Hannlomax HX-309CD User manual

CD Boombox with Radio
USB Port for MP3 playback
And Bluetooth
Model HX-309CD
(Bluetooth pair code HX-309CD Hannlomax)
INSTRUCTION MANUAL
Note Please read and follow these instructions before using your unit
1 Read these instructions Keep these instructions Heed all warnings Follow all instructions
2 Do not use this apparatus near water
3 Clean only with dry cloth
4 Do not block any ventilation openings Install in accordance with the manufacturer’s instructions
5 Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat
6 Do not defeat the safety purpose of the polarized or grounding-type plug A polarized plug has two
blades with one wider than the other A grounding type plug has two blades and a third grounding
prong The wide blade or the third prong are provided for your safety If the provided plug does not fit
into your outlet, consult an electrician for replacement of the obsolete outlet
7 Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles, and the point where they exit from the apparatus
8 Only use attachments/accessories specified by the manufacturer
9 Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold
with the apparatus When a cart is used, use caution when moving the cart/apparatus
combination to avoid injury from tip-over
10 Unplug this apparatus during lightning storms or when unused for long periods of time
11 Refer all servicing to qualified service personnel Servicing is required when the apparatus
has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture,
does not operate normally, or has been dropped
12 Grounding or Polarization – This product may be equipped with a polarized alternating-current line
plug (a plug having one blade wider than the other) This plug will fit into the power outlet only one
way This is a safety feature If you are unable to insert the plug fully into the outlet, try reversing the
plug If the plug should still fail to fit, contact your electrician to replace your obsolete outlet Do not
defeat the safety purpose of the polarized plug
13 Alternate Warnings – This product is equipped with a three-wire ground-type plug, a plug having a
third (grounding) pin This plug will only into a grounding-type power outlet This is a safety feature If
you are unable to insert the plug into the outlet, contact your electrician to replace your obsolete
outlet Do not defeat the safety purpose of the grounding-type plug
14 Ventilation – Slots and openings in the cabinet are provided for ventilation and to ensure reliable
operation of the product and to protect it from overheating, and these openings must not be blocked
or covered The openings should never be blocked by placing the product on a bed, sofa, rug, or
other similar surface This product should not be placed in a built-in installation such as a bookcase
or rack unless proper ventilation is provided or the manufacturer’s instructions have been adhered to
15 The MAINS plug or an appliance coupler is used as the disconnect device, the disconnect device
shall remain readily operable
16 回: CLASS II apparatus with double insulation, and no protective earth provided
17 Caution Marking and rating plate was located at bottom enclosure of the apparatus
18 To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture
19 The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids,
such as vases, shall be placed on apparatus
20 The mains plug is used as disconnect device The mains plug of apparatus should not be obstructed
OR should be easily accessed during intended use To be completely disconnect the power input,
the mains plug or apparatus shall be disconnected from the mains
21 Battery shall not be exposed to excessive heat such as sunshine, fire or the like
22 Excessive sound pressure from earphones and headphone can cause hearing loss
FCC NOTICE
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules These limits are designed to provide reasonable protection against harmful
interference in a residential installation This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications
However, there is no guarantee that interference will not occur in a particular installation If this equipment
does cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
– Reorient or relocate the receiving antenna
– Increase the separation between the equipment and receiver
– Connect the equipment into an outlet on a circuit different from that to which the receiver is needed
– Consult the dealer or an experienced radio/TV technician for help
This device complies with part 15 of the FCC Rules Operation is subject to the following two conditions :
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation
-1-
LOCATION OF CONTROLS

1 BAND button 11 Carry handle
2 PROG/MEM button 12 AUX-IN jack
3 FOLDER/M− button 13 Speaker
4 MODE/M+ button 14 LCD display
5 STOP CD/USB button 15 FUNCTION switch
6 PLAY/PAUSE button 16 VOLUME control
7 SKIP−/TUN− button 17 Battery Compartment
8 SKIP+/TUN+ button 18 AC socket
9 Rod antenna 19 USB port for MP3 playback
10 CD Compartment
- 2 -
AC OPERATION
Before operation, please make sure that the VOLTAGE mentioned on the unit is same
as the voltage of your local area Unravel the AC power cord, insert one end into the AC
socket on the set, and the other end into a standard AC outlet
ATTENTION
1 Do not plug or unplug the power cable while you have wet hands
2 When planning not to use this unit for a long time, disconnect the power cable from
the wall outlet
3 When disconnecting the power cord from the wall outlet, do not pull on the cord in
order to avoid shock risks caused by damaged cable
BATTERY OPERATION
Disconnect the AC cord set completely Open the battery compartment door and insert
8 pieces UM-2 "C" size batteries into the battery compartment with battery polarity as
shown inside the battery compartment
RADIO OPERATION
1 Set the FUNCTION switch to RADIO position
2 Press the BAND button to select the desired AM or FM broadcasting
3 Auto Tuning :
Press and hold the SKIP+/TUN+ or SKIP−/TUN− button for approximately 1 second, it
will start to search the next radio station in the direction of the search The search
operation simply finds stations with strong signals
4 Manual Tunning:
Stations with weak reception can only be tuned in manually Press the SKIP+/TUN+ or
SKIP−/TUN- button, the unit skips 0 05 MHz (FM) or 9 KHz (AM) in the direction of skip
5 Adjust the sound level by rotating the VOLUME control
6 To turn off the radio, set the FUNCTION switch to other position
ANTENNA
For best reception, fully extend the FM Antenna to receive FM stations For AM
reception, the unit has a built-in antenna, turn the whole unit for best reception
-3-

SAVING A RADIO STATION TO THE MEMORY
1 Tune the radio to the desired station
2 Press the PROG/MEM button to store this radio station in the next memory station
number The display will show PXX (XX is the memory station number )
3 Press the FOLDER/M− or REPEAT/M+ button to select the desired station number
4 Press the PROG/MEM button to confirm, the radio station will stored in the memory
5 Up to 10 AM and 10 FM radio stations can be stored in the memory
TO LISTEN TO A SAVED RADIO STATION
Press the REPEAT/M+ button or RANDOM/M− button to select the stored stations in
the memory
BLUETOOTH OPERATION
Connecting BLUETOOTH
1 Set the FUNCTION switch to BT position
2 “bt” and Bluetooth logo will show in the LCD display
3 Turn on the Bluetooth of your device and search the unit for connection Your
Bluetooth device should find “HX-307CD HANNLOMAX” (If password is needed
for connection, please enter “0000” )
4 If connection is successful, your Bluetooth device will show Bluetooth is connected
Also, the Bluetooth logo will stop flashing
5 Select and play the audio file though your Bluetooth device
6 During playing, press the PLAY/PAUSE button to temporarily pause playing To
resume, press the PLAY/PAUSE button again
7 During play or pause mode, press the SKIP+/TUN+ button to go to the next track
8 During play or pause mode, press the SKIP-/TUN- button to go to the previous
track
9 To stop this function, set the FUNCTION switch to other position
AUTO PAIRING
Once the unit paired with the Bluetooth device, it will automatically pair with that device
next time when you turn on the unit and that Bluetooth device
- 5 -
CD/MP3/USB OPERATION
Playing Audio CDs
1 Set the FUNCTION switch to CD/USB/AUX position
2 Press and hold the STOP CD/USB button to select CD mode
3 Insert the CD disc in the CD compartment and close the CD door, the unit will start
reading the disc and start playing the first track of the entire disc
4 During playing, press the PLAY/PAUSE button to temporarily pause playing To
resume, press the PLAY/PAUSE button again
5 Adjust the VOLUME control to the desired volume level
6 To stop playing the CD, press the STOP CD/USB button
Playing MP3 disc
1 Set the FUNCTION switch to CD/USB/AUX position
2 Press and hold the STOP CD/USB button to select CD mode
3 Insert a MP3 disc in the CD compartment and close the CD door, the unit will start
reading the disc and start playing the first MP3 files on the entire disc
4 If your MP3 disc has folders, press and hold the FOLDER/M− button, FOLDER will
appear and flash on the display
5 Press the SKIP+/TUN+ or SKIP−/TUN− button to select the desire folder
6 During playing, press the PLAY/PAUSE button to temporarily pause playing To
resume, press the PLAY/PAUSE button again
7 Adjust the VOLUME control to the desired volume level
8 To stop playing the MP3 disc, press the STOP CD/USB button
-6-

Playing MP3 files with USB device
1 Set the FUNCTION switch to CD/USB/AUX position
2 Press and hold the STOP CD/USB button to select USB mode
3 Plug your USB device into the USB port on the unit, the unit will start reading the
files in the USB device and start playing the first track on the entire device
4 If your USB device has folders, press and hold the FOLDER/M− button, FOLDER
will appear and flash on the display
5 Press the SKIP+/TUN+ or SKIP−/TUN− button to select the desire folder
6 During playing, press the PLAY/PAUSE button to temporarily pause playing To
resume, press the PLAY/PAUSE button again
7 During playing, press the PLAY/PAUSE button to temporarily pause playing To
resume, press the PLAY/PAUSE button again
8 Press the STOP CD/USB button to stop playing
Skip Mode
1 During play or pause mode, press the SKIP+/TUN+ button to go to the next track
2 If the MP3 disc or storage device has folders, when the end of the folder is reached,
press the SKIP+/TUN+ button will go to the first MP3 file of the next folder
3 While playing, press the SKIP−/TUN− button twice will go to the previous track
4 If the MP3 disc or storage device has folder, when reaching the beginning of the
folder, press the SKIP−/TUN−button will go to the last file of the previous folder
Programming the Track
The programming of the CD player should be done during STOP mode
1 Press the PROG/MEM button, the LCD display will show P01
2 Press the SKIP+/TUN+ or SKIP−/TUN− buttons to select the desired track
3 Press the PROG/MEM button again to store this track in memory, the LCD display
will show P02
4 Repeat steps from 2 to 3 to store more tracks in memory
5 For Audio CD, you can store up to 20 tracks in the memory and for MP3 files, you
can store up to 99 tracks in the memory
6 Press the PLAY/PAUSE button to play the disc in the programmed order
7 To stop playing, press the STOP CD/USB button
8 To cancel the programming list, press the STOP CD/USB button and open the CD
door or set the FUNCTION switch to other position
-7-
Different Play Mode
Press the MODE/M+ button to select different kinds of play mode with the following
sequence
For CDA files: Repeat One  Repeat All  Normal
For MP3 files: Repeat One  Repeat Folder  Repeat All  Normal
 Repeat 1 – repeat the track being played
 Repeat All – repeat all the tracks in the storage device
 Repeat Folder – repeat the tracks in the entire album/folder
 Normal – play the tracks in sequence
MP3/AUX IN CONNECTION
1 Set the FUNCTION switch to CD/USB/AUX position
2 Insert one side of the audio cable (requires 3 5mm stereo plug, not supplied) into
the line-out jack or phones jack on your MP3 player and the other side to the aux-in
jack on the unit
3 Turn on your MP3 player and follow the playback instruction
4 Adjust the VOLUME control to the desired volume level
5 To stop this function, simply turned off your MP3 player or set the FUNCTION switch
to other position
-8-

CARE AND MAINTENANCE
 Always turn off the unit after use
 Keep the unit away from magnetic objects, water or heat sources
 Use a clean soft cloth moistened with lukewarm water to clean the cabinet Never
use chemical cleaners that could damage the finish of the unit
 Never touch the CD pickup and lens If fingerprints get on the pickup lens, clean it
gently with a commercial lens cleaner
 Disconnect the unit from any power sources before cleaning
 To remove a disc from its storage case, press down on the centre of the case and
lift the disc out, holding it carefully by the edges
 Fingerprints and dust should be carefully wiped off the disc’s recorded surface with
a soft cloth Unlike conventional records, compact discs have no grooves to collect
dust and microscopic debris so gently wiping with a soft cloth should remove most
particles Wipe in a straight line from the inside to the outside of the disc Small
dust particles and light stains will have absolutely no effect on reproduction quality
 Never use chemicals such as record sprays, anti-static sprays, benzene or
thinners to clean compact discs These chemicals can irreparably damage the
disc’s surface
 Discs should be returned to their cases after use This avoids serious scratches
that could cause the Laser pickup to skip
 Do not expose discs to direct sunlight, high humidity, or high temperatures for
extended periods Long exposure to high temperatures can warp the disc
 Do not stick paper or write anything with a ballpoint pen on the label side of the
disc
SPECIFICATIONS
Frequency Range: AM 530 - 1600 KHz
FM 87 5 - 108 MHz
Power Supply: AC 120V ~ 60Hz
DC 12V (UM-2 x 8 pcs)
Specifications are subject to change without further notice
-9-
TROUBLE SHOOOTING
Symptom Possible Problem Solution
AC power cord is not plugged
properly into a wall outlet or
the connector is not plugged
into the AC Socket on the back
of the System
Re-plug the AC power
cord into the wall outlet
and the connector into AC
Socket on the System
Unit does not
respond (no power)
Wall outlet is not functioning Plug another device into
the same outlet to confirm
the outlet is working
Radio no sound
Unit not in RADIO function
mode
Volume set at minimum
Tap FUNCTION button to
RADIO position
Increase Volume
Noise or sound
distorted on AM or
FM broadcast
Station not tuned properly for
AM or FM
FM: Wire antenna is not fully
extended
AM: The reception at the set
location is poor
Retune the AM/FM broadcast
station
FM: Fully extend or reposition
the FM wire antenna
AM: Change the position for the
best reception
CD disc does not
play
Unit not in CD function
mode
Audio disc is installed
incorrectly
It the disc is self-compiled, the
media used may not be
compatible with the player
Select CD mode
Insert audio disc with label
side up
Use better quality blank media
and retest
Audio disc skips
while playing
Disc is dirty or scratched Wipe disc with clean cloth or
use another disc
Intermittent sound
from the player
Dirty or defective disc
Dirty pick up lens
Player is subject to excessive
shock or vibration
Clean or replace the
defective disc
Use a lens cleaning disc to
clean the lens
Relocate the player away
from shock or vibration
Unit gets warm after
extended play at
high volume
This is normal Turn the unit off a period
of time or lower volume
