Hamlet HRDSL512P4 User manual

Router ADSL2+ Modem/Router
Router ADSL2+ Switch 4 Porte
Quick Start Guide
www.hamletcom.com

For more detailed instructions on configuring and using
the ADSL2+ Modem/Router, please refer to the on-line
manual.
Package Contents
ADSL2+ Modem/Router
CD-ROM containing the on-line manual
RJ-11 ADSL/telephone Cable
Ethernet (CAT-5 LAN) Cable
AC-DC power adapter (12VDC, 1A) for (Wireless) ADSL Router with 4-port Switch
AC-AC power adapter (12VAC, 1A) forADSL Modem/Router with Single Ethernet Port
This Quick Start Guide
Warning
 Do not use the ADSL2+ Modem/Router in high humidity or high
temperatures.
 Do not use the same power source for the
A
DSL2+
Modem/Router as other equipment.
 Do not open or repair the case yourself. If theADSL2+
Modem/Router is too hot, turn off the power immediately and
have it repaired at a qualified service center.
 Avoid using this product and all accessories outdoors.
A
ttention
 Place the ADSL2+ Modem/Router on a stable surface.
 Only use the power adapter that comes with the package. Using
a different voltage rating power adaptor may damage the router.
1

Quick Start Guide
The Front LEDs
ADSL2+ Router with 4-port Switch
ADSL2+ Modem/Router with Single Ethernet Port
LED Meaning
1 PPP : Lit steady when there is a PPPoA / PPPoE connection.
2 ADSL: Lit when successfully connected to an ADSL DSLAM (“linesync”).
3 LAN Port: Lit when connected to an Ethernet device.
Green for 100Mbps; Orange for 10Mbps.
Blinking when data is Transmitted / Received.
4 WLAN :
(Wireless
only)
Lit green when the wireless connection is established.
Flashes when sending/receiving data.
5 SYS : Lit when the system is ready.
6 PWR : Lit when power is ON.
2

The Rear Ports
HRDSL512P4
3
2 45
3
HRDSL512
5 2
43
Port Meaning
1 Power Switch Power ON/OFF switch
2 PWR Connect the supplied power adapter to this jack.
3 RESET
After the device is powered on, press it to reset the device or
restore to factory default settings.
0-3 seconds: reset the device
6 seconds above: restore to factory default settings (this is used
when you can not login to the router, e.g. forgot the password)
4 LAN
(RJ-45
connector)
Connect a UTP Ethernet cable (Cat-5 or Cat-5e) to one of the four
LAN ports when connecting to a PC or an office/home network of
10Mbps or 100Mbps.
5 ADSL(LINE) Connect the supplied RJ-11 (“telephone”) cable to this port when
connecting to the ADSL/telephone network.

Quick Start Guide
Connect ADSL2+ Modem/Router
1. Connect the Router to a LAN (Local Area Network) and the ADSL/telephone (LINE) network.
HRDSL512P4
HRDSL512
2. Power on the device.
3. Make sure the PWR and SYS LEDs are lit steadily and that the relevant LAN LED is lit.
4

Configuring PC in Windows XP
1. Go to Start / Control Panel (in Classic
View). In the Control Panel, double-click on
Network Connections
2. Double-click Local Area Connection.
3. In the Local Area Connection Status
window, click Properties.
4. Select Internet Protocol (TCP/IP) and click
Properties.
5. Select the Obtain an IP address
automatically and the Obtain DNS server
address automatically radio buttons.
6. Click OK to finish the configuration.
5

Quick Start Guide
Configuring PC in Windows 2000
1. Go to Start / Settings / Control Panel. In the Control
Panel, double-click on Network and Dial-up
Connections.
2. Double-click Local Area Connection.
3. In the Local Area Connection Status
window click Properties.
4. Select Internet Protocol (TCP/IP) and click
Properties.
5. Select the Obtain an IP address
automatically and the Obtain DNS server
address automatically radio buttons.
6. Click OK to finish the configuration.
6

Configuring PC in Windows 98/Me
1. Go to Start / Settings / Control Panel. In
the Control Panel, double-click on Network
and choose the Configuration tab.
2. Select TCP/IP ->
NE2000 Compatible, or the name of your
Network Interface Card (NIC) in your PC.
3. Select the Obtain an IP address
automatically radio button.
4. Then select the DNS Configuration tab.
5. Select the Disable DNS radio button and
click OK to finish the configuration.
7

Quick Start Guide
Configuring PC in Windows NT4.0
1. Go to Start / Settings / Control Panel. In
the Control Panel, double-click on Network
and choose the Protocols tab.
2. Select TCP/IP Protocol and click
Properties.
3. Select the Obtain an IP address from a
DHCP server radio button and click OK.
8

Configuring Your ADSL Firewall Router
To configure this device, you must have IE 5.0 / Netscape
4.5 or above installed
1. Open the web browser and type
http://192.168.1.254 in the browser’s
address box. This number is the default IP
address for this router. Press Enter.
2. A username and password window will
appear. The default username and
password are admin and Hamlet.
Press OK to proceed.
3. You will get a status report on web page.
9
