Operating Instructions
electronic solenoid valve control type IFC 30
Driftinstruktion
Bedrijfshandleiding
Instruções de serviço
Instrucciones de servicio
Istruzioni per l`ésercizio
Instruction de service
Betriebsanleitung
Operating Instructions
Electronic
Solenoid Valve Control
Type IFC 30

HAINKE Staubfilter GmbH
fon 04408 / 8077-0
fax
04408 / 8077-10
PO box 12 48
An der Imbäke 7
email
[e-mail]
27795 Hude
27798 Hude
web
www.hainke.de
Operating Instructions
electronic solenoid valve control type IFC 30
operating instructions
Ifc30-ba_eng
Version: 02/2015
Date: 26.02.2015
Page: 1
Table of Contents
1Safety Precautions and Warnings 2
1.1 Designation electrical apparatus for explosion-hazardous areas 3
1.2 Operating of the Unit in the add-on housing 4
1.3 Remarks for special conditions for safe use 4
2Use as agreed 4
3Technical Data 5
4Installation 7
4.1 Safety notes for the installation general Fehler! Textmarke nicht definiert.
5Electrical Connection 10
6Commissioning 12
7Control and Signal Functions 15
7.1 Remote Control Input R 15
7.2 Operational Message 16
7.3 Pressure Switch Input P 16
7.4 Post Cleaning 17
8Fault Messages 18
8.1 Causes of fault and elimination 18

HAINKE Staubfilter GmbH
fon 04408 / 8077-0
fax
04408 / 8077-10
PO box 12 48
An der Imbäke 7
email
[e-mail]
27795 Hude
27798 Hude
web
www.hainke.de
Operating Instructions
electronic solenoid valve control type IFC 30
operating instructions
Ifc30-ba_eng
Version: 02/2015
Date: 26.02.2015
Page: 2
1 Safety Precautions and Warnings
IMPORTANT NOTICE!
Non-
observance of the safety instructions can result in severe personal injury or
property damage.
This equipment may be installed, connected, commissioned, operated and maintained by
qualified and authorised personnel only, under strict observance of these operating
instructions, any relevant standards and legal requirements.
Take particular note of the general and regional installation and safety regulations regarding
work on high voltage installations (e.g. VDE), as well as the relevant regulations regarding
the correct use of tools and personal protective gear.
Hazardous voltages are present in this electrical equipment during operation.

HAINKE Staubfilter GmbH
fon 04408 / 8077-0
fax
04408 / 8077-10
PO box 12 48
An der Imbäke 7
email
[e-mail]
27795 Hude
27798 Hude
web
www.hainke.de
Operating Instructions
electronic solenoid valve control type IFC 30
operating instructions
Ifc30-ba_eng
Version: 02/2015
Date: 26.02.2015
Page: 3
1.1 Designation electrical apparatus for explosion-hazardous areas
Designation according
to Directive 94/9/EC: II 3D
Sign Signification
II Equipment Group II
3 Equipment Category 3
D For explosive mixtures of air and combustible dust
Particular addition to
EN 60079-0 Ex tc IIIB T80°C Dc X IP65 Ta:-5°C … +40°C
Ex Ex-protection at European standard
tc Protection class: protection by enclosure, use in category 3D
IIIB Dust-group: non-conductive dust
T80°C Maximum surface temperature
Dc EPL= Equipment Protection Level: Dust (II 3D)
X Remarks for special conditions for safe use
IP 65 Ingress protection IP 65
Ta: -5°C … +40°C Permissible operating temperature range
Areas of application
Equipment Category Explosive dust-air mixtures (D)
Category 1 Zone 20, 21 or 22
Category 2 Zone 21 or 22
Category 3 Zone 22 not conductive dust
Equipment Group II
Category 3
Electrical apparatus for
use in the presence of
combustible dust
Equipments, they are constructively arranged to operate in agreement with
the characteristic quantities given by the manufacturer and ensure a normal
measure of safety.
Equipments of this category are intended for the use in areas where you
have not to calculate with an explosive atmosphere of dust whirled up. If an
explosive atmosphere appears nevertheless, in all probability it will be only
rare and during a short time period.

HAINKE Staubfilter GmbH
fon 04408 / 8077-0
fax
04408 / 8077-10
PO box 12 48
An der Imbäke 7
email
[e-mail]
27795 Hude
27798 Hude
web
www.hainke.de
Operating Instructions
electronic solenoid valve control type IFC 30
operating instructions
Ifc30-ba_eng
Version: 02/2015
Date: 26.02.2015
Page: 4
1.2 Operating of the Unit in the add-on housing
ATTENTION!
The control may be used in normal operation only with closed lid.
For commissioning and maintenance work with power on you must make sure that no
explosive atmosphere of dust-air mixture is present or could occur.
Otherwise the lid may be opened only if the power is switched off.
At least the ingress protection IP54 must be guaranteed.
1.3 Remarks for special conditions for safe use
in explosion-hazardous areas zone 22
for the control IFC 30-E (add-on housing polycarbonate)
ATTENTION!
1. Permissible operating temperature range Ta: -10°C to +40°C.
2. The control has to be installed within the visual range and must be protected from any
mechanical damage.
3. The control must be protected from
ultraviolet light (daylight or ultraviolet light from
lamps) respectively be mounted in a protected place.
4. Avoid dust deposits on the unit.
5. To avoid electrostatic charging clean the unit with a damp cloth only.
Rubbing with
nonconductive materials must be strictly avoided.
2 Use as agreed
NOTE!
If used incorrectly application-related dangers may arise.
The control was developed for the cyclic dedusting of filterelements with compressed air
impulses.
Up to 24
solenoid valves can be controlled in rotation, with adjustable impulse and delay
timing periods.
A 24VDC-Remote control input is available for an external start.
A potential free relay contact is availabe to give an operatinal message to a host system.
The control must not be operated outside of its electrical, thermal and mechanical
performance limits.

HAINKE Staubfilter GmbH
fon 04408 / 8077-0
fax
04408 / 8077-10
PO box 12 48
An der Imbäke 7
email
[e-mail]
27795 Hude
27798 Hude
web
www.hainke.de
Operating Instructions
electronic solenoid valve control type IFC 30
operating instructions
Ifc30-ba_eng
Version: 02/2015
Date: 26.02.2015
Page: 5
3 Technical Data
Supply Voltage
(see type plate) 220 to 240VAC 50/60Hz 110 to 120VAC 50/60Hz 24VDC
voltage tolerance +/- 5% 24-32VDC
switchable with mains switch
fuse 315mA medium slow 630mA medium slow 1,6A medium slow
quiescent current consumption typical 40mA typical 80mA typical 60mA
Type IFC 30 E
in add-on housing polycarbonate
Outputs 3-30 solenoid valve outputs 24VDC,
output power max. 24W/1A,
activated manually by means of a multi-contact switch.
All outputs are suppressed with a recovery diode.
Impulse period Adjustable from 60 to 600 ms, indicated by red LED
Delay period Adjustable from 6 to 60 s, indicated by green LED
Post cleaning Selectable from 0 to 5 cycles,
delay period is automatically reduced
Indication by LEDs Red: wire breakage, lack of air
Green: operational signal (active)
Signal output Operational signal, potential-free relay contact, normally open,
contact load max. I = 0,5A, U = 230VAC
Control inputs 24VDC R: Remote control input, yellow LED,
P: Input for pressure switch, yellow LED,
current consumption approx. 15mA
Supply voltage for
external triggers 24VDC, 50mA max.
Housing material Polycarbonate
Colour RAL 7032 (pebble gray), transparent lid
Installation Wall installation

HAINKE Staubfilter GmbH
fon 04408 / 8077-0
fax
04408 / 8077-10
PO box 12 48
An der Imbäke 7
email
[e-mail]
27795 Hude
27798 Hude
web
www.hainke.de
Operating Instructions
electronic solenoid valve control type IFC 30
operating instructions
Ifc30-ba_eng
Version: 02/2015
Date: 26.02.2015
Page: 6
Type IFC 30 E
in add-on housing polycarbonate
Ingress protection IP65 to EN 60529
Dimensions (W x H x D) 375 x 250 x 150 mm
Weight 5,6 kg
Cable entries 4 x M16, 4 x M20,
Clamp range of
Cable entries M16 for 4,0 to 8,0 mm M20 for 6,5 to 12,0 mm or 10,0 to 14mm
Connection cross
section 0,2 to 2,5 mm²
unit marking
II 3D T
Ex tc IIIB T80°C Dc X
IP65
Ta: -5°C …+40°C
Maximum surface
temperature Tof the
housing (Category 3D)
at 40°C ambient
temperature
80°C
Permissible operating
temperature explosion-hazardous area zone 22: Ta: - 5 °C to + 40°C
Not explosion-hazardous area:
- 20 °C to + 40°C
Conformity •EU- Directive 2006/95/EG
(EN 60204-1)
•EU- Directive 2004/108/EG
(EN 61000-6-1, EN 61000-6-2, EN 55014-1)
•Ex- Directive 94/9/EG
(EN 60079-0, EN60079-31)

HAINKE Staubfilter GmbH
fon 04408 / 8077-0
fax
04408 / 8077-10
PO box 12 48
An der Imbäke 7
email
[e-mail]
27795 Hude
27798 Hude
web
www.hainke.de
Operating Instructions
electronic solenoid valve control type IFC 30
operating instructions
Ifc30-ba_eng
Version: 02/2015
Date: 26.02.2015
Page: 7
4 Installation
ATTENTION!
Observe relevant regulations!
For use in Ex-Area you have to check whether the unit is suitable for the application.
(refer to type plate and technical data)
In general The control is suitable for the installation in an industry plant.
To be used in explosion-hazardous area (Ex-Area) Zone 22 not conductive dust and in not
Ex-Area.
After removal the lid the mounting holes are accessible.
The control is to be installed in a vibration-free location.
Add-on
housing
polyester The polyester add-on housing can be installed indoors and outdoors under hard conditions.
The mechanical resistance is high. Polyester is absolutely corrosion-proof and high-resistant
against aggressive chemical mediums.
It has to be installed within the visual range and must be protected from a mechanical
damage.
For the installation outdoors the housing must be protect for weather influences with a roof or
similar.
For use in explosion-hazardous area the remarks in chapter 1.3 must be observe.
Refer to drawing 4.1 for mounting dimensions

HAINKE Staubfilter GmbH
fon 04408 / 8077-0
fax
04408 / 8077-10
PO box 12 48
An der Imbäke 7
email
[e-mail]
27795 Hude
27798 Hude
web
www.hainke.de
Operating Instructions
electronic solenoid valve control type IFC 30
operating instructions
Ifc30-ba_eng
Version: 02/2015
Date: 26.02.2015
Page: 8
4.1 Safety notes for the installation
IMPORTANT NOTICE!
Install according to the manufacturer´s instructions and the respective
national regulations
and provisions as well as the relevant installation regulations.
Connect and carry the ground wire.
4.2 Safety notes for the installation of the add-on housing
IMPORTANT NOTICE!
The unit must be installed such that the degree of protection IP 65 to EN 60529 is
guaranteed (state of delivery).
Therefore it is important
to fix all screws of the lid,
to mount the cable entries competently,
to close unnecessary cable entries with stoppers,
to use in the ex-area only cable glands and stoppers approved for this area.
The requirements of the EN 60079-14 must be met.
In addition, only the connection of permanently installed cable and wire is allowed. A
corresponding strain relief must be ensured.

HAINKE Staubfilter GmbH
fon 04408 / 8077-0
fax
04408 / 8077-10
PO box 12 48
An der Imbäke 7
email
[e-mail]
27795 Hude
27798 Hude
web
www.hainke.de
Operating Instructions
electronic solenoid valve control type IFC 30
operating instructions
Ifc30-ba_eng
Version: 02/2015
Date: 26.02.2015
Page: 9
cable entries from below
mounting dimensions
Illustration 4.1: Add on housing polycarbonate

HAINKE Staubfilter GmbH
fon 04408 / 8077-0
fax
04408 / 8077-10
PO box 12 48
An der Imbäke 7
email
[e-mail]
27795 Hude
27798 Hude
web
www.hainke.de
Operating Instructions
electronic solenoid valve control type IFC 30
operating instructions
Ifc30-ba_eng
Version: 02/2015
Date: 26.02.2015
Page: 10
5 Electrical Connection
IMPORTANT NOTICE!
The unit may only be connected to the supply voltage as indicated on the type plate.
The connection of 115 VAC or 230 VAC to a control for 24 VDC
will lead to destruction of
the entire control unit.
General The control is to be connected according to drawing 5.1.
The values given in the technical specification are to be observed.
(refer to Section 3).
Supply Voltage Supply voltage is to be connected to contact strip (1). L and N or L+ and M.
(refer to drawing 6.1)
Solenoid Valves
The solenoid valves are to be connected to contacts 1 to 30 on contact strip
(2). Paid attention on a uniform distribution of the solenoid valves to the 3
output groups.
For example:
There are to connect 8 solenoid vales per output group if you have 24
solenoid vales complete.
Valve 1-8 to contact 1-8
Valve 9-16 to contact 11-18
Valve 17-24 to contact 21-28
The plus poles of the solenoid valves must be bound together and connected
to contacts +.
Connect the ground wire to PE on contact strip (1). It is also possible to
connect the ground wire on the mounting plate.
The power of the conntected solenoid valves may not be exceeded the
maximum output power.
Operating Signal
Output The operating signal output is available at contacts 31 and 32 on contact strip
(3). It´s a potential-free normally open relay contact
Refer to Section 7.2.
Remote control Input
(R) Contact 34 on contact strip (3) is for connection of the remote control signal.
Refer also to Section 7.1.
Pressure Switch
Input (P) Contact 33 on contact strip (3) is for connection of the pressure switch signal
for pneumatic monitoring.
Refer also to Section 7.3.
Supply of power to the triggers is available from contact 35, plus 24VDC and
contact 36, 0V potential.

HAINKE Staubfilter GmbH
fon 04408 / 8077-0
fax
04408 / 8077-10
PO box 12 48
An der Imbäke 7
email
[e-mail]
27795 Hude
27798 Hude
web
www.hainke.de
Operating Instructions
electronic solenoid valve control type IFC 30
operating instructions
Ifc30-ba_eng
Version: 02/2015
Date: 26.02.2015
Page: 11
solenoid valve control IFC 30
Drawing 5.1: Electrical Connection

HAINKE Staubfilter GmbH
fon 04408 / 8077-0
fax
04408 / 8077-10
PO box 12 48
An der Imbäke 7
email
[e-mail]
27795 Hude
27798 Hude
web
www.hainke.de
Operating Instructions
electronic solenoid valve control type IFC 30
operating instructions
Ifc30-ba_eng
Version: 02/2015
Date: 26.02.2015
Page: 12
6 Commissioning
ATTENTION!
For commissioning and maintenance work you must make sure that no explosive
atmosphere of dust-air mixture is present or could occur.
Otherwise the lid may be opened only if the power is switched off.
The control must not be operated outside of its electrical, thermal and mechanical
performance limits.
The following points are to be carried out in the sequence given for
initial operation: (Refer to drawing 6.1)
•Set the ON/OFF switch (6) to OFF
•Check with the type plate which supply voltage is suitable for the unit on
hand. 110-120VAC and 220-240VAC or 24VDC
•Set the mains voltage switch (4) to the correct setting for the available
supply voltage (110-120V or 220-240VAC)
•Ensure that the correct fuse is inserted. Refer to the technical data.
•Pre-select the outputs per group to be controlled by setting multi-position
switch (7), as desired
•Set the potentiometers delay and impulse time (10)(11) according to the
specifications of the filter manufacturers.
•Select the operating modi and monitoring functions required by means of
the DIP switches (19):
DIP switch 1 ON start the controller either via remote control
or pressure difference switch (refer to
Section 7.1).
DIP switch 1 OFF Controller direct start at connecting supply
voltage
DIP switch 2 ON Nominal operating pressure test (refer to
Section 7.3). Pressure switch on storage
column must be in place.
DIP switch 2 OFF Nominal operating pressure is not tested.
DIP switch 3 no function

HAINKE Staubfilter GmbH
fon 04408 / 8077-0
fax
04408 / 8077-10
PO box 12 48
An der Imbäke 7
email
[e-mail]
27795 Hude
27798 Hude
web
www.hainke.de
Operating Instructions
electronic solenoid valve control type IFC 30
operating instructions
Ifc30-ba_eng
Version: 02/2015
Date: 26.02.2015
Page: 13
•Pre-select the number of post cleaning cycles required via multi-position
switch (12) (refer to Section 7.4). Post cleaning is only available when the
remote control function, DIP switch 3 ON is used.
•Re-check that the controller is correctly connected in accordance with the
connection diagramme, Drawing 5.1.
•Connect the supply voltage according to the type plate and activate the
controller by using the ON/OFF switch (6).
Signalling The following LED's will come on after the controller has been
switched on :
Active (green) (17) if remote control function is active,
start via 1 signal on input "R"(refer
to Section 7.1)
next output (green) (8)
operational message
(green) (20) only if controller is ACTIVE
signal "P" (yellow)
pessure switch input (21) dependents on switch status of connected trigger
signal "R" (yellow)
remote control (22) dependents on switch status of connected trigger
output group 1 (yellow) (23)
Start with remote
control The dedusting process commences as soon as 1 signal is detected at
input R. The connected solenoid vales will be controlled with the selected
impuls-delay periode. 0 signal at input R stops the valve control.
If post cleaning cycles are pre-selected, the valve control stops after it has
finished the post cleaning. The control continues with a renewed start.
remote control OFF The dedusting commences as soon as the supply voltage is connected. The
connected solenoid vales will be controlled with the selected impuls-delay
periode.
•Check that the solenoid valves are working correctly
At a fault-free drive the operational message contact remains closed for
the complete run. LED (20) lights without interruption.
•After completing the commissioning:
Screw the lid on again and check the cable entries. Not needed cable
entries must be closed with stoppers.

HAINKE Staubfilter GmbH
fon 04408 / 8077-0
fax
04408 / 8077-10
PO box 12 48
An der Imbäke 7
email
[e-mail]
27795 Hude
27798 Hude
web
www.hainke.de
Operating Instructions
electronic solenoid valve control type IFC 30
operating instructions
Ifc30-ba_eng
Version: 02/2015
Date: 26.02.2015
Page: 14
Drawing 6.1: Front panel overview

HAINKE Staubfilter GmbH
fon 04408 / 8077-0
fax
04408 / 8077-10
PO box 12 48
An der Imbäke 7
email
[e-mail]
27795 Hude
27798 Hude
web
www.hainke.de
Operating Instructions
electronic solenoid valve control type IFC 30
operating instructions
Ifc30-ba_eng
Version: 02/2015
Date: 26.02.2015
Page: 15
7 Control and Signal Functions
7.1 Remote Control Input R
It is possible to control the controller remotely via input R on contact strip (3).
The following switch types may be connected to input R :
1. potential-free contact (switch or relay);
2. switch with electronic output PNP;
3. 12 to 30 VDC against 0V.
The input is reverse polarity safe.
The remote control function is activated by setting DIP switch 1 (19) to ON
and de-activated when that switch is set to OFF. The DIP switch position may
be changed whilst the controller is in operation.
If the remote control function is activated, the dedusting process commences
as soon as 1 signal is detected at input R. LED (22) lights up.
If the remote control function is not active, then dedusting commences as
soon as the supply voltage is connected.
Input R may alternatively be used for connection of a pressure difference
switch. This starts the dedusting process in dependence to the filter
resistance.
If the pressure difference switch is to be connected to input R as well as the
remote control, then the remote control start signal must be wired in series
with the pressure difference switch contact.
Illustration 7.1: Possible settings of DIP switch 1

HAINKE Staubfilter GmbH
fon 04408 / 8077-0
fax
04408 / 8077-10
PO box 12 48
An der Imbäke 7
email
[e-mail]
27795 Hude
27798 Hude
web
www.hainke.de
Operating Instructions
electronic solenoid valve control type IFC 30
operating instructions
Ifc30-ba_eng
Version: 02/2015
Date: 26.02.2015
Page: 16
7.2 Operational Message
A potential-free normally open relay contact is available on contact strip (3) for
indicating the operational status.
The operating relay only closes if the controller is switched to ACTIVE. If a
fault occurs, such as overload or wire break, the operating relay will open.
The controller will continue operation without interruption.
The relay will close again as soon as no further faults are detected. The green
LED (20), above contact strip (3) will light up.
7.3 Pressure Switch Input P
Nominal Operating
Pressure Test The nominal operating pressure in the pressure storage column can be
monitored by connecting a pressure sensitive switch to input "P", contact strip
(3).
The following switch types may be connected to input "P" :
1. Potential free contact (normal pressure switch);
2. Switch with electronic output PNP;
3. Direct current between 12 and 30VDC, against 0V.
The input is reverse polarity proof.
The nominal operating pressure test function is activated by setting DIP
switch 2 (19) to ON, it is de-activated by setting this same DIP switch to the
OFF position. The DIP switch position may be changed whilst the controller is
in operation.
The nominal operating pressure test occurs at the end of the delay.
If a signal is not detected at input "P", the LED "lack of air" (14) will light up.
This indicator goes off if a 1 signal is detected at input "P" when the test is
repeated at the end of the following delay.
If a 1 signal is detected at input "P", yellow LED (21) will light up.
Illustration 7.2: DIP switch 2 settings

HAINKE Staubfilter GmbH
fon 04408 / 8077-0
fax
04408 / 8077-10
PO box 12 48
An der Imbäke 7
email
[e-mail]
27795 Hude
27798 Hude
web
www.hainke.de
Operating Instructions
electronic solenoid valve control type IFC 30
operating instructions
Ifc30-ba_eng
Version: 02/2015
Date: 26.02.2015
Page: 17
7.4 Post Cleaning
The "post-cleaning" selector switch (12) may be set to values between 0 and
5 and enables post cleaning of the filter after the controller has been switched
off via input "R" with reduced delay period.
The number of cleaning cycles can be set to between 0 and 5 via the selector
switch. If this switch is set to "0", there will be no post cleaning. If the
controller is switched OFF, it will come to a standstill immediately following the
end of any dedusting impulse (operating mode STANDBY").
If the selector switch is set to values between 1 and 5, the controller will
switch over to post cleaning. Any sequence which has already commenced
will be further processed using the shortened delay period. Post cleaning itself
commences with the beginning of the next cycle.

HAINKE Staubfilter GmbH
fon 04408 / 8077-0
fax
04408 / 8077-10
PO box 12 48
An der Imbäke 7
email
[e-mail]
27795 Hude
27798 Hude
web
www.hainke.de
Operating Instructions
electronic solenoid valve control type IFC 30
operating instructions
Ifc30-ba_eng
Version: 02/2015
Date: 26.02.2015
Page: 18
8 Fault Messages
The fault indication “wire break” is assigned to the disturbed output. This
indicator will go off when the next non-faulty impulse is received.
For example:
The message “wire break” occurs after the output 5 was controlled. After
controlling the output 6 the LED wire break goes off again.
From this results that the wire break fault was causes from the solenoid valve 5.
8.1 Causes of fault and elimination
Messages Indication Causes of Fault Elemination
wire break LED red
This
indicator
will go off
when the
next non-
faulty
impulse is
received
No output load during the
control impulse or short-
circuited valve output.
•Check the adjusting of the multi-
position switch (7). The number
of connected valves must agree
with the adjusting of the multi-
position switch
•Check the valve connection
•Check the valve
lack of air LED red
The pressure switch input P
indicates no signal at the end
of the delay time.
•Check the compressed air and
the pressure switch
•If no monitoring of the
compressed air shall be
carried out, switch the DIP
switches 2 (19) to the OFF
position.

HAINKE Staubfilter GmbH
fon 04408 / 8077-0
fax
04408 / 8077-10
PO box 12 48
An der Imbäke 7
email
[e-mail]
27795 Hude
27798 Hude
web
www.hainke.de
EC Declaration of Conformity
electronic solenoid valve control type IFC 30
Hude, 26.02.2015 (R. Hainke – General Manager)
Herewith we declare that the electronic solenoid valve control
IFC 30 in add-on housing polycarbonate IP65
comply with following relevant regulations:
•EC directive 2004/108/EG
•(on electromagnetic compatibility)
•EC low voltage directive 2006/95/EG
•EC directive 94/9/EG
•(Equipment and protective systems intended for use in potentially explosive atmospheres)
Applied standards:
•EN 61000-6-1
•EN 61000-6-2
•EN 55014-1
•EN 60204-1
•EN 60079-0
•EN 60079-31
