Halo ELITE4B User manual

1
ESSENTIALS GUIDE

2
08
TURN UP THE HEAT WITH EIGHT COOKING ZONES
TABLE OF CONTENTS
04
MEET THE ELITE 4-BURNER OUTDOOR GRIDDLE
06
FEATURES OF YOUR ELITE 4B
10
OWNER'S MANUAL
18
LIGHTING INSTRUCTIONS
24
CARING FOR YOUR ELITE 4B
14
PRODUCT RECORD
11
CSA - ENGLISH
15
CONNECTING 20 LBS. TANK
GREASE CUP + LEVELING 20
TROUBLESHOOTING 29
23
SEASONING YOUR GRIDDLE
33
FIVE (5) YEAR LIMITED
WARRANTY
ELITE 4B PARTS LIST 30
32
ASSEMBLED DIMENSIONS
27
CONVERTING YOUR GRIDDLE

3
36
MANUAL DEL USUARIO
43
INSTRUCCIONES DE ENCENDIDO
50
CUIDANDO TU ELITE 4B
40
REGISTRO DE PRODUCTOS
37
CSA - ESPAÑOL
41
CONECTAR TANQUE DE 20 LBS.
46
CONVERTIR SU PLANCHA 53
49
TRATAMIENTO DE LA PLANCHA
58
DIMENSIONES ENSAMBLADO
SOLUCIÓN DE PROBLEMAS 55
GARANTÍA LIMITADA DE CINCO (5) AÑOS 59
56
LISTA DE PIEZAS ELITE 4B
62
MANUEL DU PROPRIÉTAIRE
70
INSTRUCTIONS D'ALLUMAGE
76
ENTRETIEN DE VOTRE ELITE 1B
66
FICHE PRODUIT
63
CSA - FRANCAIS
67
CONNEXION 20 LBS. RÉSERVOIR
BAC À GRAISSE + NIVELLEMENT 72
TRANSFORMATION DE VOTRE GRIL 79
75
APPRÊT DE VOTRE GRILL
84
DIMENSIONS DE MONTAGE
DÉPANNAGE 81
GARANTIE LIMITÉE DE CINQ (5) ANS 85
82
LISTE DES PIÈCES ELITE 4B
DEPÓSITO DE GRASA + NIVELACIÓN

4
MEET THE
Taking your outdoor cooking skills above and beyond never felt so simple.
With the Elite 4B, enjoy true wall to wall cooking with the industry’s first
8 zone 4 burner outdoor griddle. Simplify your cooking experience with a
unique wind proof design, rear grease management and utensil clean off.
When it comes to innovation and an Elite outdoor cooking experience, we’ve
got you covered.
We strive to Rise Above in both who we are and what we create. Our mission
is to be a catalyst for reconnecting people and enhancing the experience
of cooking outdoors—In the greatness of nature, on-the-go, and in your
backyard.
The entire team here at Halo thanks you for joining our community. We look
forward to serving you by listening and continuing to bring you authenticity,
versatility and innovation.
-

5

6
Get the most use out of your entire cooking surface with custom zones!
Control 8 zones with 4 control knobs.
WALL TO WALL COOKING SURFACE
Season the Elite 4B's 720 in2total cooking surface within 18-20 minutes.
SEASON YOUR GRIDDLE IN UNDER 30 MINUTES
8 ZONE BURNER SYSTEM
FEATURES OF YOUR
WIND-PROOF DESIGN
QUICK WARM UP TIME
Innovative wind-proof design ensures your flame stays lit!
Ready to cook in 15 minutes depending on the ambient temperature.
6

7
Designed to connect a 20 lb
propane tank. NEW FEATURE -
adjustable regulator between 9.5" to
11" WC for more temperature control.
Attach the included handles
to remove the griddle top.
GRIDDLE PLATE LIFT OFF
PROPANE FUELED
WIDE RANGE TEMPERATURE
300°F to 750°F
BUILT IN UTENSIL CLEAN OFF
Clean utensils as you cook.
REAR GREASE MANAGEMENT
Extra large capacity grease
container included.
7
SWING AWAY WARMING RACK
The included rack provides
205.5 in2of additional space for
keeping foods warm.

8
88
WITH 8 COOKING ZONES
ZONES 1 +2
8
ZONES 3 +4

9
9
9
The Elite 4B Outdoor Griddle takes control to the next level by splitting each of
its 4 burners into 2 zones. Ignite any of the 4 front zones without igniting the
back zones for custom cooler zones ready to keep your food from burning.
9
ZONES 5 +6 ZONES 7 +8

10
SCAN FOR
Product Registration
Online Owner’s Guide
Assembly Videos
10
OWNER'S MANUAL
MODEL NO: HZ-1001-XNA
This instruction manual
contains important
information necessary for
the proper assembly and
safe use of the appliance.
WARNING
Do not try to light this appliance without
reading the Ignition Instructions section of this
manual.
WARNING
The manufacturer has made every effort to eliminate any
sharp edges. However, you should handle all components
with care to avoid accidental injury.
WARNING
• "FOR OUTDOOR USE ONLY."
• "READ ALL INSTRUCTIONS BEFORE
INSTALLING AND USING THE APPLIANCE."
• "SAVE THESE INSTRUCTIONS."
WARNING
Halo Products Group LLC
850 West Park Rd Elizabethtown KY, 42701
Toll free: 1-833-572-1688
"Follow all warnings and
instructions when using the
appliance."
WARNING
• The use of alcohol, prescription, or non-prescription drugs
may impair the consumer's ability to properly assemble or
safely operate the appliance.
• When cooking with oil or grease, have a type BC or ABC
re extinguisher readily available.
• In the event of an oil or grease re do not attempt
to extinguish with water. Immediately call the re
department. A Type BC or ABC re extinguisher may, in
some circumstances, contain the re.
• This appliance is not intended for and should never be
used as a heater.
• This appliance will be hot during and after use. Use
insulated oven mitts or gloves for protection from hot
surfaces or splatter from cooking liquids.
• Do not store a spare LP gas cylinder under or near
this appliance.
• Never ll the cylinder beyond 80 percent full; and if
the instructions in bold above are not followed exactly, a
re causing death or serious injury may occur.
• The LP gas tank used must have a collar to protect the
tank valve.
WARNING
Minimum distance from sides and back of unit
to walls or railings 36” (914.4mm).“ Do not use
under overhead construction.
WARNING

11
IMPORTANT SAFETY INFORMATION
If you smell gas:
• Shut off gas to the
appliance.
• Extinguish any open ame.
• Open lid.
• If odor continues, keep
away from the appliance
and immediately call your
re department.
Failure to follow the
Dangers, Warnings and
Cautions contained in this
Owner’s Manual may result
in serious bodily injury or
death.
DANGER • Never operate this
appliance unattended.
• Never operate this
appliance within 10'
(3.0 m) of any structure,
combustible material or
other gas cylinder.
• Never operate this
appliance within 25'
(7.5 m) of any ammable
liquid.
• If a re should occur, keep
away from the appliance
and immediately call your
re department. Do not
attempt to extinguish an
oil or a grease re with
water.
Failure to follow these
instructions could result
in re, explosion or
burn hazard which could
cause property damage,
personal injury or death.
DANGER
Do not leave the appliance unattended. Keep children
and pets away from the appliance at all times.
WARNING
This product can expose you to chemicals,
including carbon monoxide, which are known to
the State of California to cause cancer and birth
defects or other reproductive harm. For more
information go to www.P65Warnings.ca.gov
WARNING
CALIFORNIA PROPOSITION 65
When using a match to light the appliance,
make sure to use the included matchlight stick
or a long 11” match.
WARNING
FOR OUTDOOR USE ONLYand
shall not be used in a building, garage, or any
other enclosed area.
WARNING
Spiders and insects can nest inside the burner
of the appliance and disrupt gas ow. Inspect
the burner at least once a year.
WARNING This appliance is not intended for commercial use.
WARNING
Check all gas supply ttings for leaks before each use.
Do not use the appliance until all connections have
been checked and do not leak.
WARNING
• "Read and follow all
warnings and instructions
before assembling and
using the appliance."
• "Follow all warnings and
instructions when using
the appliance."
• "Keep this manual for
future reference."
• "Keep the fuel supply hose
away from any heated
surface(s)."
WARNING
In the event of rain, snow, hail, sleet, or other
forms of precipitation while cooking with oil
or grease, cover the cooking vessel immediately and
turn off the appliance burners and gas supply. Do
not attempt to move the appliance or cooking vessel.
WARNING
Keep any electrical supply cord and the fuel
supply hose away from any heated surfaces.
WARNING
Place dust cap on cylinder valve outlet whenever the
cylinder is not in use. Only install the type of dust
cap on the cylinder valve outlet that is provided
with the cylinder valve. Other types of caps or plugs
may result in leakage of propane.
WARNING

12
• Use your HALO Elite 4B Outdoor Griddle as purchased.
• HALO Elite 4B Outdoor Griddle installation must conform with local
codes, or in the absence of local codes, with either the National Fuel
Gas Code, ANSI Z223.1/ NFPA 54, Natural Gas and Propane Installation
Code, CSA B149.1, or Propane Storage and Handling Code, B149.2, or the
Standard for Recreational Vehicles, ANSI A 119.2/NFPA 1192, and CSA
Z240 RV Series, Recreational Vehicle Code, as applicable.
• HALO Elite 4B Outdoor Griddle is not for use in or on recreational
vehicles and/or boats.
• HALO Elite 4B Outdoor Griddle is safety certied for the United States
use only. Do not modify for use in any other countries. Alteration will
result in a safety hazard.
• Ensure that the pressure regulator supplied with the appliance is used.
The replacement pressure regulator P/N: #HZ-1001-22, for a 20 lb.
cylinder, must be used with the appliance.
• Place dust cap on cylinder valve outlet whenever the cylinder is not in
use. Only install the type of dust cap on the cylinder valve outlet that
is provided with the cylinder valve. Other types of caps or plugs may
result in leakage of propane.
INSTALLATION SAFETY PROTECTIONS
• Keep the appliance area clear and free from combustible materials,
gasoline, and other ammable vapors and liquids.
• Do not obstruct the ow of combustion and ventilation.
• Keep the ventilation opening of the cylinder enclosure free and clear
from debris.
• Visually check burner ames.
• Clean the appliance, including special surfaces, with recommended
cleaning agents, if necessary.
• Check and clean the burner/venturi tube for insects and insect nests.
A clogged tube can lead to a re beneath the appliance.
SAFETY MAINTENANCE
Turn OFF your HALO Elite 4B Outdoor Griddle when not in use.
• Never move HALO Elite 4B Outdoor Griddle while it is in operation or
still hot.
• Use long-handled barbecue utensils and oven mitts to avoid burns and
grease splatters.
• Keep unit a minimum of 36” away from walls, buildings, vehicles, or
other structures while in use.
USE AND CARE
• Clean your HALO Elite 4B Outdoor Griddle after each cook.
• Turn off the gas supply if you notice grease dripping onto the valve or
regulator. Determine the cause, correct it, then clean and check valve,
hose, and regulator before continuing to operate your HALO Elite 4B
Outdoor Griddle.
• Keep ventilation openings in cylinder enclosure free and clear of debris.
• The regulator may make a humming or whistling noise during
operation. This will not affect safety or use of your HALO Elite 4B
Outdoor Griddle.
• Turn off your HALO Elite 4B Outdoor Griddle immediately if the
regulator frosts. This indicates a problem with the LP cylinder, and it
should not be used on any product. Return to supplier.
• Please call Consumer Service at 1-833-572-1688 if you have a
problem with your HALO Elite 4B Outdoor Griddle and refer to the
Troubleshooting Section on page 29.
IMPORTANT:
• To check the valve, rst push in the control knob, and then release. The
control knob should spring back. If the control knob does not spring
back, replace the valve assembly before using your HALO Elite 4B
Outdoor Griddle.
• Push and turn the control knob counterclockwise to LOW position, then
turn back to OFF position. The valve should rotate smoothly.
CHECK CONTROL VALVE CONDITION
Turn the control knob to to ignite the burner. Press the electronic
ignition button for 2-3 seconds. You will hear it click, then turn knob to
to light both burner zones. Turn knob from HIGH to LOW. You should see a
smaller ame in the LOW position than seen on HIGH. Always check the ame
prior to each use. If only the LOW ame is seen, refer to “Sudden drop or low
ame” in the Troubleshooting section on page 29.
BURNER FLAME CHECK
• Plastic components: Do not use Cortisol, abrasive cleaners, degreasers,
or a concentrated oven cleaner on plastic parts that could cause
damage. Wash with warm soapy water and wipe dry.
• Painted surfaces: Wash with mild detergent or nonabrasive cleaner and
warm soapy water. Wipe dry with a soft nonabrasive cloth. Do not use
an abrasive pad on areas with graphics. The grease deposits or baked
on grease may require the use of a non-abrasive plastic cleaning pad.
Do not apply a corrosive oven cleaner to painted surfaces.
GENERAL CLEANING

13
CSA - ENGLISH
• Stainless Steel Cleaning Tips:
Step 1: Dip a soft cloth in warm water mixed with a mild dish detergent.
Wipe the surface, rinse the cloth and wipe again, then dry with a towel
to prevent water spots.
Step 2: If you still see ngerprints, spray a glass cleaner onto a soft
cloth and wipe ngerprints away.
Step 3:To remove baked-on food and grease, make a paste of baking
soda and warm water. Gently rub onto the surface using a soft cloth or
sponge. Wipe with a clean wet cloth and towel dry. For scratches and
stains, use a stainless-steel cleaner and apply it to the area, following
directions. Rinse with a clean damp cloth, then dry.
Food storage safety tips:
• Understand what “high-risk” foods are.
• Always keep high-risk food at the proper temperature.
• Store raw foods, such as raw meat, seafood, and vegetables below cooked
foods in the refrigerator or freezer.
• Store food in properly covered containers made of glass or plastic.
• Avoid refreezing already thawed foods.
WHAT YOU SHOULD KNOW ABOUT
FOOD SAFETY
1. WASH YOUR HANDS-Wash your hands with hot water and soap for at
least 15-20 seconds before and after handling food.
2. SEPARATE RAW AND READY TO EAT/COOKED FOODS
• Ensure that raw food is always kept refrigerated and away from ready
to eat/cooked foods. Food that is marinating should also be kept
covered in the fridge.
• Ready to eat foods (such as salads, vegetables, sauces) and cooked
foods, should never come into contact with raw food as this causes
harmful bacteria to contaminate the cooked food.
• Always ensure that you use separate chopping boards/utensils for raw
and cooked foods, and always wash your hands after handling raw food.
3. COOK FOOD THOROUGHLY
• Food poisoning is caused by harmful bacteria, such as E-Coli and
Salmonella, which are killed by cooking. In order to ensure food
safety, it is essential to cook food thoroughly.
GRIDDLE FOOD AND SAFETY
• Slice into the thickest part of the meat with a fork and a sharp
knife to check whether it's cooked. If the color of the meat in the
center is still pink, it needs to cook longer.
• Burgers should always be cooked thoroughly and never be served
pink.
• Food thermometers are available in most supermarkets, and they
can easily tell whether meat is cooked by probing it for 165 degrees
Fahrenheit or 74 degrees Celsius. They are a handy tool to have in
your kitchen.
4. SERVE FOOD IMMEDIATELY AFTER COOKING - Letting cooked
food sit at room temperature allows for harmful bacteria to grow.
Once food is cooked, serve immediately; otherwise, you should cool
cooked food quickly, refrigerate, and consume within 2 days.
5. ALWAYS KEEP FOOD COVERED - Always keep food covered to ensure
that ies are not contaminating your food.
• Use a meat thermometer to ensure food has reached a safe internal
temperature.
• Whole poultry should reach 165° F/ 73.8 °C for dark meat, 160°F/ 71°C for
white meat.
• Hamburgers made of any ground meat or poultry should reach
160°F/71°C and be brown in the center with no pink juices. Beef, veal and
lamb steaks, roasts and chops can be cooked to 145°F/63°C. All cuts of
pork should reach 160°F/71°C.
NEVER partially grill meat or poultry and nish cooking later. Cook food
completely to destroy harmful bacteria.
HOW TO CHECK IF MEAT IS DONE ON
THE GRIDDLE

14
PRODUCT RECORD
IMPORTANT:Fill out the product information record below, or to
register your product, visit our website at www.halo-pg.com.
Model Number:
Serial Number:
Purchase Date:
NOTICE: Model number and Serial Number located on the back of front panel.

15
CONNECTING 20 LBS. TANK
1. Place LP tank on tank support bracket and secure with tank retention wire or level, and stable surface.
2. Make sure the burner valve is on OFF position.
3. LP tank should be in the OFF position. If not, turn the wheel clockwise until it stops.
4. Remove the protective cap from LP tank valve. Always use cap and strap supplied with OPD valve.
5. DO NOT USE A POL TRANSPORT PLUG (plastic part with internal threads)! IT WILL DEFEAT THE SAFETY FEATURE OF
THE VALVE.
CONNECTING HOSE + ADJUSTABLE REGULATOR 20 LBS. TANK
WARNING
The LP tank used with this Flat Top Griddle must meet the following requirements:
• Use the appliance only with LP (propane) gas and the regulator/valve assembly supplied.
• Installation must conform with local codes, or in their absence with National Fuel Gas Code, NFPA 54/ANSI Z223.1. Handling and
storage of LP cylinders must conform to LP Gas Code NFPA/ANSI 58.
• Do not modify this appliance. Modications will result in a safety hazard.
• Apartment Dwellers: Check with management to learn the requirements and re codes for using an LP Gas appliance at an apartment.
If allowed, use outside on the ground oor with a 10-foot clearance from walls or rails.
Regulator attached

16
11" Water Column 8.5" Water Column
11" Water Column
8.5" Water Column
ADDED FEATURE
Your griddle is equipped with an adjustable low-pressure regulator. The normal
operating pressure is 11" water column and the lower operating pressure available
is 9.5" water column. When operating your griddle under normal circumstances,
you will want to have the regulator set at the 11" water column pressure. If you
want to cook with slightly lower temperatures, then set the regulator to the 9.5"
water column setting. Depending on what temperature setting you have the
control knob set at will determine how much lower your temperature will be
when using the lower pressure setting. Please see the instructions on how to
change from the 11" water column setting and back again.
9.5" Water Column
11" Water Column
Leak Check
• Pull back the spring-loaded coupling to release regulator cap to achieve 9.5"
water column.
• Pull back the spring-loaded coupling then push the regulator cap rmly and
release. The regulator cap will snap in and lock in place to reset the regulator
to 11" water column.
HOW TO SET REGULATOR SETTING
Regulator attached

17
1. Attach hose assembly to the cylinder.
2. Slowly open the cylinder valve.
3. Perform a leak check on regulator to griddle hose to
regulator and hose to cylinder connections with soapy
water. Bubbles indicate a leak. Check that the connection
is not cross threaded and that it is tight.
4. Perform another leak check. Check the coupling nut for
tightness. If there is still a leak, remove the cylinder and
contact the manufacturer for service and repair.
5. When appliance is not in use, turn off the control knob
and LP tank valve on the supply cylinder.
LEAK TEST PROCEDURE
Tripping hazard over hose and supply cylinder.
• Make sure to attach the cylinder securely with the tank retention wire.
• Do not operate the appliance on a tabletop higher than 39.8” (101.09 cm).
• Make sure to the cylinder on a level surface and away from tripping
hazards.
WARNING
6. Never use an LP tank if visibly rusted, damaged, or out of date.
7. If you notice grease or other hot material dripping from appliance onto the valve, hose or regulator, turn off gas supply at once.
Determine the cause, correct, clean and inspect valve, hose and regulator before continuing. Perform a leak test.
8. The regulator may make a humming or whistling noise during operation. This will not affect the safety or use of appliance.
9. Clean and inspect the hose before each use of the appliance. If there is evidence of abrasion, wear, cuts or leaks, the hose
must be replaced prior to the appliance being put into operation. See product tag for hose and regulator information.
10.Do not block holes in bottom or sides of appliance.
11. Never operate appliance with LP tanks out of correct position specied in Assembly Instructions.
12. Always close LP tank valve and remove coupling
nut before moving LP tank form specied operating
position.
13. NEVER store a spare LP tank under or near appliance or
in an enclosure.
14. If you see, smell, or hear escaping gas, immediately
get away from the LP tank/appliance and call your re
department.
15. All spare LP tanks must have safety caps installed on the
LP tank outlet.
Table Height
30” (76.2cm)
Hose Length
23.35”(59.31cm)
Check for leaks at these connections.

18 Lighting instructions located here
Burner Viewing Ports
FRONT
ZONE
DUAL
ZONES
1. Open lid during lighting.
2. Push and turn control knob to . Press the
electronic igniter and hold for 3-5 seconds
then turn to light front section of burner.
LIGHTING THE GRIDDLE
LIGHTING INSTRUCTIONS
NOTE: To conrm the burner is lit, look through the burner
viewing port above the control knob, then turn the control knob to
light the back section.
3. If ignition does not occur in 5 seconds,
turn the burner control off, wait 5
minutes, and repeat the lighting
procedure.
SYMBOLS
Represents Burner being lit
Represents Burner already lit
Represents Front Zone on
HIGH setting
Represents Dual Zones on
HIGH setting
NOTE: Lighting instructions are located under the bottom of the
control panel. Rotate out to follow the instructions. Represents Unit is in "OFF" position

19
Match
Lighting
Opening
Match
Lighting
Stick
3/16”-1/4”(4.76-6.35mm)
MATCH LIGHTING INSTRUCTIONS
1. Open lid.
2. Make sure the control knob is in the OFF
position (Push control knob down and
turn clockwise to make sure that it is in
the OFF position.)
3. Light burner with match lighting stick
or with an 11” long match, then place the
match on top of the burner.
4. Push and turn control knob to
setting to light the burner.
5. Make sure the burner lights and stays lit.
Do not lean over the open barbecue. Keep your face
and body at least one foot away from the matchlight
hole when lighting the griddle.
WARNING
To create a solid spark, the DISTANCE between
the electrode and burner should be 3/16”-1/4”
(4.76-6.35mm). The electrode should not touch
the burner or be spaced out too far. Be sure that
the spark goes to a port instead of a random
spark to burner.
IGNITION-ELECTRODE GAP
DISTANCE
NOTE: A match lighting stick is conveniently located at the front left side of the re chamber.
19

20
GREASE CUP +LEVELING
To avoid grease leakage, position the lip of the grease cup under the griddle drip ledge when
installing the grease cup. Check the grease cup often and clean it out after each use.
1. Pull-out spring-loaded knurl knob.
2. Rotate the handle back to empty the grease.
FOLDING THE GREASE CUP HANDLE
WARNING
Make sure the griddle is
cooled before removing the
grease cup.
POSITIONING THE GREASE CUP
NOTE: For easy cleanup, purchase Halo's disposable grease
bucket liners at www.halo-pg.com.
