H&B JK 20-S User manual

1

2
The information in this document is subject to change without notice. The manufacturer makes no representations or warranties with respect
to the contents hereof and specifically disclaim any implied warranties of merchantability or fitness for any particular purpose. The
manufacturerreservestherighttorevisethispublicationandtomakechangesfromtimetotimeinthecontenthereofwithoutobligationofthe
manufacturertonotifyanypersonofsuchrevisionorchanges.
This publication, including all photographs, illustrations and software, is protected under international copyright laws, with all rights reserved.
Neitherthismanual,noranyofthematerialcontainedherein,maybereproducedwithoutwrittenconsentoftheauthor.
©H&BCopyrightJuly,2003
Readthismanualcarefullybeforeusingthedevice.
•DONOTalterthisdeviceinanyway.Itmaycausefire,injury,electricshock,orseriousdamagetothisdeviceortotheuser.
•Keep this deviceaway from water. Water may cause fire, electric shock, or mechanical or electricalbreakdown.
•DONOTleave this deviceinacarorother places wherethereisthepossiblyof high temperature. Keep it away from the direct rays
of the sun or drastic temperature changes. Being exposed to high temperature may be harmful to thecomponents in this device or
possiblycausefire.
•Useonly therecommendedbatterycharger.Other chargersmaycausefireor productmalfunction.
•Avoidusingthisdeviceinhightemperatureorhighhumiditylocations.Itmaycauseseriousdamagetothedevice.
•Avoiddropping it fromhighplaces.Itmay cause malfunctionorseriousdamageto the device.
•DO NOTuseany accessories other than the ones recommended by the manufacturer. The manufacturer IS NOT responsible for any
malfunctionorbreakdowncausedbytheuseof accessories.
•DONOTclean thisdevicewithalcoholorvolatile detergent.Itmaycausefadingof device surfaces.
•DONOTdisassemblethisdevice.Incaseofproblems,contact theAfterService(A/S)centre.
DISCLAIMER
COPYRIGHT
IMPORTANT SAFETY INF
ORMATION

3
WHAT IS MP3/WMA FORMAT?
MP3 / WMA format files are compressed digital audio files, which consumers can listen to with near CD quality
Commercial CD audio files can be compressed to MP3 / WMA format files, which are suitable for internet transmission due to
their compact size and can be stored in a portable audio device. The users, for example, can record their own favorite music
album, storing it in HDD in a digital audio player.
WHAT IS THIS DIGITAL JUKEBOX PLAYER?
This Digital Jukebox Player is a portable device, which can be used for MP3 music files playback and MP3 files record/playback,
and it additionally can be used as a drive while connected to PC.
You can enjoy CD quality music with the mass storage capacity device, in which you can store up to 5000 songs, because the
digital music files accessed by this Digital Jukebox player are stored in 2.5”HDD.
Furthermore, it can be recognized as portable removable drives when connected to PC or notebook by the USB
interface cable.
PACKING LIST
Please check the following items that can be found in this package.
•Digital Jukebox Player
•Earphone
•USB cable; A to Mini USB type
•AC/DC Adapter
•Carry Case
•User Manual
•Driver installation CD incl. MUSICMATCH Software
1.Under Copyright lawsthe user is liable to obtain the license, before playing or recording copyright protected music, except for personal
use. That is, if you makeone recording only for playing to yourself, or for personal use at home. This applies to music files on Web
pages too!
2.The moment you give only one copy to someone else, you are distributing or duplicating the music and it is no longer for your personal use,
you must obtain a license to do this first.
The supplier holds no liability for any claims if the product ceases to function correctly due to misuse, because it has been dropped, subjected to
violent vibration, extremes of temperature or if any attempt has been made to open thecase, apart from the battery cover, to replace batteries.
1.Normal vibration will not affect the operation of the Digital Jukebox player. However, dropping or shocking may cause damage to the
product.
2.The product is not designed for water-resistant usage. Drenching the product may cause damage.
3.Do not clean up the product with chemicals such as thinners, benzene and alcohol that may deface the surface.
4.Avoid placing the Digital Jukeboxplayer in places of high humidity or close to a heat source.
5.Unintentional electrostatic discharge may shut down or damage the product. You may need to remove then replace the batteries to reset it.
INTRODUCTION
PRECAUTIONS
WARNINGS

4
MINIMUM SYSTEM REQUIREMENTS
§Windows 98SE / ME / 2000 / XP.
§Pentium 200 MHz or above.
§Disk Drive 16MB free hard disk space (to download and upload files from the player).
§32MB system memory
§USB port (A-Type).
NOTE:
lThis specification is for the download driver software supplied with this player only. An increased PC specification
is likely to be required for application software for music file creation.
lIt is highly recommended that charge the battery first before you power on the Digital Jukebox player.
INSTALLING THE DRIVER SOFTWARE
Under Win98 OS, if you plug the Digital Jukebox player into the USB port on your PC, the windows will automatically detect it as
a new hardware and pop out a “New Hardware Found” message. After the above step, the “Add Device Driver Wizard” will show
up automatically. Click the “next” button to follow the on screen instructions to finish the installation process.
1.Click the “search for a suitable driver for my device (recommend)” item and then click the “next” button to continue.
2.In this dialog box, the wizard will ask you to check the optional search location. Please insert the installation CD to CD ROM
drive firstly, check the “specify a location” item, press the “browse” button to specify the driver location selected as the
following path: Audio/HDD Jukebox/Driver and click “OK” button to complete the whole installation.
3.Click My Computer icon at desktop, you will find one “Jukebox” drive in the My Computer window.
INSTALLING THE MUSIC MANAGEMENT SOFTWARE, AudioPhile.exe.
Now it’s time to introduce our sophisticated AudioPhile.exe, music management software between the computer operating
system and the Digital JukeBox player. This section will describe PC System Requirements, installation method and detailed
introduction on Audiophile.exe by steps as follows:
1.PC System Requirements
lMicrosoft Windows 98,Me, 2000 or XP
lPentium II with 32MB RAM and 64 MB RAM (Recommended)
lUSB port
lCD-ROM drive
lInternet connection recommended
l32MB free hard drive space
2.Installation method
lInsert the installation CD into your PC’s CD-ROM drive and go into the windows explorer.
lClick the icon of CD-ROM drive, follow the path: driver CD\Audio\HDD Jukebox\AP\AudioPhile.exe and then just
drag and drop the Audio Phile.exe to anywhere you want it to be stored on your desktop.
3.Executing the AudioPhile.exe
lMake sure the supplied USB cable has been connected right between the PC and MP3 player.
lDouble-click audiophile.exe icon to start the following music management functions and firstly you will see the window
shown below.
INSTALLING SOFTWARE

5
lOn the ”transfer”tab, you can do the following features described below by function-oriented items:
1.To download files to your MP3 player
lGo click the specified folder and then the file name(s) saved in the folder will show up soon in the file list on PC.
lSelect the desired MP3 file(s) shown in the file list on PC and then click the “Send to player”button to download
to the MP3 player. Meanwhile the progress bar will dynamically show the status of the progress.
2.To upload files to your PC system
lSelect the desired MP3 file(s) stored in the “music”tab, the file list on MP3 player, and then click the “Back to PC”
button to upload to the PC system. Meanwhile the progress bar will dynamically show the status of the progress.
lOn the “My Collection”tab, you can easily manage or reorganize your music files. The related descriptions are
as follows:
