HAMPTON BAY H15 Quick start guide

FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4918-516c
MODELS: H15-NG1 Natural Gas H15-LP1 Propane
04/12/11
H15 Direct Vent Gas Fireplace
Owners &
Installation Manual
WARNING:
If the information in these instructions are not
followed exactly, a fire or explosion may result
causing property damage, personal injury or loss
of life.
FOR YOUR SAFETY
Do not store or use gasoline or other flammable
vapours and liquids in the vicinity of this or any
other appliance.
Installation and service must be performed by
a qualified installer, service agency or the gas
supplier.
FOR YOUR SAFETY
What to do if you smell gas:
Do not try to light any appliance
Do not touch any electrical switch:
do not use any phone in your
building.
Immediately call your gas supplier
from a neighbour's phone. Follow
the gas supplier's instructions.
If you cannot reach your gas sup-
plier, call the fire department.
This appliance may only be
installed in an aftermarket
permanently located, manu-
factured(USAonly)ormobile
home,wherenotprohibitedby
local codes.
This appliance is only for use
with the type of gas indicated
on the rating plate. This ap-
pliance is not convertible for
use with other gases, unless
a certified kit is used.
Tested by: Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
www.hampton-fire.com

2Hampton® H15-1 Direct Vent Freestanding Gas Stove
HAMPTON®
Direct Vent Freestanding Gas Stove
To the New Owner:
Congratulations!
You are the owner of a state-of-the-art Hampton®Gas Stove by FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. The
H15-1 is a hand crafted appliance and has been designed to provide you with all the warmth and charm of a wood fireplace
at the flick of a switch. The model H15-1 has been approved by Warnock Hersey for both safety and efficiency. As it also
bears our own mark, it promises to provide you with economy, comfort and security for many trouble free years to follow.
Please take a moment now to acquaint yourself with these instructions and the many features of your Hampton®Stove.

Hampton® H15-1 Direct Vent Freestanding Gas Stove 3 Hampton® H15-1 Direct Vent Freestanding Gas Stove 3
SAFETY LABELDIMENSIONS
UNIT DIMENSIONS

4Hampton® H15-1 Direct Vent Freestanding Gas Stove
DIMENSIONS
Conversion from NG to LP ..........................................31
Log Set Installation......................................................34
Optional Wall Thermostat ...........................................36
Optional Remote Control ............................................36
Final Check..................................................................36
Wiring Diagrams..........................................................37
OPERATING INSTRUCTIONS
Operating Instructions .................................................39
Lighting Procedure ......................................................39
Shutdown Procedure...................................................39
First Fire ......................................................................39
Adjusting Flame Height ...............................................39
Automatic Convection Fan Operation..........................39
Copy of the Lighting Plate Instructions .......................40
Normal Operating Sounds of Gas Appliances.............41
MAINTENANCE
Maintenance Instructions.............................................41
Pilot Adjustment...........................................................41
Fan Maintenance.........................................................42
General Vent Maintenance..........................................42
Log Replacement ........................................................42
Glass Replacement.....................................................42
Removing Valve...........................................................43
Installing Valve Assembly ............................................43
PARTS LIST
Main Assembly ............................................................44
Burner & Log Assembly...............................................45
WARRANTY
Warranty......................................................................47
DIMENSIONS
Unit Dimensions ............................................................3
SAFETY LABEL
Copy of Safety Decal.....................................................5
REQUIREMENTS
MA Code - CO Detector.................................................5
INSTALLATION
Important Message ......................................................7
Specifications ................................................................7
Manufactured Homes After First Sale............................7
Before You Start ............................................................7
General Safety Information............................................8
Installation Checklist......................................................8
Clearances to Combustibles..........................................9
Locating Your Gas Stove...............................................9
Manufactured Mobile Home Additional Requirements ..9
Combustion and Ventilation Air......................................9
Optional Fan Installation..............................................10
Venting Introduction.....................................................12
Installation Precautions ...............................................12
Safety Precautions for the Installer..............................12
Vent Restrictor Position...............................................12
Rotating Elbow ............................................................12
Exterior Vent Terminal Locations.................................13
4” x 6-5/8” Rigid Pipe ..................................................14
Cross Reference Chart................................................14
Rigid Pipe Venting Systems ........................................16
Venting Arrangements.................................................19
Vertical Termination with Co-linear Flex System .........20
DV Stove Horizontal Vent Kit.......................................21
Residential and Manufactured Homes ......................23
Minimum Horizontal Termination Installations.............23
Dura-Vent Termination Kit............................................24
Horizontal terminations................................................25
Vertical Terminations ...................................................26
Converting Class-A Metal Chimney or
Masonry Chimney to Direct Vent System...................28
Cathedral Ceilings.......................................................29
High Elevation .............................................................29
Gas Connection...........................................................29
Aeration Adjustment ....................................................30
Gas Pipe Pressure Testing..........................................30

Hampton® H15-1 Direct Vent Freestanding Gas Stove 5
SAFETY LABEL
This is a copy of the label that accompanies
each Direct Vent Freestanding Gas Stove.
We have printed a copy of the contents here
for your review.
NOTE: Hampton®units are constantly being
improved. Check the label on the unit and if
there is a difference, the label on the unit is
the correct one.
For the State of Massachusetts, installation and repair must be done by a plumber or gasfitter licensed in the Commonwealth of Massachusetts.
For the State of Massachusetts, flexible connectors shall not exceed 36 inches in length.
For the State of Massachusetts, the appliances individual manual shut-off must be a t-handle type valve.
The State of Massachusetts requires the installation of a carbon monoxide alarm in accordance with NFPA 720 and a CO alarm with battery back
up in the same room where the gas appliance is installed.
C 2" / 50mm
E 2" / 50mm
A 6" / 150mm
B 0" / 0mm
Minimum ceiling height from top of unit: mm
Minimum plafond hauteur en haut de
l'appareil: 24"/610mm
24"/610
Minimum clearance of Vent Terminal
to Outside Corner & Inside Corner:
with AstroCap 6"/150mm
with Dura-Vent Cap 12"/300mm
E
E
A
AA
B
36” max 36” max
Left Side Wall
Right Side Wall
Horizontal
Pipe
5" WC/C.E. (1.25 kPa)
3.8" WC/C.E. (0.94 kPa)
1.1" WC/C.E. (0.27 kPa)
Minimum supply pressure
Manifold pressure High
Manifold pressure Low
Maximum Input
Minimum Input
Orifice size
Altitude
Pression d’allimentation minimum
Pression la tubulure d' chappement lev e
Pression la tubulure d' chappement basse
àééé
àé
18,000 Btu/h (5.28 Kw/h)
10,500 Btu/h (3.08 Kw/h)
#47 DMS
0-4500 ft/pi (0-1372m)
D bit Calorifique maximum
D bit Calorifique minimum
Dimensions de l'orifice
L'altitude
é
é
12" WC/C.E. (3.00 kPa)
11" WC/C.E. (2.74 kPa)
2.9" WC/C.E. (0.72 kPa)
Minimum supply pressure
Manifold pressure High
Manifold pressure Low
Maximum Input
Minimum Input
Orifice size
Altitude
Maximum Input
Minimum Input
Orifice size
Altitude
Pression d'allimentation minimum
Pression la tubulure d' chappement lev e
Pression la tubulure d' chappement basse
àééé
àé
18,000 Btu/h (5.28 Kw/h)
10,600 Btu/h (3.10 Kw/h)
#55 DMS
0-2000 ft/pi (0-610m)
15,500 Btu/h (4.54 Kw/h)
8,200 Btu/h (2.40 Kw/h)
#56 DMS
2000-4500 ft/pi (610-1372m)
D bit Calorifique maximum
D bit Calorifique minimum
Dimensions de l'orifice
L'altitude
é
é
D bit Calorifique maximum
D bit Calorifique minimum
Dimensions de l'orifice
L'altitude
é
é
A
Left Side Wall
Right Side Wall
C
Vertical
Pipe
See Manual for details
Model/Modele:
H15-LP1
Listed:
Certified for/Certifi e pour:
Tested to:
WN# 16443
CANADA and U.S.A.
CGA-2-17-M91, ANSI Z21.88a-2007 / CSA 2.33a-2007
VENTED GAS FIREPLACE HEATER / FOYER AU GAZ À ÉVACUATION
é
PROPANE GAS STOVE: Model H15-LP1
L
APPAREIL FONCTIONNANT AU PROPANE
CONCU POUR ETRE POELE: Modéle H15-LP1
MAY BE INSTALLED IN MANUFACTURED (MOBILE) HOMES AFTER FIRST SALE
DO NOT REMOVE THIS LABEL / NE PAS ENLEVER CETTE ÉTIQUETTE
301
DUPLICATE SERIAL NO.
FPI Fireplace Products International Ltd.
Delta, BC, Canada
Made in Canada/
Fabrique au Canada
Minimum Clearances to Combustibles /
Degagement Minimum
De Materiaux Combustibles
Serial No./ No de serie
918-494b
Electrical supply / Électrique 115VAC, 1.13 A, 60Hz.
This appliance must be installed in accordance with local codes, if any; if none, follow the National Fuel Gas Code, ANSI Z223.1, or Natural Gas and Propane Installation
Code, CSA B149.1.
This appliance must be installed in accordance with the Standard CAN/CSA Z240 MH, Mobile Housing, in Canada, or with the Manufactured Home Construction and Safety
Standard, Title 24 CFR, Part 3280, in the United States, or when such a standard is not applicable, ANSI/NCSBCS A225.1/NFPA 501A, Manufactured Home Installations
Standard orANSI A119.2 ou NFPA501C Standard for Recreational Vehicles
This appliance is only for use with the type of gas indicated on the rating plate and may be installed in an aftermarket, permanently located, manufactured (mobile) home where not
prohibited by local codes. See owner's manual for details.
Installer l'appareil selon les codes ou règlements locaux, ou, en l'absence de tels règlements, selon les codes d'installation ANSI Z223.1,National Fuel Gas Code ou CSA-B149.1
en vigueur.
Installer l'appareil selon la norme CAN/CSA-Z240, Série MM, Maison mobiles ou CAN/CSA-Z240 VC, Véhicules de camping, ou la norme 24 CFR Part 3280, Manufactured
Home Construction and Safety Standard. Si ces normes ne sont pas pertinentes, utilisez la norme ANSI/NCSBCS A225.1/NFPA 501A, Manufactured Home Installations
Standard, ouANSI A119.2 ou NFPA501C Standard for Recreational Vehicles.
For use with glass doors certified with the appliance only.
This vented gas fireplace heater is not for use with air filters. Ne pas utiliser de filtre à air avec ce foyer au gaz à évacuation.
Cet appareil doit être utilize uniquement avec le type de gaz indiqué sur la plaque signalétique. Cet appareil peut être installé dans une maison préfabriquée ou mobile (É.-U.
seulement) installée à demeure si les règlements locaux le permettent. Voir la notice de l'utilisateur pour plus de renseignements. Cet appareil ne peut pas être utilisé avec
d'autres gaz sauf si une trousse de conversion certifiée est fournie.
Pour utilisation uniquement avec les portes en verre certifiées avec l'appareil.
301
Model/Modele:
H15-NG1
NATURAL GAS STOVE: Model H15-NG1
L
APPAREIL FONCTIONNANT AU NATURAL GAS
CONCU POUR ETRE POELE: Modéle H15-NG1
VENTED GAS FIREPLACE HEATER - NOT FOR USE WITH SOLID FUELS.
NE PAS UTILISER AVEC DUCOMBUSTIBLE SOLIDE.FOYER AU GAZ À ÉVACUATION -

6Hampton® H15-1 Direct Vent Freestanding Gas Stove
REQUIREMENTS
5.08: Modifications to NFPA-54, Chapter 10
(2) Revise 10.8.3 by adding the following additional requirements:
(a) For all side wall horizontally vented gas fueled equipment installed in every dwelling, building or structure used in whole or in part for
residential purposes, including those owned or operated by the Commonwealth and where the side wall exhaust vent termination is less than
seven (7) feet above finished grade in the area of the venting, including but not limited to decks and porches, the following requirements shall
be satisfied:
1. INSTALLATION OF CARBON MONOXIDE DETECTORS. At the time of installation of the side wall horizontal vented gas fueled
equipment, the installing plumber or gasfitter shall observe that a hard wired carbon monoxide detector with an alarm and battery back-up is
installed on the floor level where the gas equipment is to be installed. In addition, the installing plumber or gasfitter shall observe that a battery
operated or hard wired carbon monoxide detector with an alarm is installed on each additional level of the dwelling, building or structure
served by the side wall horizontal vented gas fueled equipment. It shall be the responsibility of the property owner to secure the services of
qualified licensed professionals for the installation of hard wired carbon monoxide detectors
a. In the event that the side wall horizontally vented gas fueled equipment is installed in a crawl space or an attic, the hard wired carbon
monoxide detector with alarm and battery back-up may be installed on the next adjacent floor level.
b. In the event that the requirements of this subdivision can not be met at the time of completion of installation, the owner shall have a period of
thirty (30) days to comply with the above requirements; provided, however, that during said thirty (30) day period, a battery operated carbon
monoxide detector with an alarm shall be installed.
2. APPROVED CARBON MONOXIDE DETECTORS. Each carbon monoxide detector as required in accordance with the above provisions
shall comply with NFPA 720 and be ANSI/UL 2034 listed and IAS certified.
3. SIGNAGE. A metal or plastic identification plate shall be permanently mounted to the exterior of the building at a minimum height of eight
(8) feet above grade directly in line with the exhaust vent terminal for the horizontally vented gas fueled heating appliance or equipment. The
sign shall read, in print size no less than one-half (1/2) inch in size, "GAS VENT DIRECTLY BELOW. KEEP CLEAR OF ALL
OBSTRUCTIONS".
4. INSPECTION. The state or local gas inspector of the side wall horizontally vented gas fueled equipment shall not approve the installation
unless, upon inspection, the inspector observes carbon monoxide detectors and signage installed in accordance with the provisions of 248 CMR
5.08(2)(a)1 through 4.
(b) EXEMPTIONS: The following equipment is exempt from 248 CMR 5.08(2)(a)1 through 4:
1. The equipment listed in Chapter 10 entitled "Equipment Not Required To Be Vented" in the most current edition of NFPA 54 as adopted by
the Board; and
2. Product Approved side wall horizontally vented gas fueled equipment installed in a room or structure separate from the dwelling, building or
structure used in whole or in part for residential purposes.
(c) MANUFACTURER REQUIREMENTS - GAS EQUIPMENT VENTING SYSTEM PROVIDED. When the manufacturer of Product
Approved side wall horizontally vented gas equipment provides a venting system design or venting system components with the equipment, the
instructions provided by the manufacturer for installation of the equipment and the venting system shall include:
1. Detailed instructions for the installation of the venting system design or the venting system components; and
2. A complete parts list for the venting system design or venting system.
(d) MANUFACTURER REQUIREMENTS - GAS EQUIPMENT VENTING SYSTEM NOT PROVIDED. When the manufacturer of a
Product Approved side wall horizontally vented gas fueled equipment does not provide the parts for venting the flue gases, but identifies
"special venting systems", the following requirements shall be satisfied by the manufacturer:
1. The referenced "special venting system" instructions shall be included with the appliance or equipment installation instructions; and
2. The "special venting systems" shall be Product Approved by the Board, and the instructions for that system shall include a parts list and
detailed installation instructions.
(e) A copy of all installation instructions for all Product Approved side wall horizontally vented gas fueled equipment, all venting instructions,
all parts lists for venting instructions, and/or all venting design instructions shall remain with the appliance or equipment at the completion of
the installation.
MA Code - CO Detector
(for the State of Massachusetts only)

Hampton® H15-1 Direct Vent Freestanding Gas Stove 7
INSTALLATION
IMPORTANT MESSAGE
SAVE THESE
INSTRUCTIONS
The Direct Vent Freestanding Gas Stove must
be installed in accordance with these instruc-
tions. Carefully read all the instructions in this
manualfirst.Consultthebuildingauthorityhaving
jurisdiction to determine the need for a permit
prior to starting the installation.
Note: Failuretofollowtheinstructionscould
cause a malfunction of the heater
which could result in death, serious
bodilyinjury,and/orpropertydamage.
Failure to follow these instructions
mayalsovoidyourfireinsuranceand/
or warranty.
Note: These instructions take precedence
overSimpsonDura-Ventinstructions.
SPECIFICATIONS
Fuels: H15-NG1 is approved for use with
natural gas.
H15-LP1 is approved for use with
liquefied petroleum gases (propane).
Electrical: 120V A.C. system.
Optional Circulation Fan:
Variable speed, 125/75.
Log Sets: Ceramic fibre, 4 per set.
Vent System: Coaxial (6-5/8" outer / 4" inner
liner) rigid flue and termination cap.
MOBILE /
MANUFACTURED
HOMES AFTER
FIRST SALE
This Hampton®product has been tested and
listed by ITS Testing Services as a Direct Vent
Room Heater to the following standards:
CGA-2.17-M91, and ANSI Z21.88a-2007/CSA
2.33a-2007.
This Direct Vent System Appliance must be
installed in accordance with the manufacturer's
installation instructions and the Manufactured
Home Construction and Safety Standard, Title
24 CFR, Part 3280, or the current Standard of
Fire Safety Criteria for Manufactured Home In-
stallations, Sites, and CommunitiesANSI/NFPA
501A,andwithCAN/CSAZ240-MHMobileHome
Standard in Canada.
This appliance installation must comply with the
manufacturer's installation instructions and local
codes, if any. In the absence of local codes follow
the current National Fuel Gas Code, ANSI Z223.1
andthecurrentNationalElectricalCodeANSI/NFPA
70 in the U.S.A., and the current CAN/CGA B149
Gas Installation Code and the current Canadian
Electrical Code CSA C22.1 in Canada.
BEFORE YOU START
Safe installation and operation of this appliance re-
quirescommonsense,however,wearerequiredby
theCanadianSafetyStandardsandANSIStandards
to make you aware of the following:
CLOTHING OR OTHER FLAMMABLE
MATERIAL SHOULD NOT BE PLACED
ON OR NEAR THE APPLIANCE.
INSTALLATION AND REPAIR SHOULD
BE DONE BY AN AUTHORIZED
SERVICE PERSON. THE APPLIANCE
SHOULD BE INSPECTED BEFORE
USE AND AT LEAST ANNUALLY BY A
PROFESSIONAL SERVICE PERSON.
MORE FREQUENT CLEANING MAY BE
REQUIRED DUE TO EXCESSIVE LINT
FROMCARPETING,BEDDINGMATERIAL,
ETC. IT IS IMPERATIVE THAT CONTROL
COMPARTMENTS, BURNERS AND
CIRCULATING AIR PASSAGEWAYS OF
THE APPLIANCE BE KEPT CLEAN.
DUE TO HIGH TEMPERATURES, THE
APPLIANCE SHOULD BE LOCATED
OUT OF TRAFFIC AND AWAY FROM
FURNITURE AND DRAPERIES.
WARNING: FAILURE TO INSTALL THIS
APPLIANCE CORRECTLY WILL VOID
YOUR WARRANTY AND MAY CAUSE A
SERIOUS HOUSE FIRE.
YOUNG CHILDREN SHOULD BE CARE-
FULLY SUPERVISED WHEN THEY ARE
IN THE SAME AREA AS THE APPLI-
ANCE. TODDLERS,YOUNG CHILDREN
AND OTHERS MAY BE SUSCEPTIBLE
TO ACCIDENTAL CONTACT BURNS. A
PHYSICAL BARRIERS IS RECOMMEND-
ED IFTHERE ARE AT RISK INDIVIDUAL
INTHE HOUSE. TO RESTRICT ACCESS
TO A FIREPLACE OR STOVE, INSTALL
AN ADJUSTABLE SAFETY GATE TO
KEEP TODDLERS, YOUNG CHILDREN
AND OTHER AT RISK INDIVIDUALS OUT
OF THE ROOM AND AWAY FROM HOT
SURFACES.
CHILDREN AND ADULTS SHOULD BE
ALERTED TO THE HAZARDS OF HIGH
SURFACE TEMPERATURES, ESPE-
CIALLY THE FIREPLACE GLASS, AND
SHOULD STAY AWAYTO AVOID BURNS
OR CLOTHING IGNITION.
This Hampton®Mobile/Manufactured
Home Listed appliance comes factory
equipped with a means to secure the unit.
ThisHampton®Mobile/ManufacturedHome
listed appliance comes equipped with a
dedicated #8 ground lug to which an 18
gauge copper wire from the steel chassis
ground must be attached.
Thisappliancemayonlybeinstalledinan
aftermarketpermanentlylocated,manu-
factured (USA only) or mobile home,
where not prohibited by local codes.
This appliance is only for use with the
typeofgas indicated ontheratingplate.
Thisappliance isnotconvertible foruse
with other gases, unless a certified kit
is used.

8Hampton® H15-1 Direct Vent Freestanding Gas Stove
INSTALLATION
1) Provide adequate clearances for servicing,
proper operation and around the air openings
into the combustion chamber.
2) Theappliancemustbeinstalledonaflat,solid,
continuous surface (e.g. wood, metal, con-
crete).Thismaybethefloor,oritcanbe raised
up on a platform to enhance its visual impact.
The appliance may be installed on carpeting,
tile,woodflooringorothercombustiblematerial,
because the appliance's base extends the full
width and depth of the appliance. The Direct
Vent Freestanding Gas Stove can be installed
in a wide variety of ways and will fit nearly any
room layout. It may be installed in a recessed
position, framed out into the room, or across
a corner.
3) The Direct Vent Freestanding Gas Stove is
approved for alcove installations, which meet
the clearances listed in the "Clearance to
Combustibles" section. This unit is approved
for manufactured home installations, see the
"Manufactured Mobile Home Additional Re-
quirements"and"RigidPipeVentingSystems"
sections for the required vent arrangements.
If installed into a manufactured home the unit
must be bolted down to the floor.
4) This appliance is Listed for bedroom instal-
lations when used with a Listed Millivolt
Thermostat. Some areas may have further
requirements,check local codesbefore instal-
lation.
5) ThisapplianceisListedforAlcoveinstallations,
maintain minimum Alcove clearances as fol-
lows, minimum width of 32-1/2" (825mm), a
maximumdepthof36"(914mm),andminimum
heightof24"(610mm)fromtopofunittoceiling.
6) We recommend that you plan your installa-
tion on paper using exact measurements for
clearances and floor protection before actu-
ally installing this appliance. Have a qualified
building inspector review your plans before
installation.
GENERAL SAFETY
INFORMATION
1) The appliance installation must conform with
local Canadian Electrical Code.
2) The appliance when installed, must be electri-
callygroundedinaccordancewithlocalcodes,
orintheabsenceoflocalcodeswiththecurrent
NationalElectricalCode,ANSI/NFPA70orCSA
C22.1 Canadian Electrical Code.
3) The applianceshouldbeinspectedforshipping
damagebeforeuseandservicedannuallyby
aprofessionalserviceperson.Morefrequent
cleaning may be required due to excessive
lint from carpeting, bedding material, etc. It
is imperative that control compartments, and
circulating air passageways of the appliance
bekeptcleanandfreefromexcessivelintfrom
carpeting.
4) See general construction and assembly in-
structions. The appliance and vent should be
enclosedwheninstalledinorpassingthrougha
livingarea,wherechildrenmaycomeincontact
with it.
5) Thisappliancemustbeconnectedtothespeci-
fied vent and termination cap to the outside of
the building envelope. Never vent to
another room or inside a building. Make sure
that the vent is fitted as per the instructions
startinginthe"ExteriorVentTerminalLocations"
section.
6) Inspect the venting system annually for block-
age and any signs of deterioration.
7) Venting terminals shall not be recessed into a
wall or siding.
8) Any safety glass removed for servicing must
be replaced prior to operating the appliance.
9) To prevent injury, do not allow anyone who is
unfamiliarwiththeoperationtousethefireplace.
INSTALLATION
CHECKLIST
1) Locateyourgasappliance.Refertothe follow-
ing sections:
a. Locating Your Gas Stove
b. Clearances to Combustibles
c. "Venting Introduction" to "Exterior Vent
Terminal Locations" sections.
2) InstallOptionalFan.Refertothe"OptionalFan
Installation" section.
3) Setventrestrictor.Refertothe"VentRestrictor
Position" section.
4) Installventing:Checkallventingrequirements.
See"VentingIntroduction"to "Dura-VentVerti-
cal Termination" sections.
5) Makegasconnections.Refertothe"GasCon-
nection" section.
Test the pilot. Must be as per diagram in the
"Pilot Adjustment" section.
If converting to Propane, make changes prior
as instructed in the "Conversion from Natural
Gas to Propane" section.
6) Test Gas Pressure. Refer to the "Gas Pipe
Pressure Testing" section.
7) Install standard and optional features. Refer
to the following sections where applicable:
a. Log Set Installation
b. Wall Thermostat
c. Remote Control
8) Finalcheck.Refertothe"FinalCheck"section.
Before leaving this unit with the customer, the
installermustensurethattheapplianceisfiringcor-
rectlyandoperationfullyexplainedtocustomer.
This includes:
1) Clocking the appliance to ensure the correct
firing rate (rate noted on label) after burning
appliance for 15 minutes.
2) If required, adjusting the primary air to ensure
that the flame does not carbon. First allow the
unit to burn for 15-20 min. to stabilize.
CAUTION: Any alteration to the product that
causessootingorcarboningthatresultsindam-
ageisnottheresponsibilityofthemanufacturer.
Emissions from burning wood or gas could
contain chemicals known to the State of
California to cause cancer, birth defects or
other reproductive harm.

Hampton® H15-1 Direct Vent Freestanding Gas Stove 9
INSTALLATION
LOCATING YOUR
GAS STOVE
When selecting a location for your stove, ensure
that the clearances listed above are met as well
asensuring that thereis adequate accessibilityfor
servicing and proper operation.
MANUFACTURED MOBILE
HOME ADDITIONAL
REQUIREMENTS
1) Ensure that structural members are not cut or
weakened during installation.
2) Ensure proper grounding using the #8 ground
lug provided.
3) Appliance must be anchored to the floor with
the supplied anchoring methods.
COMBUSTION AND
VENTILATION AIR
The combustion air from this appliance is drawn
from outside the building through the outer flue.
Extra provision for combustion air inside the
room is not required.
A) Cross Corner
B) Room Divider
C) Island
D) Flat on Wall
E) Flat on Wall Corner
F) Flush with Wall/Alcove
ForVentTerminationrequirements,seethe"Exterior
Vent Terminal Locations" section.
* 12' max. only if vertical height is achieved.
CLEARANCES TO
COMBUSTIBLES
The clearances listed are MINIMUM distances.
Measure the clearance to both the appliance and
the chimney connector. The farthest distance is
correct if the two clearances do not coincide.
For example, if the appliance is set as indicated in
one of the figures but the connector is too close,
move the stove until the correct clearance to the
connector is obtained.
This appliance may be installed only with the
clearances as shown in the situations pictured.
Do not combine clearances from one type of
installation with another in order to achieve
closer clearances.
This unit can be installed on a solid combustible
surface like a wood floor. This unit can also be
installed directly on carpeting or vinyl.
Use the minimum clearances shown in the dia-
grams below:
H15-NG1 & H15-LP1 Clearances
A Left Side Wall to Unit*6" / 150 mm
*BBack Wall to Unit 0" / 0 mm
C Vertical Vent Pipe to Back Wall
2" / 50 mm
E Unit Corner to Wall 2" /50 mm
Unit Top to Alcove Ceiling 24" / 610 mm
Minimum ceiling height is 24" /610 mm from top
of unit.
*IMPORTANT
It is recommended that unit is moved away from
the wall, if installing the blower option, so the fan
can be easily installed and/or serviced.

10 Hampton® H15-1 Direct Vent Freestanding Gas Stove
INSTALLATION
9) Remove 2 screws from unit.
10) Place grommet in rear plate through the
bottom of the opening as shown below.
11) Placetheblowerclosetothebaseoftheunit
and feed the wires through the grommet in
the rear plate.
Grommet
Rear Plate
Wires
OPTIONAL FAN
INSTALLATION
Fan Kit Contains:
Qty. Description
1 Fan Assembly c/w green wire attached
1 Thermodisc
1 Fan Speed Control
1 Grommet
1) Remove the rear access panel on the back of
the stove by removing the 2 screws under the
rear panel, then lift rear panel off of 2 bolts at
thetop.Take carenot to cutwireswhen lower-
ing the panel.
2) Disconnect the red and grey wires.
Top Control Panel Assembly
Fan Speed
Controller
4) Remove the nylon hole plug from the control
panel.
5) Install the fan speed controller onto the control
panelandsecurewithnutandwasher.Connect
theredandblackwiresfromthewireharnessto
speed controller. NOTE: Speed control wires
must be in the down position when control
panel is in place.
6) Push black knob onto speed control.
7) Re-attachcontrolpanelwith3screws,reversing
step 3.
screw screw
Lift Rear Panel off of the 2 top bolts.
bolt
3) Remove the Top Control Panel Assembly
by removing the three screws.
8) Slide Thermodisc into the bracket on the left
side of the rear firebox.
Thermodisc
Thermodisc
Bracket

Hampton® H15-1 Direct Vent Freestanding Gas Stove 11
INSTALLATION
16) Slide the RearAccess Panel back into position and secure with 2 screws.
WARNING: Electrical Grounding Instructions
This appliance is equipped with a three pronged (grounding) plug for your protection against shock hazard and should be plugged directly into
a properly grounded three-prong receptacle. Do not cut or remove the grounding prong from this plug.
12) Slide fan into place and secure with the two
screws removed in step 9.
13) Connect long black & red wires to thermodisc and secure wires.
14) Connect fan ground wire to lug nut at base of unit.
15) Before re-attaching the rear access panel, the valve wires and the fan
wires need to be connected.
Re-connect the red and grey valve wires removed in step 2.
Connect the black and white fan wires as per the wiring diagram below.
Lug Nut

12 Hampton® H15-1 Direct Vent Freestanding Gas Stove
INSTALLATION
INSTALLATION
PRECAUTIONS
These venting systems are engineered products
that have been designed and tested for use with
the H15-NG1, and H15-LP1. The warranty will be
voidedandserious fire, healthor other safetyhaz-
ards may result from any of the following actions:
1) Installation of any damaged Rigid Pipe com-
ponent.
2) Unauthorized modification of any Rigid Pipe
System.
3) InstallationotherthanasinstructedbySimpson
Dura-VentandFPIFireplaceProductsInterna-
tional Ltd.
Warning: Always maintain required
clearances (air spaces) to nearby
combustiblestopreventafirehazard.
Do not fill air spaces with insulation.
Be sure to check the vent termination clearance
requirements from decks, windows, soffits, gas
regulators,airsupplyinletsandpublicwalkwaysas
specified in the "Exterior Vent Terminal Locations"
section and in your local building codes.
The gas appliance and vent system must be
vented directly to the outside of the building,
and never be attached to a chimney serving a
separate solid fuel or gas-burning appliance.
Each direct vent gas appliance must use it's own
separate vent system. Common vent systems are
prohibited.
VENTING INTRODUCTION
The Horizontal Termination Kit and the Simpson
Dura-VentDirectVentventingsystems,incombina-
tionwith the DirectVent FreestandingGas Stoves,
H15-NG1,andH15-LP1,havebeentestedandlisted
as direct vent heater systems by Warnock Hersey.
These units use the "balanced flue" technology
Co-Axial system. The inner liner vents products
of combustion to the outside while the outer pipe
draws outside combustion air into the combustion
chambertherebyeliminatingtheneedtouseheated
room air for combustion and losing warm room air
up the chimney.
Note: These flue pipes must not be
connected to any other appliance.
Thegasapplianceandventsystemmustbevented
directly to the outside of the building, and never
be attached to a chimney serving a separate solid
fuel or gas burning appliance. Each direct vent gas
appliance must use it's own separate vent system.
Common vent systems are prohibited.
IMPORTANT
Read all instructions carefully before starting the
installation.Failuretofollow theseinstructionsmay
createafireorothersafetyhazard,andwillvoidthe
warranty. Be sure to check the venting and clear-
ance to combustible requirements. Consult your
local building codes before beginning installation.
The location of the termination cap must conform
to the requirements in the "Exterior Vent Terminal
Locations" section.
SAFETY PRECAUTIONS
FOR THE INSTALLER
1) Wear gloves and safety glasses for protec-
tion.
2) Exercise extreme caution when using lad-
ders or on roof tops.
3) Be aware of electrical wiring locations in
walls and ceilings.
VENT RESTRICTOR
POSITION
To set the Vent restriction as indicated in the
Venting Arrangement diagrams in the "Rigid
Pipe Venting System" section, simply loosen
the screws and push the vent restrictor plate to
the correct position. Tighten the screws. This
will be located inside the firebox.
ROTATING ELBOW
1) Remove top casting.
2) Removeall4 screwsthatsecure
the elbow to the unit using a 1/4"
magnetic nut driver.
3) Rotate the elbow 180o
4) Secure the elbow by securing
it with the 4 screws.
Remove all 4 screws
and washers

Hampton® H15-1 Direct Vent Freestanding Gas Stove 13
INSTALLATION
EXTERIOR VENT TERMINAL LOCATIONS
Minimum Clearance Requirements Canada1USA2
AClearance above grade, veranda, porch, deck, or balcony 12"(30cm) 12"(30cm)
BClearance to window or door that may be opened 12"(30cm) 9" (23cm)
CClearance to permanently closed window **
DVertical clearance to ventilated soffit located above the terminal within a horizontal distance of 2 feet (61cm)
from the center line of the terminal (check with the local code)
22"(56cm) 22"(56cm)
EClearance to unventilated soffit 12"(30cm) 12"(30cm)
FClearance to outside corner: with AstroCap and Vent Riser Termination Cap 6"(15cm) 6"(15cm)
Clearance to outside corner: with all other approved Termination Caps. 12"(30cm) 12"(30cm)
GClearance to inside corner: with AstroCap and Vent Riser Termination Cap 6"(15cm) 6"(15cm)
Clearance to inside corner: with all other approved Termination Caps 12"(30cm) 12"(30cm)
HClearance to each side of center line extended above meter/regulator assembly 36"(90cm)a*
JClearance to service regulator vent outlet 36"(90cm) *
KClearance to non-mechanical air supply inlet to building or the combustion air inlet to any other appliance 12"(30cm) 9" (23cm)
LClearance to a mechanical air supply inlet
#3' (91cm) above if within 10' (3m) horizontally.
72"(1.8m) 36"(90cm)b
MClearance above paved sidewalk or a paved driveway located on public property 84"(2.1m)┼*
NClearance under veranda, porch, deck, or balcony 12"(30cm)‡*
1In accordance with current CSA B149.1, Natural Gas and Propane Installation Code
2In accordance with the current ANSI Z223.1/NFPA 54, National Fuel Gas Code
┼A vent shall not terminate directly above a sidewalk or paved driveway which is located between two single family dwellings and serves both dwellings.
‡ Permitted only if veranda, porch, deck, or balcony is fully open on a minimum of two sides beneath the floor.
*Clearance in accordance with local installation codes and the requirements of the gas supplier
a3 feet (91cm) within a height of 15 feet (4.5m) above the meter / regulator assembly
b3 feet (91cm) above - if within 10 feet (3m) horizontally

14 Hampton® H15-1 Direct Vent Freestanding Gas Stove
INSTALLATION
4” X 6-5/8” RIGID PIPE
CROSS REFERENCE CHART
Components from different Manufacturers may not be mixed. Not All Rigid Pipe components are available directly from FPI.
Description Simpson
Direct Vent Pro®
Selkirk
Direct Temp™
American Metal
Products®
Amerivent Direct
Metal-Fab™
Sure Seal
Security
Secure- Vent®
ICC Excel
Direct
6” Pipe Length-Galvanized 46DVA-06 4DT-6 N/A 4D6 SV4L6 TC-4DL6
6” Pipe Length-Black 46DVA-06B 4DT-6B N/A 4D6B SV4LB6 TC-4DL6B
7” Pipe Length-Galvanized N/A N/A 4D7 N/A N/A N/A
7” Pipe Length-Black N/A N/A 4D7B N/A N/A N/A
9” Pipe Length-Galvanized 46DVA-09 4DT-9 N/A N/A N/A N/A
9” Pipe Length-Black 46DVA-09B 4DT-9B N/A N/A N/A N/A
12” Pipe Length-Galvanized 46DVA-12 4DT-12 4D12 4D12 SV4L12 TC-4DL1
12” Pipe Length-Black 46DVA-12B 4DT-12B 4D12B 4D12B SV4LB12 TC-4DL1B
18” Pipe Length-Galvanized 46DVA-18 4DT-18 4D18 4D18 SV4LA TC-4DL18
18” Pipe Length-Black 46DVA-18B 4DT-18B 4D18B 4D18B SV4LA TC-4DL18B
24” Pipe Length-Galvanized 46DVA-24 4DT-24 4D24 4D24 SV4L24 TC-4DL2
24” Pipe Length-Black 46DVA-24B 4DT-24B 4D24B 4D24B SV4LB24 TC-4DL2B
36” Pipe Length-Galvanized 46DVA-36 4DT-36 4D36 4D36 SV4L36 TC-4DL3
36” Pipe Length-Black 46DVA-36B 4DT-36B 4D36B 4D36B SV4LB36 TC-4DL3B
48” Pipe Length-Galvanized 46DVA-48 4DT-48 4D48 4D48 SV4L48 TC-4DL4
48” Pipe Length-Black 46DVA-48B 4DT-48B 4D48B 4D48B SV4LB48 TC-4DL4B
60” Pipe Length-Galvanized 46DVA-60 4DT-60 N/A N/A N/A N/A
60” Pipe Length-Black 46DVA-60B 4DT-60B N/A N/A N/A N/A
Adjustable Length 3”-10”-Galvanized N/A N/A N/A 4DAL N/A TC-4DLT
Adjustable Length 3”-10”-Black N/A N/A N/A 4DALB N/A TC-4DLTB
Adjustable Length 7”-Galvanized N/A N/A 4D7A N/A N/A N/A
Adjustable Length 7”-Black N/A N/A 4D7AB N/A N/A N/A
Extension Pipe 8-1/2”-Galvanized 46DVA-08A N/A N/A N/A N/A N/A
Extension Pipe 8-1/2”-Black 46DVA-08AB N/A N/A N/A N/A N/A
Adjustable Length 12”-Galvanized N/A N/A 4D12A N/A SV4LA12 N/A
Adjustable Length 12”-Black N/A N/A 4D12A N/A SV4LBA12 N/A
Extension Pipe 16”-Galvanized 46DVA-16A N/A N/A N/A N/A N/A
Extension Pipe 16”-Black 46DVA-16AB N/A N/A N/A N/A N/A
45ºElbow-Galvanized 46DVA-E45 4DT-EL45 4D45L N/A N/A TE-4DE45
45ºElbow-Black 46DVA-E45B 4DT-EL45B 4DT-EL45B N/A N/A TE-4DE45B
45ºElbow Swivel-Galvanized See 46DVA-E45 N/A N/A 4D45L SV4E45 N/A
45ºElbow Swivel-Black See 46DVA-E45B N/A N/A 4D45LB SV4EB45 N/A
90ºElbow-Galvanized 46DVA-E90 4DT-EL90S 4DT-EL90S N/A N/A TE-4DE90
90ºElbow-Black 46DVA-E90B 4DT-EL90SB 4DT-EL90SB N/A SV4EBR90-1 TE-4DE90B
90ºElbow, Swivel-Galvanized See 46DVA-E90 N/A N/A 4D90L SV4E90-1 N/A
90ºElbow, Swivel-Black See 46DVA-E90B N/A N/A 4D90LB SV4EB90-1 N/A
90º Starter Elbow, Swivel-Galvanized N/A N/A N/A 4D90A N/A N/A
Adaptor* N/A N/A N/A 4D90L N/A N/A
Ceiling Support N/A 4DT-CS 4DFSP 4DSP SV4SD TE-4DE45
Cathedral Support Box 46DVA-CS 4DT-CSS 4DRSB 4DRS SV4CSB TE-4DE45B
Wall Support/Band 46DVA-WS 4DT-WS/B 4DWS 4DWS SV4BM N/A
Offset Support 46DVA-ES (N/A - FPI) 4DT-OS N/A N/A SV4SU N/A
Wall Thimble-Black 46DVA-WT 4DT-WT 4DWT 4DWT SV4RSM TE-4DE90
Wall Thimble Support/Ceiling Support 46DVA-DC N/A N/A N/A SV4PF TE-4DE90B
Firestop Spacer 46DVA-FS 4DT-FS 4DFSP 4DFS SV4BF N/A
Trim Plate-Black N/A 4DT-TP 4DFPB 4DCP SV4LA N/A

Hampton® H15-1 Direct Vent Freestanding Gas Stove 15
INSTALLATION
Description Simpson
Direct Vent Pro®
Selkirk
Direct Temp™
American Metal
Products®
Amerivent Direct
Metal-Fab™
Sure Seal
Security
Secure- Vent®
ICC Excel
Direct
Attic Insulation Shield 12” 46DVA-IS N/A@ FPI N/A 4DAIS12 N/A SV4RSA N/A
Attic Insulation Shield - Cold Climates 36” N/A N/A 4DAIS12 N/A N/A TM-4AS
High Wind Vertical Cap 46DVA-VCH N/A N/A N/A N/A TM-4VT
High Wind Horizontal Cap 46DVA-HC N/A N/A N/A N/A TM-4DHT
Horizontal Square Termination Cap See 46DVA-HC 4DT-HHC 4DHC 4DHT SV4CHC-1 TM-4HT
Vertical Termination Cap 46DVA-VC 4DT-HVC 4DVC 4DVT SV4CGV-1 TM-4VT
Storm Collar 46DVA-08A 4DT-SC 4DSC 4DSC SV4FC TM-SC
Restrictor Disk N/A N/A N/A N/A N/A TM-4DS
Extended Vertical Termination Cap N/A N/A N/A N/A N/A N/A
Chimney Conversion Kit A (USA only) 46DVA-KCA N/A N/A N/A N/A TM-4CA6
Chimney Conversion Kit B (USA only) 46DVA-KCB N/A N/A N/A N/A TM-4CA7
Chimney Conversion Kit C (USA only) 46DVA-KCC N/A N/A N/A N/A TM-4CA8
Chimney Conversion Kit Masonry
(USA only)
46DVA-KMC N/A N/A N/A N/A N/A
Wall Firestop 46DVA-WFS N/A N/A N/A N/A TM-4TR
Colinear Flex Connectors 46DVA-ADF N/A N/A N/A N/A N/A
Adjustable Flashing 0/12-6/12 46DVA-F6 4DT-ST14 4D12S 4DST14 SV4STC14 TF-4FA
Adjustable Flashing 6/12-12/12 46DVA-FLA 4DT-ST36 4D36S 4DST36 SV4STC36 TF-4FB
Vinyl Siding Standoff 46DVA-VSS 4DT-VS N/A 4DVS SV4VS TM-VSS
Vinyl Siding Shield Plate N/A 4DT-VSP N/A N/A SV4VS N/A
Snorkel Termination 14” 46DVA-SNKL N/A N/A N/A N/A TM-4ST14
Snorkel Termination 36” N/A N/A N/A N/A N/A TM-4ST36
Basic Horizontal Termination Kit (A) Disc. 4DT-HKA 4DHTK2 4DHTKA SV-SHK N/A
Horizontal Termination Kit (B) 46DVA-KHA
(Changed Components)
4DT-HKB 4DHTK1 4DHTKB SV-HK N/A
Vertical Termination Kit Disc. 4DT-VKC 4DHTK 4DHTK SV-FK N/A
FPI
946-506/P Vent Guard (Optional) for AstroCap 946-205 Vinyl Siding Shield for Riser Vent Terminal
510-994 Rigid Pipe Adaptor (Must use with all rigid piping) 946-208/P Vent Guard (Optional) for Riser Vent Terminal
640-530/P Riser Vent Terminal 946-523/P AstroCap Horizontal Cap
946-605 Starter Collar Increaser 4” x 6-5/8” to 5” x 8” 946-206 Vinyl Siding Standoff for AstroCap
Note: When using Metal-Fab Sure Seal Rigid Piping - please note that the Adaptor (4DDA) must be used in conjunction with FPI Rigid Pipe Adaptor (510-994).
Note: Horizontal runs of vent must be level, or have a 1/4” rise for every 1 foot of run towards the termination.
Never allow the vent to run downward - this could cause high temperatures and may present a possible fire hazard.
Offset Pipe Selection: Use this table to determine offset pipe lengths.
Pipe Length
(L)
4” x 6-5/8” Venting For specific instructions on venting components - visit the
manufacturers website listed below.
Run (X) Rise (Y)
0” (0mm) 4-7/8” (124mm) 13-7/8” (340mm) Simpson Direct Vent Pro: www.duravent.com
6” (152mm) 8” (203mm) 16-1/2” (419mm) Selkirk Direct-Temp: www.selkirkcorp.com
9” (229mm) 10-1/8” (257mm) 18-5/8” (473mm) American Metal Products: www.americanmetalproducts.com
12” (305mm) 12-1/4” (311mm) 20-3/4” (527mm) Metal-Fab Sure Seal: www.mtlfab.com
24” (610mm) 20-5/8” (524mm) 29-1/8” (740mm) Security Secure Vent: www.securitychimneys.com
36” (914mm) 29” (737mm) 37-1/2” (953mm) Industrial Chimney Company: www.icc-rsf.com
48” (1219mm) 37-7/16” (951mm) 45-15/16” (1167mm)
Regency Fireplace Products . 6988 Venture St. . Delta, BC . Canada . V4G 1H4 . 604-946-5155 . www.regency-fire.com

16 Hampton® H15-1 Direct Vent Freestanding Gas Stove
INSTALLATION
Pipe Length
Vertical
Termination
Cap
Storm Collar
Flashing
Ceiling Firestop
24" Pipe
Length
Adj.Pipe Length
11" - 14-5/8"
90 Elbow
o
Horizontal
Termination
Cap
Wall Thimble
Vinyl Siding
Standoff (Optional)
RIGID PIPE VENTING SYSTEMS
Horizontal or Vertical Terminations
Alternate
Horizontal
Termination
Caps
When using Rigid Vent other than
Simpson Dura-Vent, 3 screws must be
used to secure rigid pipe to adaptor.
This product has been evaluated by Intertek
for using a Rigid Pipe Adaptor in conjunction
withDuraventDirect-Vent,SelkirkDirect-Temp,
AmeriVentDirectventingandSecuritySecure
Vent systems. Use of these systems with the
Rigid Pipe adaptor is deemed acceptable
and does not affect the Intertek WHI listing of
components.
WARNING:
Do not combine venting components from
different venting systems.
However use of the the AstroCapTM and FPI
Riser is acceptable with all systems.
The FPI AstroCapTM and FPI Riser Vent terminal are certified for installations using FPI venting systems as well as Simpson Dura-Vent®Direct Vent,
American Metal Products Ameri Vent Direct Vent, Security Secure Vent®, Selkirk Direct-Temp. AstroCapTM is a proprietary trademark of FPI Fireplace
Products International Ltd. Dura-Vent® and Direct Vent are registered and/or proprietary trademarks of Simpson Dura-Vent Co. Inc.
Max.

Hampton® H15-1 Direct Vent Freestanding Gas Stove 17
INSTALLATION
H1
H
V
Horizontal Venting with Two (2) 90oElbows
Option V H + H1
A) 1' Min. 3' Max.
B) 2' Min. 4' Max.
C) 3' Min. 5' Max.
D) 4' Min. 6' Max.
E) 5' Min. 7' Max.
F) 6' Min. 8' Max.
Horizontal Venting with Two (2) 90oElbows
Option H V H + H1
A) 1' Max. 1' Min. 3' Max.
B) 2' Max. 2' Min. 5' Max.
C) 3' Max. 4' Min. 6' Max.
D) 4' Max. 6' Min. 7' Max.
E) 5' Max. 8' Min. 8' Max.
With these options, max.
total pipe length is 30 feet
with min. of 8 feet total
vertical and max. 8 feet
total horizontal.
Please note min. 1 foot
between 90oelbows is
required.
With these options, maxi-
mum total pipe length is 30
feet with minimum of 6 feet
totalvertical and maximum
8 feet total horizontal.
Please note minimum 1
foot between 90oelbows
is required.
One 90oelbow = Two 45oelbows.
One 90oelbow = Two 45oelbows.
H
H1
V
Vent restrictor position A(fully open), refer to the "Vent
Restrictor Postion" section.
Vent restrictor position A(fully open), refer to the "Vent
Restrictor Postion" section.
Lengths do not include elbow indicated
Lengths do not include elbow indicated

18 Hampton® H15-1 Direct Vent Freestanding Gas Stove
INSTALLATION
H1
H
V
Vertical Venting with Two (2) 90oElbows
Option V H V + V1
A) 1' Min. 4' Max. 2' Min.
B) 2' Min. 5' Max. 3' Min.
C) 3' Min. 6' Max. 4' Min.
D) 4' Min. 7' Max. 5' Min.
E) 5' Min. 8' Max. 6' Min.
Vertical Venting with Two (2) 90oElbows
Option H + H1 V
With these options, max. total
pipelengthis30feetwithmin.
of6feettotalverticalandmax.
8 feet total horizontal.
Please note min. 1 foot
between 90oelbows is re-
quired.
A) 2' Max. 2' Min.
B) 3' Max. 3' Min.
C) 4' Max. 4' Min.
D) 5' Max. 5' Min.
E) 6' Max. 6' Min.
Withtheseoptions,max.total
pipelengthis30feetwithmin.
of6feettotalverticalandmax.
6 feet total horizontal.
Please note min. 1 foot
between 90oelbows is
required.
One 90oelbow = Two 45oelbows.
One 90oelbow = Two 45oelbows.
V1
V
H
Vent restrictor position A(fully open), refer to the "Vent
Restrictor Postion" section.
Vent restrictor position A(fully open), refer to the
"Vent Restrictor Postion" section.
Lengths do not include elbow indicated
Lengths do not include elbow indicated

Hampton® H15-1 Direct Vent Freestanding Gas Stove 19
INSTALLATION
Offset to Vertical Terminations
Venting Arrangements - Horizontal Terminations
VENTING ARRANGEMENTS
Vertical Terminations Systems for
Residential Manufactured and Mobile Homes
Theshadedareain the diagrambelowshowsallallowablecombinations of straight
vertical and offset to vertical runs with vertical terminations. Maximum two 45o
elbows.
If the vent is ENCLOSED in a chase (min. size 9" x 9") maintain a 1-1/4" clearance to
combustibles.
May be installed in Manufactured (Mobile) Homes after first sale.
Horizontal Terminations for
All Venting Systems
The shaded areas in the diagram below show all
allowable combinations of vertical runs with hori-
zontal terminations. Maximum one 90Oelbow (two
45o elbows equal one 90oelbow).
Propane and Natural Gas:
Residential, Manufactured and Mobile
Homes Installations
May be installed in Manufactured (Mobile)
Homes after first sale.
The two diagrams show all allowable com-
binationsofstraighthorizontal termination
with one 45oelbow off the unit. Restrictor
position "A".
12" max. w/AstroCap or Simpson Duravent
Horizontal Square Termination Cap.
24" max. w/FPI Riser or Snorkel Termination
Cap.

20 Hampton® H15-1 Direct Vent Freestanding Gas Stove
INSTALLATION
Venting Arrangements - Vertical Terminations
with Co-linear Flex System for both
Residential & Manufactured Homes
into Masonry Fireplaces
The shaded area in the diagram shows the allowable vertical
terminations.
VERTICAL TERMINATION WITH CO-LINEAR FLEX SYSTEM
THE APPLIANCE MUST NOT BE
CONNECTED TO A CHIMNEY FLUE
SERVING A SEPARATE SOLID FUEL
BURNING APPLIANCE.
This appliance is designed to be attached to
two 3" (76mm) co-linear aluminium flex running
the full length of the chimney. See the Venting
Arrangements chart below for minimum and
maximum flue lengths. See chart below for
minimumdistancesfromroof.Periodicallycheck
that the vent is unrestricted.
Masonry chimneys may take various contours which the flexible liner will accommodate. However, keep
the flexible liner as straight as possible, avoid unnecessary bending.
The Air Intake pipe must be attached to the inlet air collar of the termination cap.
Straight Vertical Terminations
Required Parts:
Part # Description
946-529 Co-linear DV Vertical
Termination Cap
948-305 3" Flex - 35 ft.
946-563 Co-Axial to Co-Linear Adapter Kit
which contains the following:
Co-linear Flex Adapter (270-585)
Outer Pipe (946-257)
Inner Pipe Adapter (946-219)
Vent Restrictors
set at fully closed,
Position "B"
Alternate Approved Caps
980 Vertical Termination Cap
991 High Wind Cap
923GK 3" Co-linear Adapter with flashing
