Halio SR300 Operation manual

Wireless Range Extender
INSTALLATION & USER GUIDE
INTRODUCTION
Halio Range Extender makes it easy to expand coverage of
the Halio wireless mesh network and ensure reliable
communication between Halio devices. It provides flexible
options for placement supplying power. Once joined to the
Halio wireless network, the Range Extender automatically
repeats wireless messages between Halio devices.
INSTALLATION WARNINGS
•The Range Extender is not weather proof and should not
be located outside or where temperature changes and
humidity may allow condensation in the enclosure.
•To be installed and used in accordance with national and
local electrical codes and regulations.
•Use only Halio approved power supplies (12 – 48VDC).
•Ensure wiring connections are made only when power is
off.
•Installation and maintenance of this unit should be done
only by a certified Halio installer.
INSTALL WIRELESS RANGE EXTENDER
To install and configure the Range Extender:
1. Select the best installation location in between the Halio
System Gateway and other Halio client devices that need
to communicate with the Gateway.
2. Wireless Range Extender is designed for optimal
performance when ceiling mounted but can also be
installed on a wall.
3. Route the power supply wires through a hole in the
ceiling or wall to the back of the Range Extender
4. Rotate the top cover slightly to the left and remove it to
access the mounting holes.
5. Insert the positive and negative wires from the DC power
supply into the + and – wiring terminals on the back of
the Range Extender
6. Use screws and anchors to secure Range Extender to the
ceiling or wall.
7. Re-attach cover plate and rotate to the right until secure.
8. Plug in the power supply to power on the Range
Extender. LED’s will blink to confirm.
COMMISSION WIRELESS RANGE EXTENDER
Wireless Range Extender must be joined to the Halio wireless
mesh network to communicate with other Halio devices.
To commission the Range Extender:
1. Set the Halio System Gateway into join mode by pressing
the network button on the right side of the enclosure.
2. Press the network button on the left side of the Wireless
Range Extender to start the joining process
3. The Network LED will begin to blink orange while
searching for a Halio wireless network to join
4. Once a network is found, the LED will change to green to
indicate it has successfully joined. It will blink red briefly
to indicate if joining the network failed.
USING WIRELESS RANGE EXTENDER
Once joined to the Halio wireless mesh network, the Wireless
Range Extender will operate without user interaction,
repeating and intelligently routing messages sent between
Halio client devices and the Halio System Gateway.
Mounting Screw Holes
Network Join
Button & LED
KEY: XXXXXX
MAC : XXXXXXXXXXXX
SN : XXXXXXXXX
FCC ID: 2AJ XY-SR 300
IC : 22717-SR 300
Ma d e in XXXXXXXXX
210-00023

HUG-SR300 190410 v0.2
TROUBLESHOOTING
If Halio Wireless Range Extender becomes unresponsive with
no LED activity, it has likely lost power.
Check Power
To check power:
1. Check the power supply has not become unplugged or is
not somehow switched off.
2. Check the power wiring has not somehow become
disconnected at the wiring terminals.
3. Use a multi-meter to confirm the voltage being supplied
to the Wireless Range Extender (12 – 48VDC).
If LEDs blink but commands appear unresponsive, it may be
useful to reboot the device using the reset button.
Device Reboot
To reboot the Tint Selector:
1. Remove the cover plate to access the reset button
2. Click the Reset button using a pen or paperclip.
3. LEDs will blink as the device restarts and rejoins the
wireless mesh network.
REGULATORY COMPLIANCE
FCC ID No. 2AJXY-SR300
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
The transmitter must not be co-located or operated in conjunction with any
other antenna or transmitter. This equipment complies with the FCC RF
radiation exposure limits set forth for an uncontrolled environment. This
equipment should be installed and operated with a minimum distance of
20cm between the radiator and any part of your body.
Note that changes or modifications not expressly approved by Kinestral
Technologies could void the user's authority to operate the equipment.
IC No. 22717-SR300
This device complies with Industry Canada’s license-exempt RSSs. Operation
is subject to the following two conditions:
(1) This device may not cause interference; and
(2) This device must accept any interference, including interference that may
cause undesired operation of the device.
The transmitter must not be co-located or operated in conjunction with any
other antenna or transmitter. This equipment complies radiation exposure
limits set forth for an uncontrolled environment. This equipment should be
installed and operated with a minimum distance of 20cm between the
radiator and any part of your body.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux
appareils radio exempts de licence. L'exploitation est autorisée aux deux
conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2)
l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi,
même si le brouillage est susceptible d'en compromettre le fonctionnement.
L'émetteur ne doit pas être co-localisé ou utilisé en conjonction avec une
autre antenne ou un autre émetteur. Cet équipement est conforme aux
limites d'exposition aux radiations définies pour un environnement non
contrôlé. Cet équipement doit être installé et utilisé à une distance minimale
de 20 cm entre le radiateur et toute partie de votre corps.
