Hanatech MULTISCAN P2 User manual

*Hanatech reserves the right to change, modify
the content of this instruction manual for product
enhancement both technical and non technical
without notice.
This may include scan tool graphic displays,
vehicle coverage, supported functions both
technical, non technical and operating procedures.
Hardware may also be modified, altered or
redesigned or may differ from the descriptions
and illustrations displayed in this manual

CHAPTER1 SAFETYANDWARRANTY
I. SAFETY INSTRUCTIONS …………. 1 - 2
II. SAFETY PRECAUTIONS …………. 1 - 4
III. WARRANTY SERVICE …………. 1 - 6
FCC RF INTERFERENCE STATEMENT …………. 1 - 8

Chapter 1
Hanatech Co., Ltd.
Chapter 1 - 1
Safety and Warranty
About this Manual
All rights reserved by Hanatech Co., Ltd., Gumi, Korea.
The contents of this manual are the result of contributions by dozens
of individuals all who have added their vital expertise and experience to
the evolution of the contents of this manual.
The information contained in this manual may contain printing errors
and is subject to change without notice according to product upgrade.
Hanatech shall not be liable for errors contained herein or for incidental
or consequential damage in connection with the furnishing, performance,
or use of this material.
No part of this manual may be photocopied, reproduced, or translated
to another language in any way without the prior written consent of
Hanatech Co., Ltd.
Using this Manual
It is recommended that the user become familiar with the
operating procedures, terminologies and information contained
within this user’s manual. This will help to increase the user’s
effectiveness with this equipment.
Vehicle system familiarity
While this equipment provides very powerful functions with extensive
vehicle coverage, it cannot replace knowledge and skill. To get the
most out of this equipment, a full understanding of vehicle systems is
required. It is recommended that the equipment be used in conjunction
with the original service manual for the vehicle being tested.
The equipment is designed for use by trained service personnel and
this manual assumes that the service technician who is going to use this
equipment has a familiarity with vehicle electronic control systems,
however, the latest service manuals and bulletins should always be
referenced before using this equipment.

USER MANUAL For MULTISCAN P2
Chapter 1 - 2
I. SAFETY INSTRUCITONS -----------------------
Thank you for purchasing MULTISCAN P2. To get the maximum performance of
the equipment, please carefully read this manual first, and keep it at hand.
On delivery inspection
When the equipment is delivered, a check should be made for any damaged or
missing components. If the unit is damaged or fails to operate according to the
specifications, contact your local distributor or the manufacturer, Hanatech Co., Ltd.,
Hana bldg., 1032-39 Wonpyeong-dong, Gumi-shi, Kyung-buk Republic of Korea 730-
924. In the unlikely event the equipment requires shipping back to the manufacturer,
please use the original packing material.
Safety symbols
The following symbols are used throughout this manual:
DANGER This mark means that dangerous consequences may
arise, with the possibility of death or serious injury to the
user, if the machine is handled incorrectly.
WARNING This mark means dangerous consequences may arise,
with the possibility of somewhat serious injury to the user
and or damage to the machine and facilities, if the
equipment is handheld incorrectly.
SYMBOL Description
This symbol is affixed to locations on the equipment where
the operator should consult corresponding topics in this
manual (which are also marked with the symbol) before
using relevant functions of the equipment. In the manual,
this symbol indicates explanations that are particularly
important that the user is expected to read the manual before
using the equipment.
This symbol represents DC (Direct Current)

Chapter 1
Hanatech Co., Ltd.
Chapter 1 - 3
Safety guideline
In order to ensure proper operation and satisfactory performance, observe the
cautions listed below.
DANGER
This equipment is designed to comply with IEC61010-1 safety standards, and
has been tested for safety prior to shipment. Excessive high voltage measurement
or improper operation could result in personal injury, as well as damage to the
equipment or the vehicle. Please read this manual carefully and be sure that you
understand its contents before using the equipment.
The manufacturer disclaims all responsibility for any accident except for that
resulting due to defect in its product.
WARNING
For safety reasons, this equipment should not be used to
measure circuits carrying more than 30Vrms or 42.4V peak.
To avoid electrical accident that could result in injury or
death, do not measure voltage in excess of these limitations.
Maximum rated measurable voltage is 30Vrms or 42.4V
peak.

USER MANUAL For MULTISCAN P2
Chapter 1 - 4
II. SAFETY PRECAUTIONS -----------------------
DANGER
When an engine is running, keep the workshop area WELL
VENTILATED or attach a building exhaust removal system to the
engine exhaust system. Engines produce carbon monoxide, an
odorless and poisonous gas that causes slower reaction time
and may lead to serious injury or death.
WARNING
Brakes and wheel blocks
Apply the hand brake and block the wheels before using the test
equipment. It is highly recommended to block the wheels on
front-wheel drive vehicles because the hand brake does not hold
the driving wheels.
Drive Test
Do not drive the vehicle and operate the test equipment at the
same time. Any distraction may cause an accident. Have one
person operate the test equipment while the other person drives
the vehicle.
Never place the test equipment in front of you when driving the vehicle because the
test equipment may hit your body and cause serious injury when
the air bag inflates.
Do not try to test the SRS air bag system while driving the
vehicle as unintended air bag inflation may result.

Chapter 1
Hanatech Co., Ltd.
Chapter 1 - 5
Engine Compartment
Maintain sufficient clearance between moving components or
belts while using the test equipment in the engine compartment.
Moving components and belts may catch loose clothing, test
cables or a part of your body and cause damage or personal
injury.
Electrical Components
Always turn the ignition key OFF when connecting or disconnecting electrical
components unless otherwise instructed.
Vehicle Battery
MULTISCAN P2 is designed to prevent damage from reverse polarity battery cable
connection, however, it is always highly recommended to always ensure correct
polarity terminal connection.
Never lay the test equipment on vehicle battery. You may short the terminals and may
cause damage to your body, the test equipment or the battery.
To avoid damaging the test equipment or displaying false data, make sure the vehicle
battery is fully charged and the connections to the electronic control module are clean
and tight.
The warning messages above and the safety messages contained hereinafter cover
situations Hanatech is aware of. Hanatech cannot know, evaluate or advise you as to
all of the possible hazards. You must make sure that any conditions or service
procedures encountered do not jeopardize your personal safety.

USER MANUAL For MULTISCAN P2
Chapter 1 - 6
III. WARRANTY SERVICE -------------------------
Warranty Period
In principle, MULTISCAN P2 is warranted to the customer to be free of defects in
material and workmanship for the period of 1 year and 3 years for main board after the
date of registration.
When the product is found defective during this period, the product can be returned to
Hanatech and will be repaired or replaced free of charge.
Freight and Repair Cost
During the warranty period, the repair cost and freight cost are covered by
manufacturer. When the defective product or part needs to be sent to the
manufacturer, it should be advised by the local distributor about how to send and the
validity of remaining warranty period before sending the defective material.
Upon delivery
Hanatech inspects all the ordered product parts and components are included in the
package before shipment, and include the original copy of pre-shipment inspection
report in the box. As soon as the product is delivered to you, please ensure
everything you ordered is properly checked and included referring to the pre-shipment
inspection report. If there is anything missing or damaged, you must notify the local
distributor immediately within 3 working days from the delivery date for free of charge
replacement of the parts.
In case of trouble
If you encounter any malfunction or trouble with the equipment, please refer to the
Trouble Shooting chapter in this manual. If the problem cannot be solved, please
contact your local distributor for assistance. For early identification of a fault or error,
your local distributor will require the following details:
1. Symptom of problem you are experiencing
2. Serial number of the head unit

Chapter 1
Hanatech Co., Ltd.
Chapter 1 - 7
3. Vehicle information: Which specific car were you testing when the problem
occurred – Model name, Model year and system ID number if available (for Mitsubishi,
Subaru and Suzuki only: Refer to Japanese car chapter for details)
Warranty Void
Even in the effective warranty period, if the problem is found to be caused by any of
the followings, Hanatech charges the cost for round trip freight and actual cost for the
service to the customer, and the shipment back to the customer will be suspended
until the customer’s payment is duly made
1. Evidence of improper use or application of the product ignoring the cautions and
warnings stipulated in the user’s manual
2. Intentional damages or modifications to the product or user’s attempt to repair
without proper authorization
3. Any damage caused by Force Majeure including war and natural disaster
4. Loss of time, inconvenience and other consequential damage or loss
Warranty void seal
In addition to the above mentioned warranty void conditions, warranty service is not
provided in case the warranty void seal is broken or removed.
If you remove the head unit safety boot, you will see a yellow round sticker covering
one of the screw holes in the back. Please be careful not to break this seal and never
try to open the head unit without direct authorization from the manufacturer.
Bought in other countries
Only the products properly supplied by the contracted authorized local distributors are
recognizable for free of charge warranty service. Any equipment bought outside the
contracted national territory of your local distributor will be charged for service.

USER MANUAL For MULTISCAN P2
Chapter 1 - 8
FCC RF INTERFERENCE STATEMENT
Note
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful
interference in a residential installation.
The equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation.
If this equipment does not cause harmful interference to radio or television reception
which can be determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the following measures;
- Reorient or relocate the receiving antenna
- Increase the separation between the equipment and receiver
- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected
Caution
Changes or modification not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS
SUBJECT TO THE FOLLOWING TWO CONDITIONS; (1) THIS DEVICE MAY NOT
CAUSE HARMFUL INTERFERENCE.AND (2) THIS DEVICE MUSTACCEPTANY
INTERFERENCE RECEIVED INCLUDING INTERFERENCE THAT MAY CAUSE
UNDESIRED OPERATION.

CHAPTER2 SPECIFICATIONANDPARTS
I. SPECIFICATION …………. 2 – 1
II. PART LIST …………. 2 – 3
A. Head unit and basic supplies 2 - 3
B. DiagnosticAdapters 2 - 6
C. Software Cartridge 2 - 15
D. Spare Parts 2 - 16
E. Optional Supplies 2 - 17

Chapter 2
Hanatech Co., Ltd.
Chapter 2 - 1
Specification and Parts
I. Specification -----------------------------------
A. Hardware
CPU: 16bit, 33MHz
RAM: 1 M byte (SRAM)
Program Cartridge Memory: 512MBytes Flash Memory
Display: 320×240 Monochrome Graphic LCD with Back Light
Key Pad: 20 membrane keys, embossing type
Communication Port: USB and RS232
Printer: General PC printer
Power: DC 12V, 700mA
SUPER CAP (2.7V / 10F SERIAL 5EA)
- Maintain the system without power for about 10 seconds when fully charged
B. Environmental Specification
Indoor use only
Operating temperature: Max 50℃/ 122℉
Maximum relative humidity: 80% (up to 31℃/88℉) and 50% (40℃/104℉or
higher)
Installation overvoltage categories: CATⅡ
Maximum measurable voltage: DC 30V Max
Pollution degree 2
Max. Altitude: Up to 2000m

USER MANUAL For MULTISCAN P2
Chapter 2 - 2
C. Mechanical Dimensions
Length: 222㎜/ 9"
Width: 187㎜/ 7.5"
Height: 51㎜/ 2"
Weight: 950g / 2.1lb (head unit only)
Body Color: Dark Grey
Safety Boot Color: Blue
All specifications are subject to change without notice for the purpose of product
and quality improvement.

Chapter 2
Hanatech Co., Ltd.
Chapter 2 - 3
II. Part List -----------------------------------------
A. Head unit and basic supplies
1. Head Unit (P/N. 1000-0007)
1) Made of strong ABS resin, each unit has
passed internal impact test before
shipment.
2) As the inner surface is coated with anti-
electromagnetic interference material, it
neither interferes the other electronic
devices nor gets interfered by the other
equipments.
2. Safety Boot (P/N. 2003-0032)
1) Flexible plastic cover that protects the head unit from physical,
chemical and electrical damage
2) Basic color is blue, however, it can be changed according to the
distributor’s demand.

USER MANUAL For MULTISCAN P2
Chapter 2 - 4
3. Carry Case (P/N. 3003-0003)
Provides convenient transportation and the
protection of the head unit and other
components from outer physical impact during
the transportation and storage. Carry case is
provided when purchasing the head unit and at
least one software package together. Includes
keys and dial lock
4. Main Data Link Cable (P/N. 3001-0001)
-Connects vehicle side DLC and MULTISCAN P2 head unit for data
transmission.
-Connecting parts on both ends
are exactly same, therefore,
simply put any one end to the
head unit, and then hook the
other end to the vehicle side
DLC after connecting an
appropriate adaptor
5. Power Cable 1 – Cigarette Lighter (P/N. 3000-0004)
-Supplies power to the head unit
from the cigarette lighter socket.
Used when DLC is located near
the driver or passenger seat and
power is not supplied through
DLC.
-LED lights on both ends turn ON
when power is properly supplied.
-The metal plunger part in the end of cigarette lighter connector is
