HAMPTON BAY 518-132 User manual

1
INSTRUCTION MANUAL
CHANDELIER FIXTURE
Brushed Nickel Finish
Chrome Finish
Home Depot SKU 518-132 (UPC 008938601863)
Home Depot SKU 526-920 (UPC 008938601962)

2
Thankyouforpurchasing thisHamptonBayinteriorchandelierfixture.Thisproducthasbeen
manufacturedwiththehigheststandards ofsafetyandquality.
FEATURES:
1. Uses120 volt,60 WattMAXeach,standard(A19)incandescentorcandelabra(B10.5)lightbulb(s)
(notincluded).
2. Standard96inwireand72 inchainforopenentry-way,dining room,andcathedralceiling installations.
3. Canbeusedwithanystandard, 120 volt, incandescentstyledimmerswitch.
QUESTIONS, PROBLEMS,MISSINGPARTS:
BeforereturningtoyourlocalHomeDepot,pleasecallourCustomerServiceTeamat1-877-527-0313 or
visit www.homedepot.com.Pleasereference SKU 518-132,UPC008938601863orSKU526-920,UPC
008938601962.
IMPORTANTSAFETYINSTRUCTIONS
INSTALLATIONINSTRUCTIONSPERTAININGTORISKOFFIREORINJURY TOPERSONS
1. Readall instructions.
2. Donotinstall thislightingsysteminwetlocations.
3. CAUTION -Whenthelightison,thelampisHOT!
4. CAUTION -Hotsurface. Keepawayfromcurtainsandothercombustiblematerials.
5. Turnoff/unplug andallowtocoolbeforereplacingbulb(lamp).
6. AllelectricalconnectionsmustbeinaccordancewithlocalcodesandtheNationalElectricalCode.If
youareunfamiliarwithmethodsofinstalling electricalwiring,securetheservicesofaqualified
licensedelectrician.
7. Thisfixtureisintendedtobemountedtoa4in.squarex2-1/8in.deepmetaloctagonoutletbox.The
boxmustbedirectlysupportedbythebuildingstructure.
8. Beforestartingtheinstallation,disconnectthepowerbyturningoff thecircuitbreakerorbyremoving
theappropriatefuseatthefusebox.Turningthepoweroff using thelightswitchisnotsufficientto
preventelectricalshock.
SAVETHESEINSTRUCTIONS
TOOLSREQUIREDFORASSEMBLY&INSTALLATION(notincluded):
BulbSafetyGogglesLadderGlovesWireStrippersFlatheadPhillips
Electricaltape
ScrewdriverScrewdriver
PARTSINCLUDEDFORASSEMBLY(parts arenottoscale):
(2)OutletBox(3)WireMountingCeiling CanopyLoopringFabricshadeSocketring
ScrewsConnectorsbracketassembly canopy loop
FIXTUREBODYASSEMBLYINSTRUCTIONS
1. Carefullyunpackthefixtureandlayoutall oftheparts onacleansurface.
2. Firstdistributethebenttubesfromfixturetothree orfivepartsequalseparately.
3. Securethecolumnintothecouplerandtighteninplace.
4. Installthefabricshadeontothesocketandtightenwiththesocketring(preassemblyontothesocket).
CEILINGASSEMBLYINSTRUCTIONS
1. Makesuretheelectricalispoweroff, pullleadsdownoutofjunctionbox.
2. Adjustthelengthofthechainaccordingtothedesiredheightbyremoving unnecessarylinks.
3. Threadthefixturewireandtheground(bare)wirethroughthechain,feeding itthroughalternating
links,thenthroughthecanopyloop.Loosentheloopringonthecanopyloopandallowringtoslide
downoverthechain.
4. Slidethecanopyoverthecanopyloopandthechain(leaveringandcanopylooseonchainatthistime).
5. Insertandsecurethethreadednippleintothecanopyloop.
6.Attachthemountingstraptotheoutletboxusingthetwooutletboxscrewsprovided.
7.Raisetheassembledfixturetoallowforinstallationtojunctionbox(itishighlyrecommendedtousea

3
secondpersontohelpsupporttheweightofthefixturefrombelowwhilethewiring connectionsare
being made).Feedthewireandgroundwirethroughtheholeinthecenterofthemountingstrapand
rotatethethreadednipple,canopyloopandpreassembledfixtureclockwiseuntilthethreadednippleis
secureinthemountingstrap.Makesurethefixturecableandgroundwiresarenottwistedduringthis
process.
8.Wrapthegroundwireunderandaroundthegroundscrewwhichismarked GND”,andfastenthe
groundscrewtomakesurethegroundwireissecurelyconnected.
9. MaketheELECTRICALCONNECTIONS(RequiredSupplyCircuit: 120V, 60Hz):
a. Connectthenegative(raisedribswithoutwriting)wirefromthefixturetothenegativewirefrom
theOutletBox.
b. Connectthepositive(smoothwithwriting)wirefromthefixturetothepositivewirefromthe
OutletBox.
c. Connecttheground(bare)wirefromthefixturetothegroundwirefromtheOutletBox.
d. Securetheconnectionsusing thewireconnectors.Wrapthewireconnectionswithelectrical
tapetosecuretheconnections.
e. Positionthewiresbackinsidetheoutletbox.
Note: Ifyouhaveelectricalquestions,consultyourlocalelectricalcodeforapprovedgroundingmethods
orobtaintheservicesofaqualified,licensedelectrician.
10.Slidethecanopybackoverthecanopyloopandtightentoceiling using theloopring(Adjustthe
lengthofthethreadednippleifnecessary).
11. Checktomakesurethecanopyisheldfirmlyagainsttheceiling.
12.Screwthebulb(notincluded)intothelamp-socket.
Caution:Refertothere-lampinglabelnearthelampholderforrecommendedwattage.
13.Installationiscomplete.Turnonthepoweratthecircuitbreakerorfusebox.
ASSEMBLYDIAGRAM:
1.
Outlet Box
2.Wireconnector
3. Ground(Bare)Wire
4. Mountingstrap
5. Groundscrew
6. Negativewire
7. Positivewire
8. Hexnut
9.Threadednipple
10.Outlet BoxScrew
11. Canopy
12.Canopyloop
13.Ring
14.Chain
15.Fixtureloop
16.Column
17.Coupler
18.Benttube
19.Socket
20.Fabricshade
21.Socketring
22.Bulb
1
2
3
4
6
10
11
8
9
7

4
TROUBLE SHOOTING:
PRODUCT MAINTENANCE:
1. To clean the outside of the fixture, use a dry or slightly dampened clean cloth (use clean water,
never a solvent) to wipe the shade and surface of the fixture.
2. To clean the inside of the fixture, first disconnect power to the fixture by turning off the circuit
breaker or by removing the fuse at the fuse box. Use a dry or slightly dampened clean cloth (use
clean water, never use a solvent) to wipe the inside glass and interior surface of the fixture.
CAUTION: Do not use any cleaners with chemicals, solvents or harsh abrasives as damage to components
or finish may occur.
LIMITED WARRANTY
The manufacturer warrants this lighting fixture to be free from defects in materials and workmanship for a
period of five (5) years from date of purchase. This warranty applies only to the original consumer
purchaser and only to products used in normal use and service. If this product is found to be defective, the
manufacturer＇s only obligation, and your exclusive remedy, is the repair or replacement of the product at
the manufacturer＇s discretion, provided that the product has not been damaged through misuse, abuse,
accident, modifications, alterations, neglect or mishandling. This warranty shall not apply to any product
that is found to have been improperly installed, set-up, or used in any way not in accordance with the
instructions supplied with the product. This warranty shall not apply to a failure of the product as a result of
an accident, misuse, abuse, negligence, alteration, or faulty installation, or any other failure not relating to
faulty material or workmanship. This warranty shall not apply to the finish on any portion of the product,
such as surface and/or weathering, as this is considered normal wear and tear. The manufacturer does not
warrant and specially disclaims any warranty, whether express or implied, of fitness for a particular
purpose, other than the warranty contained herein. The manufacturer specifically disclaims any liability
and shall not be liable for any consequential or incidental loss or damage, including but not limited to any
labor / expense costs involved in the replacement or repair of said product.
Problem
Possible Cause
Corrective Action
1. Light bulb is burned out. 1. Replace light bulb.
2. Power is off. 2. Make sure power supply is on.
3. Faulty wire connection. 3. Check wiring.
Light bulb will not
illuminate.
4. Faulty switch. 4. Test or replace switch.
Fuse blows or circuit
breaker trips when light
bulb is illuminated.
Crossed wires or power wire is
grounding out. Check wire connections.
