Instructions
Keep the instruction near the product after reading.
Please retain the instruction since it is included with the guarantee
Portable hydrogen
water generator
• Chosen as a product recommended
by the Corporation Aggregate Korea Atopy Association
• Certified company with the relief mark
by the Corporation Aggregate Korea Atopy Association
• Certified company with ISO 9001 / ISO 14001
• Patent registration for the invention venture company certification
1. Company name : Handong Hydro Co.,Ltd.
2. Model : Hydrogen water maker(H2-mini)
3. Manufacturer : Handong Hydro Co.,Ltd.
/ Made in Korea
2H2-mini
Instructions
■
Product name
Portable hydrogen water generator
■
Model name
H2-mini
■
Size
70 x 88 x 270mm
■
Weight
425g
■
Capacity
500ml
■
Rated voltage
power consumption
DC 15V 1.0A / 2.5W
■
Certification No.
HU10553-11006
■
Power supply
for an adapter
AC 100~220V 50/60Hz 1.5A
■
Material
Tritan, ABS
■
Electrode
Titanium+ white gold plating
■
Components
Body, Charger
■
Lifespan of
electrode
Semi-permanent (Battery and electrode should be replaced in ve years)
■
Number of use per a charge
60 to 90 times
✽
Separately
purchased
Chlorine remover, charger for cars
Body
Chlorine Remover
Switch
Cap
DC Jack
Optional
The name of each part
Product specication
3
H2-mini Instructions
Receive H2-mini box. Take out and
check all the components in the box
(body, charger, product and manual).
●
Use designated charger to charge at least more than two hours.
● If you use the product for the first time, fill 60 to 80 degree of water and press
the operation button without closing the lid to produce hydrogen and through
water out for cleansing.
●
Put drinking water (bottled water, purified water or groundwater) in H2-mini.
* While tap water is not harmful to human body, it can have the smell of
disinfectant. You can use a chlorine remover (sold separately) to avoid that.
●Please fill at least half or more of water when using the product.
●
Recommended water temperature is 10~40 ℃. In general, the lower the
temperature of water, the higher the amount of dissolved hydrogen.
●
Close the lid until you hear the 'click' sound.
Use the product after washing inside of
the body with water. Do not use
detergent or organic solvent.
2
Fill at least half or two-third of water. (If
you use the product for the first time, fill
60 to 80 degree of water and press the
operation button without closing the lid
to produce hydrogen and through water
out for cleansing.)
3
Press the operation button once to operate the
product. LED light will be turned off automatically
after three to six minutes, indicating the
completion of producing hydrogen. You can
have dissolved hydrogen until at least two hours
after it has been produced).
4
1
How to use product
Please read it before using it for the rst time.
4H2-mini
Instructions
▶
Water types
Water types that can be used in the product :
Please use drinking water (bottled water, puried
water and groundwater).
* Please use a chlorine remover (sold separately) when using tap water.
Unavailable water :
Reverse osmosis water, distilled water and water with a lot of heavy metal.
▶ Movements regarding use
After lling water into the pot, if you push the button, it will work for 3~7min with ickering LED
light and stop automatically.
▶ Intake time
You can have water abundant in hydrogen until at least two hours after the creation.
It is recommended that you press operation button again afterward.
▶ About charging
In case of connecting charger :
If you connect charger, red LED will appear on the operation button (H) and start charging.
Green LED will be turned on after completing charging.
* Be sure to start a car before using car charger (sold separately)
▶If you do not use the product for a long time
●
If you do not use the product for a long time (more than one week), keep the inside dry after
washing. Take disincentive action before re-using the product.
▶ How to disinfect the inside
●
Fill hot water (60 ℃~90 ℃) and press the button to create hydrogen with the open lid. If you
close the lid, you can get burned due to heat.
●
Once the hydrogen is generated, discard the water before use.
▶ How to clean the outer body
●
Soak a soft cloth in lukewarm water and wipe the product out.
●
Do not use sulfate, hydrochloric acid or organic solvents (thinner, acetone, etc.) to wipe out the
surface of the product or attack stickers. It may damage the surface.
Checklists when using the product
5
H2-mini Instructions
This information is to protect the safety of users and prevent property damages.
Be sure to read the instructions carefully and use the product correctly.
●
White form that is produced during the generation of hydrogen water is a process of
generating hydrogen and is not harmful to human body.
●
In case that there is a strange noise, smell or smoke from the product, please contact
to customer service immediately.
●
Do not arbitrarily disassemble, repair or modify the product.
●
The material that has been used in the product is called tritan, material used in baby
bottle or used by Lock & Lock, and you would not need to worry about endocrine
disruptor.
●
You can keep the product clean and sanitary if you clean the inside with hot water
(60℃ ~ 90℃) once a week (Do not use cleaners or scrubbers).
●
Be sure to open the lid when using hot water or you can get burn
due to internal pressure or hot steam.
●
Do not put the bucket in a washing machine. This may cause
a malfunction of the internal parts.
●
When you combine the cap and its body after separation of the cap from its body,
Please pay special attention lest the rubber ring rolled up
(Because it caused the water leak. Don’t separate them as far as possible)
●
This product was done the waterproofing. But, because of electronic goods, please
pay attention lest water enter to the switch and recharging socket.
●
Chlorine remover (Instructions and replacement cycle are specified separately)
●
Car charger (Be sure to use the product while starting the engine)
www.handonghydro.com
All the information on hydrogen (H2) can be found in the website!
Precautions
Separately sold products
6H2-mini
Instructions
Check
Check
Check
Is the battery charged?
Did you clean the inside of the product?
Check
The battery might be low.
Check
Did you use different kinds of drinking water or the temperature?
Check
Did you use water that does not contain minerals (reverse osmotic pressured
water)?
Did you use tap water?
Measure
Measure
Measure
Connect the power to charge the product for more than two hours and then press
the operating button.
We recommend you clean the inside once a week.
Measure
Use the charger to charge the product for more than two hours.
Measure
The amount of hydrogen can vary depending on water quality or temperature.
Measure
Use recommended water such as drinking water and then press the operation
button.
It might smell disinfectant if you use tap water while cleaning the product. While it
is not harmful to human body, it is better to use chlorine remover (optional).
▶ The product does not operate
▶ Water tastes weird.
▶ The product stops suddenly during operation.
▶ The amount of hydrogen (bubbles) is different.
▶ Hydrogen (bubbles) is not generated.
Be sure to check the following before you ask repair.
Checklists before reporting a failure of the product
WARRANTEE
For the service
In accordance with the consumers dispute settlement regulations (notification of the Fair Trade
Commission), Handong Hydro carries out a warranty for the product as follows. In case that you
request service, Handong Hydro will provide service to your request. We will give a response
regarding the warranty and details within 14 days from the request.
Date of purchase
Sales price
Warrantee period
Model Name
One year H2-mini
Address
Address
Customer Name Telephone
Salesperson Name Telephone
Free service
Warranty period will be reduced in half if you use the product for a business purpose.
Types of customer damage Within warranty period After warranty period
In case that an exchange is not possible Refund N/A
In case that the same failure occurs less than
two times within warranty period Free repair Paid repair
In case that the same failure occurs three times
within warranty period Exchange or refund Paid repair
In case that failure occurs ve times for different
reasons within warranty period. Exchange or refund Paid repair
If a business loose the product that a customer
demands to repair. Exchange Exchange
Damages incur during the transportation. Exchange N/A
Paid service
Category Details
If it not a product
failure
Other cases
If a failure occurs
due to the
negligence of a
customer
■
Loss of product due to the movement of product or moving of a house
■
Inexperienced use of product by a customer
■
Internal cleansing service request
■
Product failure due to natural disasters (lightning, re, damage from sea wind, ood
damage, etc.)
■
In case that the lifetime of consumable parts are expired (chlorine remover, etc.)
■
In case that a customer lost consumables by mistake
■
In case of product failure due to the negligence of a customer or modication
■
In case that a product failure occurs due to the wrong electricity capacity
■
In case that a product failure occurs due to an external shock or falling of the product
■
In case that a product failure occurs due to A/S by staffs not afliated with Handong Hydro
■
In case that a product failure occurs due to the use of components or options not
specied by Handong Hydro
■
Product failure due to a non-adherence of precautions in the manual
