizontalcentre.
ReceiveNTSCsignaland repeataboveadjustment.
AGCAdjustment
Receive60dBμ(1mV) VHcolourbarpatternsignal.
SelectTOPitem.
Adjust value, tonoisereducegraduallyandjust disappeared point.
CRTcutoffandwhitebalance adjustment
a)CRTcut off adjustment
1.SelectitemVG2B, then adjustvalue to32.
2.PRESS “0”key,when the screen shows”VG2”adjustthe SCREENcontrolon Flyback transformerto
makethe screen showalternating flashing charactersof “INSIDEHIGHINSIDELOW”.
b)Whitebalanceadjustment
1.ReceiveaBlackand Whitepattern.
2.AdjustWRP, WRG,WRBitemstogetcolourtemperature9300K ±3JND.
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn
6
AdjustableItems
DirectaccesskeyItems Description Preset Remark
“1”5/6HSH Horizontalshift ON A
“2”5/6VSL Verticalslop 32 A
5/6VAM Verticalamplitude 23 A
5/6SCL S-correction 17 A
5/6VSH Verticalshift 27 A
5/6VOF OSDVerticaloffset 37 A
HOF* OSDHorizontaloffset 42 A
“3”RED Blackleveloffset R 32 A
GRN BlackleveloffsetG 32 A
WPR WhitepointR 30 A
WPG Whitepoint G 26 A
WPB WhitepointB 38 A
“4”TOP AGCTake-overpoint 20 A
VOL Volume 42
9860 Sub-volumeof TDA9860/59 18
HDOL Cathodedrivelevel 59
AGC IFAGCspeed 1
VG2B VG2Brightness 42
IFFS 2
“5”Picturepreset 1
0CON Listen: Contrast 0 A
0BRI Listen: Brightness 0 A
0COL Listen: Colour 50 A
0SHP Listen: Sharpness 50 A
1CON Soft:Contrast 45 A
1BRI Soft:Brightness 45 A
1COL Soft:Colour 50 A
1SHP Soft:Sharpness 50 A
“6”Picturepreset 2
2CON Standard: Contrast 75 A
2BRI Standard: Brightness 50 A
2COL Standard: Colour 50 A
2SHP Standard: Sharpness 60 A
3CON Dynamic: Contrast 85 A
3BRI Dynamic: Brightness 60 A
3COL Dynamic: Colour 60 A
3SHP Dynamic: Sharpness 80 A
NOTE: THEITEMSWITHREMARK “A”ISADJUSTABLEDATA.
Optional data
1.OP1
Bit Function Description Preset Remark
Bit0 VG2_MODE 0 EA
Bit1 YPRPB 1=Enable 1 EA
Bit2 SUPERWOOFER TranslucenceOSDmanual1=Enable 0 EA
Bit3 WOOFER_VOL
1=Enable(CanonlybeselectedeitherRGBandDVD)
0 EA
Bit4 AV2 1=Enable 1 EA
Bit5 SVHS 1=Enable 0 EA
Bit6 DVD 1=Enable 1 EA
Bit7 RGB 1=Enable 0 EA
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn
7
2.OP2
Bit Function Description Preset Remark
Bit7 FSL 1=21dBμV0=26dBμV 0 EA
Bit6 SOY 1=Enable 1 EA
Bit5 ARABIC_SET 1=Enable 0 EA
Bit4 FARSI_SET 1=Enable0 EA
Bit3 CYRILLIC_SET 0 EA
Bit2 EUROUP_SET 1=Enable 1 EA
Bit1 AUTO_SOUND 1 EA
Bit0 AVL 1=Enable 1 EA
3.OP3
Bit Function Description Preset Remark
Bit7 RUSSIA 1=Enable 0 EA
Bit6 ITALY 1=Enable 0 EA
Bit5 GERMANY 1=Enable 0 EA
Bit4 FRANCE 1=Enable 0 EA
Bit3 RUTKISH 1=Enable 0 EA
Bit2 ARABIC 1=Enable 0 EA
Bit1 FARSI 1=Enable 0 EA
Bit0 ENGLISH 1=Enable 1 EA
4.OP4
Bit Function Description Preset Remark
Bit6 HALFTONE 1=Enable 1 EA
Bit5 IDENT_SENSITIVE 1 EA
Bit4 HCO 1=Enable 0 EA
Bit3 LOGO 1 EA
Bit2 TILT 0 EA
Bit1 SPANISH 0 EA
Bit0 ROMANIA 0 EA
5.OP5
Bit Function Description Preset Remark
Bit7 STORE_AV 1= Enable 1 EA
Bit6 OSO 1= Enable 0 EA
Bit5 SOFR_CHANGE 1=Enable 0 EA
Bit4 FADE 1=Enable 0 EA
Bit3 SOUND_M 1= Enable 0 EA
Bit2 SOUND_I 1= Enable 0 EA
Bit1 SOUND_BG 1=EnableWithDVDselect1 1 EA
Bit0 SOUND_DK 1=Enable 0 EA
6.OP6
Bit Function Description Preset Remark
Bit7 RESERVE 1=Enable 0 EA
Bit6 POR_WHEN_BLUE 1=Enable 1 EA
Bit5 MENU_MIDLINE 1=Enable 1 EA
Bit4 MENU_BLUE 1=Enable 1 EA
Bit3 CHILDLOCK 1=Enable 1 EA
Bit2 16_9 1=Enable 0 EA
Bit1 BLUE_SCREEN 1=Enable 1 EA
Bit0 LOGO_LISTEN 1 EA
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn
8
7.OP7
Bit Function Description Preset Remark
Bit7 FMWS 1=Enable 1 EA
Bit6 HOTEL 1=Enable 0 EA
Bit5 PROG_ID 1=Enable 0 EA
Bit4 LED 1=Enable 0 EA
Bit3 TWIST 1=Enable 0 EA
Bit2 BYELORUSSIAN 1=Enable 0 EA
Bit1 UKRANIAN 1=Enable 0 EA
Bit0 AV1 1=Enable 1 EA
8.OP8
Bit Function Description Preset Remark
Bit6 DIRECT_SWITCH_ON
1=Enable 0 EA
Bit5 INNER_DVD 1=Enable 1 EA
Bit4 PROG_FREQ 1=Enable 0 EA
Bit3 FAST_BAR 1=Enable 1 EA
Bit2 AUSTRALIA 1=Enable 0 EA
Bit1 FREQ 1=Enable 1 EA
Bit0 9860 1=Enable 0 EA
Note：Don t adjustanyOPTIONitems,pleaseinformtheengineeraboutanychange.
5. ICsfunctionaldescription
1.N501 UOCTDA9361
SYMBOL PIN DESCRIPTION
STAND BYoutput. 1 InSTANDBYmode,lowlevel(PowerOFF).
ForPowerONthispinwillbehigh.
SCL 2 I2C-busclock line
SDA 3 I2C-busdataline
TUNING 4 tuning Voltage(Vt)PWMoutput
KEY 5 Controlkeys input
SYSTEM 6 TVsystemcontrol
VOL 7 Sound VolumecontrolPWMoutput
MUTE 8 Sound muteoutput
VSSC/P 9 Digitground for μ-controllercoreandperiphery
CTL 10 DVDpowercontrol
STANDBY 11 STANDBYcontrol
VSSA 12 AnaloggroundofdigitalgroundofTV-processor
SECPLL 13 Internallyconnected
VP2 14 2nd supplyvoltageTV-processor(+8V)
DECDIG 15 decouplingdigitalsupplyof TV-processor
PH2LF 16 Phase-2filter
PH1LF 17 Phase-1filter
GND3 18 Ground3forTV-processor
DECBG 19 Band gapdecoupling
AVL/EWD 20 Automaticvolumelevelling
VDRB 21 VerticaldriveBoutput
VDRA 22 VerticaldriveAoutput
IFIN1 23 IFinput1
IFIN2 24 IFinput2
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn
9
IREF 25 Referencecurrentinput
VSC 26 Verticalsawtoothcapacitor
TUNERAGC 27 TunerAGCoutput
AUDEEM/SIFIN1*1 28 AudiodeemphasizeorSIFinput
DECSDEM/SIFIN229 Decouplingsound demodulator
GND2 30 Ground2forTVprocessor
SNDPLL/SIFAGC*1 31 NarrowbandPLL filter
AVL 32 AutomaticVolumeLevelling
HOUT 33 Horizontaloutput
FBISO 34 Flyback input/sandcastleoutput
AUDEXT 35 Externalaudiooutput
EHTO 36 EHT/overvoltageprotection input
PLLIF 37 IF-PLL loopfilter
IFVO/SVO 38 IFvideooutput/selectedCVBS output
VP1 39 supplyvoltageTVprocessor
CVBS INT 40 internalCVBS input
GND1 41 groundforTVprocessor
CVBS/Y 42 CVBS/SVHS(Y)input
CHROMA 43 SVHS(C)input
AUDOUT 44 Audiooutput
INSSW2 45 YUVinsertion input
R2/VIN 46 Rinput/V(R-Y)input/PRinput
G2/YIN 47 Ginput/ Yinput
B2/UIN 48 Binput/U(B-Y)input/PBinput
BCLIN 49 Beamcurrentlimiterinput
BLKIN 50 Blackcurrentinput
RO 51 Redoutput
GO 52 Greenoutput
BO 53 Blueoutput
VDDA 54 Analogsupplyof ClosedCaptiondecoderanddigitalsupplyofTV-processor(3.3V)
VPE 55 Ground
VDDC 56 Digitalsupplytocore(3.3V)
OSCGND 57 Oscillatorgroundsupply
XTALIN 58 Crystaloscillatorinput
XTALOUT 59 Crystaloscillatoroutput
RESET 60 Ground
VDDP 61 Digitalsupplytoperiphery(+3.3V)
P1.0/INT1 62 AV1/AV2modeOutput.
P1.1/T0 63 AV/S-VHSmodeOutput.
P1.2/INT0 64 Remotecontrolsignalinput.
Note Pin TV SVHS AV1 AV2
62 1 0 0 1
63 1 1 0 0
2.N902 24C08/PCF8598
PIN Function
1 GND
2 GND
3 Upperresistance
4 GND
5 SDAdatawire
6 SCLclockwire
7 GND
8 +5VPower
3.N601: Sound poweramplify(AN7522N)
Symbol PINFunction Symbol PIN
Function
Vcc 1 Powersupply GND 7 ground
Out 1(+) 2 Ch1output(+) In2 8 Ch2input
GND(out1) 3 Ch1Ground VOL 9 VolumeControl
Out 1(-) 4 Ch1output(-) Out 2(-) 10 Ch2output(-)
Standby 5 Muteinput GND(out2) 11 Ch2Ground
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn
10
In1 6 Ch1input Out 2(+) 12 Ch2output(+)
4.N301: Verticaloutput (TDA8357A)
Symbol PIN
Function SymbolPIN
Function
INVIN 1 Input PUMPUP 6 Pumpuppower
INVIN 2 Input VOUT 7 Verticaloutput
Vcc 3 Pumpuppower VPRO 8 Verticalprotection
VOUT 4 Verticaloutput VFEEDBACK 9 Verticalfeedback
GND 5 Ground
5.U101：Tuner
PIN
Function PIN
Function
1 AGC 7 +5V
2 vacant 8 vacant
3 Gnd 9 Vt 33V
4 SCL 10 Gnd
5 SDA 11IFOut
6 +5V
6. Test pointWaveforms
7. ICvoltages
5Vpp
0.9Vpp
1.3Vpp
H
H
1Vpp
V
CRTKB
CRTKGCRTKR
95Vpp
95Vpp
95Vpp
H
H
H
TDA9361 PIN53
2.5Vpp
2.5Vpp
3.8Vpp
H
H
H
TDA9361 PIN52
TDA9361PIN51
TDA9361 PIN
33
TDA9361 PIN
34
0.8Vpp
V
TDA9361 PIN21 TDA9361PIN22 TDA9361 PIN59
1.2Vpp
2.6Vpp
H
H
TDA9361 PIN40
TDA9361 PIN38
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn
11
TDA9361
PIN
1 2 3 4 5 6 7 8 9 10
11
12
13
14
15
16
V 03.8
3.6
3.3
3.5
4.4
5.1
1.8
00.18
0.17
02.3
8 5 3
PIN
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
V 4 0 4 0.5
0.7
0.8
1.9
1.9
3.9
3.8
1.6
3.2
2.3
02.3
0.2
PIN
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
V 0.5
0.3
01.7
2.4
3.4
83.9
03.3
03.6
1.4
2.5
2.5
2.5
PIN
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
V 1.9
5.0
2.4
2.4
2.4
3.1
03.2
01.8
1.7
03.2
5.1
3.3
5
TDA8357
PIN
1 2 3 4 5 6 7 8 9
V 0.8
0.7
16 6.9
0 43 7.2 0.3 7.2
AN7522N
PIN
1 2 3 4 5 6 7 8 9 10 11 12
V 10 4.4 0 4.42.75
1.4 0 1.40.35
4.4 0 4.4
24C08/PCF8598
PIN
1 2 3 4 5 6 7 8
V 0 0 5.1
03.2
0 0 5.1
8. PURITY/ CONVERGENCE ADJUSTMENT
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn
12
PURITYADJUSTMENT
1.DemagnetizeCRTwiththe demagnetizer.
2.Loosen the retainerscrewofthe deflection yoke.
3.Removethe wedges.
4.Inputagreen rastersignalfromthe signalgenerator,
and turnthe screen togreen raster.
5.Movethe deflection yokebackward.
6.Bring the long lug ofthe puritymagnetson the short
lug and positionthemhorizontally. (Fig2)
7.Adjustthe gap betweentwolugssothatthe GREEN
RASTERwillcomeintothe centreofthe screen.
(Fig. 3)
8.Movethedeflection yokeforward,andfixtheposition
ofthedeflection yokesothatthe wholescreen will
becomegreen.
9.Insert the wedge tothe top side of the deflection yoke
sothat it will notmove.
10.Input acrosshatchsignal.
11.Verifythatthe screen ishorizontal.
12. Inputred and blue rastersignals,and makesurethat
purityisproperlyadjusted.
CRT
WEDGE
DEFLECTION YOKE
P
46
P:PURITYMAGNET
4:4-POLES (convergencemagnets)
6:6-POLES (convergencemagnets)
P/CMAGNETS
Fig. 1
PURITYMAGNETS
Longlug
Shortlug
Bring thelonglugovertheshortlugand
positionthem horizontally.
Fig. 2
(FRONTVIEW)
GREENRASTER
CENTER
Fig.3
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn
13
STATICCONVERGENCEADJUSTMENT
1.Input acrosshatchsignal.
2.Using 4-poleconvergencemagnetsoverlapthered
and blue linesinthe centerofthe screen (Fig.1)and
turnthemtomagenta(red/blue).
3.Using 6-poleconvergencemagnetsoverlap the
magenta(red/blue)and green linesinthe centerofthe
screen and turnthemtowhite.
4.Repeat2and 3above,and makethe best
convergence.
DYNAMICCONVERGENCEADJUSTMENT
1.Movethedeflectionyokeupand downand overlap
linesinthe periphery.(Fig.2)
2.Movethe deflectionyokelefttorightand overlap the
linesinthe periphery.(Fig.3)
3.Repeat1and 2above,and makethe best
convergence.
Afteradjustment,fixthe wedge at the originalposition.
Fasten the retainerscrewof the deflection yoke.
Fixthe 6magnetswithglue.
(FRONTVIEW)
Fig. 1
(FRONTVIEW)
REDGREENBLUE
BLUE
RED
GREENGREEN
REDBLUE
BLUEGREENRED
Fig.2
(FRONTVIEW)
REDGREENBLUEBLUEGREENRED
RED
GREEN
BLUE
BLUE
GREEN
RED
Fig. 3
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn
14
9. DVDPart:IntroductionofMTK1379maintenance
1.Undernormal powersupplyconditions,the maintenanceplan forMT1379 mono-chipis:firstthe reset
circuitresetsthe MT1379,afterthe crystal oscillatorcircuitgavetheclock signal toMT1379,MT1379 will
startthe initialization check forFlash、E2PROM、SDRAM,aftereverything ischecked tobe normal,itwill
start initialization checkfor7AudioDAC, MT1336 and motorDriver.
2.Ifthe allthe a.m.partsaregood, then MT1379 will sendsignaltomotorDrivertodrivethe servosystem，
pickup then togenerateDVDlightforcollection,tracingthe mainshafttocheckifthereisanydisc,and
confirmifitisCD formatorDVDformatdisc.Ifthe discisinDVDformat,the systemwill read the data
fromthe discdirectly;ifitisinCD formatMT1336 will drivethe CDlasertosend out CDlightand read the
data,the datathen willbe amplified through MT1336 andsenttoMT1379 fordataprocessing,released by
MPEGand resolved intovideodataand audiodata,then theywillbe returned toanalog signalsthrough
VIDEODAC、AUDIODAC.
Decodersection
3.Thereispowersupply, clockand reset, butthe systemdoesnot work.
1）Check ifallthe address wiresrequired forFLASHareexist,and iftheyareinnormalstatus,
especiallycheck ifthe A0~A15 ofFLASHhavenormalsignals,iftherearen t,then inspectMT1379
tosee ifthereisfaultysoldering. IftherearenormalsignalsatA0~A15,checkif the address data
signalofMT1379 and SDRAM isnormal.Ifitisnormal,then check the signalatA16~A19 of
MT1379;iftherearealsosignals,then check the 8video datawires;itthereisno signal,then
check the corresponding pinsofMT1397 tosee ifthereisanyshortcircuit,breakorfaulty
soldering.
2）Ifallthe a.m.conditionsaregood,butthereisstill no video signaloutput, then the filtercircuitafter
MT1379 shall be checked.
4.Systeminnormal operation,butthe audiohasno sound.
1）Check ifallthe signalsofDATA,MCLK,BCLK,LRCKand resetrequired bythe AudioDACare
exist,if thereissignal missing,thencheckthesignal line between MT1379 and AudioDAC. If the
lineisconnectedproperly,butthereisnosignal,then check ifthereisanywelding problematthe
corresponding pinsofMT1379.Ifitisstill OK,it isprobablytheproblemonMT1379 itself.
2）Allthe requiredsignalsareexist, whilethereisno audio output. Then you need tocheckthelower
passing amplifying circuitand the MUTEcircuitatthe back ofAudioDAC.Alsocheck ifthereis
anypowersupplytotheAudioDAC.
3）Check if the powersupplyvoltage required forplaying isat normallevel.
ServoSection
5.Afterthe LOGO ofthemachineshowsnormally,thereisno OSDdisplay.Thisproblemmainlyiscaused
bythe abnormalitybetween servoand MPEG, possibleproblemsmaybe:
1）T1336 and itssurrounding circuitshaveproblems.
2)Servopart of MT1379 hasproblems.
6.OSDdisplayisnormal，whilethereisno action ofservopart（feedingmotordoesnotwork,mainshaft does
no turn, possiblefault statusare:
1)The corresponding signalsgivingbyMT1379 toDMSO、FMSOaremissing,thereason maybe the
problemof MT1379 orthe communication between MT1379 and motorDriver.
2)NotoutputfromMotorDriver,thereason maybe the problemon motorDriveroritscorresponding
circuit.
7.Servopartingood status, whilethereisno pickup action（no light,no focus）
1）No light, checkthe powersupply（powersupplyforpick up）,orthelight producing driving circuit tosee
if theyareinnormalstatus.
2）No focus, check MT1379 tosee ifthereissignal output fromFOSO、TRSO.
Secondly,check motordrivertosee if thereisF+、F-、T+、T-signaloutput.
Thirdly, checkthe externalcorresponding circuit of themotordrivertosee if thereisanyproblem.
8.Allthe servopart hasaction, whileitcannot read outthedisc
1）Check MT1336 ifthereisRFnetpictureoutput, ifthereisn t, then it mustbe the problemofMT1336
and external surrounding circuits,itthereisoutput,then itmightthe problemofMT1369 and its
surrounding circuits.
2）ThereisRFsignal，butnotinnormalstatus，then check MT1336 and surrounding circuits.
3 ）Everything isnormal,butthe disccannot beread out, check MT1369 and itssurrounding circuit
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn
15
10. List ofParts
LOCATIONDESCRIPTION PART
NUMBER QTY
FRONTCABINET ASS Y BCJ7008-----Q 90804172 1
LENSMTAA7011AA--Q 90204552 1
SCREW SJ2824-87 ST3X10F 90600011 1
KEYS MTAA7012AA--Q 90204553 1
SCREW SJ2824-87 ST3X10F 90600011 3
SCREW SJ2838-87 ST3x12F 90600200 2
SWITCH BUTTON MTAA7013AA--Q 90204554 1
SPRING MTBH7004BC--Q 90100663 1
SPEAKER YDT0407-9AU-8W-8Ω94008903 2
SPEAKERWIRE 90401453 2
SCREW SJ2824-87 ST3X8F 90600012 8
SCREW SJ2824-87 ST4X12F 90600015 2
FRONT AVCONNECTORASS Y 90401336 1
DVDSTAND MTAC7014AA--Q 90204549 1
DVDSHIELD（UP）90100709 1
DVDSHIELD（DOWN）90100710 1
SCREW SJ2824-87 ST3X12F 90600034 4
DVDASS Y DC011B 94010705 1
BACKCABINET MTFC7011AJ--Q 90804193 1
SCREW SJ2825-87 ST3X10F 90600037 1
AVLABEL 69.6X71.4 90204538 1
HIGHVOLTAGESPACER TEM101 90200008 1
DVDDOOR MTAH7008AA--Q 90204558 1
POWERCORD CLIP MTAH7005AA--Q 90205628 1
SCREW SJ2824-87 SJ4X16F 90600023 8
SCREW SJ2824-87 SJ4X16F 90600023 2
TOPFOAM STAND MTEE7013AB--Q 90503695 1
BOTTOMFOAMSTAND MTEE7014AB--Q 90503696 1
POWERCORD 90400533 1
PLASTICBRACKET MTFC1014AJ--Q 90806490 1
SCREW SJ2825-87 ST3X10F 90600037 6
ULPOWERCORD JPRVVZ202XDFQ 90402120 1
040 PLASTICCLIP MTAJ1001AG--Q 90200038 1
CRTASS Y 94005582 1
21"CRT A51LXR195X91JD 94004133 1
GROUNDINGWIRE TJC1-1Y/2 90401291 1
DEGUASSINGCOIL AH-HXC-54H 94501083 1
NUT M6 90600003 1
PARKAGINGASS Y 90804858 1
RATING LABEL MTFB5364CA--Q 90205788 1
CARTONBOX 90505178 1
BATTERY 7# 94000213 2
PLASTICBAG FORUSERMANUAL 90204759 1
REMOTECONTROL 94010404 1
PLASTICBAGFOR14”COMPLETESET 90500102 1
PLASTICBAGFORPOWERCORD 90500018 1
USERMANUAL 90506152 1
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn
16
TELESCOPICMAST 94501185 1
MAINBAORDASS Y 94008724 1
N301B HEATSINK HEATSINK 90100450 1
N301C IC TDA8357J 94401409 1
N301D SCREW ST3X8FSJ2831-87 90600097 1
V401B SCREW ST3X8FSJ2831-87 90600097 1
V401A HEATSINK QHS-30184A 90100017 1
V401 TRANSISTOR 2SD2499 94401401 1
N801A HEATSINK QHS-30184A 90100765 1
N801C IC KA5Q0765RTH-YDTU 94401392 1
N801D SCREW ST3X8FSJ2831-87 90600097 1
N802C IC L7809CS 94400808 1
N802B SCREW ST3X8FSJ2831-87 90600097 1
N802A HEATSINK QHS-30184A 90100017 1
N601B IC AN7522N 94401684 1
N601A HEATSINK QHS-30184A 90100665 1
N601C SCREW ST3X8FSJ2831-87 90600097 2
N804B IC KA278R05 94401923 1
N804A HEATSINK MTBH4070BC--Q 90100443 1
N804C SCREW ST3X8FSJ2831-87 90600097 2
VD806 IC FFPF10U20STU 94401512 1
R625 CARBONFILMRESISTOR RT13-1/6W-1K-J------T 94100023 1
R110 METALOXIDERESISTOR RY16S-1W-33-J-05-E-A 94102578 1
R407 METALOXIDERESISTOR RY16S-1W-3.9K-J-12.5-E-A 94102667 1
R307 METALOXIDERESISTOR RY17S-2W-390-J-05-E-A 94100097 1
R414 METALOXIDERESISTOR RY17S-2W-1K-J-05-E-A 94102457 1
R413 METALOXIDERESISTOR RY17S-2W-7.5K-J-05-E-A 94100098 1
R810 METALOXIDERESISTOR RY17S-2W-18K-J-17.5-L-A 94102580 1
R802 METALOXIDERESISTOR RY17S-2W-33K-J-05-E-A 94100101 1
R801 METALOXIDERESISTOR RY17S-2W-33K-J-05-E-A 94100101 1
R501H CARBONFILMRESISTOR RT13-1/6W-47-J------T 94100066 1
C501 CERAMICCAPACITOR CC1-B-500V-470PF-K-F05 94201264 1
C502 CERAMICCAPACITOR CC1-B-500V-470PF-K-F05 94201264 1
R502 CARBONFILMRESISTOR RT13-1/6W-47-J------T 94100066 1
R825 METALOXIDERESISTOR RY17S-2W-47K-J-05-E-A 94102581 1
R818 METALOXIDERESISTOR RY15S-1/2W-1.5K-J------T 94100085 1
R503 CARBONFILMRESISTOR RT13-1/6W-47-J------T 94100066 1
R505 FUSE RESISTOR RF10-2W-2.4Ω-J-A 94100704 1
R506 FUSE RESISTOR RF10-2W-68-J-05-E-A 94100128 1
R820 FUSE RESISTOR RF10-2W-68Ω-J-05-C 94100128
R821 FUSE RESISTOR RF10-2W-1-J-05-E-A 94100125 1
R824 FUSE RESISTOR RF10-1/2W-1-J-05-E-A 94102583 1
R415 FUSE RESISTOR RF10-1/2W-1-J-05-E-A 94102583 1
R302 FUSE RESISTOR RF10-1/2W-10-J-05-E-A 94102668 1
R409 FUSE RESISTOR RF10-1/2W-0.22-J-05-E-A 94102584 1
R306 FUSE RESISTOR RF10-2W-0.68-J-05-E-A 94102586 1
R815 FUSE RESISTOR RF10-2W-0.18-J-15-L-A 94102669 1
R416 FUSE RESISTOR RF10-1/2W-68-J-12-L-A 94102591 1
DV801 TVR14561 94400806 1
P801 THERMISTOR MZ73-14RM270V 94400046 1
RP801 THERMISTOR MF72-2-5Ω±N 94400047 1
C248 CERAMICCAPACITOR CS1-F-63V-0.1μF-Z-F05 94201617 1
C419 CERAMICCAPACITOR CT1-B-2kV-681pF-K-07-A 94201373 1
C410 CERAMICCAPACITOR CT1-B-2kV-681pF-K-07-A 94201373 1
C807 CERAMICCAPACITOR CT1-B-2kV-561pF-K-07-A 94200067 1
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn
17
C810 CERAMICCAPACITOR CT1-B-500V-560pF-K-F05 94201449 1
C823 CERAMICCAPACITOR CT81-400VAC-18B-2E4-332-M-10-C-A
94202412 1
C805 CAPACITOR CT1-B-1kV-1000pF-K-07-A 94201071 1
C849 CAPACITOR CL21X-63V-224-J------F 94201463 1
C216 CAPACITOR CL21X-63V-224-J------F 94201463 1
C414 CAPACITOR CL21X-400V-104-J-07-A-A 94200098 1
C227 CAPACITOR CBB13-50V-104-J-07-A-A 94200099 1
C416 CAPACITOR CBB21-400V-364-J-20-G-A 94200101 1
C409 CAPACITOR CBB81-1.6KV-752-J-20-A-A 94200104 1
C802A CAPACITOR MKT61-275V-104-M-15-G-A 94200105 1
C222 ELECT. CAPACITOR CD110X-50V-1μF-M-F05 94200043 1
C236 ELECT. CAPACITOR CD110X-16V-22μF-M-F05 94201043 1
C846 ELECT. CAPACITOR CD110X-25V-1000μF-M-05-A 94201011 1
C811 ELECT. CAPACITOR CD110X-25V-2200μF-M-05-A 94201319 1
C610 ELECT. CAPACITOR CD110X-25V-1000μF-M-05-A 94201011 1
C304 ELECT. CAPACITOR CD263-100V-33uF-M-05-A 94202297 1
C418 ELECT. CAPACITOR CD263-100V-33uF-M-05-A 94202297 1
C808 ELECT. CAPACITOR CD263-160V-100μF-M-07-A 94200736 1
C411 ELECT. CAPACITOR CD288H-250V-22uF±20%-05-G-A 94201604 1
C801 ELECT. CAPACITOR CD293-400V-150μF-M-10-A 94201341 1
C852 ELECT. CAPACITOR CD110X-16V-1000μF-M-F05 94200802 1
N201 IC TDA9361PS/N2/A 94401967 1
N202 IC M24C08(BR24C08) 94400636 1
N202 IC PC817C 94400036 1
N703 IC TC4052BP 94400138 1
N702 IC HEF4053 94400503 1
X201 CRYTAL JA12D-12MHZ-20PF 94600198 1
Z201 CERAMICTRAPFILTER XT5.5B 94600015 1
TU101 TUNER TEDE9-280A 0094005862
1
SF101 SAWFILTER D2901C 94600276 1
F801 FUSE TSG-3.15A-250V 94000137 1
F801A FUSE CLIP FC503 90100021 1
F801B FUSE CLIP FC503 90100021 1
L401 LINEARITYCOIL LX034 94501053 1
L801 LINEFILTER LCL-207 94500686 1
T444 FLYBACKTRANSFORMER BSC25-0283G 94501054 1
T801 SWITCHING MODETRANSFORMER
BCK-07-DE7 94501146 1
T401 HORIZONTALTRANSFORMER AA26-50001B 94500034 1
V999 CRTSOCKET GZS10-2-BD 94300007 1
CN801 CONNECTORSOCKET TJC1-2A 94300110 1
CN802 CONNECTORSOCKET TJC2-2A 94300063 1
CN601 CONNECTORSOCKET TJC3-2A 94300092 1
CN602 CONNECTORSOCKET TJC3-2A 94300092 1
CN502 CONNECTORSOCKET TJC3-3A 94300111 1
CN200 CONNECTORSOCKET TJC3-3A 94300012 1
CN211 CONNECTORSOCKET TJC3-3A 94300012 1
CN210 CONNECTORSOCKET TJC3-5A 94300104 1
CN503 CONNECTORSOCKET TJC3-5A 94300104 1
CN401 CONNECTORSOCKET TJC1-4A 94300307 1
CN809 CONNECTORSOCKET TJC3-5A 94300104 1
VD802 DIODE T1R5GU41-12.5-M 94401993 1
VD803 DIODE T1R5GU41-12.5-M 94401993 1
C259 DIODE MTZJ5.1B------T 94400617 1
CN501 WIREASS Y TJC3-5Y-750mm 90401725 1
CN502 WIREASS Y TJC3-3Y-750mm 90401724 1
GT501 CONNECTORSOCKET TJC1-1A 94300090 1
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn
18
GT502 CONNECTORSOCKET TJC1-1A 94300090 1
C503 CERAMICCAPACITOR CC1-B-500V-470PF-K-F05 94201264 1
C705 CAPACITOR CD71-50V-1uF-M-F05 94200994 1
C848 ELECT. CAPACITOR CD110X-25V-1000μF-M-05-A 94201011 1
CN702 WIREASS Y 90401872 1
CN706 WIREASS Y 90401670 1
CN703 CONNECTORSOCKET TJC3-8A 94300106 1
S WIREASS Y 90401672 1
CN810 WIREASS Y TJC3-4A 90400514 1
CN807-CN808
WIREASS Y 90401671 1
G WIREASS Y 150mm 90400064 1
DVD SCARTSOCKET CS-103 94300457 1
MAINPCB 91801280 91801280 1
R104 CARBONFILMRESISTOR RT13-1/6W-10-J------T 94100065 1
R752 CARBONFILMRESISTOR RT13-1/6W-10-J------T 94100065 1
R742 CARBONFILMRESISTOR RT13-1/6W-10-J------T 94100065 1
R216 CARBONFILMRESISTOR RT13-1/6W-47-J------T 94100066 1
R103 CARBONFILMRESISTOR RT13-1/6W-100Ω-J-T52 94100017 1
R943 CARBONFILMRESISTOR RT13-1/6W-47-J------T 94100066 1
R250 CARBONFILMRESISTOR RT13-1/6W-47-J------T 94100066 1
R257 CARBONFILMRESISTOR RT13-1/6W-47-J------T 94100066 1
R258* CARBONFILMRESISTOR RT13-1/6W-75-J------T 94100067 1
R265 CARBONFILMRESISTOR RT13-1/6W-75-J------T 94100067 1
R715 CARBONFILMRESISTOR RT13-1/6W-75-J------T 94100067 1
R735 CARBONFILMRESISTOR RT13-1/6W-75-J------T 94100067 1
R733 CARBONFILMRESISTOR RT13-1/6W-75-J------T 94100067 1
R734 CARBONFILMRESISTOR RT13-1/6W-75-J------T 94100067 1
RS03 CARBONFILMRESISTOR RT13-1/6W-75-J------T 94100067 1
R718 CARBONFILMRESISTOR RT13-1/6W-75-J------T 94100067 1
RS01 CARBONFILMRESISTOR RT13-1/6W-75-J------T 94100067 1
RS02 CARBONFILMRESISTOR RT13-1/6W-100-J------T 94100017 1
R208 CARBONFILMRESISTOR RT13-1/6W-100-J------T 94100017 1
R209 CARBONFILMRESISTOR RT13-1/6W-100-J------T 94100017 1
R210 CARBONFILMRESISTOR RT13-1/6W-100-J------T 94100017 1
R230 CARBONFILMRESISTOR RT13-1/6W-100-J------T 94100017 1
R235 CARBONFILMRESISTOR RT13-1/6W-100-J------T 94100017 1
R236 CARBONFILMRESISTOR RT13-1/6W-100-J------T 94100017 1
R237 CARBONFILMRESISTOR RT13-1/6W-100-J------T 94100017 1
R245 CARBONFILMRESISTOR RT13-1/6W-100-J------T 94100017 1
R252 CARBONFILMRESISTOR RT13-1/6W-100-J------T 94100017 1
R743 CARBONFILMRESISTOR RT13-1/6W-100-J------T 94100017 1
R744 CARBONFILMRESISTOR RT13-1/6W-100-J------T 94100017 1
R745 CARBONFILMRESISTOR RT13-1/6W-100-J------T 94100017 1
R740 CARBONFILMRESISTOR RT13-1/6W-100-J------T 94100017 1
R741 CARBONFILMRESISTOR RT13-1/6W-100-J------T 94100017 1
W235 CARBONFILMRESISTOR RT13-1/6W-100-J------T 94100017 1
W236 CARBONFILMRESISTOR RT13-1/6W-100-J------T 94100017 1
R280 CARBONFILMRESISTOR RT13-1/6W-100-J------T 94100017 1
R281 CARBONFILMRESISTOR RT13-1/6W-100-J------T 94100017 1
R251 CARBONFILMRESISTOR RT13-1/6W-200-J------T 94100133 1
R263 CARBONFILMRESISTOR RT13-1/6W-200-J------T 94100133 1
R843 CARBONFILMRESISTOR RT13-1/6W-220-J------T 94100019 1
R817A CARBONFILMRESISTOR RT13-1/6W-220-J------T 94100019 1
R244 CARBONFILMRESISTOR RT13-1/6W-390-J------T 94100134 1
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn
19
R255 CARBONFILMRESISTOR RT13-1/6W-430-J------T 94100069 1
R106 CARBONFILMRESISTOR RT13-1/6W-470-J------T 94100020 1
R256 CARBONFILMRESISTOR RT13-1/6W-470-J------T 94100020 1
R242 CARBONFILMRESISTOR RT13-1/6W-1K-J------T 94100023 1
R243 CARBONFILMRESISTOR RT13-1/6W-1K-J------T 94100023 1
R258 CARBONFILMRESISTOR RT13-1/6W-1K-J------T 94100023 1
R840 CARBONFILMRESISTOR RT13-1/6W-510-J------T 94100070 1
R227 CARBONFILMRESISTOR RT13-1/6W-1K-J--------T 94100023 1
R841 CARBONFILMRESISTOR RT13-1/6W-1K-J------T 94100023 1
R310 CARBONFILMRESISTOR RT13-1/6W-1.5K-J------T 94101350 1
R861 CARBONFILMRESISTOR RT13-1/6W-1.5K-J------T 94100025 1
R102 CARBONFILMRESISTOR RT13-1/6W-2.2KΩ-J-T52 94100026 1
R215 CARBONFILMRESISTOR RT13-1/6W-3.3K-J------T 94101328 1
R266 CARBONFILMRESISTOR RT13-1/6W-3.3K-J------T 94101328 1
R247 CARBONFILMRESISTOR RT13-1/6W-3.3K-J------T 94101328 1
R220 CARBONFILMRESISTOR RT13-1/6W-3.3K-J------T 94101328 1
R278 CARBONFILMRESISTOR RT13-1/6W-3.3K-J------T 94101328 1
R747 CARBONFILMRESISTOR RT13-1/6W-3.3K-J------T 94101328 1
R746 CARBONFILMRESISTOR RT13-1/6W-3.3K-J------T 94101328 1
R845 CARBONFILMRESISTOR RT13-1/6W-3.3K-J------T 94101328 1
R846 CARBONFILMRESISTOR RT13-1/6W-3.3K-J------T 94101328 1
R229 CARBONFILMRESISTOR RT13-1/6W-3.9K-J------T 94100071 1
R830 CARBONFILMRESISTOR RT13-1/6W-3.3K-J------T 94101328 1
R105 CARBONFILMRESISTOR RT13-1/6W-3.3K-J------T 94101328 1
R211 CARBONFILMRESISTOR RT13-1/6W-4.7K-J------T 94100029 1
R212 CARBONFILMRESISTOR RT13-1/6W-4.7K-J------T 94100029 1
R207 CARBONFILMRESISTOR RT13-1/6W-4.7K-J------T 94100029 1
R262* CARBONFILMRESISTOR RT13-1/6W-4.7K-J------T 94100029 1
R241 CARBONFILMRESISTOR RT13-1/6W-4.7K-J------T 94100029 1
R623 CARBONFILMRESISTOR RT13-1/6W-4.7K-J------T 94100029 1
R605 CARBONFILMRESISTOR RT13-1/6W-5.6KΩ-J------T94100721 1
R606 CARBONFILMRESISTOR RT13-1/6W-5.6KΩ-J------T94100721 1
R610 CARBONFILMRESISTOR RT13-1/6W-5.6KΩ-J------T94100721 1
R611 CARBONFILMRESISTOR RT13-1/6W-5.6KΩ-J------T94100721 1
R213 CARBONFILMRESISTOR RT13-1/6W-6.2K-J------T 94100072 1
R848 CARBONFILMRESISTOR RT13-1/6W-15K-J------T 94100034 1
R847 CARBONFILMRESISTOR RT13-1/6W-15K-J------T 94100034 1
R248 CARBONFILMRESISTOR RT13-1/6W-6.8K-J------T 94100031 1
R246 CARBONFILMRESISTOR RT13-1/6W-8.2K-J------T 94100032 1
R860 CARBONFILMRESISTOR RT13-1/6W-10K-J------T 94100033 1
R862 CARBONFILMRESISTOR RT13-1/6W-15K-J------T 94100034 1
R218 CARBONFILMRESISTOR RT13-1/6W-10K-J------T 94100033 1
R214 CARBONFILMRESISTOR RT13-1/6W-10K-J------T 94100033 1
R218 CARBONFILMRESISTOR RT13-1/6W-10K-J------T 94100033 1
R831 CARBONFILMRESISTOR RT13-1/6W-10K-J------T 94100033 1
R620 CARBONFILMRESISTOR RT13-1/6W-10K-J------T 94100033 1
R622 CARBONFILMRESISTOR RT13-1/6W-10K-J------T 94100033 1
R738 CARBONFILMRESISTOR RT13-1/6W-220-J------T 94100019 1
R739 CARBONFILMRESISTOR RT13-1/6W-220-J------T 94100019 1
R849 CARBONFILMRESISTOR RT13-1/6W-10K-J------T 94100033 1
R833 CARBONFILMRESISTOR RT13-1/6W-10K-J------T 94100033 1
R832 CARBONFILMRESISTOR RT13-1/6W-10K-J------T 94100033 1
R850 CARBONFILMRESISTOR RT13-1/6W-10K-J------T 94100033 1
R238 CARBONFILMRESISTOR RT13-1/6W-1K-J------T 94100023 1
R311 CARBONFILMRESISTOR RT13-1/6W-12K-J------T 94100073 1
R219 CARBONFILMRESISTOR RT13-1/6W-15K-J------T 94100034 1
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn
20
R226 CARBONFILMRESISTOR RT13-1/6W-15K-J------T 94100034 1
R249 CARBONFILMRESISTOR RT13-1/6W-20K-J------T 94100074 1
R274 CARBONFILMRESISTOR RT13-1/6W-22K-J------T 94100779 1
R276 CARBONFILMRESISTOR RT13-1/6W-27K-J------T 94100780 1
W610 CARBONFILMRESISTOR RT13-1/6W-56K-J------T 94100038 1
R275 CARBONFILMRESISTOR RT13-1/6W-270K-J------T 94100943 1
R273 CARBONFILMRESISTOR RT13-1/6W-33K-J------T 94100036 1
R621 CARBONFILMRESISTOR RT13-1/6W-33K-J------T 94100036 1
R851 CARBONFILMRESISTOR RT13-1/6W-33K-J------T 94100036 1
R233 CARBONFILMRESISTOR RT13-1/6W-36KΩ-J 94100767 1
R261 CARBONFILMRESISTOR RT13-1/6W-68K-J------T 94100039 1
R277 CARBONFILMRESISTOR RT13-1/6W-100K-J------T 94100077 1
R303 CARBONFILMRESISTOR RT13-1/6W-100K-J------T 94100077 1
R314 CARBONFILMRESISTOR RT13-1/6W-270K-J------T 94100943 1
R407 METALOXIDERESISTOR RY15S-1/2W-0.39-J------T 94100079 1
R408 METALOXIDERESISTOR RY15S-1/2W-33-J------T 94100080 1
R403 METALOXIDERESISTOR RY15S-1/2W-270-J------T 94100083 1
R406 METALOXIDERESISTOR RY15S-1/2W-330-J------T 94102592 1
R809 METALOXIDERESISTOR RY15S-1/2W-39K-J------T 94102161 1
R822 METALOXIDERESISTOR RY15S-1/2W-470K-J------T 94100090 1
R823 METALOXIDERESISTOR RY15S-1/2W-470K-J------T 94100090 1
R807 RESISTOR RS11-1/2W-3.3M-K------T 94100103 1
RX801 RESISTOR RS11-1/2W-3.3M-K------T 94100103 1
R260 METALFILMRESISTOR RJ13-1/6W-9.1K-J------T 94100106 1
R262 METALFILMRESISTOR RJ13-1/6W-9.1K-J------T 94100106 1
R259 METALFILMRESISTOR RJ13-1/6W-100K-J------T 94102210 1
R228 METALFILMRESISTOR RJ13-1/6W-39K-G------T 94101159 1
R312 METALFILMRESISTOR RJ15X-1/2W-2.2KΩ-F-T52 94102527 1
R313 METALFILMRESISTOR RJ15X-1/2W-2.2KΩ-F-T52 94102527 1
R308 METALFILMRESISTOR RJ15S-1/2W-1.5-F------T 94101353 1
R305 METALFILMRESISTOR RJ15S-1/2W-1.3-F------T 94102593 1
R803 METALFILMRESISTOR RJ15S-1/2W-390Ω±1%-----T94102526 1
R805 METALFILMRESISTOR RJ15S-1/2W-600-J------T 94102162 1
R819 METALFILMRESISTOR RJ15S-1/2W-1K-F------T52 94101354 1
R420 METALFILMRESISTOR RJ15S-1/2W-232K-F------T 94102851 1
R816 METALFILMRESISTOR RJ15S-1/2W-123K-F------T 94102595 1
R817 METALFILMRESISTOR RJ15S-1/2W-2.49K-F-J 94101355 1
C417 CERAMICCAPACITOR CT1-B-500V-330pF-K-F05 94202282 1
C403 CERAMICCAPACITOR CT1-B-500V-470pF-K-F05 94201264 1
C402 CERAMICCAPACITOR CT1-B-500V-560pF-K-F05 94201449 1
C847 CERAMICCAPACITOR CT1-B-500V-560pF-K-F05 94201449 1
C845 CERAMICCAPACITOR CT1-B-500V-560pF-K-F05 94201449 1
C239 CERAMICCAPACITOR CC1-CH-63V-33pF-J-F05 94201124 1
C240 CERAMICCAPACITOR CC1-CH-63V-33pF-J-F05 94201124 1
C208 CERAMICCAPACITOR CC1-CH-63V-56pF-J-F05 94201228 1
C209 CERAMICCAPACITOR CC1-CH-63V-56pF-J-F05 94201228 1
C804 CERAMICCAPACITOR CT1-B-63V-3900PF-K-F05 94202277 1
C218 CERAMICCAPACITOR CT1-B-63V-2200pF-K-F05 94200760 1
C249 CERAMICCAPACITOR CC1-CH-63V-150PF-J-F05 94200715 1
C232 CERAMICCAPACITOR CC1-CH-63V-330PF-J-F05 94202373 1
C231 CERAMICCAPACITOR CT1-B-63V-1000pF-K-F05 94200981 1
C234 CERAMICCAPACITOR CT1-B-63V-1000pF-K-F05 94200981 1
C110 CERAMICCAPACITOR CT1-B-63V-1000pF-K-F05 94200981 1
C229 CERAMICCAPACITOR CT1-B-63V-3300PF-K-F05 94201178 1
C221 CERAMICCAPACITOR CT1-B-63V-4700PF-K-F05 94201039 1
C603 CERAMICCAPACITOR CT1-B-63V-4700PF-K-F05 94201039 1
PDF 件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.com.cn
Other manuals for DTA21F98
1
Table of contents
Other Haier TV manuals
Haier
Haier L32D1120 User manual
Haier
Haier DX-RCRT20-09 User manual
Haier
Haier HL42K User manual
Haier
Haier HL15T Building instructions
Haier
Haier HT-3788 User manual
Haier
Haier L26V6-A8 User manual
Haier
Haier MX-TM7414Mpeg4 User manual
Haier
Haier 29F9D User manual
Haier
Haier L42V6-A8K User manual
Haier
Haier 28e2000 User manual
