Haier FCD-8 User manual

Group
Qingdao Economic &Technical Development Zone
Haier Water Heater Co.,Ltd.
Please read this manual before usage
Retain it for future reference
Mini Sea-ox
Haier Household Electric Water Heater User' Manual
FCD-8

6
Contents
Before usage
Installlation
FAQ *After service
Features
Installation
FAQ
Parameters
Dimension figure
Packing list 6
Attention
Usage
Schematic diagram
5
6
Packing List
Gasket User's
manual
1
Expansion
bolt
4
2
Safety
valve
1
Electric
water
heater
1
Name
Quantity
4
After installation, be sure to fill the tank with water before switching on the
power. The receptacle of water heater shall be set to places beyond the water
spraying. Never plug or pull the power plug with wet hand. If the power cord
is damaged, be sure to have it replaced by appointed maintenance.
In cold area, if the water heater is idle for long period in winter, please pull
the safety valve to discharge the water to avoid freezing.
The shell of the water heater is all plastic. To clean the shell, please wipe it
gently with wet cloth and neutral detergent. Do not use petrol or other
solvent.
In case of breakdown, please contact us or the appointed maintenance to
resume normal usage as soon as possible.
See to thephysical product forthe appearance, coloror pattern.
Phenomenon
Please check
How to solve
No water output
Cold
water
output
only
Is water supply failed or water pressure too low?
Is water exit blocked? Is hot water valve opened?
Heater breakdown
Is the power switched on?
Is there temperature regulator breakdown?
Heating indicator is on
Heating indicator is off
The heating indicator keeps on
Unstable quantity and temperature
with water output
Is the tap water input pressure stable?
Is there temperature regulator breakdown?
The set water temperature is not reached yet
Check and clear
Contact the maintenance
Switch on the power
Continue heating
Contact the maintenance
Contact the maintenance
Make check
Make check
FAQ

Before Usage
Features
52
Usage
(Figure 5)
Earthing wire
Live wire
Neutral wire
Earthing wire
Live wire
Earthing wire
Live wire
Neutral wire
Earthing wire
Live wire
Attention
Power: 1200W Weight: (See to Figure 1)
Rated pressure: 0.75MPa Volume: (See to Figure 1)
Waterproof grade: antisplash( ) Tap water pressure: no less than 0.05MPa
Parameters
After installation, as there's no water inside the tank, please be sure to open
the water inlet valve and any of water exit. When the tank is filled with water
and the water exit keeps discharging water, close the valve. Check if there's
water leakage at each joint. Plug the power plug. In usage, be sure to open
the cold water valve before the hot water valve to avoid scalding .You can
t
.
Switch on the power. The heating indicator is on. The water heater starts
operating. When the water temperature reaches 60 , the heating indicator is
off. The water heater will stop heating and enters heat preservation mode.
If the water temperature drops to certain degree, the red indicator will light on
again to continue heating. It will circulate like that to guarantee the continuous
hot water supply.
urn the handle of the mixing valve upward to the left then pull the handle of
the safety valve to discharge the water
This product requires power supply with 220V , 50Hz.
The max heating temperature is 60 , not drinkable.
Reliable earthing is requested. Earthing wire shall be separated from neutral
wire strictly. T the positions of the live wire and earthing
wire can not be replaced.(See to Figure 5.)
o avoid accident,
¡ÂDear users,
Thanks for choosing Haier water heater product.
Haier products have good quality and excellent performance. To facilitate
you to use the product, please read the manual and operate accordingly.
Please retain it for future reference.
The international star service of Haier Group will always accompany you.
No matter what kind of problems you meet in usage, please contact with the
local after -sales service agent. We are at your service all the time. Thanks
again for choosing Haier Product.
The water heater you purchased may not fully comply with the figure in
the manual due to the improvement of product. We apologize for the
inconvenience occurred therefrom.
1.Safely:
Hai-quality heat proof stainless steel electric heating element, safe and
Reliable; overtemperature protection; overpressure protection of tank;
2. Durability:
Full plastic shell, elegant and durable;
Enamel tank, with more reliable quality and longer operation life.
3. Multi- usage:
Enclosed structure, capable of supplying multiple places;
Suitable for family , enterprise, catering, beauty service etc. on hot water
Supply.
4. Nice molding, space-saving
Arc appearance, appealing design, dapper and elegant.
5. Convenience:
60 thermostatic heating. It will stop heating when the temperature
Reaches 60 .
Rated voltage:220V~50Hz Dimension(See to Figure 1)

Dimension Figure
£¨Figure 1£©
34
Installation
Schematic Diagram
Front view Cutaway view Side view
a1
c1
b1
d1
A Hot water outlet
B Cold water inlet
C Mg anode rod
D Heating element
E Enamel tank
F Wall-mounting bracket
F
BB
D
E
L:Brown wire
N:Blue wire
MT:High temperature limiter
EH:Heating element
E:Yellow/green wire
ThermostatBT:
HL:Heating indicator
L
NE
BT
HL
EH
E
MT
Cold water inlet
(Figure 4) for reference in installation only
Hot water outlet
Safety valve
(Figure 3)
Connect to drain hose
(Figure 2)
Wall-mounting
plate
Expansion bolt
Model Volume Net
weight
a1 b1 c1
8L 325mm 414mm 100mm 255mm
8kg
d1
FCD-8
Remarks:the petmitted error limit of above parameters is 10%.
Be sure to have it installed by the appointed staff. It adopts wall-mounting installation.
First decide the installation location according to the usage requirement. Make two
holes in the wall with depth 70mm and 9mm by churn drill as per the indication of
installation diagram.
Fasten the wall-mounting plate on the wall tightly with two expansion bolts as per
indicated in Figure 2. Check and confirm that the bolts are not loose.
Hang the water heater vertically onto the wall by the wall-mounting plate. Confirm it
is firmly mounted. Please reserve certain space for the future maintenance during
installation.
When the power is switched on, and the water heater starts operating, there may
be some water discharged from the pressure relief hole of safety valve. It is due to
the water expansion under heating, and is normal phenomenon. The pressure
relief hole shall communicate with the air directly. Do not block it.
Fasten the drain hose to the drain thread of safety valve by twisting (see to
Figure 3). According to the need, you could truncate or elongate the hose in your
favor. Connect the other end of drain hose to the sewer to avoid polluting the
room by splashing. The drain hose connecting to the safety valve shall be kept
downward sloping in installation and in a frost-free environment.
Be sure to check and confirm that the tank is filled with water, there's no leakage
at each joint and the power supply complies with the stipulation before switching
on the power.
If the water
heater will be installed in the bathroom without sewer, we suggest you add drain
hose.
