Halo COMPACTOR SENSOR TRASH CAN User manual

COMPACTOR SENSOR TRASH CAN®USER MANUAL
Have Questions or Comments? Contact halo Customer Support at:
www.haloquality.com/contact
COMPACTOR SENSOR TRASH CAN™
USER MANUAL
Items included in the package:
•Sensor Trash Can Lid
•Brushed Stainless Steel Coating Trash Can Body
•Trash Bag Retainer Ring
•Compactor Tool
•One (1) Compactor Plate Cover
Suggested replacement every 1-3 weeks
•Activated Carbon Deodorizer Compartment
•One (1) Activated Carbon Odor Filter
Suggested replacement every 1-3 months
•User Manual
Optional items NOT in the package:
•Official AC Power Adaptor
•Replacement Activated Carbon Deodorizer
•Replacement Compactor Plate Cover
•Replacement Compactor Plate
•Stainless Steel Cleaner
•Custom Fit Premium Trash Bags
To order optional items, please visit www.haloquality.com
Protect your purchase. Register today!
www.haloquality.com/register

COMPACTOR SENSOR TRASH CAN®USER MANUAL
Have Questions or Comments? Contact halo Customer Support at:
www.haloquality.com/contact
ABOUT YOUR COMPACTOR SENSOR TRASH CAN:
The Compactor Sensor Trash Can™is the world’s first sensor-operated trash can that has a compacting feature designed
to help you save money, time, and the environment. This extremely convenient feature results in fewer trash bag
changes and reduced consumption of trash bags. There is a Compactor Tool that is foldable and concealable within the
lid compartment that allows you to manually compress trash up to 40% of can capacity. Compacting your trash not only
saves you money, but also reduces the negative impact your trash has on the environment.
The touchless sensor operation promotes a germ-free environment. The Activated Carbon deodorizer neutralizes
odors. The lid sensor uses invisible and harmless, patented infrared technology for accurate and responsive lid open
and close operation. There are two buttons on the front of the lid, “OPEN” and “CLOSE”, to open and close the lid
manually, and an ON/OFF power switch on the back of the trash can lid. The infrared sensor on the lid (Sensor Zone as
shown on PICTURE 1) will automatically open the lid when your hand or object is within 6 inches/10 cm of the sensor.
The lid will remain open if the sensor detects any object within its radius and will automatically close in 4 seconds after
the object is withdrawn.
Indicator Light (LED Light)
(1) In stand-by mode, the indicator light flashes red once every 3 seconds.
(2) When the lid is opened using the “Open” button, the indicator light flashes green once every 3 seconds.
(3) When the batteries are nearly depleted, the indicator light flashes yellow/amber once every 3 seconds.
ATTENTION:
1. Do not submerge the lid in water as it houses the electronic control. You may clean it with a lightly dampened
cloth.
2. Clean the trash can body only with products safe for use on stainless steel.
3. Do not press or force the Lid Cover to close. Lid will close automatically after your hand is removed from the
sensor zone.
4. Do not use excessive force on the Compacting Tool to compact contents. If contents are compacted to tightly,
the trash bag may be too heavy to remove.
5. Replace batteries immediately when the indication light turns to yellow/amber. This will ensure the lid continues
to operate properly.
6. To ensure the maximum performance of this trash can, it is highly recommended to replace both the Compactor
Plate Cover and the Activated Carbon Deodorizer at least once every 3 months.
7. Avoid direct sunlight on the infrared sensor.
8. Ensure there is enough room to operate the trash can without blocking the opening and closing of the lid.
9. Do not use a power adaptor that is not authorized by halo; it may result in fire, electric shock, or injury.
10. Do not use power adaptor and battery at the same time to operate the trash can. It can only be powered by one
source at a time.
11. Do not overstuff trash bag. It may cause tearing or difficulty removing.
12. Automatic parts may not be suitable for small children or pets.

COMPACTOR SENSOR TRASH CAN®USER MANUAL
Have Questions or Comments? Contact halo Customer Support at:
www.haloquality.com/contact
OPERATING INSTRUCTIONS:
a. Remove Lid Unit from the trash can. Remove Deodorizer Compartment located on the underside of Lid Unit (PICTURE 2) to
insert a Carbon Deodorizer (see HOW TO USE THE ACTIVATED CARBON ODOR FILTER). Open battery compartment cover
to insert 4 "D" size batteries . Close compartment cover and reattach Deodorizer Compartment.
b. Insert one 13 gallon to 18 gallon trash bag through Smart Retainer Ring and wrap the top part of the bag over the Ring
(STEP 1 in HOW TO USE THE SMART RETAINER RING). Put the Ring onto the top edge of the can body (STEP 2).
c. Wrap the Compactor Plate with the Compactor Plate Cover (See HOW TO USE THE COMPACTOR PLATE COVER).
d. Place Lid Unit onto the can body and make sure it is securely attached.
e. Turn on the power switch on the back of the Lid Unit (PICTURE 4). A red Indicator Light will turn on for 3 seconds. It will
flash once every 3 seconds to indicate that the system is on and ready to use.
f. Place your hand or any object 6 inches above the Infrared Sensor on the front of Lid Unit to open. The Lid will remain open
if it detects objects within the Sensor Zone. The Lid will close in 4 seconds after your hand or object moves away.
g. If you press the open button, the Lid will open, and remain open for 5 minutes before closing automatically –unless you
press the close button. The trash can will then resume operating in automatic mode.
h. To compact trash, turn off the power, push the round cover on the Lid open and turn the cover of the Compactor Tool
Compartment counter-clockwise to reveal the Compactor Tool, remove the Tool, flip and straighten the Tool following the
numbers from 1 to 5 to make it T-shape, fit the tip of the Tool into the hole inside the Compactor Tool Compartment and
turn it counterclockwise to lock the pole, and then push the pole downward from the top (see HOW TO USE THE
COMPACTOR TOOL).

COMPACTOR SENSOR TRASH CAN®USER MANUAL
Have Questions or Comments? Contact halo Customer Support at:
www.haloquality.com/contact
HOW TO USE THE SMART RETAINER RING
STEP 
Place garbage bag inside
trash can, then wrap the
top of the bag over Ring.
STEP 
Secure Ring onto the
edge of the can body.
HOW TO USE THE ACTIVATED CARBON ODOR FILTER:
This Compactor Sensor Trash Can is equipped with a Deodorizer Compartment that houses
the odor-neutralizing Activated Carbon Odor Filter. One (1) replaceable Activated Carbon
Odor Filter is pre-installed inside the Deodorizer Compartment. Please follow these
instructions to maximize the Activated Carbon Odor Filter’s effectiveness.
1. Turn power switch to “Off” mode. Remove and turn Lid Cover upside down.
2. Slide Deodorizer Compartment (Fig.1) to the right (Fig.2) to remove.
3. Remove Activated Carbon Odor Filter from the Compartment.
4. Remove new Activated Carbon Odor Filter pouch from plastic bag (do NOT cut open
the Odor Filter pouch).
5. Insert the new Odor Filter pouch (Fig.3) into the Deodorizer Compartment.
6. Return the Deodorizer Compartment to Lid Cover (Fig.1) and slide to the left (Fig.2)
to lock the Deodorizer Compartment in position.
7. Replace Activated Carbon Odor Filter every 3 months or when odor becomes too
strong.
8. Order replacement Activated Carbon Odor Filters online at www.haloquality.com.
Cleaning Tips:
•Deodorizer Compartment can be washed with soap and warm water (not intended
for dishwasher cleaning).
•Used Activated Carbon Odor Filter pouch should be disposed of in trash.
HOW TO USE THE COMPACTOR PLATE COVER:
1) Wrap the Cover over the
plate starting from the
bottom.
2) Stretch the Cover and
continue wrapping over the
top of the plate.
3) Adjust the Cover until
the entire cap is covered.
4) The Cover is covered by
the bag and ready to use.

COMPACTOR SENSOR TRASH CAN®USER MANUAL
Have Questions or Comments? Contact halo Customer Support at:
www.haloquality.com/contact
HOW TO USE THE COMPACTOR TOOL:
(1) Push down on the
“PUSH OPEN” dot
and then turn the
Compactor Tool
Compartment Cover
counter-clockwise to
access the
Compactor Tool.
(2) Remove the
Compactor Tool from
the Compartment.
Straighten the Tool
by following the
numbers from 1 to 5
to make it T-shaped.
(3) Fit the tip of the
Tool into the hole
inside the
Compactor Tool
Compartment and
turn it counter-
clockwise to lock the
Tool in place.
(4) Push the Compactor
Tool downward
from the top.

COMPACTOR SENSOR TRASH CAN®USER MANUAL
Have Questions or Comments? Contact halo Customer Support at:
www.haloquality.com/contact
HOW TO REPLACE THE COMPACTOR PLATE:
1) Unfasten the two screws to remove
the Plate.
2) Align the holes on the replacement Compactor
Plate on top of the screw holes.
3) Fasten the screws to
secure the new Plate.
Three (3) YEAR LIMITED WARRANTY
Compactor Sensor Trash Can is distributed by halo™ with the highest quality components and most advanced technologies available.
The trash can is warranted to be free from defects in material and workmanship, given normal use and care, for three years from the date
of the original purchase with proof of purchase within the United States and Canada. halo will only honor warranty requests from orders
placed with our authorized dealers. Items sold as used, floor sample or refinished are sold solely under the terms and conditions of the
selling party; halo will not warrant such purchase. halo will repair or replace the damaged part thereof which fails as the result of such a
defect during the warranty period.
The warranty is the customers' exclusive remedy for product defect and does not apply to:
User modification
Attachments to product by user that causes damage
Any product, on which the seals and/or serial numbers have been broken, removed, tampered with, defaced or altered in any manner
Damage caused by abuse, misuse, accident, water or theft
Except as stated above, halo makes no express or implied warranties as to any product, in particular, makes no warranty of
merchantability or of fitness for any particular purpose. halo shall not be liable for consequential or incidental damages arising from any
product defect. Our Liability is limited to the replacement of any defective product. halo expressly disclaims all warranties not satisfied in
this limited warranty. Any implied warranties that may be imposed by law are limited to the terms of this limited warranty. The Can Body,
Activated Carbon Odor Filter, Trash Bag Retainer Ring, Deodorizer Compartment, and Compactor Tool are not covered by this warranty.
If Trash Can should fail during the warranty period, contact us at http://www.haloquality.com/contact to submit a request for warranty
service. An administrative fee is assessed to cover the cost of shipping, packaging, and administration. The required administrative fee is
subject to location. Fee references are as following: for Contiguous 48 U.S. States $9.95 and up, for Canada $19.95 USD and up, for
Alaska and Hawaii $29.95 and up.
Subject to the above conditions, we will ship a working unit to you after payment has been provided for the administrative fee. This
warranty gives you specific legal rights. However, you may also have other rights that vary from state to state and province.

COMPACTOR SENSOR TRASH CAN®USER MANUAL
Have Questions or Comments? Contact halo Customer Support at:
www.haloquality.com/contact
TROUBLESHOOTING:
Problem
Solution
1. The trash can is brand new,
and only works occasionally
Peel off the thin, transparent protector/sticker on top of the sensor eye. If
the lid still doesn’t work regularly, try a new set of batteries. Then follow
the General Troubleshooting Steps below.
2. The lid stays open or lid
opens and closes
continuously
The sensor eye may be affected by dirt, stain, dust, moisture or reflection.
Move the trash can to a different location or turn the trash can slightly so
that the sensor faces another direction, and follow the General
Troubleshooting Steps.
3. Grinding noise when the lid
opens/closes
This can be caused by broken gears or lid hinge.
Check for damage on the hinges that connect to the lid
Follow the General Troubleshooting Steps below
Visit www.haloquality.com to order a new lid unit
Contact us at www.haloquality.com for warranty service
4. The lid does not open/close
Important: Do not use
batteries and the AC power
adaptor at the same time. It
can only be powered by one
source at a time.
If you are using batteries:
Ensure batteries are inserted correctly and close the battery cover
firmly
Turn power switch to “ON" position to see if the indication light is
visible
If you are using AC Power Adaptor:
Unplug the adaptor and insert new alkaline batteries to see if the lid
works on battery
If the lid works with batteries, the AC adaptor may be broken
5. I wave my hand over the
sensor eye, but the lid does
not open
It is not a motion sensor. Hold your hand or object steadily (do not wave
your hand) within 4-6 inches over sensor eye for it to detect and open.
6. The lid seems to lose
tension
The gear might lose tension over time. To fix the issue, locate the 2
screws inside the two holes in the battery compartment by removing the
batteries, if any. Turn both screws clockwise to tighten the tension. The
more you turn clockwise, the tighter the tension is.
7. Why is the indicator light
flashing in yellow/amber
color?
The battery power is low. Replace all batteries with a new set of alkaline
batteries. Do not use rechargeable batteries or old batteries.
GENERAL TROUBLESHOOTING STEPS:
(1) Turn power switch to “Off,”remove batteries or AC power adaptor, then rub and wipe clean the sensor area with a soft
damp cloth and dry it immediately with a soft dry cloth. Re-insert batteries or plug in AC adaptor (DO NOT USE batteries
and AC adaptor at the same time).
(2) Place trash can in an open area where nothing is blocking or within 10 inches of the sensor eye. Make sure no sunlight or
direct light shines on the sensor. Turn on the power and try opening lid again.
(3) If trash can is still not working correctly, remove the batteries or AC adaptor. Let trash can sit for at least 2 hours to reset.
Try opening lid after reset.
If your halo product is still not working after trying these troubleshooting steps, please contact us at:
www.haloquality.com/contact for warranty service.
