Haier XQS70-98 User manual

Please read this manual carefully
before using.
Retain it for future reference.
Double-drive Automatic Washing Machine
This manual is for
XQS70-98
User's manual

Contents
Names of the parts..............
Safety precautions............................................... 2
Installation and adjustment................................
Install the water inlet hose.................................. ..6
Preparation before washing................................
Put in the laundries..............................................
Use of the detergent...........................................
Use the operation buttons.................................
Close the top lid................................................ 14
Finish washing.................................................. 14
Disposal after washing...................................... 15
Trouble shooting answer to question................ 16
Packing list Specification
.....................................1
....
.......4
....
......8
.....9
.....9
.......10
.......
.......
.......
.......
.....................................17

Water inlet valve
Water absorption
cushion
Power cord
Handle
Top lid components
Inner cover components
Detergent box
Control panel seat
Outer tub cover
Balance ring
Attachment block 3 pieces
Inner tub
Lint filter
Pulsator
Control panel coating
Cabinet
Liquid blenching filler
Adjustable leg
Rear faceplate
The figure in this manual being sketch map and with the improvement of our products, the machine you buy
is like to be different from the figure indicated in the manual .Please understand.
Back cover
Draining hose
hanging hole
Drain hose
Names of the parts
Meaning and description of the symbols
Contents marked with that symbol are actions forbidden to perform.
Performing of those actions may result in damage of the machine
or influence the personal safety of the users.
Contents marked with that symbol are related to the safety of the product
and the personal safety of the users. Please operate in strict conformity to
the contents, otherwiseit may result in damage of the machine or influence
the personal safety of the users.
Warning sign
Forbidden sign
1

Safety precautions
Earth
The ventilation
holes at the bottom
Soft object
Do not let the machine share one receptacle with other
electric appliances. If the plugging into the receptacle
is loose, do not use the plug any more.
Do not wash water-proof laundries like
the raincoat, bike covers etc. to avoid
abnormal vibrations in spinning.
Please plugthe powerplug onspecial
receptacle. Be sure to use three-pins
power receptacle. Ensurethat the earthing
prong of the power receptacle is earthed
reliably. Useleakage protector ifpossible.
Do not bend ,extend,twist,bind by force.Do not press or nip it with weight.
Keep the pin of the power plug clean,if the power plug is polluted with dust,please wipe with
dry cloth carefully.
If the power cord or the power plug is bad, to avoid risk it is
required to have it replaced by the technicians of our
special shop or the after-sale service department.
Do not put the machine at damp place like
the bathroom. Never wash it with water. Do
not put wet laundries on the control panel.
Do not use water hotter than 50
In case the washing machine is installed on ground with
carpet, do not block the ventilation hole with carpet.
The washing machine must be positioned
so that the plug isaccessible. Be sure topull the
plug off and close the water faucet in
following cases: power failure, delivering
the machine, setting the machine idle or
cleaning the machine. Do not plug
or pull the power plug with wet hand.
2

Do not stretch hands into the working machine.
It is dangerous even if the rotation is slow.
Take special care of the children.
Do not decompose, repair or alter the machine
by yourself.
Do not put any hot or heavy items (such as the kettle
with hot water) on the washing machine
Do not wash laundries with volatile materials
(such as thinner, petrol etc.).
Keep the machine away from direct sunlight and
heat source like the heater.
The lint filter shall be kept in good condition, and
installed to proper position. If the lint filter is lost
or damaged, please contact the local after-sales
service department of our company.
To prevent your laundries and washing machine from
damages, be sure to take out all of the foreign materials
from your pocket, such as coins, buttons, sandor hair
pins etc.
Before washing, please check if the water tap is open,
and if the water inlet pipe is connected properly.
It is suggested to use low-foaming washing powder.
The appliance is not instruct for use of
young children of infirm persons without
supervision.Young children should be
supervised to ensure that they do not
play with the appliance.
Benzene
3
Dismantle
Install
Dismantle
Install
The cover of lint filter
lint filter
The back coverof lint filter
lint filter

Inner cover shaft
Outer tub cover
shaft groove
Outer tub cover
Inner cover
Install the bottom plate
After opening the package, please lean
the washing machine gently down on
soft items (liketowel cloth, blanket,etc.).
Install the bottom plate to the bottom
of the machine with eight screws by a
cross screwdriver, then lift the
machine up gently. See to the figure:
Adjust the Installation position
The largest allowed slope of the shank base of the machine is 2 . The slanting or rough ground will result in
unstable running or stoppage of the machine. Please adjust it with following methods:
Confirm it's horizontal
Hang the plumb to confirm it's horizontal
Adjust the adjustable foot
(1) To twist theadjustable foot atthe right frontof
the cabinet (frontthe sight offront), please first
lift up theside of thefoot slightly,loosen the
adjustable nut, andtwist the foot.
(2) Fasten thenut after adjustment.
Loosen Fasten
High Low
adjustable nut
adjustable foot
Please install and adjust the machine according to the requirement of the manual.
It is very important to your security and correct operating the machine.
Install the inner cover components
1.Open the top lid of the washing machine.
2.Put the inner cover component on the outer tub cover, aiming
the inner cover shaft to the installation hole of the corresponding
outer tub cover shaft groove.
3.Firstly insert the inner cover shaft of Iside into the correspon
-ding outer tub cover shaft groove, then push the another inner
cover shaft into the corresponding outer tub cover shaft groove.
Please install to designated position to guarantee there are no
dropping or abnormal sound in opening and closing of the inner
cover, and the operation shall be smooth. Do not dismount the
inner cover component after washing.
Soft items
Back
Screw
Front
Bottom plate
4

1.The height of the drain hose shall be
less than 10cm, or the drainage will not
be smooth, and cost such long time that
the machine may stop at mid way.
2.Do not ramp or press the drain hose.
3.If the drain hose is too long, cut it at mid
point. To make smooth drainage, cut the
front end of the hose slantingly.
4.If extra drain hose is needed, please
make separate purchase. The inner
diameter of the extra hose shall not
less than 30mm, and the length shall
not exceed 1.5m.
Usage of the drain hose
The drain hoseshall drain smoothly
5.If the extrahose is toolong, cut it
either atA orat B point.
How to change the direction of the drain hose
1.Lean the machine downgently with the front
surface facing the ground. Loosen the eight
screws by a crossscrewdriver.
3.Extend the drain hose from the right side. Push the
drain hose into the groove with hands.
4.Install the bottom plate (as per indicated before),
then lift the machine up gently.
2.Pull out the drain hose from the groove at the left side.
Back
Front
Bottom plate
Soft item
Use groove at
this side after
direction changing
Page 4
5

The exit end face of the faucet
Connection between the water inlet hose jointerand the water faucet
water faucet, suitable water faucet, not suitable
It is required that the front end shall be longer than 10mm.
The exit end face of the faucet shall be flat and smooth. If not please file it to avoid leakage.
2 Loosen the screw till the water faucet can be accessed. Put the jointer of the water inlet hose on the faucet.
See to Figure 2. (If the faucet is too large and the jointer can not be set on the water faucet, please loosen
the four screws and take out the bushing in the jointer. The front end of the faucet must be smooth, otherwise
it may leak water. See to Figure 3.)
1.Press the lower end of the lock lever and push down the slider. Take off the water inlet hose jointer from the
water inlet hose component. See to Figure 1.
3.Fasten the four screws evenly. See to Figure 4.
about 4mm after twisting
Remark: .Before twisting the fastening nut, the threading is 4mm above the upper
surface of the nut. After twisting, the threading is less than 2mm above the upper
surface of the nut. See to Figure 6
About above 2mm after twisting
water inlet hose jointerwater inlet hose jointer
Screw knife
Screw
Bushing
Nameplate
Screw nut
water inlet hose Figure 1
Figure 4
Figure 2
Figure 5
Figure 3
Figure 6
Slider
Lock level
4 Take off the nameplate. Twist the fastening nut as per the indication of the figure
to seal up the exit end face of the faucet. See to Figure 5.
Confirm the water faucet
Install the water inlet hose
6

Connection between the water inlet hose and the washer
Dismantle the water inlet hose
Connection between the jointer of the water inlet hose
and the water inlet hose
Check the connection between the jointer of the water inlet hose
and the water faucet
1.Do not take off the water absorption cushion. Please check if the
cushion is dropped or damaged before each usage. If it happens
please contact our after-sale department immediately.
1.Swing the hose gently to confirm if it is fastened stable.
2.After installation, open the faucet to check if it leaks.
3.Do not bend the hose with overstrain.
1.Push down the slider. Insert the water inlet hose into the jointer.
2 Hang the lock lever to the jointer. Release the slider till a click sound is heard.
Locking level
Slider
water absorption cushion.
nut of the water inlethose
the jointer of the water inlet hose
Slider
Locking level
jointer of the water inletvalve
1. Close the water faucet.
2. Press the locking lever. Push down the slider. Then pull of the water inlet hose.
If the machine is used frequently, the jointer of the water inlet hose can be kept
on the faucet to prevent damaging the fixing screw.
2 Put the nut of the water inlet hose on the valve jointer.
3 Fasten the nut. Swing it gently to confirm if it's suitable.
4.Before each usage please check if the connection
between the jointer of the water inlet hose and the
water faucet, and the installation of the water inlet
hose are firm, so as to prevent dropping from
improper installation position.
Remarks: use the newhose sets suppliedwith the washer.
Any otherold hose setsshould not beused.
7

1 Preparation before washing
Pay attention to followings before washing the laundries
Preparation before washing
1.Connect the water inlet hose. Open the water faucet.
2.Confirm that the washing machine is earthed reliably.
Then insert the power plug into the receptacle. The
earth terminal shall not link to gas pipeline and
faucet water pipeline.
3.Put down the drain hose.
Check if
the laundries
has special
requirement
on washing
Clear the
pocket. Take
out the coins,
sand, hairpins
etc.
Tie the long
strips; fasten
the buttons;
close zippers.
When the pulsator
is running , the
buttons of the
laundries may
cause noise. For
the sake of
discretion, please
put the laundries
with buttons into
other laundries.
The quantity of
the laundries
shall not be too
large. Stretch
and loosen the
laundries before
putting them in
the tub.
a. Check ifthe laundries are applicable for washing with machine.
b. Divide thelaundries that are not colorfast from other laundries.
c. Put thoselaundries difficult to absorb water into water with hand.
d. For thoselaundries with heavy soil, pleasefirst remove the dirt like mudor dust.
For the partswith heavy soil, please apply detergent on them in advance, which
can make iteasier to remove the soil.
e. For thoselaundries that may get lint ball and thosewith long fur, turn itover before
putting in.
f. Do not put those laundries polluted by chemicals into the washing machine directly.
Pay attention to following before washing
8
