HaiKe KJ70F-119 Quick reference guide

READ AND SAVE THESE INSTRUCTIONS
RPICTURE FOR REFERENCE ONLY
AIR PURIFIER
KJ70F-119
USE & CARE INSTRUCTIONS

01
03
04
05
07
CATALOG
SAFETY INFORMATION
PACKING LIST
PRODUCT OPERATION INSTRUCTION
FILTER REPLACEMENT
TROUBLESHOOTING GUIDE

SAFETY INFORMATION 01
This product should be used only in accordance with the specifications outlined in this manual.
Usage other than what has been specified here may result in serious injury.
When using electrical appliances, basic precautions should always be followed to reduce the risk of
fire, electric shock and injury to persons, including the following:
-This appliance can be used by children aged from 8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of experience and knowledge if they have been given
supervision or instruction concerning use of the appliance in a safe way and understand the hazards
involved.
-Children shall not play with the appliance.
-Cleaning and user maintenance shall not be made by children without supervision.
· Read all instructions before using the product.
· To avoid fire or shock hazard, plug the appliance directly into a Right electrical outlet.
· To avoid fire or shock hazard, DO NOT pull,bend, distort and damage the power cord.
· DO NOT use the product if the power cord/power plug/power outlet is damaged.
· To protect against electrical hazards, DO NOT immerse in water or other liquids. Do not use the
product near water.
· Children cannot recognize the hazards associated with the usage of electrical appliances. For this
reason, always supervise children when they are near the unit.
· DO NOT touch the power cord with wet hands.
· Always unplug the air purifier before moving it, opening the grill, changing filters, cleaning or when
ever the air purifier is not in use. Be sure to pull by the plug and not the cord.
· NEVER drop or insert any object into any openings.
· DO NOT cover cord with throw rugs, runners, or similar coverings.
· DO NOT use outdoors.
· DO NOT place anything on top of the unit.
· NEVER block the air openings, grills/outlets or place on a soft surface such as a bed or sofa, as
this could cause the unit to tip over, blocking the air intake or outtake opening.
· DO NOT use gasoline, beneze, thinner, harsh cleaners, etc, on and/or in the unit while cleaning as
they will damage the product. NEVER use alcohol or other solvents.
· WARNING - TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,DO NOT USE THIS FAN WITH
ANY SOLID-STATE SPEED CONTROL DEVICE.
WARNINGS

SAFETY INFORMATION 02
· DO NOT place the machine near heat sources such as heater,radiators, stoves and so on.
· To ensure the effect of purification, keep the air purifier around with a certain area to let wind go in and out.
Do not clean and reuse the composite filter; Please be careful when cleaning the machine. A strong corrosive
· Only soft cloth can be used to clean the surface of the machine, otherwise the machine may be damaged or
broken, and may cause sensor failure.
· It is forbidden to wipe with alcohol or organic solvent, otherwise it will damage the product or cause electric
shock, fire, etc.
· When cleaning the machine or not using this machine, please disconnect the device power supply and wipe
the dust or other matter of the power plug and power plug. Otherwise, it may cause electric shock or fire
caused by short circuit.
· This machine is not suitable for people with disabilities, perceptual impairment,mental retardation or children.
· It is prohibited to sit, lean on or climb onto the equipment to prevent the machine from being unstable and
causing injury.
· When moving, be sure to stop running and pull out the power plug.
· DO NOT attempt to repair or adjust any electrical or mechanical functions on this unit.
· Doing so will void your warranty. The inside of the unit contains no user serviceable parts. All servicing should
be performed by qualified personnel only.
· If the equipment produces odors at running time, please stop using the equipment and contact after-sales to
replace the odor net.
· The cord, wires and/or cables supplied with this product contain chemicals, including lead or lead compounds,
know to the state of California to cause cancer and birth defects or other reproductive harm. Wash hands
after using.
Warm Reminder
FOR USAGE
FOR USAGE
·DO NOT use the machine without filter in.
· Please install the equipment in a dry environment.
· Do not install the equipment in a flammable environment.
· Please take out the polybag outside before installing the machine.

03
PACKING LIST
Perspective View Bottom View
PRODUCT STRUCTURE
Main Unit User Manual
Control Panel
Air Outlet
Main Unit
Bottom Cover
Combination Filter
(including Pre-filter+ HEPA filter
Charcoal filter )
Bottom Cover
Combination
(Filter inside included)
READ AND SAVE THESE INSTRUCTIONS
RPICTURE FOR REFERENCE ONLY
AIR PURIFIER
KJ70F-119
USE & CARE INSTRUCTIONS

04
CONTROL PANEL
On power on state, the device enters in standby mode when ON/OFF indicator light turns red
CHILD LOCK
ON/OFF
SPEED
SLEEP Change Filter Indicator
(Filter Life Reset)
Press “ON/OFF” button to turn on/off the device.
a. The fan speeds switches from High to Medium to Low to Medium by each touch. And the indicator
light turns green.
b. Medium speed is default set when turns on the unit.
c. “ ” indicates fan speed. It changes via fan speed.
（The indicator of running function turns green when power is on）
Press “SLEEP” button to turn on/off sleep mode.
a. On sleep mode, only “SLEEP” indication button turns green.
b. Press any button to turn down sleep mode.
a. On Child lock state, press the button for 3 seconds to turn down the child lock mode, the
indicator light turns white.
b. All the other buttons are not working when child lock is on.
On power on state, press “CHILD LOCK”for 3 seconds to turn on child lock
mode, the indicator light turns green.
Please replace the filter when the filter indicator”FILTER”light flashes and
make sounds. (please refer to the instruction for how to replace the filter)
a. Press “FILTER”button fo r 3 seconds to reset the filter life
Press the “SPEED” button to adjust the fan speed when power is on
PRODUCT OPERATION INSTRUCTION

05
FILTER REPLACEMENT
1. Turn it off and unplug the unit
3. Please take out the combination filter and pack
it into polybag to avoid dust falling indoor.
2. Remove the bottom cover
NOTICE
Please pull out the power lord to cut off
the power supply. The device is still under
stand by mode when touching
“ON/OFF” button only.
Please rotate the bottom cover according
to the arrow instruction way to remove it.
NOTICE
a. To ensure the purifying efficiency, please
read the instruction of filter replacement.
b. Please do not reuse the filter which has
reached its working life. the instruction
of filter replacement.

06
FILTER REPLACEMENT
5. When the unit is powered on, press“ON/OFF”button to turn on the unit. Then
press the“FILTER”button for 3 seconds to reset the filter time.
NOTICE
The working life of filter may differ
from the different using environmnt.
It can be simply judged by smell or
sound generated by the working unit.
4. (Method 1) Put a towel or other soft protective pad on the desktop, turn the main
unit upside down, and place the filter element on the bottom. Then install the bottom
cover, and rotate it according to the arrow way and lock it well . After the installation ,
flip the main unit and the top faces up.
(Method 2) Adjust the direction of the new filter, install the filter well, put the main
unit and rotate the bottom cover according to the arrow way at bottom until it is locked.

07
TROUBLESHOOTING GUIDE
Machine can not start
A. Unplug power plug.
B. Machine rear cover not in position.
A . Reconnect power plug.
B. Re-install the rear
cover in position.
A. It is recommended that
the room air be changed.
B. Replace with the all new
filter.
A. Install the filter correctly.
B. Place the unit at least a foot
away from the obstacles.
C. Replace for new
combination filter.
A.Contact after-sales center.
B.Clean other matters.
Press 3 second to turn off
the LOCK mode.
Adjust the filter to right
directionand install the
filter to the bottom slot.
A. More pollutants indoor such
as more smoking.
B. Filter is polluted severely.
A. Whether the installation is not tight.
B. Other matter stored in the machine.
LOCK mode is worked.
Filter is installed opposite.
A. Filter is not installed into the
machine.
B. Machine is placed in narrow
space or space with obstacles
nearby which may have negative
impact on the purification effect.
C. Filter is too dirty.
Odor in the outlet
None obvious dust
removal effect,none
air quality improvement
Running noise loud
Main buttons not work
Filter cannot be installed
After all the checks above, troubleshooting still existed, please contact our service
center or contact technical service center. Do not attempt to disassemble and
maintain themaintenance by yourself, to avoid any danger and damages to the
machine.
Phenomenon Possible reason Solution
If malfunction occurs in the air purifier, please check as blow phenomenon showed
before repair
