Hamilton Beach 14010 User manual

Irons
Fer à repasser
Planchas
840182703
Le invitamos a leer cuidadosamente este
instructivo antes de usar su aparato.
READ BEFORE USE
À LIRE AVANT UTILISATION
LEA ANTES DE USAR
English ......................................................................................... 2
USA: 1-800-851-8900
Visit www.hamiltonbeach.com for our complete line of products and Use and Care
Guides – as well as delicious recipes, tips, and to register your product online!
Français ..................................................................................... 15
Canada : 1-800-267-2826
Rendez-vous sur www.hamiltonbeach.ca pour notre liste complète de produits et de nos
manuels utilisateur – ainsi que nos délicieuses recettes, nos conseils et pour enregistrer
votre produit en ligne !
Español ...................................................................................... 27
En México: 01-800-71-16-100
¡Visite www.hamiltonbeach.com.mx para obtener nuestra línea completa de productos y
las Guías de Uso y Cuidado, además de deliciosas recetas, consejos y para registrar su
producto en línea!
840182703 ENv01.indd 1840182703 ENv01.indd 1 10/2/12 2:41 PM10/2/12 2:41 PM

When using an iron, basic precautions should always be followed,
including the following:
READ ALL INSTRUCTIONS BEFORE USING
1. Only use an iron for its intended use.
2. To avoid the risk of electric shock, do not immerse the iron
in water or other liquids.
3. Always turn the iron to OFF (O) before plugging or unplugging
the iron from the electrical outlet. Never pull on the cord to
disconnect the iron from the electrical outlet; instead, grasp
the plug and pull on the plug to disconnect the iron.
4. Do not let the cord touch hot surfaces. Let the iron cool
completely before putting the iron away. Loop cord loosely
around iron when storing.
5. Always disconnect the iron from the electrical outlet before
filling the iron with water, emptying the water from the iron,
and when the iron is not in use.
6. Do not operate the iron with a damaged cord or in the event
the iron has been dropped or damaged or there are visible signs
of damage or it is leaking. To avoid the risk of electric shock,
do not disassemble the iron. Take it to a qualified serviceman for
examination and repair. Incorrect assembly might result in a risk
of electric shock when the iron is used after reassembly.
7. The iron must be used and rested on a stable surface.
8. When placing the iron on its stand, ensure that the surface
on which the stand is placed is stable.
9. Close supervision is required for any appliance used by or near
children. Do not leave the iron unattended while the iron is
connected or on an ironing board.
10. Burns can occur from touching hot metal parts, hot water, or
steam. Use caution when you turn a steam iron upside down—
there might be hot water in the reservoir.
11. To avoid a circuit overload, do not operate an iron on the same
circuit with another high-wattage appliance.
IMPORTANT SAFETY INSTRUCTIONS
2
840182703 ENv01.indd 2840182703 ENv01.indd 2 10/2/12 9:42 AM10/2/12 9:42 AM

3
This appliance is intended for household use only.
WARNING! Shock Hazard: This appliance has a polarized plug (one
wide blade) that reduces the risk of electric shock. The plug fits only
one way into a polarized outlet. Do not defeat the safety purpose of
the plug by modifying the plug in any way or by using an adapter.
If the plug does not fit fully into the outlet, reverse the plug. If it still
does not fit, have an electrician replace the outlet.
Use the iron on an ironing board. Ironing on any other surface may
damage that surface.
Do not iron or vertical steam clothes that are being worn.
Do not use vertical steam in the direction of people or pets.
Please Read Before First Use:
• During first use of the iron, it may appear to smoke. This will stop
and does not indicate a defect or hazard.
• Many irons spit or sputter during the first few uses with tap water.
This happens as the steam chamber becomes conditioned. This
will stop after a few uses.
• To clean steam vents before first use, prepare iron for steam
ironing; then iron over an old cloth for a few minutes while letting
the iron steam. Press the Blast of Steam button several times
to clean the vents. Then follow the Self-Cleaning instructions on
page 11.
SAVE THESE INSTRUCTIONS
12. If an extension cord is absolutely necessary, a cord with an
ampere rating equal to or greater than the maximum rating of
the iron shall be used. A cord rated for less amperage can result
in a risk of fire or electric shock due to overheating. Care shall
be taken to arrange the cord so that it cannot be pulled or be
tripped over.
Other Consumer Safety Information
840182703 ENv01.indd 3840182703 ENv01.indd 3 10/2/12 9:42 AM10/2/12 9:42 AM

Parts and Features
MAX
Steam
OFF
Position
Steam
ON
Position
4
Blast of
Steam Button
Water Fill
Opening
Adjustable
Steam
Control
Blast of
Steam Button
Self-Clean
Swivel
Power
Cord
Heel Rest
Temperature
Control Dial
Soleplate
Spray
Trigger
Power On
Light
840182703 ENv01.indd 4840182703 ENv01.indd 4 10/2/12 9:42 AM10/2/12 9:42 AM

5
This iron is equipped with a position/motion sensor. This
means that if the iron is left motionless it will turn off
automatically and cool to room temperature.
To restart iron, simply move the iron and allow it to reheat
on heel position.
The iron will reheat to the previously selected setting.
Iron Position
Resting on soleplate
Resting on either
side
Resting on heel
Sensor Control (available on some models)
Position Sensing
The iron will turn off automatically when left in the following
positions.
The auto off time varies based on the iron’s position.
Auto Shutoff Reset Light
After 30 seconds of no movement in the horizontal position,
the iron will automatically shut off and the red light will blink.
Move iron upright to vertical position to turn back on.
Motionless Time
30 seconds
30 seconds or
15 minutes
depending on
exact orientation
15 minutes
840182703 ENv01.indd 5840182703 ENv01.indd 5 10/2/12 9:42 AM10/2/12 9:42 AM

1. Plug the iron into outlet.
2. Set Adjustable Steam Control to
0 (Dry Iron).
3. Turn Temperature Control Dial to
desired temperature. Allow 2 minutes
for iron to reach desired temperature.
4. To turn iron off, turn Temperature
Control Dial to OFF and unplug iron.
To Dry Iron
6
Iron
High Temp
Setting Med Temp
Setting Low Temp
Setting
Fabric care labels on garments have symbols that show
ironing instructions and recommended temperature settings.
These symbols are shown below along with their meaning.
Do Not
Iron Do Not
Use Steam
DRY IRON: Synthetics, Silk/Wool (reverse side of fabric)
STEAM IRON: Cotton (while damp; use steam or spray)
Linen (while damp on reverse side of fabric)
NOTE: To prevent possible garment damage, we do not
recommend ironing fabrics labeled “Dry Clean Only.”
Fabric Care Label Symbols
840182703 ENv01.indd 6840182703 ENv01.indd 6 10/2/12 9:42 AM10/2/12 9:42 AM

7
1. Unplug iron. Set Adjustable Steam Control to 0 (Dry Iron).
Hold iron with soleplate parallel to the ground.
2. Using a cup, slowly pour tap water into water fill opening
until MAX fill line is reached. Do not fill iron directly from
the faucet.
3. Plug iron into outlet.
4. Turn Temperature Control Dial to desired fabric setting in
the steam range.
5. Allow 2 minutes for the iron to reach
desired temperature.
6. Set Adjustable Steam Control to
desired steam setting.
7. To turn iron off, set Set Adjustable
Steam Control to 0 (Dry Iron). Turn
the Temperature Control Dial to OFF.
Unplug iron.
8. Empty water from the iron following directions in “Care
and Cleaning.”
Water: Please use ordinary tap water. If you have extremely
hard water, alternate between tap water and distilled water
for use in the iron.
To Steam Iron
840182703 ENv01.indd 7840182703 ENv01.indd 7 10/2/12 9:42 AM10/2/12 9:42 AM

8
1. Follow Steps 1 through 5 in
“To Steam Iron.”
2. Hang garment in a location that is
not susceptible to damage from heat
or moisture. Do not hang in front of
wallpaper, window, or mirror.
3. Hold iron about 6 inches (15 cm) away
from garment and press and release
the Blast of Steam Button to steam out
wrinkles. Do not press Blast of Steam
Button more than once every 5 seconds.
4. To turn iron off, turn Temperature Control Dial to OFF.
Unplug iron.
5. Empty water from the iron following directions in “Care
and Cleaning.”
NOTICE: Do not allow hot soleplate to touch delicate
garments.
To Vertical Steam
840182703 ENv01.indd 8840182703 ENv01.indd 8 10/2/12 9:42 AM10/2/12 9:42 AM

9
Power On Light
The red light stays on even
if Temperature Control Dial
is turned to OFF. Light flashes
if position sensor is activated.
Blast of Steam Button
Push Blast of Steam Button for
an extra blast of steam.
Adjustable Steam Control
This control adjusts the steam
to desired steam level.
Features
840182703 ENv01.indd 9840182703 ENv01.indd 9 10/2/12 9:42 AM10/2/12 9:42 AM

10
Care and Cleaning
Iron Storage
1. The water tank of your iron should be emptied after each
use. Turn Temperature Control Dial to OFF. Unplug the
iron and hold over a sink. Slowly tilt pointed end of iron
down over sink. Water will run out of water fill opening.
2. After iron has completely cooled, wrap cord loosely around
iron and store in an upright position. Do not store iron
laying flat on soleplate.
Soleplate
1. Never iron over zippers, pins, metal rivets, or snaps, since
these may scratch the soleplate.
2. To clean occasional buildup on the soleplate, wipe with
a sudsy cloth. Do not use abrasive cleansers or metal
scouring pads.
3. Always store iron upright in the heel rest position.
Spray Trigger
Press Spray Trigger to release
a fine spray of water for difficult
wrinkles in cotton or linen.
Features (cont.)
