1.0 Introduction
The ECHO family is a series of extension products designed to allow a single
HDMI 2.0 source to display remotely at up to eight different locations, using
HDBaseT technology. HDMI resolutions up to 4K UHD (4K@60 4:4:4) can be
extended up to 70m, while resolutions up to 1080p can be extended 100m over
a single CAT5e or CAT6 cable. The ECHO family supports HDCP 2.2 and 1.4
content protection, as well as HDR10 high dynamic range video.
In addition to HDMI extension, the ECHO family also extends RS-232 serial data,
and bi-directional IR for control of remote devices. All senders include a local
HDMI output, EDID routing control, de-embedded analog audio, and Power over
Cable (PoC) to power remote receivers. The ECHO-4S and ECHO-8S have built-
in HDMI splitters to extend a single video to four and eight receivers
respectively and have additional features including RS-232 and IR loop output
for daisy-chaining Senders, and digital TOSLINK audio de-embedding.
The ECHO-RX2 receiver has a built-in HDMI splitter for connection to a
secondary display, RS-232 and bi-directional IR for control, and de-embedded
analog audio output. When used with an ECHO-1S, install the power supply at
either sender or receiver – whichever is more convenient.
Typical Connection Diagram – ECHO-4S and ECHO-RX2

ECHO Family
4
© Copyright 2020 Hall Research, LLC
.
Features
 18Gbps bandwidth HDBaseT extender
 Extend UHD 4K@60Hz 4:4:4 up to 70m & 1080p up to 100m
 HDCP 2.2, HDR10, 3D support
 RS-232 pass-through & control
 Bi-directional IR (Wide Band)
 HDMI loop output on the sender
 Dual HDMI output on the receiver
 Audio extraction on the sender and receiver
 Daisy-chain support of senders up to eight levels deep
 EDID management
 Power over Cable (only sender side needs power supply)
 Locking power supply connector
2.0 Package Contents
Model ECHO-1S
(x1) ECHO-1S sender (x1) 3-pin Phoenix terminal
(x1) IR TX cable (x1) 24 V DC universal adapter
(x1) IR RX cable (x1) User’s manual card
Model ECHO-4S
(x1) ECHO-4S sender (x2) 3-pin Phoenix terminal
(x1) IR TX cable (x1) 24 V DC universal adapter
(x1) IR RX cable (x2) Rack mount ears
(x2) 3.5 mm cable (IR daisy chain) (x1) User’s manual card
Model ECHO-8S
(x1) ECHO-8S sender (x2) 3-pin Phoenix Terminal
(x1) IR TX cable (x2) 24 V DC universal adapter
(x1) IR RX cable (x2) Rack mount ears
(x2) 3.5 mm cable (IR daisy chain) (x1) User’s manual card
Model ECHO-RX2
(x1) ECHO-RX2 receiver (x1) 3-pin Phoenix terminal
(x1) IR TX cable (x1) User’s manual card
(x1) IR RX cable
3.0 Setup

HDMI 2.0 HDBaseT Extenders
© Copyright 2020 Hall Research, LLC
.
5
Installation
 Connect the HDMI source (Blu-ray, PC, media player, etc.) to the HDMI IN
port on the sender.
 Optionally, connect the HDMI OUT to a local display.
 Connect the HDBaseT output(s) of the sender to HDBaseT Input(s) of the
receiver(s). Ensure the cables do not exceed 70m for 4K or 100m for
1080p video.
 Connect the HDMI OUT1 and/or OUT2 of the receiver to a compatible
display.
 Connect power to the sender. (For ECHO-8S, use 24 V 2 A supply for main
power, and 24 V 4 A supply for PoC power.)
 Optionally, connect Audio Out at the sender or receiver to an external
audio amplifier or sound reinforcement system.
 Optionally, connect the RS-232 or IR detectors and emitters to allow for
remote control of the displays or other compatible peripherals. See
Section 5 below for more information about RS-232 commands.
EDID Routing and Emulation
Each ECHO sender has a three-position switch to control which EDID is
presented to the video source: Local, Remote, or EMUL (emulate).
 Local: Use the EDID of the display attached to the local HDMI OUT port.
 Remote: Use the EDID of the display attached to the Receiver. For
ECHO-4S and 8S, the Sender will check the first HDBaseT Output, then
the second, and so on. If there are no displays attached, it will use an
emulated EDID that is stored in the ECHO-RX2 Receiver.
 EMUL: Use an emulated EDID stored in the Sender.
NOTE When using the ECHO-1S with ECHO-RX2, install the power
supply at either the sender or receiver, whichever is more
convenient. When using the ECHO-4S or ECHO-8S, install
the power supply at the sender side only, and all of the
receivers receive power via PoC.
DO NOT apply power to receivers
when using ECHO-4S or ECHO-8S.

ECHO Family
6
© Copyright 2020 Hall Research, LLC
.
Connecting multiple senders – Daisy-chain
Daisy-chaining Audio and Video
To extend video to more than eight remote displays, additional senders can be
daisy-chained together using the HDMI IN and HDMI OUT connectors.
The ECHO-4S and ECHO-8S support daisy-chaining of up to eight senders;
totaling up to 64 possible remote displays.
To daisy-chain the HDMI source, use quality
HDMI cables to connect HDMI OUT of the
first box to HDMI IN of the second.
Hall Research carries a line of SnugFit™
HDMI cables designed for HDMI 2.0 and
featuring locking tabs to more securely affix
the HDMI cable in the connectors.
Daisy-chaining RS-232 (ECHO-4S and ECHO-8S)
By default, RS-232 sends all characters received by the 1st ECHO-x RS-232 input
to all RS-232 outputs at each receiver and RS-232 Loop Output.
If certain RS-232 outputs in the daisy-chain require unique commands, then
each sender must be assigned a unique device ID (from 1 to 8).
This ensures that every HDBaseT Output has a unique address for connecting
and routing serial commands. See Section 5 below for information on setting
Device IDs.
To daisy-chain the RS-232; connect the RS-232 Loop of the first Sender to the
RS-232 In of the second, and so on.
RX Loop connects to TX In, TX Loop connects to RX In, and GND connects to GND
as shown:
Model CHD-SF*

HDMI 2.0 HDBaseT Extenders
© Copyright 2020 Hall Research, LLC
.
7
Daisy-chaining IR (ECHO-4S and ECHO-8S)
To daisy-chain IR, use the supplied 3.5mm cables to connect the IR Loop Out of
the first sender to the IR In of the second, and the IR Loop In of the first sender
to the IR Out of the second, as shown:
4.0 Connector and Indicator Functions
Model ECHO-1S (front)
1 2 3 4 5
1) HDMI IN: Connect HDMI IN into an HDMI source, such as a PC, Blu-ray,
or media player.
2) HDMI OUT: Local HDMI output for connection to a display, or daisy-
chaining to another sender.
3) IR IN: Connect supplied IR Detector to send IR commands to the
receiver.
4) IR OUT: Connect supplied IR Emitter to output IR commands from the
receiver.
5) 24V DC: 24 V power input. Power is sent to the receiver via PoC.

ECHO Family
8
© Copyright 2020 Hall Research, LLC
.
Model ECHO-1S (rear)
1 2 3 4 5 6
1) RS-232: Connect to an RS-232 controller using the Phoenix terminal to
transmit RS-232 commands.
2) EDID: 3-position switch to control EDID routing.
a. Local: Use EDID from display connected to HDMI OUT port.
b. EMUL: Use internal emulated EDID.
c. Remote: Use EDID from display connected to receiver.
3) HDBaseT Out: Connect CAT5e or CAT6 cable to receiver.
4) RST: Reset switch. Hold 3 seconds to reset the unit to factory defaults.
5) FW: USB Micro port used to update firmware.
6) Audio Out: Line level stereo analog audio, de-embedded from HDMI IN.
Model ECHO-4S (front)
1 2 3 4
1) Status LEDs: POWER indicates sender power. PoC indicates the 24 V
Power over Cable is being used. HDMI IN indicates an HDMI signal is
detected.
2) RST: Reset switch. Hold 3 seconds to reset to the unit to factory
defaults.
3) EDID: 3-position switch to control EDID routing.
a. Local: Use EDID from display connected to HDMI OUT port.
b. EMUL: Use internal emulated EDID.
c. Remote: Use EDID from display connected to receiver.
4) FW: USB Micro port used to update firmware.

HDMI 2.0 HDBaseT Extenders
© Copyright 2020 Hall Research, LLC
.
9
Model ECHO-4S (rear)
1 2 3 4 5 6 7
1) HDMI IN/OUT: Connect HDMI IN to an HDMI source, such as a PC, Blu-
ray, or media player. Connect HDMI OUT to a display, or daisy chain
multiple senders.
2) HDBaseT Out: Connect to ECHO-RX2 using CAT5e or CAT6 cable.
3) RS-232/Loop: Connect to an RS-232 controller using the Phoenix
terminal to transmit RS-232 commands. Loop is used to daisy-chain to
multiple senders.
4) IR In/Out/Loop: Connect IR Detector to IR In, and IR Emitter to IR Out.
See Section 3 for IR daisy-chain.
5) Audio Out: Line level stereo analog audio and Optical TOSLINK audio,
de-embedded from HDMI IN.
6) PoC: Switch to enable Power over Cable. Do NOT use PoC when ECHO-
RX2 receiver power supplies are being used.
7) 24V DC: 24V power input. Power is sent to the receiver via PoC.
Model ECHO-8S (front)
1 2 3 4
1) Status LEDs: POWER indicates sender power. PoC indicates 24 V Power
over Cable is being used. HDMI IN indicates an HDMI signal is detected.
2) RST: Reset switch. Hold 3 seconds to reset to factory defaults.
3) EDID: 3-position switch to control EDID routing.
a. Local: Use EDID from display connected to HDMI OUT port.
b. EMUL: Use internal emulated EDID.
c. Remote: Use EDID from display connected to receiver.
4) FW: USB Micro port used to update firmware.

ECHO Family
10
© Copyright 2020 Hall Research, LLC
.
Model ECHO-8S (rear)
1 2 3 4 5 6 7
1) HDMI IN/OUT: Connect HDMI IN to an HDMI source, such as a PC, Blu-
ray, or media player. Connect HDMI OUT to a display, or daisy chain
multiple senders.
2) HDBaseT Out: Connect to ECHO-RX2 using CAT5e or CAT6 cable.
3) RS-232/Loop: Connect to an RS-232 controller using the Phoenix
terminal to transmit RS-232 commands. Loop is used to daisy-chain to
multiple senders.
4) IR In/Out/Loop: Connect IR Detector to IR In, and IR Emitter to IR Out.
See Section 3 for IR daisy-chain.
5) Audio Out: Line level stereo analog audio and Optical TOSLINK audio,
de-embedded from HDMI IN.
6) 24V DC PoC: 24 V power input to supply Power over Cable to ECHO-
RX2 receivers. Use the 24 V 4 A supply.
7) 24V DC Main: Main 24 V power input. Use the 24 V 2 A supply.
Model ECHO-RX2 (front)
1 2 3 4
1) HDMI OUT1 & OUT2: HDMI outputs for connection to displays.
2) IR IN: Connect supplied IR Detector to send IR commands to the sender.
3) IR OUT: Connect supplied IR Emitter to output IR commands from the
sender.
4) 24V DC: 24V power input. Power is sent to the sender via PoC.
ONLY FOR USE WITH ECHO-1S SENDER.

HDMI 2.0 HDBaseT Extenders
© Copyright 2020 Hall Research, LLC
.
11
Model ECHO-RX2 (rear)
1 2 3 4 5
1) RS-232: Connect to an RS-232 controller using the Phoenix terminal to
transmit RS-232 commands.
2) HDBaseT In: Connect CAT5e or CAT6 cable to Sender.
3) RST: Reset switch. Hold 3 seconds to reset to factory defaults.
4) FW: USB Micro port used to update firmware.
5) Audio Out: Line level stereo analog audio, de-embedded from HDMI
OUT.
5.0 Serial RS-232 Control
The ECHO-4S and ECHO-8S senders use system commands to select which
HDBaseT output to route the RS-232. Before daisy-chaining multiple senders,
assign a unique Device ID to each one by issuing an RS-232 system command to
each sender.
Serial Communication Parameters
Baud rate: 115200, Bits: 8, Parity: None, Stop bits: 1, Flow Control: None
Serial Commands
 System commands start with the “#” character and terminate with a
carriage return and line feed <CR><LF>.
 System Commands must be sent as a complete string without any delay
between characters.
 All responses from connected receivers are output on a first-come-first-
served basis.
 Do NOT send the ‘[‘ and ‘]’ characters
System Command
Description
#set_device_id[n]
<CR><LF>
Where:
n is Device ID
n = 1 to 8
Device ID #1 (Default)
Set the Device ID
of the unit
to
allow
control of daisy
-
chained senders
Response example:
Set Device ID to 3
>>#set_device_id3<CR><LF>

ECHO Family
12
© Copyright 2020 Hall Research, LLC
.
System Command
Description
#route id[n] port[m]=[c]
<CR><LF>
Where:
n is the Device ID
n = 0 ( To send to all devices in the chain)
n=1 to 8
m is the HDBaseT port
m = 0 to connect all ports
m = 1 to 4 for ECHO-4S
m = 1 to 8 for ECHO-8S
c is used to Connect/Disconnect the route
c = 0 to Disconnect
c = 1 to Connect
Controls the routing of
RS
-
232 Commands
Examples:
Enable routing of RS-232 to all ports on all devices
>>#route id0 port0=1<CR><LF>
Disable routing RS-232 on all ports on all devices
>>#route id0 port0=0<CR><LF>
Enable routing RS-232 to Device 1 & 2 and Port 3 & 4
>>#route id0 port0=0<CR><LF>
>>#route id1,2 port3,4=1<CR><LF>
Enable routing RS-232 to all ports of Device 1
and port 3 & 4 of Device 2
>>#route id0 port0=0<CR><LF>
>>#route id1 port0=1<CR><LF>
>>#route id2 port 3,4=1<CR><LF>
#sys_info
Outputs the RS
-
232 routing information and device ID
The ‘System ID’ in the output is the ‘Device ID’ for the unit.
The output below is from an ECHO-4S
System ID is 1.
The scanned port is DB9 .
###################### RS232 MAP STR #######################
[01] : DB9 <=> LOOP
[02] : DB9 <=> HDBT1
[03] : DB9 <=> HDBT2
[04] : DB9 <=> HDBT3
[05] : DB9 <=> HDBT4
###################### RS232 MAP END #######################
Using this command in a daisy-chained configuration can result
in a garbled response.

HDMI 2.0 HDBaseT Extenders
© Copyright 2020 Hall Research, LLC
.
13
6.0 Troubleshooting
If you are experiencing problems getting the ECHO to work properly, please use
the following troubleshooting suggestions.
 Ensure the CATx cables do not exceed 70 m for 4K video, or 100 m for
1080p video in length.
The use of RJ45 couplers not recommended.
Substitute a shorter length or known-good cable to test the output port
or receiver.
 Ensure the proper power supplies are used on each device:
o ECHO-1S uses a 24 V 1 A supply.
o ECHO-4S uses a 24 V 4 A supply.
o ECHO-8S uses a 24 V 2 A supply for main power, and 24 V 4 A
supply for receiver PoC power.
o ECHO-RX2 does not use a power supply unless paired with
ECHO-1S ONLY. Use a 24 V 1 A supply.
 Check the EDID routing.
For example, if the ECHO-RX2 is receiving a 4K signal, but some of the
monitors are 1080P; those monitors may not display an image.
Change the EDID routing to read the EDID from the 1080P display, or
whatever resolution is the highest common denominator.
 Try resetting the system by unplugging the power supply, waiting 5
seconds, and plugging it back.
Alternately, press and hold the RST button for 3 seconds to reset to
Factory Default.
(The sender Device IDs MUST BE reprogrammed if used in a daisy-
chain configuration.)
Contacting Hall Research
If you determine that your ECHO sender or receiver is malfunctioning, do not
attempt to repair the unit.
There are no user-serviceable parts inside, and you will void your warranty.
Instead, contact Hall Research Technical Support at 714-641-6607. To return
the unit to Hall Research you must first get a Return Authorization (RMA)
number.
Package the unit carefully, if returning. We recommend that you use the original
container.

ECHO Family
14
© Copyright 2020 Hall Research, LLC
.
7.0 Specifications
Video
Standards
HDMI 2.0
video specifications including
HDR10
, 3D video
HDCP 2.2, 1.4
DVI (single link)
Connectors
ECHO
-
1S
(1) HDMI Input
(1) HDMI Output
ECHO
-
4S
(1) HDMI Input
(1) HDMI Output
ECHO
-
8S
(1) HDMI Input
(1) HDMI Output
ECHO
-
RX2
(2) HDMI Outputs
Resolutions
HDTV signal
480p through
4K@60 4:4:4
DVI signal VGA (640x480) thru WUXGA (1920x1200)
Audio
Formats
LPCM
2
CH
Audio (32
-
192
kHz
sample rate)
,
DTS
-
HD, DOLBY
-
HD
Other Signals
RS
-
232
ECHO
-
1S, ECHO
-
RX
-
2
(1) RX, TX and GND on Terminal Strip
RS-232 pass-through
ECHO-4S, ECHO-8S
(2) RX, TX and GND on Terminal Strip (Input and Loop Output)
RS-232 Input Baud Rate: 115200, N, 8, 1
RS-232 Output to ECHO-RX2 Baud Rate: Configurable at 1200, 2400, 4800, 9600, 19200,
38400, 57600, or 115200
IR
Wide
-
band IR pass
-
through
: 38
–
56 kHz supported
ECHO-1S, ECHO-RX-2
(1) 3.5 mm IR Input
(1) 3.5 mm IR Output
ECHO-4S, ECHO-8S
(2) 3.5 mm IR Input (Input and Loop)
(2) 3.5 mm IR Output (Input and Loop)
USB
USB 2.0 Micro type B (firmware update only)
General
Power S
upply
100 VAC to 240 VAC, 47
-
63 Hz, External;
24
VDC
ECHO
-
1S, ECHO
-
RX
-
2
24 VDC 1 A
ECHO
-
4S
24 VDC 4 A
ECHO
-
8S
MAIN: 24 VDC 2 A
PoC: 24 VDC 4 A
Temp/humidity
Stor
age:
-
40 to +158°F (
-
40 to +70°C) / 5
% to 90%, non
-
c
ondensing
Operating: +14 to +131°F (-10 to +55°C) / 5% to 90%, non-condensing
Typical
Power
Consumption
ECHO
-
1S
& ECHO
-
RX2 = 12
W total
ECHO-4S & ECHO-RX2 = 15 W (Sender) 30 W (PoC)
ECHO-8S & ECHO-RX2 = 36 W (Sender) 60 W (PoC)

HDMI 2.0 HDBaseT Extenders
© Copyright 2020 Hall Research, LLC
.
15
Cooling
Convection
Enclosure type
Metal (Steel)
Dimensions
ECHO
-
1S
–
0.82” H x 6.06” W x 3.09” D (22.8mm H x 153.9mm W x 78.5mm
D)
(Width includes mounting flanges)
ECHO-4S – 1.74” H x 10.64” W x 7.46” D (44.2mm H x 270mm W x 189.5mm D)
ECHO-8S – 1.72” H x 18.9” W x 7.46” D (43.7mm H x 480mm W x 189.5mm D)
ECHO-RX2 – 0.82” H x 6.06” W x 3.09” D (22.8mm H x 153.9mm W x 78.5mm D)
(Width includes mounting flanges)
Product weight
Model Only
ECHO
-
1S
-
0.75 lbs
ECHO-4S - 3.85 lbs
ECHO-8S - 10.8 lbs
ECHO-RX2 - 0.75 lbs
Shipping ECHO-1S - 2.0 lbs
ECHO-4S - 10.0 lbs
ECHO-8S - 15.0 lbs
ECHO-RX2 - 2.0 lbs
Safety
CE
EMI/EMC
CE, FCC Class A
MTBF
9
0,000 hours (
e
stimate)
Warranty
3 years parts and labor
Specifications are subject to change without notice

© Copyright 2020. Hall Research, LLC.
All rights reserved.
1163 Warner Ave., Tustin, CA 92780
Ph: [phone]
