Hamilton Beach 40792 User manual

READ BEFORE USE
LIRE AVANT UTILISATION
LEA ANTES DE USAR
Visit www.hamiltonbeach.com for our
complete line of products and Use and
Care Guides – as well as delicious recipes,
tips, and to register your product online!
Rendez-vous sur www.hamiltonbeach.ca
pour notre liste complète de produits et de
nos manuels utilisateur – ainsi que nos
délicieuses recettes et nos conseils !
¡Visite www.hamiltonbeach.com ( EE. UU.)
o www.hamiltonbeach.com.mx (México)
para ver otros productos de Hamilton Beach
o para contactarnos!
Questions?
Please call us – our friendly
associates are ready to help.
USA: 1.800.851.8900
¿Preguntas?
Por favor llámenos – nuestros
amables representantes están
listos para ayudar.
EE. UU.: 1.800.851.8900
MEX: 01 800 71 16 100
Le invitamos a leer cuidadosamente este
instructivo antes de usar su aparato.
Questions ?
N’hésitez pas à nous appeler –
nos associés s’empresseront
de vous aider.
CAN : 1.800.267.2826
English ....................... 2
Français.................... 19
Español .................... 37
Espresso
Maker
Cafetière
espresso
Cafetera
Espresso

2
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always be followed to reduce the risk of fire, electric shock, and/or injury
to persons, including the following:
1. Read all instructions.
2. This appliance is not intended for use by persons (including
children) with reduced physical, sensory, or mental capabilities,
or lack of experience and knowledge, unless they are closely
supervised and instructed concerning use of the appliance by a
person responsible for their safety.
3. Close supervision is necessary when any appliance is used by or
near children. Children should be supervised to ensure that they
do not play with the appliance.
4. Do not touch hot surfaces. Use handles or knobs. Care must
be taken, as burns can occur from touching hot parts or from
spilled, hot liquid.
5. To protect against fire, electric shock, and injury to persons,
do not immerse cord, plug, or espresso maker in water or
other liquid.
6. Unplug from outlet when the espresso maker is not in use and
before cleaning. Allow to cool before putting on or taking off
parts and before cleaning the appliance.
7. Appliance must be operated on a flat surface away from the
edge of counter to prevent accidental tipping.
8. Do not operate any appliance with a damaged supply cord or
plug, or after the appliance malfunctions or has been dropped
or damaged in any manner. Supply cord replacement and
repairs must be conducted by the manufacturer, its service
agent, or similarly qualified persons in order to avoid a hazard.
Call the provided customer service number for information on
examination, repair, or adjustment.
9. The use of accessory attachments not recommended by the
appliance manufacturer may result in fire, electric shock, or
injury to persons.
10. Do not use outdoors.
11. Do not let cord hang over edge of table or counter or touch
hot surfaces, including the stove.
12. Be certain filter holder is securely in place when brewing
espresso. Scalding may occur if the filter holder is removed
during the brewing cycle.
13. Do not place appliance on or near a hot gas or electric burner
or in a heated oven.
14. To disconnect appliance, turn controls to OFF (O) and then
remove plug from wall outlet.
15. WARNING: To reduce the risk of fire or electric shock, do not
remove the top or bottom covers. No user-serviceable parts are
inside. Repair should be done by authorized service personnel
only.
16. Do not use appliance for other than intended use.
SAVE THESE INSTRUCTIONS!

3
Other Consumer Safety Information
This appliance is intended for household use only.
wWARNING Electrical Shock Hazard: This appliance is provided
with a polarized plug (one wide blade) to reduce the risk of electric
shock. The plug fits only one way into a polarized outlet. Do not defeat
the safety purpose of the plug by modifying the plug in any way or by
using an adapter. If the plug does not fit fully into the outlet, reverse the
plug. If it still does not fit, have an electrician replace the outlet.
The length of the cord used on this appliance was selected to reduce
the hazards of becoming tangled in or tripping over a longer cord. If a
longer cord is necessary, an approved extension cord may be used.
The electrical rating of the extension cord must be equal to or greater
than the rating of the appliance. Care must be taken to arrange the
extension cord so that it will not drape over the countertop or tabletop
where it can be pulled on by children or accidentally tripped over.
To avoid an electrical circuit overload, do not use another high-wattage
appliance on the same circuit with this appliance.

4
Parts and Features
*To order parts:
US: 1.800.851.8900
www.hamiltonbeach.com
Canada: 1.800.267.2826
Mexico: 01 800 71 16 100
BEFORE FIRST USE: Wash all removable parts in hot, soapy
water. Rinse and dry. Brew one cycle and discard water.
Removable Water
Reservoir
Frothing Nozzle
and Cover
Measuring Scoop
With Tamping Tool
Removable
Drip Tray Holder
Cup Warmer
Ground Espresso/Pod
Filter Holder
Espresso/Pod
Filter for 1 Cup
Espresso
Filter for 2 Cups
Frothing Nozzle
Wrench
Filter Holder
Locking Lever
Base
Brew Head Opening
Removable Drip Tray

5
Parts and Features (cont.)
ON/OFF Button
Control Knob
BREW Knob Position
STANDBY Knob Position
Amber ON Light Green READY Light
(for BREW and STEAM)
STEAM Knob Position

6
Before First Use (Priming the Pump)
6
4
Turn the control knob back to the
STANDBY position.
Turn the control knob to the
STEAM setting. Steam will
begin to flow from the steam
nozzle.
132
Plug in the unit and press the
ON/OFF button to turn unit
ON (I). The amber ON light will
illuminate.
The ready light will glow green
when the water is heated and unit
is ready for use. Place an empty
container under frothing nozzle in
order to catch any drips of water
from the steam nozzle.
Fill the removable water reservoir
to the MAX fill line with cold
water and replace securely on
the back of unit.
5
Allow steam to flow for about
2 minutes. NOTE: After the ready
light initially glows green, the
light may cycle on and off during
operation.
NOTICE: The water pump must be “primed” before
first use to work properly. Operating without water in
the reservoir can permanently damage the appliance.

7
Before First Use (cont.)
910 87
Place a container under brew
head—it should be wide enough
to catch water from both spouts.
Turn the control knob to BREW
and dispense one cup.
Turn the control knob back to the
STANDBY position. Press ON/OFF button to turn the unit OFF (O). The light next to the
button will turn off. Unplug the
unit.
Wash parts again with warm,
soapy water. Rinse and dry
thoroughly.
wWARNING Shock Hazard.
Do not immerse machine, cord,
or plug in water or any other
liquid. See Cleaning section on
page 15 for full instructions.

8
How to Use
21 3
Add 1 tablespoon (15 ml) of
ground espresso for each cup
being made. Use shallow filter
for 1 cup and deep filter for 2
cups. Press grounds firmly with
tamping tool and ensure no
grounds remain on the rim.
Align raised dimple on the
exterior of ground espresso/pod
filter with cutout notch on inside
of filter holder. Rotate filter holder
180º to secure.
Fill the removable water reservoir
to the MAX fill line with cold
water and replace securely on the
back of unit.
Place pod into filter. When using
an ESE (Easy Serving Espresso)
pod, always use the shallower
espresso/pod filter. Never put two
pods in either filter at one time.
3
NOTE: Ensure there are no grounds on the rim of the filter holder. This
prevents a proper seal from forming and may damage the machine.
OR

9
How to Use (cont.)
4
8
6
9
75
Pull down on the lever handle to
lock the filter holder into place.
The lever will be locked when it
is slightly below horizontal and
cannot be pushed down any
further.
Plug in and press the ON/OFF
button to turn unit ON (I). The
amber ON light will illuminate.
The ready light will glow green
when the water is heated and unit
is ready for use.
As espresso dispenses, it will
gradually look lighter in color.
Press ON/OFF button to turn the
unit off and to stop dispensing.
Allow espresso to drip from filter
holder for 15–20 seconds before
removing cup(s). This will make
about 1–1.5 oz. of espresso or a
total of 2–3 oz. if using the 2-cup
filter.
Place one or two cups under
brew head spouts. If using one
cup, use one wide enough to
catch espresso from both spouts.
Holding filter holder handle
securely, align locking tabs of
filter holder with the brew head
opening. Insert filter holder until it
slides all the way to the back and
cannot be pushed in any further.
Turn the control knob to BREW
to begin the flow of espresso.

10
How to Use (cont.)
1110 12
Wait about 1 minute before
unlocking the lever and removing
filter holder. This will allow any
water still flowing through the
pump to finish.
Push ON/OFF button to OFF (O).
Unplug unit from outlet.
Turn control knob back to the
STANDBY position.
NOTES:
• Some water may continue to
drip intermittently from brew
head. This is normal and a
result of product operation.
• This unit has a steam purge in
the drip tray that will cycle if
there is any water remaining in
the heater. Some steam may
escape under the drip tray—this
is normal.

11
How to Use (cont.)
13 15 1614
Keeping thumb on handle lever,
dispose of espresso grounds and/
or pod filter.
Ensure filter holder is cool. Align
raised dimple on espresso/pod
filter with cutout notch in filter
holder base; then remove.
Clean filter holder and brew head
after each use. See Cleaning
instructions on page 15. DO NOT
allow grounds to remain in filter
holder; this can clog filter holder
and cause unit to malfunction.
To empty espresso grounds
and/or an espresso pod from the
filter holder, flip the plastic lever
located on the handle of the filter
holder and hold the lever open.
wCAUTION Burn Hazard.
The metal parts of the filter
holder may be hot.
OR

12
How to Steam and Froth Milk
13 42
Plug in unit; press ON/OFF button
to begin heating water. The ready
light will glow green when the
water is heated and unit is ready
for use.
Fill a metal or ceramic cup 1/3
full with cold milk. A stainless
steel cup and skim milk are
recommended.
Hold cup underneath frothing
nozzle, leaving about 1/4 to
1/2 inch (0.6 to 1.3 cm) between
the nozzle and the bottom of
the cup.
Ensure there is water in the
removable water reservoir and
move the frothing nozzle to the
right of the unit.
wWARNING Burn Hazard. Vapor and
water emitted from frothing nozzle are hot.

13
How to Steam and Froth Milk (cont.)
57 86
TO STEAM: Milk is steamed
when the cup becomes warm to
the touch.
TO FROTH: Making sure there is
always milk covering the nozzle,
move cup up and down until
desired consistency is reached.
Froth should be stiff and
scoopable with a spoon.
Turn the control knob back to the
STANDBY position; then remove
cup from underneath frothing
nozzle.
NOTE: After each time steaming
and to prevent clogging nozzle,
hold a cup with water under
nozzle and “steam” into the cup
to clean.
Push ON/OFF button to OFF (O).
Unplug unit from outlet.
Turn the control knob to
STEAM . Steam will begin
to flow from the nozzle.

14
Recipes
Espresso
Brew one or two cups at a time following
directions. Optional: Add sugar to taste.
Cappuccino
Mix 1/3 espresso, 1/3 steamed milk, and
1/3 frothed milk. Top with ground nutmeg,
ground cinnamon, powdered chocolate or
vanilla to taste.
Latte
Mix 1/2 espresso with 1/2 steamed milk.
Top with ground nutmeg, ground cinnamon,
powdered chocolate or vanilla to taste.
Iced espresso, cappuccino, or latte
Mix beverage as described above; then pour
over ice.
Mocha
Mix 1 ounce thick chocolate syrup with 1/3
espresso. Fill with frothed or steamed milk.

15
Cleaning
3 421
Place a container under brew
head wide enough to catch water
from both spouts. Turn control
knob to BREW and dispense
at least 1 cup (237 ml) of water.
Make sure unit is turned on and
the green ready light illuminated.
Turn control knob to STEAM
position and let steam flow for
about 30 seconds into a cup;
then turn control knob back to
the STANDBY position.
Carefully wipe exterior and brew
head with warm water and damp
cloth.
Wash all parts with warm, soapy
water. Rinse and dry thoroughly.
No parts are dishwasher-safe.
Turn control knob back to
STANDBY position; then press
ON/OFF button to turn unit OFF
(O). Unplug the unit.
Allow unit to cool completely;
then remove cover of frothing
nozzle and wipe down nozzle
with a cloth.
Every other use: Remove nozzle
tip with wrench on tamping tool
and wash in warm, soapy water.
wWARNING Electrical Shock Hazard. Disconnect power before wiping exterior of
unit or brew head. Do not immerse cord, plug, or base in any liquid.
65

16
Tips for Making Espresso
• For best results, use fresh-ground, dark, espresso roast coffee.
• If espresso preground coffee is used, store the unused portion in an airtight container and keep in a cool, dark area for up to one
week.
• The grind of the coffee will affect the taste of the coffee and how the appliance works. If the grind is too coarse, water will flow too
fast through the coffee and result in a weaker flavor. If the grind is too fine, the flavor may be too strong or bitter, and the grounds may
clog the filter.
• For hotter espresso, preheat the filter holder, the ground espresso filter, and the pod filter by first brewing water into the cups for a few
seconds and then emptying the brewed water.
wCAUTION Burn Hazard. The metal parts of the filter holder may be hot.
• Espresso beans may be ground in a coffee grinder. For best results, use a coffee grinder on the fine setting. If grinding espresso in a
store or using a burr mill, then use a setting that is one to two notches coarser than the espresso setting.
• Grind your espresso so that it looks gritty, like salt or sand. It is too fine if it looks like powder and feels like flour. If the coffee is ground
too fine, then the water will not flow through the coffee.
• Espresso pods make it even easier to brew a great cup of espresso and cleanup is as easy as throwing out the used pod. Pods can be
purchased at many local coffee houses and specialty housewares stores. A Web search for “coffee pods” will also connect you with
many coffee pod suppliers.
• Always use cold water to make coffee. Warm water or other liquids could cause damage to the appliance.
• Filtered water will make the best-tasting coffee.

17
Troubleshooting
PROBLEM PROBABLE CAUSE/SOLUTION
Espresso will not flow out. • Is the water reservoir empty?
• Is the water reservoir properly fitted into position?
• Make sure that the coffee grounds are not overpacked in the filter.
• Is filter holder properly fitted into the espresso maker?
• Clean the filter, filter holder, and brew head.
• Holes in filter holder may be clogged. Clear with a toothpick or straightened paper clip.
Machine is noisy when operating. • Is the water reservoir empty?
• Is the water reservoir properly fitted into position?
• Is the filter holder properly fitted into position?
Espresso is too weak. • Always use fresh espresso ground coffee and tamp the ground coffee down firmly.
• The longer the brew time, the weaker the espresso (1 serving = 1 to 1 1/2 ounces [28–43 g]).
• Be sure there is sufficient ground coffee in the filter.
• Coffee grounds are too coarse.
• Try a different brand or roast of coffee.
Espresso is too strong or bitter. • Too much ground espresso was used.
• Grounds were too fine.
• Brew longer before turning control knob back to STANDBY.
Difficult to froth milk. • Always use fresh, cold milk (skim milk is recommended).
• Use a cold, stainless steel cup and move the cup slightly up and down while frothing.
• Clean the frothing nozzle.
• Trying to froth too much milk; reduce amount of milk in cup.

18
This warranty applies to products purchased and used in the U.S. and Canada. This is the only express warranty for this product and
is in lieu of any other warranty or condition.
This product is warranted to be free from defects in material and workmanship for a period of five (5) years from the date of original
purchase in Canada and one (1) year from the date of original purchase in the U.S. During this period, your exclusive remedy is repair
or replacement of this product or any component found to be defective, at our option; however, you are responsible for all costs
associated with returning the product to us and our returning a product or component under this warranty to you. If the product or
component is no longer available, we will replace with a similar one of equal or greater value.
This warranty does not cover glass, filters, wear from normal use, use not in conformity with the printed directions, or damage to
the product resulting from accident, alteration, abuse, or misuse. This warranty extends only to the original consumer purchaser or
gift recipient. Keep the original sales receipt, as proof of purchase is required to make a warranty claim. This warranty is void if the
product is used for other than single-family household use or subjected to any voltage and waveform other than as specified on the
rating label (e.g., 120V ~ 60 Hz).
We exclude all claims for special, incidental, and consequential damages caused by breach of express or implied warranty. All
liability is limited to the amount of the purchase price. Every implied warranty, including any statutory warranty or condition
of merchantability or fitness for a particular purpose, is disclaimed except to the extent prohibited by law, in which case such
warranty or condition is limited to the duration of this written warranty. This warranty gives you specific legal rights. You may have
other legal rights that vary depending on where you live. Some states or provinces do not allow limitations on implied warranties or
special, incidental, or consequential damages, so the foregoing limitations may not apply to you.
To make a warranty claim, do not return this appliance to the store. Please call 1.800.851.8900 in the U.S. or 1.800.267.2826 in Canada
or visit hamiltonbeach.com in the U.S. or hamiltonbeach.ca in Canada. For faster service, locate the model, type, and series numbers
on your appliance.
Limited Warranty

19
PRÉCAUTIONS IMPORTANTES
Pour utiliser un appareil électroménager, vous devez toujours prendre des mesures élémentaires de sécurité pour réduire le risque
d’incendie, d’électrocution et/ou de blessure corporelle, en particulier les mesures suivantes :
1. Lire toutes les instructions.
2. Cet appareil n’est pas destiné à être utilisé par des personnes (y
compris les enfants) dont les capacités physiques, sensorielles
ou mentales sont réduites, ou manquant d’expérience et
de connaissance, sauf si elles sont étroitement surveillées
et instruites sur l’utilisation de l’appareil par une personne
responsable de leur sécurité.
3. Une surveillance étroite est requise pour tout appareil utilisé par
ou près des enfants. Surveiller que les enfants ne jouent pas
avec l’appareil.
4. Ne pas toucher aux surfaces chaudes. Utiliser les poignées ou
les boutons. Prendre toutes les précautions nécessaires pour
éviter les risques de brûlures occasionnés par les surfaces
chaudes, les déversements de liquides chauds.
5. Pour éviter l’incendie, l’electrocution et les blessure corporelles,
ne pas immerger le cordon, la fiche ou la cafetière espresso dans
l’eau ou tout autre liquide.
6. Débrancher de la prise murale lorsque la cafetière espresso
n’est pas utilisée et avant le nettoyage. Laisser refroidir avant
d’installer ou de retirer des pièces et avant de la nettoyer.
7. L’appareil doit être utilisé sur une surface plane et loin du rebord
du comptoir pour prévenir les balancements accidentels.
8. Ne pas faire fonctionner un appareil électroménager avec un
cordon ou une fiche endommagée, ou lorsque l’appareil ne
fonctionne pas bien ou a été échappé ou endommagé d’une
manière quelconque. Le remplacement et la réparation du
cordon d’alimentation doivent être faits par le fabricant, son
agent de service ou toute personne qualifiée de façon à éviter
tout danger. Appeler le numéro de service à la clientèle fourni
pour des renseignements concernant l’examen, la réparation ou
l’ajustement.
9. L’utilisation d’accessoires non recommandés par le fabricant
d’électroménagers peut causer l’incendie, l’electrocution ou les
blessures corporelles.
10. Ne pas utiliser à l’extérieur.
11. Ne pas laisser pendre le cordon de la table ou du comptoir
et éviter tout contact avec les surfaces chaudes incluant la
cuisinière.
12. S’assurer que le porte-filtre est bien en place avant de
commencer l’infusion d’espresso. Des risques de brûlures
peuvent survenir si le porte-filtre est retiré pendant le cycle
d’infusion.
13. Ne pas placer cet appareil sur ou près d’une cuisinière électrique
ou à gaz ou dans un four chaud.
14. Pour débrancher l’appareil, tourner les boutons de réglage à OFF
(O/ARRÊT) puis débrancher la fiche de la prise murale.
15. AVERTISSEMENT ! Pour éviter les risques d’incendie et
d’électrocution, ne pas enlever le couvercle superieur ou
inférieur de la cafetière. Aucune pièce réparable à l’intérieur.
Les réparations doivent être faites par un technicien agréé
seulement.
16. N’utiliser cet appareil que pour les fonctions auxquelles il est
destiné.
CONSERVEZ CES INSTRUCTIONS

20
Autres renseignements relatifs à la sécurité du consommateur
Cet appareil est destiné à un usage domestique uniquement.
wAVERTISSEMENT Risque de choc électrique : Cet appareil est
fourni avec une fiche polarisée (une broche large) pour réduire le
risque d’électrocution. Cette fiche n’entre que dans un seul sens dans
une prise polarisée. Ne contrecarrez pas l’objectif sécuritaire de cette
fiche en la modifiant de quelque manière que ce soit ou en utilisant
un adaptateur. Si vous ne pouvez pas insérer complètement la fiche
dans la prise, inversez la fiche. Si elle refuse toujours de s’insérer, faire
remplacer la prise par un électricien.
La longueur du cordon installé sur cet appareil a été sélectionnée afin de
réduire les risques d’enchevêtrement ou de faux pas causés par un fil
trop long. L’utilisation d’une rallonge approuvée est permise si le cordon
est trop court. Les caractéristiques électriques de la rallonge doivent être
équivalentes ou supérieures aux caractéristiques de l’appareil. Prendre
toutes les précautions nécessaires pour installer la rallonge de manière
à ne pas la faire courir sur le comptoir ou sur une table pour éviter qu’un
enfant ne tire sur le cordon ou trébuche accidentellement.
Pour éviter la surcharge du circuit électrique, ne pas utiliser un autre
appareil à haute puissance sur le même circuit que cet appareil.
