HANNspree HannSpad SN1W72 User manual

SN1AW72(HSG1297)

1
English
Contents
Precautions...................................................................................................................... 4
Declaration....................................................................................................................... 5
What’s in the box............................................................................................................. 6
1. Product Overview....................................................................................................... 7
Front View ........................................................................................................7
Back View ........................................................................................................8
How to remove the SD & SIM card cover ...........................................................8
2. Initial Operation .......................................................................................................... 9
Managing and Charging the Battery ...................................................................9
Connecting to the Wi-Fi Network .....................................................................10
Connecting PC and Data Transmission ............................................................11
Use Micro SD card ..........................................................................................11
3. The Android Interface .............................................................................................. 12
Home Screen..................................................................................................12
Extended Home Screen...................................................................................13
Customizing the Home Screen Panels .............................................................13
Managing Applications ....................................................................................13
Creating Application Folders ...........................................................................14
4. System Firmware Update ........................................................................................ 15
SIM Management ............................................................................................15
Voice call...................................................................................................15
Video Call ..................................................................................................16
Message ....................................................................................................16
Data Connection ........................................................................................16
5. Product Specifications ............................................................................................ 17
6. Appendix ................................................................................................................... 18

2
English
Control information
This device is in accordance with the requirements in Radio & Telecommunications Terminal Equipment Directive
1995/5/EC.
This device complies with the requirements in EMC Electromagnetic Compatibility Directive 2004/108/EC and Low Voltage
Directive 2006/95/EC.
The highest CE SAR value for the device is 1.81 W/Kg.
Recycling information
Hannspree attaches great importance to our environmental policy, and firmly believe that we can better protect the "health"
of the earth by properly disposing and recycling the industrial technological equipment that has reached service life.
These devices contain recyclable materials, which can be re-added to new material after decomposition. In contract, other
materials are classified as dangerous and toxic substances. We sincerely hope that you contact the relevant institutions
based on the information we provide to recycle this product.
For more information, please visit:
http://www.hannspree.com/

3
English
Preventing Hearing Loss
Caution: Permanent hearing loss may occur if earphones or headphones are used at high volume for prolonged periods of
time.
This device have been tested to comply with the Sound Pressure Level requirement laid down in the applicable
EN 50332-1 and/or EN 50332-2 standards.

4
English
Precautions
For the correct use and good performance of the device, the user must fully understand the manual as well as strictly
follow the instructions provided.
• Please avoid high temperatures (over 35°C) or low temperatures (below 0°C).
• Never knock the main machine violently.
• Never let the device come in contact with chemicals such as benzene, thinner etc.
• Do not let the device get close to strong magnetic field, electric field etc.
• Keep away from direct sunlight or heating appliances.
• Never privately dissemble, repair or modify the device.
• Using the device and the earpiece during bicycling, car and motorcycle driving is likely to cause danger.
• Never use higher volume, which may damage your hearing ability.
• Please charge under the following circumstances:
A. The battery icon shows no power ( ) on the upper-right corner of the screen.
B. The system automatically shuts down, and immediately shuts down after a re-start.
C. The operating button does not respond.
D. The product displays the red icon ( ) on the upper-right corner of the screen.
HANNspree Europe Holdings BV: Marco Poloweg 6
5928 LE Venlo The Netherlands
HANNspree UK Ltd: Ground Floor, Suite F, Breakspear Park, Breakspear Way, Hemel Hempstead, Hertfordshire,
HP2 4TZ
Do not attempt to replace the battery of your HannsPad yourself, you may damage the battery and this could cause
overheating and injury. The lithium-ion battery in you HannsPad should be replaced only by HANNspree or a HANNspree
Authorized Service Provider, and must be recycled or disposed of separately from household waste. Do not incinerate the
battery. For more information about battery recycling and replacement, go to
http://www.hannspree.eu/en/support/battery-replacement.
The Li-ion battery package in the product is not serviced and replaced.
DO NOT throw the battery in municipal waste.
The symbol of crossed out wheeled bin
indicates that the battery should NOT be
placed in municipal waste.

5
English
Declaration
1. The information in this manual may not, except under written license by The Company, be copied, transmitted,
distributed, or stored.
2. Although efforts have been made for the correctness and completeness during the preparation of the manual, there is
no guarantee that this manual is free from any error or omission. The Company assumes no reliability regarding the
errors or omissions that might exist in the manual.
3. For sustainable development, The Company reserves the right to modify and improve any product described in this
manual without prior notice.
4. Under no circumstance shall the Company assume any liability, direct or indirect, related to data or income loss, or any
special, accidental, incidental or indirect losses.

6
English
What’s in the box
Check Supplied Items
This Quick Start Guide and a Warranty card are also included.
• If any item is damaged or missing, contact your point of purchase for assistance.
• Use only approved accessories.
• Accessories may vary by country or region.
Micro USB cable
Power adapter
Tablet PC SN1AW72 (HSG1297) Adapter head
NOTE:
• The included adapter head may vary depending on the region.
• The illustrations in this document may appear differently from your model.

7
English
1. Product Overview
1.1 Front View
No. Item Description
1Touch Screen Displays the user interface and receives touch input.
2 Volume Keys Press to adjust the volume.
3Power Key • Press and hold to turn the device on or off.
• Press to turn the backlight on / off and put the device into
sleep mode.
4 Front Camera For video chatting or taking self-portrait pictures.
About the Power key:
•Power on: Press and hold the key for 2~3 seconds until the device is turned on.
•Power off: Press and hold the key until the option menu appears on the screen. Select Power off and tap
OK to turn the device off.
•Reset: Press the RESET button and the device will power off automatically. Then press and hold the
POWER button for at least 3 seconds to turn the device on.
4321

8
English
1.2 Back View
1.3 How to remove the SD & SIM card cover
Locate the cover (as shown in the figure) and gently lift to disengage the cover from the main unit.
Then move your finger in the direction of the arrow until all buckles are released.
To prevent damage to the cover and the narrow edge, do not use excessive force when removing
the card cover.
Remove the cover to insert the SIM and SD cards.
No. Item Description
1Rear Camera For taking pictures or recording videos.
2 Micro USB Port Connects to a PC using the supplied USB cable.
3Earphone Jack Connects to an earphone using a 3.5 mm audio jack.
4 MicroSD/SIM Card Slot
Cover
Remove the cover to access the microSD and SIM cards
slots.
5Speakers Emits sound output.
5
1
2
3
4

9
English
2. Initial Operation
2.1 Managing and Charging the Battery
Before using the tablet PC for the first time, fully charge the battery. This tablet PC has a
built-in polymer battery; use only the dedicated charger to charge the device.
In order to prolong the service life of the device, use the device until the battery is depleted before
charging the battery the first two times.
To charge the battery, connect the charger / adapter to the device and the DC jack.
When the device is not in use, be sure to turn off the device.
If the device will not be used for a long time, be sure to discharge and then charge the battery once
a month.
The built-in polymer battery must be recharged regularly. Battery damage caused by depletion or by
the use of an unauthorized charger are not covered by the warranty.
NOTE:
• For the first two times of charging the battery, the charging time may take up to 10 hours; succeeding times
may take up to 5 hours.
• During charging, the battery icon on the screen will scroll.
• When charging is complete, the battery icon will turn blue and stop scrolling.
• When you plug in the charger after the device shuts down due to low power, it may take a while before the
system enters the Home screen.

10
English
2.2 Connecting to the Wi-Fi Network
A Wi-Fi connection makes it easy to connect to the Internet. Once you have successfully connected
to a Wi-Fi network, the device will automatically connect to the network when you are within range.
To configure the Wi-Fi connection, do the following:
1. Tap and drag the status bar downward to open the notification panel.
2. On the Quick Settings screen, tap SETTINGS.
3. Turn on Wi-Fi. The device searches for available networks within range and displays the
searched Access Point (AP) names on the right panel.
4. Tap an access point name that you want to connect to. If the selected access point is
protected by a password, the device will prompt for the password.
5. If prompted, enter the password to connect to the AP.
6. Tap Connect.
NOTE:
Tap the Wi-Fi switch button to turn Wi-Fi on or off.
• The Wi-Fi icon showing indicates Wi-Fi is turned off.
• The Wi-Fi icon showing indicates Wi-Fi is turned on.
NOTE:
• The password entry is required only when connecting to the AP for the first time.
• To make the Wi-Fi password visible while typing it, select the “Show password” checkbox.
NOTE:
• Some public places offer free wireless internet access. This means no password is required to establish
the connection.
• For secured networks, you may need to enter several parameters to complete the settings. If you are not
sure about the parameters, please contact your local Internet Service Provider (ISP).
• This tablet PC keeps track and recognizes Wi-Fi networks that have been connected before. Once Wi-Fi is
turned on and a known connection is detected, the device automatically connects to that network.

11
English
2.3 Connecting PC and Data Transmission
Use the supplied USB cable, connect the device to the PC to transfer data or power up the device.
To enter the USB disk mode to copy and delete files to and from the PC, do the following:
1. When the operation menu appears, tap “USB connected”: Tap “Turn on USB storage” on the
prompting window, then enter the data transmission state.
2. Locate the tablet storage card and SD card (if the card has been plugged in) in My
Computer list.
3. After data transmission, tap “Turn off USB storage”, and then it will quit the data
transmission state.
2.4 Use Micro SD card
After connecting the device to a PC, you will find two removable disks, the front one is the
built-in-memory disk, the other one is the Micro SD card disk. If there is no card plugged in, the
second disk cannot be opened. The device supports up to 32GB Micro SD card expansion.
Plug-in: insert the memory card with the side with prints facing to the front of the device. Push the
memory card into the card slot until it is firmly seated. Now the device can access the data and play
the files stored on the card.
Plug-out: push Micro SD card slightly inward to release it from the slot. Then gently pull it out of the
card slot.
NOTE: USB charging only supports 500mA. If the battery power is lower than 4%, the device cannot be turned
on.
NOTE: Before quitting the state of data transmission, please safety remove them from the PC, otherwise the
file may be missing.

12
English
3. The Android Interface
3.1 Home Screen
After powering on the device, the locked Home screen is displayed. After you unlock the screen, the
main Home screen appears.
The following describes the main touch screen area and some tips on how to use the touch screen.
Item Description
Status Bar Display notifications and system icons such as Wi-Fi connection
status, battery power/ battery charging status, current time, and
USB connection status.
Widget (Google Search) Enter the text you want to search in the search box.
Default AndroidTM
applications
Tap an icon to open the corresponding application.
All APPs button ( ) Tap to reveal all AndroidTM applications and widgets installed
on your Tablet PC.
• To create shortcuts on the Home screen, refer to “Managing
Applications” on page 13.
• To install other application, search and download it from
Play Store.
Status Bar
Navigation BarAll APPs button
Widget
Default Android
(Google Search)
applications
TM

13
English
3.2 Extended Home Screen
You can navigate between different Home screen panels by swiping your finger to the left or right.
Tap to return to the main Home screen.
3.3 Customizing the Home Screen Panels
You can customize the wallpaper of your Home screen with the default wallpaper or with the photos
stored in the device. Long press the touch-screen, the Wallpaper option menu will appear on the
screen. Then choose the desired option from the list.
3.4 Managing Applications
•Add application shortcuts: Long press an application icon from the application menu and then
drag the icon to the Home screen to add as shortcut.
•Moving application shortcuts: Long press an application icon in the Home screen until the
positioning gridlines appear. Then drag the icon to the desired location and release your finger.
•Remove application shortcuts: Long press an application icon in the Home screen, the top of
the screen displays . Drag the application icon towards until it turns red, and then release
your finger to remove the application shortcut.
Navigation
Bar
Back key
()
Tap to return to the previous screen.
Home key
()
Tap to return to the Home screen.
Shortcut key
()
Tap to view the most-recently accessed applications.
• To access the specific application, tap directly on the icon.
• To remove a thumbnail from the list, swipe the icon upward
or downward.
Screenshot key
()
Tap to capture the snapshot of the current screen.
Item Description

14
English
3.5 Creating Application Folders
You can combine several similar applications in a folder. Simply, drag one application icon over
another application icon and release it. A folder is automatically created.

15
English
4. System Firmware Update
Android devices automatically receive over-the-air (OTA) updates. To manually check for a firmware
update, select Settings > About tablet > Wireless Update.
4.1 SIM Management
4.1.1 Voice call
Click settings in main menu, choose SIM Management, as Picture 4.1
Picture 4.1
Click voice call, choose defaulted SIM card, as Picture 4.2
Picture 4.2

16
English
4.1.2 Video Call
Click settings in main menu, choose SIM Management, and click video call, choose defaulted SIM
card when makes video call, as Picture 4.3
Picture 4.3
4.1.3 Message
Click settings in main menu, choose SIM Management, click message, choose the defaulted SIM
card when sends message, as Picture 4.4
Picture 4.4
4.1.4 Data Connection
Click setting application in main menu, choose SIM management, click data connection, choose the
defaulted SIM card, as Picture 4.5
Picture 4.5

17
English
5. Product Specifications
Platform
Operating System Android 4.4x
Processor Quadcore 1.3G cortex-A7
Memory 1 GB
Storage Storage 8 GB EMMC
Display
Brightness LCD Panel with LED backlight, 210 cd/m2
Resolution 10.1 inch, 1280x800
Type Capacitive type
Sensor (points) Multi touch
Communications
WLAN WLAN(802.11 b/g/n)
Bluetooth BT4.0
Camera Front camera: 2MP
Rear camera: 5MP (AF)
Sensor
3 axis Accelerometer Yes, Supported x/y/z axis and +/- direction
G Sensor Yes, resolution: 10 bits
I/O Port
DC power port DC Jack in x1
Headphones 3.5mm x1
Microphone Built-in
USB 2.0 Micro USB 2.0 x1 (OTG), Supported USB K/B, Mouse,
USB flash disk, 2.5" HDD, battery charging function
Card reader Micro SD x1, Max. supported 32GB
SIM card slot SIM x 2
Speakers output spec. 8ohm, 1W x2
HW button
Power Yes
Volume Yes
Power
Battery 3.7V Li-Polymer, 6000mAh
Operation Battery Life >= 5 hours @ 720p Videp playback, WiFi off, WebCam
off, brightness 60%, Volume 50%
Battery Operating
Temperature
Standard charge: 0~450C
Discharge: 0~550C
Adaptor AC 100V~240V , DC 5V/2.0A
Dimension Dimension(W*D*H mm) 259.5mm x 162.3mm x 10.0mm

18
English
6. Appendix
Warranty and Service
Warranty and service and related information, please refer to, the warranty card or Hannspree
support site below for further help and support with your device including how to install software
updates if available and much more:
http://www.hannspree.com/
FAQ
FAQ (Frequent Asked Questions) please refer to the below link:
http://www.hannspree.com/
Resetting Your Device to Factory Defaults
If you need to reset your device to the factory default settings for any reason please follow the
process below:
WARNING!!!
Please be aware any information currently on the device will be permanently erased by following
this procedure.
1. From the Home screen, tap Settings.
2. Tap Backup & Reset.
3. Select Factory data reset.
4. Leave the erase SD card option unchecked and tap Reset tablet.
5. Tap erase everything.
The unit will now reset itself back to factory reset and any previous information/data will have
been permanently erased.
NOTE: Some of the applications downloaded from Play Store or produced by other third party are not fully
supported on this device.
