HAMPTON BAY CAROL STREAM S4-AJL01499 User manual

THANK YOU
We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this lounge seating.
We strive to continually create quality products designed to enhance your home.
Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!
Item #699034
Model #S4-AJL01499
USE AND CARE GUIDE
CAROL STREAM LOUNGE SEATING WITH BAR TABLE
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM

2
Table of Contents
Table of Contents
Warranty
What is Covered
What is Not Covered
Pre-Assembly
Planning Assembly
Hardware Included
Package Contents
................................2
..............................................2
.....................................2
...............................2
......................................3
..................................3
..................................3
...................................4
Assembly
Maintenance
Care and Cleaning
.............................................5
.......................................7
..............................7
3 Year Frame / 2 Year Fabric / 2 Year Wicker Limited Warranty
What is Covered
We warrant the frame to be free of manufacturing defects to the original purchaser for three years and the fabric and wicker for two years.
What is Not Covered
It remains the customer’s responsibility for freight and packaging charges to and from our service center. This warranty does not cover
commercial use, hardware, acts of nature, fire, freezing and abusive use. In addition, purchased parts are not covered under this warranty.
We reserve the right to make substitutions with similar merchandise, if the model in question is no longer in production.
Contact Customer Care at 1-855-HD-HAMPTON or visit www.HamptonBay.com.
Warranty

3
Pre-Assembly
PLANNING ASSEMBLY
Identify all parts packed in the carton against the parts list. Remove all protective materials. Place parts on a non-abrasive surface to avoid
scratching. If you are missing any parts or are unsure how to proceed with the assembly, call our Customer Service Team at 1-855-HD-HAMPTON.
Do not attempt assembly if any parts are missing or damaged.
Two people may be required to assemble the lounge seat.
Damage to welds or frames resulting from over tightened bolts or improper assembly is not covered under our warranty. Please read all
instructions carefully before assembly. If you have any questions regarding your assembly, call our Customer Service Team at 1-855-HD-HAMPTON.
NOTE: Hardware not shown to actual size.
HARDWARE INCLUDED
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
Part Description Order Part # Quantity
1/4 in. x 20 mm Bolt
1/4 in. x 30 mm Bolt
1/4 in. x 60 mm Bolt
Ø6.5 x 1.0 mm Washer
Bolt Cover
Connector
Hex Bolt Driver
Umbrella Pole Lock Knob (Preassembled)
Foot Cap-1 (Preassembled)
Foot Cap-2 (Preassembled)
18
2
3
23
29
4
1
1
10
4
AA
BB
CC
DD
EE
FF
GG
HH
II
JJ
HW0036
HW0038
HW0135
HW0004
HW0105
HW0840
HW0006
G0091
FC0607
FC0131
____GG
____AA ____BB ____EE
____DD____CC ____FF
____HH ____II ____JJ

4
Pre-Assembly (continued)
PACKAGE CONTENTS
Part Description Order Part # Quantity
Table Top
Seat Frame-1
Seat Frame-2
Support Bar
Back Frame-1
Back Frame-2
Leg
1
1
1
1
1
1
1
A
B
C
D
E
F
G
AK0981
AK0982
AK0983
AK0984
AK0985
AK0986
AK0987
B
F
G
C
D
A
E

Assembly
5
2Attaching the back frames
3Attaching the table top
□ Attach the table top (A) to the back frames (E and F) by using
three 1/4 in. x 60 mm bolts (CC) and two 1/4 in. x 20 mm
bolts (AA). Add a washer (DD) to each bolt.
□ Guide the bolts through the holes in the table top (A), into the
pre-drilled holes in the back frames (E and F).
□ Hand tighten only.
1Attaching the support bar
□ Attach the support bar (D) to seat frame-1 (B) by using four
1/4 in. x 20 mm bolts (AA) and Ø6.5 x 1.0 mm washers (DD).
□ Guide the bolts through the holes in the support bar (D), into
the pre-drilled holes in seat frame-1 (B).
□ Hand tighten only.
□ Attach back frame-1 (E) to back frame-2 (F) by using 1/4 in.
x 30 mm bolts (BB) and Ø6.5 x 1.0 mm washers (DD).
□ Guide the bolts through the holes in back frame-1 (E), into the
pre-drilled holes in back frame-2 (F).
□ Hand tighten only.
4Attach the leg
□ Attach the leg (G) to the back frames (E and F) by using four
1/4 in. x 20 mm bolts (AA) and washers (DD).
□ Guide the bolts through the holes in the leg (G), into the
pre-drilled holes in the back frames (E and F).
□ Hand tighten only.
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
B
EE
G
AA
DD
EE
ACC
EE
AA
DD
E
F
DD BB EE
G
DD
AA EE

Assembly
6
6Tightening bolts
5Attaching seat and back frames
□ Attach seat frame-1 (B) to the back frames (E and F) by using
one connector (FF) and two 1/4 in. x 20 mm bolts (AA) with
two washers (DD).
□ Guide the bolts (AA) through the holes in seat frame-1 (B),
into the pre-drilled holes in the back frames (E and F).
□ Repeat for the other connectors (FF).
□ Hand tighten only.
□ After making any necessary adjustments to the the alignment
of the seat, use the hex bolt driver (GG) to tighten all bolts (AA,
BB and CC). Tighten each bolt a few revolutions at a time. In
order to apply equal pressure to all bolt joints, we recommend
working in a cross corner (X) pattern. Repeat until all bolts are
tight. Do not over tighten. Over tightening may strip the bolts.
Ensure all bolts are covered with bolt covers (EE). See the
illustrations in Steps 1 - 5 for proper placement of the bolt
covers (EE).
C
FF
EE
AA
DD

7
Maintenance
FRAME:
Periodically clean and dry thoroughly. Be sure to drain any water accumulated inside the frames. To thoroughly drain the frames, remove the foot
caps and tilt the frames, if necessary, to remove all water. This is critical. Water allowed to accumulate inside the frames and then exposed to
sub-freezing temperatures can cause damage to the frame tubing. Such damage is not covered under the warranty. Always clean, drain, and dry
thoroughly before storing for the winter. For best results, always store or cover your furniture when not in use. We recommend commercially
available outdoor furniture covers. Any small nicks or scratches can be covered with a light application of touchup paint.
FABRIC (CUSHIONS/SLINGS):
The best way to maintain the appearance of cushions and slings is to store them in a dry area and out of the elements when not in use or cover
with commercially available outdoor furniture covers.
Care and Cleaning
FRAME:
Use mild soap and warm water. Do not use abrasive materials, cleansers, or bleach products. Rinse with clean water and dry thoroughly.
FABRIC (CUSHIONS/SLINGS):
Wipe minor spills immediately. Clean with mild soap, warm clean water, and a soft cloth. Do not use abrasive materials, cleansers, or bleach
products. Although fabric has been treated to resist stains, occasional use of commercially available fabric cleaners may be necessary. Follow the
manufacturer's instructions.
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.

Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
Retain this manual for future use.
