Hannlomax HX-301CD User manual

CD/MP3 Boombox
With AM/FM Radio
Model : HX-301CD
INSTRUCTION MANUAL
Note: Please read and follow these instructions before operating your unit.
SAFETY INSTRUCTION
TO PREVENT FIRE OR SHOCK HAZARD. DO NOT EXPOSE THIS APPLIANCE TO RAIN OR
MOISTURE.
THIS APPLIANCE SHALL NOT BE EXPOSED TO DRIPPING OR SPLASHING WATER AND THAT NO
OBJECT FILLED WITH LIQUIDS SUCH AS VASES SHALL BE PLACED ON APPARATUS.
The lightning flash with
arrowhead symbol, within an
equilateral triangle, is
intended to alert the user to
the presence of uninsulated
“dangerous voltage” within
the products enclosure that
may be of sufficient
magnitude to constitute a risk
of electric shock to persons.
CAUTION
The exclamation point within
an equilateral triangle is
intended to alert the user to
the presence of important
operating and maintenance
(servicing) instructions in the
literature accompanying the
appliance.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
Warning: To reduce the rise of
electric shock, do not remove
cover (or back) no
user-serviceable parts inside.
Refer servicing to qualified service
personnel.
IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide
blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult
an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and
the point where they exit from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer,
or sold with the apparatus. When a cart is used, use caution when moving the
cart/apparatus combination to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused for long periods of
time.
14. Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does
not operate normally, or has been dropped.
15. Grounding or Polarization – This product may be equipped with a polarized alternating-current line plug (a
plug having one blade wider than the other). This plug will fit into the power outlet only one way. This is a
safety feature. If you are unable to insert the plug fully into the outlet, try reversing the plug. If the plug
should still fail to fit, contact your electrician to replace your obsolete outlet. Do not defeat the safety
purpose of the polarized plug.
16. Alternate Warnings – This product is equipped with a three-wire ground-type plug, a plug having a third
(grounding) pin. This plug will only into a grounding-type power outlet. This is a safety feature. If you are
unable to insert the plug into the outlet, contact your electrician to replace your obsolete outlet. Do not
defeat the safety purpose of the grounding-type plug.
17. Ventilation – Slots and openings in the cabinet are provided for ventilation and to ensure reliable operation
of the product and to protect it from overheating, and these openings must not be blocked or covered. The
openings should never be blocked by placing the product on a bed, sofa, rug, or other similar surface. This
product should not be placed in a built-in installation such as a bookcase or rack unless proper ventilation is
provided or the manufacturer’s instructions have been adhered to.
18. The MAINS plug or an appliance coupler is used as the disconnect device, the disconnect device shall
remain readily operable.
19. 回: CLASS II apparatus with double insulation, and no protective earth provided.
20. Caution Marking and rating plate was located at bottom enclosure of the apparatus.
21. WARNING : To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture.
22. The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such as
vases, shall be placed on apparatus.
23. The mains plug is used as disconnect device. The mains plug of apparatus should not be obstructed OR
should be easily accessed during intended use. To be completely disconnect the power input, the mains
plug or apparatus shall be disconnected from the mains.
24. Battery shall not be exposed to excessive heat such as sunshine, fire or the like.
25. Excessive sound pressure from earphones and headphone can cause hearing loss.
- 1 -

FCC NOTICE
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different from that to which the receiver is needed.
– Consult the dealer or an experienced radio/TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions :
(1) This device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
WARNING:
Changes or modifications to this unit not expressly approved by the party responsible for compliance could void
the user's authority to operate the equipment.
- 2 -
LOCATION OF CONTROLS
1. Carry Handle 16. CD FOLDER UP Button
2. CD Compartment 17. CD SKIP/SEARCH Button
3. BAND Switch 18. CD Button
4. TUNING Knob 19. CD Button
5. FUNCTION Switch 20. CD MODE Button
6. Dial Scale 21 LCD Display
7. Cassette STOP Button 22. POWER Indicator
8. Cassette F.F. Button 23. FM ST. Indicator
9. Cassette REWButton 24. Cassette Compartment
10. Cassette EJECT Button 25. Speaker
11. Cassette ◄PLAY Button 26. Rod Antenna
12. Cassette REC Button 27. Headphone Jack
13. VOLUME Control Knob 28. Battery Compartment
14. CD Door OPEN Button 29. AC Socket
15. CD SKIP/SEARCH Button
CONNECTING THE UNIT TO POWER
AC OPERATION
Before operation, please make sure that the VOLTAGE mentioned on the unit is same as the
voltage of your local area. Unravel the AC power cord, insert one end into the AC socket on the set,
and the other end into a standard AC outlet.
- 3 -

ATTENTION
1. Do not plug or unplug the power cable while you have wet hands.
2. When planning not to use this unit for a long time, disconnect the power cable from the wall
outlet.
3. When disconnecting the power cord from the wall outlet, do not pull on the cord in order to
avoid shock risks caused by damaged cable.
BATTERY OPERATION
Disconnect the AC Cord Set completely. Open the Battery Compartment Door and insert 6 pieces
UM-2 "C" size batteries into the battery compartment with battery polarity as shown inside the
battery compartment.
RADIO OPERATION
1. Set the FUNCTION switch to RADIO position.
2. Set the BAND switch to the AM or FM position.
3. Turn the TUNING knob to your desired radio station.
4. Adjust the sound level by rotating the VOLUME control knob.
FM STEREO INDICATOR
When turn to a FM stereo broadcast, the FM ST. LED Indicator will light up.
ANTENNA
For best reception, fully extend the FM Antenna to receive FM stations. For AM reception, the unit
has a built-in antenna, turn the whole unit for best reception.
CD/MP3 OPERATION
Playing a Compact Disc
1. Set the FUNCTION switch to CD position. Open the CD compartment by pushing the CD door
OPEN button.
2. Place a CD into the CD compartment and close the CD door.
3. The unit will start reading the disc and the total number of tracks in the entire disc will display.
4. Press the CD button to start playing the disc.
5. During playing, press the CD button to temporarily pause playing. To resume playing,
pressed the CD button again.
6. To stop playing, press the CD button.
Playing a MP3 Disc
1. Set the FUNCTION switch to CD position. Open the CD compartment by pushing the CD door
OPEN button.
2. Place a MP3 disc into the CD compartment and close the CD door.
3. The unit will start reading the disc and the total number of tracks in the entire disc will display.
4. Press the CD button to start playing the disc.
5. During playing, press the CD button to temporarily pause playing. To resume playing,
pressed the CD button again.
6. If the MP3 disc have folders, you can press the CD FOLDER UP button to skip to the next
folder.
7. To stop playing, press the CD button.
- 4 -
Skip Mode
During playing or in pause mode
1. Press the CD SKIP/SEARCH button to go to the next track.
2. Press the CD SKIP/SEARCH button to go back to the beginning of the track.
3. Press the CD SKIP/SEARCH button twice to go back to the previous track.
4. Press and hold the CD SKIP/SEARCH button, it will search the track with audible high
speed forward.
5. Press and hold the CD SKIP/SEARCH button, it will search the track with audible high
speed backward.
Different Play Mode
During CD playback, you can press the CD MODE button to accomplish different kinds of play
mode as below
.
Note:
Because of none-standardized format definition/production of MP3 CD, playback quality &
performance are not guaranteed.
Manufacturer is not responsible for the playability of MP3 in any case due to recording conditions
such as PC performance, writing software, media ability and etc.
CASSETTE OPERATION
Tape Playback
1. Press the Cassette EJECT button to open the cassette door, insert a cassette tape into the
Cassette Compartment and push the cassette door to close.
2. Slide the FUNCTION switch to TAPE position and press the Cassette ◄PLAY button to start
playing the tape.
3. Adjust the VOLUME control knob to your desired volume level.
4. To stop the tape, simply press the Cassette STOP button.
- 5 -

Fast Forward and Rewind
The tape can be fast forward or rewind by pressing the Cassette F.F. button or Cassette REW
button respectively.
Auto Stop System
When the tape runs to its end during playback or recording, the cassette operation will be stopped
automatically.
CAUTION: To avoid damage to the cassette mechanism or to the cassette tape, always press the
Cassette STOP button between each operation
RECORDING FROM THE RADIO
1. Tune to desired radio program as described in the "RADIO OPERATION" section.
2. Insert a blank cassette tape into the Cassette Compartment.
3. Press the Cassette REC button and the Cassette ◄PLAY button simultaneously to start
recording. With the built-in Automatic Level Control (ALC), the best recording quality is
automatically adjusted. Changing the volume level will not affect the recording.
4. Press the Cassette STOP button to stop recording.
5. When the tape runs to its end, the cassette operation will be stopped automatically.
RECORDING FROM CD PLAYER
1. Set the FUNCTION switch CD position.
2. Insert a CD or MP3 disc into the CD compartment and close the CD door.
3. Insert a blank cassette into the Cassette compartment.
4. Press the Cassette REC button and the Cassette ◄PLAY button simultaneously to start
recording.
5. Activate the CD player, playing in a desired track as described in the CD/MP3 OPERATION
section.
6. Press the Cassette STOP button to stop recording.
7. When the tape runs to its end, the cassette operation will be stopped automatically.
8. With the built-in Automatic Level Control (ALC), the best recording quality is automatically
adjusted. Changing the volume level will not affect the recording.
STEREO HEADPHONE JACK
For private listening, insert the plug of a stereo headphone into the Stereo Headphone Jack and
adjust the VOLUME control knob accordingly. During the use of a headphone, the speakers are
automatically disconnected.
- 6 -
CARE AND MAINTENANCE
Precautions
Always turn off the unit after use.
Keep the unit away from magnetic objects, water or heat sources.
Use a clean soft cloth moistened with lukewarm water to clean the cabinet. Never use
chemical cleaners that could damage the finish of the unit.
Never touch the CD pickup and lens. If fingerprints get on the pickup lens, clean it gently with
a commercial lens cleaner.
Disconnect the unit from any power sources before cleaning.
To remove a disc from its storage case, press down on the centre of the case and lift the disc
out, holding it carefully by the edges.
Fingerprints and dust should be carefully wiped off the disc’s recorded surface with a soft cloth.
Unlike conventional records, compact discs have no grooves to collect dust and microscopic
debris so gently wiping with a soft cloth should remove most particles. Wipe in a straight line
from the inside to the outside of the disc. Small dust particles and light stains will have
absolutely no effect on reproduction quality.
Never use chemicals such as record sprays, anti-static sprays, benzene or thinners to clean
compact discs. These chemicals can irreparably damage the disc’s surface.
Discs should be returned to their cases after use. This avoids serious scratches that could
cause the Laser pickup to skip.
Do not expose discs to direct sunlight, high humidity, or high temperatures for extended
periods. Long exposure to high temperatures can warp the disc.
Do not stick paper or write anything with a ballpoint pen on the label side of the disc.
SPECIFICATIONS
Frequency Range: AM 530 - 1710 KHz
FM 88 - 108 MHz
Power Supply: AC 120V ~ 60 Hz
DC9V(UM-2x6)
Specifications are subject to change without further notice.
- 7 -
